FCB-EH Series
High Definition Color Block Cameras
FCB-EH6300
FCB-EH3400 FCB-EH3300
SONY57676_FCB-EH Series.indd 1 7/29/11 9:38 AM

2
INTRODUCTION
KEY FEATURES
Excellent high-definition (HD) picture quality
The Exmor CMOS sensor realizes high image
quality and high sensitivity
Powerful zoom capability
Bright, fast and robust 28x zoom lens
The FCB-EH3400 incorporates a new 28x bright zoom lens with
f=1.35.This lens has a fast zooming capability (approx.2.6
seconds from tele end to wide end) and high durability.
Various output modes
nHD
Analog: Component (Y/Pb/Pr)
Digital: Y/Cb/Cr 4:2:2 via LVDS (Y: 8-bit, C: 8-bit,V-sync,
H-sync, Field and Clock)
nSD
VBS
Simple connection - one cable, one connector
• Covering video, VISCA communication and power supply
with a single cable.
• Supports both 30-pin micro coaxial (digital and analog
output) and 24-pin FFC (analog output only) interfaces.
Image Stabilization*
The FCB-EH3400 is equipped with an image-stabilization
function which minimizes the appearance of shaky images
caused by low-frequency vibration. This function is useful for
outdoor surveillance and traffic monitoring applications.
* When image stabilization is activated, residual movement may
appear at the top and bottom of the image.
StableZoom™ Mode
The FCB-EH3400 adopts a new method of image stabilization
by using the digital zoom. In StableZoom mode, this function
starts naturally without bringing an abrupt change to the
horizontal angle of view.
FCB-EH6300 FCB-EH3400 FCB-EH3300
Imager sensor 1/2.8-type 1/4-t ype 1/4 -type
Lens 20x 28x 20x
Picture Quality Full HD 1080p (1920 x 1080) HD 720p (1280 x 720)
Minimum illumination* 0.5 lx (F1.6, 50%) 0.25 lx (F1.35, 50%)
Digital zoom 12x (240x with optical zoom) 12x (336x with optical zoom) 12x (240x with optical zoom)
Wide-D (Wide dinamic range) lll
Image stabilization l
StableZoom l
Auto ICR (Auto IR-cut Filter Removal) lll
Spherical privacy zone masking lll
Noise reduction lll
Slow AE response lll
* High sensitivity mode
Sony, a leader in high-definition (HD) technology, is expanding its FCB Block Camera Series with the
addition of three new HD resolution cameras. In response to the growing demand for high-quality and
high-resolution images that only HD can offer, the FCB- EH Series offers a range of 20x to 28x optical zoom
lens options with outstanding features for surveillance, intelligent traffic, unmanned vehicles,photo
booths, police vehicles, low vision and videoconferencing applications.
The flagship FCB-EH6300 camera incorporates a 1/2.8-type Exmor™ CMOS image sensor with 1080p
resolution.The FCB-EH3400 and FCB-EH3300 cameras incorporate a 1/4-type Exmor CMOS image sensor
with 720p resolution. All three cameras inherit a multitude of features from Sony’s world-renowned FCB
Series such as Wide-D,Auto ICR and Spherical Privacy Zone Masking. With this breadth of choices,it has
never been easier to select the right Sony camera for your specific imaging applications.
SONY57676_FCB-EH Series.indd 2 7/29/11 9:38 AM

3
Other Features
lVarious modes for White Balance
(Auto, ATW, Indoor, Outdoor, Outdoor Auto, Sodium Vapor
Lamp Fix/Auto, One-push, Manual)
lPicture effects
(E-Flip, Nega Art, Black & White, Mirror Image, Color
Enhancement)
lPicture freeze
lTemperature readout
l Slow AE response (Approx. 5 min.)
lTitle display (20 characters per line,max. 11 lines)
lCamera mode display (English)
lElectronic shutter/slow shutter
l Spot AE
l High Sensitivity Mode
l IR Focus Correction Function
l4 Levels of Chrominance Suppression
Video Mode Change on The Fly
Without any power cycle,it is possible to change the video
mode from 1080p/29.97 mode to 720p/59.94 mode for
example.
