SNIPER SN1015 Manual
SNIPER SN1015 12MP GPRS CAMERA SETUP
NEEDED: 12X AA ALKALINE or 12x AA RECHARGEABLE BATTERIES, SEE MANUAL WHERE TO FIT. IMPORTANT NOTE: YOU HAVE TO SELECT THE BATTERY TYPE YOU CHOOSE TO USE IN
THE MENU SETTING. YOU CAN ALSO CHOOSE TO USE A SOLAR PANEL. IF A SOLAR PANEL WILL BE USED, PLEASE MAKE SURE THERE ARE NO BATTERIES IN THE UNIT AS THIS WILL
CAUSE PERMANENT DAMAGE TO THE CAMERA!
SIM CARD: STANDARD SIZE SIM CARD IS NEEDED. PLEASE LOAD WITH AIRTIME IF YOU WANT TO USE MMS/ A DATA BUNDLE IF YOU WANT TO USE SMTP (EMAIL TO EMAIL). (NOTE:
MMS BUNDLES WILL NOT WORK. PLEASE ASK THE PROVIDER OF THE SIM CARD (VODACOM, MTN, CELL C.......) TO ACTIVATE THE MMS FUNCTION ON THE SIM CARD BEFORE YOU
LEAVE THE SHOP.
NB! IF THE SIM CARD DOESN'T SLIDE IN EASILY IT IS TOO LARGE AND THE MODULE PINS MAY BREAK. THIS WILL INVALIDATE THE WARRANTY.
CAMERA: YOU HAVE 1X FLIP SWITCH ON THE BACK OF THE CAMERA:
“ON, SETUP AND OFF”,
START SETUP AND USE AS INDICATED BELOW:
PLEASE EFFECT THE FOLLOWING SETTINGS AS IT WILL ENSURE THE CORRECT OPPERATION OF THE CAMERA. MAKE SURE THAT THE ANTENNA IS FASTENED.
SWITCH THE CAMERA TO “SETUP”, ALLOW 2 SECONDS.
THIS WILL START UP THE DISPLAY LCD SCREEN OF THE CAMERA.
PLEASE WAIT UNTIL YOU CAN SEE THE IMAGE THE CAMERA IS VIEWING ON THE LCD DISPLAY.
ON THE LEFT SIDE OF THE SCREEN YOU WILL FIND VERTICAL STRIPES (FROM SHORT TO LONG) INDICATING SIGNAL STRENGTH (IF YOU HAVE A WORKING SIM CARD IN THE CAMERA)
NOW PRESS THE “M” (MENU) BUTTON ONCE. YOU WILL NOW OPEN THE MENU
YOU CAN SELECT WITH THE “OK BUTTON” AND EXIT WITH THE “M” BUTTON. MOVE UP AND DOWN, LEFT AND RIGHT WITH THE ARROW BUTTONS.
SET THE CAMERA TO THE FOLLOWING:
• CAM ID: “ON OR OFF” YOU CAN DECIDE TO NAME IT OR NOT (THIS WILL ALSO SHOW ON THE PHOTO’S)
• CAM MODE: THIS MUST BE ON “PHOTO” TO SEND MMS OR EMAILS (IF YOU WANT TO RECORD VIDEO THE CAMERA WILL NOT SEND A MMS OR EMAIL WHEN VIDEO
IS ON)
• IMAGE SIZE: SELECT 5MP- 12MP (REMEMBER THAT THE PHOTO SENT TO YOUR PHONE IS NOT THE QUALITY SELECTED HERE AND WILL BE A COMPRESSED FILE ONLY,
SO 5MP IS OK)
• NIGHT MODE: CHOOSE THE ONE YOU NEED (“BALANCED” RECOMMENDED)
• MULTI-SHOT: TO 1P – 5P (THIS IS THE NUMBER OF PHOTO’S TAKEN PER MOVEMENT BUT ONLY THE LAST ONE TAKEN WILL BE SENT VIA MMS OR EMAIL. MAKE SURE
