SOLZAIMA SIENA User manual

Instruction Manual
English
Insert Fires
SIENA | ORION | RIALTO | SIRIUS | URANO | IACO
BASIC | SLIM | DUO – BO
BASIC | SLIM | DUO – BACK BO
HERA | LOKI | JUNO | HEKA
Mod. 115 – J

2
Thank you for purchasing a SOLZAIMA unit.
Please read this manual carefully and keep it for future reference.
* All our products fulfil the requirements of the European Regulation (Reg UE 05/2011) and have
been certified with the CE conformity trademark;
* SOLZAIMA disclaims responsibility for damages to the unit if it is installed by non-qualified personnel;
* SOLZAIMA disclaims responsibility for damages to the unit if the rules for installation and use
described in this manual are not followed;
* All local regulations, including those referring to national and European standards, should be
complied with when installing the unit;
* Our Insert Fires have been tested according to standards EN 1 229:2001 + EN
1 229:2001/AC:200 + EN 1 229:2001/A1:200 + EN 1 229:2001/A2:2004 + EN
1 229:2001/AC:2006 + EN 1 229:2001/A2:2004/AC:2006;
* Technical support is normally provided by SOLZAIMA, except in exceptional cases to be determined
by the installer or support technician;
* Whenever you need assistance, you should contact your unit’s supplier or installer. You should
provide its serial number, which is on the identification plate located on the left side of the ash drawer,
as well as on the label on the back cover of this manual.

3
Contents:
1. Technical Specifications…………………………………………………………………………………………………………………….. 5
2. Your unit…………………………………………………………………………………………………………………………………………… 9
3. Components……………………………………………………………………………………………………………………………………… 12
4. Installation………………………………………………………………………………………………………………………………………… 13
Combustion Air an Gas Circulation………………………………………………………………………………………………. 13
Installation Location Requirements………………………………………………………………………………………………. 15
Force Ventilation…………………………………………………………………………………………………………………………. 16
Force Ventilation (Double Si e Equipment)………………………………………………………………………………. 18
Switches Ventilation Kit 3 an 4 Si es Frame………………………………………………………………………………… 21
Switches Ventilation Kit Integral Frame…………………………………………………………………………………………. 24
5. Instructions for Use…………………………………………………………………………………………………………………………… 27
Fuel……………………………………………………………………………………………………………………………………………….. 27
Power……………………………………………………………………………………………………………………………………………. 28
Energy Efficiency an Performance Ratings…………………………………………………………………………………… 28
A First Use…………………………………………………………………………………………………………………………………….. 29
Normal Use…………………………………………………………………………………………………………………………………… 29
Optional Accessories……………………………………………………………………………………………………………………… 30
A itional Outlets…………………………………………………………………………………………………………………………. 31
6. Safety………………………………………………………………………………………………………………………………………………… 31
7. Cleaning an Maintenance………………………………………………………………………………………………………………. 32
8. Troubleshooting………………………………………………………………………………………………………………………..……… 33
9. En of Life………………………………………………………………………………………………………………………………….…….. 33
10. Sustainability………………………………………………………………………………………………………………………….…….. 34
11. Glossary………………………………………………………………………………………………………………………………….…….. 35
12. Warranty……………………………………………………………………………………………………………………………….……… 37
13. Statement of Performance……………………………………………………………………………………………………………. 44

4
Solzaima
Having first entered the market in 1978, we are a leading specialist company in the design and
manufacture of biomass heating solutions, including insert, back boiler and free-standing fires.
As a market leader and specialist in the area in which we operate, we put a premium on the quality of
our products to make sure that we satisfy our customers' needs.
Solzaima is certified in accordance with standards ISO9001:2015 (Quality Management) and
ISO14001:2015 (Environment) and is well aware of its environmental obligations. In addition, we
submit to a demanding testing regime in order to guarantee top quality and performance across our
entire range of products, in terms of raw materials selection, control of the manufacturing process,
and treatment of all the waste generated. All this to ensure your home is fitted with solid and reliable
equipment.

