5. REPAIR PARTS LIST
5. REPAIR PARTS LIST
DCR-TRV380/TRV480/TRV480E
5-1-1. OVERALL ASSEMBLY
Ref. No. Part No. Description Ref. No. Part No. Description
1X-2024-897-1 CABINET (C (970)) ASSY, P
23-080-203-31 SREW (M2), LOCK ACE, P2
33-087-813-11 COVER (51), JACK
42-548-261-31 SHEET (90), JACK
53-087-811-11 CABINET (UPPER) (51)
63-078-889-11 SCREW (M1.7)
73-087-810-11 LID (51), CPC
8COUTION RETAINER (51), EVF FLEXIBLE
93-079-012-11 SCREW (30), TRIPOD
10 2-580-024-41 LABEL (90)
11 3-080-204-21 SCREW, TAPPING, P2
12 3-078-890-21 SCREW, TAPPING
13 3-080-204-31 SCREW (1.7X6), TAPPING, P2
5-1. EXPLODED VIEWS
CAUTION :
For the part of 8 : RETAINER (51), EVF FLEXIBLE
(3-088-616-01), cut WOVEN (T0.25), FABRIC NON
(3-076-631-01) into the desired length and use it.
ns
1
2
2
3
4
Front panel block
(See page 5-3.)
Battery panel bloc
k
(See page 5-8.)
Cabinet R bloc
k
(See page 5-6.)
MD frame block
(See page 5-9.)
Lens block
(See page 5-4.)
LCD block
(See page 5-5.)
2
5
6
7
9
10
2
2
22
2
2
212
13
11
EVF block
(See page 5-7.)
8
(SIZE:
1.5cm X 3.5cm)
ns: not supplied
Ver. 1.4 2008.07
The changed portions from
Ver. 1.3 are shown in blue.
SYSSET
2021/07/2107:47:00(GMT+09:00)

5-3
5. REPAIR PARTS LIST
5. REPAIR PARTS LIST
DCR-TRV380/TRV480/TRV480E
SI-041
51
62
53
54
55
56
58
58
59
60 61
58
58
52
MIC901
ns
ns
ns
J752
CN752
D753
D001
D002
D003
D754
IC751
CN751
5-1-2. FRONT PANEL BLOCK
Ref. No. Part No. Description Ref. No. Part No. Description
51 3-087-738-31 RETAINER (51), MICROPHONE
52 3-087-740-31 PLATE (51), MAGNIFICATION
53 X-2024-888-1 PANEL (970) ASSY, FRONT
54 3-087-739-01 PLATE (51), NAME
55 3-087-743-01 SCREW (51), FILTER
56 3-087-742-01 RING (51), FRONT
58 3-080-204-21 SCREW, TAPPING, P2
59 A-1082-752-A SI-041 BOARD, COMPLETE (Note 1)
60 1-860-929-11 FP-792 FLEXIBLE BOARD (Note 2)
61 3-087-994-01 CUSHION (51), JACK
62 3-088-031-01 CUSHION (51), MICROPHONE
CN751 1-794-276-11 CONNECTOR, SQUARE TYPE 4P (DV) (Note 1)
CN752 1-794-962-11 CONNECTOR, SQUARE TYPE (USB 5P) (USB)
(Note 1)
D001 6-500-744-01 DIODE NSPW500BS-TL2 (VIDEO LIGHT)
(Note 2)
D002 6-500-744-01 DIODE NSPW500BS-TL2 (VIDEO LIGHT)
(Note 2)
D003 6-500-744-01 DIODE NSPW500BS-TL2 (VIDEO LIGHT)
(Note 2)
D753 8-719-078-24 DIODE DAC3825 (IR EMITTER) (Note 1)
D754 8-719-078-24 DIODE DAC3825 (IR EMITTER) (Note 1)
IC751 6-704-975-01 IC RPM7240-V4 (Note 1)
J752 1-778-040-11 JACK, SMALL TYPE (A/V OUT) (Note 1)
MIC901 1-542-513-11 MICROPHONE
ns: not supplied
Note 1: CN751, CN752, D753, D754, IC751 and J752 are not
included in SI-041 complete board.
Note 2: D001, D002 and D003 are not included in FP-792 flex-
ible board.
SYSSET
2021/07/2107:47:00(GMT+09:00)

