SERVICE MANUAL
HDR-PJ50/PJ50E/PJ50V/PJ50VE/XR160/XR160E_L3
Check the SERVICE NOTE (LEVEL 2) before the service.
Revision History
Published by Sony Techno Create Corporation
Sony Corporation
LEVEL 3
983455311.pdf
Ver. 1.0 2011.03
Digital HD Video Camera Recorder
The components identified by mark
0or dotted line with mark 0are
critical for safety.
Replace only with part number
specified.
Les composants identifiés par une
marque 0sont critiques pour la
sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
9-834-553-11
US Model
Canadian Model
AEP Model
UK Model
North European Model
E Model
Australian Model
Hong Kong Model
Chinese Model
Korea Model
Brazilian Model
Tourist Model
Japanese Model
Ver. Date History Contents S.M. Rev.
issued
1.0 2011.03 Official Release — —
2011C08-1
© 2011.03
HDR-PJ50/PJ50E/PJ50V/
PJ50VE/XR160/XR160E
Photo: HDR-PJ50V/Black

– 2 –
HDR-PJ50/PJ50E/PJ50V/PJ50VE/XR160/XR160E_L3
SAFETY-RELATED COMPONENT WARNING!!
COMPONENTS IDENTIFIED BY MARK 0OR DOTTED LINE WITH
MARK 0ON THE SCHEMATIC DIAGRAMS AND IN THE PARTS LIST
ARE CRITICAL TO SAFE OPERATION. REPLACE THESE COMPO-
NENTS WITH SONY PARTS WHOSE PART NUMBERS APPEAR AS
SHOWN IN THIS MANUAL OR IN SUPPLEMENTS PUBLISHED BY
SONY.
ATTENTION AU COMPOSANT AYANT RAPPORT
À LA SÉCURITÉ!
LES COMPOSANTS IDENTIFIÉS PAR UNE MARQUE 0SUR LES
DIAGRAMMES SCHÉMATIQUES ET LA LISTE DES PIÈCES SONT
CRITIQUES POUR LA SÉCURITÉ DE FONCTIONNEMENT. NE REM-
PLACER CES COMPOSANTS QUE PAR DES PIÈCES SONY DONT
LES NUMÉROS SONT DONNÉS DANS CE MANUEL OU DANS LES
SUPPLÉMENTS PUBLIÉS PAR SONY.
Caution
Danger of explosion if battery is incorrectly replaced.
Replace only with the same or equivalent type.
Dispose of used batteries according to the instructions.
注意
電池の交換は，正しく行わないと破裂する恐れがあります。
電池を交換する場合には必ず同じ型名の電池又は同等品と
交換してください。
使用済み電池は，取扱指示に従って処分してください。
SAFETY CHECK-OUT
After correcting the original service problem, perform the following
safety checks before releasing the set to the customer.
1. Check the area of your repair for unsoldered or poorly-soldered
connections. Check the entire board surface for solder splashes and
bridges.
2. Check the interboard wiring to ensure that no wires are “pinched”
or contact high-wattage resistors.
3. Look for unauthorized replacement parts, particularly transistors,
that were installed during a previous repair. Point them out to the
customer and recommend their replacement.
4. Look for parts which, through functioning, show obvious signs of
deterioration. Point them out to the customer and recommend their
replacement.
5. Check the B+ voltage to see it is at the values specified.
6. Flexible Circuit Board Repairing
• Set the soldering iron tip temperature to 350 °C approximately.
• Do not touch the soldering iron on the same conductor of the circuit
board (within 3 times).
• Be careful not to apply force on the conductor when soldering or
unsoldering.
1. 注意事項をお守りください。
 サービスのとき特に注意を要する個所については，キャビ
ネット，シャーシ，部品などにラベルや捺印で注意事項を
表示しています。これらの注意書き及び取扱説明書等の注
意事項を必ずお守り下さい。
2. 指定部品のご使用を
 セットの部品は難燃性や耐電圧など安全上の特性を持った
ものとなっています。従って交換部品は，使用されていた
ものと同じ特性の部品を使用して下さい。特に回路図，部
品表に0印で指定されている安全上重要な部品は必ず指定
のものをご使用下さい。
3. 部品の取付けや配線の引きまわしはもとどおりに
 安全上，チューブやテープなどの絶縁材料を使用したり，
プリント基板から浮かして取付けた部品があります。また
内部配線は引きまわしやクランパによって発熱部品や高圧
部品に接近しないよう配慮されていますので，これらは必
ずもとどおりにして下さい。
4. サービス後は安全点検を
 サービスのために取外したネジ，部品，配線がもとどおり
になっているか，またサービスした個所の周辺を劣化させ
てしまったところがないかなどを点検し，安全性が確保さ
れていることを確認して下さい。
5. チップ部品交換時の注意
 ・取外した部品は再使用しないで下さい。
 ・タンタルコンデンサのマイナス側は熱に弱いため交換時
は注意して下さい。
6. フレキシブルプリント基板の取扱いについて
 ・半田こてのこて先温度は約350℃に設定してください。
 ・同一パターンに何度もコテ先を当てないで下さい。（3回
以内）
 ・パターンに力が加わらないよう注意して下さい。
サービス，点検時には次のことにご注意ください。
– ENGLISH – – JAPANESE –
UNLEADED SOLDER
This unit uses unleaded solder.
Boards requiring use of unleaded solder are printed with the lead free
mark (LF) indicating the solder contains no lead.
(Caution: Some printed circuit boards may not come printed with the
lead free mark due to their particular size.)
: LEAD FREE MARK
Be careful to the following points to solder or unsolder.
• Set the soldering iron tip temperature to 350 °C approximately.
If cannot control temperature, solder/unsolder at high temperature
for a short time.
Caution: The printed pattern (copper foil) may peel away if the
heated tip is applied for too long, so be careful!
Unleaded solder is more viscous (sticky, less prone to
flow) than ordinary solder so use caution not to let solder
bridges occur such as on IC pins, etc.
• Be sure to control soldering iron tips used for unleaded solder and
those for leaded solder so they are managed separately. Mixing un-
leaded solder and leaded solder will cause detachment phenomenon.
無鉛半田について
本機には無鉛半田が使用されています。
無鉛半田を使用している基板には，無鉛（LeadFree）を意味する
レッドフリーマークがプリントされています。
（注意：基板サイズによっては，無鉛半田を使用していてもレッ
ドフリーマークがプリントされていないものがありま
す）
：レッドフリーマーク
無鉛半田は，下記の点に注意して使用してください。
・ 半田こてのこて先温度は約350℃に設定してください。
 温度調節が無理な場合は，高温短時間で作業を行ってくだ
さい。
 注意：半田こてを長く当てすぎると，基板のパターン（銅
箔）がはがれてしまうことがありますので，注意して
ください。また，従来の半田よりも粘性が強いため，
IC端子などが半田ブリッジしないように注意してく
ださい。
・ 半田こてのこて先は，必ず無鉛半田用と有鉛半田用に分け
て管理してください。
 無鉛半田と有鉛半田が混在すると剥離現象が発生してしま
います。

HDR-PJ50/PJ50E/PJ50V/PJ50VE/XR160/XR160E_L3
2-1
Ref. No. Part No. DescriptionRef. No. Part No. Description
(ENGLISH)
NOTE:
• -XX, -X mean standardized parts, so they may have some differ-
ences from the original one.
• Items marked “*” are not stocked since they are seldom required for
routine service. Some delay should be anticipated when ordering
these items.
• The mechanical parts with no reference number in the exploded
views are not supplied.
• Due to standardization, replacements in the parts list may be dif-
ferent from the parts specified in the diagrams or the components
used on the set.
• CAPACITORS:
uF: μF
• COILS
uH: μH
• RESISTORS
All resistors are in ohms.
METAL: metal-film resistor
METAL OXIDE: Metal Oxide-film resistor
F: nonflammable
• SEMICONDUCTORS
In each case, u: μ, for example:
uA...: μA... , uPA... , μPA... ,
uPB... , μPB... , uPC... , μPC... ,
uPD..., μPD...
(JAPANESE)
【使用上の注意】
• ここに記載されている部品は,補修用部品であるため,回路図及び
セットに付いている部品と異なる場合があります。
• -XX, -Xは標準化部品のため,セットに付いている部品と異なる場
合があります。
• *印の部品は常備在庫しておりません。
• コンデンサの単位でuFはμFを示します。
• 抵抗の単位Ωは省略してあります。
 金 被：金属被膜抵抗。
 サンキン：酸化金属被膜抵抗。
• インダクタの単位でuHはμHを示します。
• 半導体の名称でuA...,uPA...,uPB...,uPC...,uPD...等はそれぞれμA...,
μPA...,μPB...,μPC...,μPD...を示します。
The components identified by mark 0
or dotted line with mark 0are critical
for safety.
Replace only with part number specified.
Les composants identifiés par une mar-
que 0sont critiques pour la sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
0印の部品，または0印付の点線で囲まれた部品は，
安全性を維持するために，重要な部品です。
従って交換時は，必ず指定の部品を使用してください。
When indicating parts by reference num-
ber, please include the board name.
図面番号で部品を指定するときは基板名又はブロック
を併せて指定してください。
お願い
A-1767-897-A CM-114 BOARD, COMPLETE
(PJ50/PJ50E/PJ50V/PJ50VE)
A-1822-825-A CM-114 BOARD, COMPLETE
(XR160/XR160E)
**********************
(CP002 is not supplied, but this is included in CM-114 COMPLETE BOARD.)
< CAPACITOR >
C6903 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C6905 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C6907 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C6908 1-165-884-11 CERAMIC CHIP 2.2uF 10% 6.3V
*C6909 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
C6910 1-165-884-11 CERAMIC CHIP 2.2uF 10% 6.3V
*C6912 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
C6914 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
C6915 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C6916 1-165-887-91 CERAMIC CHIP 0.22uF 10% 6.3V
*C6917 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
C6920 1-165-884-11 CERAMIC CHIP 2.2uF 10% 6.3V
C6921 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C6923 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C6924 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C6925 1-165-884-11 CERAMIC CHIP 2.2uF 10% 6.3V
C6927 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C6928 1-165-884-11 CERAMIC CHIP 2.2uF 10% 6.3V
C6930 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C6932 1-165-884-11 CERAMIC CHIP 2.2uF 10% 6.3V
*C6933 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
*C6935 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
*C6936 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
C6939 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
*C6940 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
C6941 1-100-567-81 CERAMIC CHIP 0.01uF 10% 25V
< CONNECTOR >
CN6901 1-822-378-11 CONNECTOR, FPC (ZIF) 33P
< COMPOSITION CIRCUIT BLOCK >
CP002 (Not supplied) IMX055CHL-13
< IC >
IC6902 (Not supplied) IC MM3404A27URE
< LINE FILTER >
*LF6901 1-457-648-21 COMMON MODE CHOKE COIL
*LF6902 1-457-648-21 COMMON MODE CHOKE COIL
*LF6903 1-457-648-21 COMMON MODE CHOKE COIL
*LF6904 1-457-648-21 COMMON MODE CHOKE COIL
*LF6905 1-457-648-21 COMMON MODE CHOKE COIL
< RESISTOR >
R6915 1-216-864-11 SHORT CHIP 0 (XR160/XR160E)
R6919 1-208-927-11 METAL CHIP 47K 0.5% 1/16W
R6932 1-218-953-11 METAL CHIP 1K 5% 1/16W
1-882-736-11 FP-1313 FLEXIBLE BOARD
********************
A-1810-716-A FP-1319 BOARD, COMPLETE
(PJ50/PJ50E/PJ50V/PJ50VE)
**********************
(CN5505 is not supplied, but this is included in FP-1319 FLEXIBLE COMPLETE
BOARD.)
