Parker Airtek Smart Cycle Plus SCP1200 User manual

Airtek Smart Cycle Plus
User Guide - PUB042209 REV. B
Models SCP1200 to SCP3000

2 - REV. B
SCP 1200 - 3000 USER GUIDE
Contents
1 Getting Started 3
1.1 Environmental & Location Considerations 3
2. Dryer Installation 4
2.1 Plumbing the Air Lines 4
2.2 Electrical Connections 5
2.3 Electrical Hook-up 6
3. Controls 7
3.1 DP5550 Displays 9
4. Start-Up Procedure 13
4.1 Smart Cycle Plus 1200 – 3000 13
4.2 When Operating Dryer 14
5. Routine Maintenance 15
6. Diagnostic Codes & Troubleshooting 16
7. Optional Control Center 18
8. Maintenance Charts 40
8.1 Maintenance Procedures 40
8.2 Routine Maintenance 41
10. Spare Parts List 79
11. Warranty and Product Registration 80

3 - REV. B
SCP 1200 - 3000 USER GUIDE
1 Getting Started
Before unpacking/uncrating your new dryer, inspect the carton/crate for damage. Note any
damage on the freight bill. File notice of concealed damage if:
(a) there are any dents in the cabinets
(b) there is any sign of oil on the skid or oor
(c) the refrigerant gauge shows NO pressure
(Upper right side – look for hole in packing)
File these claims with the carrier immediately!
Otherwise, proceed with unpacking/uncrating the unit.
1.1 Environmental & Location Considerations
Following these guidelines will help insure that your new dryer will provide safe and
reliable service.
• Unless supplied for special conditions, all SCP dryers must be located indoors in
an area with an ambient temperature between 41 - 100ºF (5-37.7ºC) and free from
explosive and corrosive fumes. Three (3) feet (92cm) of space must be allowed
between all open grills, walls, or other objects.
If the dryer is installed in a conned area, an exhaust system must be provided to
eliminate re-circulation of hot atmospheric air.
• High ambient temperatures affect the outlet dew point of the dryer. For every
10º of ambient temperature over 100ºF (37.7ºC) a decrease of 10% of dryer
performance is encountered with air cooled dryers. The unit must not operate
in an ambient of over 115ºF (46ºC). If ambient temperature conditions are over
100ºF (37.7º), water cooled dryers are recommended.
• Unit must be installed indoors.

4 - REV. B
SCP 1200 - 3000 USER GUIDE
2. Dryer Installation
• NEVER work on unit under pressure
• NEVER work on unit when power is connected
• DO NOT over pressurize unit.
• DO NOT pass air through the unit until it has been stabilized (operating about 15-20
minutes)
2.1 Plumbing the Air Lines
The dryers are shipped ready to run. All connections are made to the outside of
the cabinet
• Air piping must be supported independently of the dryer.
• Direction of the air ow must be observed for proper installation.
• Use unions or ange joints on inlet and outlet pipe connections.
• If vibration is present, exible metal hoses must be installed to prevent the
vibration from being transmitted to the dryer.
• Install a bypass line and gate valves to permit isolation of the dryer from the
air system. This is done to provide easy service and/or removal of the dryer
without interruption of air to the system.
USE TWO (2) WRENCEHS WHEN CONNECTING DRYER TO PIPING. THIS
WILL PREVENT DAMAGE TO INTERNAL AIR LINES.

5 - REV. B
SCP 1200 - 3000 USER GUIDE
2.2 Electrical Connections
To be performed by a qualied person only. Risk of serious injury or death.
Before connecting electrical power to the dryer check for correct voltage and
phase at the connection box. All units must be externally grounded to protect
against severe electrical shock.
Service Switch (On Models SMART CYCLE PLUS 1200 to 3000)