5-4
5. REPAIR PARTS LIST
5. REPAIR PARTS LIST
DCR-TRV380/TRV480/TRV480E
Note 2: Be sure to read “Precuations for Replacement of CCD
Imager” on page 4-5 when changing the CCD imager.
Ref. No. Part No. Description Ref. No. Part No. Description
101 8-848-765-01 DEVICE, LENS LSV-820A
102 1-758-554-11 FILTER BLOCK, OPTICAL
103 3-053-973-01 RUBBER (W), SEAL
104 A-7111-980-A CD-472 BOARD, COMPLETE
5-1-3. LENS BLOCK
105 3-080-204-21 SCREW, TAPPING, P2
IC951 A-7013-401-A CCD BLOCK ASSY (CCD IMAGER)
(TRV480E) (Note 1, 2)
IC951 A-7016-724-A CCD BLOCK ASSY (CCD IMAGER)
(TRV380/TRV480) (Note 1, 2)
CD-472
101
102
103
104
105
IC951
(Note1, 2)
Note 1: IC951 is not included in CD-472 complete board.
Ver 1.1 2004. 12
SYSSET
2021/07/2107:47:00(GMT+09:00)

5-5
5. REPAIR PARTS LIST
5. REPAIR PARTS LIST
DCR-TRV380/TRV480/TRV480E
5-1-4. LCD BLOCK
Ref. No. Part No. Description Ref. No. Part No. Description
151 X-2024-898-1 CABINET (M (970)) ASSY, P
152 3-087-902-01 FRAME (61), PANEL
153 A-1081-090-A PD-205 BOARD, COMPLETE
154 3-078-890-21 SCREW, TAPPING
155 3-078-889-11 SCREW (M1.7)
156 3-088-536-01 CUSHION (61), LCD
157 1-479-063-11 KEY BLOCK, CONTROL (SB-9000)
LCD901 8-753-052-10 ACX307AKM-1
0ND901 1-518-951-21 TUBE, FLUORESCENT, COLD CATHODE
The components identified by
mark 0or dotted line with
mark 0are critical for safety.
Replace only with part num-
ber specified.
Les composants identifiés par une
marque 0sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
PD-205
PD-205
151
157
156
152
153
LCD901
ND901
155
154
Ver. 1.4 2008.07
The changed portions from
Ver. 1.3 are shown in blue.
SYSSET
2021/07/2107:47:00(GMT+09:00)

5-6
5. REPAIR PARTS LIST
5. REPAIR PARTS LIST
DCR-TRV380/TRV480/TRV480E
Ref. No. Part No. Description Ref. No. Part No. Description
201 1-478-416-61 KEY BLOCK, CONTROL (CF-5100)
(including BT001)
202 3-080-206-11 SCREW, TAPPING, P2
203 3-080-205-21 SCREW, TAPPING, P2
204 1-962-648-11 HARNESS (PD-124)
205 3-087-826-11 COVER (M) (51), HINGE
206 3-087-825-31 COVER (C) (51), HINGE
5-1-5. CABINET R BLOCK
207 3-078-889-11 SCREW (M1.7)
208 1-478-418-11 KEY BLOCK, CONTROL (PR-5100)
209 X-3953-962-1 HINGE (51) ASSY
210 X-2024-894-1 CABINET (R (970)) ASSY
211 CAUTION TAPE (CF)
CAUTION :
For the part of 211 : TAPE (CF) (3-090-115-01), cut
WOVEN (T0.25), FABRIC NON (3-076-631-01) into
the desired length and use it.
201
(including BT001)
202
203
203
203
204 205
206
207
208
203
! : BT001 (BATTERY, LITHIUM SECONDARY)
Included in the control switch block (CF-5100).
%
%
209
210
ns
(BT001)
211
(SIZE:
0.7cm X 2.8cm)
CAUTION
Dangerofexplosionifbatteryisincorrectlyreplaced.
Replace only with the same or equivalent type.
ns: not supplied
SYSSET
2021/07/2107:47:00(GMT+09:00)

