Sony Handycam HDR-CX250 User manual
SERVICE MANUAL
HDR-CX250/CX250E/CX260E/CX260V/CX260VE/CX270E/CX270V_L3
Check the SERVICE NOTE (LEVEL 2) before the service.
Revision History
Published by Sony Techno Create Corporation
Sony Corporation
LEVEL 3
983463511.pdf
Ver. 1.0 2011.12
Digital HD Video Camera Recorder
The components identified by mark
0or dotted line with mark 0are
critical for safety.
Replace only with part number
specified.
Les composants identifiés par une
marque 0sont critiques pour la
sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
9-834-635-11
US Model
Canadian Model
AEP Model
UK Model
North European Model
E Model
Australian Model
Hong Kong Model
Chinese Model
Korea Model
Japanese Model
Ver. Date History Contents S.M. Rev.
issued
1.0 2011.12 Official Release — —
2011L08-1
© 2011.12
HDR-CX250/CX250E/CX260E/CX260V/
CX260VE/CX270E/CX270V
Photo: HDR-CX250/Black
MODEL GROUP
IM Model (Internal Memory Model): CX260E/CX260V/CX260VE/CX270E/CX270V
Non IM Model (Non Internal Memory Model): CX250/CX250E
GPS Model: CX260V/CX260VE/CX270V
Non GPS Model: CX250/CX250E/CX260E/CX270E
– 2 –
HDR-CX250/CX250E/CX260E/CX260V/CX260VE/CX270E/CX270V_L3
SAFETY-RELATED COMPONENT WARNING!!
COMPONENTS IDENTIFIED BY MARK 0OR DOTTED LINE WITH
MARK 0ON THE SCHEMATIC DIAGRAMS AND IN THE PARTS LIST
ARE CRITICAL TO SAFE OPERATION. REPLACE THESE COMPO-
NENTS WITH SONY PARTS WHOSE PART NUMBERS APPEAR AS
SHOWN IN THIS MANUAL OR IN SUPPLEMENTS PUBLISHED BY
SONY.
ATTENTION AU COMPOSANT AYANT RAPPORT
À LA SÉCURITÉ!
LES COMPOSANTS IDENTIFIÉS PAR UNE MARQUE 0SUR LES
DIAGRAMMES SCHÉMATIQUES ET LA LISTE DES PIÈCES SONT
CRITIQUES POUR LA SÉCURITÉ DE FONCTIONNEMENT. NE REM-
PLACER CES COMPOSANTS QUE PAR DES PIÈCES SONY DONT
LES NUMÉROS SONT DONNÉS DANS CE MANUEL OU DANS LES
SUPPLÉMENTS PUBLIÉS PAR SONY.
Caution
Danger of explosion if battery is incorrectly replaced.
Replace only with the same or equivalent type.
Dispose of used batteries according to the instructions.
注意
電池の交換は，正しく行わないと破裂する恐れがあります。
電池を交換する場合には必ず同じ型名の電池又は同等品と
交換してください。
使用済み電池は，取扱指示に従って処分してください。
SAFETY CHECK-OUT
After correcting the original service problem, perform the following
safety checks before releasing the set to the customer.
1. Check the area of your repair for unsoldered or poorly-soldered
connections. Check the entire board surface for solder splashes and
bridges.
2. Check the interboard wiring to ensure that no wires are “pinched”
or contact high-wattage resistors.
3. Look for unauthorized replacement parts, particularly transistors,
that were installed during a previous repair. Point them out to the
customer and recommend their replacement.
4. Look for parts which, through functioning, show obvious signs of
deterioration. Point them out to the customer and recommend their
replacement.
5. Check the B+ voltage to see it is at the values specified.
6. Flexible Circuit Board Repairing
• Set the soldering iron tip temperature to 350 °C approximately.
• Do not touch the soldering iron on the same conductor of the circuit
board (within 3 times).
• Be careful not to apply force on the conductor when soldering or
unsoldering.
1. 注意事項をお守りください。
サービスのとき特に注意を要する個所については，キャビ
ネット，シャーシ，部品などにラベルや捺印で注意事項を
表示しています。これらの注意書き及び取扱説明書等の注
意事項を必ずお守り下さい。
2. 指定部品のご使用を
セットの部品は難燃性や耐電圧など安全上の特性を持った
ものとなっています。従って交換部品は，使用されていた
ものと同じ特性の部品を使用して下さい。特に回路図，部
品表に0印で指定されている安全上重要な部品は必ず指定
のものをご使用下さい。
3. 部品の取付けや配線の引きまわしはもとどおりに
安全上，チューブやテープなどの絶縁材料を使用したり，
プリント基板から浮かして取付けた部品があります。また
内部配線は引きまわしやクランパによって発熱部品や高圧
部品に接近しないよう配慮されていますので，これらは必
ずもとどおりにして下さい。
4. サービス後は安全点検を
サービスのために取外したネジ，部品，配線がもとどおり
になっているか，またサービスした個所の周辺を劣化させ
てしまったところがないかなどを点検し，安全性が確保さ
れていることを確認して下さい。
5. チップ部品交換時の注意
・ 取外した部品は再使用しないで下さい。
・ タンタルコンデンサのマイナス側は熱に弱いため交換時
は注意して下さい。
6. フレキシブルプリント基板の取扱いについて
・ 半田こてのこて先温度は約350℃に設定してください。
・ 同一パターンに何度もコテ先を当てないで下さい。（3回
以内）
・ パターンに力が加わらないよう注意して下さい。
サービス，点検時には次のことにご注意ください。
– ENGLISH – – JAPANESE –
UNLEADED SOLDER
This unit uses unleaded solder.
Boards requiring use of unleaded solder are printed with the lead free
mark (LF) indicating the solder contains no lead.
(Caution: Some printed circuit boards may not come printed with the
lead free mark due to their particular size.)
: LEAD FREE MARK
Be careful to the following points to solder or unsolder.
• Set the soldering iron tip temperature to 350 °C approximately.
If cannot control temperature, solder/unsolder at high temperature
for a short time.
Caution: The printed pattern (copper foil) may peel away if the
heated tip is applied for too long, so be careful!
Unleaded solder is more viscous (sticky, less prone to
flow) than ordinary solder so use caution not to let solder
bridges occur such as on IC pins, etc.
• Be sure to control soldering iron tips used for unleaded solder and
those for leaded solder so they are managed separately. Mixing un-
leaded solder and leaded solder will cause detachment phenomenon.
無鉛半田について
本機には無鉛半田が使用されています。
無鉛半田を使用している基板には，無鉛（LeadFree）を意味する
レッドフリーマークがプリントされています。
（注意：基板サイズによっては，無鉛半田を使用していてもレッ
ドフリーマークがプリントされていないものがありま
す）
：レッドフリーマーク
無鉛半田は，下記の点に注意して使用してください。
・ 半田こてのこて先温度は約350℃に設定してください。
温度調節が無理な場合は，高温短時間で作業を行ってくだ
さい。
注意：半田こてを長く当てすぎると，基板のパターン（銅
箔）がはがれてしまうことがありますので，注意して
ください。また，従来の半田よりも粘性が強いため，
IC端子などが半田ブリッジしないように注意してく
ださい。
・ 半田こてのこて先は，必ず無鉛半田用と有鉛半田用に分け
て管理してください。
無鉛半田と有鉛半田が混在すると剥離現象が発生してしま
います。
HDR-CX250/CX250E/CX260E/CX260V/CX260VE/CX270E/CX270V_L3
2-1
Ref. No. Part No. DescriptionRef. No. Part No. Description
(ENGLISH)
NOTE:
• -XX, -X mean standardized parts, so they may have some differ-
ences from the original one.
• Items marked “*” are not stocked since they are seldom required for
routine service. Some delay should be anticipated when ordering
these items.
• The mechanical parts with no reference number in the exploded
views are not supplied.
• Due to standardization, replacements in the parts list may be dif-
ferent from the parts specified in the diagrams or the components
used on the set.
• CAPACITORS:
uF: μF
• COILS
uH: μH
• RESISTORS
All resistors are in ohms.
METAL: metal-film resistor
METAL OXIDE: Metal Oxide-film resistor
F: nonflammable
• SEMICONDUCTORS
In each case, u: μ, for example:
uA...: μA... , uPA... , μPA... ,
uPB... , μPB... , uPC... , μPC... ,
uPD..., μPD...
(JAPANESE)
【使用上の注意】
• ここに記載されている部品は,補修用部品であるため,回路図及び
セットに付いている部品と異なる場合があります。
• -XX,-Xは標準化部品のため, セットに付いている部品と異なる場
合があります。
• *印の部品は常備在庫しておりません。
• コンデンサの単位でuFはμFを示します。
• 抵抗の単位Ωは省略してあります。
金 被：金属被膜抵抗。
サンキン：酸化金属被膜抵抗。
• インダクタの単位でuHはμHを示します。
• 半導体の名称でuA...,uPA...,uPB...,uPC...,uPD...等はそれぞれμA...,
μPA...,μPB...,μPC...,μPD...を示します。
The components identified by mark 0
or dotted line with mark 0are critical
for safety.
Replace only with part number specified.
Les composants identifiés par une mar-
que 0sont critiques pour la sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
0印の部品，または0印付の点線で囲まれた部品は，
安全性を維持するために，重要な部品です。
従って交換時は，必ず指定の部品を使用してください。
When indicating parts by reference num-
ber, please include the board name.
図面番号で部品を指定するときは基板名又はブロック
を併せて指定してください。
お願い
A-1851-196-A CM-123 BOARD, COMPLETE
**********************
(CP001 (CMOS IMAGER) is not supplied, but this is included in CM-123 COMPLETE
BOARD.)
< CAPACITOR >
C6701 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C6703 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C6706 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C6707 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C6708 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C6709 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C6710 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C6711 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C6712 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
C6713 1-165-884-11 CERAMIC CHIP 2.2uF 10% 6.3V
C6714 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C6715 1-112-300-91 CERAMIC CHIP 4.7uF 10% 10V
C6716 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C6717 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C6718 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C6719 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C6728 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C6729 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C6743 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
C6746 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C6747 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C6749 1-112-746-11 CERAMIC CHIP 4.7uF 10% 6.3V
C6750 1-112-746-11 CERAMIC CHIP 4.7uF 10% 6.3V
C6751 1-112-746-11 CERAMIC CHIP 4.7uF 10% 6.3V
C6752 1-112-746-11 CERAMIC CHIP 4.7uF 10% 6.3V
< CONNECTOR >
CN6702 1-821-500-11 CONNECTOR, FPC (ZIF) 45P
< COMPOSITION CIRCUIT BLOCK >
CP001 (Not supplied) IMX116CHL-13
< IC >
IC6703 6-715-211-01 IC MM3404A28URE
< RESISTOR >
R6707 1-218-973-11 METAL CHIP 47K 5% 1/16W
R6708 1-218-953-11 METAL CHIP 1K 5% 1/16W
1-884-922-11 FP-1484 FLEXIBLE BOARD
********************
1-884-923-11 FP-1485 FLEXIBLE BOARD
********************
1-884-924-11 FP-1486 FLEXIBLE BOARD (IM Model)
********************
1-884-925-11 FP-1487 FLEXIBLE BOARD
*********************
(Not supplied) FP-1516 FLEXIBLE BOARD
*********************
A-1865-435-A GP375 ASSY (GPS Model)
(Not supplied) GP-037 BOARD, COMPLETE
**********************
(All mounted parts and GP-037 COMPLETE BOARD are not supplied, but they are
included in GP375 ASSY.)
A-1851-187-A JK-402 BOARD, COMPLETE
**********************
< CONNECTOR >
*CN1001 1-822-914-11 CONNECTOR, FPC (LIF (NON-ZIF))
CN1002 1-815-794-13 CONNECTOR (MULTIPLE)
< FERRITE BEAD >
FB1001 1-400-927-31 BEAD, FERRITE (1005)
FB1002 1-400-927-31 BEAD, FERRITE (1005)
FB1003 1-400-927-31 BEAD, FERRITE (1005)
FB1004 1-400-927-31 BEAD, FERRITE (1005)
< VARISTOR >
VD1001 1-802-090-21 VARISTOR, CHIP
VD1002 1-802-090-21 VARISTOR, CHIP
VD1003 1-802-090-21 VARISTOR, CHIP
A-1853-736-A MM-102 BOARD, COMPLETE (SERVICE)
(CX260E/CX260V/CX260VE)
A-1853-737-A MM-102 BOARD, COMPLETE (SERVICE)
(CX270E/CX270V)
*******************************
< CAPACITOR >
C8102 1-112-300-91 CERAMIC CHIP 4.7uF 10% 10V
C8103 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C8104 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C8701 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
< CONNECTOR >
*CN8101 1-816-647-61 FFC/FPC CONNECTOR (LIF) 18P
< FERRITE BEAD >
FB8701 1-481-250-11 INDUCTOR, FERRITE BEAD (1005)
FB8702 1-481-250-11 INDUCTOR, FERRITE BEAD (1005)
FB8703 1-481-250-11 INDUCTOR, FERRITE BEAD (1005)
FB8704 1-481-250-11 INDUCTOR, FERRITE BEAD (1005)
FB8705 1-481-250-11 INDUCTOR, FERRITE BEAD (1005)
FB8706 1-481-250-11 INDUCTOR, FERRITE BEAD (1005)
FB8707 1-481-250-11 INDUCTOR, FERRITE BEAD (1005)
FB8708 1-481-250-11 INDUCTOR, FERRITE BEAD (1005)
2-2. ELECTRICAL PARTS LIST
Note 1: イメージャの交換時は6-1ページの“イメージャ交換時の
注意”を必ずお読みください。
Caution
Danger of explosion if battery is incorrectly replaced.
Replace only with the same or equivalent type.
Dispose of used batteries according to the instructions.
注意
電池の交換は，正しく行わないと破裂する恐れがあります。
電池を交換する場合には必ず同じ型名の電池又は同等品と交換し
てください。
使用済み電池は，取扱指示に従って処分してください。
Note 2: Replace the battery holder (BH8001) together when replac-
ing the lithium storage battery (BT8001) on the MS-477
board. (The battery holder removed once cannot be used
again.)
When mounting these parts, mount new battery holder first
and attach new lithium battery next.
Note 2: MS-477基板のリチウム蓄電池（BT8001）を交換する場合は
バッテリホルダ（BH8001）も同時に新品に交換して下さい。
（一度使用したバッテリホルダは再使用できません。）
部品 取り付けの際は，先にバッテリホ ルダを取り付けて
からリチウム電池を装着して下さい。
Note 1: Be sure to read “Precautions for Replacement of Imager”
on page 6-1 when changing the imager.
CM-123 FP-1484 FP-1485 FP-1486 FP-1487 FP-1516 GP-037 JK-402 MM-102
HDR-CX250/CX250E/CX260E/CX260V/CX260VE/CX270E/CX270V_L3
2-2
Ref. No. Part No. Description Ref. No. Part No. Description Ref. No. Part No. DescriptionRef. No. Part No. Description
< IC >
IC8101 6-718-157-01 IC THGBM4G8D4GBAIE (CX270E/CX270V)
IC8101 6-718-204-01 IC THGBM4G7D2GBAIE
(CX260E/CX260V/CX260VE)
IC8701 6-716-442-11 IC MM3404A29URE
< RESISTOR >
R8101 1-218-965-11 METAL CHIP 10K 5% 1/16W
R8112 1-218-990-81 SHORT CHIP 0
< COMPOSITION CIRCUIT BLOCK >
RB8101 1-200-051-21 RES, NETWORK 150 (1005X4)
RB8102 1-200-051-21 RES, NETWORK 150 (1005X4)
A-1853-735-A MS-477 BOARD, COMPLETE (SERVICE)
*******************************
(BT8001 is not included in MS-477 COMPLETE BOARD SERVICE.)
