Sony EVI-D80 User manual

EVI-H100S
•Full HD 1080p/30
•20x optical zoom lens
•HD-SDI interface
•1/2.8-type Exmor™ CMOS sensor
•Both standard mounting and ceiling
mounting with E-flip function
•Smart and stylish design -
available in black or white
EVI-H100V
•Full HD 1080p/30
•20x optical zoom lens
•DVI interface
•1/2.8-type Exmor™ CMOS sensor
•Both standard mounting and ceiling
mounting with E-flip function
•Smart and stylish design -
available in black or white
EVI-D90
•28x optical zoom lens
•Wide-D technology
•1/4-type EXview HAD CCD sensor
•Both standard mounting and ceiling
mounting with E-flip function
•Smart and stylish design -
available in black or white
EVI-D80
•18x optical zoom lens
•1/4-type CCD sensor
•Both standard mounting and ceiling
mounting with E-flip function
•Smart and stylish design -
available in black or white
From standard definition to high definition, Sony’s new EVI PTZ
cameras are ideal for videoconferencing, houses of worship,
corporate training, and distance learning.
EVI-H100S/H100V/D90/D80
Color Video Cameras

Model name EVI-H100S EVI-H100V EVI-D90 EVI-D80
Image sensor 1/2.8-type Exmor CMOS 1/2.8-type Exmor CMOS 1/4-type EXview HAD CCD 1/4-type CCD
Signal system HD 1080p/29.97, 1080p/25, 1080i/59.94
(frame out 1080PsF29.97), 1080i/50
(frame out 1080PsF25), 720p/59.94,
720p/50, 720p/29.97, 720p/25
1080p/29.97, 1080p/25, 1080i/59.94
(frame out 1080PsF29.97), 1080i/50
(frame out 1080PsF25), 720p/59.94,
720p/50, 720p/29.97, 720p/25
– –
SD NTSC/PAL – NTSC/PAL NTSC/PAL
Lens Focal length f=4.7 mm (wide) to 94.0 mm (tele) f=4.7 mm (wide) to 94.0 mm (tele) f=3.5 mm (wide) to 98.0 mm (tele) f=-4.1 mm (Wide) to 73.8 mm (Tele)
F1.6 to F3.5 F1.6 to F3.5 F1.35 to F3.7 F1.4 to F3.0
Optical zoom 20x 20x 28x 18x
Digital zoom 12x 12x 12x 12x
Min. object distance 10 mm (wide) - 800 mm (tele)
*Default: 290 mm
10 mm (wide) - 800 mm (tele)
*Default: 290 mm
10 mm (wide) - 1,500 mm (tele)
*Default: 300 mm
10 mm (wide) - 800 mm (tele)
*Default: 290 mm
Horizontal viewing angle 55.4 degrres (wide) to
2.9 degrees (tele)
55.4 degrres (wide) to
2.9 degrees (tele)
55.8 degrees (wide) to
2.1 degrees (tele)
48.0 degrees (wide) to
2.8 degrees (tele)
Focus systems Auto, One-push AF, Manual, Infinity Auto, One-push AF, Manual, Infinity Auto, One-push AF, Manual, Infinity Auto, One-push AF, Manual, Infinity
Min. illumination High sensitivity mode: 0.5 lx
(F1.6, 50 IRE)
Normal mode: 1.7 lx
(F1.6, 50 IRE)
High sensitivity mode: 0.5 lx
(F1.6, 50 IRE)
Normal mode: 1.7 lx
(F1.6, 50 IRE)
0.65 lx (F1.35, 50 IRE) 0.4 lx (F1.4, 50 IRE)
Shutter speed 1 to 1/10,000 s 1 to 1/10,000 s 1 to 1/10,000 s 1 to 1/10,000 s
Gain Auto/Manual/Max.AE Gain Limit
(-3 to 28 dB, 2 dB steps)
Auto/Manual/Max.AE Gain Limit
(-3 to 28 dB, 2 dB steps)
Auto/Manual/Max.AE Gain Limit
(-3 dB to +28 dB, 2 dB steps)
Auto/Manual/Max.AE Gain Limit
(-3 dB to +28 dB, 2 dB steps)
White balance
Auto, Indoor, Outdoor, One-push, Manual Auto, Indoor, Outdoor, One-push, Manual Auto, Indoor, Outdoor, One-push, Manual Auto, Indoor, Outdoor, One-push, Manual
Wide-D Yes Ye s Yes No
Exposure control Auto, Manual, Priority mode
(shutter priority & iris priority), Bright,
EV compensation, Slow Shutter AE
Auto, Manual, Priority mode
(shutter priority & iris priority), Bright,
EV compensation, Slow Shutter AE
Auto, Manual, Priority mode
(shutter priority & iris priority), Bright,
EV compensation, Slow Shutter AE
Auto, Manual, Priority mode
(shutter priority & iris priority), Bright,
EV compensation, Slow Shutter AE
S/N ratio More than 50 dB More than 50 dB More than 50 dB More than 50 dB
Pan/Tilt Angle Pan ±170° ±170° ±170° ±170°
Tilt +90°/-20° +90°/-20° +90°/-20° +90°/-20°
Max.