6 - REV. B
SCP 1200 - 3000 USER GUIDE
Voltage Phase Wire Colors
115V Single Black, White, Green
230V Single Black, Red, Green
230V 3 Phase 3 Black, 1 Green
460V 3 Phase 3 Black, 1 Green
575V 3 Phase 3 Black, 1 Green
2.3 Electrical Hook-up
1. Remove side cover and locate electrical box.
2. Remove electric box cover from inside unit.
3. Locate the wires.
4. Locate hole on side of box, place and tighten connector, run wires
through connector.
5. Using wire connectors, connect Black to Hot wire, White to Neutral and
Green to Ground wire. Refer to table above for voltage and wire colors.
6. Make sure no bare wire is exposed; replace box cover and screw closed.
7. Turn Service Switch “ON”.
8. Replace side covers.
Wire the dryer separately from the air compressor. The dryer must not cycle
with the air compressor.
Phase rotation is important if the dryer has a 3 phase condenser (SCP3000).
Fans must pull air through condenser coil.
Crankcase heaters are pre-wired from the factory to the line side of the
compressor contactor. When power is applied to the dryer, the heater will
energize. Heater must be energized for 12 hours prior to start–up and after
prolonged shut down. The power must be left on at all times except when
servicing.

7 - REV. B
SCP 1200 - 3000 USER GUIDE
(1) – RUN SELECT KEY: (MODE SELECTOR)
Push Key to toggle through the four modes of operation (‘AUTO’ Run Mode, ‘LOAD/
UNLOAD’ Mode, ‘CYCLING’ Mode, and ‘OFF’). The Display ‘main screen’ will indicate
all modes of operation along with the current Dew Point measurement.
(2) – ALARM KEY: (RESET ALARMS)
When the ALARM Key red ‘LED’ is ashing, the system has experienced an alarm
event. The Display will indicate all alarms when they occur. Pushing the ALARM Key will
attempt to clear the fault. Note with some alarms, the system will need to be restarted.
(3) – DRAIN KEY: (OPERATE DRAIN)
When the ‘DRAIN’ Key is pressed, the drain solenoids will operate for the programmed
time duration. (see Settings, Drains). The green LED will illuminate indicating the drains
are open.
(4) – LOAD KEY: (VIEW LOAD %)
Pushing the ‘LOAD’ Key will toggle the Display between indicating ‘Mode & Dewpoint’
(standard), and, ‘Percent of Load’ (optionally) that the dryer is experiencing. The green
LED will illuminate indicating the display option is active.
(5) – READ KEY: (MEASUREMENT READINGS)
The ‘READ’ Key will scroll through each system measurement.
(6) – SETTINGS KEY: (PROCESS VALUES)
The ‘SETTINGS’ Key will scroll through each user setting (process value). The amber
LED will illuminate indicating the display is active.
3. Controls

8 - REV. B
SCP 1200 - 3000 USER GUIDE
(7) – YES / UP KEY: (YES & UP)
When the ‘YES / UP’ Key is pressed, the controller will either increment up or toggle
depending on which user setting is selected in the ‘SETTINGS menu. Note the
SETTINGS Key amber LED will now ash. To save the ‘new’ process value setting,
press the SETTINGS Key again – a message ‘ARE YOU SURE?’ will display (answer
either YES or NO, the LED will stop ashing.
(8) – NO / DOWN KEY: (NO & DOWN)
When the ‘NO / DOWN’ Key is pressed, the controller will either decrement up or
toggle depending on which user setting is selected in the ‘SETTINGS menu. Note the
SETTINGS Key amber LED will now ash. To save the ‘new’ process value setting,
press the SETTINGS Key again – a message ‘ARE YOU SURE?’ will display (answer
either YES or NO, the LED will stop ashing.
(9) – MULTI COLORS INDICATOR:
These LED’s will illuminate in RED, AMBER and GREEN. They represent a ‘visual’
indication as to dryer loading. If all the LED’s are RED, this is the worst possible state (a
combination of very bad dew point and or overloaded. The other side of the spectrum
would be only one GREEN LED illuminated; indicating less then (<10%) ten percent
capacity is being utilized and all is OK.
(10) – MAINTENANCE MONITOR:
The controller will remind the user to perform maintenance on the dryer every six
month. The Display will indicate (and the ALARM LED will ash), the statement
“CHANGE FILTER.” IMPORTANT – The user should change the coalescing lter on a
regular basis. Also do all other recommended maintenance (see maintenance section
of the Operating Manual) at this time.
To reset the ‘Maintenance Monitor’ at the completion of the maintenance procedures,
push the ALARM Key and when the “HAS FILTER BEEN CHANGED? (YES / NO)”
message is in the Display, press the ‘YES’ Key. Pressing the YES Key will reset the
Change Filter timing for six months. Selecting the ‘NO’ key will exit the menu and the
message will repair again in 8 hours.
OTHER FEATURES:
On ‘power-up’ the Display will indicate the system conguration (System Operating
Code #, CFM Range and Firmware Revision) for three seconds.

