Soen Transit XS User manual

Pocket Size Premium Sound
by
ENGLISH USER GUIDE
®
®

INDEX
ABOUT ..........................................3
SET UP ..........................................4
CONTROLS .................................6
SPEC’S .........................................7
HELP ............................................8
CAUTIONS ...................................9
REGULATIONS ..........................10
CONTACT ..................................11

ABOUT
TRANSITXS
Pocket Size Premium Sound
The ultra-portable TRANSITXS sets a new standard for portable performance, style and fun with an
amazingly thin and compact speaker.
Finally a speaker with incredible sound that is truly small enough to take with you wherever you go.
Making it easier than ever to enjoy your music with friends at home or on the go.
INCREDIBLE SOUND & WIRELESS FREEDOM!
TRANSITXS utilizes the most advanced transducer and acoustic technologies available today and provides
amazing sound usually produced by speakers several times larger. SOEN wizards have engineered the
most compelling acoustic engine for high performance portable speakers. These exclusive SOEN
transducers combined with our other groundbreaking technologies including the revolutionary Momen-
tum Port™ provide rich and vibrant sound with thumping bass!
ABOUT SOEN AUDIO
SOEN was founded in California by industry leading designers, engineers and craftsmen, brought together
by their passions to create the world’s finest audio products. We are committed to continuously push the
frontiers of acoustics and bring you many more amazing products in future. The SOEN team thanks you
for choosing TRANSITXS and hopes that you will enjoy it for years to come!
FOR MORE INFO
Learn more about our latest products and high-performance technologies online at: www.SoenAudio.com
JOIN THE SOEN TRIBE ON FACEBOOK
Keep in touch and stay informed about new SOEN products and member benefits available exclusively for
our Facebook family: www.Facebook.com/SoenAudio
COMPATIBILITY
WIRELESS
TRANSITXS works with any wireless Bluetooth device
profile 2.0 or above, including:
Phones / Smartphones
Tablets
MP3 Players
Computers equipped with Bluetooth®wireless stereo
NOTE: When the 3.5mm jack is plugged in Bluetooth®will be automatically turned off.
WIRED
TRANSITXS will also work with any device that has a 3.5mm stereo output headphone jack.
PACKAGE CONTENTS
TRANSITXS Bluetooth®Wireless Speaker
SOEN Mounting Clip
36” (91cm) USB Charging Cable
36” (91cm) 3.5mm Stereo Audio Cable
Integrated Rechargeable Battery
TRANSITXS Quick Start Guide

SET UP
CONNECT TO YOUR BLUETOOTH DEVICE
Scan the QR code for direct access to
TRANSITXS Quick & Easy Set Up video
on our website.
1. Switch TRANSITXS ‘ON’. TRANSITXS comes partially charged and ready to use right out of the
box. Just switch it ‘ON’. If none of the power indicator LEDs comes ‘ON’, plug the TRANSITXS into a USB
Port using the included USB charging cable to charge the integrated battery. No damage will occur to
the speaker or battery if used before full charge.
2. Press and Hold the Option button ‘∞’until TRANSITXS begins emitting the Bluetooth pairing
tone. The charge-level indicator LED lights will also begin flashing, indicating TRANSITXS is in Bluetooth
pairing mode and available to connect with your Bluetooth device. NOTE: While in Bluetooth pairing
mode, TRANSITXS will emit the Bluetooth pairing tone every 3 seconds.
3. On the phone or device you are connecting, access the Bluetooth settings, turn Bluetooth ‘ON’,
then ‘Add’ or ‘Search’ for devices. When TRANSITXS by Soen appears in the device list, select it. If a
passcode is required, enter “0000”. Once TRANSITXS connects, it will produce the double beep to
confirm successful Bluetooth connection and the LEDs will stop flashing. Time to Rock!
For additional Bluetooth set up help, review the instruction manual that came with the device you are
trying to connect.
NOTE: This is a one-time set up for each device you connect to TRANSITXS. To pair TRANSITXS with
another device, repeat the steps above. TRANSITXS will remember upto 8 devices. After pairing more
than 8 devices, the first device will have to be paired with TRANSITXS again in order to connect with
TRANSITXS.
BLUETOOTH AUTO-RECONNECT
For your convenience, TRANSITXS remembers the device that it pairs with, and will attempt to reconnect
(for 15 seconds) to the last connected device every time it is turned ‘ON’.
If your device is out of range or has its Bluetooth feature turned ‘OFF’, TRANSITXS will not be able to
reconnect automatically. If the connected device goes out of range or loses connection with TRANSITXS,
you can easily reconnect by pressing the OPTION ‘∞’button.
PLAY AUDIO USING 3.5mm CABLE
Connect the included 3.5mm stereo cable to any audio output device, and plug it into the ‘3.5mm
Audio Input’ jack of TRANSITXS.
NOTE: When the 3.5mm jack is plugged in, Bluetooth will be automatically turned off.
1
2

