SONIQ Qmedia QMi92GB User manual

-1-
Notes on Copyright
It is forbidden by law to copy, broadcast, show, broadcast on cable, play in public, or rent copyrighted material
without permission.
Apparatus Claims of U.S. Patent Nos. 6,836,549; 6,381,747; 7,050,698; 6,516,132 and 5,583,936 licensed for
limited viewing uses only.
This product incorporates copyright protection technology that is protected by U.S. patents and other intellectual property
rights. Use of this copyright protection technology must be authorized by Macrovision, and is intended for home and other
limited viewing uses only unless otherwise authorized by Macrovision. Reverse engineering or disassembly is prohibited.
On Placement
• Do not use the unit in places that are extremely hot, cold, dusty, or humid.
On Safety
• When connecting or disconnecting the AC adaptor, grip the plug and not the cord itself. Pulling the cord may
damage it and create a hazard.
• When you are not going to use the unit for a long period of time, disconnect the AC adaptor.
On Condensation
• When left in a heated room where it is warm and damp, water droplets or condensation may form inside the unit.
When there is condensation inside the unit, the unit may not function normally. Let the unit stand for 1 to 2 hours
before turning the unit on, or gradually heat the room up and allow the unit to dry before use.
Ventilation Warning
• Do not block the ventilation openings or holes. (If the ventilation openings or holes are blocked by a newspaper
or cloth, etc., the heat may not be able to get out.)
• Do not operate the unit in a confined space, such as a bookcase or built-in cabinet, allow about 10cm of free
space all around the unit for adequate ventilation.
Rating Plate Location
• The rating plate is located on the bottom of the unit.
WARNING:
• Should any trouble occur, disconnect the AC adaptor and refer servicing to a qualified technician.
• The apparatus should not be exposed to splashing or dripping liquids, and no objects filled with liquids,
such as vases, should be placed on apparatus.
• The AC adaptor is used as the disconnect device and it shall remain readily operable. If a malfunction
occurs, disconnect the AC adaptor from the wall outlet at once.
CAUTION
INVISIBLE LASER RADIATION WHEN OPEN
AND INTERLOCKS DEFEATED.
AVOID EXPOSURE TO BEAM
This product contains a
low power laser device.
The symbol for Class II
(Double lnsulation)
* SEE BOTTOM OF UNIT FOR
GRAPHIC SYMBOLS *
The lightning flash with an arrowhead symbol,
within the equilateral triangle, is intended to alert
the user to the presence of uninsulated "dangerous
voltage" within the product's enclosure that may be
of sufficient magnitude to cause an electric shock.
WARNING: TO REDUCE THE RISK OF ELECTRIC
SHOCK, DO NOT REMOVE COVER (OR BACK).
NO USER-SERVICEABLE PARTS INSIDE. REFER
SERVICING TO QUALIFIED SERVICE PERSONNEL.
WARNING: TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.
The exclamation point within the equilateral
triangle is intended to alert the user to the
presence of important operating and maintenance
(servicing) instructions in this owner's manual.
Safety Instructions

-2-
SAFE USE OF YOUR EQUIPMENT
Here are a few tips to help you do this:
READ this instruction manual before you attempt to use the equipment.
NEVER fit make shift stands or legs with woodscrews. Use only approved supports and fasteners specially
designed for the equipment.
NEVER let anyone, especially children, push objects into holes, ventilation slots or any other opening; this
could result in fatal electric shock!
ALWAYS disconnect the AC adaptor when you are not going to use the unit for a long period of time.
ENSURE that all electrical connections (including the mains plug, extension leads and interconnections
between pieces of equipment) are properly made in accordance with the instructions given. Switch off the
main supply when making or changing connections.
CONSULT your dealer if you are ever in doubt about the installation, operation or safety of your equipment.
DON'T continue to operate the equipment if it is damaged in any way or if it does not function normally.
Disconnect the AC adaptor and consult your dealer.
DON'T leave equipment switched on when it is unattended unless it is part of it's normal function to operate
in your absence, for example a video cassette recorder with timed recording facility.
LISTEN to headphones at moderate volume levels; high volume levels can permanently damage your
hearing.
WARNING:
• AC adaptor is used as the disconnect device. It shall remain readily operable and should not be
obstructed during intended use. To be completely disconnected the apparatus from supply mains, the AC
adaptor of the apparatus shall be disconnected from the mains socket outlet completely.
• Never use an AC adaptor that is damaged, route power lead in a safe manner and make sure it is not
subjected to trapping or pinching. If the power lead is damaged refer to a qualified service agent.
• Place the unit on a flat and even surface.
• Do not restrict the air flow of the unit by placing it in a place with poor air flow, by covering it with a cloth,
or by placing it on carpeting.
• To avoid magnetized, do not place the unit near speaker or magnet.
• Do not use this unit in direct sunlight or leave the unit in a closed automobile (or yacht, etc) where it
would be exposed to high temperatures above 40°C.
• Use the apparatus in moderate climates.
• No naked flame sources such as lighted candles should be placed on the AC adaptor and main unit.
Important safety instructions

