SNC LYTE LYNX P30112 Operating and installation instructions

6- Slot Card Shelf
Description & Installation
P30112
Print ed in USA – 09/ 11 TO395 Rev. E

Table of Content s
Page
1. 0 PRODUCT SCOPE 2
2. 0 PRODUCT OVERVIEW 2
2. 1 Int ended Uses 2
2. 2 Syst em Requirement s 2
2. 3 Part s List 2
2. 4 Physical Charact erist ics 2
3. 0 PRODUCT FEATURES 3
3. 1 Isolat ion Card Slot s 3
3. 2 Powering 3
4. 0 INSTALLATION 3
4. 1 Card Shelf Mount ing 4
5. 0 INSTALLATION – STATION SIDE CONNECTIONS 4
5. 1 St at ion Side Cable Pair Ent rance 4
Figure 1: St at ion Side Upper Backpl ane 5
5. 2 St at ion Side Pair Designat ions 5
5. 3 St at ion Power/ Ground Connect ions 6
Figure 2: St at ion Connect ors 6
Figure 3: Connect ing 24V Ext ernal Power Supply 8
Figure 4: Connect ing 48V Ext ernal Power Supply 8
6. 0 INSTALLATION – CO/ REMOTE SIDE CONNECTIONS 9
6. 1 Remot e Side Cable Pair Ent rance 9
Figure 5: Remot e Side Terminal Blocks 10
6. 2 Remot e Side Pair Designat ions 10
6. 3 Remot e Ground 11
6.4 Circuit s Requiring 2 or 3 Isol at ion Cards 11
7. 0 TROUBLE SHOOTING 12
8. 0 PIN OUT DIAGRAMS 13
Figure 6: St at ion & Remot e Back Plane 13
Page 1

1. 0 PRODUCT SCOPE
This document describes t he t echnical specif icat ions, t echnical requirement s and inst all at ion
inst ruct ions for t he P30112 SNC Lyt e Lynx® 6-Slot Card Shel f. It provides an underst anding of
t he basic funct ions and feat ures avail able wit h t his product .
2. 0 PRODUCT OVERVIEW
2. 1 Int ended Uses
The 6-slot Card Shel f provides an isolat ed int erf ace f or voice (POTS), analog dat a and
digit al circuit s, depending on t he isol at ion cards t hat are insert ed int o t he Card Shel f.
The primary funct ion of t he Card Shelf is t o provide a convenient connect ion locat ion
or housing in which isol at ion cards can be insert ed “ t ransparent l y” int o t he circuit .
This product present s a very small foot print , making it ideal for inst allat ions where
space is at a premium and onl y four or six circuit s are required.
Lyt e Lynx® syst ems are int ended f or use at power subst at ions and similar locat ions
where high volt age isolat ion is required on t he incoming copper t elephone pairs to
prot ect t he t elco net work from harm and to provide a personnel saf et y barrier against
volt ages. This specif ically incl udes prot ect ion f rom longit udinal vol t age surges and
Ground Pot ent ial Rise (GPR) t hat may occur during power syst em f aul t s.
2. 2 Syst em Requirement s
Print ed circuit boards designed for inst allat ion in t he SNC Lyt e Lynx® 12-Slot , 6-sl ot
and 3-Slot Card Shelves or Tel eline Isolat or* 8-Slot Card Shelf may be used. A 24VDC,
48VDC, 130VDC or 120VAC power source from t he subst at ion is required whenever
fiber opt ic or ot her act ive elect ronic PC isolat ion cards are t o be used.
2. 3 Part s List
QTY Descript ion
2 5/ 16” X 1 1/ 2” Lag Bol t s
3 18 pin t erminal blocks marked RM1, RM2, RM3
1 ¾” inch male adapt er f or (CO) remot e side
3 18 pin t erminal blocks marked ST1, ST2, ST3
1 1/ 2” inch male st rain rel ief for st at ion side
1 6 Foot A/ C Power Cord
1 Descript ion/ Inst all at ion Inst ruct ion Manual T0395
2. 4 Physical Charact erist ics
2. 4.1 Mechanical Configurat ion
The P30112 Card Shelf is const ruct ed of a high diel ect ric mat erial t hat meet s
Underwrit ers Laborat ories St andard 94V-0 flammabilit y t est .
2. 4.2 Environment al Requirement s
The Lyt e Lynx® syst em is designed f or an indoor environment and is operable in
t emperat ures ranging from –40฀C to 100฀C (–40฀F to 212฀F) under humidity conditions
from 0–99 percent . (Requirement s f or individual cards may vary. )
* Teleline Isolat or is a t rademark of Posit ron Indust ries, Inc.
Page 2