5-7
5. REPAIR PARTS LIST
5. REPAIR PARTS LIST
DCR-TRV380/TRV480/TRV480E
5-1-6. EVF BLOCK
Ref. No. Part No. Description Ref. No. Part No. Description
251 X-2025-532-1 CABINET (UPPER (955)) ASSY, EVF
252 X-3951-166-1 LENS (M) ASSY, VF
253 X-2025-533-1 CABINET (LOWER (905)) ASSY, EVF
254 3-080-204-21 SCREW, TAPPING, P2
255 X-2048-474-1 BASE (910) ASSY, SLIDE
257 3-080-203-31 SCREW (M2), LOCK ACE, P2
258 1-860-928-12 FP-797 FLEXIBLE BOARD
LCD902 1-805-465-61 INDICATOR MODULE LIQUID CRYSTAL
(TRV380/TRV480)
LCD902 1-805-465-81 INDICATOR MODULE LIQUID CRYSTAL
(TRV480E)
ns: not supplied
251
252
253 254
254
255
257
258
ns
LCD902
ns
ns
ns
SYSSET
2021/07/2107:47:00(GMT+09:00)

5-8
5. REPAIR PARTS LIST
5. REPAIR PARTS LIST
DCR-TRV380/TRV480/TRV480E
5-1-7. BATTERY PANEL BLOCK
ns: not supplied
Ref. No. Part No. Description Ref. No. Part No. Description
301 3-087-799-01 SHEET METAL (LOWER) (51), STRAP
302 3-078-889-11 SCREW (M1.7)
303 X-2024-900-1 PANEL (970) ASSY, BATTERY
304 3-072-305-11 LID (2500), JACK
305 1-816-271-21 MEMORY STICK CONNECTOR 10P
306 1-860-931-11 FP-799 FLEXIBLE BOARD
307 2-583-929-01 SHEET (970), MS SHIELD
BT901 1-694-772-11 TERMINAL BOARD, BATTERY
301
302 302
305
306
307
302
302
303 304
BT901
ns
ns
Ver 1.1 2004. 12
SYSSET
2021/07/2107:47:00(GMT+09:00)

5-9
5. REPAIR PARTS LIST
5. REPAIR PARTS LIST
DCR-TRV380/TRV480/TRV480E
5-1-8. MD FRAME BLOCK
ns: not supplied
Ref. No. Part No. Description Ref. No. Part No. Description
351 1-478-417-81 KEY BLOCK, CONTROL (SS-5100)
352 3-080-253-01 SCREW (M1.7), LOCK ACE, P2
353 X-3953-958-2 FRAME (51) ASSY, CS
354 3-080-204-21 SCREW, TAPPING, P2
355 3-078-889-11 SCREW (M1.7)
356 3-066-169-01 SHEET (30), MD
357 3-087-809-02 FRAME (51), MD
358 1-860-927-11 FP-796 FLEXIBLE BOARD
359 A-1093-414-A VC-345 BOARD, COMPLETE (SERVICE)
(TRV380)
359 A-1093-415-A VC-345 BOARD, COMPLETE (SERVICE)
(TRV480/TRV480E)
360 1-860-930-11 FP-794 FLEXIBLE BOARD
361 3-089-368-01 LABEL, FUSE REPLACEMENT (51)
(TRV380/TRV480)
362 X-2048-472-1 CABINET (L (910)) ASSY
363 3-978-765-01 SLIDER, G LOCK
364 3-087-802-01 BELT (51), GRIP
365 3-080-203-31 SREW (M2), LOCK ACE, P2
366 2-548-267-31 LABEL (L (95)) (TRV380)
366 2-548-267-41 LABEL (L (95)) (TRV480)
366 2-548-267-51 LABEL (L (95)) (TRV480E)
367 3-080-204-11 SCREW, TAPPING, P2
368 2-583-930-01 SHEET (970), VC SHIELD
VC-345
351
352
353
354
363
367
ns
ns
ns
ns
355
356
357
355
355
358 359
360
355
355
361
362
ns
364
365
366
365
Mechanism deck block
(See page 5-10 to 5-13.)
368
Ver 1.1 2004. 12
SYSSET
2021/07/2107:47:00(GMT+09:00)