-3-
Safety Instructions .................................. 1
Important Safety Instructions................. 2
Table of Contents .................................... 3
Disc Formats............................................ 4
Accessories ............................................. 5
Remote Control........................................ 5
Control Reference Guide ................... 6 - 7
Power Supply...................................... 8 - 9
Using the AC adaptor ................................. 8
Using the car power adaptor ...................... 8
Using the rechargeable battery ................... 9
Turning on the unit ...................................... 9
Connections........................................... 10
Connecting a TV........................................ 10
Using headphones / earphones ................ 10
Sound System........................................ 10
Playing a Disc ................................. 11 - 12
Playing a disc ............................................ 11
Pausing playback (still mode).................... 11
Stopping playback ..................................... 11
Fast forward / Fast reverse ....................... 11
Skip (forward / reverse) ............................. 11
Audio selection ......................................... 11
Subtitle selection ....................................... 12
Angle selection .......................................... 12
Display function ......................................... 12
Adjust the LCD screen .............................. 12
Locating a Desired Section .................. 13
Locating a specific title .............................. 13
Locating a specific chapter........................ 13
Locating a specific time ............................. 13
DVD Programmable Memory................ 14
Playing titles / chapters in a favourite order
.................................................................. 14
Repeat Playback .................................... 14
Repeating a chapter / title ......................... 14
Repeating a single track / whole disc ........ 14
Repeating a specific section...................... 14
Viewing JPEG Files ............................... 15
Viewing JPEG Files................................... 15
Play Modes for CD or JPEG Disc......... 15
Play modes for CD or JPEG disc .............. 15
Customizing the Function Settings
..........................................................16 - 17
Language setup......................................... 16
Video setup ............................................... 16
Rating setup .............................................. 17
Misc setup ................................................. 17
Using Your iPod..............................18 - 19
Compatible iPod types: ............................. 18
Connecting your iPod ................................ 18
Playing music ............................................ 18
Playing videos ........................................... 19
Playing photos........................................... 19
Maintenance........................................... 20
Cleaning the disc....................................... 20
Cleaning the unit ....................................... 20
Important note ........................................... 20
Troubleshooting Guide ......................... 21
Carrying Bag Installation...................... 22
Table of Contents

-4-
The unit can playback discs bearing any of the following marks:
Region Management Information
Region Management Information: This unit is designed and manufactured to respond to the Region Management
Information that is encoded on DVDs. If the region number printed on the DVD does not correspond to the region
number of this unit, this unit cannot play that disc.
The region number of this unit is 4.
Disc Function or Operation that is Not Available
When the symbol appears on the TV screen, it indicates that the function or operation attempted is not available
at that time. This occurs because the DVD manufacturer determines the specific functions. Certain functions may
not be available on some discs. Be sure to read the documentation provided with the disc.
Title, Chapter and Tracks
• DVDs are divided into “titles” and “chapters”. If the
disc has more than one movie on it, each movie would
be a separate “title”. “Chapters” are sections of titles.
• Audio CDs are divided into “tracks”. A “track” is
usually one song on an Audio CD.
Note:
• Numbers identify each title, chapter, and track on a disc. Most discs have these numbers recorded on them, but
some do not.
Icons Used on DVDs
Sample lcons
Note:
• When playing back a CD-G (Graphics) or CD EXTRA disc, the audio portion will be played, but the graphic
images will not be shown.
Notes on Unauthorized Discs
You may not be able to play back some DVDs on this unit if they were purchased from outside your
geographic area or made for business purposes.
DVDs
[8cm(3")/12cm(5") disc]
Audio CDs
[8cm(3")12cm(5") disc]
Compatible
Language selections for audio
Language selections for subtitles
Screen aspect ratio
Multiple camera angles
Region code indicator
Disc Formats

-5-
Using the Remote Control
• Point the remote control at the REMOTE SENSOR
located on the unit.
• When there is a strong ambient light source, the
performance of the infrared REMOTE SENSOR may
be degraded, causing unreliable operation.
• The recommended effective distance for remote
operation is about 16 feet (5 meters).
BATTERY REPLACEMENT
When the battery becomes weak, the operating distance of the remote control will be greatly reduced and you will
need to replace the battery.
Notes:
• If the remote control is not going to be used for a long time, remove the battery to avoid damage caused by
battery leakage corrosion.
• Corrosion, oxidation, battery-leakage and any other gradually acidic defect of this nature will void the warranty.
• When discarding batteries, environmental problems must be considered and local rules or laws governing the
disposal of these batteries must be followed strictly.
WARNING:
• Do not dispose of battery in fire, battery may explode or leak.
• The battery should not be exposed to excessive heat such as sunshine, fire or the like.
CAUTION:
Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type.
To Change Remote Battery
1. Open the battery door.
Remove the plastic sheet before operating the
remote control.
2. Insert one CR2025 (3V) size battery.
Remote Control
Accessories
Remote control (with battery)...........................................................................................x 1
AC Adaptor ......................................................................................................................x 1
Car Power Adaptor...........................................................................................................x 1
Earphones .......................................................................................................................x 1
Audio/Video Cable ...........................................................................................................x 1
Carrying Bag....................................................................................................................x 1
Instruction Manual............................................................................................................x 1
Warranty Card..................................................................................................................x 1
Hotline Card .....................................................................................................................x 1
Please check and identify the supplied accessories.

