Snapper 01666-1 Setup guide

G1000
Questions? Help is just a moment away!
Preguntas? La ayuda es justa un momento lejos!
Call: Generator Helpline - 1-800-317-7833 M-F 8-5 CT
Llamada: Generador Helpline - 1-800-317-7833 M-F 8-5 CT
BRIGGS & STRATTON POWER PRODUCTS GROUP, LLC
JEFFERSON,WISCONSIN, U.S.A.
Snapper™ is a licensed trademark of Briggs & Stratton Power Products.
Snapper™ se usa abajo licencia a Briggs & Stratton Power Products.
Illustrated Parts List
Model No. 01666-1 (1000 Watt AC Generator) Manual No. 196735A Revision 0 (02/07/2005)

G1000 Portable Generator
2
EXPLODED VIEW AND PARTS LIST – MAIN UNIT
Item Part # Description
1 § ENG, 2.4HP (050032-0113-E1)
2 187378GS ROTOR
3 187411GS BRG
4 187379GS STATOR
5 187430GS LEAD, GREEN
6 187409GS BUSHING, LEAD WIRE, G790B
7 187381GS RBC, 1K
8 187399GS SCREW, SELF TAP, M6-12
9 187382GS FAN, COOLING
10 187388GS BOLT, RTR
11 187389GS BOLT, STATOR
12 187405GS INSLTN, HEAT SEALED, #1
13 187384GS MFFLR, SEALED
14 187407GS INSLTN, HEAT SEALED, #2
15 187403GS DUCT,AIR
Item Part # Description
16 187392GS PHMS, M6-1.0,W/L/FW
17 187383GS BASE, GEN
18 187390GS BOLT, FLNG, M6-1.0 X 10
19 187385GS MNT,VIBR
20 187427GS HHCS, FLNG, M8-1.25 X 12
21 187424GS NUT,WING, M5 X 0.8
22 187423GS NUT, M5 X 0.8
23 187419GS WSHR, LOCK
24 187420GS WSHR, FLAT
25 187401GS NUT, M8-1.25, FLANGE
26 187415GS PHMS, M5-0.8 X 20
27 187413GS CNNCTR
28 187434GS HHCS, FLNG
29 187431GS STND, ENG
§ - Contact Engine Manufacturer

G1000 Portable Generator
3
Item Part # Description
1 187436GS CAP, FUEL
2 187439GS PACKING,TANK
3 187438GS FLTR, FUEL
4 187769GS U-PACKING
5 187437GS TANK, FUEL, 4.5L
6 187766GS DECAL, CHOKE
7 187756GS BOLT, COVER (M5-16)
8 187832GS HSG, GEN, MFFLR
9 190200GS DECAL,WARNING
10 187772GS COVER, SPARK PLUG
11 187757GS BOLT, COVER (M6-16)
12 187760GS PHMS, M4-12 W/FW
13 187435GS CVR, MFFLR, GEN
14 187775GS BOLT, MFFLR CVR (M6-16)
15 187768GS DECAL CAUTION HOT
16 187774GS BOLT, COVER (M6-20)
17 187761GS NUT, M4X0.6 W/FW
18 187463GS INSLTN, MFFLR
19 187833GS HSG, GEN
20 NSP DECAL, EMISSIONS
21 187457GS CONDENSER, 300V
22 187765GS DECAL, CAUTION FUEL
23 187759GS BOLT, COVER (M5-10)
24 187462GS DIODE, BRIDGE
26 190089GS DECAL, GEN, SNAPPER
Item Part # Description
27 187773GS COVER, OIL FILL
28 196624GS CB, DC
29 196623GS CB, 8A, 125V
30 187873GS OUTLET,ACCESSORY DC
31 187450GS SWITCH, ENG, ON/OFF
32 187812GS CPNL
33 187456GS RECPTCL, 15A, 125V
34 187763GS DECAL, CAUTION OIL
35 187876GS CABLE, BATTERY CHARGE
36 190201GS DECAL, MODEL
37 187764GS DECAL, FUEL SHUTOFF
38 187447GS INSLTN, HTSHLD,TANK #1
39 187448GS INSLTN, HTSHLD,TANK #2
40 187442GS BRKT,TANK, FUEL
41 187758GS BRKT, FUEL COCK
42 187443GS COCK, FUEL
43 187770GS PHMS, M5-10 W/FW
44 187579GS CLIP, FUEL HOSE
45 187440GS FLTR, FUEL
46 187578GS HOSE, FUEL
Items Not Illustrated
BB3061BGS BOTTLE, Oil
196735GS MANUAL, Owners
MS6669 MANUAL, Engine
EXPLODED VIEW AND PARTS LIST – MAIN UNIT