2. 4. 3 Physical Dimensions
Table 1
P30112 Height
Width Depth
CARD SHELF
WITH COVER
13.13”
(33 cm)
17.13”
(43.5 cm)
9. 75”
(25 cm)
3. 0 PRODUCT FEATURES
3. 1 Isolat ion Card Slot s
The P30112 Card Shelf cont ains six (6) isolat ion card slot s. Slot s 1 t hrough 6 are used
for any combinat ion of Lyt e Lynx® isolat ion cards and can t erminat e a t ot al of 12
t elephone pairs (t wo pairs per slot ). Any combinat ion of t wo-wire or four-wire service
can be configured. Card slot no. 1 (J1) has pairs one and t wo of remot e ent rance cable
and t he st at ion ent rance cable t erminat ed as “ odd” or “ even. ” Sl ot 2 (J2) has pairs
t hree and four, et c. The pair color order f or t he remot e cable is t hat of st andard 25
pair exchange cable (i.e. , pair one=blue/ whit e, pair t wo=orange/ whit e, et c.). The
pair color order for t he st at ion cabl e is t hat of st andard 25 pair “ inside wiring” cable
(i.e. , pair one = Whit e/ Bl ue and Blue/ Whit e; pair t wo = Whit e/ Orange and
Orange/ Whit e, et c. See Tabl e 2 and 4.
3. 2 Powering
The subst at ion side of most SNC Lyt e Lynx® and Tel eline Isolat or* fiber opt ic isol at ion
cards requires a supply of -24VDC or -48VDC power t o operat e. Float ed 48VDC or
130VDC bat t ery and 120VAC power is commonl y available at most power subst at ions.
Various Lyt e Lynx® int ernal power supply cards are availabl e (See Tabl e 3) t o convert
t he chosen power source t o -24VDC or -48VDC t o power up t he el ect ronic circuit ries on
act ive isolat ion cards. The -24VDC or -48VDC is made available to each isol at ion card
sl ot by means of t he upper, st at ion side backplane plug-in connectors.
The power suppl y and some isolat ion cards may be powered by f loat ed 48VDC, 130VDC
or 120VAC power. It will accept any t wo of t hese power sources at one t ime (one as
primary power and anot her as secondary act ive backup power) t o provide cont inuous
operat ion in t he event of a power suppl y card f ail ure or power out age. If only one
power source is used, a 24VDC bat t ery backup module may be used.
4. 0 Inst allat ion
* Teleline Isolat or is a t rademark of Posit ron Indust ries, Inc.
Page 3
CAUTION:
The incoming t elephone pair should be cont ained in insulat ed
conduit (PVC, et c. ), or t he pair should be j acket ed wit h suf ficient insul at ion
t o wit hst and a vol t age rise from ground fault pot ent ial and f rom f ault
induct ion vol t age.

