Snow Peak CK-166 User manual

ver.2.10
1 2 3 1 2 43
3 Units
CK-145/147
2 Units
CK-166
4 Units
CK-146/148
CK-166 : 400 legs
CK-145/146 : 660 legs
CK-147/148 : 830 legs
1 2
Iron Grill Table
CK-166 Frame Short 400 Leg Set
CK-145/146 Frame 660 Leg Set / Frame Long 660 Leg Set
CK-147/148 Frame 830 Leg Set /Frame Long 830 Leg Set
Instructions Manual
Contents of Set (Names of Parts)
Main unit x 1 Instruction manual
Leg x 4 (with adjuster)
Boss
Leg
protrusion
Adjuster
CK-166 / Iron Grill Table
Frame Short 400 Leg Set
CK-145 / Iron Grill Table
Frame 660 Leg Set
CK-146 / Iron Grill Table
Frame Long 660 Leg set
● Size: W596×D496×H400mm
(when set up)
● Weight: 4.5kg (when set up)
● Main unit
Size: W596×D496×H30mm
Weight: 3.4kg
Material: Aluminum
● Legs
Size: 25×410mm
Weight: 1.1kg (4 units)
Materials: Stainless steel, POM
● Size: W846×D496×H660mm
(when set up)
● Weight: 5.6kg (when set up)
● Main unit - Size: W846×D496×H30mm
Weight: 4.1kg - Material: Aluminum
● Legs - Size: 25×670mm
Weight: 1.5kg (4 units)
Materials: Stainless steel, POM
CK-147 / Iron Grill Table
Frame 830 Leg Set
CK-148 / Iron Grill Table
Frame Long 830 Leg Set
● Size: W1096×D496×H660mm
(when set up)
● Weight: 6.3kg (when set up)
● Main unit - Size: W1096×D496×H30mm
Weight: 4.8kg - Material: Aluminum
● Legs - Size: 25×670mm
Weight: 1.5kg (4 units)
Materials: Stainless steel, POM
● Size: W846×D496×H830mm
(when set up)
● Weight: 5.9kg (when set up)
● Main unit - Size: W846×D496×H30mm
Weight: 4.1kg - Material: Aluminum
● Legs - Size: 25×840mm
Weight: 1.8kg (4 units)
Materials: Stainless steel, POM
● Weight: 6.6kg (when set up)
● Main unit - Size: W1096×D496×H30mm
Weight: 4.8kg
Material: Aluminum
● Legs - Size: 25×840mm
Weight: 1.8kg (4 units)
Materials: Stainless steel, POM
Before use: Please read thoroughly to use safely and avoid expected accidents.
Although sufficient attention has been paid to safety in the design of this product, misuse can still cause injury to yourself or others, as
well as physical damage. The following precautions are provided to prevent the occurrence of such accidents.
DANGER: Could easily result in a serious accident or death
WARNING: Misuse could result in serious injury or death to the user.
CAUTION: Misuse could result in injury or damage to property.
Specifications
Thank you for purchasing this Snow Peak product. This product is a cooking table. In order to ensure your safety when
using this product, please read these instructions carefully before use. Please be sure to keep this document for future
reference. Although this product is expected to be complete and safe, please check all accessory items and practice
assembling and handling it in a safe location prior to use in the field. If there is an item in the instructions that you do not
understand, or if you find a fault in the product, stop use immediately and consult where the store you purchased this
product or contact our User Service department.
Safety Precautions
Safety
DANGER: Could easily result in a serious accident or death
• Before use, read the instruction manuals for each item you are using
in combination with this product.
•If you are using this product in combination with items that are for
outdoor use only, do not use this product indoors.
• Confirm that there are no flames in the surrounding area when replacing
the gas cartridge in or refueling a heating appliance.
• Lining up fires side by side is strictly prohibited. Place at least half a
unit of space between each unit.

MADE IN JAPAN
WARNING: Misuse could result in serious injury or death to the user.
CAUTION: Misuse could result in injury or damage to property.
• Confirm that the leg protrusions are not deformed.
• Only replace a unit or change the layout after confirming that the
main unit and other items have sufficiently cooled down.
• Use under the hot sun will cause the main unit and ambient
temperature to increase. Watch out for burns.
• Do not place more than 100kg on this product, and ensure that
the load is evenly placedamong the 4 legs.
• Always keep a watch over children to ensure they do not touch
this product.
• If you are using this product in combination with a product that uses
a flame, do not use under or near easily combustible objects
(tent, tarp, dry grass, etc.).
• Confirm that the legs are firmly secured to the main unit. Inspect
the legs for looseness during use, and do not use in a loose state.
The legs could fall off or come out, which could lead to the unit
tipping over, fire, or burns.
• Do not scrape with a metal spatula or other hard, sharp object.
This may scratch it, cause the coating to peel off, etc.
• Using this product in a sloped or unstable location may result in
the unit tipping over, which can cause serious accidents.
• Do not move the main unit during use.
• Keep the main unit and leg connections clean at all times. Sand,
dust, or dirt can cause assembled legs to get stuck or become rickety.
• Do not apply lubricant, etc. to the main unit and leg connections.
Doing so may make it impossible to secure the legs.
• Do not secure the legs with more force than is necessary.
• Ensure that no sand, dirt, etc. gets into the adjuster screws.
• Do not use with more than 25mm of the adjuster screws exposed.
• Improper handling can lead to injury, burn, or damage to the
product.
• If water, salt, etc. gets on the product, promptly wipe it off and
allow to sufficiently dry.
Assembly and Method of Use
There is a marker
line above the
protrusion,
making it easy to
determine the
direction of
rotation.
Turn the main unit upside down. Line up the protrusions on the leg
pipes with the leg holes at the four
corners, and insert. (Confirm that
the bosses on the tips of the leg
pipes are protruding on the
opposite side.)
Rotate the legs until they no
longer slip or wobble (either
clockwise or counter-
clockwise; they will lock in
either direction), and firmly
secure them. (The legs are
designed to have an angle
so they open forwards and
away with respect to the
direction of use.)
Do not apply horizontal force
to the unit after turning it back
over. Confirm that the main unit
has cooled down before taking
apart for storage, and
disassemble in the reverse
order.
Do not place your body
weight on the frame. This
will cause it to tip over.
Maintenance & Storage
• When cleaning this product, wipe it with a well-wrung cloth, etc. Washing it will allow water to get inside the main unit, which
can cause deterioration due to rusting, etc.
• Wipe any dirt off the product after use, and store it in a well-ventilated area.
Quality Assurance
This product is expected to be complete and safe. However, in the unlikely event that any product you have purchased is defective, contact
the store where you purchased it or our User Service department. If it is a manufacturing defect, the product will be repaired or replaced
free of charge. In any other cases, the product will be repaired for a reasonable price. Whether a product will be repaired or replaced will
be determined at our discretion. The product may not be guaranteed or repaired in the following cases.
For question or concerns
contact the Snow Peak
Customer Service Department.
Snow Peak USA Branch
[phone](9:00~17:00)
Email: [email protected]
1. The product was not used according to the instruction manual.
2. The product’ s life span has been reached due to the aging
of its materials.
3. The product was damaged by modification or rough handling.
4. The product was damaged by an unforeseen accident.
5. The product was damaged by something other than a
manufacturing defect.
6. The product was damaged by dirt or rust.
7. A malfunction or breakage occurred due to disassembly.
8. A malfunction occurred due to part deformation or breakage
caused by dropping or other impact.
9. The deterioration, breakage, or damage of a consumable
part, or associated malfunction.
10. The product was damaged due to it being used in
combination with another company’s product.