< BATTERY HOLDER >
BH8001 1-251-928-21 HOLDER, BATTERY
< BATTERY >
BT8001 1-756-135-31 BATTERY LITHIUM SECONDARY
< CAPACITOR >
C7505 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C7506 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
C7507 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
C7508 1-114-411-21 CERAMIC CHIP 0.33uF 10% 6.3V
C7509 1-114-411-21 CERAMIC CHIP 0.33uF 10% 6.3V
C7512 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C7513 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C7514 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C7515 1-112-746-11 CERAMIC CHIP 4.7uF 10% 6.3V
C8001 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C8002 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
< CONNECTOR >
CN8001 1-822-837-21 CARD CONNECTOR
CN8002 1-821-500-11 CONNECTOR, FPC (ZIF) 45P
< DIODE >
D8001 6-501-216-01 DIODE CL-271HR-C-TS
< COIL >
*L7501 1-481-425-21 INDUCTOR 10uH
< RESISTOR >
R7508 1-250-553-11 METAL CHIP 270K 1% 1/16W
R7509 1-250-553-11 METAL CHIP 270K 1% 1/16W
*R7510 1-250-511-11 METAL CHIP 4.7K 1% 1/16W
*R7511 1-250-511-11 METAL CHIP 4.7K 1% 1/16W
R7512 1-250-519-11 METAL CHIP 10K 1% 1/16W
R7513 1-250-519-11 METAL CHIP 10K 1% 1/16W
*R7514 1-250-559-11 METAL CHIP 470K 1% 1/16W
*R7515 1-250-559-11 METAL CHIP 470K 1% 1/16W
R8048 1-218-937-11 METAL CHIP 47 5% 1/16W
R8049 1-218-937-11 METAL CHIP 47 5% 1/16W
R8050 1-218-937-11 METAL CHIP 47 5% 1/16W
R8051 1-218-937-11 METAL CHIP 47 5% 1/16W
R8052 1-220-169-11 METAL CHIP 75 5% 1/16W
R8053 1-220-169-11 METAL CHIP 75 5% 1/16W
R8054 1-220-169-11 METAL CHIP 75 5% 1/16W
R8055 1-220-169-11 METAL CHIP 75 5% 1/16W
< SWITCH >
S8002 1-798-119-11 SWITCH, TACTILE
S8003 1-798-119-11 SWITCH, TACTILE
S8005 1-798-119-11 SWITCH, TACTILE
< SENSOR>
SE7501 1-487-653-11 SENSOR, ANGULAR VELOCITY (PITCH/YAW)
A-1851-186-A PD-458 BOARD, COMPLETE
**********************
< CAPACITOR >
C6203 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C6205 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C6208 1-127-861-11 CERAMIC CHIP 2.2uF 10% 16V
C6209 1-125-889-11 CERAMIC CHIP 2.2uF 10% 10V
C6212 1-125-889-11 CERAMIC CHIP 2.2uF 10% 10V
C6214 1-125-889-11 CERAMIC CHIP 2.2uF 10% 10V
C6215 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C6220 1-100-591-91 CERAMIC CHIP 1uF 10% 25V
C6221 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C6222 1-100-591-91 CERAMIC CHIP 1uF 10% 25V
C6223 1-125-889-11 CERAMIC CHIP 2.2uF 10% 10V
C6224 1-100-591-91 CERAMIC CHIP 1uF 10% 25V
C6225 1-100-591-91 CERAMIC CHIP 1uF 10% 25V
C6226 1-100-581-81 CERAMIC CHIP 0.0047uF 10% 50V
C6227 1-100-581-81 CERAMIC CHIP 0.0047uF 10% 50V
C6242 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C6243 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C6244 1-164-856-81 CERAMIC CHIP 18PF 5% 50V
C6245 1-164-856-81 CERAMIC CHIP 18PF 5% 50V
C6246 1-164-856-81 CERAMIC CHIP 18PF 5% 50V
C6247 1-164-856-81 CERAMIC CHIP 18PF 5% 50V
< CONNECTOR >
*CN6201 1-821-503-11 CONNECTOR, FPC (ZIF) 39P
CN6202 1-821-857-51 CONNECTOR, FPC (LIF (NON-ZIF)) 6P
*CN6203 1-821-503-11 CONNECTOR, FPC (ZIF) 39P
CN6207 1-816-655-61 CONNECTOR, FFC/FPC 8P
< IC >
IC6201 6-715-211-01 IC MM3404A28URE
< COIL >
*L6201 1-481-102-21 INDUCTOR 10uH
< TRANSISTOR >
Q6202 6-552-538-01 TRANSISTOR DMG9640N0R
Q6203 6-552-538-01 TRANSISTOR DMG9640N0R
< RESISTOR >
R6218 1-218-977-11 METAL CHIP 100K 5% 1/16W
R6229 1-216-864-11 SHORT CHIP 0
R6236 1-216-864-11 SHORT CHIP 0
R6259 1-216-864-11 SHORT CHIP 0
R6260 1-218-990-81 SHORT CHIP 0
< COMPOSITION CIRCUIT BLOCK >
RB6204 1-234-375-21 RES, NETWORK 1K (1005X4)
< SENSOR >
*SE6201 1-487-118-11 GMR SENSOR
A-1853-734-A VC-652 BOARD, COMPLETE (SERVICE)
******************************
(FB1414, FB1415 and IC1301 are not supplied, but they are included in VC-652
COMPLETE BOARD (SERVICE).)
< CAPACITOR >
C1001 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C1006 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
C1012 1-100-567-81 CERAMIC CHIP 0.01uF 10% 25V
C1302 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C1303 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C1304 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C1305 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C1306 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C1307 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C1308 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C1309 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C1310 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C1313 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C1314 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C1315 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C1317 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C1318 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C1320 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C1321 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C1322 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C1323 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C1324 1-164-933-11 CERAMIC CHIP 220PF 10% 50V
C1325 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C1339 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C1340 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C1407 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C1409 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C1410 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C1411 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C1412 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C1413 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C1421 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C1422 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C1424 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C1428 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C1431 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C1433 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C1435 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C1437 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C1438 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C1439 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C1441 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C1446 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C1447 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C1503 1-112-746-11 CERAMIC CHIP 4.7uF 10% 6.3V
C1504 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C1505 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C1506 1-100-611-91 CERAMIC CHIP 22uF 20% 6.3V
C1507 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C1508 1-100-611-91 CERAMIC CHIP 22uF 20% 6.3V
C1509 1-100-611-91 CERAMIC CHIP 22uF 20% 6.3V
C1510 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C1512 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C1514 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C1515 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C1516 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C1517 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C1518 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
C1519 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
C1520 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
C1521 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C1522 1-100-611-91 CERAMIC CHIP 22uF 20% 6.3V
C1524 1-112-746-11 CERAMIC CHIP 4.7uF 10% 6.3V
C1526 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C1529 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C1530 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C2401 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C2402 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C2403 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C2404 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C2405 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C2406 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C2407 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C2408 1-112-746-11 CERAMIC CHIP 4.7uF 10% 6.3V
C2409 1-112-746-11 CERAMIC CHIP 4.7uF 10% 6.3V
C2410 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
C2411 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C2412 1-112-746-11 CERAMIC CHIP 4.7uF 10% 6.3V
C2413 1-112-746-11 CERAMIC CHIP 4.7uF 10% 6.3V
C2414 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
C2415 1-100-567-81 CERAMIC CHIP 0.01uF 10% 25V
C2416 1-100-567-81 CERAMIC CHIP 0.01uF 10% 25V
C2417 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C2418 1-164-935-11 CERAMIC CHIP 470PF 10% 50V
C2419 1-112-746-11 CERAMIC CHIP 4.7uF 10% 6.3V
C2420 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C2421 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C2422 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C2423 1-165-897-11 TANTAL. CHIP 22uF 20% 10V
C2424 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C2601 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C2603 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
MM-102 MS-477 PD-458 VC-652
HDR-CX250/CX250E/CX260E/CX260V/CX260VE/CX270E/CX270V_L3
2-3
Ref. No. Part No. Description Ref. No. Part No. Description Ref. No. Part No. DescriptionRef. No. Part No. Description
C2604 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C2605 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C2606 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C2607 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C2608 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
C2609 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C2610 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
C2611 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C2614 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C3001 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C3002 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C3003 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C4101 1-112-300-91 CERAMIC CHIP 4.7uF 10% 10V
C4102 1-112-300-91 CERAMIC CHIP 4.7uF 10% 10V
C4103 1-112-300-91 CERAMIC CHIP 4.7uF 10% 10V
C4301 1-125-889-11 CERAMIC CHIP 2.2uF 10% 10V
C4302 1-125-889-11 CERAMIC CHIP 2.2uF 10% 10V
C4303 1-125-889-11 CERAMIC CHIP 2.2uF 10% 10V
C4304 1-125-889-11 CERAMIC CHIP 2.2uF 10% 10V
C4305 1-125-889-11 CERAMIC CHIP 2.2uF 10% 10V
C4306 1-125-889-11 CERAMIC CHIP 2.2uF 10% 10V
C4308 1-112-300-91 CERAMIC CHIP 4.7uF 10% 10V
C4309 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C4310 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C4311 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C4312 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C4313 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C4314 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C4315 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C4316 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C4317 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C4318 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C4319 1-112-298-91 CERAMIC CHIP 1uF 10% 16V
C4320 1-100-567-81 CERAMIC CHIP 0.01uF 10% 25V
C4321 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C4322 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C4323 1-112-298-91 CERAMIC CHIP 1uF 10% 16V
C4324 1-112-298-91 CERAMIC CHIP 1uF 10% 16V
C4325 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C4326 1-100-597-91 CERAMIC CHIP 0.1uF 10% 25V
C4327 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C4328 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C4329 1-127-715-11 CERAMIC CHIP 0.22uF 10% 16V
C4330 1-127-715-11 CERAMIC CHIP 0.22uF 10% 16V
C4331 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C4332 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C4333 1-112-298-91 CERAMIC CHIP 1uF 10% 16V
C4334 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C4337 1-165-884-11 CERAMIC CHIP 2.2uF 10% 6.3V
C4338 1-100-591-91 CERAMIC CHIP 1uF 10% 25V
C4349 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C4350 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C4801 1-119-750-11 TANTAL. CHIP 22uF 20% 6.3V
C4802 1-164-852-11 CERAMIC CHIP 12PF 5% 50V
C4803 1-164-852-11 CERAMIC CHIP 12PF 5% 50V
C4804 1-100-567-81 CERAMIC CHIP 0.01uF 10% 25V
C4805 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C4806 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C4807 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C4808 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C4809 1-100-567-81 CERAMIC CHIP 0.01uF 10% 25V
C4810 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C4811 1-100-567-81 CERAMIC CHIP 0.01uF 10% 25V
C4812 1-100-567-81 CERAMIC CHIP 0.01uF 10% 25V
C5219 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C5221 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C5501 1-165-897-11 TANTAL. CHIP 22uF 20% 10V
C5502 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C5505 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C5506 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C5507 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C5508 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C5509 1-127-772-81 CERAMIC CHIP 0.033uF 10% 10V
C5510 1-127-772-81 CERAMIC CHIP 0.033uF 10% 10V
C5511 1-127-772-81 CERAMIC CHIP 0.033uF 10% 10V
C5512 1-127-772-81 CERAMIC CHIP 0.033uF 10% 10V
C5513 1-119-923-11 CERAMIC CHIP 0.047uF 10% 10V
C5514 1-119-923-11 CERAMIC CHIP 0.047uF 10% 10V
C5515 1-119-923-11 CERAMIC CHIP 0.047uF 10% 10V
C5516 1-119-923-11 CERAMIC CHIP 0.047uF 10% 10V
C5518 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C5519 1-119-923-11 CERAMIC CHIP 0.047uF 10% 10V
C5520 1-127-772-81 CERAMIC CHIP 0.033uF 10% 10V
C5521 1-165-887-91 CERAMIC CHIP 0.22uF 10% 6.3V
C5522 1-119-923-11 CERAMIC CHIP 0.047uF 10% 10V
C5523 1-119-923-11 CERAMIC CHIP 0.047uF 10% 10V
C7701 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C7702 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C7703 1-119-923-11 CERAMIC CHIP 0.047uF 10% 10V
C7704 1-119-923-11 CERAMIC CHIP 0.047uF 10% 10V
C7705 1-100-611-91 CERAMIC CHIP 22uF 20% 6.3V
C7706 1-114-411-21 CERAMIC CHIP 0.33uF 10% 6.3V
