Sony FCBEX12E User manual

FCB-EX1020/FCB-EX1020P
FCB-EX490E/FCB-EX490EP
FCB-EX995E/FCB-EX995EP FCB-EX985E/FCB-EX985EP
FCB-EX48E/FCB-EX48EP
FCB-EX Series
Color Block Cameras
www.sony.com/videocameras
FCB-EX11D/FCB-EX11DP
FCB-EX15E/FCB-EX15EP FCB-EX12E/FCB-EX12EP
FCB-EX20D/FCB-EX20DP
SONY57676_FCX-EX.indd 1 7/29/11 9:39 AM

2
Sony’s FCB Series of color block cameras offers excellent picture quality, superb flexibility,
and easy operation in a variety of applications ranging from surveillance to traffic
monitoring, and in many other visual communication environments. These cameras are
specifically designed to be integrated into security domes/cameras,police vehicles, photo
booths, document stands, and low-vision systems. There are nine cameras in the FCB-EX
Series lineup,and each incorporates a wide variety of optical zoom lenses ranging from
10x to 36x. With this breadth of choice, it’s never been easier to select the right camera for
your specific monitoring applications.
INTRODUCTION
FEATURES
Wide Dynamic Range with New Technology
FCB-EX1020/FCB-EX1020P FCB-EX995E/FCB-EX995EP
FCB-EX490E/FCB-EX490EP FCB-EX15E/FCB-EX15EP
The Wide Dynamic Range (Wide-D) feature allows for the
capture clear of images in extreme lighting environments.
Auto Mode: When shooting in high or low contrast lighting
situations, these cameras monitor the luminance differences
within an image and automatically switch on and off the Wide
D feature depending on the visibility of the subjects and
background.
Interlace Wide-D and Progressive Wide-D Modes: There are two
modes to choose from.The Interlace mode is ideally suited for
high-contract lighting environments. The Progressive Scan
mode is suited for low-contrast environments.
<At normal speed shutter> <At high speed shutter>
simulated image
FCB-EX Series
Cameras
FCB-EX1020
FCB-EX1020P
FCB-EX995E
FCB-EX995EP
FCB-EX985E
FCB-EX985EP
FCB-EX490E
FCB-EX490EP
FCB-EX48E
FCB-EX48EP
FCB-EX15E
FCB-EX15EP
FCB-EX12E
FCB-EX12EP
FCB-EX11D
FCB-EX11DP
FCB-EX20D
FCB-EX20DP
Optical
Zoom Lens 36x 28x 18x 12x 10x
Key Features
Progressive
Scan
Wide D
Auto ICR
Stabilization
Digital
Output
Progressive
Scan
Wide D
Auto ICR
Stabilization
Digital
Output
Progressive
Scan
Wide D
Auto ICR
Stabilization
Digital
Output
Progressive
Scan
Wide D
Auto ICR
Stabilization
Digital
Output
Progressive
Scan
Wide D
Auto ICR
Stabilization
Digital
Output
Progressive
Scan
Wide D
Auto ICR
Stabilization
Digital
Output
Progressive
Scan
Wide D
Auto ICR
Stabilization
Digital
Output
Progressive
Scan
Wide D
Auto ICR
Stabilization
Digital
Output
SONY57676_FCX-EX.indd 2 7/29/11 9:39 AM

3
Progressive Scan Broadens Capabilities
FCB-EX1020/FCB-EX1020P FCB-EX995E/FCB-EX995EP
FCB-EX490E/FCB-EX490EP FCB-EX15E/FCB-EX15EP
Ideally suited for IP-ready monitoring applications, these
cameras adopt a Progressive Scan mode to provide
smooth and clear images when viewing details in a
moving image (i.e., license plate of moving vehicle,a
person running). Since network cameras typically have
backend systems based upon progressive scan, the
original picture quality can be maintained without any
conversion from interlace scan to progressive scan.
Digital Output (ITU-R BT656)
These cameras are equipped with a digital interface
(Y/Cb/Cr 4:2:2) which is comparable to ITU-R-BTU656. By
using the digital interface,the quality of the camera’s
video signal does not deteriorate. In addition, there is no
need for an external analog/digital converter between
the camera and other equipment.
High Resolution & High Sensitivity Images
These cameras in the FCB E Series deliver exceptional
picture quality and high sensitivity – ideal for security
applications. These cameras achieve a high horizontal
resolution of 550 TV lines enabling the reproduction of
amazingly clear and detailed images. The FCB-EX985E/
EX985EP camera achieves 0.25 lx (F1.35,50IRE) by
incorporating a Super HAD CCD II sensor and bright 28x
lens (f=1.35).
Auto IR-Cut Filter Removal (Auto ICR)
The Auto ICR function incorporated in these cameras
offers optimal sensitivity in both day-and-night shooting
applications. At a set level of darkness, the IR-cut filter is
automatically disabled (ICR ON) and the near-infrared
sensitivity is increased. At a set level of brightness, the
filter is automatically enabled (ICR OFF). The IR-cut filter
automatically engages depending on the ambient light,
allowing the cameras 24/7 operation in a variety of
lighting conditions.
Image Stabilization – StableZoom™ Mode
FCB-EX1020/FCB-EX1020P FCB-EX995E/FCB-EX995EP
FCB-EX985E/FCB-EX985EP
The FCB-EX1020/EX1020P, FCB-EX995E/EX995EP and
FCB-EX985E/EX985EP cameras adopt a new method of
Image Stabilization by using the digital zoom. The
Image Stabilization function starts naturally without an
abrupt change to the horizontal angle of view.
Bright, Fast and Robust 28x Zoom Lens
FCB-EX995E/FCB-EX995EP FCB-EX985E/FCB-EX985EP
The FCB-EX995/995EP and FCB-EX985E/985EP cameras
incorporate a new 28x bright zoom lens with f=1.35. This
lens has a fast zooming capability (2.5 seconds from tele
end to wide end) and high durability.
White Balance – New Modes
Sodium Vapor Lamp Mode: When a camera is shooting
under a sodium vapor lamp (typically a street lamp or
tunnel lamp), images could appear to have a yellowish
tint. The new FCB E Version cameras are equipped with a
new Sodium Vapor Lamp Mode that automatically
compensates for the sodium vapor lamp degree of Kelvin
to restore objects to their original color.
Outdoor Auto Mode: When a camera is shooting at
dawn or dusk, images could appear bluish. The new FCB
E Version cameras are equipped with a new Outdoor
Auto Mode feature that automatically adjusts the white
balance to reduce the dark tones at dawn or dusk.
Enhanced Noise Reduction
By combing 2D and 3D noise reduction, the cameras offer
a selection of noise-reduction settings (from Level 1 to
Level 5) to allow the user to choose the ideal level for
shooting conditions.
