MT1-19-33
Operating Instructions
Model No. MT1-19-33
3092402
HumidiBreeze
MISTING SYSTEM

Thank you for choosing a Soleus Air HumidiBreeze Misting System. This owner’s manual will
provide you with valuable information necessary for the proper care and maintenance of your new
product. Please take a few moments to thoroughly read the instructions and familiarize yourself with
all the operational aspects of your new Soleus Air HumidiBreeze.
For your own records, please attach a copy of your sales receipt to this manual. Also, write the store
name/location, date purchased, and serial number below:
Store Name: ____________________________________________________
Location: ______________________________________________________
Date Purchased: _________________________________________________
Serial Number (located on back of unit): ______________________________
IMPORTANT INSTRUCTIONS
Before installing and using your HumidiBreeze, please read this owner’s manual carefully. Store this manual in a
safe place for future reference.
1) Always place the unit on a level surface.
2) Never use or store gasoline or other flammable vapor or liquid near this unit unless instructed by this
manual.
3) Maintain at least 10 inches (25 cm) clearance space around this unit. Do not block or cover air inlet or
outlet grilles.
4) The unit must be connected to a correctly grounded power supply.
5) Do not start or stop the unit by inserting or pulling out the power plug.
6) Do not use an adapter plug or extension cord.
7) Do not use the unit in the immediate surroundings of a bath, a shower or a swimming pool.
8) Do not insert anything into the air outlet. Do not obstruct air inlet or outlet grills unless instructed by this
manual.
9) Do not let children play near this unit.
10) Always inspect the cord for signs of damage before use. If the power cord is damaged, it must be replaced
by the manufacturer or a qualified service technician.
11) When cleaning the unit, always turn the unit off and unplug the power cord.
2

SPECIFICATIONS
• Noise level is measured at a distance of 3.28 ft away from the front of the unit, when the unit is in cooling mode.
• Power consumption is measured when the fan runs at the highest speed setting.
• These specifications are for reference only. For actual data, please refer to the rating label on the back of the unit.
• If the environment temperature is higher than the max operating temperature or lower than the minimum operating temperature,
the unit may not work properly.
DISCLAIMER
ALL INFORMATION AND THE TECHNICAL SPECIFICATIONS PRESENTED IN THIS USER’S MANUAL ARE THE
PRESENTATION OF THE MANUFACTURER. SOLEUS INTERNATIONAL HAS NOT CONDUCTED INDEPENDENT
TEST TO THE INFORMATION AND THE SPECIFICATIONS PRESENTED HEREWITHIN.
PACKAGE CONTENTS
HumidiBreeze Misting System
Operating Instructions
3
MODEL MT1-19-33
Humidifying Capacity 19 Gallons per Day
Water Tank Size 1 Gallon
Power Consumption 70 Watts
Air Flow Volume 353 CFM / 600m3/h
Power Source 120 V / 60 HZ
Sound Pressure Level <55 db(A)
Weight 20.8 lbs
Dimensions (WxDxH) 16.5”x10”x23.5”
WARNING: This fan is for use on 120 volts. The cord
has a plug as shown in A. An adapter as shown in C is
available for connecting three-blade grounding-type
plugs to two-slot receptacles. The grounding lug ex-
tending from the adapter must be connected to a per-
manent ground such as a properly grounded outlet
box. The adapter should not be used if a three-slot
grounded receptacle is available.
DO NOT DEFEAT THE SAFETY PURPOSE OF
THE GROUNDED PLUG.

PRODUCT DIAGRAM
4
POWER BUTTON
CENTRIFUGAL DISK
SECURING KNOB
FRONT PANEL
BASE
CARRYING HANDLE
AIR INLET & FAN
CONTROL DIAL
WATER RESERVOIR DRAWER
WATER LEVEL INDICATOR
WATER DRAIN

