SERVICE MANUAL

LEVEL 2

• For INSTRUCTION MANUAL, refer to SERVICE MANUAL, LEVEL 1 (987622241.pdf).

• For MECHANISM ADJUSTMENTS, refer to the “DV MECHANICAL ADJUSTMENT MANUAL

Z MECHANISM ”(9-876-210-11).

•Reference No. search on printed wiring boards is available.

Link

SERVICE NOTE

DISASSEMBLY

BLOCK DIAGRAMS

FRAME SCHEMATIC DIAGRAMS

SCHEMATIC DIAGRAMS

PRINTED WIRING BOARDSSPECIFICATIONS

REPAIR PARTS LIST

SERVICE NOTE

DISASSEMBLY

BLOCK DIAGRAMS

FRAME SCHEMATIC DIAGRAMS

SCHEMATIC DIAGRAMS

PRINTED WIRING BOARDS

REPAIR PARTS LIST

SPECIFICATIONS

Link

Revision History

Ver 1.1 2003. 06

On the VC-312 board

This service manual provides the information that is premised the circuit board replacement service and not intended repair

inside the VC-312 board.

Therefore, schematic diagram, printed wiring board, waveforms, mounted parts location and electrical parts list of the VC-312

board are not shown.

The following pages are not shown.

Schematic diagram .............................Pages 4-37 to 4-64

Printed wiring board............................Pages 4-85 to 4-88

Waveforms ...........................................

Pages 4-91 to 4-92

Mounted parts location .............................

Page 4-95

Electrical parts list................................... Pages 5-21 to 5-26

Z MECHANISM Photo : DCR-TRV22

DIGITAL VIDEO CAMERA RECORDER

DCR-TRV22/TRV22E

RMT-814

US Model

Canadian Model

Korea Model

Brazilian Model

DCR-TRV22

AEP Model

UK Model

North European Model

East European Model

Chinese Model

Australian Model

DCR-TRV22E

E Model

Hong Kong Model

Tourist Model

DCR-TRV22/TRV22E

—2 —

DCR-TRV22/TRV22E

SPECIFICATIONS

SAFETY-RELATED COMPONENTWARNING!!

COMPONENTS IDENTIFIED BY MARK 0OR DOTTED LINEWITH

MARK 0ON THE SCHEMATIC DIAGRAMS AND INTHE PARTS

LIST ARE CRITICAL TO SAFE OPERATION. REPLACE THESE

COMPONENTS WITH SONY PARTS WHOSE PART NUMBERS

APPEAR AS SHOWN IN THIS MANUAL OR IN SUPPLEMENTS

PUBLISHED BY SONY.

ATTENTION AU COMPOSANT AYANT RAPPORT

À LA SÉCURITÉ!

LES COMPOSANTS IDENTIFÉS PAR UNE MARQUE 0SUR LES

DIAGRAMMES SCHÉMATIQUES ET LA LISTE DES PIÈCES SONT

CRITIQUES POUR LA SÉCURITÉ DE FONCTIONNEMENT. NE

REMPLACER CES COMPOSANTS QUE PAR DES PIÈSES SONY

DONT LES NUMÉROS SONT DONNÉS DANS CE MANUEL OU

DANS LES SUPPÉMENTS PUBLIÉS PAR SONY.

COVER

CAUTION :

Dangerofexplosionifbattery is incorrectly replaced.

Replace only with the same or equivalent type.

Video camera

recorder

System

Video recording system

2 rotary heads

Helical scanning system

Audio recording system

Rotary heads, PCM system

Quantization: 12 bits (Fs 32 kHz,

stereo 1, stereo 2), 16 bits

(Fs 48 kHz, stereo)

Video signal

PAL colour, CCIR standards

NTSC color, EIA standards

Usable cassette

Mini DV cassette with the

mark printed

Tape speed

SP: Approx. 18.81 mm/s

LP: Approx. 12.56 mm/s

Recording/playback time

(using cassette DVM60)

SP: 1 hour

LP: 1.5 hours

Fastforward/rewind time

(using cassette DVM60)