-6-
Remote Control
1) VIDEO MODE button
Adjust Brigntness, Contrast, Color or View mode
of the LCD screen.
2) PREV button
Move back through titles, chapters or tracks.
3) / SEARCH buttons
SEARCH: Fast reverse playback.
SEARCH: Fast forward playback.
4) GOTO button
Skip directly to a location on a DVD.
5) Cursor ( , , , ) buttons
Use to move between selections on a menu
screen and adjust certain settings.
, Buttons
Navigate the iPod menu lists.
ENTER button
Confirm selections on a menu screen.
6) MEMORY button
In STOP mode, set titles/chapters in a favourite
order.
7) Number (0 - 9) buttons
Use when entering password, creating programs
or locating a title/chapter/track or specific time.
8) REPEAT A-B button
Perform point-to-point repeat playback on a DVD
or CD.
REPEAT DISC button
Repeat a DVD chapter or title.
Repeat a CD track or the whole disc.
SETUP button
When a DVD is stopped, display the unit’s SETUP
menu.
9) SUBTITLE button
Select one of the subtitle languages programmed
on a DVD (if available).
RETURN button
Return to normal operation after using the SETUP
menu of a DVD.
10) AUDIO button
Select one of the audio sound tracks on a DVD
(if more than one is available) or select the audio
output mode on a CD.
11) ANGLE button
Switch between multiple camera angles when the
DVD you are playing has been programmed with
multiple camera angles.
12) DISPLAY button
Show status information on the screen.
13) STOP button
Stop playback.
PLAY button
Start or resume playback.
PAUSE button
Press once to pause playback. Press subsequently
to advance frame by frame on a DVD.
14) NEXT button
Move forward through titles, chapters or tracks.
15) MENU button
Enter and exit the main DVD menu.
Return to the previous menu in iPod mode.
Control Reference Guide

-7-
Unit
1) LCD screen
2) iPOD / DVD switch
3) DC IN 9V-12V jack
4) VIDEO OUT jack
5) AUDIO OUT jack
6) CHARGE / STANDBY / ON switch
7) VOLUME control
Adjust the volume.
8) Headphones / Earphones jack
9) NEXT button
Move forward through titles, chapters or tracks.
PREV button
Move back through titles, chapters or tracks.
PAUSE button
Press once to pause playback. Press subsequently
to advance frame by frame on a DVD.
PLAY button
Start or resume playback.
STOP button
Stop playback.
/ buttons
SEARCH: Fast forward playback.
SEARCH: Fast reverse playback.
10) iPod docking bracket
11) Disc door
Close tray by pushing the disc door.
12) OPEN knob
Slide the OPEN knob rightwards to open the disc
door.
13) Remote sensor
Receive the remote control unit signals.
14) ON indicator
When the CHARGE / STANDBY / ON switch is
in the ON position, the light will illuminate.
15) CHARGING indicator
Charge the rechargeable battery before using
it for the first time. The normal charging time is
approximately 4-5 hours. The charging light will
go out when the battery becomes fully charged.
Control Reference Guide

-8-
A. Using the AC Adaptor
This AC adaptor operates on AC between 100V~ and 240V~.
• The supplied AC adaptor is suitable for use on AC mains supplies of 100-240V~ and should only be connected
to a mains supply within these parameters.
Cautions:
• The AC adaptor included with this unit is for its use only. Do not use it with other equipment.
• Turn off the unit before unplugging the AC adaptor from the unit so as to avoid the unit being damaged.
• When the unit is not going to be used for long time, disconnect the AC adaptor from the AC outlet.
IMPORTANT
• Be sure to use it near the wall outlet and easily accessible. If a malfunction occurs, disconnect the plug from
the wall outlet at once.
• When the AC adaptor is plugged in, the apparatus is not completely disconnected from the main power source,
even when the unit is turned off.
B. Using the Car Power Adaptor
The 12V car power adaptor is designed for use with vehicles that have a 12V, negative ground electrical system.
Cautions:
• Use only the included 12V car power adaptor. Use of any other 12V car power adaptor could damage the unit.
• The 12V car power adaptor included is for use with this unit only. Do not use it with any other equipment.
• In the interest of traffic safety, drivers should not operate the unit or view videos while driving.
• If the inside of the cigarette lighter socket is dirty with ashes or dust, the plug section may become hot due to
poor contact. Be sure to clean the cigarette lighter socket before use.
• After use, disconnect the car power adaptor from both the unit and cigarette lighter socket.
• If the unit is not properly attached to a vehicle, it may become airborne in the event of an accident and cause
damage, injury, or death.
• Check your local traffic laws for rules governing the use of video devices in vehicles before using this unit in
your vehicle.
Car power adaptor 2
1
To the cigarette
lighter socket
LEFT SIDE OF UNIT
To DC IN 9V-12V jack
WARNING:
Disconnect this car power
adaptor when not in use.
Not for use in 24V vehicles.
LEFT SIDE OF UNIT
To AC outlet
2To DC IN 9V-12V jack
1
AC adaptor
Power Supply