9 - REV. B
SCP 1200 - 3000 USER GUIDE
3.1 DP5550 Displays
Power On Screen – Displayed for 3 seconds after power-on or reset
Model and Size
Firmware Rev/Date
Main Display - System OFF
Main Display - System Running, No Alarms
Press the RUN SELECT key to cycle thru the operating modes
Operating Mode
Operating Dew Point
Operating Modes
“SYSTEM OFF”
“AUTO MODE (L)” (L) = load/Unload Mode,
(C) = Cycling Mode
“LOAD/UNLOAD MODE”
“CYCLING MODE”
Main Display - System Running, with Warning Alarms
Alarm Description(s)
Operating Dew Point
Warning Alarms
“HIGH DEW POINT”
“DRAIN FAULT”
“HIGH CONDENSER TEMP.”
“HIGH INLET TEMP”
“HIGH DIFF PRESSURE”
“BAD SENSOR WARNING”
“CHANGE FILTER”
[4] 1500-3000 CFM
1.0.4.9x/Dec 1 2009
SYSTEM OFF
Press Run Select
AUTO MODE (L)
DEW POINT:36°F
HIGH INLET TEMP
DEW POINT:36°F
(11) Air Inlet & Outlet PSI Gauges. Indicates that unit is pressurized. Unit MUST be
depressurized and bypassed before any service work is done on air system. Excessive
pressure drop (more than 5 PSIG) across dryer indicates water may be freezing in the
evaporator.

10 - REV. B
SCP 1200 - 3000 USER GUIDE
3.1 DP5550 Displays
Power On Screen – Displayed for 3 seconds after power-on or reset
Model and Size
Firmware Rev/Date
Main Display - System OFF
Main Display - System Running, No Alarms
Press the RUN SELECT key to cycle thru the operating modes
Operating Mode
Operating Dew Point
Operating Modes
“SYSTEM OFF”
“AUTO MODE (L)” (L) = load/Unload Mode,
(C) = Cycling Mode
“LOAD/UNLOAD MODE”
“CYCLING MODE”
Main Display - System Running, with Warning Alarms
Alarm Description(s)
Operating Dew Point
Warning Alarms
“HIGH DEW POINT”
“DRAIN FAULT”
“HIGH CONDENSER TEMP.”
“HIGH INLET TEMP”
“HIGH DIFF PRESSURE”
“BAD SENSOR WARNING”
“CHANGE FILTER”
HIGH DISCHARGE PRES.
Alarm Shutdown
AUTO MODE (L)
Alarm Shutdown
Dew point
36°F
Note: if more than one alarm condition exists, then the top line of the
display will automatically cycle thru all active alarms.
Main Display - System Shutdown Due To Critical Alarm
Alarm Description
Shutdown status
Critical Alarms
“DRYER OVERLOAD”
“BAD SENSOR SHUTDOWN”
“LOW SUCTION PRESSURE”
“HIGH DISCHARGE PRES.”
“HIGH SUPERHEAT”
“EVAPORATOR FROZEN”
“EMERGENCY STOP”
“BAD PUMPDOWN”
“SYSTEM FAULT”
Press the ALARM key to reset all alarms
Press the RUN SELECT key to restart the dryer after an alarm
Note: if more than one alarm condition exists, then the top line of the
display will automatically cycle thru all active alarms.
Read System Parameters
Press the READ key to cycle thru the system parameter values
Parameter Description
Parameter Value
Dew Point Temp. 0 thru 200°F
Superheat Temp. 0 thru 100°F
Suction Temperature 0 thru 200°F
Suction Pressure 0 thru 600 psi
Discharge Pressure 0 thru 600 psi