SET UP
BATTERY LEVEL INDICATOR LEDs
When plugged in and charging the four charge-level indicator LEDs will blink to indicate that the
battery is charging. As the battery charge level increases, the LEDs will remain lit to display the
battery level.
Four LEDs ON: Battery Fully Charged
Three LEDs ON, One Blinking: Battery 76%–99% Charged
Two LEDs ON, Two Blinking: Battery 50%–75% Charged
One LED ON, Three Blinking: Battery 25%–49% Charged
All LEDs Blinking: �Battery 0%–24% Charged
CHARGING & PLAY TIME
TRANSITXS can be charged using the included USB charging cable. Simply connect the cable to a USB
power source. Any computer USB port or standard wall or car charger (for iPhone®, iPad®or other
smartphones and tablets) can be used to charge the internal TRANSITXS battery. For faster charge
times use a charger that has at least 1.5A output.
An empty battery takes between 2 to 3 hours to fully charge using a standard charger, and will
last 4 to 8 hours on a full charge (actual battery playtime depends on volume level and playback
content).
Battery can be charged with the TRANSITXS switched ON or OFF.
On Apple®iOS devices: The battery level of TRANSITXS will also be displayed directly next to the
battery level of your iPad or iPhone.
NOTE: The battery is not user replaceable.
AUTOMATIC ‘SLEEP’ MODE
To extend the battery playtime, TRANSITXS automatically enters ‘Sleep’ mode if no Bluetooth or wired
audio is playing.
To wake TRANSITXS from ‘Sleep’ mode, simply press any button and the system will restart. TRANSITXS
will then attempt to reconnect using Bluetooth, or playback over the 3.5mm audio cable if it is plugged
in.

CONTROLS
MUSIC PLAYBACK
When TRANSITXS is connected to device via Bluetooth, the OPTION ‘∞’button works as PLAY / Pause
button for music playback control. Simply press the OPTION ‘∞’button to control the music playback
directly from TRANSITXS.
PHONE CALLS
TRANSITXS provides a great speakerphone experience for hands-free phone calls by utilizing an
advanced integrated microphone and SOEN Precise Talk™ technology.
Accept Call or End Call: Press the OPTION ‘∞’button once.
Reject Call: ‘Press and Hold’ the OPTION ‘∞’button until the ‘REJECT Call’ tone is heard.
Easy Mount –�Standard (camera) Tripod Mount Connector
The integrated standard (camera) tripod mount (1/4”–20 connector) allows your new TRANSITXS to
be used with a broad range of standard and inexpensive accessories. This feature makes it even
easier to use TRANSITXS on the go, when and where you want it. From a simple belt clip for attaching
TRANSITXS to your backpack, or a bicycle handle bar mount, the options are endless. Mounting
accessories are sold separately.