speed
Pan 100°/sec 100°/sec 100°/sec 100°/sec
Tilt 90°/sec 90°/sec 90°/sec 90°/sec
Preset positions 6 6 6 6
Video output HD HD-SDI DVI-I
(Digital (RGB) and Analog component)
– –
SD VBS – VBS,Y/C VBS,Y/C
Camera control Interface RS-232C/RS-422 RS-232C/RS-422 RS-232C/RS-422 RS-232C/RS-422
Protocol VISCA VISCA VISCA VISCA
Power requirements DC 12 V DC 12 V DC 12 V DC 12 V
Power consumption 12 W 11 W 8 W 6 W
Operating temperature 32°F to 104°F (0°C to 40°C) 32°F to 104°F (0°C to 40°C) 32°F to 104°F (0°C to 40°C) 32°F to 104°F (0°C to 40°C)
Storage temperature -4°F to +140°F (-20°C to +60°C) -4°F to +140°F (-20°C to +60°C) -4°F to +140°F (-20°C to +60°C) -4°F to +140°F (-20°C to +60°C)
Weight 3 lb 7 oz (1,550 g) 3 lb 7 oz (1,550g) 3 lb 3 oz (1,460 g) 3 lb 3 oz (1,440 g)
Dimensions (W x H x D) 5 3/4 x 6 1/2 x 6 1/2 inches
(145 x 164 x 164 mm)
5 3/4 x 6 1/2 x 6 1/2 inches
(145 x 164 x 164 mm)
5 3/4 x 6 1/2 x 6 1/2 inches
(145 x 164 x 164 mm)
5 3/4 x 6 1/2 x 6 1/2 inches
(145 x 134 x 164 mm)
Body color Black, White Black, White Black, White Black, White
Supplied accessories AC adaptor,AC power cable,
IR remote commander unit,
Ceiling bracket, Operating instructions,
RS-422 connector plug
AC adaptor,AC power cable,
IR remote commander unit,
Ceiling bracket, Operating instructions,
RS-422 connector plug
AC adaptor,AC power cable,
IR remote commander unit,
Ceiling bracket, Operating instructions,
RS-422 connector plug
AC adaptor,AC power cable,
IR remote commander unit,
Ceiling bracket, Operating instructions,
RS-422 connector plug
Specifications
HD models Black White
HD-SDI Interface EVI-H100S EVI-H100S/W
DVI Interface EVI-H100V EVI-H100V/W
SD models Black (NTSC) Black (PAL) White (NTSC) White (PAL)
Optical Zoom 28x EVI-D90N EVI-D90P EVI-D90N/W EVI-D90P/W
Optical Zoom 18x EVI-D80N EVI-D80P EVI-D80N/W EVI-D80P/W
Product Lineup
Sony Electronics Inc.
1 Sony Drive
Park Ridge, NJ 07656
www.sony.com/videocameras
IS-1245 (MK10856V3)
©2011 Sony Corporation.All rights reserved.
Reproduction in whole or in part without written permission is prohibited.
Features and specifications are subject to change without notice.
The values for weight and dimension are approximate.
SONY,“make.believe”,“Exmor” and “EXview HAD” are trademarks of Sony Corporation.
All other trademarks are the property of their respective owners.
Printed in USA (12/11)
