The new series of thermosiphon systems EUROSTAR ECO, have
been designed in order to cope with
the demands of any market all over
the world specializing in very hot
climates without the need for
refilling the solar circuit.
Solar Water Heater
Quality Solar Systems
www. .comeurostar-solar
The EUROSTAR ECO solar
water heater is manufactured
in compliance with the
Internaonal Standards for
Quality Assurance ISO
9001:2008, is tested according
to internaonal standards
EN12976‐1‐2.
The collector's performance
and reliability is tested
according to EN 12975‐2.
The system has been granted
with the Solar Keymark
Cerficate.
SOLE S.A.is the inventor of the closed circuit
Solar Water Heater.

Eurostar EcoTank
Eurostar EcoCollector
The EUROSTAR ECO tank has a mild steel external
casing, with high temperature oven powder coating
for maximum protection from rain, sun and salty
environment, ensuring durability and an elegant
appearance.
The FREON FREE polyurethane insulation is casted
under pressure in the tank, surrounding the cylinder
and maintaining hot water for up to 48 hours.
The new revolutionary heat exchanger of the closed
circuit assures instant hot water at very high
temperature. The tank is made of low carbon steel
with a double “enameling” coating (glass), oven-
0
treated at 860 C.
The magnesium anode effectively protects the
cylinder from electrolysis. The backup electric heater
ensures hot water even in very cloudy days.
The EUROSTAR ECO collector casing is made of
specially designed extruded aluminum profile,
without any external connections, screws, nuts or
rivets. The Rockwool insulation will maintain very high
temperatures achieving an incredibly high efficiency.
The absorber is composed of Blue Selective
Aluminum fins 0,50mm thickness, welded to copper
pipes with laser welding.
The thermal liquid achieves maximum transfer of heat
to the water while protecting the system against
scaling, rusting, freezing and overheating.
SOLE's respect for
the environment
starts at the
production stage.
TYPE
A
B
C
D
E
F
G
H
I
J
K
150‐1‐S200
2147
878
1383
1960
800
500
1195
960
820
745
2411
200‐1‐S230
2147
878
1413
1960
800
530
