Solo 880-12 User manual

9 880 100 04/2012
880-12 / 880-14 // 881-12 / 881-14
Instruction Manual
Translation of the original instructions Cut-off machine
A
ttention!
Before first commissioning, read these operating
instructions thoroughly and observe the safety
provisions under all circumstances!
en

ENGLISH 1
Instruction manual cut-off machines 880-12 / 880-14 // 881-12 / 881-14
Translation of the original instructions
Dear customer
thank you for purchasing this quality product from
our company.
For many decades, we have been a producer of
hand-held and back-carried gas powered motor
devices. Each of our motor devices benefits from
this experience in detail today as well.
State-of-the-art production materials in connection
with our know-how warrant a long service life and
high utilisation value of the motor device.
The motor devices of this model line are
particularly high-quality cut-off machines of
German production and designed specifically for
the high demands of professional users. A newly
developed single-cylinder two-stroke high-
performance engine with stationary nikasil-coated
cylinder in proven four-channel technology for
great performance at low fuel consumption and
the latest exhaust cleaning technology warrant
high utilisation value of the motor-driven device.
Maintenance-free electronic ignition,
health-protecting anti-vibration system,
patented twin-pipe suction procedure,
vibration system for particularly easy interim
emptying of the air filter during work,
optionally usable water connection with water
supply to the cutting disc to reduce dust when
working,
smart solutions with electronic carburettor control
for simple starting and
ergonomic design and extremely compact build
ensure excellent operating comfort and facilitate
daily work with the motor device.
The safety equipment corresponds to the latest
state of the art and meets all nationally and
internationally relevant safety provisions. Among
others, it comprises:
One-touch stop button
Throttle control lock
Electronic speed limiter
Protective device for the cutting disc
Motor stop facility for maintenance purposes
Before first commissioning, read these operating instructions thoroughly and always
observe all safety provisions and instructions for action.
If you have any further questions after reading these operating instructions, contact your
specialist vendor.
Observe the maintenance guidelines closely to ensure the long service life of your
equipment

ENGLISH 2
Packaging and disposal
Please keep the original packaging in order to protect the equipment against transport damage in case
you ever need to ship or transport it If the packaging materials are no longer required they must be
disposed of properly in accordance with applicable local regulations. Cardboard packaging materials are
raw materials which can be recycled or reused.
At the end of the equipment’s service life, please make sure that you dispose of it in accordance with the
local provisions
Patents
The following patents are pending:
PCT/EP 2011/067574 (separate lubrication)
US13/331,898 (airbox)
The following patents have been granted:
US2010206278A1
US2009007435A1
US2010000846A1
EP2011594A2
EP2011991A2
EP2011992A2
Registered brands and trademarks
solo®and iLube®are registered brands of SOLO Kleinmotoren GmbH.
Any other product and company names named in these operating instructions may be registered brands or
trademarks of the respective manufacture. Use of these names by third parties for their purposes may
injure the rights of the manufacturer. The fact that the ® or ™ sign is missing does not mean that the
designation is a free brand name.
Reservation of changes
In the interest of continuous further development of our motor devices, we must reserve changes to the
delivery scope in form, technology and equipment. For that reason, no claims can be accepted with
reference to text and illustrations in this manual.