11 - REV. B
SCP 1200 - 3000 USER GUIDE
Inlet Temperature 0 thru 200°F
Condenser Temperature 0 thru 200°F
Note: The parameter value will display “FAULT!” if the sensor input is invalid
Settings Menu - User Settings
Press the SETTINGS key to cycle thru the user settings
Setting Description
User Settings
Default Settings
TARGET DEW POINT? 38 oF 36 thru 50 °F
DRAIN DURATION? 2 secs 1 thru 30 seconds
DRAIN CYCLE? 60 mins 0 thru 60 minutes
MAX CONDENSER TEMP? 100°F 0 thru 125°F
MAX INLET TEMP? 101°F 0 thru 125°F
TEMPERATURE UNITS? °F °F, °C
PRESSURE UNITS? psi psi, kPa, bars
NETWORK ADDRESS? 1 1 thru 247
Changing the User Settings
Setting Description
Use the UP and DOWN keys to change the setting
Press the SETTINGS key when nished
Select YES or NO to conrm
YES selected, store setting
NO selected, restore previous setting
TARGET DEW POINT?
36°F
TARGET DEW POINT?
36°F
TARGET DEW POINT?
ARE YOU SURE?
New Setting Saved
Setting NOT Saved!

12 - REV. B
SCP 1200 - 3000 USER GUIDE
Load Display
Press the LOAD key to display the dryer load percentage
Clearing the Maintenance Timer
Press the ALARM RESET key to reset the maintenance timer and alarm
Press YES to reset the timer to 6 months (after maintenance has been performed)
Press NO to reset the timer to 8 hours (until maintenance has been performed)
Dryer Load
67%
HAS FILTER BEEN
REPLACED? (YES/NO)

13 - REV. B
SCP 1200 - 3000 USER GUIDE
4. Start-Up Procedure
There should be NO air ow through the dryer before or during start-up. It is recommened
that the dryer be installed with bypass piping to better service the unit.
4.1 Smart Cycle Plus 1200 – 3000
1. After electrical connection (Refer to Section 3), apply power.
2. After power has been applied the control panel should say “OFF” and the
crankcase heater will now start heating. THE CRANKCASE HEATER MUST
BE SWITCHED ON 12 HOURS BEFORE STARTING THE DRYER. Failure to
comply with this rule may cause serious damage to the compressor.
3. Remove side panel from unit.
4. Some units are shipped with the refrigeration service valve tagged. These
tagged service valves must not be opened until the dryer is ready to be
started and the main power is permanently applied. Only tagged service
valves must be opened.
5. Locate tagged service valves and remove end cap from valve stem.
(Fig. 3 below)

14 - REV. B
SCP 1200 - 3000 USER GUIDE
6. Using a refrigeration service or small crescent wrench, turn the valve stem
counterclockwise until it stops. Occasionally, it may be necessary to re-tighten
the packing nut (turn clockwise) if a leak is noticed. The valve will now be fully
opened. (Fig. 3)
7. Replace cap.
8. Once the crankcase heater has been pre-heated, pressure the RUN SELECT
button on the control panel to start the dryer.
9. If the storage conditions were adverse (for example very cooled) the refrigeration
compressor may make a loud metallic hammering noise. If this happens, turn
the dryer off at the panel and wait 60 seconds. Then turn the dryer back on.
Repeat this procedure until the refrigeration compressor runs smoothly. The
dewpoint should start to drop towards the set point.
Do not pass air through the dryer until it is stabilized.
(Unit cycles 2 – 3 times)
10. With the dryer turned on from the control panel, and is stabilized, you can now
introduce compressed air to the dryer.
11. Check the automatic drain for proper operation. Drain should open at regular
intervals based on the drain control settings.
Clean Y-Strainer on drains after the rst 4 hours of operation. (See Section 5.0, Fig. 4)
12. Restart dryer using this procedure after maintenance, power outage or prolonged
periods of shutdown.
4.2 When Operating Dryer
1. Turn dryer On and Off at control panel only.
2. Keep power to unit at all times except when servicing.
3. Start dryer prior to allowing air ow through unit.
4. Clean condenser when necessary.
5. Maintain ambient temperature between 41-100ºF (5-37.7ºC)
6. Keep inlet temperature under 101ºF (38ºC)
7. Check and clean Y-strainer regularly.
8. NEVER allow dryer to cycle ON/OFF with air compressor.