Tools required for P30112 Card Shelf inst allat ion incl ude:
· Tape Measure · Screwdriver, 1/ 8" Blade · 7/ 16" Wrench or Socket
· Cent er Punch · 1/ 8" Drill Bit · Drill · Hammer
4. 1 Card Shel f Mount ing
(a) Det ermine t he locat ion for t he Card Shel f, l eaving room t o t he l ef t or below t he
shel f for a light ning arrest er, if required. The shelf should be mount ed t o a 3/ 4"
t hick plywood wall (or equivalent ).
(b) Mark t he locat ion for t he lag bolt s. Two keyhole cut out s dist anced on 8" cent ers
are provided in t he back wall of t he Card Shelf.
(c ) Cent er punch locat ion and drill 1/ 8" pilot holes in wall at cent er punch marks.
(d) Mount t he Card Shelf t o t he wall using t he 5/ 16" lag bol t s (included).
5. 0 INSTALLATION – STATION SIDE CONNECTIONS
5. 1 St at ion Cable Pair Ent rance
(a) The upper right side of t he card shel f has a 1/ 2 inch–14 NPT t hreaded hole for t he
st rain relief . It is shown in t he Figure 2 bel ow as t he st at ion cable ent rance.
(b) Run cust omer side cable int o st at ions side ent rance of card shelf .
(c )St rip 1/ 4 inch from t he end of each wire.
(c) Secure t he wire pairs t o t he appropriat e 18-pin t erminal bl ocks marked ST1, ST2,
and ST3 by t ight ening t he screws wit h a small 1/ 8 inch bl ade screwdriver. See
Table 2 and Figure 1 f or appropriat e cable pair t erminat ion.
(e) Plug t he t hree t erminal blocks int o t he t hree, 18 posit ion, push-on connect or
blocks (ST1, ST2, ST3) locat ed in t he upper right hand corner of t he card shel f.
(i) Plug ST1 int o ST1 on st at ion side backplane.
(ii) Plug ST2 int o ST2 on st at ion side backplane.
(iii)Plug ST3 int o ST3 on st at ion side backplane.
(See Figure 1)
Page 4
CAUTION:
Any met all ic shielding on t he incoming CO/ Remot e pair must be
isol at ed from subst at ion grounds al l t he way from t he net work low volt age
int erf ace (300 vol t peak GPR point per IEEE St andard 487) t o t he ent ry int o
t he Card Shelf . The conduct ors must also be isolat ed.
CAUTION:
The Lyt e Lynx® Remot e/ CO t erminals and el ect ronics are isol at ed
from subst at ion ground. To provide personnel isolat ion f rom local ground,
st and on a t hick rubber mat and use ot her adequat e insul at ion devices (rubber
gloves) when working on t he Card Shelf .

5. 2 St at ion Side Pair Designat ions
Each of t he six (6) slot s will support t wo (2) pairs. The f irst pair is connect ed to t he
lef t side of t he backpl ane j acks and assigned a numeric designat ion (i.e. T1, R1, et c. ).
The second pair is connect ed t o t he right side of t he backpl ane j acks and is assigned
an alpha designat ion (i. e. TA, RA, et c.). (See Table 2 and Figure 4)
Page 5
ST3
J25 Power
Feed Jumper
ST1
ST2
F1
J27
S5 PRI/SEC
J28 LED Indicator
Figure 1:
St at ion Side (Upper) Backplane

Table 2: Station Side Pin Configurations
Station Side
SLOT # CONNECTOR COLOR – TIP PAIR COLOR – RING CONNECTOR
1 ST2-28 WHT/ BLU – T1 1 BLU/ WHT – R1 ST2-27
1 ST2-26 WHT/ ORN – TA 2 ORN/ WHT – RA ST2-25
2 ST2-24 WHT/ GRN – T2 3 GRN/ WHT – R2 ST2-23
2 ST2-22 WHT/ BRN – TB 4 BRN/ WHT – RB ST2-21
3 ST3-54 WHT/ SLT – T3 5 SLT/ WHT – R3 ST3-53
3 ST3-52 RED/ BLU – TC 6 BLU/ RED – RC ST3-51
4 ST3-50 RED/ ORN – T4 7 ORN/ RED – R4 ST3-49
4 ST3-48 RED/ GRN – TD 8 GRN/ RED – RD ST3-47
5 ST3-46 RED/ BRN – T5 9 BRN/ RED – R5 ST3-45
5 ST3-44 RED/ SLT – TE 10 SLT/ RED – RE ST3-43
6 ST3-42 BLK/ BLU – T6 11 BLU/ BLK – R6 ST3-41
6 ST3-40 BLK/ ORN – TF 12 ORN/ BLK – RF ST3-39
ST1-2 STA. GND. -24VD/ C ST1-1
ST2-20 (-) 48/ 130VDC (+) 48/ 130VDC ST2-19
5. 3 St at ion Power/ Ground Connect ions
Page 6
Figure 2: Station Connectors
Station
Cable
Entrance
120VAC
Input
Station
Ground
48VDC/130VDC
Floated Input
24/48V
Indicator
F
use Holder

