Sonorix C2 User manual

1

CONTENTS
Introduction .........................................................................................................................3
Safety Instructions..............................................................................................................3
Product Features................................................................................................................. 4
What’s Included in the Package ........................................................................................ 4
Description of Parts............................................................................................................ 5
Wearing the C2 ....................................................................................................................5
Charging the Battery...........................................................................................................6
Switching the C2 ON/OFF................................................................................................... 6
Locking the C2 buttons......................................................................................................6
Pairing C2 with Bluetooth Devices.................................................................................... 7
Using C2 for Handsfree Operations.................................................................................. 8
Stereo Audio & Remote Control Operations..................................................................10
Hints for Optimum Audio Transmission .........................................................................10
Specifications.....................................................................................................................11
2

Introduction
Thank you for purchasing our C2 Bluetooth Stereo Headset.
The C2 Bluetooth Stereo Headset is a high quality Bluetooth audio device for
audio entertainment and voice functions at its best. It functions as ‘Wireless Stereo
Headset’ when linked to Bluetooth A2DP enabled audio devices such as Mobile
Phones, MP3 Players etc and as ‘Handsfree Headset’ with Bluetooth Phones.
With 3 easy to use buttons, user can switch between music and phone call as well
as remote control music playback functions. The C2 with its exceptional audio
quality is a truly indispensable device for wireless enthusiasts.
Safety Instructions
zCheck the laws and regulations on the use of mobile phones and handsfree
equipments in areas you intend to use.
zContinuous listening of music at high volume may cause hearing defects.
zWhen cleaning the device, do not use any type of abrasive pad, scouring
powder or solvents as these may render the finish dull permanently.
zCharge the battery for at least 2 hours before using.
zDo not use in places like hospitals, airplanes etc. where use of electronic
devices is prohibited.
zDo not expose components to extremes of sunlight, temperature, moisture or
vibrations.
3

Product Features
zCD quality sound and high quality voice
zSupports A2DP for stereo audio streaming andAVRCP for remote controlling
of music playback functions
zSupports Headset/Handsfree Profiles for handsfree operation with Bluetooth
phones
z3 easy to use buttons
zBuilt-in microphone
zComfortable design suited for users of all ages
zBuilt-in Li-Polymer battery for long lasting play
zCharging via USB
What’s Included in the Package
zC2 Bluetooth Stereo Headset
zEarphone Set
zUSB Cable
zUser Manual
4

Description of Parts
Wearing the C2
Simply clip the C2 onto shirt or clothing.
Earphone Jack
Vol
Up Vol
Down
MFB
Button Lock
Switch
O – Unlock
X – Lock USB
Port
5

Charging the Battery
zIf battery level is low, LED will flash red every 5 seconds.
zTo charge the battery, connect C2 to PC using the USB Cable.
zDuring charging, LED will light up red and when fully charged, it will change to
constant blue.
Switching the C2 ON/OFF
zTo switch on C2, click and hold MFB until LED flashes blue.
zTo switch off C2, click and hold MFB until LED flashes red and then turn off.
Locking the C2 buttons
zTo prevent unintentional button press, you can lock or unlock the buttons by
sliding the ‘Button Lock Switch’ from O to X and vice versa.
6

Pairing C2 with Bluetooth Devices
Function Action / Indicator
To put C2 in pairing mode, click and hold MFB until
LED flashes blue and then change to alternating red
and blue LED flash. Pairing mode lasts for 3 minutes
and if pairing is made within this period, C2 returns to
standby mode.
Pairing Mode
From your Bluetooth device, search for devices and
select ‘sonorix C2 from the list. If prompted for pinkey,
enter ‘0000’. When paired and connected, LED will
turn off.
Pairing Successful
&
Connection State Note: For some phones, you may need to establish
the Bluetooth connection separately after pairing.
Please refer to your phone manual for details.
7

Using C2 for Handsfree Operations
Function Action / Indicator
Answer Call On an incoming call, short click MFB.
Blue LED flashes with ring tone.
To make a call, first dial from phone and short click
MFB to switch to C2. Note: For some phone models,
call is automatically transferred to C2 after dialing.
Make Call
To redial, long click (+) key. Notes: For some phones,
when (+) is long clicked, it first displays the numbers
last called or received. In this case, long click (+)
again to redial. Some phones allow direct redialing by
long clicking (+) just once.
Redial
Voice Dial Long click (-) to voice dial.
Volume Control Short click (+) or (-) to adjust volume. Beep tones are
heard at minimum or maximum volume.
Reject Call To reject call, long click MFB.
End Call To end call first, long click MFB during ‘Talk Mode’.
If other party ends the call first, C2 automatically
returns to handsfree standby mode.
8

