OPERATOR’S MANUAL
ELECTRIC TILLER + CULTIVATOR
16-INCH | 13.5-AMP
IMPORTANT!
Safety Instructions
All Operators Must Read These
Instructions Before Use
Always follow these safety guidelines. Failure to do so may
result in serious bodily injury or death.
General Safety WARNINGS!
You and any other operator of this garden tiller + cultivator
must read, understand, and follow these instructions in their
entirety. Failure to follow these instructions may result in
ELECTRIC SHOCK, FIRE, and/or serious PERSONAL INJURY.
Notice the personal safety alert symbol mused in this
manual to draw your attention to a WARNING given along
with the particular operating instruction. This means that
the operation requires special ATTENTION, CAUTION, and
AWARENESS.
1. Keep work area clean and well-lit – Cluttered, dark
areas invite accidents.
2. Replacement parts – When servicing this unit, use only
identical replacement parts. Replace or repair damaged
cords immediately.
3. Keep children, bystanders, and pets away – All
spectators, including pets, should be kept a safe distance
away from the work area.
4. Know your product – Know how to start and stop the
machine. Be thoroughly familiar with the controls.
5. Use the right tool – Do not use this machine for any job
except that for which it was intended.
6. Dress properly – Do not wear loose clothing or jewelry as
such articles can become caught in moving parts. Wear
a protective covering to contain long hair. Wearing rubber
gloves and substantial non-slip footwear is recommended
when working outdoors.
7. Extension cords – To prevent electric shock, use only
with an extension cord suitable for outdoor use.
8. Avoid accidental starting – Do not carry the garden tiller
+ cultivator with your nger on the switch. Make sure the
switch is o before plugging in or unplugging the unit.
mCAUTION! Moving parts will continue to run for several
seconds after turning o the machine.
9. Do not abuse the cord – Never carry the garden tiller +
cultivator by the cord or yank the cord to disconnect it
from the receptacle. Keep the cord away from heat, oil,
and sharp edges.
10. Moving parts – Keep hands and feet away from moving
parts. Keep guards in place and in proper working order.
11. Do not force the tool – It will perform better with less
likelihood of personal or mechanical injury if it is used at
the rate for which it was designed.
12. Do not overreach – Keep proper footing and balance at
all times.
If the tiller + cultivator strikes a foreign object, follow these
steps:
• Stop the electric tiller + cultivator.
• Inspect for damage.
• Repair any damage before restarting and
operating the tool.
13. Use safety glasses – Also use safety footwear,
snug-tting clothing, protective gloves, hearing, and
head protection.
14. Disconnect the tool – Disconnect the tiller + cultivator
from the power supply when it is not in use, before
servicing it, when changing accessories, and when
performing any other maintenance task.
15. Store idle tool indoors – When not in use, the tiller +
cultivator should be stored indoors in a dry and high or
locked-up place out of the reach of children.
16. Maintain the tiller + cultivator with care – Keep the
cutting edges sharp and clean for optimal performance
and to reduce the risk of injury. Inspect the extension
cord periodically and immediately replace it if damaged.
Keep the handles dry, clean, and free from oil and grease.
Follow the additional recommendations described in the
maintenance section of this manual.
17. Avoid dangerous environments – Do not use the tiller
+ cultivator in rain or in damp or wet locations. Do not
operate the tiller + cultivator in gaseous or explosive
atmospheres or use the tiller + cultivator near ammable
or combustible liquids. Motors in these tools normally
spark, and the sparks might ignite fumes.
18. Stay alert – Watch what you are doing. Use common
sense. Do not operate the tiller + cultivator when you are
tired or under the inuence of drugs, alcohol, or other
medication.
1

2
19. Check for damaged parts – Before further use of the
appliance, a guard or other part that is damaged should
be carefully checked to determine that it will operate
properly and perform its intended function. Check for
alignment of moving parts, binding of moving parts,
breakage of parts, mounting, and any other condition
that may aect its operation. A guard or other part that
is damaged should be properly repaired or replaced.
Contact the Snow Joe®+ Sun Joe®customer service
center at 1-866-SNOWJOE (1-866-766-9563) for
assistance.
Training
• Read, understand, and follow all instructions on the tiller
+ cultivator and in the manual before operating this unit.
Thoroughly familiarize yourself with the controls and the
proper use of the equipment. Know how to stop the unit
and disengage the controls quickly.
• Children should never be allowed access to the equipment.
Adults should never operate the equipment without
carefully reading and understanding these instructions.