Approx. 2 min. and 40 seconds

Viewfinder

Electric viewfinder (colour)

DCR-TRV22:

DCR-TRV22E:

DCR-TRV22: 0.286 Vp-p,

DCR-TRV22E: 0.3 Vp-p,

Image device

4.5 mm (1/4 type)

CCD (Charge Coupled Device)

Gross:

Effective (still):

Effective (moving):

Lens

Carl Zeiss Vario-Sonnar

Combined power zoom lens

Filter diameter: 30 mm

(1 3/16 in)

10×(Optical), 120×(Digital)

F = 1.7 – 2.2

Focal length

3.3 – 33 mm (5/32 – 1 5/16 in.)1)

42 – 420 mm (1 11/16 – 16 5/8

in.)2)

42 – 420 mm (1 11/16 – 16 5/8

in.)3)

1) When converted to a 35 mm still

camera

2) In CAMERA mode

3) In MEMORY mode

Colour temperature

Auto, HOLD, INDOOR (3 200 K),

OUTDOOR (5 800 K)

Minimum illumination

5 lx (lux) (F1.7)

0 lx (lux) (in the NightShot

mode)*

* Objects unable to be seen due to

the dark can be shot with

infrared lighting.

Input/Output connectors

S video input/output

4-pin mini DIN

Luminance signal: 1 Vp-p,

75 Ω(ohms), unbalanced

Chrominance signal:

75 Ω(ohms), unbalanced

Audio/Video input/output

AV MINI JACK, 1 Vp-p,

75 Ω(ohms), unbalanced

327 mV, (at output impedance

more than 47 kΩ(kilohms))

Output impedance with less than

2.2 kΩ(kilohms)/Stereo minijack

(ø 3.5 mm)

Input impedance more than

47 kΩ(kilohms)

DV input/output

4-pin connector

Headphone jack

Stereo minijack (ø 3.5 mm)

LANC jack

Stereo mini-minijack (ø 2.5 mm)

USB jack

mini-B

MIC jack

Minijack, 0.388 mV low impedance

with 2.5 to 3.0 V DC, output

impedance 6.8 kΩ(kilohms)

(ø 3.5 mm)

Stereo type

LCD screen


6.2 cm (2.5 type)

Total dot number

123 200 (560

50.3 37.4mm

220)

(2 ×1 1/2in.)

General

Power requirements

7.2 V (battery pack)

8.4 V (AC Adaptor)

Average power consumption

(when using the battery pack)

3.3 W1)

2.5 W2)

1) During camera recording using

LCD

2) Viewfinder

Operating temperature

0°C to 40°C (32°F to 104°F)

Storage temperature

–20°C to + 60°C

(–4°F to + 140°F)

Dimensions (approx.)

71 ×90 ×112 mm

(2 7/8 ×3 5/8 ×4 1/2 in.) (w/h/d)

Mass (approx.)

Main unit only

530 g (1 lb 2 oz)

Including the rechargeable battery

pack NP-FM30, cassette DVM60

and lens cap

620 g (1 lb 5 oz)

Supplied accessories

See page 3.

AC Adaptor

AC-L15A/L15B

Power requirements

100 – 240 V AC, 50/60 Hz

Current consumption

0.35 – 0.18 A

Power consumption

18 W

Output voltage

DC OUT: 8.4 V, 1.5 A

Operating temperature

0°C to 40°C (32°F to 104°F)

Storage temperature

–20°C to + 60°C

(–4°F to + 140°F)

Dimensions (approx.)

56 ×31 ×100 mm

(2 1/4 ×1 1/4 ×4 in.) (w/h/d)

excluding projecting parts

Mass (approx.)

190 g (6.7 oz)

excluding power cord

Rechargeable

battery pack

NP-FM30

Maximum output voltage

DC 8.4 V

Output voltage

DC 7.2 V

Capacity

5.0 Wh (700 mAh)

Dimensions (approx.)

38.2 ⋅20.5 ⋅55.6 mm

(1 9/16 ×13/16 ×2 1/4 in.)

(w/h/d)

Mass (approx.)