SPEC’S
WARRANTY INFO
Through precision engineering, high quality materials and rigorous testing, we have worked hard to
ensure the reliability of TRANSITXS exceeds expectations. TRANSITXS is backed by SOEN with a one-year
limited warranty against hardware defects.
For any problems please visit www.SoenAudio.com for help and contact information.
STORAGE & TEMPERATURE
Do not leave the TRANSITXS exposed to extreme temperatures above 130°F (45°C) or below 32°F (0°C).
Prolonged exposure to extreme temperatures can cause damage to the TRANSITXS battery and
electronics. Do not leave TRANSITXS exposed to direct sunlight for extended periods of time as this may
damage or discolor the device.
TECHNICAL SPECIFICATIONS
Bluetooth 4.0 compliant. Profiles: A2DP (wireless stereo Bluetooth), HFP
Bluetooth wireless range: 33ft (10m)
Size: 2.6in (66.5mm) tall, 6.3in (160mm) wide x 1.0in (24.8mm) thin
Weight: 0.5 lb. (0.27kg)
Battery: Long-Life Lithium Polymer
Battery playtime: Between 4 to 8hrs (based on volume level and playback content)
Charging: Use a standard computer USB connection or wall/car charger
Micro USB port for charging.
Temperature range for use: 130°F (45°C) to 32°F (0°C)
BLUETOOTH INFO
The typical range for Bluetooth is up to 33ft. (10m)
TRANSITXS can pair up to 8 devices, but can only playback from one device at a time.

HELP
TROUBLESHOOTING
1. UNABLE TO CONNECT/PAIR WITH BLUETOOTH DEVICE.
Confirm your phone, tablet or device is compatible with Bluetooth version 2.0 or above by checking
the user guide of the device you are trying to connect.
Make sure the 3.5mm audio cable is NOT plugged into TRANSITXS. (NOTE: when the 3.5mm jack is
plugged in, Bluetooth is automatically turned off.)
Follow the connection instructions in the ‘SETUP’ section of this User Guide.
Switch TRANSITXS ‘OFF’ and back ‘ON’, and confirm at least one of the charge level LEDs is ON. If
none of the charge level LEDs comes on, plug TRANSITXS in to charge the battery.
Make sure the volume on TRANSITXS is turned up by pressing the ‘+’ button until you see the LED
flash quickly.
2. WIRELESS AUDIO IS DROPPING OUT.
Move TRANSITXS closer to the connected Bluetooth device.
Make sure TRANSITXS is charged, or plugged in and charging. At least one of the power level LEDs
should be ON.
3. AUDIO IS DISTORTED.
Lower the volume on TRANSITXS by pressing the ‘–’ button.
The best audio clarity will be achieved using the provided 3.5mm audio input cable.
Make sure the TRANSITXS Momentum Port™ is not blocked or obstructed.
Switch the TRANSITXS speaker ‘OFF’ and back ‘ON’.
Play a variety of tracks to confirm that the content is not corrupted ot low (bit-rate) quality.
4. TRANSITXS WILL NOT PLAYBACK USING 3.5MM AUDIO INPUT.
Make sure the volume on TRANSITXS is turned up by pressing the ‘+’ button until you see the LED
flash quickly.
Confirm audio is playing on your source device, and that the volume is turned up on the source
device.
Make sure the 3.5mm audio jack is plugged in FULLY to both the TRANSITXS speaker and the source
device.
Confirm that there is no damage to the audio cable.
Make sure TRANSITXS is turned ON and at least one of the charge level LEDs are ON.
Make sure TRANSITXS is charged or plugged in and charging.
STATIC DISCHARGE: TRANSITXS is designed to withstand normal static discharges, but in the event of
a significant static discharge TRANSITXS may lose Bluetooth connection or cause the LEDs to momentar-
ily turn off. To correct, simply turn the power switch ‘OFF’ and back ‘ON’.
a.
b.
c.
d.
e.
a.
b.
a.
b.
c.
d.
e.
a.
b.
c.
d.
e.
f.