External Connections
Just below t he st at ion cable ent rance is a cl ust er of four it ems. See Figure 2.
1) LED – The first of t hese it ems (f urt hest t o t he l eft ) is an LED t hat when lit indicat es
24VDC or 48 VDC GROUNDED power is availabl e at each slot in t he card shel f. If t he
LED is not l it , see Int ernal Connect ion Sect ion for proper j umper set t ing. If t he
alt ernat e powering of 48VDC FLOATING is chosen, t he LED wil l NOT light . If t he
LED is blinking, see Trouble Shoot ing sect ion.
2) 120VAC Input – Next t o t he LED is a male 120VAC recept acle t hat will accept t he
female end of a st andard IEC (inst rument / comput er-t ype) power cord (provided).
This AC recept acle feat ures a built -in 250V, 2 amp fuse. A spare f use is accessible
by pul ling out t he small drawer in right side of t he recept acle. Anot her 250V,
4 amp fuse in series wit h t his fuse is locat ed on t he PCB backplane. These fuses
may be swapped bef ore inst all at ion if t he card shelf is used in an applicat ion
where it is diff icult or impossible t o get access t o t he fuse compart ment on t he
side. The card shelf is shipped from the factory with this input terminal wired
as primary power.
3. BAT Input – The t hird it em f rom t he l ef t is a screw t erminal bl ock (“ BAT” ) for
connect ing DC Input (Floating Battery 130VDC or 48VDC Only). Connect posit ive
(+) bat t ery t o t he t op screw and negat ive (–) bat t ery t o t he bot t om screw. The card
shelf is shipped from the factory with this “ BAT” terminal wired as secondary
power, though S5 must be set to “Sec. Pwr” if this terminal is used.
4. St at ion Ground – The it em f urt hest t o t he right is a ground lug for connect ing a #6
AWG wire t hat can be used t o bring st at ion ground int o t he card shel f.
Internal Connections
Note:
IF INTERNAL POWER SUPPLY IS USED, NO INTERNAL CONNECTION IS
NECCESSARY.
LED Indicator Jumper J28
This j umper must be set t o appropriat e posit ion for t he LED t o be lit . If a 24V
power supply is used, t he j umper must be set t o 24V (def ault set t ing); if a 48V
power supply is used, t he j umper must be set t o 48V posit ion.
J27 Ground/ Float Setting
This j umper provides opt ional set t ing f or grounding t he card shelf t hrough t he AC
power cord. Note: The j umper is set t o FLOATED by f act or y.
Page 7
CAUTION:
All st at ion t erminal apparat us should be on t he same ground grid
as t he Card Shelf when t he st at ion ground is connect ed in t he Lyt e Lynx®
Card Shel f .

To bring external 24VDC into the card shelf:
A separat e wire can be brought into t he card shelf and connect ed direct ly t o
t he ST1-2 (GND) and ST1-1 (–24V) t erminal block posit ions. The LED indicat or
j umper J28 shoul d be set t o "24V” .
To Bring external 48VDC into the card shelf as GROUNDED 48VDC:
A separat e wire can be brought into t he card shelf and connect ed direct ly t o
t he ST1-2 (GND) and ST2-20 (-48V) t erminal block posit ions. The LED indicat or
j umper J28 must be set t o "48V” .
Page 8
Connect Negative (-) Terminal Here
Connect Positive (+) Terminal Here
Set Jumper J28 to 48V.
Figure 4:
Connect ing 48V Ext ernal Power Supply
Connect Positive (+) Terminal Here
Connect Negative (-) Terminal Here
Set Jumper J28 to 24V.
Figure 3:
Connect ing 24V Ext ernal Power Supply

