SNOWJOE Sun Joe 24V-LRPL2-LTE User manual

© 2020 by Snow Joe®, LLC
All rights reserved. Original instructions. SAVE THESE INSTRUCTIONS
1
A Division of Snow Joe®, LLC
OPERATOR’S MANUAL
Model 24V-LRPL2-LTE Form No. SJ-24V-LRPL2-LTE-880E-M
R
CORDLESS TELESCOPING
POLE PRUNER
24-VOLT MAX* | 2.0 Ah | 1.02"
IMPORTANT!
Safety Instructions
All Operators Must Read These
Instructions Before Use
Read all safety warnings and instructions. Failure to follow the
warnings and instructions may result in electric shock, re and/
or serious injury.
General Safety WARNINGS!
Notice the personal safety alert symbol m used in this manual
to draw your attention to a WARNING given along with the
particular operating instruction. This means that the operation
requires special ATTENTION, CAUTION, and AWARENESS.
When using this power tool, basic safety precautions,
including the following, should always be followed to reduce
the risk of re, electric shock, personal injury and material
damage.
mWARNING! This unit can be dangerous! Careless or
improper use can cause serious injury.
mWARNING! The cutting blades can cut you. Keep hands
and feet away from the blades and the cutting area.
Retain this manual for future reference and reread it at the start
of each trimming season.
• Avoid accidental starting.
• When the tool is not in use, keep it away from other metal
objects.
• Before operating the tool, read the entire manual carefully
and make sure you know how to switch the tool OFF in an
emergency.
Work Area Safety
1. Keep work area clean and well lit. Cluttered and dark
areas invite accidents.
2. Do not operate power tools in explosive atmospheres,
such as in the presence of ammable liquids, gases or
dust. Power tools create sparks which may ignite the dust
or fumes.
3. Keep bystanders and children away. All bystanders,
including children and pets, should be kept a safe
distance away from the work area.
4. Avoid dangerous environment. Don't use the appliance
in wet or damp location.
Electrical Safety
mWARNING! Do not operate near electrical power
lines. The unit has not been designed to provide protection
from electric shock in the event of contact with overhead
electric lines. Consult local regulations for safe distances from
overhead electric power lines and ensure that the operating
position is safe and secure before operating as a pole pruner.
1. Avoid body contact with the earthed or grounded
surfaces, such as pipes, radiators, rangers and
refrigerators. If the body is earthed or grounded, the risk
of electric shock will increase.
2. Do not expose the power tool to rainy or wet
conditions. A power tool contacting with water will
increase the risk of electric shock.
Battery tool use and care
mWARNING! Read all safety warnings and instructions.
Failure to follow the warnings and instructions may result in
electric shock, re and/or serious injury.
1. Recharge only with the charger specied by the
manufacturer. A charger that is suitable for one type of
battery pack may create a risk of re when used with
another battery pack.
2. Use appliances only with specically designated battery
packs. Use of any other battery packs may create a risk of
injury and re.
3. When the battery pack is not in use, keep it away from
other metal objects, like paper clips, coins, keys, nails,
screws or other small metal objects that can make a
connection from one terminal to another. Shorting the
battery terminals together may cause burns or a re.
4. Under abusive conditions, liquid may be ejected from
the battery; avoid contact. If contact accidentally occurs,
ush with water. If liquid contacts eyes, additionally seek
medical help. Liquid ejected from the battery may cause
irritation or burns.
5. Do not use a battery pack or appliance that is damaged
or modied. Damaged or modied batteries may exhibit
unpredictable behavior resulting in re, explosion or risk of
injury.
6. Do not expose a battery pack or appliance to re or
excessive temperature. Exposure to re or temperature
above 104°F (40.5°C) may cause explosion.