5
1. Technical Specifications
Insert fires are designed to heat their surroundings and are perfect for those who already own a
fireplace and intend on refurbishing it or simply making it more efficient and cost-effective - such is the
case of wall-mounted fires or, as they are commonly known, "cassettes".
Our stores offer you a range of options to suit the design of your room. The Back Box and Box units
come in Basic, Slim and Duo variants, so you can find the right model to blend harmoniously into its
surroundings without any need for major alterations, as they do not insert into the wall.
* Technical specifications across the range:
* CE certified
* Average reloading time: ≤ 45 minutes
* Fuel: Dry firewood
* Voltage: 2 0 V (except Urano/Iaco, Basic/Slim/Duo - Box)
* Frequency: 50 Hz (except Urano/Iaco, Basic/Slim/Duo - Box)
* Power: 2x8,5 W (except Urano/Iaco, Basic/Slim/Duo - Box)
* Type of Equipment: intermittent use

6
Table 1 - Technical Specifications for each Unit
W – Width; H – Height
1
Power output is calculate by taking into account a variation of  30% in relation to the rate output.
2
Consumption of firewoo , taking into account the range of power outputs.
Siena Orion Rialto Sirius Urano
Dimensions W H W H W H W H W H
Front (inches/mm) 27,6
70
26,6
678
1,6
80
4,5
678
5,5
90
26,6
678
5,5
90
26,6
678
27,6
70
2 ,
59
Casing (inches/mm) 24,6
627
2 ,2
590
28,6
727
2 ,2
590
2,5
827
2 ,2
590
2,5
827
2 ,2
590
24,6
627
19,8
504
Total Depth (inches/mm) 16,7 / 425 18,2 / 462 18,2 / 462 24,5 / 624 16,7 / 425
Flue Ø (inches/mm) Ø 5,9 / 150 int. Ø 7,0 / 180 int. Ø 7,0 / 180 int. Ø 7,8 / 200 int. Ø 5,9 / 150 int.
Rated output (kW) 7 9,5 11 16,5 7
Efficiency (%) 71 71 71 75 71
CO Emissions (1 %O
2
) (%) 0,20 0,20 0, 7 0,26 0,20
CO2 Emissions (%) 8,8 9,7 8,79 11,2 9,7
Average combustion temperature
(ºF/ºC) 802 / 428 70 / 7 599 / 15 696 / 69 802 / 428
Combustion flow (g/s) 10 11 10 1 10
Power output
1
(kW) 4,9 – 9,1 6,7 – 12,4 7,7 – 14, 11,6 – 21,5 4,9 – 9,1
Firewood consumption
2
(pounds/kg / h) ,7 / 1,7 – 6,8 / ,1 ,5 / 1,6 – 6,4 / 2,9 4 / 1,8 – 7,5 / ,4 7,9 / ,6–14,5 / 6,6 ,7 / 1,7 – 6,8 / ,1
Weight (pounds/kg) 172 / 78 200 / 91 220 / 100 268 / 122 147 / 67
Maximum heated volume (m ) 207 279 2 488 207
Energy efficiency rating Class 1 Class 1 Class 1 Class 1 Class 2
Length Firewood (inches/mm) 15,7 / 400 19,6 / 500 19,6 / 500 19,6 / 500 15,7 / 400
Depression (Pa) 12 12 12 12 12
Chamber width (inches/mm) 19,6 / 500 2 ,6 / 600 27,5 / 700 27,5 / 700 19,6 / 500

7
3
Power output is calculate by taking into account a variation of  30% in relation to the rate output.
4
Consumption of firewoo , taking into account the range of power outputs.
Box
Iaco Basic Slim Duo
Dimensions
With 4
-
sided frame
(50 mm)
W H W H W H
W
H
Front (inches/mm) 1,6
80
2 ,
59
,4
850
6,6
9
,4
850
7
942
66,9
1700
6,7
9
Casing (inches/mm) 28,6
727
19,8
504 --- --- --- --- --- ---
Total Depth (inches/mm) 18,1 / 462 2 ,6 / 600 2 ,6 / 600 2 ,6 / 600
Flue Ø (inches/mm) Ø 7,0 / 180 int. Ø 7,8 / 200 int. Ø 7,8 / 200 int. Ø 7,8 / 200 int.
Rated output (kW) 9,8 10 10 10
Efficiency (%) 68 75 75 75
CO Emissions (1 %O
2
) (%) 0,20 0,26 0,26 0,26
CO2 Emissions (%) 9,7 11,2 11,2 11,2
Average combustion temperature
(ºF/ºC) 70 / 7 696 / 69 696 / 69 696 / 69
Combustion flow (g/s) 11 1 1 1
Power output (kW) 6,9 – 12,7 7 – 1 7 – 1 7 – 1
Firewood consumption
4
(pounds/kg / h) 5,4 / 2,45 – 10,1 / 4,6 ,7 / 1,7–6,8 / ,1 ,7 / 1,7–6,8 / ,1 ,7 / 1,7–6,8 / ,1
Weight (pounds/kg) 176 / 81 17 / 144 7 / 15 8 / 174
Maximum heated volume (m ) 290 294 294 294
Energy efficiency rating Class 2 Class 1 Class 1 Class 1
Length Firewood (inches/mm) 19,6 / 500 2 ,6 / 600 2 ,6 / 600 2 ,6 / 600