C7707 1-112-746-11 CERAMIC CHIP 4.7uF 10% 6.3V
C9101 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C9102 1-112-298-91 CERAMIC CHIP 1uF 10% 16V
C9103 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C9104 1-112-298-91 CERAMIC CHIP 1uF 10% 16V
C9105 1-112-298-91 CERAMIC CHIP 1uF 10% 16V
C9107 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C9109 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C9111 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C9112 1-112-746-11 CERAMIC CHIP 4.7uF 10% 6.3V
C9113 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C9115 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C9116 1-112-300-91 CERAMIC CHIP 4.7uF 10% 10V
C9118 1-100-670-91 CERAMIC CHIP 4.7uF 20% 16V
C9119 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
< CONNECTOR >
CN1001 1-573-806-21 PIN, CONNECTOR (1.5MM) (SMD) 6P
*CN1003 1-821-503-11 CONNECTOR, FPC (ZIF) 39P
CN1008 1-821-500-11 CONNECTOR, FPC (ZIF) 45P
*CN1009 1-816-647-61 FFC/FPC CONNECTOR (LIF) 18P
*CN1010 1-770-619-11 PIN, CONNECTOR 2P
CN1021 1-816-645-61 FFC/FPC CONNECTOR (LIF) 14P
CN1024 1-816-654-61 FFC/FPC CONNECTOR (LIF) 6P
CN1025 1-816-654-61 FFC/FPC CONNECTOR (LIF) 6P
CN1026 1-794-057-21 PIN, CONNECTOR (PC BOARD) 2P
CN1031 1-821-500-11 CONNECTOR, FPC (ZIF) 45P
*CN1033 1-822-165-11 CONNECTOR, FPC (ZIF) 39P
CN1034 1-842-602-11 CONNECTOR, HDMI
*CN1036 1-822-914-11 CONNECTOR, FPC (LIF (NON-ZIF))
CN9101 1-843-120-11 HEADER ASSEMBRY
CN9102 1-822-425-21 CONNECTOR, USB (MINI AB)
< DIODE >
*D1001 6-503-109-01 DIODE DZ2S12000K8
D1303 6-500-854-01 DIODE 1SS413 (TPL3)
D1304 6-500-854-01 DIODE 1SS413 (TPL3)
D1401 6-503-126-01 DIODE DA2S10100K8
D1402 6-503-126-01 DIODE DA2S10100K8
D4101 6-503-126-01 DIODE DA2S10100K8
*D9101 6-502-988-01 DIODE RB480Y-40T2R
D9102 6-503-702-01 DIODE RB070M-30FJTR
D9103 6-502-934-01 DIODE DB2S31100K8
D9104 6-503-217-01 DIODE RKZ5.6B2KJR1
D9105 6-503-217-01 DIODE RKZ5.6B2KJR1
< FUSE >
F001 1-523-133-31 FUSE (1.4A/50V)
F002 1-523-133-31 FUSE (1.4A/50V)
F003 1-523-133-31 FUSE (1.4A/50V)
F004 1-523-133-31 FUSE (1.4A/50V)
F005 1-523-133-31 FUSE (1.4A/50V)
*F006 1-576-872-31 FUSE (0.25A/50V)
F007 1-523-134-31 FUSE (2A/50V)
< FERRITE BEAD >
FB1301 1-481-747-21 INDUCTOR, FERRITE BEADS
FB1302 1-400-833-21 SMD EMI FERRITE
FB1303 1-481-984-21 EMI FERRITE (SMD)(1005)
FB1401 1-400-827-31 BEAD, FERRITE (1005)
FB1402 1-400-827-31 BEAD, FERRITE (1005)
FB1405 1-469-580-21 INDUCTOR, FERRITE BEAD (1005)
FB1406 1-400-921-21 FERRITE, EMI (SMD)
FB1407 1-400-921-21 FERRITE, EMI (SMD)
FB1408 1-400-921-21 FERRITE, EMI (SMD)
FB1409 1-400-921-21 FERRITE, EMI (SMD)
FB1410 1-400-921-21 FERRITE, EMI (SMD)
FB1411 1-400-921-21 FERRITE, EMI (SMD)
FB1412 1-400-921-21 FERRITE, EMI (SMD)
FB1413 1-400-921-21 FERRITE, EMI (SMD)
FB1414 (Not supplied) FERRITE CHIP ARRAY 120(2010)
FB1415 (Not supplied) FERRITE CHIP ARRAY 120(2010)
FB1416 1-469-580-21 INDUCTOR, FERRITE BEAD (1005)
FB1501 1-481-912-21 EMI FERRITE (SMD) (1005)
< IC >
IC1301 (Not supplied) AVY1G2G04B
IC1302 6-716-878-01 IC AK8153AU-L
IC2401 6-718-156-01 IC BU76312GUW-E2
*IC2601 6-714-928-01 IC BD8871GW-E2
IC3001 6-718-186-01 IC CS48L10-CWZR
IC4301 6-717-389-01 IC BD8330AGU-E2
IC4302 6-716-945-01 IC BD8331GU-E2
IC4303 6-718-155-01 IC R1207N823B-TR-FE
*IC4304 6-714-502-01 IC BD2224G-TR
IC4801 6-718-258-01 IC MB95005ABGL-G-135-ERE1
IC5202 6-715-211-01 IC MM3404A28URE
IC5501 6-716-760-01 IC R2J30503LG
IC5502 6-716-952-01 IC R2A30427BM
IC7701 6-707-333-01 IC NJM3230SE7
IC9101 6-718-158-01 IC MAX14593EEWV+TG1A
IC9102 6-718-154-01 IC BD8668GW-E2
IC9103 6-716-783-01 IC BD11600NUX-E2
IC9104 6-716-783-01 IC BD11600NUX-E2
*IC9105 6-714-833-01 IC TPS2553DBVR-1
< COIL >
L2402 1-400-588-11 INDUCTOR 10uH
*L2601 1-481-425-21 INDUCTOR 10uH
L4301 1-460-355-11 INDUCTOR 4.7uH
L4302 1-460-370-11 INDUCTOR 10uH
L4303 1-460-370-11 INDUCTOR 10uH
L4304 1-460-370-11 INDUCTOR 10uH
L4305 1-460-370-11 INDUCTOR 10uH
L4306 1-460-355-11 INDUCTOR 4.7uH
L4307 1-460-369-11 INDUCTOR 33uH
*L7701 1-481-425-21 INDUCTOR 10uH
*L9101 1-457-858-11 INDUCTOR 4.7uH
< LINE FILTER >
LF1301 1-457-539-11 COMMON MODE CHOKE COIL
LF1302 1-457-539-11 COMMON MODE CHOKE COIL
LF9101 1-457-223-11 COMMON MODE CHOKE COIL
LF9102 1-457-223-11 COMMON MODE CHOKE COIL
< TRANSISTOR >
*Q1001 6-552-397-01 TRANSISTOR DSC300100L
*Q1006 6-552-344-01 TRANSISTOR DRA3143T0L
Q1301 6-552-621-01 TRANSISTOR SSM3K37MFV, L3SOF
*Q1302 6-552-723-01 TRANSISTOR SSM6N37FE, RSONYM
*Q1402 6-552-344-01 TRANSISTOR DRA3143T0L
*Q1403 6-552-535-01 TRANSISTOR DMG964030R
Q2401 8-729-056-75 TRANSISTOR MCH3211-TL-E
Q4101 8-729-043-60 TRANSISTOR CPH6102-TL-E
*Q4102 6-552-354-01 TRANSISTOR DRC3144E0L
*Q4103 6-552-123-01 TRANSISTOR ECH8652-S-TL-H
Q4304 6-552-749-01 TRANSISTOR RN2131MFV
Q4305 6-552-749-01 TRANSISTOR RN2131MFV
*Q4801 6-552-535-01 TRANSISTOR DMG964030R
Q9102 6-553-025-01 TRANSISTOR MCH6341-TL-E
*Q9103 6-552-354-01 TRANSISTOR DRC3144E0L
*Q9107 6-552-348-01 TRANSISTOR DRC3114E0L
< RESISTOR >
R1001 1-218-989-11 METAL CHIP 1M 5% 1/16W
R1017 1-218-945-11 METAL CHIP 220 5% 1/16W
R1018 1-218-953-11 METAL CHIP 1K 5% 1/16W
R1025 1-218-990-81 SHORT CHIP 0
R1030 1-218-958-11 METAL CHIP 2.7K 5% 1/16W
R1031 1-218-937-11 METAL CHIP 47 5% 1/16W
R1032 1-218-951-11 METAL CHIP 680 5% 1/16W
VC-652
HDR-CX250/CX250E/CX260E/CX260V/CX260VE/CX270E/CX270V_L3
Ref. No. Part No. Description Ref. No. Part No. Description Ref. No. Part No. Description
2-4E
R1033 1-218-953-11 METAL CHIP 1K 5% 1/16W
R1034 1-218-963-11 METAL CHIP 6.8K 5% 1/16W
R1048 1-218-947-11 METAL CHIP 330 5% 1/16W
R1052 1-218-990-81 SHORT CHIP 0
R1315 1-208-869-11 METAL CHIP 180 0.5% 1/16W
R1321 1-208-703-11 METAL CHIP 6.8K 0.5% 1/16W
R1331 1-250-481-11 METAL CHIP 270 1% 1/16W
R1332 1-218-970-11 METAL CHIP 27K 5% 1/16W
R1335 1-218-953-11 METAL CHIP 1K 5% 1/16W
R1342 1-218-956-11 METAL CHIP 1.8K 5% 1/16W
R1343 1-218-956-11 METAL CHIP 1.8K 5% 1/16W
R1363 1-218-973-11 METAL CHIP 47K 5% 1/16W
R1364 1-218-973-11 METAL CHIP 47K 5% 1/16W
*R1373 1-250-469-11 METAL CHIP 82 1% 1/16W
R1374 1-218-961-11 METAL CHIP 4.7K 5% 1/16W
R1375 1-218-961-11 METAL CHIP 4.7K 5% 1/16W
R1409 1-218-940-11 METAL CHIP 82 5% 1/16W
R1410 1-218-943-11 METAL CHIP 150 5% 1/16W
R1411 1-218-940-11 METAL CHIP 82 5% 1/16W
R1412 1-208-859-81 METAL CHIP 68 0.5% 1/16W
R1413 1-218-937-11 METAL CHIP 47 5% 1/16W
R1414 1-218-943-11 METAL CHIP 150 5% 1/16W
R1421 1-218-941-81 METAL CHIP 100 5% 1/16W
R1422 1-218-937-11 METAL CHIP 47 5% 1/16W
R1423 1-218-937-11 METAL CHIP 47 5% 1/16W
R1458 1-218-945-11 METAL CHIP 220 5% 1/16W
R1459 1-218-945-11 METAL CHIP 220 5% 1/16W
R1460 1-218-945-11 METAL CHIP 220 5% 1/16W
R1461 1-218-945-11 METAL CHIP 220 5% 1/16W
R1462 1-218-945-11 METAL CHIP 220 5% 1/16W
R1463 1-218-945-11 METAL CHIP 220 5% 1/16W
R1464 1-218-945-11 METAL CHIP 220 5% 1/16W
R1465 1-218-945-11 METAL CHIP 220 5% 1/16W
R1468 1-218-990-81 SHORT CHIP 0
R1470 1-218-961-11 METAL CHIP 4.7K 5% 1/16W
R1471 1-218-961-11 METAL CHIP 4.7K 5% 1/16W
R1505 1-218-953-11 METAL CHIP 1K 5% 1/16W
R1515 1-208-668-11 METAL CHIP 240 0.5% 1/16W
R2410 1-218-953-11 METAL CHIP 1K 5% 1/16W
R2411 1-218-953-11 METAL CHIP 1K 5% 1/16W
R2412 1-218-961-11 METAL CHIP 4.7K 5% 1/16W
R2413 1-218-955-11 METAL CHIP 1.5K 5% 1/16W
R2414 1-218-957-11 METAL CHIP 2.2K 5% 1/16W
R2415 1-218-957-11 METAL CHIP 2.2K 5% 1/16W
R2416 1-218-971-11 METAL CHIP 33K 5% 1/16W
R2601 1-218-978-11 METAL CHIP 120K 5% 1/16W
R2602 1-218-978-11 METAL CHIP 120K 5% 1/16W
R2605 1-208-703-11 METAL CHIP 6.8K 0.5% 1/16W
R2606 1-208-703-11 METAL CHIP 6.8K 0.5% 1/16W
R2610 1-218-965-11 METAL CHIP 10K 5% 1/16W
R2611 1-218-965-11 METAL CHIP 10K 5% 1/16W
R3006 1-218-990-81 SHORT CHIP 0
R3007 1-218-961-11 METAL CHIP 4.7K 5% 1/16W
R4101 1-216-796-11 METAL CHIP 8.2 5% 1/10W
R4102 1-218-953-11 METAL CHIP 1K 5% 1/16W
R4103 1-218-961-11 METAL CHIP 4.7K 5% 1/16W
R4302 1-218-941-81 METAL CHIP 100 5% 1/16W
R4303 1-250-535-11 METAL CHIP 47K 1% 1/16W
R4315 1-250-449-11 METAL CHIP 12 1% 1/16W
R4334 1-218-965-11 METAL CHIP 10K 5% 1/16W
R4341 1-250-449-11 METAL CHIP 12 1% 1/16W
R4802 1-245-604-11 METAL CHIP 10M 5% 1/16W
R4803 1-208-893-11 METAL CHIP 1.8K 0.5% 1/16W
R4807 1-208-703-11 METAL CHIP 6.8K 0.5% 1/16W
R4808 1-218-973-11 METAL CHIP 47K 5% 1/16W
R4809 1-218-953-11 METAL CHIP 1K 5% 1/16W
R4810 1-218-949-11 METAL CHIP 470 5% 1/16W
R4812 1-218-973-11 METAL CHIP 47K 5% 1/16W
R4814 1-208-927-11 METAL CHIP 47K 0.5% 1/16W
R4815 1-208-935-11 METAL CHIP 100K 0.5% 1/16W
R4817 1-208-927-11 METAL CHIP 47K 0.5% 1/16W
R4818 1-208-935-11 METAL CHIP 100K 0.5% 1/16W
R4823 1-218-953-11 METAL CHIP 1K 5% 1/16W
R4824 1-218-965-11 METAL CHIP 10K 5% 1/16W
R4825 1-218-985-11 METAL CHIP 470K 5% 1/16W
R4826 1-218-989-11 METAL CHIP 1M 5% 1/16W
R5504 1-218-941-81 METAL CHIP 100 5% 1/16W
R5506 1-208-711-11 METAL CHIP 15K 0.5% 1/16W
R5508 1-218-971-11 METAL CHIP 33K 5% 1/16W
R5509 1-218-971-11 METAL CHIP 33K 5% 1/16W
R5510 1-218-971-11 METAL CHIP 33K 5% 1/16W
R5511 1-218-971-11 METAL CHIP 33K 5% 1/16W
R5522 1-250-531-11 METAL CHIP 33K 1% 1/16W
R5526 1-250-487-11 METAL CHIP 470 1% 1/16W
R7702 1-218-969-11 METAL CHIP 22K 5% 1/16W
R7703 1-218-969-11 METAL CHIP 22K 5% 1/16W
R7705 1-218-965-11 METAL CHIP 10K 5% 1/16W
*R7706 1-250-523-11 METAL CHIP 15K 1% 1/16W
R7707 1-218-985-11 METAL CHIP 470K 5% 1/16W
R9116 1-218-941-81 METAL CHIP 100 5% 1/16W
R9120 1-218-989-11 METAL CHIP 1M 5% 1/16W
R9133 1-248-311-11 RES-CHIP 0.1 1% 1/4W
R9134 1-250-535-11 METAL CHIP 47K 1% 1/16W
R9135 1-218-969-11 METAL CHIP 22K 5% 1/16W
R9136 1-218-944-11 METAL CHIP 180 5% 1/16W
R9137 1-250-521-11 METAL CHIP 12K 1% 1/16W
R9138 1-218-973-11 METAL CHIP 47K 5% 1/16W
R9140 1-257-317-11 METAL CHIP 47 1% 1/2W
R9141 1-218-963-11 METAL CHIP 6.8K 5% 1/16W
R9152 1-218-953-11 METAL CHIP 1K 5% 1/16W
< COMPOSITION CIRCUIT BLOCK >
RB1401 1-234-371-11 RES, NETWORK 47 (1005X4)
RB1403 1-234-371-11 RES, NETWORK 47 (1005X4)
RB1412 1-234-375-21 RES, NETWORK 1K (1005X4)
RB1413 1-234-375-21 RES, NETWORK 1K (1005X4)
RB1414 1-234-378-21 RES, NETWORK 10K (1005X4)
RB1415 1-234-381-11 RES, NETWORK 100K (1005X4)
*RB1416 1-234-384-11 RES, NETWORK 1M (1005X4)
RB1418 1-234-380-21 RES, NETWORK 47K (1005X4)
RB3001 1-234-380-21 RES, NETWORK 47K (1005X4)
RB4801 1-234-378-21 RES, NETWORK 10K (1005X4)
RB9101 1-234-381-11 RES, NETWORK 100K (1005X4)
< SENSOR >
*SE1001 1-487-118-11 GMR SENSOR
SE7701 1-479-022-61 SENSOR, ANGULAR VELOCITY (32.2KHZ)
< VARIABLE RESISTOR >
VR1002 1-802-078-11 VARISTOR (SMD)
< VIBRATOR >
X1302 1-814-219-31 QUARTZ CRYSTAL OSCILLATOR (60MHz)
X4801 1-781-525-11 VIBRATOR, CRYSTAL (32.768kHz)
VC-652
4-1
HDR-CX250/CX250E/CX260E/CX260V/CX260VE/CX270E/CX270V_L3
4. BLOCK DIAGRAMS
4-1. OVERALL BLOCK DIAGRAM (1/2)( ) : Number in parenthesis ( ) indicates the division number of schematic diagram where the component is located.
CMOS
IMAGER
CP001
IRIS
(SHUTTER)
LENS BLOCK (1/2)
LCD_XVD/XHD
XCS_LCD
XBB_RST
AV_SO/SCK
PANEL_NOR/REV
TP_X/Y/SEL1
Q1402
TP_SEL2
BEEP_PWM_P
LCD_CLK
CN6702
DOAP - DOHP,
DOAM - DOHM
XVS
SDI, XCE, SCK
DCKP,DCKM
INCK
XCLR
FP-1484
FLEXIBLE
BOARD
CM-123 BOARD
CN1008
VC-652 BOARD (1/2)
SENS_VD
SUBL_CLKINN/CLKINP
SUBL_DINN2-DINN9/DINP2-DINP9
XFLASH_RST
CLK_CMOS_IN_IMG
CLK_CMOS_IN_GEN
CPU,
AV SIGNAL PROCESS,
LENS CONTROL,
MODE CONTROL,
HDMI PROCESS
(2/14 - 4/14)
IC2401
BCK_OUT, MCK_INOUT, LRCK_OUT
GPIO_SB_4
SDO
AV_SO/SCK
INT_MIC_L
INT_MIC_R
AUDIO_L_I/O
AUDIO_R_I/O
JACK_AD
LANC_SIG
XSYS_RST
XSYS_RST
MIC_JACK_IN,
XMIC_MONO,
MIC_PWR_ON,
EXT_LINE_SEL
(5/14)
AUDIO
INTERFACE
COMPO_VIDEO
CN1036 CN1001
FP-1516
FLEXIBLE
BOARD
A/V R
AUDIO_L_I/O
AUDIO_R_I/O
MICAMP_OUT_L
MICAMP_OUT_R
EXT_MIC_L
EXT_MIC_R
JACK_AD
CN1033 (1/2)
IC1301
(1/2)
CLOCK
GENERATOR
TOUCH
PANEL
INTERFACE
(2/14)
IC1302
CLK_SYS_IN
CLK_CMOS_IN
XFLASH_RST
XHS
X1302
60MHz
SDO
IC_1301_SENSSI/SENSXCS/SENSSCK
IC_1301_SENSSO
SENS_HD
AUDIO DSP
(7/14)
XSYS_RST
AV_SO/SCK
IC3001
DAO_D1
MISO_SDA
BCK_OUT,
MCK_INOUT,
LRCK_OUT
XCS_IC_3001
XBUSY_HS0_IC_3001
XINT_HS1_IC_3001
DAI_D1
XCS_LCD
XBB_RST
AV_SO/SCK
PANEL_NOR/REV
TP_X/Y/SEL1
XSYS_RST
LCD_DATA[0] - DATA[7]
SP901
(SPEAKER)
J1001
COMPO_VIDEO
: VIDEO SIGNAL
: AUDIO SIGNAL
MIC901
MICROPHONE
UNIT
JACK_AD
COMPO_VIDEO
AUDIO_L_I/O
AUDIO_R_I/O
CN1002
JK-402 BOARD
CN1024
CN1026
SP ±
(L)
(R)
TOUCH
PANEL
3.0 INCH
WIDE COLOR
LCD
LCD901
(LCD MODULE)
CN6201 (1/2)
CN6203
TP_SEL1
TP_X/Y
TP_X/Y/SEL1 CN6202
TP_R
TP_BOT
TOUCH PANEL
INTERFACE
Q6202, Q6203
SE6201
XCS_LCD
LCD_VS/HS/CLK_OUT
PANEL_NOR/REV
XBB_RST
PD-458 BOARD (1/2)
PANEL
NORMAL/REVERSE
DETECT
AV_SO/SCK
FP-1487
FLEXIBLE
BOARD (1/2)
STEADYSHOT
PROCESSOR
(12/14)
IC5501
IC_5501_SO/SI/SCK
XCS_IC_5501
XIC_5501_CPU_RST
IC_5501_INT_REQ
ZM_DIR_A/B, ZM_ENB
CAM_V
IC_5501_IC_5201_CLK
IC_5501_P_LIMIT
IC_5501_2_EXPOSE
LENSV_EN
LENS_COVER_DIR_PWM
SHUTTER_A
SHUTTER_XA
LENS_COVER_
DIR_PWM
LENSV_EN
CN1010
LENS
BARRIER
UNIT
CN1003
I_BIAS-, I_HALL±, I_DRIVE±,
LENS_TEMP_AD
FC_SENSE
IRIS
DRIVE
LENS TEMP
SENSOR
OIS TEMP
SENSOR
PITCH/YAW
DRIVE
OPTICAL IMAGE
STABILIZER
PITCH_HALL±/BIAS-
LENS BLOCK (2/2)
ZOOM_A/B/XA/XB_OUT
ZM_SENSE1A
FOCUS_A/B/XA/XB
ZOOM
DRIVE
FOCUS
DRIVE
YAW_HALL±/BIAS-
PITCH±
YAW±
TZ_HALL_TEMP
XSYS_RST
CRESET_P
YAW_AD
PITCH_AD
ROLL SENSOR
AMP
(13/14)
IC7701
LENS
BARRIER
DRIVE
(12/14)
IC5502
ROLL
SENSOR
(13/14)
SE7701
ROLL_AD
VST_C_CHARGE
LENS_TEMP_AD
ZM_SENSE1A
TZ_HALL_TEMP
FC_SENSE
FC_DIR_A/B, FC_ENB
LCD_D0-D7
LCD_XVD/XHD/CLK
OVERALL (2/2)
(PAGE 4-2)
2
IC2601
MIC AMP
(6/14)
08
F2
K2
40,37,
34,31,
25,22,
19,16,
39,36,
33,30,
24,21,
18,15
12
28,27
9,6,7
2
4
39,36,
33,30,
24,21,
18,15,
40,37,
34,31,
25,22,
19,16
12
27,28
9,6,7
2
4
AK28
6
8
10
14
11
9
7
3
AH2
15
13
2
4
19
21
1,7,
5,8,
4,10,
11,2
16,15,
13
20,17
27,28,
29
30
W2,W1
OVERALL (2/2)
(PAGE 4-2) 4
OVERALL (2/2)
(PAGE 4-2)
1
4
1
3
AF2
AD30
G3
G1
11
10
11
10
D1
AC30
AC29
9
1
6
7
15 22
6
3
1,2
2
5
4, 1
4
3
17 - 10
8, 7, 9
5, 6
21
19
39,33,
35,32,
36,30,
29,38
24,25,
27
20,23
12,13,
11
10
D1
F5
E4
20,22,
21,23,
17,18
15,14,
13,12
1,4,
2,3
7
9
6
27,28
25,26
33,31,
30
35,37,
36
39
1
2
OVERALL (2/2)
(PAGE 4-2)
3
AE10
PLUG IN
POWER
4-2
HDR-CX250/CX250E/CX260E/CX260V/CX260VE/CX270E/CX270V_L3
4-2. OVERALL BLOCK DIAGRAM (2/2)( ) : Number in parenthesis ( ) indicates the division number of schematic diagram where the component is located.