65 g (2.3 oz)

Operating temperature

0°C to 40°C (32°F to 104°F)

Type

Lithium ion

“Memory Stick”

Memory

Flash memory

8MB: MSA-8A

Operating voltage

2.7 – 3.6 V

Power consumption

Approx. 45 mA during operation

mode

Approx. 130 µA during tape

recording standby

Dimensions (approx.)

50 ×2.8 ×21.5 mm

(2 ×1/8 ×7/8 in.) (w/h/d)

Mass (approx.)

4 g (0.14 oz)

Design and specifications are

subject to change without notice.

DCR-TRV22: Approx. 680 000 pixels

DCR-TRV22E: Approx. 800 000 pixels

DCR-TRV22: Approx. 340 000 pixels

DCR-TRV22E: Approx. 400 000 pixels

—3 —

DCR-TRV22/TRV22E

1. Check the areaof yourrepair for unsolderedor poorly-soldered

connections. Check the entireboard surfaceforsolder splashes

and bridges.

2. Check the interboard wiring to ensure that no wires are

"pinched" or contact high-wattage resistors.

3. Look for unauthorized replacement parts, particularly

transistors, that were installed during a previous repair. Point

them out to the customer and recommend their replacement.

4. Look for parts which,through functioning, show obvioussigns

of deterioration. Point them out to the customer and

recommend their replacement.

5. Check the B+ voltage to see it is at the values specified.

6. Flexible Circuit Board Repairing

• Keep the temperature of the soldering iron around 270˚C

during repairing.

• Do not touch the soldering iron on the same conductor of the

circuit board (within 3 times).

• Be careful not to apply force on the conductor when soldering

or unsoldering.

Unleaded solder

Boards requiring use of unleaded solder are printed with the lead-

free mark (LF) indicating the solder contains no lead.

(Caution: Some printed circuit boards may not come printed with

the lead free mark due to their particular size.)

: LEAD FREE MARK

Unleaded solder has the following characteristics.

•Unleaded solder melts at a temperature about 40°C higher than

ordinary solder.

Ordinary soldering irons can be used but the iron tip has to be

applied to the solder joint for a slightly longer time.

Soldering irons using a temperature regulator should be set to

about 350°C.

Caution: The printed pattern (copper foil) may peel away if the

heated tip is applied for too long, so be careful!

•Strong viscosity

Unleaded solder is more viscous (sticky, less prone to flow) than

ordinary solder so use caution not to let solder bridges occur such

as on IC pins, etc.

•Usable with ordinary solder

It is best to use only unleaded solder but unleaded solder may

also be added to ordinary solder.

SAFETY CHECK-OUT

After correcting the original service problem, perform the following

safety checks before releasing the set to the customer.

•SUPPLIED ACCESSORIES

Makesure that the following accessories are supplied withyour camcorder.

1AC-L15A/L15B AC Adaptor (1), Power

cord

MSA-8A

(1)

2NP-FM30 rechargeable battery pack

(1)

3A/V connecting cable (1)

4Wireless Remote Commander

RMT-814 (1)

5R6 (size AA) battery for Remote

Commander (2)

6Shoulder strap (1)

7Lens cap (1)

8Shoe cover (1)

9“Memory Stick” (1)

0USB cable (1)

qa CD-ROM (USB Driver)

SPVD-010 (I) TRV22:US, CND model only

SPVD-010 TRV22:E, HK, BR, JE, KR/

TRV22E model only

(1)

qs Cleaning cloth (1)

qd 21-pin adaptor* (1) (AEP, UK, EE, NE model only)

The models with mark printed on their

bottom surfaces only.

qd qf

qs qd

qf 2-pin conversion adaptor (1)

(DCR-TRV22 : JE/TRV22E : JE only)

qg 2-pin conversion adaptor (1)

(DCR-TRV22 : E, HK/TRV22E : E/HK only)