-9-
C. Using the Built-in Battery
The unit has a built-in, non-replaceable, rechargeable battery. Charge the built-in battery before using it for the
first time. The normal charging time should be completed within 4-5 hours. The charging light will go out when the
built-in battery becomes fully charged.
To Recharge the Built-in Battery
Turning On the Unit
1. Slide the CHARGE / STANDBY / ON switch on the left side of the unit to ON position.
2. Slide the iPOD / DVD switch to DVD position. The DVD logo (start-up picture) will appear
on the screen.
3. After use, slide the CHARGE / STANDBY / ON switch to the STANDBY position.
Warnings:
• The built-in battery can only be recharged when the unit is in CHARGE mode while using the AC adaptor.
• The built-in battery cannot be recharged when the unit is in power ON mode.
• Do NOT recharge the built-in battery using the car power adaptor.
• The unit should not be exposed to excessive heat such as sunshine, fire or the like.
Cautions:
• The AC adaptor included with this unit is for its use only. Do not use it with other equipment.
• When the unit is not going to be used for long time, disconnect the AC adaptor from the AC outlet.
• When the AC adaptor is plugged in, the apparatus is not completely disconnected from the mains, even when
the unit is turned off.
Condition and attention:
• When the built-in battery power is low, "BATTERY LOW" will display on the screen and the unit will stop playing.
• Recharge the built-in battery when you are ready to use it again.
• While using the built-in battery, the environmental temperature should be 5°C (41°F) to 35°C (95°F).
• To get the longest service life of the built-in battery, charge at indoor-temperature.
• The built-in battery in this device may present a risk of fire or chemical burn if mistreated. Do not disassemble,
heat above 100°C (212°F), or incinerate.
• When discarding the unit, environmental problems must be considered and local rules or laws governing the
disposal of such products must be strictly followed.
3Slide the switch
to CHARGE
AC adaptor
4Charging light ON
5
Recharging is
completed when
charging light
goes out
2To DC IN
9V-12V jack
1To AC outlet
Power Supply

-10-
A. Connecting a TV
If your TV has audio/video inputs, you can also connect the unit to your TV using the Audio/Video cable, and
watch DVD on your TV screen.
Audio/Video cable
To AUDIO OUT jack
LEFT SIDE OF UNIT
TV
White Red Yellow
Manufactured under license from Dolby Laboratories.
"Dolby" and the double-D symbol are trademarks of Dolby Laboratories.
Dolby Digital
Dolby Digital is a technology developed by Dolby Laboratories. Soundtracks encoded in Dolby Digital can
reproduce from one to 5.1 discrete channels of excellent quality audio.
The unit automatically recognizes the Dolby Digital bitstream and provides a downmix suitable for two-channel
listening. An additional Dolby Digital decoder is required for reproduction of the discrete multi-channel soundtracks
available on many DVDs.
LEFT SIDE OF UNIT
Headphones /
Earphones
(3.5mm diameter plug)
B. Using Headphones / Earphones
• Turn down the volume before connecting, and then
adjust the level.
• When headphones / earphones are connected, no
sound will be emitted from the unit's speaker.
Caution:
• Avoid listening to sound at levels which may be
harmful to your ears.
To VIDEO OUT jack
Connections
Sound System
Watching a DVD on your TV
1. Turn on the unit. Set "Video Out Only" to "On" in the Video Setup menu. (Refer to Video on page 16.)
2. Turn on the TV and set its source to AV or similar (see the TV instruction manual for details).
Notes:
• The unit TFT LCD screen will be off when output video to the TV. The TFT LCD screen will be on again
automatically after the unit is power off and on again.
• If you accidentally activate "Video Out Only" when the unit is not connected to a TV, please turn the unit off and
then back on to restore output on the unit's screen.

