SOARING MODELS E-Kite 2P User manual

E-Kite 2P Soaring Models
Assembly instruction 2021
1
Kit components
Wing
Wing joiner
Fuselage with canopies
Fin
Stabilizer
Accessories

E-Kite 2P Soaring Models
Assembly instruction 2021
2
Accessories components
1- Tail rods
2- Reinforcement for ailerons axis
3- Tail torsions
4- Aileron’s rods
5- Tube for tail rods
6- Crimping tubes for tail rods
7- Ailerons axis
8- Servo tray
9- Tail horns
10-Aileron rod limiter
11-Ailerons horns
12-Fin screw M3*8 (+1 spare)
13-Front wing screw M3*12 (+1
spare)
14-Rear wing screw M3*10 (+1
spare)

E-Kite 2P Soaring Models
Assembly instruction 2021
3
Recommended electronic components
1- Battery 2S 350-500 mAh
2- Servos KST X-08H*4
3- Receiver 6-8 channels
4- ESC 15-30 A
5- Motor 1806 M5 shaft (CW thread)
Tools and materials for assembling
1- Ruler
2- Files
3- Sand paper
4- Knife
5- Cyanoacrylate
6- Epoxy

E-Kite 2P Soaring Models
Assembly instruction 2021
4
Tail assembling
Cut the slots for the control horns with a knife according to the pictures.
In rudder on the right side 5mm from the bottom.
In elevator at the bottom side 2mm left from center.
File out control horns before gluing.
Paste in control horns using epoxy with filler.
Make a holes for torsions with a needle,
install torsions and fix them with
cyanoacrylate.

E-Kite 2P Soaring Models
Assembly instruction 2021
5
Wing assembling
Clean up from foam slots for aileron horns and check is it fits good without glue.

E-Kite 2P Soaring Models
Assembly instruction 2021
6
File out control horns axis and spot for axis gluing.
Paste in control horns using epoxy with filler.

E-Kite 2P Soaring Models
Assembly instruction 2021
7
While epoxy is liquid press down axis to the slot in wing and fix it with CA.

E-Kite 2P Soaring Models
Assembly instruction 2021
8
Glue two layers of carbon about 8mm width from accessories set to reinforce axis
fixation using CA and a piece of film
Cut the rest of carbon and sand.

E-Kite 2P Soaring Models
Assembly instruction 2021
9
Servos installation
Cut servos control horns. Center distance should be about 7-8 mm.
Expand holes close to the wall of fuselage with the file.
Screw up 4 KST x-08h servos to servo tray.
Smear servo tray and spot for servos inside fuselage with epoxy.
Insert servo tray through the top hatch.

E-Kite 2P Soaring Models
Assembly instruction 2021
10

E-Kite 2P Soaring Models
Assembly instruction 2021
11
Connect rods to aileron horns and screw up wing to fuselage
Set ailerons in zero position and ailerons servos about 20 degrees back.

E-Kite 2P Soaring Models
Assembly instruction 2021
12
Fix servos with piece of foam and tape.
Rods should be protected from falling out from horns with fuselage wall. If rods can
fall out from horns, you can glue Aileron rod limiter to the fuselage wall.
Tail linkage
Make a loop for tail horns at the
wires. Stabilizer loop should be very
tight because of not a lot of free space
inside tail boom.

E-Kite 2P Soaring Models
Assembly instruction 2021
13
Make a hole for rudder wire at the middle line at the right side of fuselage

E-Kite 2P Soaring Models
Assembly instruction 2021
14
Lay wires through fuselage.
Set neutral position of tail servos, rudder and elevator.
Put on 20mm plastic tube to wire.
Crimp the crimping tube with pliers.
Fix plastic tube with CA.

E-Kite 2P Soaring Models
Assembly instruction 2021
15

E-Kite 2P Soaring Models
Assembly instruction 2021
16
Repeat same operations for the second tail servo.
For ease crimping inside fuselage you can make longer loop, fix crimping tube and
wire in zero position using CA, extract it from fuselage and crimp it.

E-Kite 2P Soaring Models
Assembly instruction 2021
17

E-Kite 2P Soaring Models
Assembly instruction 2021
18

E-Kite 2P Soaring Models
Assembly instruction 2021
19
Settings and flight modes
Recommended CG position 72-76 mm from leading edge
Cruise - 0 Normal flight –2mm down
Thermal –4-9mm down Brakes –maximum down