2
7. Follow all charging instructions and do not charge the
battery pack or appliance outside of the temperature
range specied in the instructions. Charging improperly
or at temperatures outside of the specied range may
damage the battery and increase the risk of re.
8. Do not modify or attempt to repair the appliance or the
battery pack except as indicated in the instructions for
use and care.
Personal Safety
1. Stay alert. Watch what you are doing and use common
sense when operating a power tool. Do not use the
power tool while you are tired or under the inuence of
drugs, alcohol or medication. A moment of inattention
while operating power tool may result in serious personal
injury.
2. Use personal protective equipment. Always wear eye
protection. Protective equipment such as safety glasses,
a dusk mask, non-skid safety shoes, a hard hat,
and hearing protection, when used for appropriate
conditions, will reduce the possibility of personal injuries.
3. Avoid unintentional starting. Ensure the switch is in
the OFF position before inserting the battery, or before
picking up or carrying the tool. Carrying power tools
with your nger on the switch can lead to accidents.
4. Remove any adjusting key or wrench before turning
the power tool on. A wrench or a key left attached to
a rotating part of the power tool may result in personal
injury.
4. Do not overreach. Keep proper footing and balance at
all times. This enables better control of the power tool in
unexpected situations.
5. Dress properly. Do not wear loose clothing or jewelry.
Dangling articles such as these can become caught
in moving parts. Using work gloves and substantial
footwear is recommended when working outdoors. Wear
a protective hair covering to contain long hair.
6. If devices are provided for the connection of dust
extraction and collection facilities, ensure these are
connected and properly used. Use of these devices can
reduce dust related hazards.
7. Don't grasp the exposed cutting blades or cutting edges
when picking up or holding the appliance.
8. Check Damaged Parts – Before further use of the
appliance, a guard or other part that is damaged should
be carefully checked to determine that it will operate
properly and perform its intended function. Check for
alignment of moving parts, binding of moving parts,
breakage of parts, mounting, and any other condition
that may aect its operation. A guard or other part that is
damaged should be properly repaired or replaced by an
authorized service center unless indicated elsewhere in
this manual.
Power Tool Use and Care
1. Do not force the appliance. It will do the job better with
less likelihood of injury if it is used at the rate for which it
was designed.
2. Use the right appliance. Do not use the appliance for any
job except that for which it is intended.
3. Do not use the power tool if the switch does not turn
it on and o. Any power tool that cannot be controlled by
the switch is dangerous and must be repaired.
4. Disconnect the battery pack from the power tool
before making any adjustments, changing accessories
or storing the power tool. Such preventative safety
measures reduce the risk of starting the power tool
accidentally.
5. Store the idle power tool out of the children’s reach
and do not allow persons unfamiliar with the power
tool or these instructions to operate the power tool.
Power tools are dangerous in the hands of untrained
users.
6. Maintain appliance with care. Check for misalignment or
binding of moving parts, breakage of parts and any other
condition that may aect the power tool's operation.
If damaged, have the power tool repaired before use.
Many accidents are caused by poorly maintained power
tools.
7. Keep cutting blades sharp and clean. Properly
maintained cutting blades with sharp edges are less likely
to bind and are easier to control.
8. Use the power tool and accessories in accordance
with these instructions and in the manner intended
for the particular use of the power tool, taking into
account the working conditions and the work to be
performed. Using the power tool for operations dierent
from those intended could result in a hazardous situation.
9. Keep all parts of the body away from the cutting blade.
Do not remove cut material or hold material to be cut
when blades are moving. Make sure the switch is o when
clearing jammed material. A moment of inattention while
operating the product may result in serious personal injury.
10. Carry the product by the handle with the cutting blade
stopped. When transporting or storing the product always
t the cutting device cover. Proper handling of the product
will reduce possible personal injury from the cutter blades.
11. Do not use the pole pruner in bad weather conditions,
especially when there is a risk of lightning. This decreases
the risk of being struck by lightning.
12. To reduce the risk of electrocution, never use near any
electrical power lines. Contact with or use near power
lines may cause serious injury or electric shock resulting in
death.
13. Always use two hands when operating the pole pruner.
Hold the pole pruner with both hands to avoid loss of
control.
14. Always use head protection when operating the pole
pruner overhead. Falling debris can result in serious
personal injury.

3
Service
1. If your power tool requires service, contact an
authorized Snow Joe®+ Sun Joe®dealer or call the
Snow Joe®+ Sun Joe®customer service center at
1-866-SNOWJOE (1-866-766-9563). Only identical
replacement parts should be utilized for repairs. This will
ensure that the safety of the power tool is maintained.
2. If the battery charger cable is damaged, it must be
immediately replaced to avoid a hazard. Contact
the Snow Joe®+ Sun Joe®customer service center at
1-866-SNOWJOE (1-866-766-9563) for assistance.
Battery & Charger
Safety Instructions
We pay a great deal of attention to the design of every battery
pack to ensure that we supply you with batteries that are safe,
durable and have a high energy density. The battery cells have
a wide range of safety devices. Each individual cell is initially
formatted and its electrical characteristic curves are recorded.
This data is then used exclusively to be able to assemble the
best possible battery packs.
Despite all the safety precautions, caution must always be
exercised when handling batteries. The following points must
be obeyed at all times to ensure safe use. Safe use can only
be guaranteed if undamaged cells are used. Incorrect handling
of the battery pack can cause cell damage.
IMPORTANT! Analyses conrm that incorrect use and poor
care of high-performance batteries are the main factors
responsible for personal and/or product damage.
mWARNING! Use only approved replacement batteries;
other batteries may damage the power tool and cause it to
malfunction, which can lead to serious personal injury.
mWARNING! Do not use a battery pack or appliance that
is damaged or modied. Damaged or modied batteries may
exhibit unpredictable behavior resulting in re, explosion or risk
of injury.
Do not modify or attempt to repair the appliance or the battery
pack except as indicated in the instructions for use and care.
Have your battery pack serviced by a qualied repair person
using only identical replacement parts. This will ensure that the
safety of the battery pack is maintained.
mCAUTION! To reduce the risk of injury, charge the
Sun Joe®24V lithium-ion battery pack only in its designated
Sun Joe®lithium-ion charger. Other types of chargers present
risk of re, personal injury and damage. Do not wire a battery
pack to a power supply plug or car cigarette lighter. Such
misuse will permanently disable or damage the battery pack.
• Avoid dangerous environments – Do not charge the
battery pack in rain, snow or in damp or wet locations.
Do not use the battery pack or charger in the presence of
explosive atmospheres (gaseous fumes, dust or ammable
materials) because sparks may be generated when inserting
or removing the battery pack, which could lead to a re.
• Charge in a well-ventilated area – Do not block the
charger vents. Keep them clear to allow for proper
ventilation. Do not allow smoking or open ames near a
charging battery pack. Vented gases may explode.
NOTE: The safe temperature range for the battery is 41°F –
105ºF (5°C – 40.5°C). Do not charge the battery outside in
freezing weather; charge it at room temperature.
• Maintain charger cord – When unplugging the charger, pull
the plug, not the cord, from the receptacle to reduce the
risk of damage to the electrical plug and cord. Never carry
the charger by its cord or yank it by the cord to disconnect
it from the receptacle. Keep the cord away from heat, oil
and sharp edges. Make sure the cord will not be stepped
on, tripped over or subjected to damage or stress when the
charger is in use. Do not use the charger with a damaged
cord or plug. Replace a damaged charger immediately.
• Do not use an extension cord unless it is absolutely
necessary – Using the wrong, damaged or improperly
wired extension cord poses a risk of re and electric shock.
If an extension cord must be used, plug the charger into a
properly wired 16 gauge or larger extension cord with the
female plug matching the male plug on the charger. Make
sure that the extension cord is in good electrical condition.
• Charger (XZ2600-0450) is rated for 100 – 240 volt AC
only – The charger must be plugged into an appropriate
receptacle.
• Use only recommended attachments – Use of an
attachment not recommended or sold by the battery
charger or battery pack manufacturer may result in risk of
re, electric shock or personal injury.
• Unplug charger when not in use – Make sure to
disconnect battery pack from unplugged charger.
mWARNING! To reduce the risk of electric shock,
always unplug the charger before performing any cleaning
or maintenance. Do not allow water to ow into the charger.
Use a Ground Fault Circuit Interrupter (GFCI) to reduce shock
hazards.
• Do not burn or incinerate battery pack – Battery pack
may explode, causing personal injury or damage. Toxic
fumes and materials are created when battery packs are
burned.
• Do not crush, drop or damage battery pack – Do not use
the battery pack or charger if they have sustained a sharp
blow, been dropped, run over or have been damaged in any
way (i.e. pierced with a nail, hit with a hammer, stepped on,
etc.).