Function Action / Indicator
Call Transfer While talking in headset mode, to transfer call from
C2 to phone or vice versa short click MFB.
Call Waiting To answer second call while in ‘Talk’ mode, short click
MFB. To switch from second call to first call and vice
versa, short click MFB. Note: This function can only
be used if user has subscribed for such service.
To reconnect headset with phone, long click MFB in
standby mode.
Reconnect
Microphone Mute For privacy reasons, if you don’t want your voice to
be transmitted to the other party, you can mute the
microphone by long clicking (+) or (-) during talk
mode. To cancel mute function, long click (+) or (-).
9

Stereo Audio & Remote Control Operations
Function Action / Indicator
Play / Pause Short click MFB to play. To pause, short click MFB.
Next Long click (+) to skip to next song.
Previous Long click (-) to play previous song.
Stop Long click MFB to stop.
Volume Short click (+) or (-) to adjust volume.
Hints for Optimum Audio Transmission
zWireless performance of Bluetooth devices depends on the environment where
it is used.
zWalls, partitions, doors, furniture etc can block the path of transmitted radio
signals thereby resulting in shorter range and even sound distortions.
zLikewise, the human body also affects the performance and since the C2 is
clipped onto clothing and held close to the body, it is a good practice not to
cover the C2 or the host device with hand.
10

Specifications
Standards Bluetooth Specification V2.1
RF Frequency Range 2402 ~ 2480 MHz
Profiles Supported A2DP, AVRCP, Headset, Handsfree V1.5
Transmission Power 0.25 ~ 2.5mW (Class 2)
Receiver Sensitivity < -80dBm (PER 1 %)
Distance 10m (in open space)
Audio S/N > 80dB
Audio THD < 1%
Audio Output Power > 20mWrms
Battery Type Li-Ion Polymer
Battery Life Standby : 150 hrs
Audio Connection : 6 hrs
Voice Connection : 7 hrs
Charging Time < 3 hrs
Charging Voltage DC +5V (USB)
Button/Switch
Multi-Function Button, Volume Up/Down,
Button Lock Switch
Weight 22g
Operating Temp. & Humidity -10 ~ +50°C, Rel. Humidity 0 ~ 95%
Certification BQB, FCC, CE
11

12
Product Warrant
y
* OpenBrain Technologies warrants this product against
all defects in material and workmanship for a period of
one year from the date of purchase by end user. The
conditions for warranty are as follows:
* The warranty is valid only if the original receipt issued to
the original purchaser by the dealer is presented with
the product to be repaired or replaced.
* The warranty is void if the serial number, date of
purchase and product label had been removed.
* The warranty does not cover any failure or damage of
the product due to normal wear and tear, physical
abuse, improper installation, misuse, modification or
repairs by unauthorized third parties.
* OpenBrain Technologies does not assume responsibility
for any loss or damage incurred during shipment and as
a result of force majeure.
* OpenBrain Technologies is not liable for any incidental
or consequential damages arising from the use or
misuse of the product.
* All warranty claims are limited to repair or replacement
of the defective product at the sole discretion of
OpenBrain Technologies.
* If OpenBrain Technologies repairs or replaces the
product, the repaired or replaced product shall be
warranted for the remaining time of the original warranty
period. Repair or replacement may involve the use of
functionally equivalent reconditioned units. Replaced
part or product becomes the property of OpenBrain
Technologies.
* Consumable components, such as batteries, are not
included in the warranty obligation.
Disclaimer Notice
The manufacturer shall not be liable for errors contained
ial damages in
ance or use of this
etary information,
ent applications and
this document may
ithout prior written
acturer reserves the
e changes from time
igation to notify any
manufacturer also
ions without notice.
herein or for incidental or consequent
connection with the furnishing, perform
material. This document contains propri
which is protected by international pat
copyright. All rights reserved. No part of
be copied, reproduced or translated w
consent of the manufacturer. The manuf
right to revise this publication and to mak
to time in the contents hereof without obl
person of such revisions or changes. The
reserves the right to change the specificat
European CE notice to users and pro
statements
This product is CE marked according to
R & TTE Directive (99/5/EC). Hereby,
Technologies Co., Ltd, declares that
compliance with the essential requi
relevant provisions of Directive 1999/
information, please contact http://www.openb
duct
the provisions of the
Openbrain
this product is in
rements and other
5/EC. For further
rain.co.kr
WEEE Directive 2002/96/EC Art. 11(2)
The use of the symbol indicates that this product may not be treated as househol
this product is disposed of correctly, you will help prevent potential negative
environment and human health, which could otherwise be caused by inappropri
this product. For more detailed information about recycling of this product, please
d waste. By ensuring
consequences for the
ate waste handling of
contact your local city
office, your household waste disposal service or the shop where you purchased the product.
FCC notice to users and product st
THIS DEVICE COMPLIES WITH PAR
RULES. Operation is subject to the follo
(1) this device may not cause harmful i
this device must accept any interferenc
interference that may cause undesired operat
Changes or modifications not express
party responsible for compliance cou
authority to operate the equipment.
atements
T 15 OF THE FCC
wing two conditions;
nterference, and (2)
e received, including
ion. CAUTION:
ly approved by the
ld void the user’s