Security-oriented functions include:
• Wide-D technology (On/Off/Auto/Ratio fix)
• Day/Night function (On/Off/Auto/Threshold enabled)
• Digital noise reduction (Up to 5 levels)
• Spherical privacy zone masking (24 zones with various PTZ
controls)
• Motion detection alarm (4 zones with several triggering and
threshold modes)
DIMENSIONS
Tripod Screw
Depth of 1/4 in or less
(5 mm - 20UNC)
8-M2
Depth of 1/8in (3 mm) or less
2-M2
Depth of 1/8in (3 mm) or less
9-M2
Depth of 1/8in (3 mm) or less
23/32 (17.5)
3 3/8(82.7)
1 15/16 (48.3) 1 (24.7)
1 3/8(33.5) 1 3/16 (29)
1 1/2(37.7) 1 5/16 (33)
7/16 (11) 11/32 (8)
CN601 30P CN501 24P
1 1/8(27)
21/32 (16)
9/16 (14±0.1)
3/16 (4.5)
23/32 (18)
1 1/8(28)
3 5/8(89.7)
3 3/8(85.5)
11/64 (4.3)
13/32 (10)
9/32 (5)
19/64 (7.6)
1
/ 2 (12.6)
11/32 (8)
7/16 (11)
13/16 (20)
13/16 (20)
3/16 (4.5)
15/16 (23.7)
31/32 (24.2)
1 1/16 (26)1 1/16 (26)
4-M2
Depth of 1/8in (3 mm) or less 4-M2
Depth of 1/8in (3 mm) or less
ø41.8
ø2.4 Hole
ø2.4 Hole
1 (25)
2 (50)
2 3/8(60)
1 3/16 (30)
1 3/16 (30)
13
/ 16 (20)
Front
Front
(without panel)
Top
Right
Left
Bottom
Rear
Tripod Screw
Depth of 1/4 in or less
(5 mm - 20UNC)
8-M2
Depth of 1/8 in (3 mm) or less
2-M2
Depth of 1/8 in (3 mm) or less
9-M2
Depth of 1/8 in (3 mm) or less
13/13 (20)
3 3/8(85.2)
2 7/8(73±0.1)
1 7/16 (36) 1 3/16 (29±0.1)
1 11/16 (40.2) 1 5/16 (33±0.1)
7/16 (11) 11/32 (8)
CN601 30P CN501 24P
1 1/8(27)
9/16 (13.5)
21/32 (16) 11/32 (8)
9/16 (14±0.1)
3/16 (4.5)
23/32 (18)
1 1/8(28±0.1)
3 1/2(87.9)
1 15/16 (48.3±0.1)
13/32 (10)
13/32 (10)
9/32 (5)
1/8(2.9)
19
/ 32 (15)
11/32 (8)
7/16 (11)
13/16 (20±0.1)
13/16 (20±0.1)
3/16 (4.5)
15/16 (23.7)
31/32 (24.2)
1 1/16 (26)1 1/16 (26)
4-M2
Depth of 1/8 in (3 mm) or less 3-M2
Depth of 1/8 in (3 mm) or less
ø41.8
ø2.4 Hole
ø2.4 Hole
1 (25)
2 (50)
2 3/8(60)
1 3/16 (30)
1 (25.4±0.1)
2 3/8(60)
1 3/16 (30)
13/16 (20±0.1)
Front
Front
(without panel)
Top
Right
Left
Bottom
Rear
Unit: inches (mm) Unit: inches (mm)
FCB-EH6300 FCB-EH3400/FCB-EH3300
SONY57676_FCB-EH Series.indd 3 7/29/11 9:38 AM

* Wide dynamic range
** Half frame rate at Off mode
SPECIFICATIONS PIN ASSIGNMENTS
Pin No. Name Level
1TXOUT3+
2TXOUT3-
3TXCLKOUT+
4TXCLKOUT-
5TXOUT2+
6TXOUT2-
7TXOUT1+
8TXOUT1-
9TXOUT0+
10 TXOUT0-
11 GND
12 TxD CMOS 5 V (Low: Max. 0.1 V,
High: Min. 4.4 V)
13 RxD CMOS 5 V (Low: Max. 0.8 V,
High: Min. 2.0 V)
14 DC IN 6 to 12 V DC
15 DC IN 6 to 12 V DC
16 DC IN 6 to 12 V DC
17 DC IN 6 to 12 V DC
18 DC IN 6 to 12 V DC
19 GND
20 GND
21 GND
22 GND
23 GND
24 GND
25 NC
26 RESET IN RESET: Low (GND)
Normal: Open (1.8 V)
27 VBS OUT
28 Y OUT HD Analog Component
29 Pb OUT HD Analog Component
30 Pr OUT HD Analog Component
Pin No. Name Level
1GND
2TxD CMOS 5 V (Low: Max. 0.1 V,
High: Min. 4.4 V)
3RxD CMOS 5 V (Low: Max. 0.8 V,
High: Min. 2.0 V)
4RESET IN RESET: Low (GND)
Normal: Open (1.8 V)
5GND
6NC
7GND
8NC
9GND
10 VBS OUT
11 GND
12 Y OUT HD Analog Component
13 GND
14 Pb OUT HD Analog Component
15 GND
16 Pr OUT HD Analog Component
17 GND
18 DC IN 6 to 12 V DC
19 DC IN 6 to 12 V DC
20 DC IN 6 to 12 V DC
21 DC IN 6 to 12 V DC
22 GND
23 DC IN 6 to 12 V DC
24 GND
Connector: USL00-30L-C (KEL Corp.)