FCB-EX1020/FCB-EX1020P
FCB-EX48E/FCB-EX48EP
FCB-EX985E/FCB-EX985EP
FCB-EX12E/FCB-EX12EP
FCB-EX995E/FCB-EX995EP
FCB-EX15E/FCB-EX15EP
FCB-EX490E/FCB-EX490EP
FCB-EX490E/FCB-EX490EP
FCB-EX1020/FCB-EX1020P
FCB-EX48E/FCB-EX48EP
FCB-EX985E/FCB-EX985EP
FCB-EX12E/FCB-EX12EP
FCB-EX995E/FCB-EX995EP
FCB-EX15E/FCB-EX15EP
FCB-EX490E/FCB-EX490EP
FCB-EX490E/FCB-EX490EP
FCB-EX1020/FCB-EX1020P
FCB-EX48E/FCB-EX48EP
FCB-EX985E/FCB-EX985EP
FCB-EX12E/FCB-EX12EP
FCB-EX995E/FCB-EX995EP
FCB-EX15E/FCB-EX15EP
FCB-EX490E/FCB-EX490EP
FCB-EX490E/FCB-EX490EP
FCB-EX1020/FCB-EX1020P
FCB-EX48E/FCB-EX48EP
FCB-EX985E/FCB-EX985EP
FCB-EX12E/FCB-EX12EP
FCB-EX995E/FCB-EX995EP
FCB-EX15E/FCB-EX15EP
FCB-EX490E/FCB-EX490EP
FCB-EX490E/FCB-EX490EP
FCB-EX1020/FCB-EX1020P
FCB-EX15E/FCB-EX15EP
FCB-EX985E/FCB-EX985EP
FCB-EX995E/FCB-EX995EP
FCB-EX12E/FCB-EX12EP
FCB-EX490E/FCB-EX490EP
SONY57676_FCX-EX.indd 3 7/29/11 9:39 AM

4
Bright, Fast and Robust 28x Zoom Lens
FCB-EX995E/FCB-EX995EP FCB-EX985E/FCB-EX985EP
The FCB-EX995/995EP and FCB-EX985E/985EP cameras
incorporate a new 28x bright zoom lens with f=1.35. This
lens has a fast zooming capability (2.5 seconds from tele
end to wide end) and high durability.
White Balance – New Modes
Sodium Vapor Lamp Mode: When a camera is shooting
under a sodium vapor lamp (typically a street lamp or
tunnel lamp), images could appear to have a yellowish
tint. The new FCB E Version cameras are equipped with a
new Sodium Vapor Lamp Mode that automatically
compensates for the sodium vapor lamp degree of Kelvin
to restore objects to their original color.
Outdoor Auto Mode: When a camera is shooting at
dawn or dusk, images could appear bluish. The new FCB
E Version cameras are equipped with a new Outdoor
Auto Mode feature that automatically adjusts the white
balance to reduce the dark tones at dawn or dusk.
Enhanced Noise Reduction
By combing 2D and 3D noise reduction, the cameras offer
a selection of noise-reduction settings (from Level 1 to
Level 5) to allow the user to choose the ideal level for
shooting conditions.
Slow AE Response
These cameras allow the user to set the auto response
speed (up to 10 minutes) to enable the cameras to
adapt to changes in lighting conditions. For example,
when shooting in an underground parking lot, valuable
images could otherwise be missed when car headlights
cause an abrupt change in lighting conditions.
Color Enhancement
Ideally suited for low vision applications,new color
enhancement options can make reading text and
pictures less challenging. Full color images can be
changed to black and white, and then inverted into two
selected colors. changed to black and white,and then
All Models
inverted into two selected colors.
Other Features
lElectronic Flip (E:Flip)
lMulti-line On-Screen Display
lVideo Motion Detection
lPicture Freeze
lSMART (Sony Modular Automatic Lens
lReset Technology)
Other Features
lGain Limit Setting
lZoom Limit Setting
lZoom Speed-up in Zoom Direct Mode
l(Focus Trace On/Off)
lFocus Compensation in ICR Mode
lAlarm Signal Output in Auto ICR Mode
lImage Stabilization Hold
lExtended Operation Temperature
lTemperature Readout
All Models
Pan range: 0
Pan range: 20
Masking area
Movement of masking area
Monitor
Monitor
Pan range: 0
Pan range: 20
Masking area
Movement of masking area
Monitor
Monitor
As camera pans and tilts, the masked area moves to maintain the desired
covered area.
Advanced Spherical Privacy Zone Masking
With these new cameras, a maximum of eight masking
areas can be displayed on the monitoring screen. Also, if
these block cameras are integrated into a Pan/Tilt/Zoom
(P/T/Z) camera system, masked areas can be interlocked
with P/T/Z movement, regardless of the camera angle or
camera movement. Up to 24 masking areas can be
preset in the entire viewing angle of a P/T/Z camera. In
addition, these cameras can mask unwanted or
prohibited areas within an image using a mosaic effect
on top of the color masking function.
All Models
FCB-EX1020/FCB-EX1020P
FCB-EX48E/FCB-EX48EP
FCB-EX985E/FCB-EX985EP
FCB-EX12E/FCB-EX12EP
FCB-EX995E/FCB-EX995EP
FCB-EX15E/FCB-EX15EP
FCB-EX490E/FCB-EX490EP
FCB-EX490E/FCB-EX490EP
FCB-EX1020/FCB-EX1020P
FCB-EX48E/FCB-EX48EP
FCB-EX985E/FCB-EX985EP
FCB-EX12E/FCB-EX12EP
FCB-EX995E/FCB-EX995EP
FCB-EX15E/FCB-EX15EP
FCB-EX490E/FCB-EX490EP
FCB-EX490E/FCB-EX490EP
FCB-EX1020/FCB-EX1020P
FCB-EX48E/FCB-EX48EP
FCB-EX985E/FCB-EX985EP
FCB-EX12E/FCB-EX12EP
FCB-EX995E/FCB-EX995EP
FCB-EX15E/FCB-EX15EP
FCB-EX490E/FCB-EX490EP
FCB-EX490E/FCB-EX490EP
Pan range: 0
Pan range: 20
Masking area
Movement of masking area
Monitor
Monitor
SONY57676_FCX-EX.indd 4 7/29/11 9:39 AM