5
OPERATING INSTRUCTIONS
1) FILL THE WATER RESERVOIR - Pull the water reservoir drawer out from the back of the unit and fill
the water reservoir by pouring water into the drawer. Once you are finished filling the reservoir, close the
drawer in the back of the unit. SEE FIGURE A BELOW.
2) POWER ON THE HumidiBreeze - Plug the power cord into a three pronged grounded electrical outlet.
Once the unit is plugged in, press the power button to turn on the HumidiBreeze. When power is “ON” the
power button will light up blue in color. To turn off the HumidiBreeze, press the power button again.
When the HumidiBreeze is “OFF” the blue light on the button will shut off.
3) ADJUST THE HumidiBreeze POWER - Turn the control dial counter-clockwise to increase the power
(increases misting power) Turn the control dial clockwise to decrease the power (decreases misting power).
SEE FIGURE B BELOW.
4) When the water bucket is empty, turn the unit off and refill the water bucket. DO NOT fill the water
bucket while the unit is on.
FIGURE A
FIGURE B
INCREASE HumidiBreeze POWER DECREASE HumidiBreeze POWER

TROUBLESHOOING
MAINTENANCE
Note: Make sure power is off and the power cord is not plugged into an electrical outlet prior to
performing any maintenance on the unit.
1. Unplug the unit and let it cool completely.
2. To keep the product clean, the outer shell may be cleaned with a soft, damp cloth. You may use a mild
detergent if necessary. After cleaning, dry the unit with a soft cloth. CAUTION: DO NOT let liquid en-
ter the product.
3. DO NOT use alcohol, gasoline, abrasive powders, furniture polish, or rough brushes to clean the prod-
uct. This may cause damage or deterioration to the surface of the product.
4. DO NOT immerse the product in water.
5. If the unit is wet, wait until the unit is completely dry before use.
STORAGE
1. Drain all of the water from the water reservoir. SEE FIGURE C.
2. Store the product in a cool, dry location when not in use. Repack the unit in the original packaging to
prevent dust and dirt buildup.
6
Problem Possible Reason Solution
Not Working
No Power Plug in power cord to grounded three
pronged outlet
Bad Electrical Outlet Repair or change outlets
Little or No Water
Mist
Cooling control valve is set too low Turn the control dial counter-clockwise
to increase power.
Water Tank is Empty Fill Water Reservoir
Low Misting
Power
Cooling control valve is set too low Turn the control dial counter-clockwise
to increase power.
Low voltage coming from electrical
outlet Repair or change outlets
Not Enough Air-
flow Low voltage coming from electrical outlet Repair or change outlets
FIGURE C

WARRANTY
One Year Limited Warranty
Soleus International Inc. warrants the accompanying Soleus Air HumidiBreeze to be free of defects in material and
workmanship for the applications specified in its operation instruction for a period of ONE (1) year from the date of
original retail purchase in the United States.
If the unit exhibits a defect in normal use, Soleus International Inc. will, at its option, either repair or replace it, free of
charge within a reasonable time after the unit is returned during the warranty period.
As a condition to any warranty service obligation, the consumer must present this Warranty Certificate along with a
copy of the original purchase invoice.
THIS WARRANTY DOES NOT COVER:
• Damage, accidental or otherwise, to the unit while in the possession of a consumer not caused by a defect in
material or workmanship.
• Damage caused by consumer misuse, tampering, or failure to follow the care and special handling provisions
in the instructions.
• Damage to the finish of the case, or other appearance parts caused by wear.
• Damage caused by repairs or alterations of the unit by anyone other than those authorized by Soleus Interna-
tional Inc.
• Freight and Insurance cost for the warranty service.
ALL WARRANTIES, INCLUDING ANY IMPLIED WARRANTY OF MERCHANT ABILITY ARE LIMITED TO
ONE-YEAR DURATION OF THIS EXPRESS LIMITED WARRANTY. SOLEUS INTERNATIONAL INC.
DISCLAIMS ANY LIABILITY FOR CONSEQUENTIAL OR INCIDENTAL DAMAGES AND IN NO EVENT
SHALL SOLEUS INTERNATIONAL INC’S LIABILITY EXCEED THE RETAIL VALUE OF THE UNIT FOR
BREACH OF ANY WRITTEN OR IMPLIED WARRANTY WITH RESPECT TO THIS UNIT.
This warranty covers only new products purchased from our authorized dealers or retailers. It does not cover used, sal-
vaged, or refurbished products.
As some states do not allow the limitation or exclusion of incidental or consequential damages, or do not allow
limitation on implied warranties, the above limitations and exclusions may not apply to you. This warranty gives you
specific legal rights, and you may also have other rights that vary from state to state.
For Technical Support and Warranty Service
Please Call [phone]
Or Write To:
Soleus International Inc.
20035 E. Walnut Dr. N.
City of Industry, CA 91789 USA
www.soleusair.com