• Keep the area of operation clear of all persons, particularly
small children or pets.
• Exercise caution to avoid slipping or falling.
• Always plan your cultivating path to avoid discharge of
material toward people, pets, and property (e.g. windows,
cars, etc.). Thrown objects can cause serious personal
injury and property damage. Do not allow anyone in front of
a running machine.
• Keep people, pets, and property at least 25 feet from the
tiller + cultivator while it is in operation. Stop the tiller +
cultivator if people or pets enter the discharge area.
• Always observe the surface conditions in order to avoid
slipping, falling, and unexpected objects.
Preparation
• Always inspect the area where the tiller + cultivator is to
be used. Remove all objects (i.e. stones, sticks, wires, and
other foreign materials) that could be thrown by the tines or
cause the operator to trip.
• Thrown objects can cause serious injury to the eyes and
exposed body. Always wear safety glasses or eye shields
during operation and while making an adjustment or repair.
• Always operate the tiller + cultivator wearing adequate
garments. Do not wear jewelry or other loose clothing,
which could become entangled in moving parts. Wear non-
slip footwear to ensure proper footing.
• Observe any noise-prevention regulations and laws.
• Inspect the tiller + cultivator for worn, missing, or damaged
parts and safety labels. See maintenance section for
detailed instructions.
Operation
• Do not operate the machine while under the inuence of
alcohol or drugs.
• Keep all safety devices in place and in proper working
order. Do not operate with missing or damaged
components.
• Ensure the controls (start/stop) function properly before
cultivating.
• Hold onto the tiller + cultivator with both hands during
operation. Ensure the grips are dry.
• Contact with rotating parts can amputate hands and feet.
Keep hands and feet away from all rotating parts.
• Only operate the tiller + cultivator when there is good
visibility or light and dry conditions. Always watch your
footing and keep a rm hold on the grips. Walk; don't run!
• Do not operate the tiller + cultivator on slippery surfaces.
Check your footing during use.
• Exercise caution when changing direction and operating the
tool on slopes. Always keep feet and legs a safe distance
away from the machine. Look for hidden obstacles or
hazards.
• Do not overload machine capacity by attempting to
cultivate too deeply. It will cause excessive resistance.
• Stop the tiller + cultivator and disconnect the electric cord
before leaving the operating position (behind the handles) to
adjust or inspect the unit. Wait until the tines have come to
a complete stop.
• If the tiller + cultivator should start to vibrate abnormally,
stop the machine and inspect thoroughly for damage.
• Turn the machine OFF and disconnect the electrical
power when moving to a new work area. Allow the tines to
completely stop rotating before transporting the unit.
• Always use proper care and good judgment when you
are confronted with a situation that is not covered in
this manual. If you are unsure of what to do, contact
your authorized Snow Joe®+ Sun Joe®dealer or call
the Snow Joe®+ Sun Joe®customer service center at
1-866-SNOWJOE (1-866-766-9563).
• Do not use in rain or wet conditions.
• Do not grasp the exposed cutting blades or cutting edges
when picking up or holding the appliance.
Stopping Work
• Always turn the tiller + cultivator OFF and disconnect the
electrical power when stopping work or when changing
work areas. Never leave the machine running when
unattended.
• The tines will continue to rotate for a short period after
turning OFF the tiller + cultivator. Wait until the tines
have completely stopped before lifting the machine or
conducting inspection and maintenance.
• The motor housing remains hot for a short period after the
machine is turned OFF. Allow the motor housing to cool
completely before touching or storing near combustible
material.

3
Maintenance + Storage
• Maintain or replace safety and instruction labels.
• Disengage all controls, stop the engine, and wait until the
tines come to a complete stop before cleaning, repairing,
or inspecting the tiller + cultivator.
• Regularly check the following:
i) Tines are clear and can rotate freely – Accumulation
of debris around the tines could impair performance or
damage the motor. Inspect and clean the area around
the tines before every use.
ii) Safety devices are operating properly – Do not
tamper with or adjust safety devices.
iii) Bolts and screws are properly tightened – Visually
inspect the machine for any damage and ensure that
the tiller + cultivator is in safe working condition.
iv) Use only identical replacement parts – Always replace
damaged parts with original equipment manufacturer’s
(OEM) parts only. Replacement parts that do not meet
the original equipment specications may lead to
improper performance and compromise safety.