5
PIN ASSIGNMENT
n 4-pin for Y/C Video Out
Pin No. Name Level
1 Y_OUT 1.0 Vp-p (75 Ω terminate) Luminance signal
2 GND (for Y signal) –
3 C_OUT Chrominance signal
4 GND (for C signal) –
Connector: JST S4B-ZR-SM4A-TF (LF)
Pin No. Name Level
1 RxD CMOS 5.0 V (Low:max 0.8 V, High: min 2.0 V) Read Data
2 TxD CMOS 5.0 V (Low:max 0.1 V, High: min 4.4 V) Send Data
3 GND (for RxD & TxD) –
4 DC IN 9.0 V ±3.0 V
5 GND (for DC IN) –
6 VBS OUT 1.0 Vp-p (75 Ω terminate)
7 GND (for VBS OUT) –
8 V LOCK PULSE External VD-Lock Pulse (Negative, 3.0 Vp-p 50% duty)
9 GND (for V LOCK PULSE) –
n 9-pin for DC/Video Out
Pin No. Name Level
1 GND –
2 GND –
3 KEY_AD0 Pull up to 3.0 V by 100 kΩ
4 KEY_AD1 Pull up to 3.0 V by 100 kΩ
5 KEY_AD2 Pull up to 3.0 V by 100 kΩ
6 KEY_AD3 Pull up to 3.0 V by 100 kΩ
7 KEY_AD4 Pull up to 3.0 V by 100 kΩ
8 KEY_AD5 Pull up to 3.0 V by 100 kΩ
9 KEY_AD6 Pull up to 3.0 V by 100 kΩ
10 KEY_AD7 Pull up to 3.0 V by 100 kΩ
11 NC –
12 Strobe Strobe timing pulse (0 to 3.0 V)
Connector: KYOCERA ELCO 08 6222 012 101 848+
n 12-pin for Key Switch Control
Pin No. Name Level
1 GND
2 Digital Out 0 0 - 3.3 Vp-p
3 Digital Out 1 0 - 3.3 Vp-p
4 Digital Out 2 0 - 3.3 Vp-p
5 Digital Out 3 0 - 3.3 Vp-p
6 Digital Out 4 0 - 3.3 Vp-p
7 Digital Out 5 0 - 3.3 Vp-p
8 Digital Out 6 0 - 3.3 Vp-p
9 Digital Out 7 0 - 3.3 Vp-p
10 GND
11 CLOCK 0 - 3.3 Vp-p
12 GND
CN500 FCB-EX1020/FCB-EX1020P
FCB-EX995E/FCB-EX995EP
FCB-EX985E/FCB-EX985EP
FCB-EX490E/FCB-EX490EP
FCB-EX48E/FCB-EX48EP
CN602 FCB-EX20D/FCB-EX20DP
CN402 FCB-EX11D/FCB-EX11DP
CN601 FCB-EX20D/FCB-EX20DP
CN401 FCB-EX11D/FCB-EX11DP
CN501 FCB-EX1020/FCB-EX1020P
FCB-EX995E/FCB-EX995EP
FCB-EX985E/FCB-EX985EP
FCB-EX490E/FCB-EX490EP
FCB-EX48E/FCB-EX48EP
FCB-EX15E/FCB-EX15EP
FCB-EX12E/FCB-EX12EP
CN702 FCB-EX1020/FCB-EX1020P
FCB-EX995E/FCB-EX995EP
FCB-EX985E/FCB-EX985EP
FCB-EX490E/FCB-EX490EP
FCB-EX48E/FCB-EX48EP
CN801 FCB-EX20D/FCB-EX20DP
Connector: KYOCERA ELCO 00 6200 509 130 000+
n 12-pin for Digital Out
CN200 FCB-EX1020/FCB-EX1020P
FCB-EX995E/FCB-EX995EP
FCB-EX985E/FCB-EX985EP
FCB-EX490E/FCB-EX490EP
FCB-EX48E/FCB-EX48EP
Connector: KYOCERA ELCO 08 6222 012 101 848+ [FFC 0.5 mm Pitch]
Pin No. Name Level
1 TXOUT3+
2 TXOUT3-
3 TXCLKOUT+
4 TXCLKOUT-
5 TXOUT2+
6 TXOUT2-
7 TXOUT1+
8 TXOUT1-
9 TXOUT0+
10 TXOUT0-
11 GND
12 TxD CMOS 5 V (Low: Max. 0.1 V, High: Min. 4.4 V)
13 RxD CMOS 5 V (Low: Max. 0.8 V, High: Min. 2.0 V)
14 DC IN 6 to 12 V DC
15 DC IN 6 to 12 V DC
16 DC IN 6 to 12 V DC
17 DC IN 6 to 12 V DC
18 DC IN 6 to 12 V DC
19 GND
20 GND
21 GND
22 GND
23 GND
24 GND
25 GND
26 GND
27 VBS OUT
28 GND
29 V LOCK PULSE
30 GND
Connector: USL00-30L-C (KEL Corp.)
n 30-pin for Digital Out
CN601 FCB-EX15E/FCB-EX15EP
FCB-EX12E/FCB-EX12EP
SONY57676_FCX-EX.indd 5 7/29/11 9:39 AM

6
DIMENSIONS
ø38.6
1 (25)
2 3/8(57.5)
1 1/8(27.5)
1 3/16 (30)
2 (50)
Front
Bottom
1 5/8(40.2)
1 1/16 (36)
1 1/8±0.1 (27)
2 1/8(53)9/16 (14)
13/16 (20)
8-M2
Depth of 1/8in (3 mm) or less
1/4-20UNC
(Tripod screw for camera)
21/32 ±0.1 (16)
1 3/16 ±0.1 (29)
1 5/16 ±0.1 (33)
3/8(9.5)
5/16 (7.5)
Rear
CN500
CN501
Left
9/16 ±0.1 (14)
Depth of 1/8in (3 mm) or less
2-M2
3/16 (4.5)
3 3/8(85.2)
Top
13/16 ±0.1
(20)1 1/8±0.1 (28)
13/16 ±0.1 (20)
19/32
(15)
1 7/16 (36.5)
29/32
(22.5)
7/32 (5)
9-M2
Depth of 1/8in (3 mm) or less
13/16 ±0.1 (20)
CN702
CN200
Tele
Wide
Right
1 ±0.1 (25.4)
3 1/2(87.9)
1/8(2.5)
4-M2
Depth of 1/8in (3 mm) or less
27/32 ±0.1 (21)
13/32 (10) 1 15/16 ±0.1 (48.3)
2 7/8±0.1 (73)
13/32 (10)
ø38.6
1 (25)
2 3/8(57.5)
1 1/8(27.5)
1 3/16 (30)
2 (50)
Front
Bottom
1 5/8(40.2)
1 1/16 (36)
1 1/8±0.1 (27)
2 1/8(53)9/16 (14)
13/16 (20)
8-M2
Depth of 1/8in (3 mm) or less
1/4-20UNC
(Tripod screw for camera)
21/32 ±0.1 (16)
1 3/16 ±0.1 (29)
1 5/16 ±0.1 (33)
3/8(9.5)
5/16 (7.5)
Rear
CN500
CN501
Left
9/16 ±0.1 (14)
Depth of 1/8in (3 mm) or less
2-M2
3/16 (4.5)
3 3/8(85.2)
Top
13/16 ±0.1
(20)1 1/8±0.1 (28)
13/16 ±0.1 (20)
19/32
(15)
1 7/16 (36.5)
29/32
(22.5)
7/32 (5)
9-M2
Depth of 1/8in (3 mm) or less
13/16 ±0.1 (20)
CN702
CN200
Tele
Wide
Right
1 ±0.1 (25.4)
3 1/2(87.9)
1/8(2.5)
4-M2
Depth of 1/8in (3 mm) or less
27/32 ±0.1 (21)
13/32 (10) 1 15/16 ±0.1 (48.3)
2 7/8±0.1 (73)
13/32 (10)
2 (50)
1 (25)
ø36.1
Front
2 3/8(57.5)
1 1/8(27.5)
1 3/16 (30)
Depth of 1/8in (3 mm) or less
Tripod Screw
Depth of 1/4 in or less
(4.7 mm-20UNC)
8-M2
1 3/16 ±0.1 (29)
1 1/8±0.1 (27)
21/32 ±0.1 (16 )
1 3/8(33.5)
1 1/2(37.7)1 5/16 ±0.1 (33)
2 5/8(64.5)
23/32 (17.5)9/16 ±0.1 (14)
Bottom
Left
1 3/8(33.9)
3 3/8(82.7)
9/16 ±0.1 (14) 3/16 (4.5)
Depth of 1/8in (3 mm) or less
2-M2
CN501
CN503
5/16 (7.55)
3/8(9.5)
Rear
27/32 (20.9)