CN601 30-pin Micro Coaxial
(for power supply/communication/video out (analog/digital)
CN501 24-pin FFC
(for power supply/communication/video out (analog)
FCB-EH6300 FCB-EH3400 FCB-EH3300
Camera
sensor Type 1/2.8-type Exmor CMOS 1/4-type Exmor CMOS 1/4-type Exmor CMOS
Number of
effective pixels Approx. 3.27 Megapixels Approx.1.43 Megapixels Approx.1.43 Megapixels
Image size (H x V) 1920 x 1080,1280 x 720, 720 x 480, 720 x 576 1280 x 720,720 x 480, 720 x 576 1280 x 720, 720 x 480, 720 x 576
Lens 20x optical zoom 28x optical zoom 20x optical zoom
f=4.7 mm (wide) to 94.0 mm (tele) f=3.5 mm (wide) to 98.0 mm (tele) f=3.5 mm (wide) to 70.0 mm (tele)
F1.6 to F3.5 F1.35 to F3.7 F1.35 to F3.4
Digital zoom 12x (240x with optical zoom) 12x (336x with optical zoom) 12x (240x with optical zoom)
Angle of
view (H) 1080p mode 55.4°(wide end) to 2.9°(tele end) – –
720p mode 37.6°(wide end) to 2.0°(tele end) 55.9°(wide end) to 2.1°(tele end) 55.9°(wide end) to 2.9°(tele end)
Minimum object distance 10 mm (wide end) to 1,000 mm (tele end)
(Default:300 mm) 10 mm (wide end) to 1,500 mm (tele end) (Default:300 mm) 10 mm (wide end) to 1,500 mm (tele end) (Default:300 mm)
Sync system Internal Internal Internal
Minimum
illumination
(50%)
High sensitivity
mode 0.5 lx (F1.6,ICR off) 0.095 lx (F1.6,ICR on) 0.25 lx (F1.35,ICR off) 0.03 lx (F1.35,ICR on) 0.25 lx (F1.35,ICR off) 0.03 lx (F1.35,ICR on)
Normal mode 1.7 lx (F1.6,ICR off)
0.3 lx (F1.6,ICR on) 1.0 lx (F1.35,ICR off) 0.1 lx (F1.35,ICR on) 1.0 lx (F1.35,ICR off) 0.1 lx (F1.35,ICR on)
Recommended illumination 100 lx to 100,000 lx 100 lx to 100,000 lx 100 lx to 100,000 lx
S/N ratio More than 50 dB More than 50 dB More than 50 dB
Signal
system HD 1080p/29.97,1080p/25, 1080i/59.94 (Frame out:29.97 PsF),1080i/50
(Fram out:25 PsF)
720p/59.94,720p/50, 720p/29.97, 720p/25
720p/59.94,720p/50, 720p/29.97, 720p/25 720p/59.94, 720p/50,720p/29.97, 720p/25
SD NTSC,PAL NTSC,PAL NTSC, PAL
Video
output HD Analog:Component (Y/Pb/Pr) Digital:Y/Cb/Cr 4:2:2 via LVDS
(Signal format conforms to SMPTE274/
SMPTE296.)
Analog:Component (Y/Pb/Pr)
Digital:Y/Cb/Cr 4:2:2 via LVDS
(Signal format conforms to SMPTE296.)
Analog:Component (Y/Pb/Pr)
Digital:Y/Cb/Cr 4:2:2 via LVDS
(Signal format conforms to SMPTE296.)
