Solmetex Hg5 Quick start guide

1.800.216.5505
www.solmetex.com
TM
Hg5 Amalgam Separator NXT Hg5 Amalgam Separator
Change-Out Instructions
RPL_Cap_Inst_0319
1. Inspect the Hg5 air/water separator to insure there is no liquid waste in it. If liquid waste is present,
contact Solmetex for further instructions.
2. If no liquid waste is present in the air/water separator, then with the vacuum running, detach the Hg5
Collection Container from the Hg5 air/water separator by removing the retaining pins and tilting the
container to break vacuum seal.
3. Prepare Hg5 Collection Container for recycling by snapping plastic cap onto
the Hg5 Collection Container and place into the Hg5 Series Collection
Container Shipping Bag and seal according to instructions on the bag.
Finally, place bag into Recycle Kit box.
4. Next, turn vacuum o and detach vacuum hosing from the inlet port and
outlet port of the air/water separator.
5. Using a 7/16" wrench, loosen both top nuts on the upper bracket.
6. Lift bracket up and remove the air/water separator from the wall
backplate and place into the provided plastic bag and seal according
to instructions on the bag.
Good question. Solmetex is
now providing the hardware
necessary to change-out the
old Hg5 Amalgam Separator
to the new NXT Hg5
Amalgam Separator without
having to remove and replace
the blue backplate.
With the supplied hardware,
you can keep the existing
backplate on the wall, and
change only the bracket,
screws, nuts & bolts to install
your new NXT Hg5 Amalgam
Separator. It's that easy!
Why do I need this hardware replacement kit?
Hg5 Top Mount
Bracket
Hg5 Bottom
Mount Bracket
NXT RPL Top
Mount Bracket
NXT RPL Bottom
Mount Bracket
PROCEDURE:
Air/Water
Separator
Collection
Container

Congratulations on your
upgrade to the latest in
Amalgam Separation Technology
Clearly the leader in amalgam separation
TM
1.800.216.5505
www.solmetex.com
7. Next, remove the top and lower bracket
hardware from the backplate, insuring that the
screws remain in place.
8. Take the new NXT adapter hardware and
attach the lower bracket first, fastening and
securing the nuts.
9. Adjust screws in order to attach the top bracket,
place the nuts on, but do not fully tighten.
10. Mount the new NXT Hg5 air/water separator
onto the lower bracket.
11. Next, align with the top bracket by
inserting the black rubber tabs into
bracket holes and tighten all nuts in the
upper bracket.
12. Reattach vacuum hoses to the air/water separator.
13. Insert the new NXT Hg5 Collection Container
into the air/water separator and secure in place
using the retaining pins.
14. Restart the vacuum.
15. Finally, recycle the old Hg5 air/water
separator and recycle the Hg5 Collection
Container. Package and ship according to
the Solmetex recycling instructions.