< CAPACITOR >
*C001 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
< CONNECTOR >
CN5503 1-842-687-11 CONNECTOR, BOARD TO BOARD 42P
CN5505 (Not supplied) CONNECTOR, BOARD TO BOARD
1-882-875-11 FP-1320 FLEXIBLE BOARD
*********************
A-1810-660-A FP-1321 BOARD, COMPLETE
**********************
< CONNECTOR >
CN0201 1-815-794-13 CONNECTOR (MULTIPLE)
A-1800-670-A ST LED BLOCK ASSY, ST
(PJ50/PJ50E/PJ50V/PJ50VE)
(Not supplied) FP-1322 BOARD, COMPLETE
***********************
(All mounted parts and FP-1322 FLEXIBLE COMPLETE BOARD are not supplied, but
they are included in ST LED BLOCK ASSY.)
1-882-879-11 FP-1324 FLEXIBLE BOARD
*********************
1-882-880-11 FP-1325 FLEXIBLE BOARD (XR160/XR160E)
*********************
1-882-881-11 FP-1326 FLEXIBLE BOARD
(PJ50/PJ50E/PJ50V/PJ50VE)
********************
1-882-882-11 FP-1327 FLEXIBLE BOARD
(PJ50/PJ50E/PJ50V/PJ50VE)
********************
2-2. ELECTRICAL PARTS LIST
Note1 : イメージャの交換時は6-1ページの“イメージャ交換時の
注意”を必ずお読みください。
Caution
Danger of explosion if battery is incorrectly replaced.
Replace only with the same or equivalent type.
Dispose of used batteries according to the instructions.
注意
電池の交換は，正しく行わないと破裂する恐れがあります。
電池を交換する場合には必ず同じ型名の電池又は同等品と交換し
てください。
使用済み電池は，取扱指示に従って処分してください。
Note 2: Replace the battery holder (BH8001) together when replac-
ing the lithium storage battery (BT8001) on the MS-454
board. (The battery holder removed once cannot be used
again.)
When mounting these parts, mount new battery holder first
and attach new lithium battery next.
Note 2: MS-454基板のリチウム蓄電池（BT8001）を交換する場合
はバッテリホルダ（BH8001）も同時に新品に交換して下さ
い。（一度使用したバッテリホルダは再使用できません。）
部品取り付けの際は，先にバッテリホルダを取り付けて
からリチウム電池を装着して下さい。
Note1 : Be sure to read “Precautions for Replacement of Imager”
on page 6-1 when changing the imager.
Note 3: Ferrite bead is mounted to the location where R1415 is
printed. Note 3: R1415にはフェライトビーズがマウントされています。
CM-114 FP-1313 FP-1319 FP-1320 FP-1321 FP-1322 FP-1324 FP-1325 FP-1326 FP-1327
2. REPAIR PARTS LIST

HDR-PJ50/PJ50E/PJ50V/PJ50VE/XR160/XR160E_L3
2-2
Ref. No. Part No. Description Ref. No. Part No. Description Ref. No. Part No. DescriptionRef. No. Part No. Description
1-882-883-11 FP-1328 FLEXIBLE BOARD
(PJ50/PJ50E/PJ50V/PJ50VE)
*********************
1-882-884-11 FP-1329 FLEXIBLE BOARD
*********************
A-1809-635-A FP-1352 BOARD, COMPLETE
***********************
< CONNECTOR >
CN1001 1-842-602-11 CONNECTOR, HDMI
< LINE FILTER >
LF001 1-457-374-21 COMMOM MODE CHOKE COIL
LF002 1-457-374-21 COMMOM MODE CHOKE COIL
LF003 1-457-374-21 COMMOM MODE CHOKE COIL
LF004 1-457-374-21 COMMOM MODE CHOKE COIL
< RESISTOR >
R001 1-220-802-11 METAL CHIP 3.3 5% 1/16W
R002 1-220-802-11 METAL CHIP 3.3 5% 1/16W
R003 1-220-802-11 METAL CHIP 3.3 5% 1/16W
R004 1-220-802-11 METAL CHIP 3.3 5% 1/16W
R005 1-220-802-11 METAL CHIP 3.3 5% 1/16W
R006 1-220-802-11 METAL CHIP 3.3 5% 1/16W
R007 1-220-802-11 METAL CHIP 3.3 5% 1/16W
R008 1-220-802-11 METAL CHIP 3.3 5% 1/16W
A-1808-076-A GP392ASSY (PJ50V/PJ50VE)
(Not supplied) GP-037 BOARD, COMPLETE
(All mounted parts and GP-037 COMPLETE BOARD are not supplied, but they are
included in GP392ASSY.)
A-1810-656-A LD-279 BOARD, COMPLETE
(PJ50/PJ50E/PJ50V/PJ50VE)
A-1810-659-A LD-279 BOARD, COMPLETE (XR160/XR160E)
**********************
< CAPACITOR >
*C5201 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
C5202 1-100-611-91 CERAMIC CHIP 22uF 20% 6.3V
C5203 1-164-939-11 CERAMIC CHIP 0.0022uF 10% 50V
(PJ50/PJ50E/PJ50V/PJ50VE)
*C5204 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
C5205 1-164-939-11 CERAMIC CHIP 0.0022uF 10% 50V
(PJ50/PJ50E/PJ50V/PJ50VE)
*C5206 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
C5207 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
C5208 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
(XR160/XR160E)
C5208 1-165-887-91 CERAMIC CHIP 0.22uF 10% 6.3V
(PJ50/PJ50E/PJ50V/PJ50VE)
*C5209 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
*C5210 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
*C5211 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
*C5212 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
*C5213 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
*C5214 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
*C5215 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
(PJ50/PJ50E/PJ50V/PJ50VE)
*C5216 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
(PJ50/PJ50E/PJ50V/PJ50VE)
C5219 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C5220 1-164-940-11 CERAMIC CHIP 0.0033uF 10% 16V
(PJ50/PJ50E/PJ50V/PJ50VE)
C5221 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C5222 1-165-887-91 CERAMIC CHIP 0.22uF 10% 6.3V
(PJ50/PJ50E/PJ50V/PJ50VE)
C5223 1-165-897-11 TANTAL. CHIP 22uF 20% 10V
C5225 1-164-942-11 CERAMIC CHIP 0.0068uF 10% 16V
(PJ50/PJ50E/PJ50V/PJ50VE)
C5226 1-164-942-11 CERAMIC CHIP 0.0068uF 10% 16V
(PJ50/PJ50E/PJ50V/PJ50VE)
C5227 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
(PJ50/PJ50E/PJ50V/PJ50VE)
C5228 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
(PJ50/PJ50E/PJ50V/PJ50VE)
C5501 1-165-897-11 TANTAL. CHIP 22uF 20% 10V
C5504 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
*C5507 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
*C5508 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
*C5509 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
*C5510 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
C5522 1-127-772-81 CERAMIC CHIP 0.033uF 10% 10V
C5523 1-127-772-81 CERAMIC CHIP 0.033uF 10% 10V
C5524 1-127-772-81 CERAMIC CHIP 0.033uF 10% 10V
C5525 1-127-772-81 CERAMIC CHIP 0.033uF 10% 10V
C5526 1-119-923-11 CERAMIC CHIP 0.047uF 10% 10V
C5527 1-119-923-11 CERAMIC CHIP 0.047uF 10% 10V
C5528 1-119-923-11 CERAMIC CHIP 0.047uF 10% 10V
C5529 1-119-923-11 CERAMIC CHIP 0.047uF 10% 10V
*C7701 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
*C7702 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