5-10
5. REPAIR PARTS LIST
5. REPAIR PARTS LIST
DCR-TRV380/TRV480/TRV480E
5-1-9. CASSETTE COMPARTMENT ASSEMBLY, DRUM ASSEMBLY
ns: not supplied
701
704
701
703
707708
712
709
711
706
702
705
710
M901 LS chassis block
assembly
(See page 5-11.)
Mechanical chassis block
assembly
(See page 5-12 to 5-13.)
Ref. No. Part No. Description Ref. No. Part No. Description
701 3-065-932-01 PAN (2 MAIN M1.4X1.6), CAMERA
702 3-065-895-01 LEVER, REEL RELEASE
703 3-065-896-01 PLATE, BLIND
704 X-3951-298-1 CASSETTE COMPARTMENT ASSY
705 X-3951-302-1 DAMPER ASSY
706 X-3951-297-1 GEAR ASSY, R DRIVE
707 3-065-840-01 CUT (0.98X3X0.13), LUMILER (W)
708 3-065-935-01 HLC CUT 1.8X4X0.5
709 3-947-503-01 SCREW (M1.4)
710 X-3951-299-1 SCREW ASSY, DRUM FITTING
711 3-074-309-01 ROLLER A, LS GUIDE
712 7-624-101-04 STOP RING 1.2 (E TYPE)
M901 A-7048-986-A DRUM (DKH-04B-R) (SERVICE)
SYSSET
2021/07/2107:47:00(GMT+09:00)

5-11
5. REPAIR PARTS LIST
5. REPAIR PARTS LIST
DCR-TRV380/TRV480/TRV480E
5-1-10. LS CHASSIS BLOCK ASSEMBLY
ns: not supplied
751
753
757
754
783
752
752
774
777
776778
779
759
758
760
765
756 762
764
763
761
766
772
775
769
768
770
771
781
773
780
767
755
ns
FP-300
ns
FP-802
ns
S002
FP-301
ns
FP-302
ns
H001
H002
D001
S001
Q001
Q002
Ref. No. Part No. Description Ref. No. Part No. Description
751 3-065-822-02 RAIL (S), GUIDE
752 3-947-503-01 SCREW (M1.4)
753 A-7096-416-B BASE (S) BLOCK ASSY, GUIDE
754 A-7096-415-A BASE (T) BLOCK ASSY, GUIDE
755 A-7096-426-A CHASSIS ASSY, LS
756 3-065-802-01 SPRING, TG7 ARM
757 A-7096-414-A ARM BLOCK ASSY, TG7
758 3-065-801-01 RETAINER, TG7
759 3-065-932-01 PAN (2 MAIN M1.4X1.6), CAMERA
760 X-3951-303-1 ARM ASSY, PINCH
761 3-065-823-01 ARM, T RATCHET
762 3-065-794-01 ROAD (SPR), PINCH ARM
763 3-065-792-01 ROLLER, P LIM ARM
764 3-065-834-01 GUIDE (T), CASSETTE
765 3-065-824-01 SPRING, T RATCHET
766 A-7096-417-A SOFT ASSY, T
767 3-071-650-01 SCREW (M1.7) (S)
768 3-065-832-01 PLATE, LS CAM
769 3-065-828-01 ARM, S RATCHET
770 3-065-829-01 PLATE, S RATCHET (RE)
771 3-065-830-01 SPRING, S RATCHET
772 X-3951-288-1 TABLE (T) ASSY, REEL
773 3-065-819-01 SPRING, TG1 ARM
774 3-065-821-01 RAIL (T), GUIDE
775 X-3951-289-1 TABLE (S) ASSY, REEL
776 3-065-833-01 GUIDE, LOCK
777 3-065-831-01 PLATE (SPR), RE RETURN
778 X-3951-304-1 ARM ASSY, TG1
779 3-065-835-01 GUIDE (S), CASSETTE
780 3-065-820-01 SPRING, RVS ARM
781 X-3951-296-1 BAND (ASSY), BT
783 3-067-167-01 SCREW (M1.4X2), CAMERA TAPPING
D001 8-719-988-42 DIODE GL453 (TAPE LED)
H001 8-719-033-37 ELEMENT, HALL HW-105C (T REEL)
H002 8-719-033-37 ELEMENT, HALL HW-105C (S REEL)
Q001 8-729-907-25 PHOTO TRANSISTOR PT4850F (TAPE TOP)
Q002 8-729-907-25 PHOTO TRANSISTOR PT4850F (TAPE END)
S001 1-692-614-11 SWITCH, PUSH (3 KEY) (REC PROOF)
S002 1-572-688-11 SWITCH, PUSH LEVER (1 KEY) (C. C. LOCK)
SYSSET
2021/07/2107:47:00(GMT+09:00)