Double-Insulated Appliances
In a double-insulated appliance, two systems of insulation
are provided instead of grounding. No grounding means is
provided on a double-insulated appliance, nor should a means
for grounding be added to the appliance. Servicing a double-
insulated appliance requires extreme care and knowledge
of the system, and should be performed only by qualied
service personnel at an authorized Snow Joe®+ Sun Joe®
dealer. Replacement parts for a double-insulated appliance
must be identical to the parts they replace. A double-insulated
appliance is marked with the words “Double Insulation” or
“Double Insulated.” The symbol (square within a square)
may also be marked on the appliance.
DOUBLE-INSULATED: GROUNDING NOT
REQUIRED. WHEN SERVICING, USE ONLY
IDENTICAL REPLACEMENT PARTS.
This electric tiller + cultivator is double-insulated, eliminating
the need for a separate grounding system. Use only identical
replacement parts. Read the instructions before servicing
double-insulated appliances. Use this electric tiller + cultivator
only as described in this manual.
Electrical Safety
1. Ground fault circuit interrupter (GFCI) protection should
be provided on the circuit(s) or outlet(s) to be used for
this electric tiller + cultivator. Receptacles are available
having built-in GFCI protection and may be used for this
measure of safety.
2. To prevent electric shock, use only with an extension cord
suitable for outdoor use, such as SW-A, SOW-A, STW-A,
STOW-A, SJW-A, SJOW-A, SJTW-A, or SJTOW-A.
Before use, check that the extension cord is in good
condition. When using an extension cord, make sure to
use one heavy enough to carry the current your product
will draw. An undersized cord will cause a drop in line
voltage resulting in loss of power and overheating.
3. To reduce the risk of electric shock, this appliance has
a polarized plug (i.e. one blade is wider than the other).
Use this appliance only with a polarized UL-, CSA-, or
ETL-listed extension cord recommended for outdoor,
all-weather use, such as the Snow Joe®+ Sun Joe®
SJTW-A 14-gauge 50-foot extension cord with lighted
end (Model PJEXT50-B). Visit sunjoe.com to purchase
this extension cord online or, to order by phone, call
1-866-SNOWJOE (1-866-766-9563).
The appliance plug will t into a polarized extension cord
only one way. If the appliance plug does not t fully into the
extension cord, reverse the plug. If the plug still does not
t, obtain a correct polarized extension cord. A polarized
extension cord will require the use of a polarized wall
outlet. The extension cord plug will t into the polarized
wall outlet only one way. If the plug does not t fully into
the wall outlet, reverse the plug. If the plug still does not
t, contact a qualied electrician to install the proper wall
outlet. Do not modify the appliance plug, extension cord
receptacle, or extension cord plug in any way.
Extension Cord
Length
Wire Gauge (A.W.G.):
Up to 50 ft
(15 m)
+50 ft - 100 ft
(+15 m - 30 m)
14 12
smWARNING m
Electric shock may cause SEVERE INJURY or
DEATH. Heed these warnings:
• Do not allow any part of the electric tiller + cultivator
to make contact with water while it is in operation. If
the appliance becomes wet while turned o, wipe dry
before starting.
• Use only a UL-, CSA-, or ETL-rated extension cord
for outdoor, all-weather use, such as the Snow Joe
®
+
Sun Joe
®
SJTW-A 14-gauge 50-foot extension cord
with lighted end (Model PJEXT50-B). Visit sunjoe.com
to purchase this extension cord online or, to order by
phone, call 1-866-SNOWJOE (1-866-766-9563).
• Do not use an extension cord over 100 ft (30 m).
• Do not touch the appliance or its plug with wet hands
or while standing in water. Wearing rubber boots
oers some protection.
EXTENSION CORD CHART

4
4. To prevent the appliance cord from disconnecting from
the extension cord during operation, use the onboard
extension cord restraint hook and/or make a knot with the
two cords as shown in Table 1.
5. Do not abuse the cord. Never pull the tiller + cultivator
by the cord or yank the cord to disconnect it from the
receptacle. Keep the cord away from heat, oil, and
sharp edges.
(B) Connect plug and receptacle
Cord set Appliance cord
(A) Tie cord as shown
Table 1. Method of Securing Extension Cord

Safety Symbols
The following table depicts and describes safety symbols that may appear on this product. Read, understand, and follow all
instructions on the machine before attempting to assemble and operate.
READ THE OPERATOR'S
MANUAL(S) – Read,
understand, and follow
all instructions in the user
manual(s) before attempting to
assemble and operate.
SAFETY ALERT – Indicates
a precaution, a warning, or
a danger.
DOUBLE INSULATION – When
servicing, use only identical
replacement parts.