C7703 1-119-923-11 CERAMIC CHIP 0.047uF 10% 10V
C7704 1-119-923-11 CERAMIC CHIP 0.047uF 10% 10V
C7705 1-100-611-91 CERAMIC CHIP 22uF 20% 6.3V
C7706 1-114-411-21 CERAMIC CHIP 0.33uF 10% 6.3V
C7707 1-112-746-11 CERAMIC CHIP 4.7uF 10% 6.3V
*C9501 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
C9502 1-119-923-11 CERAMIC CHIP 0.047uF 10% 10V
C9503 1-119-923-11 CERAMIC CHIP 0.047uF 10% 10V
C9504 1-119-923-11 CERAMIC CHIP 0.047uF 10% 10V
C9505 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C9506 1-100-567-81 CERAMIC CHIP 0.01uF 10% 25V
C9507 1-100-567-81 CERAMIC CHIP 0.01uF 10% 25V
< CONNECTOR >
CN4001 1-821-501-11 CONNECTOR, FPC (ZIF) 51P
(PJ50/PJ50E/PJ50V/PJ50VE)
*CN4002 1-821-503-11 CONNECTOR, FPC (ZIF) 39P (XR160/XR160E)
CN4003 1-816-654-61 FFC/FPC CONNECTOR (LIF) 6P
*CN4004 1-770-619-11 PIN, CONNECTOR 2P
CN4005 1-818-803-21 CONNECTOR, BOARD TO BOARD 100P
CN4006 1-816-654-61 FFC/FPC CONNECTOR (LIF) 6P
< DIODE >
D4001 6-501-216-01 DIODE CL-271HR-C-TS (PJ50/PJ50E/PJ50V/PJ50VE)
< IC >
*IC4001 6-600-563-01 IC RS-450-T (PJ50/PJ50E/PJ50V/PJ50VE)
*IC5201 6-808-503-01 IC BU24130GU-E2
IC5202 6-715-211-01 IC MM3404A28URE
IC5203 6-717-167-01 IC NJU7036SE3 (TE2) (PJ50/PJ50E/PJ50V/PJ50VE)
IC5204 6-717-167-01 IC NJU7036SE3 (TE2) (PJ50/PJ50E/PJ50V/PJ50VE)
IC5501 6-716-760-01 IC R2J30503LG
IC7701 6-707-333-01 IC NJM3230SE7
< COIL >
*L7701 1-481-425-21 INDUCTOR 10uH
< TRANSISTOR >
*Q4001 6-552-344-01 TRANSISTOR DRA3143T0L
< RESISTOR >
R4001 1-218-947-11 METAL CHIP 330 5% 1/16W
(PJ50/PJ50E/PJ50V/PJ50VE)
R4003 1-208-687-11 METAL CHIP 1.5K 0.5% 1/16W
R4004 1-208-687-11 METAL CHIP 1.5K 0.5% 1/16W
R4005 1-208-687-11 METAL CHIP 1.5K 0.5% 1/16W
R5203 1-218-958-11 METAL CHIP 2.7K 5% 1/16W
(PJ50/PJ50E/PJ50V/PJ50VE)
R5204 1-208-909-11 METAL CHIP 8.2K 0.5% 1/16W
(PJ50/PJ50E/PJ50V/PJ50VE)
R5205 1-208-721-11 METAL CHIP 39K 0.5% 1/16W
(PJ50/PJ50E/PJ50V/PJ50VE)
R5205 1-218-990-81 SHORT CHIP 0 (XR160/XR160E)
R5206 1-218-958-11 METAL CHIP 2.7K 5% 1/16W
(PJ50/PJ50E/PJ50V/PJ50VE)
R5207 1-208-909-11 METAL CHIP 8.2K 0.5% 1/16W
(PJ50/PJ50E/PJ50V/PJ50VE)
R5208 1-208-721-11 METAL CHIP 39K 0.5% 1/16W
(PJ50/PJ50E/PJ50V/PJ50VE)
R5208 1-218-990-81 SHORT CHIP 0 (XR160/XR160E)
R5209 1-208-699-11 METAL CHIP 4.7K 0.5% 1/16W
R5210 1-208-943-11 METAL CHIP 220K 0.5% 1/16W
R5211 1-208-671-11 METAL CHIP 330 0.5% 1/16W
R5212 1-208-941-11 METAL CHIP 180K 0.5% 1/16W
R5215 1-208-909-11 METAL CHIP 8.2K 0.5% 1/16W
R5217 1-208-911-11 METAL CHIP 10K 0.5% 1/16W
R5221 1-208-909-11 METAL CHIP 8.2K 0.5% 1/16W
(PJ50/PJ50E/PJ50V/PJ50VE)
R5222 1-208-911-11 METAL CHIP 10K 0.5% 1/16W
(PJ50/PJ50E/PJ50V/PJ50VE)
R5225 1-208-943-11 METAL CHIP 220K 0.5% 1/16W
(PJ50/PJ50E/PJ50V/PJ50VE)
R5228 1-208-941-11 METAL CHIP 180K 0.5% 1/16W
(PJ50/PJ50E/PJ50V/PJ50VE)
R5228 1-218-990-81 SHORT CHIP 0 (XR160/XR160E)
R5229 1-218-990-81 SHORT CHIP 0 (PJ50/PJ50E/PJ50V/PJ50VE)
R5230 1-208-697-11 METAL CHIP 3.9K 0.5% 1/16W
(PJ50/PJ50E/PJ50V/PJ50VE)
R5231 1-218-990-81 SHORT CHIP 0 (PJ50/PJ50E/PJ50V/PJ50VE)
R5233 1-208-911-11 METAL CHIP 10K 0.5% 1/16W
(PJ50/PJ50E/PJ50V/PJ50VE)
R5234 1-218-990-81 SHORT CHIP 0 (XR160/XR160E)
R5235 1-218-990-81 SHORT CHIP 0 (XR160/XR160E)
R5237 1-208-911-11 METAL CHIP 10K 0.5% 1/16W
(PJ50/PJ50E/PJ50V/PJ50VE)
R5238 1-208-911-11 METAL CHIP 10K 0.5% 1/16W
(PJ50/PJ50E/PJ50V/PJ50VE)
R5239 1-208-911-11 METAL CHIP 10K 0.5% 1/16W
(PJ50/PJ50E/PJ50V/PJ50VE)
R5240 1-208-911-11 METAL CHIP 10K 0.5% 1/16W
(PJ50/PJ50E/PJ50V/PJ50VE)
R5241 1-208-911-11 METAL CHIP 10K 0.5% 1/16W
(PJ50/PJ50E/PJ50V/PJ50VE)
R5242 1-208-911-11 METAL CHIP 10K 0.5% 1/16W
(PJ50/PJ50E/PJ50V/PJ50VE)
R5243 1-208-911-11 METAL CHIP 10K 0.5% 1/16W
(PJ50/PJ50E/PJ50V/PJ50VE)
R5244 1-208-911-11 METAL CHIP 10K 0.5% 1/16W
(PJ50/PJ50E/PJ50V/PJ50VE)
R5245 1-208-911-11 METAL CHIP 10K 0.5% 1/16W
(PJ50/PJ50E/PJ50V/PJ50VE)
R5246 1-208-911-11 METAL CHIP 10K 0.5% 1/16W
(PJ50/PJ50E/PJ50V/PJ50VE)
R5247 1-218-990-81 SHORT CHIP 0 (XR160/XR160E)
R5248 1-218-990-81 SHORT CHIP 0 (PJ50/PJ50E/PJ50V/PJ50VE)
R5249 1-218-990-81 SHORT CHIP 0 (PJ50/PJ50E/PJ50V/PJ50VE)
R5250 1-218-990-81 SHORT CHIP 0 (XR160/XR160E)
R5251 1-218-990-81 SHORT CHIP 0 (PJ50/PJ50E/PJ50V/PJ50VE)
R5252 1-218-990-81 SHORT CHIP 0 (PJ50/PJ50E/PJ50V/PJ50VE)
R5255 1-218-990-81 SHORT CHIP 0 (XR160/XR160E)
R5256 1-218-990-81 SHORT CHIP 0 (XR160/XR160E)
R5257 1-218-990-81 SHORT CHIP 0 (XR160/XR160E)
R5258 1-218-990-81 SHORT CHIP 0 (XR160/XR160E)
R5259 1-218-990-81 SHORT CHIP 0 (XR160/XR160E)
R5260 1-218-990-81 SHORT CHIP 0 (XR160/XR160E)
R5515 1-208-711-11 METAL CHIP 15K 0.5% 1/16W
R5519 1-218-990-81 SHORT CHIP 0 (XR160/XR160E)
R5520 1-218-990-81 SHORT CHIP 0 (PJ50/PJ50E/PJ50V/PJ50VE)
R5522 1-218-990-81 SHORT CHIP 0 (XR160/XR160E)
R5523 1-218-990-81 SHORT CHIP 0 (XR160/XR160E)
R5525 1-218-990-81 SHORT CHIP 0 (XR160/XR160E)
R5527 1-218-971-11 METAL CHIP 33K 5% 1/16W
R5528 1-218-971-11 METAL CHIP 33K 5% 1/16W
R5529 1-218-971-11 METAL CHIP 33K 5% 1/16W
R5530 1-218-971-11 METAL CHIP 33K 5% 1/16W
R5531 1-218-990-81 SHORT CHIP 0 (PJ50/PJ50E/PJ50V/PJ50VE)
R5532 1-208-911-11 METAL CHIP 10K 0.5% 1/16W
(PJ50/PJ50E/PJ50V/PJ50VE)
R7702 1-218-969-11 METAL CHIP 22K 5% 1/16W
R7703 1-218-969-11 METAL CHIP 22K 5% 1/16W
R7705 1-218-965-11 METAL CHIP 10K 5% 1/16W
R7706 1-208-711-11 METAL CHIP 15K 0.5% 1/16W
R7707 1-218-985-11 METAL CHIP 470K 5% 1/16W
R9502 1-218-981-91 METAL CHIP 220K 5% 1/16W
R9507 1-208-935-11 METAL CHIP 100K 0.5% 1/16W
R9508 1-208-935-11 METAL CHIP 100K 0.5% 1/16W
FP-1328 FP-1329 FP-1352 GP-037 LD-279

HDR-PJ50/PJ50E/PJ50V/PJ50VE/XR160/XR160E_L3
2-3
Ref. No. Part No. Description Ref. No. Part No. Description Ref. No. Part No. DescriptionRef. No. Part No. Description
< SENSOR >
SE7701 1-479-022-61 SENSOR, ANGULAR VELOCITY (32.2KHZ)
*SE9501 1-480-307-41 3 AXIS ACCELEROMETOR
A-1815-404-A MS-454 BOARD, COMPLETE (SERVICE)
**********************
(BT8001 is not included in MS-454 COMPLETE BOARD (SERVICE).)