YOU SELECT THE CORRECT SETTING. (FOR MOST APPLICATIONS SELECT 1P)
• VIDEO SIZE: DOES NOT MATTER
• VIDEO LENGTH: DOES NOT MATTER
(TO MOVE ACROSS TO THE NEXT COLUMN PIR MAKE SURE THE CAM IS HIGHLIGHTED IN RED AND PRESS THE RIGHT ARROW)
• SENSITIVITY: SET TO “MIDDLE”
• DELAY: MUST BE “ON” AND SET TO MIN 15 SEC (YOU CAN MAKE THE DELAY LONGER IF TO MANY PHOTO’S ARE SENT OR YOU NEED A LONGER TIME BETWEEN
PHOTO’S)
• TIME LAPSE: MUST BE “OFF”
• TIMER: SELECT “OFF” TO WORK 24H (A FULL DAY), “ON” IF ONLY FOR A PART OF A DAY AND SET THE TIME. (PLEASE NOTE: THE CAMERA CAN SEND YOU A FEW
PICTURES DURING THE “OFF TIME” IF TIMER IS ON. THIS IS ONLY TO CONFIRM STANDBY AND BATTERY LIFE IS STILL OK)
(TO HIGHLIGHT PIR TO MOVE ACROSS TO 3G PRESS THE UP ARROW IF NOT IN RED) (IF YOU CAN NOT SELECT THE COUNTRY SET OPTION IN THE MENU YOUR GPRS
SWITCH IS OFF.... PLEASE SWITCH “ON” AND START THE CAMERA UP AGAIN)
• SIM AUTO MATCH: Select AUTO
• # MMS SETUP: CONFIRM IT IS “ON” IF YOU WANT TO USE MMS ONLY. (DO NOT CHANGE ANY OTHER SETTINGS IN HERE) IF YOU WANT TO SEND EMAIL TO EMAIL
THIS MUST BE “OFF”
• # SMTP SETUP: CONFIRM IT IS “ON” IF YOU WANT TO SEND EMAIL TO EMAIL IF YOU WANT TO SEND VIA MMS THIS MUST BE “OFF”
TO SETUP SMTP FOR EMAIL TO EMAIL: OPEN SMTP AND TURN “ON”
• Mail server IP: smtp.gmail.com
• PORT: 587
• Mail Account: Create an email account with Gmail... that you want to send from (NB: keep it short there is limited space to enter!)
• Mail Password: Enter the password for the above email address that you created.
• NB: You have to set the security access to this email account on gmail to allow less secure devices to access this email account! This is in the
security setup of Gmail.
• FTP SETUP: CONFIRM IT IS “OFF” IF NOT SET TO “OFF” (DO NOT CHANGE ANY OTHER SETTINGS IN HERE)
• SEND TO:
PHONE: SELECT PHONE 1 AND ENTER NUMBER TO WHICH THE PHOTO MUST BE SENT (THIS IS ONLY IF YOU ARE USING MMS OPTION). YOU CAN ADD 2 NUMBERS IN
HERE. (NOTE: PLEASE ENTER NUMBER AS 082 000 0000 AND NOT AS +2782 000 0000) YOU WILL BE CHARGED PER NUMBER YOU SEND THE PHOTO TO.
EMAIL: ENTER YOUR EMAIL ADDRESS THAT YOU WANT TO RECEIVE THE PICTURE TO. (THIS IS FOR SMTP OPTION, EMAIL TO EMAIL)
• SENDING PIC SIZE: SELECT THE SIZE (THIS WILL ONLY BE APPLICABLE TO EMAIL TO EMAIL SENDING.
