SOCO VS1 Installation instructions

Please do not use bike before you read this manual carefully and know function of it.
Please keep this manual carefully.
Follow us
Scan QR code to
download e-user manual
Vmoto Soco
www.vmotosoco.com

1
1
2
3
4
5
To ensure the safety of you and others, please make sure to observe the following matters:
1
2
3
SAFETY INSTRUCTION
USER INSTRUCTION
To ensure your safety,please read this manual carefully before riding and make sure you are always follow-
ing the requirements below:
Fully understand the information in this manual, include but not limited to the relevant instruction, precautions and warnings.
Fully understand the operation and contingency measures of VS1 smart electric bike.
Be Fully aware of warning labels of VS1 smart electric bike.
Don’t disassemble vehicle or any parts, if need replacement, please contact local dealer.
Please keep this manual carefully.
All parameters of this vehicle have been permanently set according to the national standard before leaving factory.The
company is not responsible, if the original electrical or circuit has changed and caused excess, such as increase the
speed.
Don’t lend your vehicle to someone who can’t operate it in order to prevent any hurts.
Please comply with local laws and regulations to drive on the road.
Do not ride after you take medications which may affect your riding ability, drink alcohol, or when you are unwell.

2
Observe traffic regulations and traffic signs, according to the provisions of laws and regulations to carry man and cargo.
Confirm the surrounding road conditions and bike condition any time,so as to actively avoid danger.
In rainy and snowy weather, braking distance will be extended, please slow down, Avoid travelling in bad weather such as
storms and typhoons.
Wear safety equipment, such as helmet, and appropriate protective clothing if necessary, such as gloves and mask.
To ensure the safety of you and others, please avoid using the high beam under good lighting conditions. Continuous use of
the high beam will cause visual obstacles to the opposite vehicles and pedestrians and affect the safe driving
Please turn off the power and remove the key immediately after use. Do not allow children to play, so as to avoid loss to your
family and property.
Perform a basic check each time before riding, and regularly go to SOCO Service Center for maintenance.
Check before riding. If there is any abnormality, please timely carry out maintenance or seek professional maintenance.
4
5
6
7
8
9
10
a. Check the status of power circuit, lighting circuit, etc.
b. Check whether the front and rear brakes work normally.
c. Check fixing of handlebars、 front and rear wheels
d. Check tire pressure.
USER INSTRUCTION

2 1 1
1 12
01
3
Intelligent remote control
key Rear view mirror wrench
Certificate,Operating manual
Charger
Rear view mirrors
Check accessories items
QUICK START

Assemble the rear view mirrors
02
QUICK START
4

03
1Put in the battery pack. 2 3 4
Open battery
compartment under the
seat and remove the
segregation board.
Plug-in the main
connector,switch on
circuit protector.
Put the segregation
board back and put
down the seat.
5
Install battery pack
QUICK START

04
QUICK START
Press ‘UNLOCK’ on remote
control.
1Wear helmet.
2 3
4 5 6
Ride on VS1,kick side
stand and main stand out.
Press ‘Power’on remote
control or turn the key to
ignition switch “On”
position, power on
Press ‘Parking’ button,
unparking VS1, parking
symbol off, READY light
on.
Turn accelerator gently,
VS1 run.
IGNITE VS1

6
Download APP
VS1 smart electric bike has GPRS function,can connect with your smart phone.
By APP,you can use smart phone to manage and query your VS1.
Only IOS and Android are currently available now,please confirm your smart phone operating system in advance.
SUPERSOCO
05
IOS system:APP only supports Apple ISO 9.0 system and above.
Android system: APP only supports Android 4.4 system and above.
Download and install the SUPER SOCO APP by QR code in this manual or key box.
QUICK START

7
DESCRIPTION OF COMPONENTS AND PARTS
OPERATION GUIDE
RIDING GUIDE
BATTERY USE INSTRUCTION
APP INSTRUCTION
MAINTENANCE
FAQ & TROUBLE SHOOTING
CUSTOMER SERVICE
08
10
16
19
20
21
22
25
CONTENTS

TOP VIEW
Front brake lever
Rear brake lever
Rear light
Left-handlebar switch assy
Accelerator
Right-handlebar switch assy
Brake cylinder
Winker
Speedometer assy
8
Seat
a. Speedmeter diagrammatic sketch
DESCRIPTION OF COMPONENTS AND PARTS

DESCRIPTION OF COMPONENTS AND PARTS
SIDE VIEW
a. Speedmeter diagrammatic sketch
Headlamp
Rear mirror
Brake system
Aluminum rim
FOC vector controller
Rear swing arm
Rear license bracket
Electronic side stand
OBD checking
Main stand
Rear winker
Rear license light
9

DESCRIPTION OF COMPONENTS AND PARTS
b. DESCRIPTION OF COMPONENTS AND PARTS
SPORT Mode NORMAL Mode ECO Mode
High beam indicator
Winker indicator light
Battery error/Charging now
Parking Light
VS1 in moving forward position
OBD checking error codes
Start lighting
READY
See page 16 FAQ & TROUBLE SHOOTING
VS1 is READY to ride when ready in display VS1 in reverse position
Charging light
Errors
10