•Abbreviation

CND : Canadian model

AUS : Australian model

JE : Tourist model

KR : Korea model

CH : Chinese model

EE : East European model

NE : North European model

HK : Hong Kong model

—4 —

DCR-TRV22/TRV22E

TABLE OF CONTENTS

1. SERVICE NOTE

1-1. SERVICE NOTE ·····························································1-1

1. POWER SUPPLY DURING REPAIRS ··························1-1

2. TO TAKE OUTA CASSETTE WHEN NOT EJECT

(FORCE EJECT) ·····························································1-1

1-2. SELF-DIAGNOSIS FUNCTION ····································1-2

1. SELF-DIAGNOSIS FUNCTION ····································1-2

2. SELF-DIAGNOSIS DISPLAY ·······································1-2

3. SERVICE MODE DISPLAY ··········································1-2

3-1. Display Method ·······························································1-2

3-2. Backup No. ······································································1-2

3-3. End of Display·································································1-2

4. SELF-DIAGNOSIS CODE TABLE································1-3

2. DISASSEMBLY

2-1. P CABINET (C) ASSEMBLY ········································2-3

2-2. CABINET (R) COVER (39E) ASSEMBLY ···················2-4

2-3. F PANEL SECTION ·······················································2-5

2-4. MA-421 BOARD ····························································2-6

2-5. CABINET (R) SECTION ···············································2-7

2-6. LCD SECTION ·······························································2-8

2-7. CK-129 BOARD,

CONTROL SWITCH BLOCK(CF-CX4000) ·················2-8

2-8. PD-188 BOARD, LCD UNIT ·········································2-9

2-9. HINGE (40) ASSEMBLY ·············································2-10

2-10. BT PANEL/EVF SECTION··········································2-11

2-11. LB-085 BOARD (REMOVING OF THE EVF)-1 ········2-12

2-12. LB-085 BOARD (REMOVING OF THE EVF)-2 ········2-13

2-13. LB-085 BOARD (REMOVING OF THE EVF)-3 ········2-14

2-14. VA-118 BOARD, LENS SECTION······························2-15

2-15. CD-430 BOARD ···························································2-16

2-16. MECHANISM DECK, VC-312 BOARD (1) ···············2-16

2-17. MECHANISM DECK, VC-312 BOARD (2) ···············2-17

2-18. CABINET (G) ASSEMBLY (40E) ·······························2-17

2-19. CONTROL SWITCH BLOCK (FK-CX4000)··············2-18

2-20. JK-242 BOARD ····························································2-18

2-21. CIRCUIT BOARDS LOCATION ·································2-20

2-22. FLEXIBLE BOARDS LOCATION ······························2-21

3. BLOCK DIAGRAMS

3-1. OVERALL BLOCK DIAGRAM (1/4) ···························3-1

3-2. OVERALL BLOCK DIAGRAM (2/4) ···························3-3

3-3. OVERALL BLOCK DIAGRAM (3/4) ···························3-5

3-4. OVERALL BLOCK DIAGRAM (4/4) ···························3-7

3-5. POWER BLOCK DIAGRAM (1/2) ································3-9

3-6. POWER BLOCK DIAGRAM (2/2) ······························3-11

4. PRINTEDWIRING BOARDS AND

SCHEMATIC DIAGRAMS

4-1. FRAME SCHEMATIC DIAGRAM (1/3) ·······················4-1

FRAME SCHEMATIC DIAGRAM (2/3) ·······················4-3

FRAME SCHEMATIC DIAGRAM (3/3) ·······················4-5

4-2. SCHEMATIC DIAGRAMS

•CD-430 (CCD IMAGER)

SCHEMATIC DIAGRAM ······························4-9

•LB-085 (EVF, BACK LIGHT)

SCHEMATIC DIAGRAM ····························4-10

•VA-118 (1/5)(RGB DRIVE, TG)

SCHEMATIC DIAGRAM ····························4-11

•VA-118 (2/5)(HI CONTROL)

SCHEMATIC DIAGRAM ····························4-13

•VA-118 (3/5)(Y/P SENSOR AMP, CONNECTOR)

SCHEMATIC DIAGRAM ····························4-15

•VA-118 (4/5)(DC/DC COVERTER)