FP-1487
FLEXIBLE
BOARD
(2/2)
GP-037 BOARDPD-458 BOARD
(2/2)
CN1033 (2/2)
CN1009 CN8101
CN6207 CN9201CN6201 (2/2)
GPS_UART_RXD
GPS_UART_TXD
GPS_UART_CTS
GPS_UART_RTS
GPS_UART_RXD
GPS_UART_TXD
GPS_UART_CTS
GPS_UART_RTS
SCK0/TX0_1
SIN0/RX0_1
SO0/RTS_1
XSCS0/CTS_1
X9201
16.368MHz
XGPS_RST XGPS_RST XGPS_RST
FLEXIBLE
FLAT
CABLE
(FFC-283)
FP-1486
FLEXIBLE
BOARD
MM-102 BOARD
MSX_BS/CLK
MSX_BIO_0 - MSX_BIO_3
MS-477 BOARD
CN8002CN8001
MSX_BS/CLK
MSX_BIO_0 - BIO_3
TE0_XSDCD
MSX_INS_HIZ
TE0_DAT_0 - DAT_3
TE0_XSDCD
TE0_CMD/SDWP/CLK
MSX_INS_HIZ
TE0_DAT_0 - DAT_3
TE0_CMD/SDWP/CLK
XMS_ACC_LED
XMS_ACC_LED
D8001
(MS ACCESS)
FR_XRESETFR_XRESET
FP-1485
FLEXIBLE
BOARD
VC-652 BOARD (2/2)
PITCH_AD
SE7501 CRESET_P
YAW_AD
PITCH_AD
CRESET_P
YAW_AD
PITCH/YAW
SENSOR
CN1031
CN1021
CONTROL
SWITCH
BLOCK
(PS37500)
TE0_XSDCD
MSX_INS_HIZ
(1/2)
08
OVERALL (1/2)
(PAGE 4-1)
3
OVERALL (1/2)
(PAGE 4-1)
2
S8002,S8003,S8005 KEY_AD2
XPOWER_TACT_SW
KEY_AD2
XPOWER_TACT_SW
D1401
D1402
XCHARGE_LED
XCAM_LED
XPHOTO_LED
KEY_AD1
ZOOM_VR_AD
FR_XRESET
XCHARGE_LED
XCAM_LED
MENU
FR_XRESET
LANC_IN/OUT
LANC_SIG
CN1034
HDMI_TXCN/TXCP
HDMI_TX0SOP-TX2SOP, HDMI_TX0SON-TX2SON
Q1302
Q1301
Q1403 HPDHDMI_JACK_IN
CEC CEC
SDA, SCL SDA, SCL HDMI OUT
USB_D± USB SWITCH
(14/14)
IC9103
USB SWITCH
(14/14)
IC9104
USB
POWER
MANEGEMENT
(14/14)
IC9101
CN9101
BUILT-IN
USB CABLE
USB_ID2
USB_SEL
USB_D±_STD_CN
USB_DP/DM
ISET1
ISET2
SMART
POWER
SELECTOR
(14/14)
IC9102
ISETOUT1
ISETOUT2
USB_DD_PGOOD
USB_DD_EN
VBUSOK
USB_ID2
USB_ID
X4801
32.768kHz
PANEL
OPEN/CLOSE
DETECT
(1/14)
SE1001
Q1001
XPANEL_POWER_ON
XSYS_RST
XCS_FRONT
XFLASH_RST XFLASH_RST
XSYS_RST
XPWR_OFF
FR_SI/SO/SCK
XRESET_REQ
ISETOUT1
ISETOUT2
USB_DD_PGOOD
USB_DD_EN
VBUSOK
OVERALL (1/2)
(PAGE 4-1)
1
TE1_DAT_0-DAT_7
IM Model
GPS Model
TE1_DAT_0-DAT_7
TE1_CMD/CLK TE1_CMD/CLK
OVERALL (1/2)
(PAGE 4-1)
4
: VIDEO/AUDIO SIGNAL
38
36
37
39
2
4
3
1
7
5
8
6
2
4
1
3
GPS
RECEIVER
IC9204
RF AMP
SF9202
SAW FILTER
SF9201
SAW FILTER
IC9203
RF AMP
IC9202
AT9201
E7
B3
18
8
32
10,8,11,1621,23,1,3
18
14
13,11,15,17
37
21
30
6
45
38
43
13,11,44,43
9
25
16
1
8
3
6,24,15
33,35,31,29
39,7,23
7,17
37,21
9,2533,35,2,37,39,23
HI CONTROL,
LANC INTERFACE
(10/14)
CPU,
AV SIGNAL
PROCESS,
LENS CONTROL,
MODE CONTROL,
HIDMI PROCESS
(2/14-4/14)
2
11
3
IC1301
(2/2)
K2
20
8
40
26
38
4
13
DC/DC
CONVERTER,
LANC DRIVER
(9/14)
IC4302
IC4801
E5
14
8,5,2,9,6,311,1216,15
19
LEVEL SHIFT
LEVEL SHIFT
LEVEL SHIFT
3, 2
3, 2
4
L3
L2
AE16
2-913,11
2-913,11
B8
A8
INTERNAL
MEMORY
(1/2)
IC8101
MEMORY
STICK
PRO DUO
SD
(USB)
CN9102
CHARGE
4-3
HDR-CX250/CX250E/CX260E/CX260V/CX260VE/CX270E/CX270V_L3
4-3. POWER BLOCK DIAGRAM (1/2) ( ) : Number in parenthesis ( ) indicates the division number of schematic diagram where the component is located.
BUILT-IN
USB CABLE
BATTERY
TERMINAL
CN1001
ACV_UNREG_CN
+
S
–
Q4103
ACV/BATT SELECT SWITCH
Q4101, Q4102
BATTERY CHARGE
SWITCH
F003 L4301
F004
DC/DC CONVERTER
(9/14)
IC4301
LX1a
FB1
LX1b
L4306
LX6a
FB6
LX6b
L4305
LX5a
FB5
LX5b
L4302
LX2
FB2
LDO1_SOURCE
B+ SWITCH
(9/14)
IC4304
VOUT
VIN
EN
F002
BATT_UNREG_SENSE
D_1.2V
L4303
LX3a
FB3
LX3b
LD02_SOURCE
D_1.8V
L4304
LX4
FB4
AU_2.8V
D_2.8V
A_3.3V
MEDIA_3.3V
D_3.3V
SD_PWR_ON TE0_VCC
D_3.3V
J_5.0V
A_5.0V
MT_5.0V
MT_5.0V
DC/DC CONVERTER
(9/14)
IC4303
VOUT
VIN
LX
BL_H
LCD_CABC_PWM
L4307
F006
EN
FB BL_L
LDO2_OUT
HB_1.2V
HB_1.8V
LDO1_OUT
CORE_UNREG
I/O_UNREG
MT_UNREG
XLANC_PWR_ON
XLANC_ON
BATT_IN
XCS_IC_4302
DC/DC CONVERTER,
LANC DRIVER
(9/14)
IC4302
F005
F001 ACV_UNREG
ACV_ON
BATT_ON
BATT/XEXT_CN
HI CONTROL,
LANC INTERFACE
(10/14)
IC4801
VC-652 BOARD (1/2)
BATT_UNREG_CN
BATT/XEXT_CN
BATT_SIG
FR_EVER_SI/SO/SCK
VuC
XLANC_ON
XLANC_PWR_ON
UNREG_IN
CS
ACV_ON
EVER3
LDO1_OUT
LDO1_FB
PVDD_LDO1
LDO2_OUT
LDO2_ON
LOAD_IN
LOAD_OUT
LOAD_ON
VCH
LANC_DC
D_1.2V
A_1.125V_SENSE
A_1.125V
HDMI_5V
MS_PWR_ON
MSX_3.3V
BATT_LI_3V
LANC_DC
LDO1_ENB
PVDD1a
PVDD1b
PVDD2
PVDD3a
PVDD3b
PVDD4
PVDD5a
PVDD5b
PVDD_CP
AVDD
PVDD6a
PVDD6b
LDO2_ENB
A_1.8V
A_2.8V
A_VID_1.1V
D_VID_1.1V
LDO1_ON
VOUT
EVER_3.0V
ACV_ON
BATT_ON
LDO2_ON
BATT_GND
ACV_GND
CN9101
USB_VCC_STD
USB POWER
MANAGEMENT
(14/14)
IC9101
VBUS1
SMART POWER
SELECTOR
(14/14)
IC9102
L9101
D9102
Q9102
VOUT
BATT
SW1
F007
DC IN
J901
DC JACK
VB1
VB2
NVP
OUT1
OUT2
REG33
D9101
UNREG_IN_DET
VBUS2
ISNS
VBUSLIMIT
SW2
1D+
USB
SWITCH
(14/14)
IC9104
2D+
D+
VCC
USB_VCC
MAIN_UNREG
OUT
CURRENT LIMITER
(14/14)
IC9105
IN
FAULT
EN
F500
VCC
D_2.8V
EVER_3.0V
USB_VBUS
J_5.0V
J_5.0V
VBUS_XOVR_CUR
VBUS_EN
CH1_OUT
CH2_OUT
CH3_OUT
CH4_OUT
CH6_OUT
CH5_OUT
D9103
VTR_UNREG
PVDD_LP02
PVDD_LP02
BATT_ON
LDO1_ON
FR_EVER_SO/SCK
FR_EVER_
SI/SO/SCK
DD_ON
UNREG_IN_DET
UNREG_IN_DET
BATT_UNREG
BATT_UNREG_SENSE
D4101 EP_2.8V
CAM_1.2V
HB_1.2V
HB_1.8V
MS_PWR_ON
SD_PWR_ON FRC_RTG_IN1
LCD_CABC_PWM
GPIO_S__6
USB_VBUS
VBUS_EN
GPIO_S__2
GPIO_S__1
GPIO_SB__5
LCD_CABC_PWM
D_2.8V
J_5.0V
EVER_3.0V
USB_VBUS
VBUS_XOVR_CUR
VBUS_EN
CPU,
AV SIGNAL
PROCESSOR,
LENS CONTROL,
MODE CONTROL,
HDMI PROCESS
(2/14 - 4/14)
IC1301
(1/2)
XO_CS_IC_4302
XPUI_LANC_PWR_ON
XO_LANC_IC_ON
I_BATT_IN HB_1.2V
HB_1.8V
VBUS_DET
Q9103
XVBUS_DET_STD_A
Q9107
XVBUS_DET_ATD_A
VBUS_DET
A_1.125V
HDMI_5V
MSX_3.3V
BATT_LI_3V
LANC_DC
EVER_3.0V
BL_H/L POWER (2/2)
(PAGE 4-4)
A
DD_ON
DD_ON
CHARGE
(USB)
CN9102
USB SWITCH
(13/13)
IC9103
D1
D2
B8
C5
A6
D3
A2
C4
B4
B2
H7
E4
H4
E3
G4
5
1
3
E8
D5
E7
5
6
1
4
3
A5
D6
A4
E1
E2
C8
A1
B1
H6
H5
G5
H2
B7
D8
D7
B1
A1
B2
A3
A5
B6
A6
B5
F5
C2
C4
E4
F4
4
3
2
5
G1 G6
E3K9
C1
A7
F6
E5
D3
C4
F10
A4
C7
Q4801
D6
E2
XPUIO_BATT_SIG
O_INIT_CHARGE
PUI_BATT_XEXT
XCS_DD
DD_ON
XO_CS_DDCON
H2
O_LDO1.2_ON
O_LDO1.8_ON
CS
INIT_CHARGE_ON
BATT_SIG BATT_SIG
1
6
1
E4
D4
B5
A5
USB VBUS
SWITCH A6
B6
A1
A2
C4
A1
A2
A3
A5 D5
3
8
10
1
1
1
63
B2
B1
4
E6
A4
Q4305
ACV
DETECT A4
D1
C1
F2
O_SYS_DD_ON
D2F1
SYS_DD_ON_IC_4302 SYS_DD_ON_IC_4302
F2
E1
Q4304
BATT
DETECT
DC JACK
DETECT
F5 DD_ON
MAIN_UNREG_SENSE
AF10
AJ20
AE21
R25
R26
T25
Y10
P24
HDR-CX250/CX250E/CX260E/CX260V/CX260VE/CX270E/CX270V_L3
4-4. POWER BLOCK DIAGRAM (2/2) ( ) : Number in parenthesis ( ) indicates the division number of schematic diagram where the component is located.
4-4E
HDMI OUT
A/V R
CN1002
FP-1487
FLEXIBLE
BOARD
PD-458 BOARD
CN6201
BL_H, BL_L
BL_H, BL_L
EP_2.8V
CN1033 CN6203
L6201
SE6201
PANEL
NORMAL/
REVERSE
DETECT
EP_2.8V
3.0 INCH
WIDE COLOR
LCD
LCD901
(LCD MODULE)
LCD BACKLIGHT
D_3.3V
2.8V REG
VOUT
VIN
ON_OFF
IC9201
L9214
CN9201
CN6207
D_3.3V
D_2.8V
D_3.3V
D_2.8V
L9201
L9202
RF AMP
IC9202
IC9203
GP-037 BOARD
FLEXIBLE
FLAT
CABLE
(FFC-283)
Q1006
LENS
BLOCK
D_2.8V
CN1003
D_1.2V
D_1.8V
A_1.8V
D_2.8V
LANC_DC
TE0_VCC
MT_5.0V
MSX_3.3V
BATT_LI_3V
EVER_3.0V
A_2.8V
CPU,
AV SIGNAL PROCESS,
LENS CONTROL,
MODE CONTROL,
HDMI PROCESS
IC1301
(2/2)
(2/14 - 4/14)
AVDD18_SUBL
VC-652 BOARD (2/2)
BL_H,BL_L
XZM_RST_LED
GPIO_SB__2
2.8V REG
Vout
VDD
CE
IC6201
D_3.3V
D_2.8V
CN6702
CN1008
CM-123 BOARD
CMOS
IMAGER
CP001
FP-1484
FLEXIBLE
BOARD
I/O_1.8V
CAM_1.2V
CMOS_A_3.3V
2.8V REG.