< BATTERY >
BT8001 1-756-135-31 BATTERY LITHIUM SECONDARY
< BATTERY HOLDER >
BH8001 1-251-928-21 SOCKET, BATTERY
< CAPACITOR >
*C7505 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
C7506 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
C7507 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
C7508 1-114-411-21 CERAMIC CHIP 0.33uF 10% 6.3V
C7509 1-114-411-21 CERAMIC CHIP 0.33uF 10% 6.3V
C7512 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C7513 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
*C7514 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
C7515 1-112-746-11 CERAMIC CHIP 4.7uF 10% 6.3V
*C8003 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
*C8004 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
< CONNECTOR >
CN8001 1-822-837-21 CARD CONNECTOR
CN8002 1-816-646-61 FFC/FPC CONNECTOR (LIF) 16P
*CN8003 1-842-522-21 CONNECTOR, FPC (ZIF) 61P
< DIODE >
D8001 6-501-216-01 DIODE CL-271HR-C-TS
< COIL >
*L7501 1-481-425-21 INDUCTOR 10uH
< RESISTOR >
R7508 1-218-982-11 METAL CHIP 270K 5% 1/16W
R7509 1-218-982-11 METAL CHIP 270K 5% 1/16W
R7510 1-208-699-11 METAL CHIP 4.7K 0.5% 1/16W
R7511 1-208-699-11 METAL CHIP 4.7K 0.5% 1/16W
R7512 1-208-911-11 METAL CHIP 10K 0.5% 1/16W
R7513 1-208-911-11 METAL CHIP 10K 0.5% 1/16W
R7514 1-218-985-11 METAL CHIP 470K 5% 1/16W
R7515 1-218-985-11 METAL CHIP 470K 5% 1/16W
R8001 1-218-953-11 METAL CHIP 1K 5% 1/16W
R8015 1-218-941-81 METAL CHIP 100 5% 1/16W
R8027 1-218-942-11 METAL CHIP 120 5% 1/16W
R8028 1-218-942-11 METAL CHIP 120 5% 1/16W
R8029 1-218-942-11 METAL CHIP 120 5% 1/16W
R8030 1-218-942-11 METAL CHIP 120 5% 1/16W
R8031 1-218-942-11 METAL CHIP 120 5% 1/16W
R8032 1-218-942-11 METAL CHIP 120 5% 1/16W
R8033 1-218-942-11 METAL CHIP 120 5% 1/16W
R8034 1-218-942-11 METAL CHIP 120 5% 1/16W
R8035 1-218-958-11 METAL CHIP 2.7K 5% 1/16W
R8036 1-218-943-11 METAL CHIP 150 5% 1/16W
R8037 1-218-948-11 METAL CHIP 390 5% 1/16W
R8038 1-218-953-11 METAL CHIP 1K 5% 1/16W
R8039 1-218-963-11 METAL CHIP 6.8K 5% 1/16W
< COMPOSITION CIRCUIT BLOCK >
RB8002 1-234-372-11 RES, NETWORK 100 (1005X4)
< SWITCH >
S8001 1-798-119-11 SWITCH, TACTILE
< SENSOR >
SE7501 1-487-653-11 SENSOR, ANGULAR VELOCITY (PITCH/YAW)
A-1810-704-A PD-432 BOARD, COMPLETE (SERVICE)
(XR160/XR160E)
A-1810-706-A PD-432 BOARD, COMPLETE (SERVICE)
(PJ50/PJ50E/PJ50V/PJ50VE)
********************
< CAPACITOR >
*C6001 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
C6002 1-100-581-81 CERAMIC CHIP 0.0047uF 10% 50V
C6003 1-100-581-81 CERAMIC CHIP 0.0047uF 10% 50V
C6004 1-164-856-81 CERAMIC CHIP 18PF 5% 50V
(PJ50V/PJ50VE)
C6005 1-164-856-81 CERAMIC CHIP 18PF 5% 50V
(PJ50V/PJ50VE)
C6006 1-164-856-81 CERAMIC CHIP 18PF 5% 50V
(PJ50V/PJ50VE)
C6007 1-164-856-81 CERAMIC CHIP 18PF 5% 50V
(PJ50V/PJ50VE)
C6019 1-112-746-11 CERAMIC CHIP 4.7uF 10% 6.3V
C6020 1-100-591-91 CERAMIC CHIP 1uF 10% 25V
C6021 1-112-746-11 CERAMIC CHIP 4.7uF 10% 6.3V
C6024 1-165-884-11 CERAMIC CHIP 2.2uF 10% 6.3V
C6025 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C6026 1-112-300-91 CERAMIC CHIP 4.7uF 10% 10V
C6027 1-112-300-91 CERAMIC CHIP 4.7uF 10% 10V
C6028 1-100-742-91 CERAMIC CHIP 2.2uF 20% 10V
C6029 1-112-300-91 CERAMIC CHIP 4.7uF 10% 10V
C6030 1-100-742-91 CERAMIC CHIP 2.2uF 20% 10V
C6031 1-112-299-91 CERAMIC CHIP 2.2uF 10% 16V
C6032 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C6036 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
(PJ50V/PJ50VE)
C6037 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
(PJ50V/PJ50VE)
*C6102 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
(PJ50/PJ50E/PJ50V/PJ50VE)
< CONNECTOR >
*CN6001 1-842-522-21 CONNECTOR, FPC (ZIF) 61P
*CN6002 1-822-910-11 CONNECTOR, FPC (LIF (NON-ZIF))
*CN6003 1-821-503-11 CONNECTOR, FPC (ZIF) 39P
CN6004 1-794-375-21 PIN, CONNECTOR 2P
CN6005 1-794-375-21 PIN, CONNECTOR 2P
CN6006 1-816-655-61 CONNECTOR, FFC/FPC 8P (PJ50V/PJ50VE)
CN6007 1-821-652-11 CONNECTOR, BOARD TO BOARD (REC
(PJ50/PJ50E/PJ50V/PJ50VE)
< DIODE >
D6001 6-503-321-01 DIODE DZ5S068D0R
< IC >
IC6001 6-715-211-01 IC MM3404A28URE (PJ50V/PJ50VE)
*IC6101 6-712-051-01 IC SN65LVDS302ZQER (PJ50/PJ50E/PJ50V/PJ50VE)
< COIL >
*L6001 1-481-102-21 INDUCTOR 10uH
< TRANSISTOR >
Q6001 6-552-538-01 TRANSISTOR DMG9640N0R
Q6002 6-552-538-01 TRANSISTOR DMG9640N0R
< RESISTOR >
R6002 1-218-990-81 SHORT CHIP 0 (PJ50/PJ50E/PJ50V/PJ50VE)
R6003 1-218-990-81 SHORT CHIP 0 (XR160/XR160E)
R6005 1-218-990-81 SHORT CHIP 0 (XR160/XR160E)
R6006 1-218-990-81 SHORT CHIP 0 (PJ50/PJ50E/PJ50V/PJ50VE)
R6009 1-218-985-11 METAL CHIP 470K 5% 1/16W
R6011 1-218-990-81 SHORT CHIP 0 (XR160/XR160E)
R6012 1-218-990-81 SHORT CHIP 0 (PJ50/PJ50E/PJ50V/PJ50VE)
R6106 1-218-990-81 SHORT CHIP 0 (XR160/XR160E)
R6107 1-218-990-81 SHORT CHIP 0 (XR160/XR160E)
R6108 1-218-990-81 SHORT CHIP 0 (XR160/XR160E)
R6109 1-218-990-81 SHORT CHIP 0 (XR160/XR160E)
R6110 1-218-990-81 SHORT CHIP 0 (XR160/XR160E)
R6111 1-218-990-81 SHORT CHIP 0 (XR160/XR160E)
R6112 1-218-990-81 SHORT CHIP 0 (XR160/XR160E)
R6113 1-218-990-81 SHORT CHIP 0 (XR160/XR160E)
< COMPOSITION CIRCUIT BLOCK >
RB6101 1-234-380-21 RES, NETWORK 47K (1005X4)
(PJ50/PJ50E/PJ50V/PJ50VE)
RB6102 1-234-380-21 RES, NETWORK 47K (1005X4)
(PJ50/PJ50E/PJ50V/PJ50VE)
< SENSOR >
*SE6001 1-487-118-11 GMR SENSOR
A-1810-708-A PJ-104 BOARD, COMPLETE
(PJ50/PJ50E/PJ50V/PJ50VE)
********************
(IC8605 is not supplied, but this is included in PJ-104 COMPLETE BOARD.)
< CAPACITOR >
C8501 1-164-934-11 CERAMIC CHIP 330PF 10% 50V
C8503 1-100-597-91 CERAMIC CHIP 0.1uF 10% 25V
*C8504 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
C8505 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
*C8507 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
C8508 1-164-934-11 CERAMIC CHIP 330PF 10% 50V
C8509 1-164-934-11 CERAMIC CHIP 330PF 10% 50V
C8510 1-116-403-91 CERAMIC CHIP 10uF 10% 6.3V
C8512 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
*C8513 1-112-298-91 CERAMIC CHIP 1uF 10% 16V
C8514 1-164-934-11 CERAMIC CHIP 330PF 10% 50V
C8516 1-100-597-91 CERAMIC CHIP 0.1uF 10% 25V
C8517 1-164-934-11 CERAMIC CHIP 330PF 10% 50V
C8518 1-100-591-91 CERAMIC CHIP 1uF 10% 25V
*C8519 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
*C8520 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
C8521 1-116-403-91 CERAMIC CHIP 10uF 10% 6.3V
C8522 1-164-934-11 CERAMIC CHIP 330PF 10% 50V
*C8523 1-112-298-91 CERAMIC CHIP 1uF 10% 16V
C8524 1-164-858-11 CERAMIC CHIP 22PF 5% 50V
C8525 1-112-746-11 CERAMIC CHIP 4.7uF 10% 6.3V
C8526 1-100-597-91 CERAMIC CHIP 0.1uF 10% 25V
C8527 1-100-567-81 CERAMIC CHIP 0.01uF 10% 25V
C8528 1-112-746-11 CERAMIC CHIP 4.7uF 10% 6.3V
C8529 1-135-960-91 CERAMIC CHIP 10uF 10% 25V
C8530 1-164-858-11 CERAMIC CHIP 22PF 5% 50V
C8531 1-100-597-91 CERAMIC CHIP 0.1uF 10% 25V
C8533 1-116-403-91 CERAMIC CHIP 10uF 10% 6.3V
*C8534 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
C8535 1-135-960-91 CERAMIC CHIP 10uF 10% 25V
*C8536 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
*C8538 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
*C8601 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
C8602 1-164-856-81 CERAMIC CHIP 18PF 5% 50V
C8603 1-164-856-81 CERAMIC CHIP 18PF 5% 50V
*C8604 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
*C8605 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
C8606 1-100-567-81 CERAMIC CHIP 0.01uF 10% 25V
*C8607 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
*C8608 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
*C8609 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
*C8610 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
*C8611 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
*C8612 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
*C8613 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
*C8614 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
*C8615 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
*C8616 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
*C8617 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
C8618 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
*C8619 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
*C8620 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
*C8621 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
*C8622 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
*C8623 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
*C8624 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