Powering Cards Requiring Other Than 24/ 48VDC GROUNDED
Some isolat ion cards have special powering requirement s, i. e. 48VDC FLOATED,
130VDC FLOATED, or 120VAC.
o48VDC/ 130VDC FLOATING – Wit h t he bat t ery t erminals connect ed properl y as
described at t he above sect ion (5. 3), t hen set swit ch S5 t o Sec. Pwr posit ion
(See Figure 1-A for locat ion of swit ch).
o120VAC – Simpl y plug t he power cord int o t he AC recept acle on t he card
shel f, t hen set swit ch S5 t o Pri. Pwr posit ion (See Figure 1).
NOTE: Cards t hat require 120VAC/ 130VDC Float ing cannot be used in t he same
card shel f as cards t hat require 48VDC Float ing (RUGEN) because t hey ut ilize t he
same ST2-19 (RUGEN) t erminal posit ion.
Internal Power Supply
In P30112, only one of t he t wo dif ferent power sources may be used. Normally
120VAC is t he primary power source. Simply plug t he power cord int o t he AC
recept acle on t he card shel f and set Swit ch S5 on t he upper right hand backplane
t o “ Pri Pwr” . If a second power source (130VDC or 48VDC) is desired, simply
connect it t o t he (+) and (–) screw t erminals on t he “ BAT” connect or block and set
Swit ch S5 t o “ Sec Pwr” . Be sure t o use t he power supply card t hat mat ches t he
power source. See Table 3 for power conf igurat ions.
Table 3
Primary
Input Volt age
Secondary
Input Volt age
Out put
Vol t age
Power Supply
(Set S5 t o Pri. Pwr)
Power Supply
(Set S5 t o Sec. Pwr)
120 VAC 130 VDC 24 VDC P30114 P30114
48 VDC 24 VDC P30079
130 VDC 24 VDC P30078
130 VDC 48 VDC P30111
6. 0 INSTALLATION – CO/ REMOTE SIDE CONNECTIONS
6. 1 Remot e Side Cable Pair Ent rance
(a) Lef t side of card shel f bot t om has a 3/ 4 inch NPT t hreaded hole. If st andard PVC
pipe is used, inst all a 3/ 4 inch–14 NPT male PVC fit t ing (PN 21300T9 – provided) in
t he t hreaded hol e and run solid or fl exible PVC conduit t o t he shel f.
(b) A st rain relief t o accommodat e a 0. 45" t hru 0.709" 12 t o 25 pair high dielect ric
CO/ Remot e cable is al so avail able (PN 23158T9). It will also screw int o t he
t hreaded hole in t he bot t om of t he card shelf .
(c) Insert cable int o remot e side cable ent rance.
(d) St rip 1/ 4 inch f rom end of each wire and secure to appropriat e connect or block
t erminal by t ight ening screws wit h a small 1/ 8 inch st andard blade screwdriver.
(e) Three (3) 18-posit ion, push-on connect or blocks (RM1, RM2, RM3) locat ed in t he
lower lef t corner of t he card shelf are used t o t erminat e t he CO/ Remot e cable
pairs. See Figure 3 and Tabl e 4 for proper cable pair t erminat ions.
(i) Plug RM1 int o RM1 on remot e side back plane.
(ii) Plug RM2 int o RM2 on remot e side back plane.
(iii)Plug RM3 int o RM3 on remot e side back plane.
(See Figure 3)
Page 9

6. 2 Remot e Side Pair Designat ions
Each of t he t wel ve (12) sl ot s will support t wo (2) pairs. The first pair is connect ed t o
t he l ef t side of t he backplane j acks and assigned a numeric designat ion (i. e. T1, R1,
et c. ). The second pair is connect ed t o t he right side of t he backpl ane j acks and is
assigned an alpha designat ion (i. e. TA, RA, et c. ). See Table 4 and Figure 4
Table 4: Remote Side Pin Configurations
Remote Side
SLOT CONNECTOR COLOR – TIP PAIR COLOR – RING CONNECTOR
J1 RM1-15 WHITE – T1 1 BLUE – R1 RM1-16
J1 RM1-13 WHITE – TA 2 ORANGE – RA RM1-14
J2 RM1-11 WHITE – T2 3 GREEN – R2 RM1-12
J2 RM1-9 WHITE – TB 4 BROWN – RB RM1-10
J3 RM1-7 WHITE – T3 5 SLATE – R3 RM1-8
J3 RM1-5 RED – TC 6 BLUE – RC RM1-6
J4 RM1-3 RED – T4 7 ORANGE – R4 RM1-4
J4 RM1-1 RED – TD 8 GREEN – RD RM1-2
J5 RM2-33 RED – T5 9 BROWN – R5 RM2-34
J5 RM2-31 RED – TE 10 SLATE – RE RM2-32
J6 RM2-29 BLACK – T6 11 BLUE – R6 RM2-30
J6 RM2-27 BLACK – TF 12 ORANGE – RF RM2-28
RM2-35 REM. GND. REM. GND. RM2-36
RM3-53 REM (-V) REM (-V) RM3-54
Page 10
M2
RM1
RM3
Figure 5
Remot e
Side
Terminal
Bl ocks