OUT A_2.8V
CE
IN
IC6703
AVDD18_SUBL
CAM_1.2V
A_3.3V
FP-1485
FLEXIBLE
BOARD
CN1031
D_2.8V
D8001
(MS ACCESS)
MS-477 BOARD
CN8002 CN8001
MSX_3.3V
TE0_VCC
A_2.8 PITCH/ YAW
SENSOR
SE7501
(1/2)
BT8001
LITHIUM
BATTERY
MSX_3.3V
TE0_VCC
D_2.8V
A_2.8
BATT_LI_3V BATT_LI_3V
ROLL SENSOR
AMP
(13/14)
IC7701
ROLL
SENSOR
(13/14)
SE7701
A_2.8V L7701
STEADYSHOT
PROCESSOR
(12/14)
IC5501
MT_5.0V
D_2.8V
D_1.2V
LENS BARRIER
DRIVE
(12/14)
IC5502
MT_5.0V
MR_A_2.8V
A_3.3V
2.8V REG
(11/14)
OUT
CE
VDD
IC5202
CLOCK
GENERETOR
(2/14)
IC1302
A_2.8V
AUDIO
INTERFACE
(5/14)
IC2401
D_1.8V
AU_2.8V
Q2401
MT_5.0V
D_2.8V
AUDIO DSP
(7/14)
IC3001
D_2.8V
D_1.2V
CN1034
HDMI_5.0V
FP-1516
FLEXIBLE
BOARD
CN1036
JK-402
BOARD
CN1001CN1002
LANC_DC LANC_DC
PANEL
OPEN/CLOSE
DETECT
(1/14)
SE1001
EVEV_3.0V
CONTROL
SWITCH
BLOCK
(PS37500)
D_2.8V
CN1021
EVER_3.0V
POWER (1/2)
(PAGE 4-3)
A
A_1.125V
A_1.8V
A_2.8V
A_3.3V
D_1.8V
D_2.8V
D_3.3V
MEDIA_3.3V
TE0_VCC
TE1_VCC
A_VID_1.1V
D_1.2V
D_2.8V_IC_1301_1
D_2.8V_IC_1301_2
D_1.8V_IC_1301_2
D_1.8V_IC_1301_1
D_1.8V_IC_1301_3
EP_2.8V
CAM_1.2V
MSX_3.3V
BATT_LI_3V
AVDD18_SUBL
CAM_1.2V
HDMI_5.0V
AU_2.8V
A_3.3V
D_1.125V
2.9V REG
(1/2)
VOUT
CE
VDD
IC8701
IC8101
INTERNAL
MEMORY
(1/2)
MEDIA_3.3V
CN1009
IM Model
GPS Model
MMC_PWR_ON1
TE1_VCC
D_3.3V
D_VID_1.1V
MEDIA_3.3V
MMC_PWR_ON1
FP-1486
FLEXIBLE
BOARD
MM-102 BOARD
CN8101
MEDIA_3.3V
MMC_PWR_ON1
TE1_VCC
TE1_VCC
MEMORY
STICK
PRO DUO
SD
GPIO_S__4
D_VID_1.1V
A_VID_1.1V
L7501
GPS
RECEIVER
IC9204
TX1/I2CC/GIO14
17,18
23,22
16
38, 39
26
24
26
34
1
2
3
7
6
2
3
8, 10
V24
3
4
1
LED
DRIVE
43
44
43
44
45
45
1
3
4
14, 15
18
27, 28
31, 3218, 19
28
40
6
MEMORY CARD
SLOT
19
12
12 34
1
43
REG
5
412
1,14
10
18
1
43
17,18
16
15
17,18
16
15
P26
G2
HDR-CX250/CX250E/CX260E/CX260V/CX260VE/CX270E/CX270V_L3
5. FRAME SCHEMATIC DIAGRAMS
5-1E
5-1. FRAME SCHEMATIC DIAGRAM
18 1
18
1
45 1
1
45
1
39
1
39
BUILT-IN
USB CABLE
CHARGE
PLUG IN POWER
Flexible Flat Cable (FFC-283)
1238
39
15
67
16
7
8
9
5
114
1
16
2119
23
22
21
20
CN1001
CN1003
CN9101
CN9102
CN1021
CN1026
CN1034
1
244
45
118
12
16
16
1
1
16
16
1
45
1
1
45
244
45
2
139
38
1
17 16
18
CN1008 CN1009
CN1010
CN1024
CN1025
IC1301
(Not supplied)
CN1031
CN1033
CN1036
1238
39
1
76
8
1
238
39
18
CN6201
CN6202
CN6203
CN6207
18
CN9201
1
29
26
30
2728
CN8001
1
244
45 CN8002
SE7501
(PITCH/YAW)
118
CN8101
1
17
16
18
16297
3
845
10
11
12
13
14
CN1001
CN1002
J1001
1
244
45
CN6702
S8002
BH8001 S8005
S8003
VC-652 BOARD
(SIDE A) VC-652 BOARD
(SIDE B)
FP-1487 FLEXIBLE BOARD
FP-1485 FLEXIBLE
BOARD
PD-458 BOARD
FP-1516
FLEXIBLE
BOARD
JK-402
BOARD
(SIDE A)
FP-1486
FLEXIBLE
BOARD
FP-1484 FLEXIBLE
BOARD
JK-402
BOARD
(SIDE B)
MS-477 BOARD (SIDE B) MS-477 BOARD (SIDE A)
MM-102 BOARD
(SIDE A)
HDMI OUT
(USB)
SP901
(SPEAKER)
DC IN
BATTERY
TERMINAL
J901
DC JACK
CONTROL
SWITCH
BLOCK
(PS37500)
LENS BLOCK
MIC901
(MIC UNIT)
LENS
BARRIER
UNIT
CPC
(FOR CHECK)
IM Model
GPS Model
GP-037 BOARD
(SIDE B)
LCD901
(LCD MODULE)
3.0 INCH
WIDE COLOR
LCD
BACKLIGHT
TOUCH
PANEL
A/V R
RESET
POWER
CM-123
BOARD
(SIDE B)
CM-123
BOARD
(SIDE A)
LITHIUM
BATTERY
BT8001
6-1
HDR-CX250/CX250E/CX260E/CX260V/CX260VE/CX270E/CX270V_L3
6. SCHEMATIC DIAGRAMS AND PRINTED WIRING BOARDS
– ENGLISH – – JAPANESE –
Precautions for Replacement of Imager
• If the imager has been replaced, carry out all the adjustments
for the camera section.
• As the imager may be damaged by static electricity from its
structure, handle it carefully like for the MOS IC.
In addition, ensure that the receiver is not covered with dusts
nor exposed to strong light.
イメージャ交換時の注意
・ イメージャを交換した場合は，カメラ部の全調整を行って
ください。
・ イメージャは構造上，静電気により破壊される恐れがある
ため，MOSICと同様に注意して取り扱ってください。
また，受光部にはゴミの付着，および強い光がはいること
のないように注意してください。
The components identified by mark 0
or dotted line with mark 0are critical
for safety.
Replace only with part number specified.
Les composants identifiés par une mar-
que 0sont critiques pour la sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
When indicating parts by reference num-
ber, please include the board name.
0印の部品，または0印付の点線で囲まれた部品は，
安全性を維持するために，重要な部品です。
従って交換時は，必ず指定の部品を使用してください。
図面番号で部品を指定するときは基板名又はブロック
を併せて指定してください。
お願い
THIS NOTE IS COMMON FOR SCHEMATIC DIAGRAMS AND PRINTED WIRING BOARDS
(In addition to this, the necessary note is printed in each block)
回路図，プリント図共通ノート
（他に必要なノートは各セクションに記載しています）
For Schematic Diagrams
• All capacitors are in μF unless otherwise noted. pF :
μF. 50 V or less are not indicated except for electrolytics
and tantalums.
• Chip resistors are 1/10 W unless otherwise noted.
kΩ=1000 Ω, MΩ=1000 kΩ.
• Caution when replacing chip parts.
New parts must be attached after removal of chip.
Be careful not to heat the minus side of tantalum capacitor,
Because it is damaged by the heat.
• Some chip part will be indicated as follows.
Example C541 L452
22U 10UH
TA A 2520
Kinds of capacitor External dimensions (mm)
Case size
• Constants of resistors, capacitors, ICs and etc with XX
indicate that they are not used.
In such cases, the unused circuits may be indicated.
• Parts with differ according to the model/destination.
Refer to the mount table for each function.
• All variable and adjustable resistors have characteristic curve
B, unless otherwise noted.
• Signal name
XEDIT →EDIT PB/XREC →PB/REC
•: non flammable resistor
• : fusible resistor
• : panel designation
• : B+ Line
• : B– Line
• : IN/OUT direction of (+, –) B LINE.
• : adjustment for repair.
For Printed Wiring Boards
• : Uses unleaded solder.
•: Circuit board
: Flexible board
Pattern from the side which enables seeing.
: pattern of the rear side
(The other layers’ patterns are not indicated)
• Through hole is omitted.
• There are a few cases that the part printed on diagram isn’t
mounted in this model.
• : panel designation
• Chip parts.
Transistor Diode
21
3
21
3
21
3
345
21
123
654
EB
C
31
5
2
46
123
654
31
5
2
46
123
54
43
12
312
45
534
12
14
23
46
2
5
31
12
43
14
23
回路図ノート
・ ケミコン，タンタルを除くコンデンサで，耐圧50V以下の
ものはその耐圧を省略。単位はすべてμF（pはpF）。
・ チップ抵抗で指示のないものは，1/10W以下。
kΩ＝1000Ω，MΩ＝1000kΩ
・ チップ部品交換時の注意
取り外した部品は再使用せず，未使用の部品をご使用く
ださい。
タンタルコンデンサのマイナス側は熱に弱いため注意し
てください。
・ チップ部品には下記のように表示したものがあります。
例 C541 L452
22U 10UH
TA A 2520
種類 外形寸法（mm）
ケースサイズ
・ 抵抗，コンデンサ，ICなど定数にXXがあるものは，使用
していない事を示しています。このため，使用していな
い回路が記載されている事があります。
・ ★印のある部品は，機種などにより異なりますので機能
別マウント一覧表を参照してください。
・ 可変抵抗と半固定抵抗で，B特性の表示を省略。
・ 信号名表記について，下記のような場合があります。
XEDIT → EDIT PB/XREC → PB/REC
・ は不燃性抵抗。
・ はヒューズ抵抗。
・ はパネル表示名称。
・ はB＋ライン。
・ はB−ライン。
・ はBライン（＋，−）の入出力方向を示す。
・ は調整名称。
プリント図ノート
・ ：無鉛半田を使用しています。
・ ：基板
：フレキシブル配線板
見ている面側のパターン。
：裏側のパターン
（他のパターンについては表示されていません）
・ スルーホールは省略。
・ プリント図には，本機で使用していない部品が記載され
ている場合があります。
・ はパネル表示名称。
• Chipparts.
Transistor Diode
21
3
21
3
21
3
345
21
123
654
EB
C
31
5
2
46
123
654
31
5
2
46
123
54
43
12
312
45
534
12
14
23
46
2
5
31
12
43
14
23
6-2
HDR-CX250/CX250E/CX260E/CX260V/CX260VE/CX270E/CX270V_L3
6-1. SCHEMATIC DIAGRAMS
FP-1484
FLEXIBLE
LND002
(PAGE 6-10)
XCLR
XVS
XHS
XVS
XHS
XCLR
Note: CP001 (COMS IMAGER) is not supplied, but this
is included in CM-123 COMPLETE BOARD.
123456789
A
B
C
D
E
F
A
B
C
D
E
F
08
CM-123 BOARD
CMOS IMAGER
XX MARK: NO MOUNT
C6729
1u
C6728
1u
C6706
0.1u C6714
0.1u
C6707
1u C6712
0.001u
C6713
2.2u
C6703
1u
C6719
1u
C6718
0.1u
C6701
0.1u
C6710
1u
C6711
0.1u
C6715
4.7u
C6717
0.1u
C6716
0.1u
C6708
1u
C6709
0.1u
I/O_1.8V
CMOS_A_3.3V
CAM_1.2V
REG_GND
REG_GND
REG_GND
A_2.8V
DOAP
DOBP
DOCM
DOBM
DOAM
A_2.8V
DCKP
DOFM
DCKM
DOHP
DOFP
DOGP
DOGM
DODP
DODM
DOHM
DOEP
DOEM
DOCP
R6741
XX
R6704
XX
R6707
47k
R6706
XX
R6703
XX
R6705
XX
R6701
XX
R6767
XX
R6702
XX CP001
IMX116CHL-13
A9
VDDHDA
A8
VSSHDA
A4
VDDHCP
A3
VSSHCP
M1
NC(4)
B5
VDDHCM1
M7
NC(6)
B9
VDDHCM2
M8
NC(6)
A7
VSSHPX
B6
VSSHPX
A5
VDDHPX
L10
NC(7)
L11
NC(7)
M10
NC(7)
C4
VDDSUB
M11
NC(7)
F2
XCLR
G1
XVS
G3
XHS
G2
XCE
F3
SCK
F1
SDI
E1
SDO
K2
INCK
M9
NC(6)
A1
NC(1)
K10
DOAM
K11
DOAP
J10
DOBM
J11
DOBP
H10
DOCM
H11
DOCP
G10
DODM
G11
DODP
F10
DOEM
F11
DOEP
E10
DOFM
E11
DOFP
D10
DOGM
D11
DOGP
C10
DOHM
C11
DOHP
A2
NC(1)
B1
NC(1)
B2
NC(1)
G9
DCKM
H9
DCKP
D3
NC(2)
E2
NC(3)
E3
NC(3)
L1
TSCANEN
L2
TENABLE
M2
TOUT
M6
NC(5)
A10
ASMON1
B10
ASMON2
A11
NC(8)
B11
NC(8)
A6
VLOADLM
M5
NC(5)
B7
VBGR
B8
VEXRES
C5
NC(9)
C6
NC(9)
B4
VRLS
B3
VRLT
C7
NC(9)
M4
NC(5)
K1
VDDLPL
K3
VSSLPL
M3
NC(5)
C1
VDDLSC
J1
VDDLSC
C2
VSSLSC
J2
VSSLSC
C9
VDDLSC
L9
VDDLSC
E9
VSSLSC
K9
VSSLSC
L7
VDDMLV
K7
VSSMLV
L6
NC(5)
L5
NC(5)
L4
NC(5)
L3
NC(5)
K6
NC(5)
K5
NC(5)
K4
NC(5)
H2
VDDMIO
C3
VSSLCB
J3
VSSLCB
C8
VSSLCB
K8
VSSLCB
D1
VDDLCN1
H1
VDDLCN1
D2
VSSLCN
H3
VSSLCN
F9
VSSLCN
J9
VSSLCN
D9
VDDLCN2
L8
VDDLCN2
C6743
0.001u
DOGP
DODP
DCKP
DOBP
DCKM
DODM
DOAM
DOEM
DOEP
DOBM
DOCP
DOCM
DOFP
DOFM
DOGM
DOAP
SDO
REG_GND
REG_GND
REG_GND
REG_GND
REG_GND
CMOS_A_3.3V
REG_GND
I/O_1.8V
SCK
REG_GND
REG_GND
REG_GND
REG_GND
CAM_1.2V
REG_GND
REG_GND
SDI
REG_GND
INCK
XCE
REG_GND
R6728 XX
LF6719
XX
2
1
34
LF6717
XX
2
1
34
LF6718
XX
2
1
34
LF6712
XX
2
1
34
LF6714
XX
2
1
34
LF6715
XX
2
1
34
LF6713
XX
2
1
34
LF6716
XX
2
1
34
CN6702 45P
1 REG_GND
2 CLK_CMOS_IN
3 REG_GND
4 XFLASH_RST
5 REG_GND
6 SENSXCE
7SENSSCK
8REG_GND
9 SENSSO
10 SENSSI
11 SENS_HD
12 SENS_VD
13 REG_GND
14 REG_GND
15 SUBL_DINN9
16 SUBL_DINP9
17 REG_GND
18 SUBL_DINN8
19 SUBL_DINP8
20 REG_GND
21 SUBL_DINN7
22 SUBL_DINP7
23 REG_GND
24 SUBL_DINN6
25 SUBL_DINP6
26 REG_GND
27 SENSE_CLK_M
28 SENSE_CLK_P
29 REG_GND
30 SUBL_DINN5
31 SUBL_DINP5
32 REG_GND
33 SUBL_DINN4
34 SUBL_DINP4
35 REG_GND
36 SUBL_DINN3
37 SUBL_DINP3
38 REG_GND
39 SUBL_DINN2
40 SUBL_DINP2
41 REG_GND
42 REG_GND
43 I/O_1.8V
44 CAM_1.2V
45 CMOS_A_3.3V
REG_GND
DOHP
DOHM
LF6720
XX
2
1
34
SCK
SDI
SDO
XCE
CL008
R6708 1k
C6745
XX
INCK
CL009
CL010
CL007
R6709 XX
REG_GND
CL006
C6746
0.1u
C6747
1u
C6749
4.7u
C6750
4.7u
C6751
4.7u
C6752
4.7u
MM3404A28URE
IC6703
1
CE
2
GND
OUT
3
IN
4
R6729
XX
C6753 XX
CMOS IMAGER
2.8V REG
6-3
HDR-CX250/CX250E/CX260E/CX260V/CX260VE/CX270E/CX270V_L3
LCD_XHD
LCD_XVD
XBB_RST
XGPS_RST
CLK_CMOS_IN_IMG
XFLASH_RST
SENS_HD
SENS_VD
FR_XRESET
FP-1487
FLEXIBLE
LND001
(PAGE 6-24)
FP-1484
FLEXIBLE
LND001
(PAGE 6-10)
FP-1486
FLEXIBLE
LND002
(PAGE 6-24)
FP-1485
FLEXIBLE
LND001
(PAGE 6-15)
FP-1516
FLEXIBLE
LND002
(PAGE 6-24)
MIC901 and LENS BARRIER UNIT are not included
in VC-652 COMPLETE BOARD (SERVICE).
Note:
J901, SP901 and CONTROL SWITCH BLOCK (PS37500)
are not included in VC-652 COMPLETE BOARD (SERVICE).
Note:
LENS BLOCK is replaced as block,
so that PRINTED WIRING BOARD and
SCHEMATIC DIAGRAM are omitted.
Note:
123456789
A
B
C
D
E
F
A
B
C
D
E
F
08
VC-652 BOARD (1/14)
CONNECTOR
XX MARK: NO MOUNT
HDMI_5V
GPS_UART_CTS
MSX_INS_HIZ
TE0_XSDCD
TE0_SDWP
VR1009
XX
EVER_3.0V
SHUTTER_A
CN1010 2P
1SHUTTER_XA
2SHUTTER_A
D1001
DZ2S12000K8
C1001
0.1u
REG_GND
REG_GND
XPANEL_POWER_ON
Q1001
DSC300100L
SHUTTER_XA
CN1003 39P
1 FOCUS_A
2 FOCUS_XA
3 FOCUS_XB
4 FOCUS_B
5 REG_GND
6 LENS_TEMP_AD
7 FC_SENSE
8 FORCUS_PI_A
9 ZM_SENSE1A
10 ZOOM_PI_A
11 REG_GND
12 ZOOM_XB_OUT
13 ZOOM_XA_OUT
14 ZOOM_B_OUT
15 ZOOM_A_OUT
16 REG_GND
17 IRIS_DRIVE+
18 IRIS_DRIVE-
19 REG_GND
20 I_BIAS+
21 I_HALL+
22 I_BIAS-
23 I_HALL-
24 REG_GND
25 YAW-
26 YAW+
27 PITCH+
28 PITCH-
29 REG_GND
30 PITCH_BIAS-
31 PITCH_HALL-
32 PITCH_BIAS+_1450A
33 PITCH_HALL+
34 YAW_BIAS+_1450A
35 YAW_HALL+
36 YAW_BIAS-
37 YAW_HALL-
38 REG_GND
39 TZ_HALL_TEMP
VR1010
XX
SE1001
GMR
4
OUT
1N.C.