*C8625 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
*C8626 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
C8627 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
*C8628 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
*C8629 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
LD-279 MS-454 PD-432 PJ-104

HDR-PJ50/PJ50E/PJ50V/PJ50VE/XR160/XR160E_L3
2-4
Ref. No. Part No. Description Ref. No. Part No. Description Ref. No. Part No. DescriptionRef. No. Part No. Description
*C8701 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
*C8702 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
*C8703 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
*C8704 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
*C8705 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
*C8706 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
*C8707 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
*C8708 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
C8710 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C8801 1-116-403-91 CERAMIC CHIP 10uF 10% 6.3V
C8802 1-164-934-11 CERAMIC CHIP 330PF 10% 50V
C8803 1-112-746-11 CERAMIC CHIP 4.7uF 10% 6.3V
< CONNECTOR >
CN8501 1-842-687-11 CONNECTOR, BOARD TO BOARD 42P
CN8502 1-816-643-51 FFC/FPC CONNECTOR (LIF) 10P
CN8503 1-822-395-51 CONNECTOR, BOARD TO BOARD 60P
< DIODE >
*D8501 6-502-629-01 DIODE 1SS420 (TL3SONY.F)
*D8502 6-502-629-01 DIODE 1SS420 (TL3SONY.F)
D8503 6-503-106-01 DIODE DZ2S100M0L
< FERRITE BEAD >
FB8501 1-400-915-21 INDUCTOR (EMI FERRITE) (2012)
FB8502 1-400-915-21 INDUCTOR (EMI FERRITE) (2012)
FB8504 1-400-915-21 INDUCTOR (EMI FERRITE) (2012)
FB8505 1-400-915-21 INDUCTOR (EMI FERRITE) (2012)
FB8506 1-400-915-21 INDUCTOR (EMI FERRITE) (2012)
FB8507 1-400-915-21 INDUCTOR (EMI FERRITE) (2012)
FB8508 1-400-915-21 INDUCTOR (EMI FERRITE) (2012)
FB8601 1-400-915-21 INDUCTOR (EMI FERRITE) (2012)
FB8602 1-400-915-21 INDUCTOR (EMI FERRITE) (2012)
FB8701 1-500-283-11 INDUCTOR, FERRITE BEAD
FB8801 1-400-619-11 BEAD, FERRITE (CHIP) (1608)
< IC >
IC8501 6-716-995-01 IC TC7SZ07AFS
IC8502 6-716-996-01 IC RT8522GQW
IC8503 6-716-997-01 IC RT8035GQW
IC8601 6-712-602-01 IC 74LVC139BQ-118
IC8602 6-717-009-01 IC TC7WG04FC
IC8603 6-716-999-01 IC W25X40BVPY03
IC8605 (Not supplied) IC DPP2601
IC8701 6-717-010-01 IC K4X56163PN-FGC6T
IC8801 6-717-011-01 IC LM3549SQX/NOPB
< COIL >
L8501 1-400-705-11 INDUCTOR 2.2uH
L8503 1-400-705-11 INDUCTOR 2.2uH
L8504 1-481-035-11 INDUCTOR 10uH
L8801 1-400-705-11 INDUCTOR 2.2uH
< RESISTOR >
R8501 1-220-210-11 METAL CHIP 200K 5% 1/16W
R8502 1-218-977-11 METAL CHIP 100K 5% 1/16W
R8503 1-220-210-11 METAL CHIP 200K 5% 1/16W
R8505 1-220-205-11 METAL CHIP 75K 5% 1/16W
R8506 1-220-196-81 METAL CHIP 13K 5% 1/16W
R8507 1-218-965-11 METAL CHIP 10K 5% 1/16W
R8508 1-218-977-11 METAL CHIP 100K 5% 1/16W
R8509 1-218-953-11 METAL CHIP 1K 5% 1/16W
R8510 1-208-953-11 METAL CHIP 560K 0.5% 1/16W
R8511 1-218-979-11 METAL CHIP 150K 5% 1/16W
R8512 1-218-981-91 METAL CHIP 220K 5% 1/16W
R8513 1-208-713-11 METAL CHIP 18K 0.5% 1/16W
R8601 1-218-977-11 METAL CHIP 100K 5% 1/16W
R8602 1-218-977-11 METAL CHIP 100K 5% 1/16W
R8605 1-218-977-11 METAL CHIP 100K 5% 1/16W
R8608 1-218-935-11 METAL CHIP 33 5% 1/16W
R8610 1-218-977-11 METAL CHIP 100K 5% 1/16W
R8611 1-218-941-81 METAL CHIP 100 5% 1/16W
R8612 1-218-989-11 METAL CHIP 1M 5% 1/16W
R8613 1-218-935-11 METAL CHIP 33 5% 1/16W
R8614 1-218-977-11 METAL CHIP 100K 5% 1/16W
R8616 1-218-977-11 METAL CHIP 100K 5% 1/16W
R8617 1-218-935-11 METAL CHIP 33 5% 1/16W
R8618 1-218-977-11 METAL CHIP 100K 5% 1/16W
R8619 1-218-977-11 METAL CHIP 100K 5% 1/16W
R8623 1-218-935-11 METAL CHIP 33 5% 1/16W
R8624 1-218-935-11 METAL CHIP 33 5% 1/16W
R8625 1-218-935-11 METAL CHIP 33 5% 1/16W
R8626 1-218-935-11 METAL CHIP 33 5% 1/16W
R8627 1-218-977-11 METAL CHIP 100K 5% 1/16W
R8628 1-218-977-11 METAL CHIP 100K 5% 1/16W
R8701 1-218-941-81 METAL CHIP 100 5% 1/16W
R8702 1-208-922-11 METAL CHIP 30K 0.5% 1/16W
R8703 1-218-935-11 METAL CHIP 33 5% 1/16W
R8801 1-218-977-11 METAL CHIP 100K 5% 1/16W
R8803 1-220-210-11 METAL CHIP 200K 5% 1/16W
< VIBRATOR >
X8601 1-814-480-11 QUARTZ CRYSTAL OSCILLATOR
A-1810-651-A ST-248 BOARD, COMPLETE
(PJ50/PJ50E/PJ50V/PJ50VE)
**********************
< CAPACITOR >
C7201 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C7202 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C7203 1-100-567-81 CERAMIC CHIP 0.01uF 10% 25V
C7206 1-165-875-11 CERAMIC CHIP 10uF 10% 10V
C7211 1-164-874-11 CERAMIC CHIP 100PF 5% 50V
< CONNECTOR >
CN7201 1-816-646-61 FFC/FPC CONNECTOR (LIF) 16P
CN7204 1-816-650-51 FFC/FPC CONNECTOR (LIF) 24P
< IC >
IC7201 6-716-796-01 IC TPS61305YFFR
< COIL >
L7202 1-481-074-21 INDUCTOR 2.2uH
< RESISTOR >
R7202 1-218-965-11 METAL CHIP 10K 5% 1/16W
R7204 1-218-965-11 METAL CHIP 10K 5% 1/16W
R7214 1-216-864-11 SHORT CHIP 0
R7217 1-218-973-11 METAL CHIP 47K 5% 1/16W
1-489-381-21 SWITCH BLOCK, CONTROL (SK37000)
(XR160/XR160E)
*********************
1-489-381-31 SWITCH BLOCK, CONTROL (SK38010)
(PJ50/PJ50E/PJ50V/PJ50VE)
*********************
A-1817-606-A VC-621 BOARD, COMPLETE (SERVICE)
(PJ50/PJ50E/PJ50V/PJ50VE)
A-1817-608-A VC-621 BOARD, COMPLETE (SERVICE)
(XR160/XR160E)
**********************
(IC1301 is not supplied, but this is included in VC-621 COMPLETE BOARD
(SERVICE).)
< CAPACITOR >
*C1001 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
C1002 1-164-874-11 CERAMIC CHIP 100PF 5% 50V
(PJ50/PJ50E/PJ50V/PJ50VE)
*C1005 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
C1006 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
C1007 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
C1010 1-164-935-11 CERAMIC CHIP 470PF 10% 50V
C1011 1-164-935-11 CERAMIC CHIP 470PF 10% 50V
*C1015 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
(PJ50/PJ50E/PJ50V/PJ50VE)
*C1016 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
(PJ50/PJ50E/PJ50V/PJ50VE)
C1017 1-164-935-11 CERAMIC CHIP 470PF 10% 50V
C1301 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C1302 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C1303 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
*C1304 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
*C1305 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
*C1306 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
*C1307 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
*C1308 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
*C1309 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
*C1310 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
C1313 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C1314 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
*C1315 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
*C1316 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
*C1317 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
*C1318 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
C1319 1-114-723-91 TANTAL. CHIP 47uF 20% 4V
*C1320 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
*C1321 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
*C1322 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
*C1323 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
C1324 1-164-933-11 CERAMIC CHIP 220PF 10% 50V
*C1325 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
C1326 1-100-567-81 CERAMIC CHIP 0.01uF 10% 25V
C1327 1-114-723-91 TANTAL. CHIP 47uF 20% 4V
*C1339 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
C1340 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C1401 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C1402 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
*C1403 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
*C1406 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
*C1407 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
*C1409 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
*C1410 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
*C1411 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
*C1412 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
*C1414 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
*C1415 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
C1416 1-164-943-81 CERAMIC CHIP 0.01uF 10% 16V
C1417 1-164-943-81 CERAMIC CHIP 0.01uF 10% 16V
C1418 1-164-943-81 CERAMIC CHIP 0.01uF 10% 16V
C1419 1-164-943-81 CERAMIC CHIP 0.01uF 10% 16V