1 3/8(33.9)
CN200
Top
Depth of 1/8in (3 mm) or less
9-M2
CN702
13/16 ±0.1 (20)
13/16 ±0.1 (20)7/325(7/32)
1/2
(12.5)
13/16 ±0.1
(20)1 1/8±0.1 (28)
Tele
Wide
Right
1 3/16 (30)
Depth of 1/8in (3 mm) or less
4-M2
3 5/8(89.8)
3 3/8(85.4)
1 15/16 (48.3)
3/16
(4.4)
5/16
(7.5)
25.4 ±0.1 (1)
27/32 ±0.1 (21)
10 (13/32)
2 7/8±0.1 (73)
2 (50)
1 (25)
ø36.1
Front
2 3/8(57.5)
1 1/8(27.5)
1 3/16 (30)
Depth of 1/8in (3 mm) or less
Tripod Screw
Depth of 1/4 in or less
(4.7 mm-20UNC)
8-M2
1 3/16 ±0.1 (29)
1 1/8±0.1 (27)
21/32 ±0.1 (16 )
1 3/8(33.5)
1 1/2(37.7)1 5/16 ±0.1 (33)
2 5/8(64.5)
23/32 (17.5)9/16 ±0.1 (14)
Bottom
Left
1 3/8(33.9)
3 3/8(82.7)
9/16 ±0.1 (14) 3/16 (4.5)
Depth of 1/8in (3 mm) or less
2-M2
CN501
CN503
5/16 (7.55)
3/8(9.5)
Rear
27/32 (20.9)
1 3/8(33.9)
CN200
Top
Depth of 1/8in (3 mm) or less
9-M2
CN702
13/16 ±0.1 (20)
13/16 ±0.1 (20)7/325(7/32)
1/2
(12.5)
13/16 ±0.1
(20)1 1/8±0.1 (28)
Tele
Wide
Right
1 3/16 (30)
Depth of 1/8in (3 mm) or less
4-M2
3 5/8(89.8)
3 3/8(85.4)
1 15/16 (48.3)
3/16
(4.4)
5/16
(7.5)
25.4 ±0.1 (1)
27/32 ±0.1 (21)
10 (13/32)
2 7/8±0.1 (73)
FCB-EX1020/FCB-EX1020P
FCB-EX995E/FCB-EX995EP/FCB-EX985E/FCB-EX985EP
Unit: inches (mm)
Unit: inches (mm)
SONY57676_FCX-EX.indd 6 7/29/11 9:39 AM

7
Top
7-M2
Depth of 1/8 in (3 mm) or less
13/16 ±0.1 (20)
13/16 ±0.1 (20)
7/32 (5)
19/32
(15)
13/16 ±0.1
(20)
5/16 (7.3)
11/32 (8.05)
CN500 CN501
Rear
Right
4-M2
Depth of 1/8 in (3 mm) or less
1±0.1 (25.4)
27/32 ±0.1 (21)
1 5/8(39.75)
7/32 (5.05)
3 1/2(88.5)
1 15/16 ±0.1 (48.3)
13/32 (10)
13/32 (10)
2 7/8±0.1 (73)
2 3/8(57.5)
1 3/16 (30)
1 (25)
2 1/8(52.55)
1 1/8(27.5)
Front 2 (50)
ø34.1
8-M2
Depth of 1/8 in (3 mm) or less
1 3/16 ±0.1 (29)
1 5/8(40.2)1 5/16 ±0.1 (33)
1 1/8±0.1 (27)
21/32 ±0.1 (16)
1 1/16 (36)
Bottom 2 1/8(53)9/16 ±0.1 (14)Tripod Screw,
Depth of 1/4 in or less
(7 mm-20UNC)
Left
3/16 (4.5)
2-M2
CN200
CN702
Depth of 1/8 in (3 mm) or less
9/16 ±0.1 (14)
3 3/8(85.2)
Tele
Wide
Top
7-M2
Depth of 1/8 in (3 mm) or less
13/16 ±0.1 (20)
13/16 ±0.1 (20)
7/32 (5)
19/32
(15)
13/16 ±0.1
(20)
5/16 (7.3)
11/32 (8.05)
CN500 CN501
Rear
Right
4-M2
Depth of 1/8 in (3 mm) or less
1±0.1 (25.4)
27/32 ±0.1 (21)
1 5/8(39.75)
7/32 (5.05)
3 1/2(88.5)
1 15/16 ±0.1 (48.3)
13/32 (10)
13/32 (10)
2 7/8±0.1 (73)
2 3/8(57.5)
1 3/16 (30)
1 (25)
2 1/8(52.55)
1 1/8(27.5)
Front 2 (50)
ø34.1
8-M2
Depth of 1/8 in (3 mm) or less
1 3/16 ±0.1 (29)
1 5/8(40.2)1 5/16 ±0.1 (33)
1 1/8±0.1 (27)
21/32 ±0.1 (16)
1 1/16 (36)
Bottom 2 1/8(53)9/16 ±0.1 (14)Tripod Screw,
Depth of 1/4 in or less
(7 mm-20UNC)
Left
3/16 (4.5)
2-M2
CN200
CN702
Depth of 1/8 in (3 mm) or less
9/16 ±0.1 (14)
3 3/8(85.2)
Tele
Wide
Top
7-M2
Depth of 1/8 in (3 mm) or less
13/16 ±0.1 (20)
13/16 ±0.1 (20)
7/32 (5)
19/32
(15)
13/16 ±0.1
(20)
Rear
Bottom
1 1/16 (36)
1 5/8(40.2)1 3/8±0.1 (34.375)
1 3/16 ±0.1 (29)
8-M2
Depth of 1/8 in (3 mm) or less
Tripod Screw,
Depth of 1/4 in or less
(7 mm-20UNC)
1 1/8±0.1 (27)
21/32 ±0.1 (16)
2 1/8(53)9/16 ±0.1 (14)
5/16 (7.3)
11/32 (8.05)
CN500 CN501
Right
4-M2
Depth of 1/8 in (3 mm) or less
1±0.1 (25.4)
27/32 ±0.1 (21)
1 5/8(39.75)
7/32 (5.05)
3 1/2(88.5)
1 15/16 ±0.1 (48.3)
13/32 (10)
13/32 (10)
2 7/8±0.1 (73)
Front 2 (50)
1 (25)
2 3/8(57.5)
1 3/16 (30)1 1/8(27.5)
ø34.1
Left
2-M2
Depth of 1/8 in (3 mm) or less
CN200
CN702
9/16 ±0.1 (14)
3/16 (4.5)
3 3/8(85.2)
Tele
Wide
Top
7-M2
Depth of 1/8 in (3 mm) or less
13/16 ±0.1 (20)
13/16 ±0.1 (20)
7/32 (5)
19/32
(15)
13/16 ±0.1
(20)
Rear
Bottom
1 1/16 (36)
1 5/8(40.2)1 3/8±0.1 (34.375)
1 3/16 ±0.1 (29)
8-M2
Depth of 1/8 in (3 mm) or less
Tripod Screw,
Depth of 1/4 in or less
(7 mm-20UNC)
1 1/8±0.1 (27)
21/32 ±0.1 (16)
2 1/8(53)9/16 ±0.1 (14)
5/16 (7.3)
11/32 (8.05)
CN500 CN501
Right
4-M2
Depth of 1/8 in (3 mm) or less
1±0.1 (25.4)
27/32 ±0.1 (21)
1 5/8(39.75)
7/32 (5.05)
3 1/2(88.5)
1 15/16 ±0.1 (48.3)
13/32 (10)
13/32 (10)
2 7/8±0.1 (73)
Front 2 (50)
1 (25)
2 3/8(57.5)
1 3/16 (30)1 1/8(27.5)
ø34.1
Left
2-M2
Depth of 1/8 in (3 mm) or less
CN200
CN702
9/16 ±0.1 (14)
3/16 (4.5)
3 3/8(85.2)
Tele
Wide
FCB-EX490E/FCB-EX490EP
FCB-EX48E/FCB-EX48EP
Unit: inches (mm)
Unit: inches (mm)
SONY57676_FCX-EX.indd 7 7/29/11 9:39 AM

8
1 3/4(43.1)
1 13/16 (45.9)
23/32 (17.9)
7/8(22.1)
Tripod Screw,
Depth 1/4 in or less (6 mm-20UNC)
4-M2 Depth 1/8in (3 mm) or less
Guide hole forTripod,
Depth 5/32 in (4 mm) or less
3/4(18.7) 9/16
(14±0.3)
1 1/4(31.5±0.3)
15/32 (11.4)
11/32
(8) 1/4
( 6 ±0.3)
21/32
(16±0.3)
CN601 (VBS)
CN801(Key SW)
4-M2 Depth 1/8in (3 mm) or less
CN803 (LANC)
11/32 (8)
1/8(3)
21/32
(16±0.3)
1 1/4(31.5±0.3)
21/32
(1 6.3±0.3)19/32
(14.9)
11/16
(17.4)2 1/2(61.1)
Front
Top
2 3/4(67.2)
2 1/2(61.1)
