Sonos Move
Move is the durable, battery-powered smart speaker for indoor and outdoor listening.
Rechargeable battery lasts up to 10 hours. Easily recharge by just setting Move on the
included charging base—no plugs or extra wires required. For power on the go, use a
compatible USB-C charger.
Weatherproof design is ideal for barbecues, pool parties, and more.
Stream over WiFi at home—switch to Bluetooth anywhere else.
Easy voice control with Amazon Alexa and the Google Assistant built right in.
Compatible with all your other Sonos speakers for multi-room listening.
Controls and lights
Volume control Touch and hold to quickly change the
volume:
Volume up (right); Volume down (left).
Play/Pause Press
once to play or pause music.

10/4/2019 sonos-one
https://www.sonos.com/support/en/sonos-user-guide/index.html#t=sonos-user-guide%2Fmove%2Fmove.htm 2/5
Press and hold to add the music that’s
playing in another room.
Next/Previous Swipe right across the touch controls to
skip to the next song.
Swipe left to go to the previous song.
Note: You can’t skip forward or go back when
listening to a radio station.
Microphone indicator Tap the microphone light to turn the microphone
on or off.
When the light is on, auto Trueplay
tuning is enabled. If you have a voice
service set up, voice control is also on.
When the light is off, voice control and
auto Trueplay are off.
Status light Indicates the speaker’s status. For more
information, see https://faq.sonos.com/led.
Power light Visible and blinks slowly when the speaker
is on.
For first charge out of the box, the status
light and the power light will flash within 3
seconds.
Back panel
Join button Press to connect to your Sonos system during
setup.
USB-C port Use a compatible USB-C charger for charging on
the go.
USB port may also be used for
diagnostic purposes. (It can’t stream
large data files, like some music files).
Note: USB-C cable not included.
Power button Press to power on; press and hold to power off.
If Move is off the charging base, it goes to sleep
to save battery when you’re not using it. Just
press the power button to wake it up.
Bluetooth/WiFi toggle
button
Toggles between Bluetooth and WiFi. Use WiFi for
setup and for listening at home—switch to
Bluetooth wherever WiFi isn’t available.
Handle Allows for easy lifting and carrying so you can
take the speaker wherever you go.
Charge Move
Charging base Just set Move on the charging base for
easy recharging—no extra wires or cables
needed.
Charging base is for indoor use only—be
sure to keep it dry.
Move’s remaining battery life is always
visible in the Sonos app.
AC power 100-240VAC, ~50/60Hz, 1.2A. Output: 18VDC,
2.5A
Charging contacts Make sure the speaker is seated properly in the
base and the charging contacts are touching.

10/4/2019 sonos-one
https://www.sonos.com/support/en/sonos-user-guide/index.html#t=sonos-user-guide%2Fmove%2Fmove.htm 3/5
Select a location
You can put your speaker just about anywhere. Here are a few guidelines:
Move is made to give you powerful sound anywhere—auto Trueplay tuning periodically
balances the sound for wherever you are and whatever you’re listening to. The microphone
has to be on for automatic tuning so if you don’t leave the microphone on all the time,
turn it on for a few minutes whenever you move your speaker so it can automatically
adjust the sound for your new surroundings.
Move sounds great even when placed next to a wall or on a shelf. For best performance,
leave at least 1" (2.5 cm) space around the back of the speaker.
It’s ultra durable. With a tough outer shell and IP56 rating, Sonos Move is built to withstand
falls, bumps, moisture, dust, UV rays, and extreme temperatures. Just don’t leave it out in
a soaking rain storm, and remember that the charging base that’s included is for indoor
use only.
Don’t use or store your Sonos Move upside down.
Auto Trueplay
You can put Sonos Move just about anywhere. Auto Trueplay tuning optimizes the sound for wherever
you are and whatever you’re listening to. Your speaker’s microphone is used to detect the environment
so auto Trueplay can make periodic tuning adjustments to deliver the best sound.
If you don’t want the microphone on all the time, be sure to turn it on whenever you move the
speaker. Your Sonos Move starts retuning when you pick it up, and continues to adjust the sound for
a few minutes after you place it in a new location.
Note: Auto Trueplay is disabled while you’re using Bluetooth.
Microphone on/off
The microphone is used for voice control, and for auto Trueplay tuning. Touch to turn the
microphone on or off.
When the microphone light is on,
If you have a voice assistant, voice control is on and your voice assistant is ready to
respond.
Auto Trueplay tuning is enabled so Move can automatically adjust its sound for your
surroundings.
When the microphone light is off,
If you have a voice assistant, voice control is off.
Auto Trueplay tuning is disabled.
Switch modes
Set Move up on your WiFi, then use the mode switch on the back of Move to switch between
Bluetooth and WiFi. When you use Bluetooth for the first time, you’ll need to pair Move with your
mobile device. Once paired, they’ll reconnect automatically next time.
Bluetooth pairing
1. Turn Bluetooth on in your mobile device settings.
2. Press the mode button on the back of Move to switch it to Bluetooth.
3. Choose Move from the list of available devices on your mobile device. If it’s not there, press
and hold the mode button and then choose Move from the list when it appears.