CAUTIONS
SAFETY INFO
Please fully read all safety warnings carefully to ensure safety and prevent property damage.
FIRE & ELECTRICAL SHOCK HAZARD
Do not expose TRANSITXS to moisture, liquid, humidity, or rain because this may result in electrical
shock, or damage to the device.
Do not use TRANSITXS near a bathtub, sink, sauna, pool, steam room or any moist environment
because this may result in electrical shock or damage to the device.
Do not drop, disassemble, open, bend, microwave, burn, or manipulate the TRANSITXS speaker or any of
its accessories because this may result in electrical shock.
Do not insert foreign objects into the TRANSITXS speaker, including the Momentum Port™ opening or
speaker grill because this may result in electrical shock, or damage to the device.
Only clean TRANSITXS with a dry cloth when the device is unplugged from the charger.
Do not block any of the ventilation openings of the TRANSITXS speaker including the Momentum Port™
when it is in use.
Do not use the TRANSITXS speaker near any heat source including open flame, heater, stove, or radiator
as this may cause permanent damage to TRANSITXS.
BATTERY / CHARGING HAZARD
Do not remove or attempt to remove the non-user-replaceable battery. The battery is NOT replaceable.
Do not dispose of TRANSITXS in a fire; this could result in the battery exploding causing injury or death.
Only charge the battery in accordance with the user instructions for TRANSITXS. Use of non-specified
charging method may cause damage to the battery or electronics and could result in fire and the battery
exploding causing injury or death.
Do not disassemble the TRANSITXS speaker because this may result in electrical shock.
Do not charge the TRANSITXS speaker in or around damp areas because this may result in electrical shock.
Do not clean the TRANSITXS speaker when it is plugged in. Only clean TRANSITXS when it is unplugged
from the power source.
AUTOMOBILE ACCIDENT HAZARD
Do not become distracted by this product while driving.
Do not position TRANSITXS or any of its accessories near, on, above, or in front of any of your vehicle’s
airbags because serious injury or damage may result when an airbag deploys.

REGULATIONS
REGULATIONS
The TRANSITXS speaker contains no user serviceable components, attempting to open the speaker will
void the warranty.
Where the mains plug of wall charger is used as the disconnect device, such disconnect device shall
remain readily operable.
Switch the TRANSITXS speaker off using the power switch before boarding an aircraft, unless allowed
by your airline.
Do not place the TRANSITXS close to the edge of a table/shelf as vibrations from music playback may
cause the speaker to shift and fall, and may cause damage to the speaker or anyone or anything
affected by the fall.
PRODUCT DISPOSAL
If you wish to dispose of this product, please do so in accordance with applicable national legislation or
other rules in your country for the treatment of old electrical and electronic equipment.
This symbol indicates that the electrical and electronic equipment should not be disposed as general
household waste at its end-of-life. Instead, the product should be handed over to the applicable
collection point for the recycling in accordance with your national legislation.
By disposing of this product correctly, you will help to conserve natural resources and will help prevent
potential negative effects on the environment and human health that could otherwise be caused by
inappropriate waste handling of this product.
For more information about collection point and recycling of this product, please contact your local
municipal office, your household waste disposal service or the shop where you purchased the product.
Penalties may be applicable for incorrect disposal of this waste, in accordance with national legislation.
This device complies with FCC radiation exposure limits set forth for an uncontrolled environment.
This device complies with Part 15 of the FCC Rules and Industry Canada RSS-210.
Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause undesired
operation.
Warning: Changes or modifications to this unit not expressly approved by the party responsible for compli-
ance could void the user’s authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
Canada
This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the
following two conditions: (1) this device may not cause interference, and (2) this device must accept any
interference, including interference that may cause undesired operation of the device.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de
licence. L'exploitation est autorisée aux deux conditions suivantes : (1) l'appareil ne doit pas produire de
brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le
brouillage est susceptible d'en compromettre le fonctionnement.
The device meets the exemption from the routine evaluation limits in section 2.5 of RSS 102 and compliance
with RSS-102 RF exposure, users can obtain Canadian information on RF exposure and compliance.
Le dispositif rencontre l'exemption des limites courantes d'évaluation dans la section 2.5 de RSS 102 et la
conformité à l'exposition de RSS-102 rf, utilisateurs peut obtenir l'information canadienne sur l'exposition et
la conformité de rf.

CONTACT
Designed & Engineered by Soen Audio
31368 Via Colinas, Suite 106, Westlake Village
California 91362 USA
Phone/Fax: [phone]
www.SoenAudio.com
© 2014 Soen Audio. All rights reserved. SOEN™, the SOEN logo, TRANSIT-XS, Momentum Port™, and
Precise Talk™ are trademarks of Soen Audio. The Bluetooth®trademark and Bluetooth®logo are owned by
Bluetooth®SIG Inc. and any use of such marks by Soen is under license. Apple®, iPhone®, iPad®are
trademarks of Apple Inc., registered in the US and other countries.

ENJOY!