SCHEMATIC DIAGRAM ····························4-17

•VA-118 (5/5)(POWER IN, CHARGE)

SCHEMATIC DIAGRAM ····························4-19

•CK-129 (FUNCTION SWITCH)

SCHEMATIC DIAGRAM ····························4-21

•PD-188 (1/2)(DRIVER, TG)

SCHEMATIC DIAGRAM ····························4-23

•PD-188 (2/2)(BACKLIGHT DRIVE)

SCHEMATIC DIAGRAM ····························4-25

•JK-242 (A.V/DV IN/OUT)

SCHEMATIC DIAGRAM ····························4-27

•CONTROL SWITCH BLOCK (FK-CX4000)

SCHEMATIC DIAGRAM ····························4-29

•MA-421 (1/2)(MIC AMP)

SCHEMATIC DIAGRAM ····························4-31

•MA-421 (2/2)(Y/P SENSOR, V/A IN/OUT)

SCHEMATIC DIAGRAM ····························4-33

•FP-467/468/228 FLEXIBLE (S/T REEL SENSOR,

TAPE SENSOR)

SCHEMATIC DIAGRAM ····························4-35

ShematicdiagramoftheVC-312boardarenotshown.

Pages from 4-37 to 4-64 are not shown.

4-3. PRINTED WIRING BOARDS

•CD-430 (CCD IMAGER)

PRINTED WIRING BOARD ·······················4-67

•LB-085 (EVF, BACK LIGHT)

PRINTED WIRING BOARD ·······················4-69

•FP-467/468/228 FLEXIBLE BOARD

(S/T REEL SENSOR, TAPE SENSOR) ·····················4-71

•FP-626 FLEXIBLE BOARD ·····································4-71

•VA-118 (RGB DRIVE, TG, HI CONTROL,Y/P

SENSOR AMP, CONNECTOR, DC/DC COVERTER,

POWER IN, CHARGE)

PRINTED WIRING BOARD ·······················4-73

•CK-129 (FUNCTION SWITCH)

PRINTED WIRING BOARD ·······················4-77

•PD-188 (DRIVER, TG, BACKLIGHT DRIVE)

PRINTED WIRING BOARD ·······················4-79

•JK-242 (A.V/DV IN/OUT)

PRINTED WIRING BOARD ·······················4-81

•MA-421 (MIC AMP,Y/P SENSOR, V/A IN/OUT)

PRINTED WIRING BOARD ·······················4-83

Printed wiring board of theVC-312 board are not shown.

Pages from 4-85 to 4-88 are not shown.

4-4. WAVEFORMS ······························································4-89

Waveforms of the VC-312 board are not shown.

Pages 4-91 and 4-92 are not shown.

4-5. MOUNTED PARTS LOCATION ·································4-93

Mounted parts location of the VC-312 board is not shown.

Page 4-95 is not shown.

5. REPAIR PARTS LIST

5-1. EXPLODED VIEWS ······················································5-1

5-1-1.OVERALL SECTION·····················································5-3

5-1-2.F PANEL SECTION ·······················································5-4

5-1-3.MAIN CHASSIS SECTION ···········································5-5

5-1-4.LENS SECTION ·····························································5-6

5-1-5.CABINET L SECTION ··················································5-7

5-1-6.BT PANEL/EVF SECTION ············································5-8

5-1-7.CABINET R SECTION ··················································5-9

5-1-8.LCD SECTION ·····························································5-10

5-1-9.OVERALL (MECHANISM DECK-Z100) ···················5-11

5-1-10. LS CHASSIS BLOCK ASSEMBLY ·························5-12

—5 —

DCR-TRV22/TRV22E

5-1-11. MECHANICAL CHASSIS BLOCK ASSEMBLY ···5-13

5-2. ELECTRICAL PARTS LIST ········································5-13

Parts list of the VC-312 board are not shown.

Pages from 5-21 to 5-26 are not shown.

1-1

DCR-TRV22/TRV22E

SECTION 1

SERVICE NOTE

COVER

1-1. SERVICE NOTE

1. POWER SUPPLY DURING REPAIRS

In this unit, about 10 seconds after power is supplied to the battery terminal using the regulated power supply (8.4V), the power is shut off so

that the unit cannot operate.