10/4/2019 sonos-one
https://www.sonos.com/support/en/sonos-user-guide/index.html#t=sonos-user-guide%2Fmove%2Fmove.htm 4/5
Your mobile device will automatically connect to Move next time.
Power Sources
Charging base, included.
USB port (USB type C PD power with 45W, 20V/2.25A).
Accessories
For add-ons tailored to perfectly fit your Move, see Accessories on our website.
Specifications
Feature Description
Audio
Amplifier Two Class-D digital amplifiers.
Tweeter One tweeter creates a crisp and accurate high frequency response.
Mid-Woofer One mid-woofer ensures the faithful playback of mid-range vocal
frequencies plus deep, rich bass.
Microphones Far-field microphone array.
Microphone LED, hard-wired to the voice microphones for
extra privacy control so you’re always aware when the
microphone is active.
Voice Control Integrated voice control.
Networking*
Wireless Connectivity Connects to your home WiFi network with any router that supports
802.11b/g/n in 2.4GHz or 802.11a/n in 5GHz.
General
Power Supply Charging base:100-240VAC, ~50/60Hz, 1.2A. Output: 18VDC, 2.5A.
USB port: USB type C PD power with 45W, 20V/2.25A.
Battery pack Capacity: 2420-2500maH
Replacement: Visit our website www.sonos.com for more information.
Disposal: Check with your local waste or recycling company to
determine the proper disposal method in your area.
Dimensions (H x W x D) 9.44 x 6.29 x 4.96 in (240 x 160 x 126 mm)
Weight 6.61 lb (3.0 kg) (including the battery)
Operating Temperature 32º to 113º F (0º to 45º C)
Storage Temperature -13º to 158º F (-25º to 70º C)
Humidity Resistant Move meets IP56 water and dust resistance levels. Just don’t leave
it out in a soaking rainstorm.
Note: The charging base included with Move is for indoor use only.
Product Finish Black with black grille
Package Contents Sonos Move, charging base, and Quickstart guide.
* Specifications subject to change without notice.
Important safety information
Please read these instructions and heed all warnings. Keep them in a convenient location and make
sure everyone in the household is aware of them.

10/4/2019 sonos-one
https://www.sonos.com/support/en/sonos-user-guide/index.html#t=sonos-user-guide%2Fmove%2Fmove.htm 5/5
Caution: Danger of explosion if battery is incorrectly replaced. Replace only with the same or
equivalent type.
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Clean only with dry soft cloth. Household cleaners or solvents can damage the finish on
your Sonos products.
If the charging base leaves a mark on wood furniture, remove with wood polish.
6. Do not block any ventilation openings. Install in accordance with the manufacturer’s
instructions.
7. Do not install near any heat sources such as radiators, heat registers, stoves, or other
apparatus that produce heat.
8. Do not expose batteries (battery pack or batteries installed) to excessive heat such as
sunshine or fire.
9. Protect the power cable from being walked on or pinched, particularly at plugs, convenience
receptacles, and the point where they exit from the apparatus.
10. Only use attachments/accessories specified by the manufacturer.
11. Unplug this apparatus during lightning storms or when unused for long periods of time.
12. Refer all servicing to Sonos qualified service personnel. Servicing is required when the
apparatus has been damaged in any way, such as power-supply cable or plug is damaged,
liquid has been spilled or objects have fallen into the apparatus, the apparatus has been
exposed to rain or moisture, does not operate normally, or has been dropped.
13. The Mains plug should be readily available to disconnect the equipment.
14. Warning: Move meets IP56 water resistance levels. To reduce the risk of fire or
electric shock, don’t expose this apparatus to a soaking rain storm.