2GND 3
VDD
C1006
0.001u
VR1002
CN1026 2P
1SP+
2SP-
PITCH-
REG_GND
FOCUS_XA
ZOOM_XB_OUT
FOCUS_B
YAW_BIAS-
YAW-
ZOOM_A_OUT
PITCH_BIAS-
ZOOM_XA_OUT
YAW+
LENZ_TEMP_AD
PITCH+
PITCH_HALL-
FC_SENSE
PITCH_HALL+
TZ_HALL_TEMP
YAW_HALL-
ZM_SENSE1A
FOCUS_XB
FOCUS_A
ZOOM_B_OUT
Q1006
DRA3143T0L
YAW_HALL+
I_HALL-
I_BIAS-
I_HALL+
CN10256P
1
2
3
4
5
6
I_DRIVE+
I_DRIVE-
AUDIO_GND
INT_MIC_L
INT_MIC_R
REG_GND REG_GND
CN100918P
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
VD1001
XX
CN1034
19P
1REG_GND
2HDMI_TX2SOP
3HDMI_TX2SON
4REG_GND
5HDMI_TX1SOP
6HDMI_TX1SON
7REG_GND
8HDMI_TX0SOP
9HDMI_TX0SON
10 REG_GND
11 HDMI_TXCP
12 HDMI_TXCN
13 REG_GND
14 CEC
15 SCL
16 SDA
21 REG_GND
22
REG_GND 20 REG_GND
23
REG_GND
17 N.C.
18 HDMI_5V
19 HPD
CN10016P
1
2
3
4
5
6
CN1031
45P
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
CN10246P
1
2
3
4
5
6
REG_GND
CN103339P
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
C1008
XX C1009
XX C1010
XX C1011
XX
CN1021 14P
1 MODE_LED_VDD
2XCAM_LED
3 XPHOTO_LED
4 XMODE_SW
5 REG_GND
6 XSTART/STOP
7 PHOTO_FREEZE
8 REG_GND
9 PHOTO_REC
10 CHARGE_LED_VDD
11 XCHARGE_LED
12 REG_GND
13 ZOOM_VR_AD
14 D_2.8V
CN1008
45P
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
CN1036
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
D_1.8V
C1012
0.01u
REG_GND
REG_GND
R1046 XX
R1001
1M
R1033
1k R1034
6800
R1050 XX
R1017 220
R1026 XX
R1044
XX
R1018
1k
R1030
2700
R1052 0
R1049 XX
R1032
680
R1025 0
R1047 XX
R1031
47
R1051 XX
R1048 330
R1043
XX
R1045 XX
R1020
XX
(SPEAKER)
SP901
PANEL
OPEN/CLOSE
DETECT
INVERTER
LED DRIVE
LENS
BLOCK
MICROPHONE
UNIT
MIC901
UNIT
BARRIER
LENS
(PS37500)
SWITCH
BLOCK
CONTROL
DC IN
(DC JACK)
BATTERY
TERMINAL
J901
HDMI OUT
SP+
SP-
XZM_RST_LED
D_2.8V
I_BIAS+
MR_A_2.8V
LCD_D0
LCD_D7
REG_GND
LCD_D4
LCD_D2
REG_GND
LCD_D1
LCD_D3
REG_GND
LCD_D5
LCD_D6
REG_GND
LCD_CLK
REG_GND
LCD_HS
LCD_VS
AV_SCK
D_1.8V
XCS_LCD
AV_SO
XBB_RST
BL_L
BL_H
EP_2.8V
SYSTEM_AD
REG_GND
TP_Y
TP_X
TP_SEL1
PALEL_NOR/REV
REG_GND
XGPS_RST
REG_GND
D_3.3V
REG_GND
GPS_UART_TXD
GPS_UART_CTS
GPS_UART_RXD
GPS_UART_RTS
D_2.8V
REG_GND
SS
EVER_3.0V
ZOOM_VR_AD
XCHARGE_LED
KEY_AD1
XPHOTO_LED
XCAM_LED
ACV_GND
ACV_UNREG_CN
BATT/XEXT_CN
BATT_UNREG_CN
BATT_SIG_CN
BATT_GND
BATT_UNREG_CN
ACV_UNREG_CN
BATT_SIG
BATT/XEXT_CN
REG_GND
REG_GND
AUDIO_GND
AUDIO_GND
INT_MIC_L
AUDIO_GND
AUDIO_GND
INT_MIC_R
LCD_DATA[4]
AV_SO
LCD_DATA[5]
LCD_DATA[1]
BL_L
LCD_CLK
XCS_LCD
AV_SCK
LCD_DATA[7]
LCD_DATA[3]
LCD_DATA[2]
LCD_DATA[6]
TP_SEL1
LCD_DATA[0]
TP_Y
TP_X
BL_H
SYSTEM_AD
EP_2.8V
PANEL_NOR/REV
GPS_UART_RXD
GPS_UART_RTS
GPS_UART_CTS
GPS_UART_TXD
D_3.3V
GENERAL_AD
D_2.8V
REG_GND
CEC
REG_GND
SCL
HDMI_TX2SOP
HDMI_TXCN
REG_GND
HDMI_TX2SON
REG_GND
HDMI_TX1SOP
HDMI_TX1SON
REG_GND
REG_GND
REG_GND
HDMI_TX0SOP
SDA
REG_GND
REG_GND
HDMI_TXCP
HDMI_TX0SON
HDMI_5V
HPD
AUDIO_GND
EXT_MIC_L
AUDIO_GND
EXT_MIC_R
AUDIO_GND
COMPO_VIDEO
REG_GND
AUDIO_L_I/O
REG_GND
AUDIO_R_I/O
REG_GND
LANC_DC
REG_GND
JACK_AD
LANC_SIG
REG_GND
AUDIO_GND
EXT_MIC_R
EXT_MIC_L
AUDIO_L_I/O
LANC_SIG
LANC_DC
AUDIO_R_I/O
JACK_AD
COMPO_VIDEO
REG_GND
CLK_CMOS_IN
REG_GND
XFLASH_RST
REG_GND
SENSXCE
SENSSCK
REG_GND
SENSSO
SENSSI
SENS_HD
SENS_VD
REG_GND
REG_GND
SUBL_DINN9
SUBL_DINP9
REG_GND
SUBL_DINN8
SUBL_DINP8
REG_GND
SUBL_DINN7
SUBL_DINP7
REG_GND
SUBL_DINN6
SUBL_DINP6
REG_GND
DCKM
DCKP
REG_GND
SUBL_DINN5
SUBL_DINP5
REG_GND
SUBL_DINN4
SUBL_DINP4
REG_GND
SUBL_DINN3
SUBL_DINP3
REG_GND
SUBL_DINN2
SUBL_DINP2
REG_GND
REG_GND
AVDD18_SUBL
CAM_1.2V
A_3.3V
AVDD18_SUBL
CAM_1.2V
A_3.3V
SUBL_DINN7
SUBL_DINN5
SUBL_CLKINP
SUBL_DINP5
SUBL_DINP8
SUBL_DINP4
SUBL_DINN3
SUBL_DINP9
SUBL_DINN6
SUBL_DINN2
SUBL_DINN4
SUBL_CLKINN
SUBL_DINP7
SUBL_DINN9
SUBL_DINP2
SUBL_DINP3
SUBL_DINP6
SUBL_DINN8
IC_1301_SENSSO
IC_1301_SENSSI
IC_1301_SENSXCS
IC_1301_SENSSCK
REG_GND
REG_GND
DEBUG_UART0_TXD
DEBUG_UART0_RXD
BOOT_MODE_1
D_2.8V
N.C.
DEBUG_UART0_TXD
DEBUG_UART0_RXD
BOOT_MODE_1
REG_GND
D_2.8V
TE1_DAT_1
TE1_CLK
TE1_CMD
TE1_DAT_4
TE1_DAT_6
TE1_DAT_0
TE1_DAT_7
TE1_DAT_2
TE1_VCC
TE1_DAT_5
TE1_DAT_3
REG_GND
MMC_PWR_ON1
MEDIA_3.3V
REG_GND
IM Model
TE1_DAT_7
TE1_DAT_2
TE1_DAT_6
TE1_DAT_1
TE1_DAT_5
TE1_DAT_0
TE1_DAT_4
TE1_DAT_3
REG_GND
TE1_CLK
REG_GND
TE1_CMD
REG_GND
TE1_VCC
MMC_PWR_ON1
MEDIA_3.3V
MEDIA_3.3V
PITCH_AD
REG_GND
YAW_AD
REG_GND
REG_GND
A_2.8V
TE0_SDWP_CN
CRESET_P
XSD_INS_CN
REG_GND
TE0_DAT_1
BATT_LI_3V
TE0_DAT_0
MSX_3.3V
MSX_3.3V
XMS_ACC_LED
REG_GND
SIGN10037
REG_GND
REG_GND
MSX_CLK
REG_GND
TE0_CLK
REG_GND
XMS_IN_
FR_XRESET
TE0_VCC
TE0_VCC
MSX_BIO_3
REG_GND
MSX_BIO_2
REG_GND
MSX_BIO_0
REG_GND
MSX_BIO_1
REG_GND
MSX_BS
XPOWER_TACT_SW
TE0_CMD
KEY_AD2
REG_GND
REG_GND
TE0_DAT_3
TE0_DAT_2
REG_GND
TE0_DAT_2
TE0_SDWP
YAW_AD
TE0_DAT_1
D_2.8V
CRESET_P
TE0_XSDCD
MSX_BIO_3
TE0_CMD
MSX_CLK
MSX_BS
TE0_VCC
MSX_BIO_1
TE0_DAT_0
MSX_BIO_2
MSX_3.3V
XMS_ACC_LED
MSX_INS_HIZ
MSX_BIO_0
PITCH_AD
TE0_CLK
TE0_DAT_3
BATT_LI_3V
XPOWER_TACT_SW
KEY_AD2
A_2.8V
A_3.3V
CPC
(FOR CHECK)
6-4
HDR-CX250/CX250E/CX260E/CX260V/CX260VE/CX270E/CX270V_L3
CLK_CMOS_IN_IMG
SENS_VD
SENS_HD
CLK_CMOS_IN
IC_5201_VD
XBB_RST
XSYS_RST
XGPS_RST
CLK_SYS_IN
CLK_CMOS_IN
CLK_SYS_IN
IC1301 is not supplied, but this is included
in VC-652 COMPLETE BOARD (SERVICE).
Note:
123456789
A
B
C
D
E
F
A
B
C
D
E
F
08
VC-652 BOARD (2/14)
CPU, AV SIGNAL PROCESS, LENS CONTROL,
MODE CONTROL, HDMI PROCESS (1/3)
XX MARK: NO MOUNT
A_2.8V
VST_C_CHARGE
R1313 XX
COMPO_VIDEO
L1301 XX
C1323
0.1u
C1326 XX
R1331 270
R1320 XX
C1314
10u
R1319 XX
C1313
10u
R1321 6800
R1307 XX R1315 180
R1335 1k
R1302 XX
Q1302
SSM6N37FE,RSONYM
6
1
52
4
3
Q1301
SSM3K37MFV,L3SOF
R1343
1800
R1342
1800
R1303 XX
R1318 XX
REG_GND
C1305
0.1u
C1306
0.1u
C1301
XX C1304
0.1u C1310
0.1u
C1302
10u
C1307
0.1u
C1308
0.1u
C1309
0.1u
C1316
XX
C1317
0.1u
C1320
0.1u C1322
0.1u
C1318
0.1u
C1315
0.1u
R1332 27k
C1321
0.1u
R1340 XX
C1325
0.1u
C1303
10u
D1304
1SS413(TPL3)
D1303
1SS413(TPL3)
A20
B20
A19
C13
A14 IOVDD_MERGE1
B13 VSS
V29 AVDD11_SUBL
W29 AVDD11_SUBL
Y29 AVDD11_SUBL
AB31
AVDD11_SUBL
AB30
AVDD11_SUBL
L29 AVDD18_SUBL
K29 AVDD18_SUBL
J29 AVDD18_SUBL
H31 AVDD18_SUBL
H30 AVDD18_SUBL
M29 VSS
N29 VSS
P29 VSS
R29 VSS
T29 VSS
U29 VSS
AC31
IOVDD_CMOSSIO
Y26
VSS
AD31
IOVDD_CLKCMOS
AD29
VSS
AK17
AVDD33_USB
AL17
AVDD33_USB
AJ19
AVSS33_USB
AK19
AVSS33_USB
AL19
AVSS33_USB
AF17
AVSS33C_USB
AF16
IOVDD_USBPERI
AJ17
VSS
AE17
VSS
C19
B19
F19
C20
AD18
AD17
AB17
G19
F18
G18
H19
C17
C18
A15
B15
C15
C16
B14
C14
F16
F17
G14
F14
F15
G15
H18
H17
G17
B16
A16
H16
G16
H14
H15
AA31
AA30
Y31
Y30
W31
W30
V31
V30
U31
U30
T31
T30
P31
P30
N31
N30
M31
M30
L31
L30
K31
K30
J31
J30
R31
R30
AC30
AC29
AB29
U26
AA29
V26
W26
AD30
AJ18
AJ20
AF18
AL18
AK18
AE18
AE19
AF19
AE21
AD19
AD20
AD21
AF20
AF21
AE20
AL21
AVDD_DAC_0
AK23
AVDD_DAC_1
AL23
AVDD_DAC_2
AK21
AVSS_DAC_0
AJ21
AVSS_DAC_1
AJ23
AVSS_DAC_2
AL25
DVDD_DAC_0
AK25
DVSS_DAC_0
M1 IOVDD_AUMIC
L1 VSS
AL16
AVDD18_HDMI
AK16
AVDD_HDMI
AL9 AVDD_HDMI
AK9 AVDD_HDMI
AJ9 AVDD_HDMI
AL15
AVSS_HDMI
AK15
AVSS_HDMI
AJ15
AVSS_HDMI
AJ14
AVSS_HDMI
AL10
AVSS_HDMI
AK10
AVSS_HDMI
AJ11
AVSS_HDMI
AJ16
IOVDD_HMI2C
AH1 IOVDD_MERGE2
AJ1 VSS
AF1 IOVDD_CLK_SYS
AE3 VSS
AF31
AVDD_PLL0
AF30
AVDD_PLL1
AF29
AVDD_PLL1
AF26
AVDD_PLL2
AF25
AVDD_PLL2
AK24
AL24
AJ25
AK26
AL26
M6
M2
M3
AL11
AK11
AL12
AK12
AL13
AK13
AL14
AK14
AJ12
AJ13
AJ10
HDMI_REXT
AF13
HDMI_SDA
AF14
HDMI_SCL
AF15
AJ8
AK7
AL7
AJ6
AK6
AL6
AJ7
AF9
AF10
AD10
AA10
AB10
AE10
AE9
AD15
AD16
AE16
AA13
AB13
AB18
AD14
AA14
AB15
AA15
AB14
AH3
AH2
AF3
AB12
AD12
AE12
AA16
AB16
AA17
AF2
AD1
AD2
AE1
AE2
AJ22
AK22
AL22
AJ24
AE25
AVSS_PLL2
AE30
AVSS_PLL1
AE26
AVSS_PLL2
AE31
AVSS_PLL0
AE29
AVSS_PLL1
C1340 10u
C1339 0.1u
1
12M
2
SEL
3
ICLK
4
REF
5
GND
6
VDD
X1302
60MHz
1
43
2
C1324
220p
CL1306
CL1307
CL1308
C1319
XX
C1327
XX
R1363 47k
R1364 47k
D_1.8V
A_2.8V A2.8V_IC_1301_1
R1304
XX
R1309 XX
D_2.8V
R1305
XX
R1306
XX
LF1301
1
2
3
4
5
6
7
8
LF1302
1
2
3
4
5
6
7
8
R1365 XX
R1366 XX
R1367 XX
R1368 XX
R1369 XX
R1370 XX
R1371 XX
R1372 XX
FB1301
R1373
82
R1374
4700
R1375
4700
COM131
COM138
COM132
COM133
COM134
COM135
COM136
COM137
C1341
XX C1342
XX
L1302 XX
FB1302
FB1303
PIsensor
DEVICE_SYNC
BEAR/ETC
USB PERI
subLVDS
USB
CMOS I/O
VDAC
HDMI
FRC_RTG
PLL
CMOS CLK IN
Digital MIC
HDMI LINKorCEC
TPU
SYSTEM
SYS CLK
Q1301, Q1302
LEVEL SHIFT
REG_GND
REG_GND
REG_GND
A2.8V_IC_1301_1
D_2.8V_IC_1301_1
D_2.8V_IC_1301_1
MODE CONTROL,
CPU, AV SIGNAL PROCESS,
LENS CONTROL,
IC1301 (1/6)
AVY1G2G04B
HDMI PROCESS
A_1.125V
REG_GND
A_1.8V
AVDD18_SUBL
A_1.125V_SENSE
A_3.3V
REG_GND
REG_GND
REG_GND
REG_GND
D_3.3V
D_1.8V_IC_1301_1
SUBL_DINP4
SUBL_DINN6
SUBL_DINP5
SUBL_DINP6
SUBL_DINP7
SUBL_DINN7
SUBL_DINN5
SUBL_CLKINP
SUBL_CLKINN
SUBL_DINN4
MIC_JACK_IN
REG_GND
REG_GND
REG_GND
SUBL_DINN9
SUBL_DINP8
SUBL_DINN8
SUBL_DINP9
SUBL_DINN2
SUBL_DINP2
SUBL_DINN3
SUBL_DINP3
IC_1301_SENSSCK
IC_1301_SENSSO
IC_1301_SENSXCS
USB_VBUS
USB_ID
VBUS_EN
VBUS_UNLIMIT
USB_ID2
REG_GND
USB_DM