6. 3 Remot e Ground
When Surge/ Lightning Arrester is NOT Used: If user has concluded t hat a surge
arrest er is not needed for t he inst allat ion, t hen the dedicat ed cable pairs are
normally connect ed in an insulat ed splice case or t erminal box t o t he card shelf
cable st ub. Pair 25 (viol et / slat e) should be connect ed t o t erminals 35 and 36 of
t erminal block RM2 t o provide a means to access cent ral of fice ground if required f or
cert ain circuit applicat ions.
When Surge/ Lightning Arrester is Used: Following t he recommended prot ect ion
pract ice of IEEE St andard 487-1992, remot e ground out side t he GPR zone of
influence (300 volt GPR locat ion) is accessible via a 5 kV spark gap l ocat ed in t he
light ning surge arrest er housing ext ernal t o t he card shelf .
One of t he 5 kV spark gap t erminals is physically connect ed to t he remot e ground
end (line t erminal end of t he power t ype surge arrest er as opposed t o it s ground
t erminal end) of t he surge arrest er used f or t he 65 kV rat ed BIL syst em. The ot her
spark gap t erminal connect s t o t he card shel f “ remot e ground” designat ed on card
shel f backplane t erminat ions via t he st ub cabl e shiel d (equipped wit h a “ bul lit bond”
or bonding clamps). The card shel f t erminat ion for t he st ub cable shield is t he
RM2-35 and RM2-36 t erminal posit ions on t he middle (RM2) connector block.
The above inst allat ion scheme provides f or coordinat ed 65 kV BIL prot ect ion of
bot h t he isol at ion equipment (shel f and cards) and t he dedicat ed ent rance cable.
The 5 kV gap coordinat es drainage of surge volt age dif ference bet ween t he
dedicat ed cable pairs and t he shield should t he power t ype surge arrest er operat e
and equalize ground pot ent ial diff erence bet ween st at ion ground and remot e ground
via t he cable shield.
The isol at ion syst em is designed around t he prot ect ion pract ice of IEEE St andard
487-1992, and it is recommended t hat t his configurat ion be used in any applicat ion
environment where surges are possible. The 65 kV BIL of t he isolat ion syst em is
assured and t he dedicat ed cabl e receives similar BIL prot ect ion and insulat ion
prot ect ion coordinat ion bet ween shield and cable conduct ors.
Note: In some applicat ions “ remot e ground” is direct ly needed f or a circuit
funct ion such as for PBX ground st art t runks (a l ess desirabl e t runk seizure
conf igurat ion t hat is more prone to possible t ransient vol t age and circuit noise
problems t han a loop st art t runk). When a direct “ remot e ground” connect ion is
required, a prot ect ion syst em appl icat ion ut ilizing t he 5 kV spark gap must have t he
gap bypassed by t he Violet / Slat e 25t h pair t o get cent ral of fice ground direct ly
accessible t o t he PBX card. This ef fect ively disabl es t he 5kV gap.
6. 4 Circuit s Requiring 2 or 3 Isolat ion Cards
CENTER TAP (CTE) CONNECTIONS
To permit DC simplex sealing loop current t o f low bet ween t wo 2-wire isolat ion
cards, all odd numbered slot s have CTE connect ions t hrough t he remot e backpl ane.
J1 is connect ed t o J3, J5 t o J7, and J9 to J11. Use t hese combinat ions when using
2-wire isolat ion cards.
Page 11