4
• Do not disassemble – Incorrect reassembly may pose
a serious risk of electric shock, re or exposure to toxic
battery chemicals. If the battery or charger are damaged,
contact an authorized Snow Joe®+ Sun Joe®dealer or
call the Snow Joe®+ Sun Joe®customer service center at
1-866-SNOWJOE (1-866-766-9563) for assistance.
• Battery chemicals cause serious burns – Never let a
damaged battery pack contact the skin, eyes or mouth. If a
damaged battery pack leaks battery chemicals, use rubber
or neoprene gloves to safely dispose of it. If skin is exposed
to battery uids, wash the aected area with soap and
water and rinse with vinegar. If eyes are exposed to battery
chemicals, immediately ush with water for
20 minutes and seek medical attention. Remove and
dispose of contaminated clothing.
• Do not short circuit – When battery pack is not in use,
keep it away from other metal objects, like paper clips,
coins, keys, nails, screws or other small metal objects
that can make a connection from one terminal to another.
Shorting the battery terminals together may cause burns or
a re.
• Store your battery pack and charger in a cool, dry
place – Do not store the battery pack or charger where
temperatures may exceed 105ºF (40.5ºC), such as in direct
sunlight or inside a vehicle or metal building during the
summer.
Information about the battery
1. The battery pack supplied with your cordless power tool is
only partially charged. The battery pack has to be charged
completely before you use the tool for the rst time.
2. For optimum battery performance, avoid low discharge
cycles by charging the battery pack frequently.
3. Store the battery pack in a cool place, ideally at 77°F
(25°C) and charged to at least 40%.
4. Lithium-ion batteries are subject to a natural aging
process. The battery pack must be replaced at the latest
when its capacity falls to just 80% of its capacity when
new. Weakened cells in an aged battery pack are no
longer capable of meeting the high power requirements
needed for the proper operation of your cordless pruner,
and therefore pose a safety risk.
5. Do not throw the battery pack into an open re as this
poses a risk of explosion.
6. Do not ignite the battery pack or expose it to re.
7. Do not exhaustively discharge batteries. Exhaustive
discharge will damage the battery cells. The most
common cause of exhaustive discharge is lengthy storage
or non-use of partially discharged batteries. Stop working
as soon as the performance of the battery falls noticeably
or the electronic protection system triggers. Place the
battery pack in storage only after it has been fully charged.
8. Protect the battery and the tool from overloads. Overloads
will quickly result in overheating and cell damage inside
the battery housing even if this overheating is not apparent
externally.
9. Avoid damage and shocks. Immediately replace batteries
that have been dropped from a height of more than
3 feet (1 meter) or those that have been exposed to violent
shocks, even if the housing of the battery pack appears to
be undamaged. The battery cells inside the battery may
have suered serious damage. In such instances, please
read the waste disposal information for proper battery
disposal.
10. If the battery pack suers overloading and overheating,
the integrated protective cuto will switch o the
equipment for safety reasons.
IMPORTANT! Do not press the ON/OFF trigger switch any
more if the protective cut-o has been activated. This may
damage the battery pack.
11. Recharge only with the charger specied by the
manufacturer. A charger that is suitable for one type of
battery pack may create a risk of re when used with
another battery pack.
12. Use appliances only with specically designated battery
packs. Use of any other battery packs may create a risk of
injury and re.
13. Under abusive conditions, liquid may be ejected from
the battery; avoid contact. If contact accidentally occurs,
ush with water. If liquid contacts eyes, additionally seek
medical help. Liquid ejected from the battery may cause
irritation or burns.
14. Do not use a battery pack or appliance that is damaged
or modied. Damaged or modied batteries may exhibit
unpredictable behavior resulting in re, explosion or risk of
injury.
15. Do not expose a battery pack or appliance to re or
excessive temperature. Exposure to re or temperature
above 265ºF (130°C) may cause explosion.
16. Follow all charging instructions and do not charge the
battery pack or appliance outside of the temperature
range specied in the instructions. Charging improperly
or at temperatures outside of the specied range may
damage the battery and increase the risk of re.
Information about the charger and the
charging process
1. Please check the data marked on the rating plate of the
battery charger. Be sure to connect the battery charger
to a power supply with the voltage marked on the rating
plate. Never connect it to a dierent mains voltage.
2. Protect the battery charger and its cord from damage.
Keep the charger and its cord away from heat, oil and
sharp edges. Have damaged cords repaired without delay
by a qualied technician at an authorized Snow Joe®+
Sun Joe®dealer or call the Snow Joe®+ Sun Joe®
customer service center at 1-866-SNOWJOE
(1-866-766-9563).