8
5
Power output is calculate by taking into account a variation of  30% in relation to the rate output.
6
Consumption of firewoo , taking into account the range of power outputs.
Back Box
Basic Slim Duo
Dimensions W H W H W H
Front (inches/mm) ,4
850
40,5
10 0
,4
850
40,7
10 6
66,9
1700
40,5
10 0
Casing (inches/mm) --- --- --- --- --- ---
Total Depth (inches/mm) 16,9 / 4 0 16,9 / 4 0 16,9 / 4 0
Flue Ø (inches/mm) Ø 7,0 / 180 int. Ø 7,0 / 180 int. Ø 7,0 / 180 int.
Rated output (kW) 11 11 11
Efficiency (%) 71 71 71
CO Emissions (1 %O
2
) (%) 0, 7 0, 7 0, 7
CO2 Emissions (%) 8,79 8,79 8,79
Average combustion temperature
(ºF/ºC) 599 / 15 599 / 15 599 / 15
Combustion flow (g/s) 10 10 10
Power output
5
(kW) 6,4 – 12 6,4 – 12 6,4 – 12
Firewood consumption
6
(pounds/kg /
h)
, 9 / 1,54
6, / 2,86
, 9 / 1,54
6, / 2,86
, 9 / 1,54
6, / 2,86
Weight (pounds/kg) 279 / 127 286 / 1 0 7 / 15
Maximum heated volume (m ) 267 267 267
Energy efficiency rating Class 1 Class 1 Class 1
Length Firewood (inches/mm) 2 ,6 / 600 2 ,6 / 600 2 ,6 / 600

9
7
Power output is calculate by taking into account a variation of  30% in relation to the rate output.
8
Consumption of firewoo , taking into account the range of power outputs.
Hera Loki Juno Heka
Dimensions W H W H W H W H
Front (inches/mm) 27,6
70
26,6
678
1,6
80
26,6
678
5,5
90
26,6
678
5,5
90
26,6
678
Casing (inches/mm) 24,6
627
2 ,2
590
28,6
727
2 ,2
590
2,5
827
2 ,2
590
2,5
827
2 ,2
590
Total Depth (inches/mm) 17,0 / 4 2 18,5 / 469 18,5 / 469 24,9 / 6 4
Flue Ø (inches/mm) Ø 5,9 / 150 int. Ø 7,0 / 180 int. Ø 7,0 / 180 int. Ø 7,8 / 200 int.
Rated output (kW) 7 9,5 11 16,5
Efficiency (%) 71 71 71 75
CO Emissions (1 %O
2
) (%) 0,20 0,20 0, 7 0,26
CO2 Emissions (%) 8,8 9,7 8,79 11,2
Average combustion temperature
(ºF/ºC) 802 / 428 70 / 7 599 / 15 696 / 69
Combustion flow (g/s) 10 11 10 1
Power output
7
(kW) 4,9 – 9,1 6,7 – 12,4 7,7 – 14, 11,6 – 21,5
Firewood consumption
8
(pounds/kg /
h) ,7 / 1,7 – 6,8 / ,1 ,5 / 1,6 – 6,4 / 2,9 4 / 1,8–7,5 / ,4 7,9 / ,6–14,5 / 6,6
Weight (pounds/kg) 172 / 78 198 / 90 222 / 101 271 / 12
Maximum heated volume (m ) 207 279 2 488
Energy efficiency rating Class 1 Class 1 Class 1 Class 1
Length Firewood (inches/mm) 17,5 / 400 19,6 / 500 19,6 / 500 19,6 / 500
Depression (Pa) 12 12 12 12
Chamber width (inches/mm) 19,6 / 500 2 ,6 / 600 27,5 / 700 27,5 / 700

