SOARING MODELS Kite User manual

Kite SoaringModels
Assembly instruction 2019
1
Kit components
1- Wing
2- Fuselage
3- Fin
4- Stabilizer
5- Rod tubes
6- Accessories
Accessories components
1- T-peg
2- Servo covers
3- Aileron’s rods
4- Tail torsions
5- Aileron’s horns
6- Stabilizer horn
7- Fin horn
8- Connector
9- Connector’s mount for fuselage
10-Wing screws M3*10, M3*12
11-Tail screws M3*6
12-Crimping tubes for tail rods
13-Tail rods

Kite SoaringModels
Assembly instruction 2019
2
Recommended electronic components
1- Battery 1S 250-350 mAh
2- KST X-08H *2 + Dymond D-47 *2 or
KST X-08H *2 + KST X-08 *2
3- Receiver 4-8 channels
4- 400 mm servo wires 22 AWG
Tools and materials for assembling
1- Ruler
2- Files
3- Sand paper
4- Knife
5- Soldering iron
6- Cyanoacrylate
7- Epoxy
8- Two-side tape

Kite SoaringModels
Assembly instruction 2019
3
Mounting of control horns
Cut the slots for the control horns and aileron rods with a knife according to the
pictures.
In rudder on the right side in the middle.
In elevator at the top side.
In ailerons at the distance of 50 mm from center of the wing.

Kite SoaringModels
Assembly instruction 2019
4
File out control horns before gluing.
Paste in control horns using epoxy.

Kite SoaringModels
Assembly instruction 2019
5
T-peg installation
Prepare t-peg for gluing using file
Make a slot for peg using knife, file and wire.
Fill slot with epoxy and paste t-peg

Kite SoaringModels
Assembly instruction 2019
6
Servos installation
Clean pockets from foam
Mark hole position on aileron’s rod, ailerons should be 8-9mm down and servos in zero
position.
Bend the rod.

Kite SoaringModels
Assembly instruction 2019
7
Soldering ailerons connector
Make holes for wires in core from servos pockets to connector pocket.
Cut original connectors (don’t forget to setup zero position before) and lay the wires
through holes to connector pocket. Make soldering like at the picture
Glue servos and connector using epoxy with filler, keep ailerons 8-9mm down and servos
in zero position

Kite SoaringModels
Assembly instruction 2019
8
If you don’t use servo frame add foam or balsa for total servos fixing
If you use servo frames for KST X-08H glue it with epoxy to the pockets and fix servos
with screws
Fix servo covers with two-side tape

Kite SoaringModels
Assembly instruction 2019
9
Fuselage assembling
Make holes for wires and tubes
Glue servos for tail with 26mm from forward of fuselage
Lay rods through fuselage, put tubes on
rods and glue them in holes of fuselage.
Fix rods with tape temporary.
Make extension with 2*200mm wires for servos

Kite SoaringModels
Assembly instruction 2019
10
Lay extension into fuselage.
Glue mount part to connector, keep movable parts from glue!
Set connector into fuselage and check
contact with wing. Make corrections with
slot for connector with file if it needs.
Glue connector’s mount part to fuselage.
Make a holes for torsions with a needle, install torsions and fix them with cyanoacrylate

Kite SoaringModels
Assembly instruction 2019
11
File out place for tail boom on fin surface
Insert fin into slot in tail boom set it vertically and fix with cyanoacrylate

Kite SoaringModels
Assembly instruction 2019
12
Set neutral position of tail servos, rudder and elevator.
Crimp tube on cable.
On the end of elevator cable add 50-80mm spread or cable for easy assembling

Kite SoaringModels
Assembly instruction 2019
13
Settings and flight modes
Recommended CG position 74-78mm from leading edge
Launch mode –ailerons 1mm up Cruise - 0
Normal flight –2mm down Thermal –4-9mm down
Brakes –maximum down