15 - REV. B
SCP 1200 - 3000 USER GUIDE
5. Routine Maintenance
The air cooled condenser must be kept clean. Inspect on a regular basis for dirt or
debris that might accumulate. Remove any debris immediately.
It is recommended that the drain and solenoid be checked weekly for proper functioning.
The Y-strainer should be checked and screen cleaned monthly. (Fig. 4)
It is not advisable to tamper with the other adjustments unless you are familiar with
refrigeration. The controls interact with each other and, although the effect of an adjustment
may not be immediately obvious, it will affect the dryer’s performance.
CHARGE LIQUID REFRIGERANT ONLY, DO NOT CHARGE WITH VAPOR!
• See tag for correct refrigerant charge.
• Unit needs to be pulled into vacuum 500 micron (minimum)
• The full charge might not be accepted. If this occurs, the unit can be started and then
the remainder of the charge should be slowly metered into the suction side (Suction side
is always the inlet to compressor side).

16 - REV. B
SCP 1200 - 3000 USER GUIDE
6. Diagnostic Codes & Troubleshooting
ALARM CODE CONDITION TIMEOUT SHUT-
DOWN RESET
HIGH DEW POINT 11 Actual dew-point is 15ºF above the
target setting 2 seconds No Auto
DRYER OVERLOAD 12 Dew Point > Set Point +40ºF 10 minutes YES MANUAL
BAD SENSOR SHUT-
DOWN 13
Dew Point, Suction Temp, Suction
Pressure, or Discharge Pressure is
reading out of range
2 seconds YES MANUAL
LOW PRESSURE 14 Suction PSI < Set point during
compressor on 5 seconds YES MANUAL
HIGH PRESSURE 15
Discharge Pressure > High Setting,
or Switch is open while compres-
sor is on
1 Seconds YES MANUAL
HIGH SUPERHEAT!
(Semi-Hermetic) 16
Compressor is running. Superheat
Calculation is >40ºF and Suction
temperature >75ºF
40 minutes no Auto
HIGH SUPERHEAT!
(Hermetic) 16
Compressor is running. Superheat
Calculation is >40ºF and Suction
temperature >75ºF
40 minutes YES MANUAL
DRAIN FAULT 17 Drain switch is closed for too long See Note 1 No Auto
FROZEN EVAP! 18 Dew-Point <= 20ºF 10 minutes YES MANUAL
HIGH CONDENSER
TEMP 21 Ambient/Water temperature is higher than setting 60 seconds No Auto
HIGH INLET TEMP 22 Inlet temperature is higher than
setting 60 seconds No Auto
HIGH DIFFERENTIAL
PRESSURE SWITCH 23 Input from PSID switch is closed 2 seconds No Auto
EMERGENCY STOP 24 E-Stop switch is opened or inter-
nal fuse is blown 2 seconds YES MANUAL
BAD PUMP DOWN 25
Pressure switch remains open for
1 minute after shutdown, or cycles
more than 8 times per hour
1 hour (see
description) YES MANUAL
BAD SENSOR
WARNING 26 Inlet, or Condener temperature is reading out of range 2 seconds No Auto
NON-RECOVERABLE
SYSTEM FAULT 27 Dryer is not congured or congu- ration has been corrupted 1 Seconds YES MANUAL
CHANGE FILTER 28 Timer has timed out 6 months or 8
hours No MANUAL
Note 1 - Timeout is Drain Duration setting +10 seconds