SD VBS VBS VBS
Camera control interface VISCA (CMOS 5 V level)
Baud rate:9.6 Kbps,19.2 Kbps,38.4 Kbps
Stop bit:1 bit
VISCA (CMOS 5 V level)
Baud rate:9.6 Kbps,19.2 Kbps,38.4 Kbps
Stop bit:1 bit
VISCA (CMOS 5 V level)
Baud rate:9.6 Kbps,19.2 Kbps,38.4 Kbps
Stop bit:1 bit
Electronic shutter speed 1/1 to 1/10,000 s,total 22 steps 1/1 to 1/10,000 s,total 22 steps 1/1 to 1/10,000 s,total 22 steps
White balance Auto,ATW,Indoor,Outdoor,Outdoor Auto,
Sodium Vapor Lamp (Fix/Auto),One-push,
Manual
Auto,ATW,Indoor,Outdoor,Outdoor Auto,
Sodium Vapor Lamp (Fix/Auto),One-push,
Manual
Auto,ATW,Indoor,Outdoor,Outdoor Auto,
Sodium Vapor Lamp (Fix/Auto),One-push,
Manual
Gain Auto/Manual (-3 dB to +28 dB,+2 dB step/total
16 steps)
Max.Gain Limit (+6 dB to +28 dB,+2 dB step/
total 12 stpes)
Auto/Manual (-3 dB to +28 dB, +2 dB step/total
16 steps)
Max.Gain Limit (+6 dB to +28 dB,+2 dB step/
total 12 stpes)
Auto/Manual (-3 dB to +28 dB, +2 dB step/total
16 steps)
Max.Gain Limit (+6 dB to +28 dB,+2 dB step/
total 12 stpes)
AE control Auto, Manual,Priority mode (shutter priority & iris
priority),
Bright,EV compensation, Slow AE
Auto, Manual,Priority mode (shutter priority & iris
priority),
Bright,EV compensation, Slow AE
Auto, Manual,Priority mode (shutter priority & iris
priority),
Bright,EV compensation, Slow AE
Focusing system Auto (Sensitivity:normal, low),One-push AF,
Manual,Infinity
Interval AF,Zoom Trigger AF,Focus compensation
in ICR on
Auto (Sensitivity:normal, low),One-push AF,
Manual,Infinity
Interval AF,Zoom Trigger AF,Focus compensation
in ICR on
Auto (Sensitivity:normal, low),One-push AF,
Manual,Infinity
Interval AF,Zoom Trigger AF,Focus compensation
in ICR on
EV compensation No No No
Backlight compensation Yes Yes Yes
Aperture control 16 steps 16 steps 16 steps
Preset 6 positions 6 positions 6 positions
Camera Features
Wide-D (*) Yes (On/Off/Auto) ** Yes (On/Off/Auto) Yes (On/Off/Auto)
Image stabilization No Yes No
StableZoom No Yes (33x) No
Digital output Yes Yes Yes
Auto ICR Yes Yes Yes
Spherical privacy zone masking Yes Yes Yes
Noise reduction Yes (On/Off) (Level 5 to 1/Off total 6 steps) Yes (On/Off) (Level 5 to 1/Off total 6 steps) Yes (On/Off) (Level 5 to 1/Off total 6 steps)
Motion detection Yes Yes Yes
Alarm Yes Yes Yes
Slow AE response Yes (Approx.5 minutes) Yes (Approx.5 minutes) Yes (Approx.5 minutes)
Picture effects Yes (E-Flip,Nega Art, Black & White,Mirror
image,Color enhancement) Yes (E-Flip,Nega Art, Black & White,Mirror image,Color enhancement) Yes (E-Flip,Nega Art, Black & White,Mirror image,Color enhancement)
Picture freeze Yes Yes Yes
Slow shutter Yes Yes Yes
Temperature readout Yes Yes Yes
Title display Yes (20 characters/line,max. 11 lines) Yes (20 characters/line,max. 11 lines) Yes (20 characters/line,max. 11 lines)
Camera mode display Yes Yes Yes
Key switch control No No No
Camera operation switch No No No
General
Storage temperature -4˚F to +140˚F (-20°C to +60°C) -4˚F to +140˚F (-20°C to +60°C) -4˚F to +140˚F (-20°C to +60°C)
Storage humidity 20% to 95% 20% to 95% 20% to 95%
Operating temperature 23˚F to +140˚F (-5°C to +60°C) 23˚F to +140˚F (-5°C to +60°C) 23˚F to +140˚F (-5°C to +60°C)
Operating humidity 20% to 80% 20% to 80% 20% to 80%
Power requirements 6.0 V to 12.0 V DC 6.0 V to 12.0 V DC 6.0 V to 12.0 V DC
Power consumption 3.2 W (zoom/focus inactive) / 3.8 W (zoom/
focus active) 2.7 W (zoom/focus inactive) / 3.4 W (zoom/ focus active) 2.7 W (zoom/focus inactive) / 3.4 W (zoom/ focus active)
Weight 9.2 oz (260 g) 8.5 oz (240 g) 8.5 oz (240 g)
Dimensions (W x H x D) 2 x 2 3/8 x 3 1/2 inches (50.0 x 60.0 x 87.9 mm) 2 x 2 3/8 x 3 5/8 inches (50.0 x 60.0 x 89.7 mm) 2 x 2 3/8 x 3 5/8 inches (50.0 x 60.0 x 89.7 mm) Connector: 046240024006800+ (Kyocera Elco)
Sony Electronics Inc.
1 Sony Drive
Park Ridge, NJ 07656
sony.com/videocameras
IS-1243 (MK10862V1)
© 2011 Sony Corporation. All rights reserved.
Reproduction in whole or in part without written permission is prohibited.
Features and specifications are subject to change without notice.
The values for weight and dimension are approximate.
SONY, make.believe, Exmor and StableZoom are
registered trademarks of Sony Corporation.
All other trademarks are the property of their respective owners.
Printed in USA (7/11)
SONY57676_FCB-EH Series.indd 4 7/29/11 9:38 AM