USB_DP
REG_GND
REG_GND
IC_1301_SENSSI
FC_SENSE
ZM_DIR_A
ZM_DIR_B
ZM_ENB
FC_DIR_B
FC_DIR_A
FC_ENB
MIC_PWR_ON
CAM_V
D_2.8V_IC_1301_1
MSHUT_EN
IC_5501_P_LIMIT
REG_GND
ZM_SENSE1A
D_2.8V_IC_1301_1
AVDD_PI
AVSS_PI
IOVDD_PI
VSS
SENS2
SENS0
FG1A
FG1B
SYS_V
CAM_V
IC_5201_VD
MSHUT_EN
STRB_ON2_MSHUT_EN2
STRB_ON3_MSHUT_EN3
STRB_ON1
DIR2A
DIR2B
BRK2A_EN2
BRK2B
DIR1A
DIR1B
BRK1A_EN1
BRK1B
DIR0A
DIR0B
BRK0A_EN0
BRK0B
SENS1A
SENS1B
ND_DIR_A
ND_DIR_B
ND_EN
IRIS0_IC_5501_2_P_LIMIT
IRIS1
AS_PWM1A
AS_PWM1B
AS_PWM0A
AS_PWM0B
SUBL_DINP11
SUBL_DINN11
SUBL_DINP10
SUBL_DINN10
SUBL_DINP9
SUBL_DINN9
SUBL_DINP8
SUBL_DINN8
SUBL_DINP7
SUBL_DINN7
SUBL_DINP6
SUBL_DINN6
SUBL_DINP5
SUBL_DINN5
SUBL_DINP4
SUBL_DINN4
SUBL_DINP3
SUBL_DINN3
SUBL_DINP2
SUBL_DINN2
SUBL_DINP1
SUBL_DINN1
SUBL_DINP0
SUBL_DINN0
SUBL_CLKINP
SUBL_CLKINN
SENS_VD
SENS_HD
SENSSCK
SENSSO
SENSSI
SENSXCS
CIS_SHT_RST
CLK_CMOS_IN
USB_TXRTUNE
USB_VBUS
USB_ID
USB_DP
USB_DM
USB_XO
USB_XI
USB_ANALOGTEST
VBUS_EN
VBUS_UNLIMIT
USB_ID_EXT
USB_CHG_EN
USB_CHG_HL
USB_PWR_EN
USB_ACV_DET
A_2.8V
REG_GND
REG_GND
REG_GND
A_1.125V
A_1.8V
REG_GND
D_2.8V_IC_1301_2
MODE CONTROL,
CPU, AV SIGNAL PROCESS,
LENS CONTROL,
IC1301 (2/6)
AVY1G2G04B
HDMI PROCESS
REG_GND
D_2.8V_IC_1301_2
D_2.8V_IC_1301_2
REG_GND
A_1.125V
D_1.8V_IC_1301_2
LENSV_EN
IC_5501_INT_REQ
XIC_5201_RST
IC_5501_IC_5201_CLK
XRESET_REQ
SD_PWR_ON
LENS_COVER_DIR_PWM
REG_GND
XBUSY_HS0_MAGIC
XCS_MAGIC
XINT_HS1_MAGIC
HDMI_TX0SON
HDMI_TX2SOP
HDMI_TX2SON
HDMI_TXCN
HDMI_TXCP
HDMI_TX1SOP
HDMI_TX1SON
HDMI_TX0SOP
REG_GND
HDMI_5V
SCL
SDA
CEC
D_2.8V_IC_1301_2
D_2.8V_IC_1301_1
D_2.8V_IC_1301_2
DAC_IOUTN_A_Pr
DAC_IOUTP_B_Pb
DAC_IOUTN_B_Pb
DAC_IOUTP_C_Y
DAC_IOUTN_C_Y
DAC_VREF
DAC_IREF
DAC_VBP
DAC_IOUTP_A_Pr
DIG_MIC_CLK
SDI3
SDI2
HDMI_TX2SOP
HDMI_TX2SON
HDMI_TX1SOP
HDMI_TX1SON
HDMI_TX0SOP
HDMI_TX0SON
HDMI_TXCP
HDMI_TXCN
HDMI_CKREFP
HDMI_CKREFN
CEC_INOUT
TPU5_OUT
TPU4_OUT
TPU3_OUT
TPU2_OUT
TPU1_INA_OUT
TPU1_INB
TPU0_INA_OUT
TPU0_INB
FRC_RTG_IN1
FRC_RTG_IN0
FRC_RTG_OUT3
FRC_RTG_OUT2
FRC_RTG_OUT1
FRC_RTG_OUT0
EXTIN_CLK2
EXTIN_CLK1
EXTIN_CLK0
EXTOUT_CLK1
EXTOUT_CLK0
IC_5501_IC_5201_CLK
BYPASS_PLL_1
BYPASS_PLL_0
PLL_MODE_0
DDRCKSEL
PLL3_FREQ_SEL
XRESET_REQ
XRESET
TEST_MODE
DEBUG_MODE_2
DEBUG_MODE_1
DEBUG_MODE_0
BOOT_MODE_2
BOOT_MODE_1
BOOT_MODE_0
CLK_SYS_IN
AVDD_PLL3
AVDD_PLL4
AVSS_PLL3
AVSS_PLL4
BOOT_MODE_1
REG_GND
A_1.8V
IC1302
AK8153AU-L
CLOCK
GENERATOR
D_1.8V_IC_1301_3
D_1.8V_IC_1301_1
D_1.8V_IC_1301_2
6-5
HDR-CX250/CX250E/CX260E/CX260V/CX260VE/CX270E/CX270V_L3
LCD_XHD
LCD_XVD
XIC_5501_CPU_RST
IC1301 is not supplied, but this is included
in VC-652 COMPLETE BOARD (SERVICE).
Note:
FB1414 and FB1415 are not supplied, but they are included
in VC-652 COMPLETE BOARD (SERVICE).
Note:
123456789
A
B
C
D
E
F
A
B
C
D
E
F
08
VC-652 BOARD (3/14)
CPU, AV SIGNAL PROCESS, LENS CONTROL,
MODE CONTROL, HDMI PROCESS (2/3)
XX MARK: NO MOUNT
R1413
47
R1414
150
R1409 82
R1410 150
R1404 XX
R1405 XX
REG_GND
R1407 XX
R1408 XX
R1422 47
R1421 100
R1423 47
C1407
0.1u
C1409
0.1u
C1411
0.1u
R1403 XX
C1412
0.1u
C1413
0.1u
C1421
0.1u
C1422
0.1u
C1423
XX
C1424
0.1u
C1428
0.1u
C1438
0.1u
C1439
0.1u
C1431
0.1u C1435
0.1u C1446
0.1u
C1441
0.1u
C1433
0.1u C1437
0.1u C1447
0.1u
A9 IOVDD_MERGE1
B9 IOVDD_MERGE1
D3 VSS
D4 VSS
AG1 IOVDD_I2C
AJ2 VSS
AL5 IOVDD_MERGE2
AJ3 VSS
G1 IOVDD_AU
F3 VSS
A21 IOVDD_MS
A26 VSS
A24 IOVDD_TE0
B26 VSS
A18 IOVDD_TE1
B18 IOVDD_TE2
A3 AVDDC_SATA
C3 AVDDC_SATA
B3 AVDDC_SATA
C4 PVDD_SATA
B2 AVDD18_SATA
C2 VTERM0_SATA
A4 AVSSC_SATA
B4 AVSSC_SATA
C5 AVSSC_SATA
C6 AVSSC_SATA
C8 AVSSC_SATA
B8 AVSSC_SATA
A8 AVSSC_SATA
G6
F6
H8
H7
G7
F7
G8
F8
AD9
AA11
AF12
AD11
AF11
AE11
AB11
AG3
AG2
AF6
AE8
AC6
AJ5
AD6
AK2
AC8
AE7
AK5
AC7
AJ4
AK4
AF8
AF7
AD8
AD7
AL3
AK3
AE6
AL4
AE13
AD13
H1
J2
J1
G2
H2
G3
H3
A23
A22
F22
F21
B23
C23
B22
C22
B21
C21
F23
A25
B25
G23
F24
C25
C26
B24
C24
L15
K15
L16
K16
L17
K17
L18
K18
L19
K19
L20
K20
K21
F20
H20
G20
H21
G21
H22
G22
A5
B5
A7
B7
A6
B6
C7
CL1402
CL1403
CL1404
CL1405
CL1406
CL1407
R1412 68
R1411 82
RB1403
47
12
34
56
78
RB1404
XX
12
34
56
78
RB1405
XX
12
34
56
78
Q1402
DRA3143T0L
RB1414
10k
12
34
56
78
RB1415
100k
12
34
56
78
RB1416
1M
12
34
56
78
RB1412
1k
12
34
56
78
RB1413
1k
12
34
56
78
D1402
DA2S10100K8
D1401
DA2S10100K8
RB1401
47
12
34
56
78
C1410
0.1u
HPD
Q1403
DMG964030R
3
5
46
2
1
R1449
XX
CL1410
R1450 XX
FB1401
FB1402
R1454
XX
FB1405
R1455 XX
D_2.8V_IC_1301_2
RB1418
47k
12
34
56
78
R1456 XX
R1458 220
R1459 220
R1460 220
R1461 220
R1462 220
R1463 220
R1464 220
R1465 220
FB1406
FB1407
FB1408
FB1409
FB1410
FB1411
FB1412
FB1413
R1467
XX
Q1404
XX
GPIO_SB_4
R1466
XX
R1468
0
R1469
XX
R1470 4700
R1471 4700
FB1414
12
34
56
78
FB1415
12
34
56
78
FB1416
D31 IOVDD_BEEP
E30 IOVSS_BEEP
A10 AVDD33_ADC0
L10 AVSS33_ADC0
B10 AVDD33_ADC1
L11 AVSS33_ADC1
P3 IOVDD_LCD_R
R8 VSS
N3 IOVDD_LCD_G
R7 VSS
P1 IOVDD_LCD_B
R6 VSS
D30
C31
G12
G11
F12
F11
F10
F9
C9
C10
C12
C11
B11
A11
L13
L12
K13
K12
K11
K10
H12
H11
H10
H9
G10
G9
N8
P8
N7
P7
N6
P6
U8
U7
V8
V7
W8
Y8
W7
Y7
W6
Y6
U6
V6
W3
V3
U3
U2
V2
V1
Y3
U1
W1
W2
Y10
Y2
K26
L24
L25
L26
M24
M25
M26
N24
N25
N26
P24
P25
P26
R24
R25
R26
T26
T24
T25
U24
U25
V24
V25
W25
K14
L14
AB1 VSS
Y1 IOVDD_CLKPNL
G31 IOVDD_MERGE1
A13 IOVDD_GPIOE
G29 VSS
R3 VSS
G30 VSS
F13 VSS
P2 IOVDD_MERGE1
TE2
TE1
TE0
MSX
DIGITAL
AUDIO I/F
CPUADC0
SYSTEM SOUND
GPIO
LCD_R/ETM
LCD_G
LCD_B
UART
SIRCS
JTAG
I2C
SIO
SATA
CPUADC1
LCD SYNC
PANEL CLK
CABC PWM
GPIO_E
SA Debug
LEVEL SHIFT
Q1402
TOUCH PANEL
INTERFACE
MODE CONTROL,
CPU, AV SIGNAL PROCESS,
LENS CONTROL,
IC1301 (3/6)
AVY1G2G04B
HDMI PROCESS
REG_GND
REG_GND
REG_GND
D_2.8V_IC_1301_1
D_2.8V_IC_1301_2
D_2.8V_IC_1301_2
REG_GND
REG_GND
MEDIA_3.3V
D_2.8V_IC_1301_1
REG_GND
TE1_VCC
REG_GND
TE0_VCC
REG_GND
SDO
TE1_DAT_7
TE1_DAT_6
TE1_DAT_5
TE1_DAT_4
TE1_DAT_3
TE1_DAT_2
TE1_DAT_1
TE1_DAT_0
TE1_CMD
TE1_CLK
TE0_CLK
TE0_CMD
TE0_DAT_2
TE0_DAT_1
TE0_DAT_3
TE0_DAT_0
TE0_XSDCD
TE0_SDWP
MSX_BS
MSX_CLK
MSX_BIO_3
MSX_BIO_2
MSX_BIO_1
MSX_BIO_0
MSX_INS_HIZ
XMIC_MONO
FR_SO
FR_SI
FR_SCK
XCS_FRONT
XCS_LCD
AV_SO
AV_SCK
XCS_IC_5201
IC_5201_SO
IC_5201_SI
IC_5201_SCK
XCS_IC_5501
IC_5501_SO
IC_5501_SI
IC_5501_SCK
LRCK_OUT
BCK_OUT
REG_GND
MCK_INOUT
MISO_SDA
DAO_D1
DEBUG_UART0_RXD
DEBUG_UART0_TXD
GPS_UART_RTS
GPS_UART_TXD
GPS_UART_RXD
GPS_UART_CTS
IC_5501_2_EXPOSE
REG_GND
REG_GND
A2.8V_IC_1301_1
A2.8V_IC_1301_1
REG_GND
A2.8V_IC_1301_1
REG_GND
D_2.8V_IC_1301_1
D_1.8V_IC_1301_1
REG_GND
REG_GND
REG_GND
REG_GND
D_2.8V_IC_1301_1
D_2.8V_IC_1301_1
REG_GND
D_2.8V
HDMI_JACK_IN
SS
VBUS_XOVR_CUR
REG_GND
PANEL_NOR/REV
MS_PWR_ON
XMS_ACC_LED
TP_SEL1
TP_SEL2
HDMI_JACK_IN
MMC_PWR_ON1
XPHOTO_LED
XZM_RST_LED
XPWR_OFF
XVBUS_DET
USB_SEL
XVBUS_DET_STD_A
GPIO_SB_4
EXT_LINE_SEL
LCD_CLK
LCD_CABC_PWM
LCD_DATA[3]
LCD_DATA[4]
LCD_DATA[7]
LCD_DATA[6]
LCD_DATA[2]
LCD_DATA[1]
LCD_DATA[0]
LCD_DATA[5]
KEY_AD1
TZ_HALL_TEMP
JACK_AD
ZOOM_VR_AD
LENZ_TEMP_AD
TP_SEL2
A_2.8V
TP_X
TP_Y
REG_GND
KEY_AD2
GPIO_SB_4
REG_GND
ROLL_AD
REG_GND
REG_GND
BEEP_PWM_N
BEEP_PWM_P
MODE CONTROL,
CPU, AV SIGNAL PROCESS,
LENS CONTROL,
IC1301 (4/6)
AVY1G2G04B
HDMI PROCESS
UART2_TXD
UART2_RXD
UART2_CTS
UART2_RTS
UART1_TXD
UART1_RXD
UART0_TXD
UART0_RXD
SIR_RXD
TDI
TCK
TMS
TDO
RTCK
nTRST
I2C_SCK
I2C_SDA
SIO4_SCK
SIO4_SCS
SIO4_TXD
SIO4_RXD
SIO3_SCK
SIO3_SCS
SIO3_TXD
SIO3_RXD
SIO2_SCK
SIO2_SCS
SIO2_TXD
SIO2_RXD
SIO1_SCK
SIO1_SCS
SIO1_TXD
SIO1_RXD
SIO0_SCK
SIO0_SCS
SIO0_TXD
SIO0_RXD
SA_TDI
SA_TDO
LRCK_OUT
BCK_OUT
MCK_INOUT
SDI1
SDI0_SPDIF_IN
SDO
SPDIF_OUT
MSX_BS
MSX_CLK
MSX_BIO_7
MSX_BIO_6
MSX_BIO_5
MSX_BIO_4
MSX_BIO_3
MSX_BIO_2
MSX_BIO_1
MSX_BIO_0
MSX_INS_HIZ
TE0_CLK
TE0_CMD
TE0_DAT_3
TE0_DAT_2
TE0_DAT_1
TE0_DAT_0
TE0_XSDCD
TE0_SDWP
TE1_DAT_7
TE1_DAT_6
TE1_DAT_5
TE1_DAT_4
TE1_DAT_3
TE1_DAT_2
TE1_DAT_1
TE1_DAT_0
TE1_CMD
TE1_CLK
TE2_DAT_7
TE2_DAT_6
TE2_DAT_5
TE2_DAT_4
TE2_DAT_3
TE2_DAT_2
TE2_DAT_1
TE2_DAT_0
TE2_CMD
TE2_CLK
SATA_RX0SIP
SATA_RX0SIN
SATA_TX0SOP
SATA_TX0SON
SATA_CKREFP
SATA_CKREFN
SATA_AMOUT
BEEP_PWM_P
BEEP_PWM_N
ADC0_IN11
ADC0_IN10
ADC0_IN9
ADC0_IN8
ADC0_IN7
ADC0_IN6
ADC0_IN5
ADC0_IN4
ADC0_IN3
ADC0_IN2
ADC0_IN1
ADC0_IN0
ADC1_IN11
ADC1_IN10
ADC1_IN9
ADC1_IN8
ADC1_IN7
ADC1_IN6
ADC1_IN5
ADC1_IN4
ADC1_IN3
ADC1_IN2
ADC1_IN1
ADC1_IN0
LCD_R_7
LCD_R_6
LCD_R_5
LCD_R_4
LCD_R_3
LCD_R_2
LCD_R_1
LCD_R_0
LCD_G_7
LCD_G_6
LCD_G_5
LCD_G_4
LCD_G_3
LCD_G_2
LCD_G_1
LCD_G_0
LCD_B_7
LCD_B_6
LCD_B_5
LCD_B_4
LCD_B_3
LCD_B_2
LCD_B_1
LCD_B_0
LCD_DATEN
LCD_CLK
LCD_XHD
LCD_XVD
LCD_CABC_PWM
EXT_PNL_CLK
GPIO_S__16
GPIO_S__15
GPIO_S__14
GPIO_S__13
GPIO_S__12
GPIO_S__11
GPIO_S__10
GPIO_S__9
GPIO_S__8
GPIO_S__7
GPIO_S__6
GPIO_S__5
GPIO_S__4
GPIO_S__3
GPIO_S__2
GPIO_S__1
GPIO_S__0
GPIO_SB__6
GPIO_SB__5
GPIO_SB__4
GPIO_SB__3
GPIO_SB__2
GPIO_SB__1
GPIO_SB__0
GPIO_EB__0
GPIO_E__0
6-6
HDR-CX250/CX250E/CX260E/CX260V/CX260VE/CX270E/CX270V_L3
XFLASH_RST
IC1301 is not supplied, but this is included
in VC-652 COMPLETE BOARD (SERVICE).