-11-
Playing a Disc
1. Slide the CHARGE / STANDBY / ON switch to the ON position. Slide the iPOD / DVD switch to the DVD position.
See CUSTOMIZING THE FUNCTION SETTINGS before proceeding to step 2.
2. Slide the OPEN knob rightwards to open the disc door.
3. Hold the disc by its sides and carefully place it onto the spindle with the label side
facing up, pushing gently until you hear a “click”.
4. Close the disc door.
It takes a short while for your unit to load the disc. After loading, the unit will
automatically bring you to the main menu of the DVD or start playing the DVD.
5. If the unit does not automatically start playing the DVD, press the PLAY button.
Pausing Playback (Still Mode)
Press the PAUSE button. To resume normal playback, press the PLAY button.
Each time you press the PAUSE button, the picture advances one frame on a DVD.
Stopping Playback
Press the STOP button at the location where you want to interrupt playback. To resume playback at the position
where the disc was stopped, press the PLAY button.
If you press the STOP button twice, the unit’s memory will be cleared and pressing the PLAY button will reset
the disc to the beginning.
Fast Forward / Fast Reverse
1. Press the SEARCH or SEARCH button when a disc is playing. Each time you press the SEARCH or
SEARCH button, the playback speed changes in the following sequence:
2. Press the PLAY button when you reach the desired point to resume normal playback.
Notes:
• The DVD player mutes sound and subtitles during reverse and forward scan of DVDs.
• The fast playback speed may differ depending on the disc.
Skip (Forward / Reverse)
• Press the PREV button to move back through titles, chapters or tracks.
• Press the NEXT button to move forward through titles, chapters or tracks.
• For audio CDs, use the number buttons on the remote control to go directly to the desired track number.
Audio Selection
On some DVDs, the sound is recorded in two or more formats. Follow the directions below to select the preferred
language and sound system.
1. While a disc is playing, press the AUDIO button to show the current audio format number.
2. Press the AUDIO button repeatedly to select the desired audio format.
Notes:
• If only one audio format is recorded on the DVD, the number does not change.
• Some DVDs allow you to change audio selections only via the disc menu. If this is the case, press the MENU
button and choose the appropriate language on the disc menu.
• You can select different audio channels (Stereo, Left or Right) on an Audio CD by pressing the AUDIO button
repeatedly.
This owner’s manual explains the basic instructions for operating this unit. Some DVDs are produced in
a manner that allows specific or limited operation during playback. Therefore, this unit may not respond
to all operating commands. THIS IS NOT A DEFECT. Please refer to the instructions accompanying the
specific DVD in question for more information about the options available on that DVD.
“ ” may appear on the screen during operation. A “ ” means that the desired operation is not
permitted by the unit or disc.
Playing a Disc

-12-
Subtitle Selection
1. While a DVD is playing, press the SUBTITLE button to display the current language setting,
as shown in the example.
2. Press the SUBTITLE button repeatedly to select the desired subtitle language. You can turn subtitles off by
pressing the SUBTITLE button repeatedly until the “ ” is displayed.
Notes:
• Some DVDs are set to display subtitles automatically, and you cannot turn them off even if you set the subtitle
function to off.
• During some scenes, the subtitles may not appear immediately after you select your desired scene.
• The number of subtitle languages recorded differs depending on the disc. If only one language is recorded, the
language does not change.
• This function can only be used for discs on which subtitles have been recorded in multiple languages.
• Some DVDs allow you to change subtitles only via the disc menu. If this is the case, press the MENU button
and choose the appropriate subtitle on the disc menu.
Angle Selection
Some DVDs contain scenes that have been shot from a number of different angles. For these discs, the same
scene can be viewed from each of these different angles.
1. While you are playing a DVD with different angles recorded, press
the ANGLE button to view the number of current angles available.
2. Press the ANGLE button repeatedly to change the scene to the
next recorded angle.
• After approx. two seconds, playback will continue from the new
angle selected.
• If no button is pressed within 10 seconds, playback continues
without changing the current angle.
Notes:
• This function can only be used for discs on which scenes shot from multiple angles have been recorded.
• If only one angle is recorded, “ ” is displayed.
Display Function
While the DVD is playing, press the DISPLAY button repeatedly to display
information on operation status.
Elapsed Time: Elapsed time from the beginning of the title that is
currently playing.
Remain Time: Remaining time of the title that is currently playing.
Adjust the LCD Screen
You can adjust Brightness, Contrast, Color or View mode of the LCD screen.
1. Press the VIDEO MODE button.
2. Press the /button to select Brightness, Contrast, Color or View mode.
3. Press the / button to change the setting. (For View Mode, press the ENTER button to change the setting.)
4. Press the VIDEO MODE button to exit the menu.
Sequence of Display
(Example)
Sequence of angle shots
(Example)
Playing a Disc

-13-
Locating a Specific Title
If a DVD contains title numbers, you can locate a specific title by directly selecting its title number.
1. Press the GOTO button.
2. Press the corresponding number button(s) for the title you want.
3. Press the ENTER button to confirm. Playback starts from the selected section.
Notes:
• If the title numbers entered is not permitted by the DVD, after you press the ENTER button, it will restore to - - -.
You should re-enter correct numbers.
• Some discs may not respond to this process.
• This method of locating a title is available only on a DVD that contains title numbers.
Locating a Specific Chapter
If you know the chapter number for the chapter that you want to play, you can locate it by directly selecting that
number.
1. Press the GOTO button.
2. Press the or button to display Chapter and press the corresponding number button(s) for the chapter you
want.
3. Press the ENTER button to confirm. Playback starts from the selected section.
Notes:
• If the chapter numbers entered is not permitted by the DVD, after you press the ENTER button, it will restore to
- - -. You should re-enter correct numbers.
• Some discs may not respond to this process.
• This method of locating a chapter is available only on a DVD that contains chapter numbers.
Locating a Specific Time
You can move to a specific location by entering its corresponding time (seconds, minutes, hours).
1. Press the GOTO button.
2. Press the or button to display Time and press the corresponding number buttons for the setting point you
want.
3. Press the ENTER button to confirm. Playback starts from the selected section.
Notes:
• If the time numbers entered is not permitted by the DVD, after you press the ENTER button, it will restore to
- - : - - : - -. You should re-enter correct numbers.
• Some discs may not respond to this process.
• Some scenes may not be located as precisely as specified.
• This method for accessing specific locations is available only within the current title of the DVD.
Locating a Desired Section