Table of Contents
ENGLISH 3
1Information about these operating instructions...............................................................................4
1.1Notational conventions used in the operating instructions............................................................4
2Warning, instruction and notice icons...............................................................................................4
3Safety provisions.................................................................................................................................6
3.1Correct use....................................................................................................................................6
3.2General safety notes.....................................................................................................................6
3.3Prescribed work clothing / PPE (Personal Protection Equipment)................................................7
3.4When fuelling up ...........................................................................................................................8
3.5In transport....................................................................................................................................8
3.6During assembly, cleaning, maintenance and repair....................................................................9
3.7Before start-up ..............................................................................................................................9
3.8When starting................................................................................................................................9
3.9During work.................................................................................................................................10
4Power tool description ......................................................................................................................11
4.1Technical data.............................................................................................................................11
4.2Type plate ...................................................................................................................................11
4.3Scope of delivery.........................................................................................................................12
4.4Device views and important operating and function parts...........................................................12
4.5Throttle control lock and throttle control......................................................................................14
4.6Function parts for starting ...........................................................................................................14
5Preparing for use...............................................................................................................................15
5.1Installing the cutting discs...........................................................................................................15
5.2Installing cutting discs with 1" inner bore ....................................................................................16
5.3Uninstalling the cutting disc.........................................................................................................16
5.4Adjusting protective cowl.............................................................................................................17
5.5Fuelling up...................................................................................................................................17
5.6Adjusting the ribbed belt tension.................................................................................................19
5.7Water connection for wet cutting.................................................................................................19
5.8Relocate cutting device from centre position to outer position....................................................20
5.9Initial commissioning / run-in behaviour......................................................................................22
6Starting up and switching off the engine ........................................................................................23
6.1Starting process..........................................................................................................................23
6.2Start-up position..........................................................................................................................24
6.3Switching on the engine..............................................................................................................24
6.4Switching off the engine..............................................................................................................24
7Power tool use ...................................................................................................................................25
7.1Cutting discs................................................................................................................................25
7.2Permissible cutting area and danger from kickback or drawing along........................................26
7.3Working behaviour and working technique.................................................................................27
7.4Cutting metal...............................................................................................................................27
7.5Cutting mineral materials ............................................................................................................28
8Operating and maintenance notes...................................................................................................29
8.1Cleaning and care.......................................................................................................................29
8.2Cleaning the screen filter insert of the connection piece.............................................................30
8.3Idle/carburettor adjustment .........................................................................................................31
8.4Air filter maintenance ..................................................................................................................32
8.5Spark plugs check and replacement if required..........................................................................33
8.6Ribbed belt replacement.............................................................................................................34
8.7Fuel filter replacement.................................................................................................................35
8.8Maintenance plan........................................................................................................................36
8.9Self-aid advice.............................................................................................................................37
8.10Shutting down and storage .........................................................................................................38
9Warranty .............................................................................................................................................39
10Wear parts ..........................................................................................................................................39
11EC Declaration of conformity ...........................................................................................................39
Table of Contents

Information about these operating instructions
ENGLISH 4
These operating instructions are an integral part of the motor device.
They contain important information and instructions for handling the motor device. Always follow
any specified safety regulations and instructions, as they are a prerequisite for ensuring that you
are working safely with the equipment.
These operating instructions must be kept available at the place of use of the equipment at all
times, and they must be read carefully by everybody who works on or with the equipment (including
for maintenance, care and repairs).
These operating instructions must only be used as operating instructions for the motor device 880/881.
Any utilisation of the contents (text and graphics illustrations) – even in excerpts – without our prior written
consent shall be forbidden and may be prosecuted.
Text highlights
Xxxxx Underlined text marks interim headlines.
Xxxxx Text in italics marks advice and notes that facilitate use of the motor device for the user.
1 Xxxxx Numbered text with a black background marks main chapter headlines.
1.1 Xxxx Numbered text with a grey background marks main subchapter headlines.
Xxxxxxx Frames mark especially highlighted sections.
Structure
The operating instructions are structured by numbered main and subchapters. The table of contents on
page 3 shows an overview of the structure.
Header
To make it easier for the user to find the chapters, the header names the main chapter to which the
content on the respective page belongs.
Pictures and diagrams
Some graphical illustrations in these operating instructions are schematic illustrations or principle
illustrations and may not show exactly your device model. The conveyed contents, however, are binding in
any case.
Important: If one or several icons in these operating instructions are centred and directly below a
chapter header the notice applies for the entire chapter.
1 Information about these operating instructions
1.1 Notational conventions used in the operating instructions
2 Warning, instruction and notice icons