17 - REV. B
SCP 1200 - 3000 USER GUIDE
ALARM FAU LT-
CODE CAUSE REMEDY
HIGH DEW POINT 11 1) Thermal load is too high.
2) Condenser is dirty.
1) Reduce compressed air quantity and/or inlet
temperature.
2) Clean condenser.
DRYER OVERLOAD 12
1) Thermal load is too high.
2) Unloader valve not closing. (Temperature on
the copper lines of each side of the valve will
be equal)
3) Compressor will not start, no hum.
4) Compressor will not start, hums but trips
overload.
1) Reduce compressed air quantity and/or inlet
temperature.
2) Replace valve internals (Repair Kit).
3) Check for: Service switch in OFF position, loose or
improper wiring, overload tripped, bad starter.
4) Check for: Loose or improper wiring or voltage,
overload tripped, bad starter or compressor failure.
BAD SENSOR SHUTDOWN
(Dewpoint, Suction Temp,
Discharge psi or Suction
psi)
13 1) Sensor connection is loose or disconnected.
2) Sensor is defective.
1) Identify which sensor (scroll thru control panel read-
ings to nd faulty sensor) & tighten connections.
2) Identify which sensor (scroll thru control panel read-
ings to nd faulty sensor) & replace.
LOW PRESSURE 14
1) Refrigerant leak.
2) Low pressure switch defective.
3) Suction line solenoid not opening.
4) Liquid line solenoid not opening.
1) Locate leak. Repair and recharge.
2) Replace.
3) Replace valve internals (Repair Kit) or coil.
4) Replace valve internals (Repair Kit) or coil.
HIGH PRESSURE 15
1) Condenser dirty / blocked.
2) Fan pressure switch defective.
3) Fan motor defective.
4) Ambient temperature too high.
5) High pressure switch defective.
6) Low water ow.
7) Water valve defective.
8) Liquid line valve or coil defective.
1) Clean condenser.
2) Replace.
3) Replace motor.
4) Improve room ventilation.
5) Replace.
6) Fix water supply.
7) Replace.
8) Replace valve internals (Repair Kit) or coil.
HIGH SUPERHEAT 16
1) Refrigerant leak.
2) Defective superheat probe.
3) Poor contact of superheat probe.
4) Faulty expansion valve.
1) Locate leak. Repair and recharge.
2) Replace.
3) Tighten probe to refrigerant line.
4) Replace.
DRAIN FAULT 17
1) Valve strainer clogged.
2) Drain valve clogged.
3) Solenoid defective.
4) Level sensor defective.
1) Clean.
2) Dis-assemble and clean.
3) Replace.
4) Replace.
FROZEN EVAP! 18 1) Unloader valve not opening. Defective valve
or coil. 1) Replace valve internals (Repair Kit) or coil.
HIGH CONDENSER TEMP 21 1) Ambient too high. 1) Improve room ventilation.
HIGH INLET TEMP 22 1) Inlet air temperature too high. 1) Clean air compressor aftercooler and or improve
room ventilation.
HIGH DIFFERENTIAL PSI 23 1) Coalescing lter is dirty.
2) Excessive compressed air ow.
1) Change lter (see serial sticker for part #).
2) Reduce ow.
EMERGENCY STOP 24
1) E-stop switch is opened.
2) Internal fuse blown.
3) E-stop jumper is disconnected.
1) Close switch.
2) Replace.
3) Replace.
BAD PUMP DOWN 25
1) Suction valve not fully closing.
2) Unloader valve stuck open.
3) Compressor is defective.
1) Replace valve internals (Repair Kit).
2) Replace valve internals (Repair Kit).
3) Replace.
BAD SENSOR
WARNING 26 1) Sensor connection is loose or disconnected. 2) A sensor is defective.
1) Check/tighten connections.
2) Identify which sensor & replace.
NON-RECOVERABLE
SYSTEM FAULT 27 1) Not programmed properly. 1) Consult factory for settings and programming instructions.
CHANGE FILTER 28 1) Filter is dirty. 1) Check and replace if necessary (see serial sticker for
lter part #).

