SOARING MODELS Cheeper User manual

Cheeper
Assembly instruction
1. Equipment, materials and tools for assembly...…………..…………………………..2
2. Assembly....…………………………………………………………………………..3
3. Setting of the model.…………..……………………………………………………..11

Cheeper
Assembly instruction SoaringModels
2
1. Equipment, materials and tools for assembly
Picture 1.1. Supply kit
1 –Wing;
2 –Fuselage;
3 –Stabilizer;
4 –Fin;
5 –Dowel for throwing;
6 –Rudder rod;
7 –Elevator rod;
8 –Aileron rod (2 pieces);
9 –Rod housing;
10 –Hatches of the aileron servos (2
pieces);
11 –Rod tips (4 pieces);
12 –Heat shrink tube;
13 –Tail control horns (2 pieces);
14 –Aileron control horns (2
pieces);
15 –Screws for mounting of the
stabilizer М2*6 (2 pieces + 2 spare
ones)
16 –Screws for mounting of the
wing М2,5*8 and М2,5*10 (1 spare
set)

Cheeper
Assembly instruction SoaringModels
3
Materials and tools for the installation of the model:
Picture 1.2. Materials and tools
1) Liquid superglue (Akfix
702);
2) Superglue activator;
3) Epoxy;
4) Masking tape;
5) Sandpaper №240-320;
6) Drills Ø2, Ø5;
7) Needle file (round and
flat);
8) Pliers;
9) Screwdriver;
10) Ruler;
11) Stationery knife;
12)Pencil.
Necessary radio equipment for the assembly:
1) Battery 250-300 mAh, recommended sizes 17*30 mm;
2) Servos Dymond D-47 (4 pieces);
3) 6-channel receiver. 2. Assembly
2.1. Insert of control horns
Cut the grooves for the control horns with a knife as it is shown in the pictures
2.1-2.4
In the rudder in the right in the middle
In the elevating rudder at the distance of 103 mm from the left edge
In ailerons at the distance of 40 mm from the centre of the wing
Paste in the control horns using the epoxy.
Avoid contact of the superglue with the foam plastic of the wing and the tail
cores!

Cheeper
Assembly instruction SoaringModels
4
Picture 2.1. Pasting in the control horn of the rudder
Picture 2.2. Pasting in the control
horns of the ailerons Picture 2.3. Pasting in the control horn of the elevator
2.2.Pasting in the fin
Set up the wing and the stabilizer, insert the fin into the groove, set it vertically and
carefully pour it with superglue.
Picture 2.3. Installing the fin Picture 2.4. Pasting in the fin

Cheeper
Assembly instruction SoaringModels
5
2.3.Installing servos and tail rods
Mark out the holes for tubes, transmitter antennas and wires of the aileron servos with
a pencil, drill with a Ø2-mm drill and finish with a needle file.
Picture 2.5. Rework of the pod
Glue the tip to one of the ends of the carbon fiber rods, put on the thermal shrinkage
and heat shrink.
Picture 2.6. Pasting in the rod tip.

Cheeper
Assembly instruction SoaringModels
6
Cut off two 60-mm-long tubes, glue them like in the picture 2.7, glue the other 5-
mm-long ones with superglue to the beam with the pace of 50-60 mm
Picture 2.7. Pasting in the rod housing tubes
Cut off the eyelets on servos, wrap them with masking tape
and, if possible, with thin strong thread.
Picture 2.8. Preparation for the servo installation
Finish the rockers of the tail servos in such a way that an arm
is 4 mm long
Picture 2.9. Tail rockers

Cheeper
Assembly instruction SoaringModels
7
Temporarily glue 2 servos and an battery with tape to the beam in the most forward
position. Make sure the cap can be put on and machine rockers don’t touch it. Glue the
servos to the beam using superglue.
Picture 2.10. Installing the servos and the battery
Insert the rods into the tube and glue the
second set of tips, having set the average
position of the servos and the rudders.
Picture 2.11. Installing the tail rods
2.4. Installing the aileron servos
Drill a hole for the wires of the servos with a Ø5-6 mm drill. Take off the plastic
cases of the connectors to pass the wires through the holes, glue the servos using epoxy.
Don’t forget to set up the rocker in the right position and tighten the screw
beforehand!

Cheeper
Assembly instruction SoaringModels
8
Picture 2.12. Installing the aileron servos.
2.5. Inserting the dowel for
throwing
Round the dowel with sandpaper
until the shape is comfortable for you
to use
Picture 2.13. Dowel for throwing

Cheeper
Assembly instruction SoaringModels
9
At the distance of 15 mm from the wingtip
drill a hole for the dowel and then finish it
with a needle file. Spread the holes inside
with epoxy, insert the dowel and form a
rounding as it is shown in the picture.
Picture 2.14. Inserting the dowel for throwing.

Cheeper
Assembly instruction SoaringModels
10
2.6. Installation of the aileron rods
Insert the rode into the control horn, denote the position of the hole of the machine
rocker with a marker, bend the edges of the rods with pliers.
Picture 2.15. Installation of the aileron rods
2.7. Installation of the aileron machine covers
Picture 2.16. Installation of the aileron machine covers
Round the cover angles with sandpaper.
Cut through the groove for the rocker with a knife and finish it off with the needle
file.
Glue the covers on the double-sided tape.

Cheeper
Assembly instruction SoaringModels
11
2.8.Final assembly Fix the rods in the
control horns by the
pieces of the thermal
shrinkage (except the
elevating rudder rod)
Picture 2.17. Fixation of the rods in the control horns
Stretch the wires of
the aileron servos out
through the hole in
the pod and attach the
wing with the screws
Picture 2.18. Wing installation

Cheeper
Assembly instruction SoaringModels
12
3. Setting of the model
Set up the receiver and establish the alignment at the distance of 50-52 mm from the
front edge.
We recommend setting up 5 flight modes on the transmitter
Start - 0,5mm up Speed - 0 Regular flight -1,5mm down
Thermal –3mm down Braking - maximally down
