Snapper RD1840, RD18S40 User manual

Parts Manual fo
r
Revision IR,
YARD TRACTOR ELECTRIC CLUTCH
SERIES 0
COPYRIGHT
©
2005
McDonough, GA, 30253 U.S.A.
TP 400-5064-IR-TC-N
6/7/2005 Manual No. 06457
SNAPPER PRODUCTS, INC.
ALL RIGHTS RESERVED.
HYDRO DRIVE REAR DISCHARGE RMO
MODEL
RD1840
(
2690342
)
RD18S40
(
2690341
)

Table Of Content
s
TP 400-5064-IR-TC-N
Manual No. 06457YARD TRACTOR ELECTRIC CLUTCH
SERIES 0 3
PAGE GROUP
4Wheels & Tires Group
6Hood, Grille & Dash Group
8Steering Group
10 Frame & Front Axle Group
14 Controls Group
18 Cruise Control Group
20 Transmission Group - Tuff Torq K-46BF
24 Seat Deck & Fuel Tank Group
26 Engine Group - 18 HP INTEK Single Cyl.
28 Engine Group - 18 HP & 20 HP VANGUARD Twin Cyl.
30 Lift Group
32 40" Mower Deck - Belt, Idle Arm & Hitch
34 40" Mower Deck - Housing, Arbors & Blade
36 40" Mower Deck - Height Adjustment & Roller Bar
40 Deflector Group
42 Hopper Group
46 Decals Group
48 Electrical Group

Wheels & Tires Group
TP 400-5064-IR-TC-N
Manual No. 06457 YARD TRACTOR ELECTRIC CLUTCH
SERIES 0
4

Wheels & Tires Group
Footnotes:
TP 400-5064-IR-TC-N
Manual No. 06457YARD TRACTOR ELECTRIC CLUTCH
SERIES 0 5
Part No Descri
p
tionItem Qt
y
Note
1 1722065 2 WHEEL & TIRE ASSEMBLY, Front, (Includes Ref. Nos. 2, 3, 4, 5
2 1722838 1 TIRE, 15 x 6, Super Turf
3 1664090 1 TUBE, Tire, Front, 4.10/3.50
4 1717056 2 BEARING, Ball
5 1722837 1 WHEEL, 4-1/2” x 6”
6 2172353 4 VALVE STEM & CAP ASSEMBLY
7 1722726 4 WASHER, Special, (As Required)
8 1919394 4 WASHER, 1, (As Required)
9 2932577 2 RING, Retaining, External #98
10 1722676 4 CAP, Hub, Gray
11 1729279 2 KEY, Parellel, 3/16 x 3/16 x 1-1/2
12 2960202 4 WASHER, 3/4
13 1709527 2 SPACER
14 1721694 2 WHEEL & TIRE ASSEMBLY, (Includes Ref. Nos. 6, 15, 16 & 17)
15 1722826 1 TIRE, 20 x 10, 8 Super Turf
16 2173477 1 TUBE, Tire, 20 x 8, Rear
17 1722835 1 WHEEL, 7 x 7.96, W/ 3/4 OD Shaft
18 1722717 2 WASHER, Special
19 1960114 2 WASHER, 3/4
20 2927794 2 RING, “E” External

Hood, Grille & Dash Group
TP 400-5064-IR-TC-N
Manual No. 06457 YARD TRACTOR ELECTRIC CLUTCH
SERIES 0
6

Hood, Grille & Dash Group
Footnotes:
TP 400-5064-IR-TC-N
Manual No. 06457YARD TRACTOR ELECTRIC CLUTCH
SERIES 0 7
Part No Descri
p
tionItem Qt
y
Note
1 1721804 1 PANEL, RH Side
1 1721804D 1 PANEL, RH Side, Red
2 1721801 1 HOOD, no Louvers
2 1721801D 1 HOOD, no Louvers, Red
3 1722110 1 HOOD, with Louvers
3 1722110D 1 HOOD, with Louvers, Red
4 1960295 12 CAPSCREW, Hex Head Flange Lock,1/4-20 x 5/8
5 1960392 1 SCREW, Phillips Head, #10-24 x 1/2
6 1687056 1 DASHBOARD, RMO with Buzzer Hole, Black
7 1933896 1 NUT, Hex Nylock,#10-24
8 1723123 1 ROD, Dash Support
9 1930641 12 NUT, Hex Flange Lock, 1/4-20
10 1721803 1 PANEL, LH Side
10 1721803D 1 PANEL, LH Side, Red
11 1721808 1 HINGE, LH
12 1722391 1 DUCT, Air Inlet
13 1721802 1 GRILLE
13 1721802D 1 GRILLE, Red
14 1721810 1 HEADLIGHT ASSEMBLY, (Includes Ref. Nos. 15 & 16)
15 1677371 4 BULB, Headligh
16 1723451 4 SOCKET, Headlight
17 1721809 1 HINGE, RH

Steering Group
TP 400-5064-IR-TC-N
Manual No. 06457 YARD TRACTOR ELECTRIC CLUTCH
SERIES 0
8