5
3. Electrical plugs must match the outlet. Never modify
the plug in any way. Do not use any adapter plugs with
grounded appliances. Unmodied plugs and matching
outlets will reduce the risk of electric shock.
4. Keep the battery charger, battery pack and the cordless
tool out of the reach of children.
5. Do not use the supplied battery charger to charge other
cordless tools.
6. During periods of heavy use, the battery pack will become
warm. Allow the battery pack to cool to room temperature
before connecting with the charger to recharge.
7. Do not overcharge batteries. Do not exceed the maximum
charging times. These charging times only apply to
discharged batteries. Frequent insertion of a charged or
partially charged battery pack will result in overcharging
and cell damage. Do not leave batteries in the charger for
days on end.
8. Never use or charge the battery if you suspect that it has
been more than 12 months since the last time they were
charged. There is a high probability that the battery pack
has already suered dangerous damage (exhaustive
discharge).
9. Charging batteries at a temperature below 41°F (5°C) will
cause chemical damage to the cells and may cause a re.
10. Do not use batteries that have been exposed to heat
during the charging process, as the battery cells may have
suered dangerous damage.
11. Do not use batteries that have suered curvature or
deformation during the charging process or those that
exhibit other atypical symptoms (gassing, hissing,
cracking, etc.).
12. Never fully discharge the battery pack (maximum
recommended depth of discharge is 80%). A complete
discharge of the battery pack will lead to premature aging
of the battery cells.
Protection from environmental inuences
1. Wear suitable work clothes. Wear safety goggles.
2. Protect your cordless tool and the battery charger from
moisture and rain. Moisture and rain can cause dangerous
cell damage.
3. Do not use the cordless tool or the battery charger near
vapors and ammable liquids.
4. Use the battery charger and cordless tools only in dry
conditions and at an ambient temperature of 41ºF – 105°F
(5°C – 40.5°C).
5. Do not keep the battery charger in places where the
temperature is liable to reach over 105°F (40.5°C). In
particular, do not leave the battery charger in a car that is
parked in the sunshine.
6. Protect batteries from overheating. Overloads,
overcharging and exposure to direct sunlight will result
in overheating and cell damage. Never charge or work
with batteries that have been overheated – replace them
immediately, if possible.
7. Store the charger and your cordless tool only in dry
locations with an ambient temperature of 41ºF – 105°F
(5°C – 40.5°C). Store your lithium-ion battery pack in a
cool, dry place at a temperature of 77°F (25°C). Protect
the battery pack, charger and cordless tool from humidity
and direct sunlight. Only place fully charged batteries in
storage (charged to at least 40%).
8. Prevent the lithium-ion battery pack from freezing. Battery
packs that were stored below 32°F (0°C) for more than 60
minutes must be discarded.
9. When handling batteries, be wary of electrostatic charge.
Electrostatic discharges can damage the electronic
protection system and the battery cells. Avoid electrostatic
charging and never touch the battery poles.

6
Safety Symbols
The following table depicts and describes safety symbols that may appear on this product. Read, understand and follow all
instructions on this tool before attempting to assemble and operate.
READ THE OPERATOR'S
MANUAL(S) – Read, understand
and follow all instructions in the
user manual(s) before attempting
to assemble and operate.
SAFETY ALERT – Indicates a
precaution, a warning or a danger.
WARNING! Do not expose the
unit to rain or wet conditions.
Keep dry.
Symbols SymbolsDescriptions Descriptions
Only use battery charger indoors.
Risk of Injury. Use safety
glasses, hearing protection
and dust mask.
Keep bystanders a safe distance
away from the work area.
Wear protective gloves and
non-slip footwear when using
the machine and handling debris.
DANGER! Keep hands away from
blade.

7
Know Your Cordless Pole Pruner
Read the owner’s manual and safety instructions carefully before operating cordless pruner. Compare the illustration below to
the cordless pruner in order to familiarize yourself with the location of the various controls and adjustments. Save this manual for
future reference.
1. Removable battery
compartment
2. Rear handle
3. Safety lock button (for
telescoping pole pruner)
4. Pole assembly
5. Telescoping pole
cam-lock
6. Multi-angle Lock Button
7. Connecting lock latch
8. Cutting head
9. Blade cover
10. Blade bolt
1 2 345678 9 10 11 12
1314
1517
18
19
20
21
22
23
24
2728
11. Cutting blade
12. Blade sheath
13. Counter blade
14. Trigger switch (for handheld
pruner)
15. Safety lock button (for
handheld pruner)
16. Cutting head connecting lock
button
17. Telescoping pole
18. Charger plug
19. 24V iON+ lithium-ion charger
(XZ2600-0450)
20. Push button for battery indicator
21. Battery indicator
22. Push lock button
23. Charge socket
24 iON+ 24V lithium-ion battery
(24VBAT-LTE) featuring exclusive
EcoSharp®technology
25. Hexagon wrench socket key
26. Lug wrench
27. Trigger switch (for telescoping
pole pruner)
28. Removable battery compartment
connecting lock button
16
Technical Data
Motor ................................................................................ 80 W
Battery Voltage* Max ................................................. 24 V D.C.
Battery Capacity ............................................................. 2.0 Ah
Battery Runtime Max ...................................................... 20 min
Up to 500 cuts of 25 mm soft wood
Charger Input ................................................... 100 – 240 V AC,
50/60 Hz, 0.4 A
Charger Output ....................................... 26 V DC 450 mA
Charge Time Max .......................................................... 5 hours
No Load Speed .......................................................... 16.7 rpm
Cutting Diameter Max ..................................... 1.02 in. (28 mm)
Cutting Speed ............................................................. 1.2 s/cut
Multi-Angle Head ....................................................... 7 position
(-45º | -22.5º | 0º |22.5º | 45º | 67.5º | 90º)
Telescopic Pole ..................................................... 4 ft to 5.83 ft
(1.22 m to 1.78 m)
Overhead Reach ...................................... Up to 11.83 ft (3.6 m)
Weight (Pruner alone) .................................... 4.16 lbs (1.89 kg)
Weight .............................................................. 5.18 lbs (2.35 kg)
(With battery installed)
*Initial no-load voltage, when fully charged, peaks at 24 volts; nominal voltage under typical load is 21.6 volts.
25
26