This following two methods are available to prevent this. Take note of which to use during repairs.

Method 1.

Use the AC power adaptor (AC-L10, AC-VQ800 etc.).

Method 2.

Connect the servicing remote commander RM-95 (J-6082-053-B) to the LANC jack, and set the commander switch to the “ADJ”side.

2. TOTAKE OUT A CASSETTEWHEN NOT EJECT (FORCE EJECT)

1Refer to 2-2 to remove the cabinet (R) cover (39E).

2Refer to 2-3 to remove the F panel section.

3Refer to 2-5 to remove the cabinet (R) section.

4Refer to 2-10 to remove the BT panel/EVF section.

5Refer to 2-14 to remove the VA-118 board and Lens section.

6Refer to 2-16 to remove theVC-312 board and Mechanism deck.

7Refer to 2-17 to remove the MD frame assembly from the VC-312 board and Mechanism deck.

8Disconnect the flexible board from CN2502 ofVC-312 board.

9Supply +4.5V from the DC power supply to the loading motor and unload with a pressing the cassette compartment.

CN2502

DC power supply (+4.5Vdc

)

VC-312 board

Loading motor

Disconnect the flexible board

from CN2502 of VC-312 board.

1-2

DCR-TRV22/TRV22E

1-2. SELF-DIAGNOSIS FUNCTION

1. SELF-DIAGNOSIS FUNCTION

When problems occur while the unit is operating, the self-diagnosis

function starts working, and displays on the viewfinder, or LCD

screen what to do. This function consists of two display; self-

diagnosis display and service mode display.

Detailsof theself-diagnosis functions areprovided in the Instruction

manual.

2. SELF-DIAGNOSIS DISPLAY

When problems occur while the unit is operating, the counter of the

viewfinder orLCD screen consists ofan alphabet and4-digit number,

which blinks at 3.2Hz. This 5-character display indicates the

“repairedby:”,“block”in which theproblem occurred,and “detailed

code”of the problem.

Note: The “self-diagnosis display”data will be kept even if the lithium battery (BT5201 of CK-129 board) is removed.

1 1

3 1C

Repaired by:

Refer to page 1-3.

Self-diagnosis Code Table.

Indicates the appropriate

step to be taken.

E.g.

31 ....Reload the tape.

32 ....Turn on power again.

Block Detailed Code

Blinks at 3.2Hz

C : Corrected by customer

H : Corrected by dealer

E : Corrected by service

engineer

Viewfinder or LCD screen

C : 3 1 : 1 1

1-3E

DCR-TRV22/TRV22E

4. SELF-DIAGNOSIS CODETABLE

Block

Function

Detailed

Code

Symptom/State

Non-standard battery is used.

Condensation.

Video head is dirty.

LOAD direction. Loading does not

complete within specified time

UNLOAD direction. Loading does not

complete within specified time

T reel side tape slacking when unloading

Winding S reel fault when counting the

rest of tape.

T reel fault.

S reel fault.

T reel fault.

FG fault when starting capstan.

FG fault when starting drum.

FG fault during normal drum operations.

LOAD direction loading motor time-

out.

UNLOAD direction loading motor

time-out.

T reel side tape slacking when

unloading.

Winding S reel fault when counting the

rest of tape.

T reel fault.

S reel fault.

T reel fault.

FG fault when starting capstan.

FG fault when starting drum

FG fault during normal drum

operations

Difficult to adjust focus

(Cannot initialize focus.)

Zoom operations fault

(Cannot initialize zoom lens.)

Steadyshot function does not work well.

(Withpitch angular velocitysensoroutput

stopped.)

Steadyshot function does not work well.

(With yaw angular velocity sensor output

stopped.)

Self-diagnosis Code

Repaired by:

Correction

Use the info LITHIUM battery.

Remove the cassette, and insert it again after one hour.

Clean with the optional cleaning cassette.

Load the tape again, and perform operations from the beginning.

Remove the battery or power cable, connect, and perform