1/4( 6.1)
7/32 (5) CN602 (Y/C)
Right
Left
Rear
Bottom
1 3/4(43.1)
1 13/16 (45.9)
23/32 (17.9)
7/8(22.1)
Tripod Screw,
Depth 1/4 in or less (6 mm-20UNC)
4-M2 Depth 1/8in (3 mm) or less
Guide hole forTripod,
Depth 5/32 in (4 mm) or less
3/4(18.7) 9/16
(14±0.3)
1 1/4(31.5±0.3)
15/32 (11.4)
11/32
(8) 1/4
( 6 ±0.3)
21/32
(16±0.3)
CN601 (VBS)
CN801(Key SW)
4-M2 Depth 1/8in (3 mm) or less
CN803 (LANC)
11/32 (8)
1/8(3)
21/32
(16±0.3)
1 1/4(31.5±0.3)
21/32
(1 6.3±0.3)19/32
(14.9)
11/16
(17.4)2 1/2(61.1)
Front
Top
2 3/4(67.2)
2 1/2(61.1)
1/4( 6.1)
7/32 (5) CN602 (Y/C)
Right
Left
Rear
Bottom
Front
Top
Right
Left
Bottom
Rear
ø23.5
21/32 (16.5)
1 7/16 (35.9)
1 5/8(40.8)
25/32 (19.8)
1 7/16 (36)
1 15/16 (48.3)
7/8(3.1)
3/8(9.1)
13/16 (20)
13/32 (10)
4-M2
Depth of 1/8in (3 mm) or less
2 3/8(59.2)
CN401
CN402
6-M2
Depth of 1/8in (3 mm) or less
Depth of 1/8in (3 mm) or less
1 1/8(27)
9/16 (14)
2 (50.3)
9/32 (7.1) 13/16 (20)
19/32 (15)
1/8(2.7)
1/4-20 UNC
(Tripod screw hole for camera)
ø5
Front
Top
Right
Left
Bottom
Rear
ø23.5
21/32 (16.5)
1 7/16 (35.9)
1 5/8(40.8)
25/32 (19.8)
1 7/16 (36)
1 15/16 (48.3)
7/8(3.1)
3/8(9.1)
13/16 (20)
13/32 (10)
4-M2
Depth of 1/8in (3 mm) or less
2 3/8(59.2)
CN401
CN402
6-M2
Depth of 1/8in (3 mm) or less
Depth of 1/8in (3 mm) or less
1 1/8(27)
9/16 (14)
2 (50.3)
9/32 (7.1) 13/16 (20)
19/32 (15)
1/8(2.7)
1/4-20 UNC
(Tripod screw hole for camera)
ø5
FCB-EX20D/FCB-EX20DP
FCB - E X11D/FCB - E X11D P
Unit: inches (mm)
Unit: inches (mm)
SONY57676_FCX-EX.indd 8 7/29/11 9:39 AM

9
Front
Top
Right
Left
Bottom
Rear
2- ø3 Hole
Depth of 1/8in (2.5 mm) or less 4-M2
Depth of 1/8in (3 mm) or less
1 3/4(43.5±0.3)
15/32 (11.5)
11/32 (8.5±0.3)
3/4(18.5±0.3)
9/32 (7±0.3)
1/21
(2±0.3)
1/2
(12±0.3)
11/32 (8.6)
3/8(9)
CN601 30P
CN501 9P
4-M2
Depth of 1/8in (3 mm) or less
2 7/8(71.8)
5/32 (3.25)
1 7/8(47±0.3)
23/32 (18)
11/32 (8.5)
19/32 (15±0.3)
1 3/16 (28.9±0.3)
5/16 (7.5±0.3)
21/32 (15.9)
3/4(19±0.3)
7/16 (10.88)
3-M2
Depth of 1/8in (3 mm) or less
ø25.2
27/32 (21.4)
15/16 (23.4)
1 13/16 (44.8)
1 7/8(46.9)
27/32 (21) 1 1/16 (25.9)
Front
Top
Right
Left
Bottom
Rear
2- ø3 Hole
Depth of 1/8in (2.5 mm) or less 4-M2
Depth of 1/8in (3 mm) or less
1 3/4(43.5±0.3)
15/32 (11.5)
11/32 (8.5±0.3)
3/4(18.5±0.3)
9/32 (7±0.3)
1/21
(2±0.3)
1/2
(12±0.3)
11/32 (8.6)
3/8(9)
CN601 30P
CN501 9P
4-M2
Depth of 1/8in (3 mm) or less
2 7/8(71.8)
5/32 (3.25)
1 7/8(47±0.3)
23/32 (18)
11/32 (8.5)
19/32 (15±0.3)
1 3/16 (28.9±0.3)
5/16 (7.5±0.3)
21/32 (15.9)
3/4(19±0.3)
7/16 (10.88)
3-M2
Depth of 1/8in (3 mm) or less
ø25.2
27/32 (21.4)
15/16 (23.4)
1 13/16 (44.8)
1 7/8(46.9)
27/32 (21) 1 1/16 (25.9)
FCB-EX15E/FCB-EX15EP/FCB-EX12E/FCB-EX12EP
Unit: inches (mm)
SONY57676_FCX-EX.indd 9 7/29/11 9:39 AM

1010
SPECIFICATIONS
FCB-EX1020 FCB-EX1020P FCB-EX995E FCB-EX995EP FCB-EX985E FCB-EX985EP FCB-EX490E FCB-EX490EP FCB-EX48E FCB-EX48EP FCB-EX15E FCB-EX15EP FCB-EX12E FCB-EX12EP FCB-EX20D FCB-EX20DP FCB-EX11D FCB-EX11DP
Camera
Signal systems NTSC PAL NTSC PAL NTSC PAL NTSC PAL NTSC PAL NTSC PAL NTSC PAL NTSC PAL NTSC PAL
Image sensor 1/4-type EXview HAD CCD™ (Progressive Scan) 1/4-type Super HAD CCD II™
(Interlace Scan)
1/4-type EXview HAD CCD™
(Progressive Scan)
1/4-type CCD (Interlace Scan) 1/4-type EXview HAD CCD™
(Progressive Scan)
1/4-type CCD (Interlace Scan) 1/3-type Super HAD CCD II™
(Interlace Scan)
1/4-type EXview HAD CCD™
(Interlace Scan)
Effective number of pixels 380,000 pixels 440,000 pixels 380,000 pixels 440,000 pixels 380,000 pixels 440,000 pixels 380,000 pixels 440,000 pixels 380,000 pixels 440,000 pixels 380,000 pixels 440,000 pixels 380,000 pixels 440,000 pixels 380,000 pixels 440,000 pixels 380,000 pixels 440,000 pixels
Lens 36x optical zoom lens
f=3.4 mm (wide) to 122.4 mm (tele)
F1.6 to F4.5
28x optical zoom lens
f=3.5 mm (wide) to 98.0 mm (tele)
F1.35 to F3.7
18x optical zoom lens
f=4.1 mm (wide) to 73.8 mm (tele)
F1.4 to F3.0
18x optical zoom lens
f=4.1 mm (wide) to 73.8 mm (tele)
F1.4 to F3.0
12x optical zoom
f=3.7 mm (wide) to 44.4 mm (tele)
F1.6 to F2.5
12x optical zoom
f=3.7 mm (wide) to 44.4 mm (tele)
F1.6 to F2.5
10x optical zoom lens
f = 5.1 mm (wide) to 51.0 mm (tele)
F1.8 to F2.1
10x optical zoom lens
f = 4.2 mm (wide) to 42.0 mm (tele)
F1.8 to F2.9
Digital zoom 12 x (432x with optical zoom) 12 x (336x with optical zoom) 12 x (216x with optical zoom) 12 x (216x with optical zoom) 12x (144x with optical zoom) 12x (144x with optical zoom) 12x (120x with optical zoom) 12x (120x with optical zoom)
Angle of view (H) 57.8 degrees (wide) to 1.7 degrees
(tele)