8
Unpacking
Carton Contents
• Pruner cutting head
• Removable battery compartment
• Pole assembly
• Blade cover
• Hexagon wrench socket key
• Lug wrench
• iON+ 24V lithium-ion battery
• iON+ 24V lithium-ion battery charger
• Manual with registration card
1. Carefully remove the cordless pruner and check to see
that all of the above items are supplied.
2. Inspect the product carefully to make sure no breakage or
damage occurred during shipping. If you nd damaged or
missing parts, DO NOT return the unit to the store.
Please call the Snow Joe®+ Sun Joe®customer service
center at 1-866-SNOWJOE (1-866-766-9563).
NOTE: Do not discard the shipping carton and packaging
material until you are ready to use your new cordless
pruner. The packaging is made of recyclable materials.
Properly dispose of these materials in accordance with
local regulations.
IMPORTANT! The equipment and packaging material are
not toys. Do not let children play with plastic bags,
foils or small parts. These items can be swallowed and pose
a suocation risk!
Battery Pack Operation
The equipment is powered by a lithium-ion battery. The battery
pack is completely sealed and maintenance free.
Battery Charge Level Indicator
The battery pack is equipped with a push button for checking
the charge level. Simply press the push button to read o the
battery charge level from the LEDs of the battery indicator:
• All 3 level monitoring LEDs are lit: Battery charge level
is high.
• 2 level monitoring LEDs are lit: Battery charge level is
decreasing. Stop work as soon as possible.
• 1 level monitoring LED is lit: Battery is at. Stop work
IMMEDIATELY and charge the battery. Otherwise the
battery’s service life will be greatly shortened.
NOTE: If the charge level button does not appear to be
working, insert the charger and charge as needed.
NOTE: Immediately after using the battery pack, the charge
level button may display a lower charge than it will if checked
a few minutes later. The battery cells “recover” some of their
charge after resting.
Charger Operation
mWARNING! Charge only Sun Joe®24V lithium-ion
battery pack with its compatible Sun Joe®24V lithium-ion
charger. Other types of batteries may cause personal injury
and damage.
To reduce the risk of electric shock, do not allow water to ow
into the charger's AC/DC plug.
When to Charge the iON+ 24VBAT-LTE
Lithium-iON Battery
NOTE: The iON+ 24VBAT-LTE lithium-ion battery pack does
not develop a "memory" when charged after only a partial
discharge. Therefore, it is not necessary to run down the
battery pack before inserting the charger plug.
• Use the battery indicator lights to determine when to charge
your iON+ 24VBAT-LTE lithium-ion battery pack.
• You can "top-o" your battery pack's charge before starting
a big job or after a long day of use.
Charging the Battery
1. Push the push lock buttons on the battery to pull the
battery pack out from the battery compartment (Fig. 1).
Charge level button
The battery is at 30% capacity
and requires charging
The battery is at 60% capacity
and requires charging soon
The battery is at full capacity
Light IndicatorsLights

9
2. Check that the mains voltage is the same as that marked
on the rating plate of the battery charger. Then, plug the
charger adapter into an appropriate AC power outlet.
Connect the charger plug into the charge socket of the
battery to start charging (Fig. 2).
3. The battery will take approximately 5 hours to charge.
The battery indicator LEDs will twinkle and illuminate one
by one during the charging process. Unplug the charger
immediately when the 3 LEDs are all illuminated.
mCAUTION! FIRE HAZARD. When disconnecting the
charger from the battery, be sure to unplug the charger from
the outlet rst, then disconnect the charger from the battery
mWARNING! This charger does not automatically
turn o when the battery is fully charged. Please take care
not to leave the battery plugged into the charger. Switch
o or unplug the charger at the mains when charging is
complete.
4. Timely recharging of the battery will help prolong the
battery's life. You must recharge the battery pack when
you notice a drop in the equipment's power.
IMPORTANT! Never allow the battery pack to become fully
discharged as this will cause irreversible damage to the
battery.
Assembly
This cordless pruner comes completely assembled with the
blade pre-installed. Users just need to connect the unit as
hand-held pruner mode or telescoping pole pruner mode
before operation. Follow the instruction below to connect the
machine.
mCAUTION! Make sure the battery is not inserted and
the blades are covered by the sheath before assembly.
Hand-held Pruner Assembly
1. To assemble the machine as a hand-held pruner, align the
small ridge on the removable battery compartment with
the guide slot on the cutting head and slide the cutting
head downward until the connecting lock button pops up
and the cutting head clicks into position (Fig. 3).
2. To disassemble the hand-held pruner, press down
the connecting lock button on the removable battery
compartment and slide up the cutting head at the same
time (Fig. 4).
Fig. 1 Battery pack
Fig. 2
Battery
indicators
Removable battery compartment
Cutting head
Connecting
lock button
Fig. 3
Removable battery compartment
Cutting head
Press down the connecting lock button
Fig. 4