Steering Group
Footnotes:
TP 400-5064-IR-TC-N
Manual No. 06457YARD TRACTOR ELECTRIC CLUTCH
SERIES 0 9
Part No Descri
p
tionItem Qt
y
Note
1 1722318 1 STEERING WHEEL, Straight Shaft
2 1725024 1 CAP, Steering Wheel, Plain
3 1960540 1 PIN, Spring
4 1722749 1 COVER, Black Rubber
5 2176440 2 BUSHING
6 1721736 1 PLATE, Mounting Steering
7 1960114 6 WASHER
8 1933260 2 CAPSCREW, Hex Head Flange Lock, 3/8-16 x 3/4
9 1931211 2 NUT, Hex Whiz Lock, 3/8-16
10 1722459 1 BEARING, Flange
11 1722461 1 SPACER
12 1724470 1 GEAR & SHAFT ASSEMBLY
13 1960032 1 CAPSCREW, Hex Head, 3/8-16 x 1-1/4
14 1930645 1 NUT, Hex Flange Lock, 3/8-16
15 1664847 2 CAPSCREW, Hex Head Taptite, 5/16-18 x 3/4
16 1723604 1 SHAFT ASSEMBLY
17 1919314 1 PIN, Cotter
18 1931317 2 CARRIAGE BOLT, 1/4-20 x 3/4
19 2928372 2 NUT, Hex,1/4-20
20 1611710 1 RING, Clipring Extension
21 1960114 2 WASHER

Frame & Front Axle Group
TP 400-5064-IR-TC-N
Manual No. 06457 YARD TRACTOR ELECTRIC CLUTCH
SERIES 0
10

Frame & Front Axle Group
Footnotes:
TP 400-5064-IR-TC-N
Manual No. 06457YARD TRACTOR ELECTRIC CLUTCH
SERIES 0 11
Part No Descri
p
tionItem Qt
y
Note
1 1930645 7 NUT, Hex Flange Lock, 3/8-16
2 1960035 2 WASHER
3 2960646 1 NUT, Hex Flange, 5/8-11
4 1722212 1 PLATE, Axle
5 1724081 1 TOWER & SUPPORT ASSEMBLY
6 1923683 4 CAPSCREW, Hex Head Taptite, 3/8-16 x 3/4
7 1723528 1 SUPPORT
8 1664847 4 CAPSCREW, Hex Head Taptite, 5/16-18 x 3/4
9 1727396 1 FRAME ASSEMBLY
10 2960645 1 CAPSCREW, 5/8-11 x 3-1/2
11 1704314 2 FITTING, Grease for Wear Plate, 1/4-20, with Ball
12 1933260 4 CAPSCREW, Hex Head, Flange Lock, 3/8-16 x 3/4
13 1722541 1 LINK, Drag
14 1922755 1 WASHER
15 1960103 2 WASHER
16 1919262 1 NUT, Hex Jam, 1/2-20
17 1702779 1 JOINT, Ball
18 1708236 1 SPACER
19 1931350 2 CARRIAGE BOLT, 3/8-16 x 1
20 1611705 2 SPACER
21 1722626 1 ROD, Tie
22 1721682 6 BUSHING
23 1930650 2 NUT, Hex Flange Lock, 7/16-14
24 1704314 3 FITTING, Lube
25 1686985 1 SPINDLE REPLACEMENT KIT, LH (Includes Ref. Nos. 22, 26,
27,
26 2823485 1 CAPSCREW, 3/8-16 x 7/8, GR8
27 1663151 1 WASHER, Spring, 3/8
28 1725112 1 HUB & ARM ASSEMBLY
29 2830671 1 KEY, Woodruff
30 1724264 1 SPINDLE, LH
31 1722200 1 AXLE ASSEMBLY, w/ LH Spindle, Complete (Includes Ref. Nos.
2
32 1931352 1 CARRIAGE BOLT, 3/8-16 x 1-1/2
33 1927531 2 CAPSCREW, Hex Head, 7/16-14 x 2, GR8
34 1721918 1 HOOK, “J”
35 1721752 1 SPACER
36 1960086 4 SCREW, Torx Head, 5/16-18 x 7/8
37 1721805 1 BUMPER, Black, Steel, Standard

Frame & Front Axle Group
TP 400-5064-IR-TC-N
Manual No. 06457 YARD TRACTOR ELECTRIC CLUTCH
SERIES 0
12

Frame & Front Axle Group
Footnotes:
TP 400-5064-IR-TC-N
Manual No. 06457YARD TRACTOR ELECTRIC CLUTCH
SERIES 0 13
Part No Descri
p
tionItem Qt
y
Note
37 1723502 1 BUMPER, Chrome, Optional
38 1930591 2 CAPSCREW, Hex Whiz Lock, 5/16-18 x 3/4
39 1724801 1 PLATE, Axle Wear
40 1931277 2 NUT, Hex Falnge Whiz Lock, 5/16-18
41 1722199 1 SPINDLE, RH
42 1919394 1 WASHER
43 2932577 1 RETAINING RING

Controls Group
TP 400-5064-IR-TC-N
Manual No. 06457 YARD TRACTOR ELECTRIC CLUTCH
SERIES 0
14