10
2. Your unit
ORION ORION with STAINLESS STEEL FRAME
SIRIUS SIRIUS with STAINLESS STEEL FRAME
URANO URANO with STAINLESS STEEL FRAME
Range with optional accessory – stainless steel or colour-
matching frame, either 1,95in (5cm) or 3,9in (10 cm) wide
Forced ventilation Combustion air
intake damper
Vermiculite
panels
Vermiculite panels
Combustion air intake
damper
Door handle
Forced ventilation
Combustion air
intake damper
Door handle
Vermiculite panels
Door handle

11
BO Range
BASIC BO SLIM BO
DUO BO
BACK BO Range
BASIC BACK BO
BACK BOX also comes in SLIM BACK BOX and DUO BACK BOX variants.
Combustion air
intake damper
Door handle
Firewood box
Forced ventilation
Smoke outlet
Vermiculite panels
Combustion air
intake damper
Vermiculite
panels
Smoke outlet
Door handle
Firewood box

12
GLASS Range
HEKA with 3 SIDES FRAME HEKA with 3SIDES FRAME
HEKA with INTEGRAL FRAME
JUNO with 3SIDES FRAME JUNO with 4 SIDES FRAME
JUNO with INTEGRAL FRAME
Figure 1 - Orion, Sirius, Urano, Box, Back Box, Heka and Juno units
Vermiculite panels
Combustion air
intake damper
Door handle
Forced
ventilation
Vermiculite panels
Combustion air intake
damper
Door handle
Forced
ventilation

13
3. Components
* Our insert fires are built entirely of top-quality carbon steel plate, with a thickness of 0,118 inches (
mm) and 0,19 inches (5 mm) in the combustion chamber and 0,019 inches (1,5mm) in the casing.
Other parts, such as the door and ash drawer, use 0,019 inches (1,5 mm) and 0,078 inches (2 mm)
plates;
* Heat-resistant ceramic glass. Can handle temperatures of up 1 82°F (750°C) in continuous use;
* The combustion chamber is coated with a heat-resistant material known as vermiculite, a hydro
silicate that can withstand temperatures in the order of 2012°F (1100°C). Its insulating properties allow
the unit to take better advantage of the heat, improve efficiency and provide greater protection for the
steel plate forming the combustion chamber walls, thus prolonging the life of the equipment.
* Heat-resistant paint for temperature peaks up to 1652°F (900°C) and operating temperatures in the
order of 1112°F (600°C);
* The ash grate is made from a 0,19 inches (5mm) thick plate.

14
4. Installation
ttention: all regulations and standards must be complied with when installing this stove.
Combustion Air and Gas Circulation
* This type of stove should be installed in a well-ventilated area. Any air intake grilles should be placed
in locations that are not liable to become blocked.
* Additional air inlets may be needed if the stove is used in simultaneous with other devises that
require an air supply. The installer should evaluate the situation according to the overall air flow
requirements.
* Use of this unit at the same time as other heating devices that require an air supply may necessitate
additional air inlets. The installer should assess the situation in light of total air flow requirements.
* Under normal operating conditions, the combustion gas flow should create a draught of 12 Pa one
metre above the throat of the flue. For proper installation, at least 78,7 inches (2 metres) of metal flue
tube with the same diameter as the unit's smoke outlet should be fitted vertically above the unit. After
this section, sections of tubing with a maximum angle of 45° may be used.
Figures 2 and illustrate correct and incorrect angles for installing a bend.
45º45º
Figure - Correct angle for bends Figure 3 - Incorrect angle for bends
* A single-walled tube installed on the outside of a building results in the condensation of water vapour
in the combustion gases. We therefore recommend the use of a double – walked insulated pipe.
* The pipe joints must be tightly sealed so that possible cracks do not allow air to enter.
45º45º45º

15
Correct sealing
Incorrect sealing
* The pipe connections must not allow bottlenecks (reductions) and the internal walls must be perfectly
smooth and free of obstacles; the hats must be placed in such a way that they do not hinder draught.
Incorrect Correct
* The flue outlet should allow for good air circulation and be placed at least 9, 7 inches (1 m) above
the top of any obstacle located within a distance of 9,8 feet ( m).
Incorrect Correct
* The same flue should not be used for more than one unit or open fireplace. With shared chimneys,
each flue should reach its outlet independently and these should be at the same level to ensure that
the air circulation expels the gases.
Minimum 1 m
acima o ponto
Minimum istance
equal to the tube
iameter.