• MAX NUM/DAY: ENSURE THAT THIS OPTION IS SET TO “UNLIMITED” TO ENSURE THE CAMERA WILL SEND EVERY PICTURE TAKEN
• SMS CTRL: SELECT “BY TRIGGER” (THIS WILL GIVE YOU THE BEST BATTERY LIFE). IF YOU NEED SMS COMMANDS TO BE DONE IMMEDIATELY YOU CAN SELECT “ALL
THE TIME” (PLEASE TAKE NOTE: THAT YOU WILL ONLY HAVE BATTERY LIFE FOR A DAY OR TWO AS THE MODEM IS KEPT LIVE AND IS USING A LOT OF POWER)
• DAILY REPORT: SELECT “OFF”
(TO HIGHLIGHT THE 3G TO MOVE ACROSS TO OTHER COLUMN PRESS THE “M” BUTTON ONCE)
• LANGUAGE: USE ENGLISH
• DATE AND TIME: SET THE TIME AND DATE. (THIS WILL BE ON THE PHOTOS TAKEN)
• STAMP: SET TO “ON” (SO THAT THE PHOTO WILL HAVE A TIME AND DATE ON IT)
• BATTERY TYPE: VERY IMPORTANT TO SELECT THE TYPE OF BATTERY IF YOU WANT TO USE RECHARGEABLE AA BATERIES (DO NOT MIX ALKALINE AND
RECHARGEABLE BATTERIES)
• FREQUENCY: LEAVE ON “50HZ”
• SD CYCLE RECORDING: SELECT “ON” (THIS WILL DELETE THE OLDEST PHOTO AND KEEP THE NEWEST ONE ONCE THE SD CARD IS FULL ONLY)
• RESET: DO NOT DO ANYTHING IN HERE.
• PASSWORD: LEAVE THIS “OFF” (IF SELECTED “ON” AND YOU LOSE YOUR PASSWORD IT WILL BE BLOCKED)
• ABOUT: DO NOT DO ANYTHING IN HERE.
WHEN THIS SETUP IS DONE YOU CAN EXIT BY PRESSING THE “M” BUTTON ONCE.
THIS WILL TAKE THE LCD SCREEN BACK TO LET YOU VIEW WHAT THE CAMERA IS POINTING AT.
SWITCH OFF THE CAMERA USING THE “ON/OFF” BUTTON. (THIS WILL NOW SAVE THE CHANGES)
TO SWITCH ON THE CAMERA, YOU MUST FOLLOW THE FOLLOWING STEP BY STEP:
(PLEASE ENSURE THAT THE ANTENNA IS SCREWED ON AND THE BACKING OF THE CAMERA IS TIED TO WHERE YOU WANT THE CAMERA TO OPERATE)
• SWITCH “ON” THE GPRS SWITCH FIRST. (IF MMS OR EMAIL MUST BE SENT)
• SWITCH “ON” THE CAMERA AND CONNECT THE FRONT AND BACK UNITS TOGETHER AND SECURE THE CLIPS ON THE SIDE. ENSURE THAT YOU CAN SEE THE “RED LED” IN
THE FRONT FLASH 1-2 TIMES AFTER THE FRONT AND BACK PARTS ARE CLIPPED TOGETHER.
• THE CAMERA IS NOW ON AND READY TO TAKE THE FIRST PICTURE AND SEND THIS TO YOUR PHONE OR EMAIL AS YOU DID THE SETUP.
NOTE: LEAVE THE CAMERA ON FOR AT LEAST 15MIN TO DO A TEST ON THE FIRST PHOTO/EMAIL. IF YOU GET 2 OR MORE PHOTOS IN SHORTER TIME YOU CAN SWITCH
OFF THE CAMERA AND MOVE IT TO WHERE YOU WANT TO PUT THE CAMERA TO USE. (IF YOU ENABLED THE TIMER, PLEASE MAKE SURE WHAT TIME IT IS AND IT IS IN
YOUR WORKING TIME... OTHERWISE THE CAMERA WILL NOT WORK TILL YOUR SET TIME COMES)
PLEASE NOTE: THE CAMERA IS ONLY EFFECTIVE IF THE SIGNAL FROM CELL PHONE PROVIDER IS RELIABLE. THE CELL PHONE RECEPTION IN SOUTH AFRICA IS
INTERMITTENT AND THIS WILL AFFECT THE CONSISTENCY OF THE CAMERA. THE CAMERA CAN ONLY TRANSMIT A PICTURE IF THE NETWORK ALLOWS IT IN YOUR AREA.
INCONSISTENT PICTURE SENDING IS IN MOST CASES DUE TO THE NETWORK AND NOT THE CAMERA. THIS CAN BE TESTED BY TESTING THE CAMERA IN TOWN OR OTHER
AREA AND COMPARING THE RESULTS.