NOTE: The SW1 backplane swit ches must be in t he down or “ St andard” posit ion t o
connect t he CTE of slot s J1 to J3 and J9 t o J11.
SW1 SWITCH ON REMOTE BACKPLANE
Bet ween sl ot s J4 and J5 is an up/ down swit ch marked “ Special Set up” (up) and
“ St andard” (down). The “ st andard” posit ion is t he def aul t posit ion in which t he card
shel f is shipped. It is rarely necessary t o change t his set t ing!
“ Standard” Position
SW1 swit ch connect s CTE of 2-wire isolat ion cards residing in slot s J1 and J3.
“ Special Setup” Position
WARNING: This “ Special Set up” posit ion is rarely needed. Use “ Special Set up” only
for 4-wire DX Signaling Applicat ions requiring a combinat ion of t hree (3) isolat ion
cards (Pilot Wire Relaying, OPX, AC). The SW1 swit ch connect s t he CTE of sl ot J1 t o
Ring (R5) of J5; and t he CTE of J3 t o Tip (T5) of J5. Put t he 2-wire AC isolat ion (56
kbs) cards in sl ot s J1 and J3. The special circuit card goes in sl ot J5.
7. 0 TROUBLE SHOOTING
A t est card P31102 is recommended for checking correct wiring and correct powering
volt ages.
7. 1 LED Not Lit
No supply volt age. Check wit h P31102 t est card.
Fuse on AC l ine recept acl e or on upper back pl ane may have burned out .
J28 on upper back plane was not set correct ly (see page 7 & 8).
7. 2 LED Blinking
Possible line and neut ral of t he AC line are reversed.
S5 on upper back plane may be set t o Primary while J28 is set t o 48V.
J28 on upper right backpl ane is set t o 48V while 120VAC is used.
Input t o one of t he isolat ion cards may be short ed.
Out put of power suppl y may be short ed.
7. 3 Fuse keeps burning
Possible line and neut ral of t he AC line are reversed while J28 is set t o 48V.
The cards being used may be short ed.
7. 4 Dat a Card Failure
Check f or correct wiring. (Use P31102 and make j umpers f rom St at ion t o Remot e)
Incorrect dat a card is used.
7. 5 POTS Card Failure
Check f or correct wiring. (Use P31102 and make j umpers from St at ion t o Remot e)
Check S1 on POTS card f or correct set t ing.
Check f or correct powering volt age (Grounded 24V/ 48V) using P31102 t est card.
Page 12

8. 0 PIN OUT DIAGRAMS
Figure 6: P30112, 6-Slot St at ion (Upper) and Remot e (Lower) Backplane
RUGEN
-48V
GND
-24V
RN
TN
-48V
GND
-24V
RUGEN
J9
Slot 1
GND
RUGEN
T7
R7
-24V
-48V
GND
-48V
-24V
RUGEN
TH
RH
Slot 2
J7
RUGEN
GND
-48V
T8
R8
-24V
J8
RUGEN
-48V
GND
TJ
RJ
-24V
-48V
-48V
T9
R9
TK
RK
Slot 3
RUGEN
-24V
GND
RUGEN
-24V
GND
Slot 4
-48V
T10
GND
-24V
RUGEN
R10
J10 J11 J12
RUGEN
RL
TL
-48V
GND
-24V
RUGEN
Slot 5
T11
R11
-24V
-48V
GND
RM
TM
RUGEN
Slot 6
R12
-48V
T12
GND
-24V
REM GND
J1
RM3
RM1
RM2
CTECTE
J3
NOT USED
REM GND
REM GND
T3
R3
J2
REM GND
RC
TC
J3 J4
NOT USED
R4
CTE
T4
REM GND
RD
TD
CTE
J4
J6J5
REM GND
SW1
CTE
CTE
J6
NOT USED
T6
R6 RF
TF
REM GND
R5
CTE
T5
REM GND
NOT USED
J5
TE
CTE
RE
RA
TA
CTE
REM GND
R1
T1
CTE
REM GND
J1
NOT USED
CTE
REM GND
R2
T2
CTE
REM GND
RB
TB
J2
NOT USED
St at ion (Upper) Backplane Remot e (Lower) Backplane
For furt her informat ion or for t echnical support – call 800-558-3325
or visit www. sncmf g.com
SNC Manufacturing Co., Inc.
101 West Waukau Ave., Oshkosh, WI 54902-7299
800-558-3325 or 920-231-7370 FAX [phone]
E-mail: [e-mail]
Website: www.sncmfg.com
Page 13 TO355 Rev. A – 09/ 11