C1420 1-100-597-91 CERAMIC CHIP 0.1uF 10% 25V
*C1421 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
*C1422 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
*C1423 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
*C1424 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
*C1428 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
*C1430 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
*C1431 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
*C1432 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
*C1433 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
*C1434 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
*C1435 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
*C1436 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
*C1437 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
*C1438 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
*C1439 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
*C1441 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
*C1443 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
(PJ50/PJ50E/PJ50V/PJ50VE)
*C1444 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
(PJ50/PJ50E/PJ50V/PJ50VE)
*C1446 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
*C1447 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
*C1450 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
(PJ50/PJ50E/PJ50V/PJ50VE)
C1501 1-127-895-91 TANTAL. CHIP 22uF 20% 4V
C1502 1-127-895-91 TANTAL. CHIP 22uF 20% 4V
C1503 1-112-746-11 CERAMIC CHIP 4.7uF 10% 6.3V
*C1504 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
*C1505 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
C1506 1-100-611-91 CERAMIC CHIP 22uF 20% 6.3V
*C1507 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
C1508 1-100-611-91 CERAMIC CHIP 22uF 20% 6.3V
C1509 1-100-611-91 CERAMIC CHIP 22uF 20% 6.3V
*C1510 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
C1511 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
PJ-104 ST-248 SK37000 SK38010 VC-621

HDR-PJ50/PJ50E/PJ50V/PJ50VE/XR160/XR160E_L3
2-5
Ref. No. Part No. Description Ref. No. Part No. Description Ref. No. Part No. DescriptionRef. No. Part No. Description
*C1512 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
C1513 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
*C1514 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
*C1515 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
*C1516 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
C1518 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
C1519 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
C1520 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
*C1521 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
C1522 1-100-611-91 CERAMIC CHIP 22uF 20% 6.3V
*C1523 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
C1524 1-112-746-11 CERAMIC CHIP 4.7uF 10% 6.3V
C1525 1-127-895-91 TANTAL. CHIP 22uF 20% 4V
*C1526 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
*C1527 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
C1528 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
*C1529 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
C1530 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C2601 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C2602 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
*C2603 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
*C2604 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
*C2605 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
*C2606 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
C2607 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C2608 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
C2609 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C2610 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
C2611 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C2612 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
(PJ50/PJ50E/PJ50V/PJ50VE)
C2613 1-165-884-11 CERAMIC CHIP 2.2uF 10% 6.3V
(PJ50/PJ50E/PJ50V/PJ50VE)
*C2614 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
*C2615 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
(PJ50/PJ50E/PJ50V/PJ50VE)
C2616 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
(PJ50/PJ50E/PJ50V/PJ50VE)
C2617 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
(PJ50/PJ50E/PJ50V/PJ50VE)
C2618 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
(PJ50/PJ50E/PJ50V/PJ50VE)
C2702 1-100-567-81 CERAMIC CHIP 0.01uF 10% 25V
*C2703 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
*C2704 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
*C2705 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
C2706 1-100-611-91 CERAMIC CHIP 22uF 20% 6.3V
*C2707 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
*C2708 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
C2709 1-164-878-11 CERAMIC CHIP 150PF 5% 50V
C2710 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C2711 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C2712 1-164-934-11 CERAMIC CHIP 330PF 10% 50V
C2713 1-100-567-81 CERAMIC CHIP 0.01uF 10% 25V
C2714 1-100-567-81 CERAMIC CHIP 0.01uF 10% 25V
C2715 1-100-567-81 CERAMIC CHIP 0.01uF 10% 25V
C2716 1-100-567-81 CERAMIC CHIP 0.01uF 10% 25V
C2801 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C2802 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C2803 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
(PJ50/PJ50E/PJ50V/PJ50VE)
C2804 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
(PJ50/PJ50E/PJ50V/PJ50VE)
C2805 1-127-988-81 CERAMIC CHIP 0.015uF 10% 16V
C2806 1-127-988-81 CERAMIC CHIP 0.015uF 10% 16V
C2807 1-127-988-81 CERAMIC CHIP 0.015uF 10% 16V
C2810 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C2813 1-112-746-11 CERAMIC CHIP 4.7uF 10% 6.3V
C2814 1-100-611-91 CERAMIC CHIP 22uF 20% 6.3V
C2815 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
*C2817 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
(PJ50/PJ50E/PJ50V/PJ50VE)
*C2818 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
(PJ50/PJ50E/PJ50V/PJ50VE)
C2820 1-112-746-11 CERAMIC CHIP 4.7uF 10% 6.3V
*C2821 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
*C2822 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
*C2823 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
*C2824 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
*C2828 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
*C2829 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
C2830 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
*C2831 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
C2832 1-112-746-11 CERAMIC CHIP 4.7uF 10% 6.3V
*C2833 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
C2834 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C2835 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C2836 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
*C2837 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
C2838 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C2839 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C2840 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
*C2841 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
*C3301 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
(PJ50/PJ50E/PJ50V/PJ50VE)
C3302 1-164-856-81 CERAMIC CHIP 18PF 5% 50V
(PJ50/PJ50E/PJ50V/PJ50VE)
C4101 1-165-875-11 CERAMIC CHIP 10uF 10% 10V
C4102 1-165-875-11 CERAMIC CHIP 10uF 10% 10V
C4103 1-165-875-11 CERAMIC CHIP 10uF 10% 10V
*C4104 1-112-298-91 CERAMIC CHIP 1uF 10% 16V
(PJ50/PJ50E/PJ50V/PJ50VE)
C4301 1-125-889-11 CERAMIC CHIP 2.2uF 10% 10V
C4302 1-125-889-11 CERAMIC CHIP 2.2uF 10% 10V
C4303 1-125-889-11 CERAMIC CHIP 2.2uF 10% 10V
C4304 1-125-889-11 CERAMIC CHIP 2.2uF 10% 10V
C4305 1-125-889-11 CERAMIC CHIP 2.2uF 10% 10V
C4306 1-125-889-11 CERAMIC CHIP 2.2uF 10% 10V
C4308 1-112-300-91 CERAMIC CHIP 4.7uF 10% 10V
C4309 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
*C4310 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
C4311 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C4312 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C4313 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C4314 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C4315 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C4316 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
