Solight AV03 User manual

Thank you for purchasing our axial fan suitable for use e.g. in the shower,
bathroom, toilet, kitchen etc. Please read this manual carefully and pay attention
to the safety warnings and instructions before using the device. This will ensure
not only the protection of persons, but also the long term viability of the device.
• 100mm (4“)
EN AV03
Axial fan

Power
220-240V~,50Hz
1. DIMENSIONS
Model
ØA
B
C
D
100mm (4")
99mm
151mm
102mm
35mm
2. TECHNICAL PARAMETERS
Warning: The following parameters are for guidance only. Please refer to the
nameplate for details.
Model V/Hz Power Air volume Noise
100mm (4") 220-240V~,50Hz 12W 95m³/h 34dB
3. WIRING DIAGRAM
Motor supply
wire
Motor supply
wire
Engine
Terminal
Brown
Brown
Blue
Blue

4. INSTALLATION
1. Panel 2. Electronics 3. Housing
4. Motor 5. Blade 6. Frame
7. Check valve 8. Ring 9. Wall
10. Screwdriver

5. WARNING
• Never install the fan in a location where the unit would be exposed to water,
flammable gases, or high temperatures.
• When using the switch to control power, avoid turning the switch on/off
frequently. Turn the switch off when the fan is not in use for an extended period
of time.
• If the power cord is damaged, it must be replaced by the manufacturer's service
personnel or by specialized personnel.
• This appliance is not intended for use by children or persons with reduced
physical, sensory or mental abilities.
• To prevent water and insects from entering, a ventilation cover should be
installed.
6. MAINTENANCE
• Disconnect the power cord for any handling or maintenance.
• Remove the louvers, cover, blade, etc. and wash them with a brush in water.
• Never use water at temperatures above 60°C, flammable substances or solvents
for cleaning.
• Do not allow water to enter the engine.
• Dry the cleaned parts with a soft dry cloth and return them to their original
places.
The product has been issued with a CE declaration of conformity
in accordance with the applicable regulations.
On request from the manufacturer: [e-mail], or
downloadable from www.solight.cz.
Solight Holding, s.r.o., Na Brně 1972, Hradec Králové 500 06, Czech Republic.