-14-
Playing Titles/Chapters in a Favorite Order
You can combine your favorite titles/chapters and play them in the order you determine.
1. When a DVD is stopped, press the MEMORY button. The following display appears.
2. Select the items in the order you want by pressing the number buttons.
Each time you press the Cursor buttons ( , , , ), the space is highlighted.
Highlight where you want to enter, then press the corresponding number buttons.
3. Press the Cursor buttons ( , , , ) to move the highlighted bar to Play Memory,
then press the ENTER button. The DVD player starts memory playback.
4. To resume normal playback from memory playback
1).Press the MEMORY button in stop mode.
2).Press the Cursor buttons ( , , , ) to move the highlighted bar to “Clear All”,
then press the ENTER button. All the input programs will be cleared.
3).Press the PLAY button to resume normal playback.
Notes:
• If the title or chapter numbers entered is not permitted by the DVD, after you press the ENTER button, it will
restore to - - -. You should re-enter the correct numbers.
• Some discs may not permit memory playback operation.
• If you select repeat during memory playback, the DVD player repeats the current memory playback.
• If you press the MEMORY button while the display appears on the TV screen, the display disappears.
• The programmed selections will be cleared when you open the disc tray or turn off the DVD player.
You can play a specific title or chapter repeatedly. (Title repeat, chapter repeat, A-B repeat)
Repeating a Chapter
1. While the DVD is playing, press the REPEAT DISC button until the “ ” indicator displays on the
screen. The current chapter is played repeatedly.
Repeating a Title
2. While the DVD is playing, press the REPEAT DISC button until the “ ” indicator displays on the
screen. The current title is played repeatedly.
To Resume Normal Playback
3. While the DVD is playing, press the REPEAT DISC button until the “ ” indicator displays on the screen.
You can play a single track or the whole disc repeatedly.
Repeating a Single Track
1. While the CD is playing, press the REPEAT DISC button until the “ ” indicator displays on the
screen. The current track is played repeatedly.
Repeating the Whole Disc
2. While the CD is playing, press the REPEAT DISC button until the “ ” indicator displays on the screen.
The whole disc is played repeatedly.
To Resume Normal Playback
3. Press the REPEAT DISC button until the “ ” indicator displays on the screen.
Repeating a Specific Section
You can play a specific section repeatedly.
1. While the disc is playing, press the REPEAT A-B button at the beginning of the section (“ ” is displayed)
you want to play repeatedly.
2. Press the REPEAT A-B button again at the end of the section (“ ” is displayed).
3. The unit will immediately begin replaying your selection.
To Resume Normal Playback
4. While the disc is playing, press the REPEAT A-B button until the “ ” indicator displays on the screen.
Notes:
• Some discs may not permit A-B repeat operation.
• You cannot set the A-B repeat function for a segment that includes multiple camera angles.
• You can specify a segment only within the current title or track.
• There may be a slight difference between point A and the location where playback actually resumes depending
on the disc.
Title
number
Chapter
number
Repeat Playback
DVD Programmable Memory

-15-
This unit can play JPEG files recorded on a CD-R or CD-ROM disc (CD-RW is not recommended).
Viewing JPEG Files
1. Slide the OPEN knob rightwards to open the disc door.
2. Hold a JPEG file disc by its edges and gently push it onto the spindle
with the label side facing up until you hear a “click”.
3. Close the disc door. A list of folders/files will appear on the screen.
4. Press the or button to select your desired file. Press the PLAY
button to start playback.
Notes:
• You can press the PAUSE button to freeze the picture. Press the PLAY button to resume picture slide show.
• You can press the STOP button to display a folder list.
• You can press the PREV or NEXT button to change the picture.
• You can press the ANGLE button to rotate direction of the picture by 90o.
• Some discs may not permit this operation.
Play Modes for CD or JPEG Disc
When playing CD / JPEG discs, you can modify the Play Modes through the Toolkit that appears on the right,
below the picture on the screen. Press the / button to navigate between the windows and the / button to
select files/tracks or play mode items. Then press the ENTER button.
1. In Stop mode, press the Cursor buttons ( , , , ) to select "Edit mode"
then press the ENTER button.
2. Use the Cursor buttons ( , , , ) to select tracks/files shown on the
left hand side of the window. Press the ENTER button to confirm the
selected tracks/files. " " will appear in front of the selected tracks/files.
3. Select "Add to program", then press the ENTER button. " " will
disappear from the screen. It means that the tracks/files you have
selected are added into the "Program view".
4. Select "Program view" to view programmed files. (To add more files by
"Browser view" follow the above steps.)
5. Press the PLAY button to start the program playback.
The Toolkit has the following play mode items:
• Repeat ( Off / Single / All ):
Off: Resumes normal playback.
Single: Repeats the current track/file.
All: Repeats all files on the current folder or all tracks on the disc.
• Mode ( Normal / Shuffle / Music intro ):
Normal: Resumes normal playback.
Shuffle: Playbacks track/file in random order.
Music intro (for Audio CD only):Only plays the first 10 seconds of all the tracks on the current folder/disc.
• Edit mode: Program operation works only when "Edit mode" is selected.
• Program view: To view tracks/files in the "Program view" list. It is disabled when the "Program view" list is
empty.
• Add to program: Add files/tracks to the "Program view" list. It is disabled if the "Edit mode" is not selected.
• Browser view: To view files/tracks in the original view list.
• Clear program: Delete the files/tracks in the "Program view" list.
In complete stop mode (press the STOP button twice), select a file/track that you want to delete. " " will
appear beside the deleted file/track. Select "Clear program" and then press the ENTER button. It is disabled if
the "Edit mode" is not selected.
Note: The program will be deleted if disc door is opened.
Viewing JPEG Files
Play Modes for CD or JPEG Disc