DESCRIPTION OF COMPONENTS AND PARTS
11
b. DESCRIPTION OF COMPONENTS AND PARTS
1
2
3
4
1
Speed
Display current speed Display the total mileage
Time
Display current time
Endurance Mileage
Total mileage 7
Display current gear/Forward,reverse status.
Gear display/Forward,reverse status display
8
Display current controller temperature
Controller temperature
5
6
Display current A、B battery power
Power display bar
Battery percentage display
Display current A、B battery power percentage
(When work with two battery, battery percentage display the higher battery)
2
8
3
4
5
6 7
Display current
endurance mileage

2
3
1
OPERATION GUIDE
12
132
Press, horn on; release, horn off.
HORN SWITCHWINKER SWITCHHigh/low beam switch
Turn to left, left winker on;
Turn to right, right winker on.
Up position, high beam on;
Down position, low beam on.
a.LEFT SWITCH

1
2
3
13
R
1 3 Forward reverse switchMode switch 2Parking switch
VS1 is set with 3 modes: 1: ECO
mode 2: NORMAL mode 3: SPORT
mode. Position at left, mode 1;
position in the middle, mode 2;
position at right, mode 3.
Press the parking switch up,VS1 at
parking position,parking indicator
(P) light on;press the park switch
down display (READY) ,VS1 at
unparking status.
Gently press two times forward reverse switch
R,display mode number change to “F”,VS1 is
ready to move forward,turn accelerator
gently,VS1 can drive forward;press again,VS1
in reverse position,keep pressing “R”
button,turn accelerator gently,VS1 can move
backward;press again,display show mode
number as normal, VS1 in normal driving
position.
OPERATION GUIDE
b. RIGHT SWITCH

14
3. LOCK
2. UNLOCK
1. Key less start
After unlocking VS1 via remote control, press the
“POWER”, power on, press again, power off
When VS1 in resting state, press “LOCK”, “POWER”
flash, VS1 locked.
When VS1 in lock state,press “UNLOCK”, “POWER”
continuously on,VS1 unlocked.
VS1 use second generation smart remote control, within 50 meter radius, press the button, can lock or unlock your VS1.
c. REMOTE CONTROL
OPERATION GUIDE

15
d. Mechanical key
1. Mechanical key start 2. HANDLEBAR LOCK
3. Open storage & seat
After unlocking VS1 via remote
control,turn the key to “ON”posi-
tion,power on,turn the key back to
“OFF” position,power off.
Put in the key and press then turn left
Put the key in then turn left
1.VS1 in parking position, turn
handlebar to the extreme left position,
put key in handlebar lock, and turn the
key to right position, handlebar locked.
2.Put the key in handlebar lock, turn the
key to left position, handlebar unlocked.
Put key in storage&seat lock, turn
key to right direction, when hear
sound “click”, storage&seat open.
Press “unlock” 3s via remote
control, when hear sound “click”,
storage&seat open.
OPERATION GUIDE

16
OFF
ON
OPERATION GUIDE
g. KILL SWITCH
TIPS：For your own safety, please put kill switch at “OFF” position:
A. Before taking out battery pack;
B. Before cleaning and washing;
C. Long time storage.
Kill switch, protect power, when current over than set range cause by abnormal situation or short circuit, kill switch will stop
the connection between battery and VS1 automatically, for safety reason.

6
17
RIDING GUIDE
Any exceptions or operational doubts, please contact Super SOCO official dealer’s service center.
1
2
3
4
5
6
7
8
9
10
11
12
a. CHECKING LIST BEFORE RIDING
Make sure to check the following items before riding your VS1
Whether the handlebar is stable and flexible when turning.
Whether the right and left switches on the handlebar can work properly or not.
Whether the accelerator can work properly or not.
Make sure the tyre pressure is correct. The recommended tire pressure is 175Kpa for front wheel, 200kpa for rear
wheel(without passenger),225kpa(with passenger)
Check tyre surface, make sure no cracks, damage, and foreign matter puncture or attachment.
Whether the tread depth is enough,such as worn to the black shadow position on the sketch ,tyre need to be replaced.
Whether any error warning light in the speedometer with power on or not.
Whether the battery capacity is enough for your trip.
Whether all light work properly or not.
Whether the horn work properly or not.
Whether the mirrors are clean and adjust them to the appropriate angle.
Whether the brake oil is enough, whether the brake lever and brake
system work properly or not.

b. POWER ON
18
RIDING GUIDE
Press “UNLOCK” on remote
control
Put on helmet.
1Riding VS1, kick out side stand
and main stand.
2 3
5Turn throttle gently, VS1 run. 6
Press “POWER”or turn the
key to on position in ignition
switch, power on
Press ‘Parking’ button,
unparking VS1, parking symbol
off,READY light on.
4