55.8 degrees (wide) to 2.1 degrees (tele) 48.0 degrees (wide) to 2.8 degrees (tele) 48.0 degrees (wide) to 2.8 degrees (tele) 53.6° (wide end) to 4.6 ° (tele end) 53.6° (wide end) to 4.6 ° (tele end) 52.0 degrees (wide) to 5.4 degrees (tele) 46.0 degrees (wide) to 4.6 degrees (tele)
Minimum object distance 10 mm (wide) to 1,500 mm (tele),
*Default:320 mm
10 mm (wide) to 1,500 mm (tele)
*Default:300 mm
10 mm (wide) to 800 mm (tele),
*Default:290 mm
10 mm (wide) to 800 mm (tele),
*Default:290 mm
300 mm (wide) ~ 1,000 mm (tele) 300 mm (wide) ~ 1,000 mm (tele) 10 mm (wide) to 800 mm (tele),
*Default:150 mm
10 mm (wide) to 800 mm (tele),
*Default:200 mm
Sync system Internal/External (V-lock) Internal / External (V-lock)
Minimum illumination (50IRE) 1.4 lx (F1.6,50IRE) 0.65 lx (F1.35,50IRE) 0.25 lx (F1.35,50IRE) 0.7 lx (F1.4,50IRE) 0.4 lx (F1.4,50IRE) 0.95 lx (F1.6,ICR off)
0.02 lx (F1.6,ICR on)
0.6 lx (F1.6,ICR off)
0.01 lx (F1.6,ICR on)
1/60 s,1/50 s mode: 0.25 lx (typical)
(F1.8,50IRE)
1/4 s,1/3 s mode: 0.015 lx (typical)
(F1.8,50IRE)
1/4 s,1/3 s mode& ICR On: 0.0004 lx
(typical) (F1.8,50IRE)
1.0 lx (typcal) (F1.8,50IRE)
Recommended illumination 100 lx to 100,000 lx 100 lx to 100,000 lx
S/N ratio More than 50 dB More than 50 dB
Video output Analog VBS:1.0 Vp-p (sync negative),Y/C VBS:1.0 Vp-p (sync negative),Y/C VBS:1.0 Vp-p (sync negative) VBS: 1.0 Vp-p (sync negative),Y/C VBS:1.0 Vp-p (sync negative),Y/C
Digital Y/Cb/Cr 4:2:2 (comparable to ITU-R BT656) Y/Cb/Cr 4:2:2 (comparable to ITU-R BT656) Y/Cb/Cr 4:2:2 via LVDS (comparable to ITU-R BT656)
Camera control interface VISCA (CMOS 5 V level)
Baud rate:9.6 kbps, 19.2 kbps,38.4 kbps
Stop bit:1 bit
VISCA (CMOS 5 V level)
Baud rate:9.6 kbps, 19.2 kbps,38.4 kbps
Stop bit:1 bit
Electronic shutter speed 1/1 sec to 1/10,000 sec,22 steps 1/1 sec to 1/10,000 sec,22 steps
White balance Auto,ATW,Indoor,Outdoor,Outdoor Auto,Sodium Vapor Lamp (fix/auto),One-push,Manual Auto,ATW,Indoor,Outdoor,Outdoor Auto,
Sodium Vapor Lamp (fix/auto), One-push,
Manual
Auto,ATW,Indoor,Outdoor,Outdoor Auto,
Sodium Vapor Lamp (Fix/Auto),One-push,Manual
Auto,ATW,Indoor,Outdoor,One-push,
Manual
Auto,ATW,Indoor,Outdoor,One-push,
Manual
Gain Auto/Manual/Max.Gain Limit (-3 dB to +28 dB,2 dB steps) Auto/Manual (-3 dB to +28 dB,+2 dB step/total 16 steps)
Max.Gain Limit (+6 dB to +28 dB,+2 dB step/total 12 stpes)
Auto/Manual (-3 dB to +28 dB,2 dB steps) Auto/Manual (-3 dB to +28 dB,2 dB steps)
AE control Auto, Manual, Priority mode (shutter priority & iris priority),Bright, EV compensation, Slow AE Auto, Manual, Priority mode (shutter priority & iris priority),Bright, EV compensation, Slow AE
Focusing system Auto (Sensitivity:normal, low),One-push AF, Manual, Infinity,
Interval AF,ZoomTrigger AF,Focus Compensation in ICR On Mode
Auto (Sensitivity:normal, low),
One-push AF, Manual,Infinity,
Interval AF,Zoom Trigger AF,Focus
Compensation in ICR On Mode
Auto (Sensitivity:normal,low),One-push AF,Manual,Infinity
Interval AF,ZoomTrigger AF,Focus compensation in ICR on
Auto (Sensitivity:normal, low),
One-push AF, Manual,Infinity,
Interval AF,Zoom Trigger AF
Auto (Sensitivity:normal, low),
One-push AF, Manual,Infinity,
Interval AF,Zoom Trigger AF
EV compensation Yes Yes
Backlight compensation Yes Yes
Aperture control 16 steps 16 steps
Preset 6 positions 6 positions
Camera Features
Wide-D (*) Auto mode Yes No Yes No Yes No
Wide-D IS/PS mode Yes No Yes No Yes No
Image stabilization Yes No No
StableZoom Yes (43x) Yes (33x) No No
Digital output Yes Yes No
Enhanced noise reduction Yes Yes No
Auto ICR Yes No Yes No
Spherical privacy zone masking Yes Yes
Motion detection Yes Yes
Alarm Yes Yes No
Slow AE response Yes (Longer than 10 minutes) Yes (Longer than 10 minutes) Yes (Longer than 10 minutes) Yes (Up to 32 times)
Picture effects Yes (E-Flip,Nega Art,Black & White,Mirror image,Color Enhancement) Yes (E-Flip,Nega Art,Black & White,
Mirror image,Color Enhancement)
Yes (E-Flip,Nega Art,Black & White,Mirror image,Color enhancement) Yes (E-Flip,Nega Art,Black & White, Mirror,Image)
Picture freeze Yes Yes
Slow shutter Yes Yes
Temperature readout Yes Yes No
Title display Yes (20 characters/line,max.11 lines) Yes (20 characters/line,max.11 lines)
Camera mode display Yes (English*/Chinese) *default Yes (English*/Chinese) *default
Key switch control Yes Yes No Yes No
Multi-line OSD Yes Yes
Flicker cancel Yes (Auto) - Yes (Auto) - Yes (Auto) - Yes (Auto) - Yes (Auto) - Yes (Auto) - Yes (Auto) - Yes (Auto) - Yes (Auto) -
General
Storage temperature -4˚F to 140˚F (-20°C to +60°C) -4˚F to 140˚F (-20°C to +60°C)
Storage humidity 20% to 95% 20% to 95%