WARNING! Do not expose the
unit to rain or wet conditions.
WARNING! Rotating parts may
cause serious injury. Make sure
the tines come to a complete
stop before transporting the
machine or before inspecting,
cleaning, or conducting any
other maintenance.
WARNING! Keep electrical
extension cord away from tines.
Wear eye protection, breathing
protection, and ear protection
(i.e. safety goggles, dust masks,
and ear defenders).
SWITCH OFF! Remove plug
from the outlet immediately if
the cord is damaged or cut.
Inspect the work area prior to
use and remove all objects that
could be thrown by the appliance.
If a hidden object is discovered
while working, stop the engine
and remove the object.
Work across slopes; never work
up and down such surfaces.
Symbols SymbolsDescriptions Descriptions
SWITCH OFF! Remove plug
from the outlet before cleaning
or conducting maintenance
checks.
Beware of foreign objects
that could be thrown from the
appliance. Keep bystanders a
safe distance away from the
work area.
Wear protective gloves and
non-slip footwear when using
the machine and handling
debris.
The rotating part will
continuously run for several
seconds after you turn o the
machine.
5

6
Know Your Electric Tiller + Cultivator
Read the owner’s manual and safety instructions carefully before operating the electric tiller + cultivator. Compare the illustration
below to the electric tiller + cultivator in order to familiarize yourself with the location of the various controls and adjustments.
Save this manual for future reference.
1. Trigger switch
2. Safety lock button
3. Right handle grip
4. Appliance cord
5. Extension cord restraint hook
6. Left handle grip
7. Upper handle
8. Upper handle knob and bolt (2)
9. Cable clip
10. Middle handle
11. Middle handle knob and bolt (2)
12. Lower handle
13. Transport handle
14. Air vents
15. Motor housing
16. Guard
17. Wheel adjustment
18. Wheels
19. Steel tines
20. Gear box
Technical Data
Rated Voltage ................................. 120 V ~ 60 Hz
Power .............................................. 13.5 A
No Load Speed ............................... 370 ± 10% rpm
Handle .............................................Foldable (3 sections)
Rotor ............................................... 6 steel blades
Cultivating Width Max .................... 16 in. (40.6 cm)
Cultivating Depth Max .................... 8 in. (20.3 cm)
Weight ............................................. 27.1 lbs (12.3 kg)
1
2
3
4
5
6
7
8
910
11 12
13
14
15
16
17
18
19
20

7
Unpacking
Carton Contents
• Electric tiller + cultivator housing
• Upper handle
• Middle handle
• Handle knob and bolt (4)
• Manual with registration card
1. Carefully remove the electric tiller + cultivator and check
to see that all of the above items are supplied.
2. Inspect the product carefully to make sure no breakage or
damage occurred during shipping. If you nd damaged or
missing parts, DO NOT return the unit to the store. Please
call the Snow Joe®+ Sun Joe®customer service center at
1-866-SNOWJOE (1-866-766-9563).
NOTE: Do not discard the shipping carton and packaging
material until you are ready to use the electric tiller +
cultivator. The packaging is made of recyclable materials.
Properly dispose of these materials in accordance with
local regulations or save the packaging for long-term
product storage.
IMPORTANT! The equipment and packaging material are not
toys. Do not let children play with plastic bags, foils, or small
parts. These items can be swallowed and pose a suocation
risk!
Assembly
mWARNING! Do not connect to the power supply
until assembly is complete. Failure to comply could result in
accidental starting and serious personal injury.
mWARNING! Before performing any maintenance, make
sure the tool is unplugged from the power supply. Failure to
heed this warning could result in serious personal injury.
mWARNING! To prevent serious personal injury,
make sure the switch is in the OFF (O) position, the unit is
unplugged, and the tines have come to a complete stop before
inspecting, cleaning, or servicing the unit.
mWARNING! The product must be fully assembled
before operation. Do not use a product that is only partially
assembled or assembled with damaged parts.
Follow the assembly instructions step-by-step and use the
pictures provided as a visual guide to easily assemble the
product.
Connecting the Handles
NOTE: Small parts can easily get lost during asembly or when
making adjustments to the machine. To avoid this, secure all
small parts that are removed from the machine and keep them
accessible.
1. Attach the cable clip on the middle handle bar (Fig. 1).
2. Remove the bolts from the knobs and keep them handy.
3. Secure the middle handle to the lower handle using the
rst set of knobs and bolts (A). Tighten the knobs on each
side to ensure a secure t (Fig. 2).