5-12
5. REPAIR PARTS LIST
5. REPAIR PARTS LIST
DCR-TRV380/TRV480/TRV480E
5-1-11. MECHANICAL CHASSIS BLOCK ASSEMBLY-1
ns: not supplied
805
810
802
809
802
815
824
817
819
802
823
820 821
822
815
818
S901
811
805
807
815
814
813
812
806
801
803
804
808
M902
M903
Mechanical chassis
block assembly-2
(See page 5-13.)
ns
Ref. No. Part No. Description Ref. No. Part No. Description
801 A-7096-422-A BASE ASSY, DRUM
802 3-947-503-01 SCREW (M1.4)
803 3-065-928-01 SPACER, GROUND
804 3-065-927-01 GROUND, DRUM
805 3-065-932-01 PAN (2 MAIN M1.4X1.6), CAMERA
806 3-067-154-01 SPRING, CAPSTAN
807 3-065-931-01 RAIL (T2), GUIDE
808 X-3947-398-1 SCREW ASSY, M1.7 PW
809 3-065-933-01 PAN (2 MAIN 1.4X4.5), CAMERA
810 1-677-049-11 FP-228 FLEXIBLE BOARD (DEW SENSOR)
811 1-680-434-11 FP-299 FLEXIBLE BOARD
812 3-065-877-01 PLATE (T), GUIDE LOCK
813 X-3951-301-1 PLATE ASSY, PINCH PRESSURE
814 3-065-881-01 SPRING, P PRESSURE PLATE
815 3-065-934-01 HLW CUT 0.98X3X0.25
817 3-065-898-01 SPRING, EJECT ARM
818 3-065-870-01 ROLLER, LS GUIDE
819 A-7096-421-A ARM ASSY, HCL
820 3-065-918-01 GEAR (2), CAM RELAY
821 A-7096-419-A GEAR ASSY, CHANGE
822 3-065-902-01 BELT, TIMING
823 3-065-905-01 GEAR, RELAY
824 3-065-882-01 ARM, EJECT
M902 8-835-701-01 MOTOR, DC SCE13A/C-NP (CAPSTAN)
M903 A-7096-420-A MOTOR ASSY, LD (LOADING)
S901 1-786-096-11 SWITCH, ROTARY (MODE SWITCH)
SYSSET
2021/07/2107:47:00(GMT+09:00)