-16-
Video
1. Press the SETUP button in stop mode.
2. Press the / button to select Video.
3. Press the button, then the / button to select the option (Aspect
Ratio, View Mode or Video Out Only).
4. Press the ENTER button, then press the / button to shift and change
the selection, then press the ENTER button.
5. Press the button to return to the previous menu. Press the SETUP or
RETURN button to exit the menu.
Aspect Ratio
• The displayable picture size is preset on the DVD. Therefore, the playback picture of some DVDs may not
conform to the picture size selected.
• When you play DVDs recorded in the 4:3 picture size only, the playback picture always appears in the 4:3
picture size regardless of the Aspect Ratio setting.
• Select 16:9 to conform to the LCD screen on the unit. Always be sure that your Aspect Ratio conforms to the
actual TV in use if you connect the unit to a TV.
View Mode
Fill Fill the screen with decoded image.
Original Display image as it’s original size.
Auto Fit Automatically fit the decoded image on screen without distortion. Black bars will be present on top/
bottom or left/right of screen.
Pan Scan Select when a standard 4:3 TV is connected. Displays pictures cropped to fill your TV screen. Sides of
the picture are cut off.
Note:
Depending on the DVD, you may not be able to view the mode as selected.
Video Out Only
For Video Out Only, use the / button to select On and press the ENTER button, the unit will output the video to
the TV only and the unit TFT LCD screen will be off. The unit TFT LCD screen will be on again automatically after
the unit is power off and on again.
Language
1. Press the SETUP button in stop mode.
2. Press the button, then the / button to select the option (OSD
Language, Subtitle, Audio or DVD Menu).
3. Press the ENTER button, then press the / button to shift and
change the Language, then press the ENTER button.
4. Press the button to return to the previous menu. Press the SETUP or
RETURN button to exit the menu.
Notes:
• Some DVDs are programmed with a specific language. You may not be able to change this feature.
• Some DVDs allow you to change languages via the disc menu only. If this is the case, press the MENU button
and choose the appropriate languages from the selection on the disc menu.
Customizing the Function Settings

-17-
Misc
Use Default Settings
1. Press the SETUP button in stop mode.
2. Press the / button to select Misc.
3. Press the button, then press the / button to select desired option
(Use Default Settings or Screen Saver).
4. Press the ENTER button, then press the / button to select “Yes”,
then press the ENTER button. The original setting will be restored. The
unit will exit the menu automatically and re-load the disc in the disc tray.
Note: It will take 3-5 seconds to reset the DVD player to the factory default.
Screen Saver
1. Press the SETUP button in stop mode.
2. Press the / button to select Misc.
3. Press the button, then press the / button to select Screen Saver.
4. Press the ENTER button, then press the / button to change the On/Off mode, then press the ENTER button.
5. Press the button to return to the previous menu. Press the SETUP or RETURN button to exit the menu.
Rating
Parental Control
DVDs are rated according to their content and some are equipped with a password function. The contents allowed
by parental lock level and the way a DVD is controlled may vary from disc to disc. For example, if the disc allows,
you could lock-out violent scenes unsuitable for children or you could lock out playback of the disc altogether.
1. Press the SETUP button in stop mode.
2. Press the / button to select Rating.
3. Press the button, then press the / button to select Parental Control.
4. Press the ENTER button, "Enter Password" screen will appear.
5. Press the number buttons to input the current password (If the
password has not been set yet after you purchase this unit, it is "8888").
Then press the ENTER button.
6. Press the ENTER button again to list the parental control level.
The parental lock levels are equivalent to the following ratings:
1 : Kid Safe 2 : G 3 : PG 4 : PG-13
5 : PG-R 6 : R 7 : NC-17 8 : Adult
7. Press the / button to select the rating from 1 to 8. Press the ENTER button to confirm. (Rating 1 has the
most restrictions while rating 8 can virtually playback all DVD software.)
8. Press the button to return to the previous menu. Press the SETUP or RETURN button to exit the menu.
Note: You cannot play DVD video discs rated higher than the level you selected unless you cancel the parental
lock function.
Set Password
1. Press the SETUP button in stop mode.
2. Press the / button to select Rating.
3. Press the button, then press the / button to select Set Password.
4. Press the ENTER button, "Enter Password" screen will appear.
5. Press the number buttons to input the current password (If the password has not been set yet after you
purchase this unit, it is "8888"). Then press the ENTER button.
6. Press the ENTER button again, "Enter New Password" screen will appear. Press the number buttons to input
the new password and press the ENTER button two times. Now your new password has been set. Be sure to
remember this number!
7. Press the button to return to the previous menu. Press the SETUP or RETURN button to exit the menu.
If you forget the password, you can erase your current password by pressing the number button 8 on the remote
control four times, then press the ENTER button to confirm the setting (PASSWORD : 8 8 8 8).
Customizing the Function Settings