Fig. 1
Cable clip
Middle handle
Fig. 2
Knob + bolt
Middle handle
Lower
handle
A
A

8
4. Connect the upper handle to the middle handle using the
second set of knobs and bolts (B). Tighten the knobs on
each side to ensure a secure t (Fig. 3).
5. Secure the cable inside the cable clip (Fig. 4).
mWARNING! Make sure all handle knobs are properly
tightened before using the electric tiller + cultivator.
Operation
Intended Use
The TJ604E electric tiller + cultivator is designated with a rated
input power consumption of 1440 Watts.
Designed for small gardens and ower beds, this electric
tiller + cultivator eectively loosens and turns over new soil. It
may also be used to mix coarse soil with fertilizer, peat, and
compost. This product may not be used to till extremely dry or
wet soil.
The use of this product in rain or wet conditions is prohibited.
For safety reasons, it is essential to read the entire instruction
manual before rst use and to observe all the instructions
contained within this manual.
This product is intended for private domestic use only. It is not
intended for any commercial trade use. It must not be used for
any purposes other than those described.
Connecting to Power Supply
NOTE: For safety reasons, this product is equipped with a short
power cord. Do not connect the electric tiller + cultivator directly
to the power supply using this power cord. A proper extension
cord is required for operation. Observe the technical requirements
for this product when purchasing an extension cord.
mWARNING! For your safety, it is required that the plug
attached to this electric tiller + cultivator be connected to an
approved extension cord. The extension cord must be suitable
for outdoor use, with all sockets protected against water
splashing. Ensure the extension cord is of the proper
size and type for your product (≥ 1.5 mm²). Always use a
residual-current device (RCD), or residual-current circuit
breaker (RCCB) protected power supply.
1. Connect the electric tiller + cultivator to a working 120 V
outlet using a heavy-duty outdoor extension power cord,
such as the Snow Joe®+ Sun Joe®SJTW-A 14-gauge 50-
foot extension cord with lighted end (Model PJEXT50-B).
Visit sunjoe.com to order online or call 1-866-SNOWJOE
(1-866-766-9563) to order by phone.
2. Make a loop in the extension cord and push it up through
the hole in the handle and around the cord restraint hook
(Fig. 5), then connect the extension cord to the appliance
cord.
Fig. 3
Knob + bolt
Middle handle
Lower handle
Upper handle
B
B
Fig. 4
Cable
Cable clip
Fig. 5
Extension
cord Appliance
cord
Restraint hook

9
mWARNING! Check the voltage to ensure it complies
with the information on the rating label.
Wheel Adjustment
mWARNING! Always switch the product o and
disconnect it from the power supply before making any
adjustments.
The wheels can be adjusted to 3 dierent positions to control
the cultivating depth.
1. Pull the wheel and move it to the desired position; let go
of the wheel and make sure it locks into position (Fig. 6).
Be sure to set both wheels to the same height.
mWARNING! Always ensure the wheels are securely
locked. Do not attempt to use the product with the wheels in
unlocked positions.
Powering ON + OFF
mWARNING! Rotating tines may cause serious injury. The
tines will continue to turn for a few seconds after the tool has
been switched OFF. Do not touch the rotating tines. Contact
with hot components (i.e. motor housing, gear box, etc.) on the
machine may cause burns. Allow the machine to cool before
handling.
1. To turn the tool ON, push and hold the safety lock button
with your thumb and then squeeze the trigger switch with
your ngers. Once the tool is running, release the safety
lock button (Fig. 7).
2. To switch OFF, release the trigger switch (Fig. 7).
Operating Tips
• Before each use, check the product, its power cord and
plug, and any other accessories for damage. Do not use the
product if it is damaged or shows wear.
• Double check that the accessories and attachments are
properly tted.
• Always hold the product by its handles. Keep the handles
dry to ensure a secure grip.
• Ensure that the air vents are always unobstructed and clear.
Clean them if necessary with a soft brush. Blocked air vents
may lead to overheating and damage the product.
• Switch the product o immediately if you are disturbed
while working by other people entering the working area.
Always let the product come to a complete stop before
averting your attention.
• Do not overwork yourself. Take regular breaks to ensure you
can concentrate on the task at hand and have full control
over the product.
mWARNING! In some countries, regulations dene
restrictions for use of such products, including the times and
days when operation is permissible. Ask your community for
detailed information and observe these regulations in order
to preserve a peaceful neighborhood and avoid committing
administrative oences.