18 - REV. B
SCP 1200 - 3000 USER GUIDE
7. Optional Control Center

19 - REV. B
SCP 1200 - 3000 USER GUIDE
PREFACE:
This document is intended to make familiar, the Control Center functionality. The “manual”, can serve as a handy
guide to quickly move through the operations of the dryer it is controlling. It is not intended to replace the more
comprehensive, specic “dryer manual” that will show all other aspects of operation and safety. It is IMPORTANT
that both manuals be referenced for complete dryer understanding.
MENU TREE
a. STARTUP NULL SCREEN--------------------------------------------------------------------[ 4 ]
• PRE-SETUP
• STARTUP
• CHANGE MODES
b. MAIN SCREEN------------------------------------------------------------------------------[ 5 ]
• DISPLAY ORIENTATION
• TYPICAL SCREEN DISPLAYS
c. EVENTS-------------------------------------------------------------------------------------[ 6 ]
• EMERGENCY STOP
• STANDBY
• DEWPOINT OPTION (not installed)
• ACTIVE ALARMS
• DEWPOINT ALARMS
• NO FLOW
d. REVIEW ALARM LOG (“J” Series Menus)--------------------------------------------------[ 6 ]
e. DISPLAY SENSOR VALUES (“K” Series Menus)-------------------------------------------[ 8 ]
• FLOW METER (4-20Ma/1 to 5 volt INPUT)
MAIN MENU
1 DEWPOINT SETTINGS (“D” Series Menus)--------------------------------------------------[ 9 ]
• DEWPOINT SETPOINT
2. SETUP MENU (“E” Series Menus)----------------------------------------------------------[ 10 ]
• COMPANY INFORMATION-----------------------------------------------------------------[ 10 ]
PHONE & www MESSAGE
• PRODUCT INFORMATION-----------------------------------------------------------------[ 10 ]
TYPE OF DRYER & SN#
FACTORY DEFAULTS
GO TO “NULL” STATE
CALIBRATION MENU (“H” Series Menus)
INLET PRSSURES
REHEATER PRESSURE
OUTLET PRESSURE
DISCHARGE PRESSURE
SUCTION PRESSURE
ELEMENT DP SETTINGS
FLOW RANGE SETTINGS
• DRAINS SETUP MENU (“I” Series Menus)----------------------------------------------[ 12 ]
#1 DEMAND or TIMED OPERATIONS

20 - REV. B
SCP 1200 - 3000 USER GUIDE
#1 AUTOTEST
#2 DEMAND or TIMED OPERATIONS
#2 INTERVAL (Timed)
#2 DURATION
#2 AUTOTEST
• COMMUNICATON MENU (“F” & “G” Series Menus)--------------------------------------[ 12 ]
ADJUST CLOCK
STAR WATCH – Host to Control: YES
MODEM SETUP
MODEM ENABLE
MODEM TEST
MODEM RESET (Reprogram)
VIEW MODEM SETTINGS
3. SENSOR SETTINGS (“C” Series Menus)---------------------------------------------------[ 14 ]
• P1: LOW INLET PRESSURE
• P1: HIGH INLET PRESSURE
• P2: REHEATER PRESSURE
• P3: OUTLET PRESSURE
• P4: DISCHARGE PRESSURE
• P5: SUCTION PRESSURE
• P6: SEPARATOR DP
• FLOW
4. TEMPERATURE SETTINGS (“B” Series Menus)--------------------------------------------[ 15 ]
• T1: DRYER INLET SETPOINT
• T2: PRECOOLER SEPOINT
• T3: DRYER OUTLET SETPOINT
• T4: REFRIGERANT SETPOINT
• T5: SUCTION SETPOINT
• T6: AMBIENT/H2O SETPOINT
5. VIEW ALARMS (“A” Series Menus)--------------------------------------------------------[ 15 ]
• HIGH DEWPOINT
• LOW FLOW
• (E1/E2) DEWPOINT PROBE FAULT (OPEN OR SHORT)
• MOTOR OVERLOAD
• (E3) SUPERHEAT OUT OF RANGE
• (E4) LOW DEWPOINT
• (E5) DRYER OVERLOAD
• (E6) LOW FREON OR OIL PRESSURE
• (E7) HIGH FREON PRESSURE
• (W1) LOW AIR-IN PSI
• (W2) HIGH AIR-IN PSI
• (W4) HIGH INLET AIR TEMP
• (W5) HIGH AMBIENT/H2O TEMP
• (W6) DRAIN FAULT
• MODEM FAULT
#1 INTERVAL (Timed)
#1 DURATION