5-13
5. REPAIR PARTS LIST
5. REPAIR PARTS LIST
DCR-TRV380/TRV480/TRV480E
Ref. No. Part No. Description Ref. No. Part No. Description
851 3-065-920-01 ARM, HC DRIVE
852 3-065-913-01 GEAR (4), LD
853 3-065-914-01 SHEET, COVER
854 3-065-917-01 GEAR (1), CAM RELAY
855 3-065-934-01 HLW CUT 0.98X3X0.25
856 3-065-915-01 GEAR (1), CAM
857 3-065-878-01 PLATE (S), GUIDE LOCK
858 3-065-932-01 PAN (2 MAIN M1.4X1.6), CAMERA
859 A-7096-413-A GEAR (S) ASSY, GUIDE
860 7-624-101-04 STOP RING 1.2 (E TYPE)
861 A-7096-412-A GEAR (T) ASSY, GUIDE
862 X-3951-307-1 PLATE ASSY, M SLIDE
863 X-3951-305-1 ARM ASSY, LS
864 3-065-901-01 ROLLER, LS ARM
865 3-065-916-01 GEAR (2), CAM
866 3-065-919-01 ARM, T1 LIMITTER
867 X-3951-308-1 ARM ASSY, GL
868 X-3951-300-2 CHASSIS ASSY, MECHANICAL
5-1-12. MECHANICAL CHASSIS BLOCK ASSEMBLY-2
852
855
856
858
857
860
859
861
865
866
867
854
868
851
853
862
864
863
SYSSET
2021/07/2107:47:00(GMT+09:00)

5-25E
DCR-TRV380/TRV480/TRV480E
Checking supplied accessories.
The components identified by
mark 0or dotted line with
mark 0are critical for safety.
Replace only with part num-
ber specified.
Les composants identifiés par une
marque 0sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
Other accessories
2-515-263-11 MANUAL, INSTRUCTION (ENGLISH)
(TRV480E: AEP, UK, E, AUS)
2-515-263-21 MANUAL, INSTRUCTION (FRENCH)
(TRV480E: AEP, E)
2-515-263-31 MANUAL, INSTRUCTION
(SPANISH, PORTUGUESE) (TRV480E: AEP)
2-515-263-41 MANUAL, INSTRUCTION (ITALIAN, GREEK)
(TRV480E: AEP)
2-515-263-51 MANUAL, INSTRUCTION (GERMAN, DUTCH)
(TRV480E: AEP)
2-515-263-61 MANUAL, INSTRUCTION (SWEDISH, RUSSIAN)
(TRV480E: NE)
2-515-263-71 MANUAL, INSTRUCTION (DANISH, FINNISH)
(TRV480E: NE)
2-515-263-81 MANUAL, INSTRUCTION (ARABIC, PERSIAN)
(TRV480E: E)
2-515-263-91 MANUAL, INSTRUCTION (SIMPLIFIED CHINESE)
(TRV480E: E)
2-515-268-11 MANUAL, INSTRUCTION (ENGLISH)
(TRV480: US, CND, E)
2-515-268-21 MANUAL, INSTRUCTION (FRENCH)
(TRV480: CND)
2-515-268-31 MANUAL, INSTRUCTION (SPANISH) (TRV380: E)
2-515-268-41 MANUAL, INSTRUCTION (PORTUGUESE)
(TRV380: E)
AC-L15A/L15B AC Adaptor (1) Power cord (1)
Lens cap (1)
Cap string (1)
Shoulder strap (1) A/V connecting cable (1)
Rechargeable battery pack
NP-FM30 (1)
Conversion 2P adaptor (1)
Wireless Remote Commander
RMT-831 (1)
Battery holder
3-083-973-01
USB cable (1)
CD-ROM
Ver 1.1 2004. 12
SYSSET
2021/07/2107:47:00(GMT+09:00)