*C4317 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
C4318 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
*C4319 1-112-298-91 CERAMIC CHIP 1uF 10% 16V
C4320 1-164-943-81 CERAMIC CHIP 0.01uF 10% 16V
*C4321 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
*C4322 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
*C4323 1-112-298-91 CERAMIC CHIP 1uF 10% 16V
*C4324 1-112-298-91 CERAMIC CHIP 1uF 10% 16V
C4325 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C4326 1-100-597-91 CERAMIC CHIP 0.1uF 10% 25V
C4327 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C4328 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C4329 1-127-715-11 CERAMIC CHIP 0.22uF 10% 16V
C4330 1-127-715-11 CERAMIC CHIP 0.22uF 10% 16V
*C4331 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
C4332 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
*C4333 1-112-298-91 CERAMIC CHIP 1uF 10% 16V
C4334 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C4337 1-165-884-11 CERAMIC CHIP 2.2uF 10% 6.3V
C4338 1-100-591-91 CERAMIC CHIP 1uF 10% 25V
*C4349 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
C4350 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C4351 1-164-942-11 CERAMIC CHIP 0.0068uF 10% 16V
C4801 1-119-750-11 TANTAL. CHIP 22uF 20% 6.3V
C4802 1-164-852-11 CERAMIC CHIP 12PF 5% 50V
*C4803 1-128-965-11 CERAMIC CHIP 13PF 5% 50V
C4804 1-100-567-81 CERAMIC CHIP 0.01uF 10% 25V
*C4805 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
*C4806 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
*C4807 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
*C4808 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
C4809 1-100-567-81 CERAMIC CHIP 0.01uF 10% 25V
*C4810 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
C4811 1-100-567-81 CERAMIC CHIP 0.01uF 10% 25V
C9101 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C9102 1-112-746-11 CERAMIC CHIP 4.7uF 10% 6.3V
*C9103 1-112-298-91 CERAMIC CHIP 1uF 10% 16V
*C9104 1-112-298-91 CERAMIC CHIP 1uF 10% 16V
*C9105 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
*C9106 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
*C9107 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
*C9108 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
*C9109 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
*C9110 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
C9111 1-112-300-91 CERAMIC CHIP 4.7uF 10% 10V
C9112 1-100-567-81 CERAMIC CHIP 0.01uF 10% 25V
C9113 1-112-746-11 CERAMIC CHIP 4.7uF 10% 6.3V
C9114 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C9116 1-112-746-11 CERAMIC CHIP 4.7uF 10% 6.3V
C9117 1-112-342-91 CERAMIC CHIP 10uF 20% 10V
C9118 1-112-342-91 CERAMIC CHIP 10uF 20% 10V
*C9119 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
C9120 1-100-415-91 CERAMIC CHIP 0.47uF 10% 6.3V
*C9121 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
*C9122 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
*C9124 1-114-582-11 CERAMIC CHIP 0.1uF 10% 16V
C9125 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
< CONNECTOR >
CN1001 1-816-644-51 FFC/FPC CONNECTOR (LIF) 12P
(PJ50/PJ50E/PJ50V/PJ50VE)
CN1002 1-816-646-61 FFC/FPC CONNECTOR (LIF) 16P
(PJ50/PJ50E/PJ50V/PJ50VE)
CN1003 1-816-646-61 FFC/FPC CONNECTOR (LIF) 16P
CN1004 1-822-378-11 CONNECTOR, FPC (ZIF) 33P
CN1005 1-779-329-51 FFC/CONNECTOR, FPC (LIF (NON-ZIF)) 10P
CN1006 1-815-460-51 CONNECTOR, FFC/FPC 26P
CN1007 1-818-804-21 CONNECTOR, BOARD TO BOARD 100P
CN1008 1-580-789-21 PIN, CONNECTOR (SMD) 6P
CN1009 1-779-327-51 FFC/CONNECTOR, FPC (LIF (NON-ZIF)) 6P
*CN1010 1-842-522-21 CONNECTOR, FPC (ZIF) 61P
CN1011 1-816-643-51 FFC/FPC CONNECTOR (LIF) 10P
*CN1012 1-842-522-21 CONNECTOR, FPC (ZIF) 61P
CN9101 1-770-622-21 PIN, CONNECTOR 5P
CN9102 1-822-425-21 CONNECTOR, USB (MINI AB)
< DIODE >
D1001 6-503-219-01 DIODE RKZ12B2KJR1
D1301 8-719-027-76 DIODE 1SS357 (PJ50/PJ50E/PJ50V/PJ50VE)
D1302 8-719-027-76 DIODE 1SS357 (PJ50/PJ50E/PJ50V/PJ50VE)
D1303 6-500-854-01 DIODE 1SS413 (TPL3)
D1304 6-500-854-01 DIODE 1SS413 (TPL3)
D1401 8-719-056-23 DIODE MA2S111-(K8).SO
D1402 8-719-056-23 DIODE MA2S111-(K8).SO
*D4101 6-502-629-01 DIODE 1SS420 (TL3SONY.F)
D4102 8-719-024-69 DIODE 1SS361 (T5LS (PJ50/PJ50E/PJ50V/PJ50VE)
D4103 6-503-219-01 DIODE RKZ12B2KJR1
*D9101 6-503-185-01 DIODE DSR520, H3SONYF
D9102 8-719-056-23 DIODE MA2S111-(K8).SO
D9103 6-503-058-01 DIODE DB2J31700L
< FUSE >
F0001 1-523-133-31 FUSE 1.4A 50V
F0002 1-523-133-31 FUSE 1.4A 50V
F0003 1-523-133-31 FUSE 1.4A 50V
F0004 1-523-133-31 FUSE 1.4A 50V
F0005 1-523-133-31 FUSE 1.4A 50V
F0006 1-523-133-31 FUSE 1.4A 50V
(PJ50/PJ50E/PJ50V/PJ50VE)
F0007 1-523-133-31 FUSE 1.4A 50V
*F1401 1-576-872-31 FUSE 0.25A 50V
*F4301 1-576-872-31 FUSE 0.25A 50V
< FERRITE BEAD >
FB1001 1-500-238-11 BEAD, FERRITE (CHIP) (1608)
FB1002 1-500-238-11 BEAD, FERRITE (CHIP) (1608)
FB1003 1-500-238-11 BEAD, FERRITE (CHIP) (1608)
(PJ50/PJ50E/PJ50V/PJ50VE)
FB1004 1-500-238-11 BEAD, FERRITE (CHIP) (1608)
(PJ50/PJ50E/PJ50V/PJ50VE)
FB1005 1-500-238-11 BEAD, FERRITE (CHIP) (1608)
(PJ50/PJ50E/PJ50V/PJ50VE)
FB1006 1-500-238-11 BEAD, FERRITE (CHIP) (1608)
FB1007 1-500-238-11 BEAD, FERRITE (CHIP) (1608)
FB1008 1-400-927-31 BEAD, FERRITE (1005) (PJ50/PJ50E/PJ50V/PJ50VE)
FB1401 1-500-975-21 FERRITE, EMI (SMD)
FB1402 1-400-827-31 BEAD, FERRITE (1005)
FB1501 1-400-619-11 BEAD, FERRITE (CHIP) (1608)
VC-621

HDR-PJ50/PJ50E/PJ50V/PJ50VE/XR160/XR160E_L3
2-6
Ref. No. Part No. Description Ref. No. Part No. Description Ref. No. Part No. DescriptionRef. No. Part No. Description
< IC >
IC1301 (Not supplied) IC AVY1G1501A
IC1302 6-716-878-01 IC AK8153AU-L
*IC2601 6-714-928-01 IC BD8871GW-E2
IC2701 6-712-944-01 IC CS42L52-CNZR
*IC2801 6-713-028-01 IC NN12926A-BB
*IC3301 6-712-050-01 IC SN65LVDS301ZQER (PJ50/PJ50E/PJ50V/PJ50VE)
IC4301 6-716-942-01 IC BD8330GU-E2
IC4302 6-716-945-01 IC BD8331GU-E2
IC4303 6-716-949-01 IC RT9292DGJ6
*IC4304 6-714-502-01 IC BD2224G-TR
IC4801 6-717-003-01 IC MB95005ABGL-G-132-ERE1
*IC9101 6-714-833-01 IC TPS2553DBVR-1
IC9102 6-713-788-01 IC BD6046
IC9103 6-716-783-01 IC BD11600NUX-E2
IC9104 6-716-783-01 IC BD11600NUX-E2
IC9105 6-716-783-01 IC BD11600NUX-E2
IC9106 6-715-684-01 IC PST8456UL
IC9107 6-716-825-01 IC MAX8895WEWA+TCAS
IC9108 6-716-824-01 IC OZ8070LN
< COIL >
*L1301 1-481-425-21 INDUCTOR 10uH
L1302 1-481-634-11 INDUCTOR 22uH
*L2601 1-481-425-21 INDUCTOR 10uH
*L2602 1-481-425-21 INDUCTOR 10uH
L2701 1-400-588-11 INDUCTOR 10uH
L2702 1-414-864-11 FERRITE, EMI (SMD) (1608)
L2703 1-400-723-11 INDUCTOR, FERRITE BEAD (1005)
L2704 1-400-723-11 INDUCTOR, FERRITE BEAD (1005)
L2705 1-400-723-11 INDUCTOR, FERRITE BEAD (1005)
L2706 1-400-723-11 INDUCTOR, FERRITE BEAD (1005)
*L2801 1-481-425-21 INDUCTOR 10uH
*L2802 1-481-425-21 INDUCTOR 10uH
*L2803 1-481-425-21 INDUCTOR 10uH
L4301 1-460-355-11 INDUCTOR 4.7uH
L4302 1-460-356-11 INDUCTOR 4.7uH
L4303 1-460-356-11 INDUCTOR 4.7uH
L4304 1-460-359-11 INDUCTOR 4.7uH
L4305 1-460-356-11 INDUCTOR 4.7uH
L4306 1-460-355-11 INDUCTOR 4.7uH
L4307 1-460-369-11 INDUCTOR 33uH
L9101 1-460-368-11 INDUCTOR 6.8uH
< LINE FILTER >
LF1001 1-457-223-11 COMMON MODE CHOKE COIL
LF1002 1-457-223-11 COMMON MODE CHOKE COIL
LF1003 1-457-223-11 COMMON MODE CHOKE COIL
LF1004 1-457-223-11 COMMON MODE CHOKE COIL
LF9101 1-457-223-11 COMMON MODE CHOKE COIL
LF9102 1-457-223-11 COMMON MODE CHOKE COIL
< TRANSISTOR >
*Q1001 6-552-397-01 TRANSISTOR DSC300100L
Q1301 6-552-621-01 TRANSISTOR SSM3K37MFV, L3SOF
*Q1302 6-552-723-01 TRANSISTOR SSM6N37FE, RSONYM
*Q1402 6-552-344-01 TRANSISTOR DRA3143T0L
*Q1403 6-552-535-01 TRANSISTOR DMG964030R
Q1406 8-729-043-60 TRANSISTOR CPH6102-TL-E
Q1407 8-729-054-48 TRANSISTOR UP04601008S0
Q4101 8-729-043-60 TRANSISTOR CPH6102-TL-E
*Q4102 6-552-354-01 TRANSISTOR DRC3144E0L
*Q4103 6-552-123-01 TRANSISTOR ECH8652-S-TL-H
*Q4104 6-552-354-01 TRANSISTOR DRC3144E0L
(PJ50/PJ50E/PJ50V/PJ50VE)
Q4105 6-551-184-01 TRANSISTOR MCH6305-TL-E-S
(PJ50/PJ50E/PJ50V/PJ50VE)
*Q4301 6-552-354-01 TRANSISTOR DRC3144E0L
*Q4302 6-552-397-01 TRANSISTOR DSC300100L
Q4303 6-552-726-01 TRANSISTOR MCH6431-P-TL-H
Q4304 6-552-749-01 TRANSISTOR RN2131MFV
Q4305 6-552-805-01 TRANSISTOR EM6M2T2R
*Q4801 6-552-535-01 TRANSISTOR DMG964030R
*Q9101 6-552-530-01 TRANSISTOR DMC964030R
*Q9102 6-552-123-01 TRANSISTOR ECH8652-S-TL-H
Q9103 6-550-791-01 TRANSISTOR SSM3J15FV (TL3S
*Q9104 6-552-354-01 TRANSISTOR DRC3144E0L
*Q9105 6-552-354-01 TRANSISTOR DRC3144E0L
*Q9106 6-552-700-01 TRANSISTOR SSM3K15AMFV, L3SF