Operating temperature 23˚F to 140˚F (-5°C to +60°C) 23˚F to 140˚F (-5°C to +60°C) 32˚F to 122˚F (0°C to +50°C)
Operating humidity 20% to 80% 20% to 80%
Power requirements DC 6.0 V to 12.0 V DC 6.0 V to 12.0 V 6.0 V to 12.0 V DC DC 6.0 V to 12.0 V
Power consumption 2.4 W (motors active:5.1 W) 2.6 W (motors active:5.0 W) 2.2 W (motors active:4.6 W) 2.4 W (motors active:4.4 W) 2.0 W (motors active: 3.1 W) 2.4 W (zoom/focus inactive) /
3.6 W (zoom/focus active)
1.9 W (zoom/focus inactive) /
3.2 W (zoom/focus active)
2.8 W (motors active:6.5 W) 1.9 W (motors active:2.8 W)
Weight 8.1 oz (230 g) 8.4 oz (238 g) 8.1 oz (230 g) 8.1 oz (230 g) 5.3 oz (150 g) 5 oz (140 g) 3.3 oz (95 g)
Dimensions (W x H x D) 2 x 2 3/8 x 3 1/2 inches
(50.0 x 57.5 x 87.9 mm)
2 x 2 3/8 x 3 5/8 inches
(50.0 x 57.5 x 89.8 mm)
2 x 2 3/8 x 3 1/2 inches
(50.0 x 57.5 x 88.5 mm)
2 x 2 3/8 x 3 1/2 inches
(50.0 x 57.5 x 88.5 mm)
1 13/16 x 1 7/8 x 2 7/8 inches
(44.8 x 46.9 x 71.8 mm)
1 13/16 x 1 3/4 x 2 3/4 inches
(45.9 x 43.1 x 67.2 mm)
1 7/16 x 1 5/8 x 2 3/8 inches
(35.9 x 40.8 x 59.2 mm)
* Wide dynamic range
SONY57676_FCX-EX.indd 10 7/29/11 9:39 AM

1111
FCB-EX1020 FCB-EX1020P FCB-EX995E FCB-EX995EP FCB-EX985E FCB-EX985EP FCB-EX490E FCB-EX490EP FCB-EX48E FCB-EX48EP FCB-EX15E FCB-EX15EP FCB-EX12E FCB-EX12EP FCB-EX20D FCB-EX20DP FCB-EX11D FCB-EX11DP
Camera
Signal systems NTSC PAL NTSC PAL NTSC PAL NTSC PAL NTSC PAL NTSC PAL NTSC PAL NTSC PAL NTSC PAL
Image sensor 1/4-type EXview HAD CCD™ (Progressive Scan) 1/4-type Super HAD CCD II™
(Interlace Scan)
1/4-type EXview HAD CCD™
(Progressive Scan)
1/4-type CCD (Interlace Scan) 1/4-type EXview HAD CCD™
(Progressive Scan)
1/4-type CCD (Interlace Scan) 1/3-type Super HAD CCD II™
(Interlace Scan)
1/4-type EXview HAD CCD™
(Interlace Scan)
Effective number of pixels 380,000 pixels 440,000 pixels 380,000 pixels 440,000 pixels 380,000 pixels 440,000 pixels 380,000 pixels 440,000 pixels 380,000 pixels 440,000 pixels 380,000 pixels 440,000 pixels 380,000 pixels 440,000 pixels 380,000 pixels 440,000 pixels 380,000 pixels 440,000 pixels
Lens 36x optical zoom lens
f=3.4 mm (wide) to 122.4 mm (tele)
F1.6 to F4.5
28x optical zoom lens
f=3.5 mm (wide) to 98.0 mm (tele)
F1.35 to F3.7
18x optical zoom lens
f=4.1 mm (wide) to 73.8 mm (tele)
F1.4 to F3.0
18x optical zoom lens
f=4.1 mm (wide) to 73.8 mm (tele)
F1.4 to F3.0
12x optical zoom
f=3.7 mm (wide) to 44.4 mm (tele)
F1.6 to F2.5
12x optical zoom
f=3.7 mm (wide) to 44.4 mm (tele)
F1.6 to F2.5
10x optical zoom lens
f = 5.1 mm (wide) to 51.0 mm (tele)
F1.8 to F2.1
10x optical zoom lens
f = 4.2 mm (wide) to 42.0 mm (tele)
F1.8 to F2.9
Digital zoom 12 x (432x with optical zoom) 12 x (336x with optical zoom) 12 x (216x with optical zoom) 12 x (216x with optical zoom) 12x (144x with optical zoom) 12x (144x with optical zoom) 12x (120x with optical zoom) 12x (120x with optical zoom)
Angle of view (H) 57.8 degrees (wide) to 1.7 degrees
(tele)
55.8 degrees (wide) to 2.1 degrees (tele) 48.0 degrees (wide) to 2.8 degrees (tele) 48.0 degrees (wide) to 2.8 degrees (tele) 53.6° (wide end) to 4.6 ° (tele end) 53.6° (wide end) to 4.6 ° (tele end) 52.0 degrees (wide) to 5.4 degrees (tele) 46.0 degrees (wide) to 4.6 degrees (tele)
Minimum object distance 10 mm (wide) to 1,500 mm (tele),
*Default:320 mm
10 mm (wide) to 1,500 mm (tele)
*Default:300 mm
10 mm (wide) to 800 mm (tele),
*Default:290 mm
10 mm (wide) to 800 mm (tele),
*Default:290 mm
300 mm (wide) ~ 1,000 mm (tele) 300 mm (wide) ~ 1,000 mm (tele) 10 mm (wide) to 800 mm (tele),
*Default:150 mm
10 mm (wide) to 800 mm (tele),
*Default:200 mm
Sync system Internal/External (V-lock) Internal / External (V-lock)
Minimum illumination (50IRE) 1.4 lx (F1.6,50IRE) 0.65 lx (F1.35,50IRE) 0.25 lx (F1.35,50IRE) 0.7 lx (F1.4,50IRE) 0.4 lx (F1.4,50IRE) 0.95 lx (F1.6,ICR off)
0.02 lx (F1.6,ICR on)
0.6 lx (F1.6,ICR off)
0.01 lx (F1.6,ICR on)
1/60 s,1/50 s mode: 0.25 lx (typical)
(F1.8,50IRE)
1/4 s,1/3 s mode: 0.015 lx (typical)
(F1.8,50IRE)
1/4 s,1/3 s mode& ICR On: 0.0004 lx
(typical) (F1.8,50IRE)
1.0 lx (typcal) (F1.8,50IRE)
Recommended illumination 100 lx to 100,000 lx 100 lx to 100,000 lx
S/N ratio More than 50 dB More than 50 dB
Video output Analog VBS:1.0 Vp-p (sync negative),Y/C VBS:1.0 Vp-p (sync negative),Y/C VBS:1.0 Vp-p (sync negative) VBS: 1.0 Vp-p (sync negative),Y/C VBS:1.0 Vp-p (sync negative),Y/C
Digital Y/Cb/Cr 4:2:2 (comparable to ITU-R BT656) Y/Cb/Cr 4:2:2 (comparable to ITU-R BT656) Y/Cb/Cr 4:2:2 via LVDS (comparable to ITU-R BT656)
Camera control interface VISCA (CMOS 5 V level)
Baud rate:9.6 kbps, 19.2 kbps,38.4 kbps
