Solight AV03T User manual

E
Thank you for purchasing our axial fan, suitable for use e.g. in the shower,
bathroom, toilet, kitchen etc. Please read this manual carefully and pay attention
to the safety warnings and instructions before using the device. This will ensure
not only the protection of persons, but also the long life of the equipment.
• 100mm (4")
EN AV03T
Axial fan with timer

Power
220-240V~,50Hz
1. DIMENSIONS
Model
ØA
B
C
D
100mm (4")
99mm
151mm
102mm
35mm
2. TECHNICAL PARAMETERS
Warning: The following parameters are for guidance only. Please refer to the
nameplate for details.
Model V/Hz Power Air volume Noise
100mm (4") 220-240V~,50Hz 12W 95m³/h 34dB
3. WIRING DIAGRAM
Motor supply
wire
Motor supply
wire
Engine
Terminal
Brown
Brown
Blue
Blue

4. TIMER
Timer wiring diagram
Time setting scheme
Using the timer
The fan with timer switches on when the control voltage (K) is applied to the
input. The timer allows the fan to continue to operate from 30s to 30min after
switching off, depending on the timer setting. The timer delay remains
unchanged until the next time the clock switch on the printed circuit board (PCB)
is pressed. The timer delay can be set by pressing the tact switch, after one press
the set timer delay will move to the next phase. Use an insulated tool to press the
tact switch to avoid damage to the switch.
PCB
timer
Display of delay time
Delay time indicator
Tact switch
light on
light off

5. INSTALLATION
1. Panel 2. PCB 3. Housing
4. Motor 5. Blades 6. Frame
7. Butterfly valve 8. Ring 9. Wall
10. Screwdriver

6. NOTICE
• Never install the fan in a location where the unit would be exposed to water,
flammable gases, or high temperatures.
• When using the switch to control power, avoid turning the switch on/off
frequently. Turn the switch off when the fan is not in use for an extended period
of time.
• If the power cord is damaged, it must be replaced by the manufacturer's service
personnel or by specialized personnel.
• This appliance is not intended for use by children or persons with reduced
physical, sensory or mental abilities.
• To prevent water and insects from entering, a ventilation cover should be
installed.
7. MAINTENANCE
• Disconnect the power cord for any handling or maintenance.
• Remove the louvers, cover, blade, etc. and wash them with a brush in water.
• Never use water at temperatures above 60°C, flammable substances or solvents
for cleaning.
• Do not allow water to enter the engine.
• Dry the cleaned parts with a soft dry cloth and return them to their original
places.
The product has been issued with a CE declaration of conformity in accordance with
the applicable regulations.
On request from the manufacturer: [e-mail], or downloadable from
www.solight.cz.
Solight Holding, s.r.o., Na Brně 1972, Hradec Králové 500 06, Czech Republic.