Tilling
• Make sure that the work area is clear of stones, sticks,
wire, or other objects that could damage the product or its
engine.
• Do not till very wet soil because wet soil tends to stick to
the working tool, preventing proper tine rotation; it could
also cause you to slip and fall.
• Always maintain a rm grip on the product. For better
guidance, apply light pressure to the handles.
mWARNING! Do not place hands, feet, or any other part
of the body or clothing near the rotating tines or any other
moving part. The tines begin to rotate forward once the trigger
switch is depressed. The tines continue to rotate until the
trigger switch is released. Failure to avoid contact with the
rotating tines could cause serious personal injury.
• Do not try to till too deeply or force the product into soil that
is extremely hard or resistant.
• Walk the product through the soil at a normal pace and in
as straight a line as possible.
• Till in slightly overlapping rows. To till most eectively,
follow the pattern indicated in Fig. 8. Start by moving the
tiller + cultivator up and down in vertical lines, then work
horizontally from left to right. This will keep the rows even
and ensure that all the ground is tilled without missing any
spots.
Fig. 6
Transport
position
Wheel
adjustment
Wheel
Work position
(low)
Work position
(high)
Fig. 7
Trigger switch
Safety lock button

10
• Pay special attention when changing direction. Apply light
pressure to the handle in order to lift the tines and facilitate
the turn. Turn the product around using the wheels as a
guide. Gradually release pressure on the handle and move
the tines back to the ground.
mWARNING! Stop the motor if the product strikes a
foreign object. Switch the product o, disconnect it from the
power supply, and let it cool completely. Inspect the product
thoroughly for damage and have any damage repaired before
restarting.
Extensive vibration of the product during operation is an
indication of damage. Immediately stop the motor and
promptly inspect and repair the tool.
After Use
• Switch the product o, disconnect it from the power supply,
and let it cool completely.
• Check, clean, and store the product as described below.
Care + Maintenance
The Golden Rules for Care
mWARNING! Always switch the product o, disconnect
the product from the power supply, and let the product cool
completely before inspecting, cleaning, or performing any
other maintenance task.
• Keep the product clean. Remove any debris after each use
and before storage.
• Regular and proper cleaning will help ensure safe use and
prolong the life of the product.
• Inspect the product before each use for worn and damaged
parts. If you nd broken and/or worn parts, do not use the
tool.
mWARNING! Only perform the repairs and maintenance
work described in this manual. Any other work must be
performed by a qualied technician.
General Cleaning
• Clean the product with a dry cloth. Use a brush for areas
that are hard to reach.
• Be sure to clean the air vents after every use with a cloth
and brush.
• Remove stubborn dirt with high pressure air (max. 3 bar).
NOTE: Do not use chemical, alkaline, abrasive, or other
aggressive detergents or disinfectants to clean this product as
such substances might damage the tool's surfaces.
• Check for worn or damaged parts. Replace worn parts as
necessary or contact the Snow Joe®+ Sun Joe®customer
service center at 1-866-SNOWJOE (1-866-766-9563) for
repair before using the product again.
Cleaning the Underbody + Working Tool
mWARNING! Wear safety gloves when working on or
near the working tool. Use appropriate tools (e.g a wooden
stick) when necessary; never use your bare hands!
• Keep the underbody and tines clean and free of debris.
Use a brush or another implement to remove soil from the
working tool.
• All nuts and bolts must be checked periodically for
tightness before operation. After prolonged use, especially
in sandy soil conditions, the working tool will become worn
and lose some of its original shape. Tilling eciency will be
reduced and the working tool should be replaced.
• Have worn or damaged working parts replaced with new
ones of the same type by a qualied technician.
• To prolong the life span of the working tool and the product,
lubricate the tines after each use.
Maintenance
mWARNING! Unexpected tine movement may cause
personal injury. Before servicing, repairing, or inspecting
the unit, turn the motor OFF and disconnect the extension
cord. Wait for the tines to completely stop rotating before
conducting inspection, cleaning, or maintenance.
Before and after each use, check the product and accessories
(or attachments) for wear and damage. When necessary, only
use identical replacement parts that are approved by the
manufacturer.
mWARNING! Contact with hot components (e.g. motor
housing, gear box, etc.) on the machine may cause burns.
Allow the machine to cool o before handling.
IMPORTANT!
• Wear protective gloves when cleaning or maintaining the
machine.
• Do not use cleaning uids or solvents or spray the
machine down with water (especially water under
pressure) when cleaning the machine.
Fig. 8