Stop bit:1 bit
VISCA (CMOS 5 V level)
Baud rate:9.6 kbps, 19.2 kbps,38.4 kbps
Stop bit:1 bit
Electronic shutter speed 1/1 sec to 1/10,000 sec,22 steps 1/1 sec to 1/10,000 sec,22 steps
White balance Auto,ATW,Indoor,Outdoor,Outdoor Auto,Sodium Vapor Lamp (fix/auto),One-push,Manual Auto,ATW,Indoor,Outdoor,Outdoor Auto,
Sodium Vapor Lamp (fix/auto), One-push,
Manual
Auto,ATW,Indoor,Outdoor,Outdoor Auto,
Sodium Vapor Lamp (Fix/Auto),One-push,Manual
Auto,ATW,Indoor,Outdoor,One-push,
Manual
Auto,ATW,Indoor,Outdoor,One-push,
Manual
Gain Auto/Manual/Max.Gain Limit (-3 dB to +28 dB,2 dB steps) Auto/Manual (-3 dB to +28 dB,+2 dB step/total 16 steps)
Max.Gain Limit (+6 dB to +28 dB,+2 dB step/total 12 stpes)
Auto/Manual (-3 dB to +28 dB,2 dB steps) Auto/Manual (-3 dB to +28 dB,2 dB steps)
AE control Auto, Manual, Priority mode (shutter priority & iris priority),Bright, EV compensation, Slow AE Auto, Manual, Priority mode (shutter priority & iris priority),Bright, EV compensation, Slow AE
Focusing system Auto (Sensitivity:normal, low),One-push AF, Manual, Infinity,
Interval AF,ZoomTrigger AF,Focus Compensation in ICR On Mode
Auto (Sensitivity:normal, low),
One-push AF, Manual,Infinity,
Interval AF,Zoom Trigger AF,Focus
Compensation in ICR On Mode
Auto (Sensitivity:normal,low),One-push AF,Manual,Infinity
Interval AF,ZoomTrigger AF,Focus compensation in ICR on
Auto (Sensitivity:normal, low),
One-push AF, Manual,Infinity,
Interval AF,Zoom Trigger AF
Auto (Sensitivity:normal, low),
One-push AF, Manual,Infinity,
Interval AF,Zoom Trigger AF
EV compensation Yes Yes
Backlight compensation Yes Yes
Aperture control 16 steps 16 steps
Preset 6 positions 6 positions
Camera Features
Wide-D (*) Auto mode Yes No Yes No Yes No
Wide-D IS/PS mode Yes No Yes No Yes No
Image stabilization Yes No No
StableZoom Yes (43x) Yes (33x) No No
Digital output Yes Yes No
Enhanced noise reduction Yes Yes No
Auto ICR Yes No Yes No
Spherical privacy zone masking Yes Yes
Motion detection Yes Yes
Alarm Yes Yes No
Slow AE response Yes (Longer than 10 minutes) Yes (Longer than 10 minutes) Yes (Longer than 10 minutes) Yes (Up to 32 times)
Picture effects Yes (E-Flip,Nega Art,Black & White,Mirror image,Color Enhancement) Yes (E-Flip,Nega Art,Black & White,
Mirror image,Color Enhancement)
Yes (E-Flip,Nega Art,Black & White,Mirror image,Color enhancement) Yes (E-Flip,Nega Art,Black & White, Mirror,Image)
Picture freeze Yes Yes
Slow shutter Yes Yes
Temperature readout Yes Yes No
Title display Yes (20 characters/line,max.11 lines) Yes (20 characters/line,max.11 lines)
Camera mode display Yes (English*/Chinese) *default Yes (English*/Chinese) *default
Key switch control Yes Yes No Yes No
Multi-line OSD Yes Yes
Flicker cancel Yes (Auto) - Yes (Auto) - Yes (Auto) - Yes (Auto) - Yes (Auto) - Yes (Auto) - Yes (Auto) - Yes (Auto) - Yes (Auto) -
General
Storage temperature -4˚F to 140˚F (-20°C to +60°C) -4˚F to 140˚F (-20°C to +60°C)
Storage humidity 20% to 95% 20% to 95%
Operating temperature 23˚F to 140˚F (-5°C to +60°C) 23˚F to 140˚F (-5°C to +60°C) 32˚F to 122˚F (0°C to +50°C)
Operating humidity 20% to 80% 20% to 80%
Power requirements DC 6.0 V to 12.0 V DC 6.0 V to 12.0 V 6.0 V to 12.0 V DC DC 6.0 V to 12.0 V
Power consumption 2.4 W (motors active:5.1 W) 2.6 W (motors active:5.0 W) 2.2 W (motors active:4.6 W) 2.4 W (motors active:4.4 W) 2.0 W (motors active: 3.1 W) 2.4 W (zoom/focus inactive) /
3.6 W (zoom/focus active)
1.9 W (zoom/focus inactive) /
3.2 W (zoom/focus active)
2.8 W (motors active:6.5 W) 1.9 W (motors active:2.8 W)
Weight 8.1 oz (230 g) 8.4 oz (238 g) 8.1 oz (230 g) 8.1 oz (230 g) 5.3 oz (150 g) 5 oz (140 g) 3.3 oz (95 g)
Dimensions (W x H x D) 2 x 2 3/8 x 3 1/2 inches
(50.0 x 57.5 x 87.9 mm)
2 x 2 3/8 x 3 5/8 inches
(50.0 x 57.5 x 89.8 mm)
2 x 2 3/8 x 3 1/2 inches
(50.0 x 57.5 x 88.5 mm)
2 x 2 3/8 x 3 1/2 inches
(50.0 x 57.5 x 88.5 mm)
1 13/16 x 1 7/8 x 2 7/8 inches
(44.8 x 46.9 x 71.8 mm)
1 13/16 x 1 3/4 x 2 3/4 inches
(45.9 x 43.1 x 67.2 mm)
1 7/16 x 1 5/8 x 2 3/8 inches
(35.9 x 40.8 x 59.2 mm)
* Wide dynamic range
SONY57676_FCX-EX.indd 11 7/29/11 9:39 AM

Sony Electronics Inc.
1 Sony Drive
Park Ridge, NJ 07656
www.sony.com/videocameras
IS-1232-B (MK10535V2)
© 2011 Sony Corporation.All rights reserved.
Reproduction in whole or in part without written permissions is prohibited.
Features and specifications are subject to change without notice.
The values for weight and dimension are approximate.
SONY, make.believe,EXview HAD CCD, and Super HAD are trademarks of Sony Corporation.
Printed in USA (8/11)
SONY57676_FCX-EX.indd 12 7/29/11 9:39 AM