10
Telescoping Pruner Assembly
1. To assemble the machine as a telescoping pole pruner,
align the small ridge on the connecting part of the pole
assembly with the guide slot on the cutting head and
slide the cutting head downward until the connecting lock
button pops up and the cutting head clicks into position
(Fig. 5).
2. Flip the connecting lock latch over the hook on the
cutting head, and press the latch lock down to secure the
connection (Fig. 6).
3. With the battery removed, slide the removable battery
compartment up the end of the pole assembly, until
the connecting lock button pops up and the battery
compartment clicks into position (Fig. 7).
4. To disassemble the telescoping pole pruner, press down
the connecting lock button on the removable battery
compartment and slide down the battery compartment at
the same time (Fig. 8).
5. Flip up the latch lock to unlock the cutting head, then
press the connecting lock button on the bottom of the
pole assembly and slide up the cutting head at the same
time (Figs. 9 – 10).
Cutting head
Pole assembly
Fig. 5
Connecting lock button
Lock latch
Fig. 6
Latch lock
Fig. 7
Removable battery
compartment
Fig. 8
Removable battery
compartment
Connecting lock
button
Fig. 9
Latch lock
Fig. 10
Connecting lock button

11
Operation
IMPORTANT! The product is intended for light-duty pruning of
shrubs and hedges for residential properties.
mWARNING! The blades continue to move to close and
open after releasing the switch. Turn OFF the tool and wait
until the blades come to a complete stop before adjusting or
cleaning.
mCAUTION! Wear protective gloves while working with
the pruner. Never touch the blade or blade rail while the tool is
in operation and be aware of the sharp edges even when the
pruner is not in use.
Starting + Stopping
1. With the unit securely assembled as hand-held pruner
mode or telescoping pole pruner mode, slide the battery
into the removable battery compartment until it clicks to
into position (Figs. 11 – 12).
2. To use the unit as a hand-held pruner, grab the pruner
with the index nger resting on the trigger switch and the
4 other ngers gripping the handle and squeeze the safety
lock button. When you are ready to make a cut, use your
index nger to squeeze the trigger switch. (Fig. 13). This
will close the blades to make a cut. Release the trigger
switch to open the blades. The pole pruner will return to
the (open) starting position.
NOTE: The safety lock button reduces the risk of accidental
starting.
3. To use the unit as a telescoping pole pruner, balance your
weight with both feet on solid ground and hold the pole
pruner by one handle on the rear handle and the other on
the pole. Position the unit at a proper angle depending on
the specic situation (Fig. 14).
4. Take the proper stance in front of the tree with the pruner
o and press the safety lock button on the rear handle.
When you are ready to make a cut, squeeze the trigger
switch to close the blades. After the cut, release the
trigger. The pole pruner will return to the (open) starting
position. (Fig. 15).
Fig. 11 TELESCOPING
POLE PRUNER
MODE
Battery pack
Removable battery
compartment
Fig. 12 HAND-HELD
PRUNER MODE
Battery pack
Removable battery
compartment
Fig. 13 HAND-HELD
PRUNER MODE
Trigger switch
Safety lock button
Fig. 14
TELESCOPING POLE
PRUNER MODE

12
mCAUTION! Always ensure proper footing and balance
in a clean and clear work environment before switching on the
cordless pruner.
Adjusting the Telescoping Pole (Optional)
When being used as the telescoping pole pruner, the machine
is equipped with a telescoping pole which provides up to an
additional 5.83 ft (1.78 m) of overhead reach. To adjust the
telescoping pole, follow the instructions below.
1. Release the trigger switch and the safety lock button.
Removed the battery from the compartment. Wait until the
tool has stopped completely.
2. Flip up the telescoping pole cam-lock, and extend the
pole to the desired length (Fig. 16).
NOTE: Push poles toward each other to shorten the pole
or pull them away from each other to lengthen the pole.
Only extend the pole to the minimum length required to
reach the limb to be cut.
3. Lock the pole in position by closing the cam-lock, and
ensure that the pole is secure.
Adjusting the Cutting Angle (Optional)
The pole assembly is also equipped with a rotating function
that will enable the pruner to cut in any of 7 positions. (-45º,
-22.5º, 0º, 22.5º, 45º, 67.5º, 90º) (Fig. 17). To adjust the cutting
angle, follow the instructions below.
1. Release the trigger switch and the safety lock button.
Removed the battery from the compartment. Wait until the
tool has stopped completely.
2. Hold the pole tightly. Press the rotating button and turn the
cutting head to the desired position. Release the rotating
button and check to make sure that the cutting head is
locked in place (Fig. 18).
Fig. 15 TELESCOPING POLE
PRUNER MODE
Trigger switch
Safety lock button
Fig. 16
Telescoping pole
cam-lock
Telescoping pole
Fig. 17
0°
-22.5°
-45°
22.5°
45°
67.5°
90°
Fig. 18
Rotating button
Cutting head