16
* Brick chimneys should not be too wide, as the smoke will cool as it disperses, reducing the draft. In
case of draft problems, a revolving chimney cowl can be installed.
Installation Location Requirements
* The unit should stand on a masonry hearth made of refractory bricks or another type of non-
combustible material.
* It is recommended for insert fires to be insulated with insulating material with a thickness of 1,57
inches (40 mm) and a density of 154 pounds (70 kg/m ) (except for the Back Box and Box ranges, in
their Basic, Slim and Duo variants). All units should be installed at least 15,7 inches (400 mm) from
combustible materials.
* Combustible materials should not be installed close to the walls of the unit.
* The floor on which the unit will stand must be able to support a permanent load of 2,2 pounds
(1kg)/cm². If the load capacity of the floor is insufficient, a solid plate can be used to distribute the load
over an area larger than the unit’s base.
* The building’s air intake grilles should not be obstructed.
* There should be a gap of around 0,19 inches (5 mm) between the unit and ornamental stones, to
allow room for the metal to expand. These should also be installed so as to allow the unit to be
removed without causing damage, if the need arises; This recommendation does not apply to the
Back Box and Box ranges, in their Basic, Slim and Duo variants.
* Ensure that the opening in the wall is of an appropriate size to house the unit.
* Materials/objects placed in front of the unit, as well as behind in the case of the Box range, should
be able to withstand the heat radiated from the glass of the door(s), so should not be combustible.
* Refractory cement or other refractory material should be applied on the chimney walls.
* The use of wood finishings may increase the risk of fire. Therefore, we recommend the use of
adequate insulation or that wood not be used at all.

17
Forced Ventilation
* The devices that are equipped with forced ventilation incorporate one tangential fan with power of
8 W and a min and max air flow of about 60 m /h and 165 m /h respectively, connected in parallel
with a thermostat, according to the following diagram.
Figure 4 - Ventilation Kit Diagram
Figure 5 - Electrical diagram
Thermostat
Cable Clamp
Fan
Resistor
3
Pos.
Switch
Groun
Neutral
P
hase
Resistor
Termostato
Fan
Interruptor 3 Pos.
Connector

18
Figure 6 - Switch Location
Figure 7 - 3 Position Switch
Attention: all three wires in the power feed cable – ground, neutral and phase – should be connected.
We take no responsibility for any damage resulting from non-compliance with this warning.
* The electrical components should always be connected to the power supply.
* The cable used for the electrical connection should be silicon-coated and heat-resistant to 56°F
(180°C). If the power feed cable is damaged, it should only be replaced by a qualified technician.
* You should take care to not lay the cable where it may be crushed.
* The electrical installation should incorporate means to switch the unit off, with a minimum separation
of 0,118 inches ( mm) between the contacts, pursuant to the applicable legislation in force
9
.
9
We recommen the use of a 30 mA ifferential switch an a 0.5 A circuit breaker for the unit’s electrical installation.
Position I – Tangential fan automatically turns on with air
flow of 60 m /h when the thermostat reaches
50 °C.
Position 0 – Tangential fan keeps inactive.
Position II – Tangential fan is activated manually with air
flow of 165 m /h.

19
Forced Ventilation (Double Sided Equipment)
* The devices that are equipped with forced ventilation incorporate two tangential fans with power of
8 W and a min and max air flow of about 60 m /h and 165 m /h respectively, connected in parallel
with a thermostat, according to the following diagram.
Figure 8 - Ventilation Kit Diagram
Thermostat
Resistor
Resistor
3 Pos.
Switch
Cable Clamp
Fan
Connector
Connector

20
Figure 9 - Switch Location
Figure 10 - 3 Position Switch
Attention: all three wires in the power feed cable – ground, neutral and phase – should be connected.
We take no responsibility for any damage resulting from non-compliance with this warning.
* The electrical components should always be connected to the power supply.
* The cable used for the electrical connection should be silicon-coated and heat-resistant to 56°F
(180°C). If the power feed cable is damaged, it should only be replaced by a qualified technician.
* You should take care to not lay the cable where it may be crushed.
* The electrical installation should incorporate means to switch the unit off, with a minimum separation
of 0,118 inches ( mm) between the contacts, pursuant to the applicable legislation in force
10
.
10
We recommen the use of a 30 mA ifferential switch an a 0.5 A circuit breaker for the unit’s electrical installation.
Position I – Tangential fans automatically turns on with air
flow of 60 m /h when the thermostat reaches
50 °C.
Position 0 – Tangential fans keeps inactive.
Position II – Tangential fans are activated manually with
air flow of 165 m /h.