-18-
Connecting Your iPod
1. Connect your iPod onto the connector of the iPod docking bracket on the right side of the unit.
Notes:
• Your iPod will charge automatically (till fully charged) once it is connected and the iPOD / DVD switch is slided
to the iPOD position.
• Push the iPod docking bracket back into the unit when not connecting your iPod.
Warning: To prevent damage to the unit and/or your iPod, connect or remove your iPod when the unit is powered
off or the unit is not in iPod mode.
Caution: Due to the iPod limitation, not all functions of some iPod models can be controlled via the remote control
of this unit. If necessory, operate on your iPod directly.
Compatible iPod Types:
• iPod nano 3rd generation (video) 4GB 8GB
• iPod 5th generation (video) 30GB 60GB 80GB
• iPod classic 80GB 160GB
• iPod touch 8GB 16GB 32GB
Playing Music
1. In iPod Home menu, use the / button to select Music and press the ENTER button.
2. Use the / and ENTER button to navigate the iPod menu lists and select a song, press the ENTER button to
begin playback.
(If necessory, operate on your iPod directly. For iPod Touch, touch the iPod screen to begin playback.)
• Press the PAUSE button to pause playback, press the PLAY button to resume playback.
• Press the PREV button to skip to the current / previous song.
• Press the NEXT button to skip to the next song.
• Press the / SEARCH button to begin fast reverse / forward, press the PLAY button to resume normal
playback.
3. Press the MENU button to go back to the previous menu.
2. Turn on the unit, slide the iPOD / DVD switch to the iPOD position.
Your iPod will be connected automatically, following screen appears.
1) Pull the iPod docking bracket out.
2) Slide the locker to the top to have enough space to place your iPod.
3) Connect your iPod onto the connector of the iPod docking bracket.
4) Slide the locker down to lock your iPod.
Note: Carefully hold your iPod touch when lock it. Be careful not
touch the On/Off button on the top of your iPod touch to turn it off.
iPod is a trademark of Apple Computer, Inc., registered in the U.S. and other countries.
Using Your iPod

-19-
Using an iPod Classic / iPod Nano to view the photo
1. In iPod Home menu, use the / button to select Photos and press the ENTER button.
2. Use the / and ENTER button to navigate the iPod menu lists and select a photo, press the ENTER button
to begin playback.
(If necessory, operate on your iPod directly.)
3. Press the ENTER button twice to activate photo showing to the unit screen.
Playing Photos
1. In iPod Home menu, use the / button to select Photos and press the ENTER button.
2. Use the / and ENTER button to navigate the iPod menu lists and select a photo, press the ENTER button
to begin playback.
(If necessory, operate on your iPod directly.)
• Press the PLAY button to pause playback, press the PLAY button again to resume playback.
• Press the PREV / NEXT button to skip to the previous / next photo.
3. Press the MENU button to go back to the previous menu.
Using an iPod Touch to view the photo
1. In iPod Home menu, touch the “Photos” selection on iPod panel, and then select the photo your prefer.
2. Touch the “ ” to confirm the photo.
3. Touch the “Yes” to activate iPod’s video output. The photo will appear on the screen.
Step 3Step 2Step 1
Note: Make sure “TV Out” in the setting of your iPod Classic / iPod Nano is set to “On”.
Step 3Step 2Step 1
Playing Videos
1. In iPod Home menu, use the / button to select Videos and press the ENTER button.
2. Use the / and ENTER button to navigate the iPod menu lists and select a video, press the ENTER button
to begin playback.
(If necessory, operate on your iPod directly. For iPod Touch, touch the iPod screen to begin playback.)
• Press the PAUSE button to pause playback, press the PLAY button to resume playback.
• Press the / SEARCH button to begin fast reverse / forward, press the PLAY button to resume normal
playback.
3. Press the MENU button to go back to the previous menu, then you can select another video to play.
Note: Make sure “TV Out” in the setting of your iPod is set to “On”.
Using Your iPod