13
Trimming Tips
The cordless pruner can be used to remove fresh blooms
from the garden; also great for pruning overgrowth, dead and
overlapping stems and twigs, as well as thin and weak growth.
Follow the tips below for operation.
1. Never cut too close to the bud, so the wound can heal
properly.
2. Always make the cut above 0.3 inch (8 mm) from the bud
(Fig. 19).
3. The cut should slope away from the bud, so the rain can
run o (Fig. 20).
4. When removing the entire stem, cut back to the point
where it branched (Fig. 21).
5. Cut branches one by one, as shown (Fig. 22).
Maintenance
mWARNING! Always switch the product o and remove
the battery before performing inspection, maintenance, and
cleaning work.
1. If the cordless pruner requires cleaning, do not use
solvents to clean it. Only use a moistened soft cloth.
Never let any liquid get inside the tool; and never immerse
any part of the tool into any liquid.
2. Apply oil around the blade bolt and open and close the
blades about 10 times to work it in. Use the steel wool to
rub the oil over the cutting surfaces. Spray the tool with
alcohol and wipe with a paper towel.
3. Inspect the product before each use for worn and
damaged parts. Do not operate it if you nd broken and
worn parts.
Blade Maintenance
To ensure years of ecient and trouble-free operation,
blade cleaning should be performed if sap and debris have
built-up, or if you live in an area where the soil is sandy.
Cleaning unusually heavy deposits may require removal of the
blade.
NOTE: Snow Joe®+ Sun Joe®will not be held responsible for
any damage or injuries caused by repair of the pruner by an
unauthorized person or by mishandling of the pruner.
1. Keep the cutting blades clean and free of debris.
Remove trimmings.
2. Keep the blades sharp. Have a worn or damaged cutting
device replaced with a new one of the same type by a
qualied specialist. Spare parts may be ordered online at
sunjoe.com or via phone by contacting the Snow Joe®+
Sun Joe® customer service center at 1-866-SNOWJOE
(1-866-766-9563).
Fig. 19
Bud
0.3 inch (8 mm)
Fig. 20
Fig. 21
1
2
3
Fig. 22

14
Blade Sharpening
mWARNING! Always take extra care, especially when
your hand may be facing the cutting edge.
Bypass pruners will generally only have one blade, the lower
part being the counter blade which should never require
sharpening.
The cut of a bypass tool is achieved by the blade precisely
passing by the counter blade. It therefore follows that you
should never sharpen the at side of the blade. If steel is
removed from here, the two parts will no longer meet precisely
and the tool will fail to cut. You must only sharpen on the
outside or bevelled side of the blade.
1. To sharpen your cordless pruner, hold the open pruner at
in one hand and with the other hand place the sharpener
at a 15 degree angle along the bevelled side of the blade
(Fig. 23).
NOTE: Be careful to not sharpen at too steep an angle as
this could damage the edge of the blade.
2. Move the sharpener in one direction only, with smooth
strokes from base to end 4 to 5 times.
mWARNING! Do not over-sharpen. Be sure to test blades
repeatedly throughout the sharpening process to prevent over-
sharpening.
3. Turn the pruner over so the at side of the blade is facing
up and slide the sharpener ush along the unbeveled edge
to remove burrs created by sharpening the cutting blade.
4. A bench vise can also be used to hold the tool during
sharpening, taking care not to over tighten the vise which
can bend the tool.
mWARNING! Minimize coating loss. Stay to the edge of
the blade when sharpening blades with low-friction or titanium
coating to minimize the loss of coating.
Blade Replacement
mWARNING! Use only recommended replacement blade.
NOTE: Cutting will become dicult if the blade edge becomes
dull, which requires a new blade to be assembled on.
mWARNING! Make sure that the pruner is o and always
wear protective gloves while changing the blade.
mWARNING! Risk of injury; keep hands away from the
switches when changing the blade.
1. Remove the blade cover by unscrewing the two screws
that x them in place (Fig. 24).
2. To remove the moving blade, use the equipped hexagon
wrench socket key to remove the blade nut which secures
the blade. Use the equipped lug wrench to remove the
blade wave washer, and then the blade bolt. The moving
blade and the blade gear should be able to come o the
assembly (Figs. 25 – 27).
Fig. 23 Blade
Counter blade
Diamond le
Fig. 24
Blade cover
Screws
Fig. 25
Blade nut
Hexagon wrench
socket key

15
3. Fit the new blade on the blade gear. Reassemble the blade
gear with the new blade, blade bolt and the blade wave
washer as the reverse order above (Fig. 27).
NOTE: When replace the blade gear, make sure the teeth
on the blade gear is t into the gearwheel inside the
housing.
4. Fix with the blade nut. Reattach the blade cover and the
two screws. Make sure they are tightened securely.
Storage
When the tool will not be used for several months, proceed as
follows:
• Remove the battery from the compartment.
• Clean the product as describe above.
• Assemble the blade sheath over the blades (Fig. 28).
• Store the tool in a secure and dry location. The storage
temperature must always remains in the range of 41°F
(5°C) to 104°F (40°C).
• Before using the tool after prolonged storage, fully
recharge the battery.
Disposal
Recycling the tool
• Do not dispose of electrical appliances as unsorted
municipal waste. Use separate collection facilities.
• Contact your local government agency for information
regarding the collection systems available.
• If electrical appliances are disposed of in landlls
or dumps, hazardous substances can leak into the
groundwater and get into the food chain, damaging your
health and well-being.
• When replacing old appliances with new ones, the retailer
is legally obligated to take back your old appliance for
disposal at least free of charge.
Recycling + Disposal
The product comes in a package that protects it against
damage during shipping. Keep the package until you are
sure that all parts have been delivered and the product is
functioning properly. Recycle the package afterwards or keep it
for long-term storage.
WEEE symbol. Waste electrical products should not
be disposed of with household waste. Please recycle
where facilities exist. Check with your local authority
or local store for recycling regulations.
Battery Caution + Disposal
Always dispose of your battery pack according to federal,
state, and local regulations. Contact a recycling agency in your
area for recycling locations.
mCAUTION! Even discharged battery packs contain
some energy. Before disposing, use electrical tape to cover
the terminals to prevent the battery pack from shorting, which
could cause a re or explosion.
Fig. 26
Blade wave
washer
Lug wrench
Fig. 27 Blade wave
washer
BladeBlade gear
Blade bolt
Gearwheel
Blade gear teeth
Fig. 28
Blade sheath