Controls Group
Footnotes:
TP 400-5064-IR-TC-N
Manual No. 06457YARD TRACTOR ELECTRIC CLUTCH
SERIES 0 15
Part No Descri
p
tionItem Qt
y
Note
1 1721353 1 ROD, Brake
2 1721891 1 KNOB, Push On, Red
3 1930591 1 CAPSCREW, Hex Head Flange Lock, 5/16-18 x 3/4
4 1960687 3 NUT, Hex Flange, 3/8-16 ESNA
5 1721134 1 PULLEY ASSEMBLY, 3 OD, W/Bearing
6 1667811 2 SPACER
7 1922755 3 WASHER, 3/8
8 1710545 1 PULLEY, Idler 4 OD
9 1960315 2 CARRIAGE BOLT, 3/8-16 x 2 G5
10 1663114 2 BUSHING
11 1727370 1 ARM & HUB ASSEMBLY, Idler
12 1727910 1 SPRING, Extension
13 1960020 1 WASHER, 5/8
14 1924366 1 WASHER, 5/8
15 1704420 1 RING, Clipring
16 1704314 1 FITTING, Lube, 1/4 Ball Check
17 1710539 1 PULLEY, Idler 3-1/4 OD
18 1960315 1 CARRIAGE BOLT, 3/8-16 x 2 G5
19 1918447 1 PIN, Cotter
20 1924940 1 WASHER
21 1727408 1 ROD, Brake (Flat Ends)
22 1722460 1 PIN, Quick
23 1919326 1 WASHER
24 1721354 1 LATCH, Brake
25 1726763 1 CONTROL ASSEMBLY, Foot Pedal
26 1721995 1 SPRING, Extension
27 1686612 1 CAM, Roller
28 1920397 1 NUT, Hex Lock ESNA, 1/4-20
29 1960636 4 NUT, Hex KEPS, 5/16-18
30 1931320 1 CARRIAGE BOLT, 1/4-20 x 1-1/4
31 1664847 3 CAPSCREW, Hex head Washer Taptite, 5/16-18 x 3/4
32 1919381 1 WASHER
33 1919438 1 NUT, Hex Lock ESNA, 5/16-18
34 1927557 3 NUT, Hex Flange Lock, 5/16-18
35 1722535 1 PEDAL, Brake
36 1721577 1 PAD, Brake Pedal
37 1931334 4 CARRIAGE BOLT, 5/16-18 x 7/8

Controls Group
TP 400-5064-IR-TC-N
Manual No. 06457 YARD TRACTOR ELECTRIC CLUTCH
SERIES 0
16

Controls Group
Footnotes:
TP 400-5064-IR-TC-N
Manual No. 06457YARD TRACTOR ELECTRIC CLUTCH
SERIES 0 17
Part No Descri
p
tionItem Qt
y
Note
38 1722083 1 ACTUATOR, Switch
39 1921333 3 CAPSCREW, Hex Head, 5/16-18 x 1
40 1722070 1 PEDAL, Forward
41 1721675 1 PAD, Foot Pedal Forward
42 1721674 1 PAD, Foot Pedal Reverse
43 1722071 1 PEDAL, Reverse

Cruise Control Group
TP 400-5064-IR-TC-N
Manual No. 06457 YARD TRACTOR ELECTRIC CLUTCH
SERIES 0
18

Cruise Control Group
Footnotes:
TP 400-5064-IR-TC-N
Manual No. 06457YARD TRACTOR ELECTRIC CLUTCH
SERIES 0 19
Part No Descri
p
tionItem Qt
y
Note
1 1960666 1 CAPSCREW, Torx Socket Head, 1/4-20 x 7/8
2 1722303 1 KNOB, Cruise
3 1920397 1 NUT, Hex ESNA Lock, 1/4-20
4 1723258 1 LEVER & BRACKET ASSEMBLY, Cruise
5 1960103 3 WASHER
6 1931333 1 CARRIAGE BOLT, 5/16-18 x 3/4
7 926192 2 WASHER, 9/16 x 1-1/4 x 1/8
8 1709043 1 SPACER
9 1931342 1 CARRIAGE BOLT, 5/16-18 x 2-3/4
10 1960273 1 CARRIAGE BOLT, 5/16-18 x 2-1/4
11 1918447 2 PIN, Cotter
12 1726059 1 ROD, Cruise
13 1960636 2 NUT, Hex KEPS, 5/16-18
14 1960001 2 CAPSCREW, Hex Head Plastite, 10-14 x 5/8
15 1717050 1 SWITCH, Push, Neutral Start, Gray
16 1722080 1 SPACER
17 1919326 1 WASHER
18 1919381 2 WASHER
19 1919438 1 NUT, Hex ESNA Lock, 5/16-18
20 1677746 1 SPRING, Compression
21 1722460 2 PIN, Quick
22 1723099 1 ROD, Cruise Return

Transmission Group - Tuff Torq K-46BF
TP 400-5064-IR-TC-N
Manual No. 06457 YARD TRACTOR ELECTRIC CLUTCH
SERIES 0
20