Note:
123456789
A
B
C
D
E
F
A
B
C
D
E
F
08
VC-652 BOARD (4/14)
CPU, AV SIGNAL PROCESS, LENS CONTROL,
MODE CONTROL, HDMI PROCESS (3/3)
XX MARK: NO MOUNT
REG_GND
FB1501
C1502
XX
C1513
XX
C1509
22u
C1501
XX
4V
C1504
0.1u
C1515
0.1u
C1503
4.7u
C1528
XX
C1527
XX
C1530
1u
C1518
0.001u
C1519
0.001u
R1505 1k
C1525
XX
C1523
XX
C1516
0.1u
R1515
240
C1506
22u C1512
0.1u
C1508
22u
C1505
0.1u C1507
0.1u C1510
0.1u C1514
0.1u C1521
0.1u
C1522
22u
C1529
0.1u
C1517
0.1u
C1520
0.001u
A28 VDD_CORE
A29 VDD_CORE
B28 VDD_CORE
B29 VDD_CORE
B30 VDD_CORE
C28 VDD_CORE
C29 VDD_CORE
C30 VDD_CORE
D29 VDD_CORE
F26 VDD_CORE
G25 VDD_CORE
G26 VDD_CORE
H24 VDD_CORE
H25 VDD_CORE
H26 VDD_CORE
J24 VDD_CORE
J25 VDD_CORE
J26 VDD_CORE
K24 VDD_CORE
K25 VDD_CORE
L22 VDD_CORE
M21 VDD_CORE
N21 VDD_CORE
N22 VDD_CORE
P21 VDD_CORE
P22 VDD_CORE
K22 VDD_CORE
L21 VDD_CORE
N10 IOVDD11_DDR
P10 IOVDD11_DDR
R10 IOVDD11_DDR
T10 IOVDD11_DDR
U10 IOVDD11_DDR
V10 IOVDD11_DDR
N1 VDD12_POP_DDR
N2 VDD12_POP_DDR
AC1 VDD12_POP_DDR
AC2 VDD12_POP_DDR
AK8 VDD12_POP_DDR
AL8 VDD12_POP_DDR
F31 VDD12_POP_DDR
A12 VDD12_POP_DDR
B12 VDD12_POP_DDR
A17 VDD12_POP_DDR
B17 VDD12_POP_DDR
AH30
IOVDD_FSP
AH31
IOVDD_FSP
AG29
VSS
AJ26
VSS
AJ27
VSS
AK27
VSS
AL27
VSS
T1
T2
T3
T6
T7
T8
K1
K2
K3
K6
K7
K8
AA1
AA2
AA3
AA6
AA7
AA8
R1
R2
E31
E29
F1
F2
F30
AK20
AL20
AG30
AG31
AA24
AA25
AA26
AB24
AB25
AB26
AC24
AC25
AC26
AD22
AD23
AD24
AD25
AD26
AE23
AE24
AA21
AA22
AA20
AB20
AB21
AB22
AH29
AJ30
AJ31
AJ29
AJ28
AF24
AL29
AL28
AK30
AK29
AK28
M22 VDD_CORE
AF23
C1 VSS
D1 VSS
D2 VSS
E1 VSS
E2 VSS
E3 VSS
H6 VSS
J3 VSS
J6 VSS
J7 VSS
J8 VSS
L2 VSS
L3 VSS
L6 VSS
L7 VSS
L8 VSS
M7 VSS
M8 VSS
AB2 VSS
AB3 VSS
AB6 VSS
AB7 VSS
AB8 VSS
AC3 VSS
AD3 VSS
G13 VSS
H13 VSS
M10 VSS
M11 VSS
M12 VSS
M13 VSS
M14 VSS
M15 VSS
M16 VSS
M17 VSS
M18 VSS
M19 VSS
M20 VSS
N11 VSS
N12 VSS
N13 VSS
N14 VSS
N15 VSS
N16 VSS
N17 VSS
N18 VSS
N19 VSS
N20 VSS
P11 VSS
P12 VSS
P13 VSS
P14 VSS
P15 VSS
P16 VSS
P17 VSS
P18 VSS
P19 VSS
P20 VSS
R11 VSS
R12 VSS
R13 VSS
R14 VSS
R15 VSS
R16 VSS
R17 VSS
R18 VSS
R19 VSS
R20 VSS
R21 VSS
R22 VSS
H29 VSS
A27 VSS
B27 VSS
C27 VSS
F29 DDR_ZQ
A1 N.C.
A2 N.C.
B1 N.C.
AK1 N.C.
AL1 N.C.
AL2 N.C.
T11
T12
T13
T14
T15
T16
T17
T18
T19
T20
T21
T22
U11
U12
U13
U14
U15
U16
U17
U18
U19
U20
U21
U22
V11
V12
V13
V14
V15
V16
V17
V18
V19
V20
V21
V22
W10
W11
W12
W13
W14
W15
W16
W17
W18
W19
W20
W21
W22
Y11
Y12
Y13
Y14
Y15
Y16
Y17
Y18
Y19
Y20
Y21
Y22
AA12
AA18
AA19
AB19
AE14
AE15
AF22
W24
Y24
Y25
F25
G24
H23
AE22
AL30
AL31
AK31
A30
A31
B31
C1511
XX
C1524
4.7u
C1526
0.1u
LN1502
D_VID_1.1V_VDD_CORE
LN1501
D_VID_1.1V
FSP
Core POWER
DRAM/OneNAND
POWER
GND
D_VID_1.1V
REG_GND
A_VID_1.1V
REG_GND
REG_GND
REG_GND
HB_1.2V
D_1.8V_IC_1301_3
REG_GND
REG_GND
D_1.2V
REG_GND
REG_GND
REG_GND
HB_1.2V
HB_1.8V
D_1.8V_IC_1301_3
IOVDDCA_DDR
IOVDDCA_DDR
IOVDDCA_DDR
IOVDDCA_DDR
IOVDDCA_DDR
IOVDDCA_DDR
IOVDDQ_DDR1
IOVDDQ_DDR1
IOVDDQ_DDR1
IOVDDQ_DDR1
IOVDDQ_DDR1
IOVDDQ_DDR1
IOVDDQ_DDR2
IOVDDQ_DDR2
IOVDDQ_DDR2
IOVDDQ_DDR2
IOVDDQ_DDR2
IOVDDQ_DDR2
DDRVREF_DQ
VSS
DDRVREF_CA
VSS
VDD18_POP_DDR
VDD18_POP_DDR
VDD18_POP_DDR
VDD18_POP_NAND
VDD18_POP_NAND
VDD18_POP_NAND
VDD18_POP_NAND
FSP_ADDR__20
FSP_ADDR__19
FSP_ADDR__18
FSP_ADDR__17
FSP_ADDR__16
FSP_AD__15
FSP_AD__14
FSP_AD__13
FSP_AD__12
FSP_AD__11
FSP_AD__10
FSP_AD__9
FSP_AD__8
FSP_AD__7
FSP_AD__6
FSP_AD__5
FSP_AD__4
FSP_AD__3
FSP_AD__2
FSP_AD__1
FSP_AD__0
FSP_XOE
FSP_XWE
FSP_XCS__2
FSP_XCS__1
FSP_XCS__0_OUT
FSP_XCS__0_IN
FSP_XADV
FSP_CLK_OUT_FLASH0
FSP_CLK_IN_FLASH0
FSP_RDY0
FSP_XRST_OUT
FSP_XRST_IN
FSP_INT
MODE CONTROL,
CPU, AV SIGNAL PROCESS,
LENS CONTROL,
IC1301 (5/6)
AVY1G2G04B
HDMI PROCESS
MODE CONTROL,
CPU, AV SIGNAL PROCESS,
LENS CONTROL,
IC1301 (6/6)
AVY1G2G04B
HDMI PROCESS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VPGM
N.C.
N.C.
N.C.
N.C.
N.C.
N.C.
6-7
HDR-CX250/CX250E/CX260E/CX260V/CX260VE/CX270E/CX270V_L3
123456789
A
B
C
D
E
F
A
B
C
D
E
F
08
VC-652 BOARD (5/14)
AUDIO INTERFACE
XX MARK: NO MOUNT
C2407 1u
R2412
4700
R2426 XX
C2410
0.001u
C2406 1u
R2413
1.5k
COM241
COMMON-GND2
1
@CirP
2
@CirP
C2412 4.7u
C2413 4.7u
Q2402
XX
6
2
1
3
5
4
Q2403
XX
R2425 XX
R2415
2200
R2414
2200
R2422
XX
C2420
0.1u
AUDIO_GND
R2423
XX
C2405
1u
C2401
1u
R2419
XX
L2402
10uH
R2421
XX
R2418
XX
R2417 XX
C2416
0.01u
C2422
10u
C2421
0.1u
C2403
0.1u
R2420
XX
C2404
0.1u
C2414
0.001u
C2417
0.1u
C2411
1u
R2409 XX
C2415
0.01u
C2419
4.7u
C2408
4.7u
G7
MIC_NF_R
E7
EX_MIC_R
F7
INT_MIC_R
E6
MIC_REG_R
D6
MIC_REG_L
C7
INT_MIC_L
C6
EX_MIC_L
D7
MIC_NF_L
B6
BIAS
A7
AVSS
B7
AVDD
C3
N.C.
D4 A6 B5 B4 A5 A4 A3 B3 A2 B2 A1 E4
E5C4F4G1G2G3E1E2F3F1F2D5
G4
SDATA
G5
SCLK
F5
CSB
C2
VVDD
C1
V_OUT
D2
V_IN
D1
VVSS
D3
PDB
G6
DMCK
F6
DMDAT
E3
TEST
C5
N.C.
C2402
1u
R2428 XX
C2409
4.7u
R2410
1k
R2411
1k
R2445 XX
R2446 XX
R2449
XX
R2450 XX
C2424
1u
R2416 33k
C2418
470p
Q2401
2SD2702TL
C2423
22u
10V
R2401 XX
R2402 XX
R2451
XX
REG
AV_SCK
LRCK_OUT
GPIO_SB_4
BCK_OUT
AV_SO
REG_GND
D_2.8V
MCK_INOUT
SDO
D_1.8V
DAI_D1
REG_GND
AUDIO_GND
N.C.
BEEP_IN
MCLK_O
DVDD
DVSS
IOVDD
DAIN
ADOUT
BCLK
LRCK
MCLK
N.C.
N.C.
MUTE_R
LINE_R
LINE_L
MUTE_L
EVROUT
SPIN
SP_-
SPVSS
SPVDD
SP_+
N.C.
IC2401
BU76312GUW-E2
AUDIO INTERFACE
MICAMP_OUT_L
MICAMP_OUT_R
A_3.3V
AU_2.8V
SP+
AUDIO_GND
D_1.2V
SP-
MT_5.0V
AUDIO_R_I/O
MT_5.0V
BEEP_PWM_N
BEEP_PWM_P
AUDIO_L_I/O
INT_MIC_L
INT_MIC_R
6-8
HDR-CX250/CX250E/CX260E/CX260V/CX260VE/CX270E/CX270V_L3
123456789
A
B
C
D
E
F
A
B
C
D
E
F
08
VC-652 BOARD (6/14)
MIC AMP
XX MARK: NO MOUNT
C2603 0.1u
C2604 0.1u
R2605
6800 R2606
6800
C2611 1u
C2609
1u
C2607
1u
C2614 0.1u
L2601 10uH
C2601
10u
A1
PATH_SEL0
B4
PATH_SEL1
A3
QSTART
D2
VCOM
A2
MGND
A5
PGND
A4
C1P
B5
C1N
A6
PVSS
F6 B3 B6 C6 D6 D5 E6
F4B2D4F3F2F5E5F1
E4
B1
D1
MIC_INR2
C2
LINE_INL
C1
MIC_INL1
D3
MIC_INL2
E1
LINE_INR
C5
LINE_OUTL
E2
LINE_OUTR
E3
MIC_INR1
C2605 0.1u
C2606 0.1u
R2601 120k
R2602 120k
C2608
0.001u C2610
0.001u
R2609 XX
R2610
10k
R2611
10k
R2612 XX
EXT_MIC_R
EXT_MIC_L
AUDIO_L_I/O
AUDIO_R_I/O
AU_2.8V
MICAMP_OUT_R
MICAMP_OUT_L
EXT_LINE_SEL
AUDIO_GND
REG_GND
SVDD
MVDD
MIC_PDB
MIC_MONO
MIC_EXT
MIC_SEL1
MIC_SEL0
MIC_BIASR
MIC_BIASL
SVSS
PVDD
SGND
HP_PDB
HP_INR
HP_INL
HP_OUTR
HP_OUTL
IC2601
BD8871GW-E2
MIC AMP
XMIC_MONO
MIC_JACK_IN
MIC_PWR_ON
6-9
HDR-CX250/CX250E/CX260E/CX260V/CX260VE/CX270E/CX270V_L3
XSYS_RST
123456789
A
B
C
D
E
F
A
B
C
D
E
F
08
VC-652 BOARD (7/14)
AUDIO DSP
XX MARK: NO MOUNT
A5
CLOCK
C5
GND
B5
VD
D5
VL
D4
CLK/SCL
C4 D3 D2 C3 C2
D1 C1 B1 B2 A1
B3B4A2A3A4
C3003
0.1u
C3002
0.1u
C3001
1u
R3004 XX
R3005 XX
C3004
XX
R3006 0
RB3001
47k
12
34
56
78
R3007
4700
CL3001
REG_GND
XCS_MAGIC
D_1.2V
AV_SO
D_2.8V
AV_SCK
MISO_SDA
XBUSY_HS0_MAGIC
XINT_HS1_MAGIC
DAO_LRCK
DAO_SCLK
DAI_D1
DAI_LRCLK
DAI_SCLK
XRESET
DBCK
DBDA
MCLK
DAO_D1
XCS
MISO/SDA
MOSI
XBUSY/HS0
XINT/HS1
IC3001
CS48L10-CWZR
AUDIO DSP
DAI_D1
MCK_INOUT
LRCK_OUT
DAO_D1
BCK_OUT
D_2.8V
Other manuals for Handycam HDR-CX250
1
This manual suits for next models
8
Table of contents
Other Sony Camcorder manuals
Sony
Sony Handycam Vision CCD-TRV89E User manual
Sony
Sony DCR-DVD92 User manual
Sony
Sony NXCAM HXR-NX3 User manual
Sony
Sony DCR-TRV15E User manual
Sony
Sony FCBEX48E User manual
Sony
Sony CCD-TRV101 Operating Instructions (English -... User manual
Sony
Sony F35 Cinealta User manual
Sony
Sony TRV38 - MiniDV 1Megapixel Camcorder User manual
Sony
Sony PDW-F355L User manual
Sony
Sony HXR-NX70 User manual
Sony
Sony ExwaveHAD DXC-190 User manual
Sony
Sony HC7 User manual
Sony
Sony VX-1000 User manual
Sony
Sony Handycam DCR-DVD510E User manual
Sony
Sony XDCAM EX PMW-EX30 User manual
Sony
Sony Handycam Vision CCD-TRV16E User manual
Sony
Sony HANDYCAM User manual
Sony
Sony HSC100R User manual
Sony
Sony Handycam 3-286-598-13(1) User manual
Sony
Sony Super HAD CCD SSC-CX13VP User manual