16
mWARNING! To reduce the risk of injury or explosion,
never burn or incinerate a battery pack even if it is damaged,
dead or completely discharged. When burned, toxic fumes
and materials are emitted into the surrounding atmosphere.
1. Batteries vary according to device. Consult your manual
for specic information.
2. Install only new batteries of the same type in your product
(where applicable).
3. Failure to insert batteries in the correct polarity, as
indicated in the battery compartment or manual, may
shorten the life of the batteries or cause batteries to leak.
4. Do not mix old and new batteries.
5. Do not mix Alkaline, Standard (Carbon-Zinc) or
Rechargeable (Nickel Cadmium, Nickel Metal Hydride, or
Lithium-Ion) batteries.
6. Do not dispose of batteries in re.
7. Batteries should be recycled or disposed of as per state
and local guidelines.
Service + Support
If your Sun Joe®cordless pruner requires service or
maintenance, please call the Snow Joe®+ Sun Joe®customer
service center at 1-866-SNOWJOE (1-866-766-9563).
Model + Serial Numbers
When contacting the company or reordering parts, you will
need to provide the model and serial numbers of your product.
These are found on the decal axed to the housing or handle
of your cordless pruner. Copy these numbers into the space
provided below.
Record the following numbers from the housing or handle of your
new product: Model #:
Serial #:
2 4 V - L R P L 2 - L T E

Optional Accessories
mWARNING! ALWAYS use only authorized Snow Joe®+ Sun Joe® replacement parts and accessories. NEVER use
replacement parts or accessories that are not intended for use with this cordless pruner. Contact Snow Joe®+ Sun Joe®if you
are unsure whether it is safe to use a particular replacement part or accessory with your cordless pruner. The use of any other
attachment or accessory can be dangerous and could cause injury or mechanical damage.
iON+ 24V lithium-ion Battery Quick Charger
iON+ 24V lithium-ion Dual-port Battery Charger
24VBAT-LTE
24VCHRG-QC
24VBAT-LT
24VBAT
24VBAT-XR
ModelAccessories Item
1
2
3
4
5
6
7
8
24V iON+ 1.3 Ah Lithium-Ion Battery
Battery Runtime Max: 13 min (Up to 320 cuts of 25 mm soft wood) 24VBAT-LTW
24V iON+ 1.5 Ah Lithium-Ion Battery
Battery Runtime Max: 15 min (Up to 375 cuts of 25 mm soft wood) 24VBAT-LTX
24V iON+ 2.0 Ah Lithium-Ion Battery
Battery Runtime Max: 20 min (Up to 500 cuts of 25 mm soft wood)
24V iON+ 2.5 Ah Lithium-Ion Battery
Battery Runtime Max: 25 min (Up to 620 cuts of 25 mm soft wood)
24V iON+ 4.0 Ah Lithium-Ion Battery
Battery Runtime Max: 30 min (Up to 1000 cuts of 25 mm soft wood)
24V iON+ 5.0 Ah Lithium-Ion Battery
Battery Runtime Max: 50 min (Up to 1250 cuts of 25 mm soft wood)
24VCHRG-DPC
NOTE: Accessories are subject to change without any obligation on the part of Snow Joe®+ Sun Joe®to provide notice of such
changes. Accessories can be ordered online at sunjoe.com or via phone by contacting the Snow Joe®+ Sun Joe®customer
service center at 1-866-SNOWJOE (1-866-766-9563).
17

18
NOTES

19 R4_01282020
SNOW JOE®+ SUN JOE®CUSTOMER PROMISE
OUR WARRANTY:
Snow Joe warrants new, genuine, powered and non-powered Products to be free from defects in material or workmanship when used
for ordinary household use for a period of two years from the date of purchase by the original, end-user purchaser when purchased
from Snow Joe or from one of Snow Joe’s authorized sellers with proof of purchase. Because Snow Joe is unable to control the quality
of its Products sold by unauthorized sellers, unless otherwise prohibited by law, this Warranty does not cover Products purchased from
unauthorized sellers. If your Product does not work or there’s an issue with a specic part that is covered by the terms of this Warranty,
Snow Joe will elect to either (1) send you a free replacement part, (2) replace the Product with a new or comparable product at no
charge, or (3) repair the Product. How cool is that!
This Warranty gives you specific legal rights, and you may also have other rights which vary from State to State.
PRODUCT REGISTRATION:
Snow Joe strongly encourages you to register your Product. You can register online at snowjoe.com/register, or by printing and
mailing in a registration card available online from our website, or calling our Customer Service Department at 1-866-SNOWJOE
(1-866-766-9563), or by e-mailing us at [email protected]. Failure to register your Product will not diminish your warranty
rights. However, registering your Product will allow Snow Joe to better serve you with any of your customer service needs.
WHO CAN SEEK LIMITED WARRANTY COVERAGE:
This Warranty is extended by Snow Joe to the original purchaser and original owner of the Product.
WHAT IS NOT COVERED?
This Warranty does not apply if the Product has been used commercially or for non-household or rental applications. This Warranty also
does not apply if the Product was purchased from an unauthorized seller. This Warranty also does not cover cosmetic changes that do
not aect performance. Wearing parts like belts, augers, chains and tines are not covered under this Warranty, and can be purchased
at snowjoe.com or by calling 1-866-SNOWJOE (1-866-766-9563).
ABOVE ALL ELSE, Snow Joe, LLC (“Snow Joe”) is dedicated to you, our customer. We strive to make your experience as pleasant as
possible. Unfortunately, there are times when a Snow Joe®, Sun Joe®, or Aqua Joe®product (“Product”) does not work or breaks under
normal operating conditions. We think it’s important that you know what you can expect from us. That’s why we have a Limited Warranty
(“Warranty”) for our Products.

sunjoe.com