*Q9107 6-552-354-01 TRANSISTOR DRC3144E0L
*Q9108 6-552-700-01 TRANSISTOR SSM3K15AMFV, L3SF
Q9109 6-552-213-01 TRANSISTOR RW1A020ZPFU7
*Q9110 6-552-354-01 TRANSISTOR DRC3144E0L
*Q9111 6-552-700-01 TRANSISTOR SSM3K15AMFV, L3SF
*Q9113 6-552-700-01 TRANSISTOR SSM3K15AMFV, L3SF
*Q9114 6-552-354-01 TRANSISTOR DRC3144E0L
*Q9115 6-552-700-01 TRANSISTOR SSM3K15AMFV, L3SF
Q9117 6-552-213-01 TRANSISTOR RW1A020ZPFU7
*Q9118 6-552-700-01 TRANSISTOR SSM3K15AMFV, L3SF
Q9119 6-552-213-01 TRANSISTOR RW1A020ZPFU7
*Q9120 6-552-700-01 TRANSISTOR SSM3K15AMFV, L3SF
Q9121 6-552-749-01 TRANSISTOR RN2131MFV
< RESISTOR >
R1001 1-218-989-11 METAL CHIP 1M 5% 1/16W
R1015 1-218-958-11 METAL CHIP 2.7K 5% 1/16W
(PJ50/PJ50E/PJ50V/PJ50VE)
R1016 1-218-963-11 METAL CHIP 6.8K 5% 1/16W
(PJ50/PJ50E/PJ50V/PJ50VE)
R1017 1-218-945-11 METAL CHIP 220 5% 1/16W
R1018 1-218-953-11 METAL CHIP 1K 5% 1/16W
R1025 1-218-977-11 METAL CHIP 100K 5% 1/16W
(PJ50/PJ50E/PJ50V/PJ50VE)
R1025 1-218-990-81 SHORT CHIP 0 (XR160/XR160E)
R1026 1-218-973-11 METAL CHIP 47K 5% 1/16W
(PJ50/PJ50E/PJ50V/PJ50VE)
R1311 1-218-961-11 METAL CHIP 4.7K 5% 1/16W
(PJ50/PJ50E/PJ50V/PJ50VE)
R1312 1-218-961-11 METAL CHIP 4.7K 5% 1/16W
(PJ50/PJ50E/PJ50V/PJ50VE)
R1313 1-218-937-11 METAL CHIP 47 5% 1/16W
R1315 1-208-869-11 METAL CHIP 180 0.5% 1/16W
R1318 1-216-864-11 SHORT CHIP 0
R1321 1-208-703-11 METAL CHIP 6.8K 0.5% 1/16W
R1331 1-208-873-81 METAL CHIP 270 0.5% 1/16W
R1332 1-218-970-11 METAL CHIP 27K 5% 1/16W
R1334 1-218-937-11 METAL CHIP 47 5% 1/16W
R1335 1-218-953-11 METAL CHIP 1K 5% 1/16W
R1340 1-216-793-11 METAL CHIP 4.7 5% 1/10W
R1342 1-218-956-11 METAL CHIP 1.8K 5% 1/16W
R1343 1-218-956-11 METAL CHIP 1.8K 5% 1/16W
R1362 1-218-937-11 METAL CHIP 47 5% 1/16W
R1363 1-208-927-11 METAL CHIP 47K 0.5% 1/16W
(XR160/XR160E)
R1364 1-218-973-11 METAL CHIP 47K 5% 1/16W
R1365 1-218-961-11 METAL CHIP 4.7K 5% 1/16W
R1366 1-218-961-11 METAL CHIP 4.7K 5% 1/16W
R1401 1-216-864-11 SHORT CHIP 0
R1402 1-216-864-11 SHORT CHIP 0
R1409 1-218-943-11 METAL CHIP 150 5% 1/16W
R1410 1-220-169-11 METAL CHIP 75 5% 1/16W
R1411 1-218-942-11 METAL CHIP 120 5% 1/16W
R1412 1-218-941-81 METAL CHIP 100 5% 1/16W
R1415 1-400-827-31 BEAD, FERRITE (1005)
R1421 1-218-937-11 METAL CHIP 47 5% 1/16W
R1443 1-218-965-11 METAL CHIP 10K 5% 1/16W
R1444 1-218-965-11 METAL CHIP 10K 5% 1/16W
R1445 1-218-977-11 METAL CHIP 100K 5% 1/16W
R1446 1-242-967-11 METAL CHIP 1 5% 1/16W
R1447 1-218-961-11 METAL CHIP 4.7K 5% 1/16W
R1448 1-218-953-11 METAL CHIP 1K 5% 1/16W
R1450 1-218-965-11 METAL CHIP 10K 5% 1/16W
R1451 1-218-965-11 METAL CHIP 10K 5% 1/16W
R1515 1-208-668-11 METAL CHIP 240 0.5% 1/16W
R2601 1-218-978-11 METAL CHIP 120K 5% 1/16W
R2602 1-218-978-11 METAL CHIP 120K 5% 1/16W
R2605 1-208-703-11 METAL CHIP 6.8K 0.5% 1/16W
R2606 1-208-703-11 METAL CHIP 6.8K 0.5% 1/16W
R2607 1-218-933-11 METAL CHIP 22 5% 1/16W
(PJ50/PJ50E/PJ50V/PJ50VE)
R2608 1-218-933-11 METAL CHIP 22 5% 1/16W
(PJ50/PJ50E/PJ50V/PJ50VE)
R2705 1-218-971-11 METAL CHIP 33K 5% 1/16W
R2808 1-218-969-11 METAL CHIP 22K 5% 1/16W
(PJ50/PJ50E/PJ50V/PJ50VE)
R2809 1-218-969-11 METAL CHIP 22K 5% 1/16W
(PJ50/PJ50E/PJ50V/PJ50VE)
R2811 1-218-971-11 METAL CHIP 33K 5% 1/16W
(PJ50/PJ50E/PJ50V/PJ50VE)
R2813 1-218-971-11 METAL CHIP 33K 5% 1/16W
(PJ50/PJ50E/PJ50V/PJ50VE)
R2816 1-218-977-11 METAL CHIP 100K 5% 1/16W
R3305 1-218-973-11 METAL CHIP 47K 5% 1/16W
(PJ50/PJ50E/PJ50V/PJ50VE)
R4101 1-216-797-11 METAL CHIP 10 5% 1/10W
R4102 1-218-953-11 METAL CHIP 1K 5% 1/16W
R4103 1-218-961-11 METAL CHIP 4.7K 5% 1/16W
R4104 1-218-965-11 METAL CHIP 10K 5% 1/16W
(PJ50/PJ50E/PJ50V/PJ50VE)
R4105 1-218-989-11 METAL CHIP 1M 5% 1/16W
(PJ50/PJ50E/PJ50V/PJ50VE)
R4106 1-218-953-11 METAL CHIP 1K 5% 1/16W
(PJ50/PJ50E/PJ50V/PJ50VE)
R4302 1-218-941-81 METAL CHIP 100 5% 1/16W
R4303 1-208-927-11 METAL CHIP 47K 0.5% 1/16W
R4315 1-208-635-11 METAL CHIP 10 0.5% 1/16W
R4316 1-216-864-11 SHORT CHIP 0 (PJ50/PJ50E/PJ50V/PJ50VE)
R4334 1-218-965-11 METAL CHIP 10K 5% 1/16W
R4336 1-218-990-81 SHORT CHIP 0
R4337 1-218-977-11 METAL CHIP 100K 5% 1/16W
R4802 1-245-604-11 METAL CHIP 10M 5% 1/16W
R4803 1-208-893-11 METAL CHIP 1.8K 0.5% 1/16W
R4807 1-208-703-11 METAL CHIP 6.8K 0.5% 1/16W
R4808 1-218-973-11 METAL CHIP 47K 5% 1/16W
R4810 1-218-949-11 METAL CHIP 470 5% 1/16W
R4812 1-218-973-11 METAL CHIP 47K 5% 1/16W
R4814 1-218-985-11 METAL CHIP 470K 5% 1/16W
R4815 1-218-989-11 METAL CHIP 1M 5% 1/16W
R4817 1-208-927-11 METAL CHIP 47K 0.5% 1/16W
R4818 1-208-935-11 METAL CHIP 100K 0.5% 1/16W
R4822 1-218-965-11 METAL CHIP 10K 5% 1/16W
R4823 1-218-953-11 METAL CHIP 1K 5% 1/16W
R4824 1-218-965-11 METAL CHIP 10K 5% 1/16W
R4825 1-218-953-11 METAL CHIP 1K 5% 1/16W
R9106 1-218-990-81 SHORT CHIP 0
R9107 1-208-918-11 METAL CHIP 20K 0.5% 1/16W
R9109 1-218-969-11 METAL CHIP 22K 5% 1/16W
R9112 1-218-977-11 METAL CHIP 100K 5% 1/16W
R9113 1-218-941-81 METAL CHIP 100 5% 1/16W
R9114 1-218-965-11 METAL CHIP 10K 5% 1/16W
R9115 1-218-965-11 METAL CHIP 10K 5% 1/16W
R9120 1-218-977-11 METAL CHIP 100K 5% 1/16W
R9122 1-208-927-11 METAL CHIP 47K 0.5% 1/16W
R9123 1-218-979-11 METAL CHIP 150K 5% 1/16W
*R9124 1-208-940-81 METAL CHIP 160K 0.5% 1/16W
R9128 1-218-977-11 METAL CHIP 100K 5% 1/16W
R9129 1-218-965-11 METAL CHIP 10K 5% 1/16W
R9130 1-218-989-11 METAL CHIP 1M 5% 1/16W
R9131 1-218-969-11 METAL CHIP 22K 5% 1/16W
R9132 1-218-973-11 METAL CHIP 47K 5% 1/16W
R9133 1-218-989-11 METAL CHIP 1M 5% 1/16W
R9134 1-218-977-11 METAL CHIP 100K 5% 1/16W
R9135 1-218-977-11 METAL CHIP 100K 5% 1/16W
R9138 1-218-965-11 METAL CHIP 10K 5% 1/16W
R9139 1-218-985-11 METAL CHIP 470K 5% 1/16W
R9140 1-218-985-11 METAL CHIP 470K 5% 1/16W
R9141 1-218-977-11 METAL CHIP 100K 5% 1/16W
R9142 1-218-989-11 METAL CHIP 1M 5% 1/16W
R9143 1-218-985-11 METAL CHIP 470K 5% 1/16W
R9144 1-218-961-11 METAL CHIP 4.7K 5% 1/16W
R9145 1-218-965-11 METAL CHIP 10K 5% 1/16W
R9148 1-218-985-11 METAL CHIP 470K 5% 1/16W
< COMPOSITION CIRCUIT BLOCK >
RB1001 1-234-400-21 CONDUCTOR, NETWORK (1005X4)
(XR160/XR160E)
RB1002 1-234-400-21 CONDUCTOR, NETWORK (1005X4)
(PJ50/PJ50E/PJ50V/PJ50VE)
RB1302 1-234-702-11 RES, NETWORK 68 (1005X4)
RB1401 1-234-371-21 RES, NETWORK 47 (1005X4)
RB1402 1-234-371-21 RES, NETWORK 47 (1005X4)
*RB1403 1-234-723-21 RES, NETWORK 75 (1005X4)
RB1412 1-234-375-21 RES, NETWORK 1K (1005X4)
RB1413 1-234-375-21 RES, NETWORK 1K (1005X4)
RB1415 1-234-381-11 RES, NETWORK100K (1005X4)
*RB1416 1-234-384-11 RES, NETWORK 1M (1005X4)
VC-621

HDR-PJ50/PJ50E/PJ50V/PJ50VE/XR160/XR160E_L3
2-7E
Ref. No. Part No. Description Ref. No. Part No. Description
RB1417 1-234-377-21 RES, NETWORK 4.7K (1005X4)
RB1418 1-234-380-21 RES, NETWORK 47K (1005X4)
RB2601 1-234-378-21 RES, NETWORK 10K (1005X4)
*RB2801 1-234-723-21 RES, NETWORK 75 (1005X4)
RB2802 1-234-372-11 RES, NETWORK 100 (1005X4)
RB3301 1-234-380-21 RES, NETWORK 47K (1005X4)
(PJ50/PJ50E/PJ50V/PJ50VE)
RB3302 1-234-400-21 CONDUCTOR, NETWORK (1005X4)
(PJ50/PJ50E/PJ50V/PJ50VE)
RB3303 1-234-400-21 CONDUCTOR, NETWORK (1005X4)
(PJ50/PJ50E/PJ50V/PJ50VE)
RB3304 1-234-371-21 RES, NETWORK 47 (1005X4) (XR160/XR160E)
RB3305 1-234-371-21 RES, NETWORK 47 (1005X4) (XR160/XR160E)
RB4301 1-234-383-21 RES, NETWORK 470K (1005X4)
RB9101 1-234-381-11 RES, NETWORK 100K (1005X4)
< SENSOR >
*SE1001 1-487-118-11 GMR SENSOR
< VARISTOR >
VD1004 1-802-090-21 VARISTOR, CHIP
VD1005 1-802-090-21 VARISTOR, CHIP
VD1006 1-802-090-21 VARISTOR, CHIP
VD1007 1-802-090-21 VARISTOR, CHIP
VD1008 1-802-090-21 VARISTOR, CHIP
VD1010 1-802-090-21 VARISTOR, CHIP
< VIBRATOR >
X1302 1-814-219-31 QUARTZ CRYSTAL OSCILLATOR (60Hz)
X1401 1-814-470-11 OSCILLATOR, CRYSTAL (25MHz)
X4801 1-781-525-11 VIBRATOR, CRYSTAL (32.768kHz)
1-838-712-11 CABLE, BUILT-IN USB
*****************
VC-621 BUILT-IN USB

4-1
HDR-PJ50/PJ50E/PJ50V/PJ50VE/XR160/XR160E_L3
4. BLOCK DIAGRAMS
4-1. OVERALL BLOCK DIAGRAM (1/2)( ) : Number in parenthesis ( ) indicates the division number of schematic diagram where the component is located.
FP-1325
FLEXIBLE
BOARD (1/2)
XR160/XR160E
FP-1326
FLEXIBLE
BOARD (1/2)
PJ50/PJ50E/
PJ50V/PJ50VE
D0±−D1±,CLK±LCD_B_0 - LCD_B_7
AUDIO SIGNAL
VIDEO SIGNAL
VIDEO/AUDIO SIGNAL
CMOS
IMAGER
CP002
IRIS
(SHUTTER)
LENS BLOCK (1/2)
IRIIS/ND
DRIVE
(2/7)
IC5201
XIC_5201_RST
IC_5201_SI/SO/SCK
XCS_IC_5201
IC_5201_VD
XIC_5201_RST
IC_5201_SI/SO/SCK
LCD_XVD/XHD
XCS_LCD
XBB_RST
AV_SO/SCK
PANEL_NOR/REV
TP_X/Y/SEL1
XPJ_PARK
PJ_TEMP_AD
SWITCH
Q1402
TP_SEL2
XPJ_RESET
LCD_B_0 - LCD_B_7
LCD_G_0 - LCD_G_7
LCD_R_0 - LCD_R_7
LCD_XVD/HXD
LCD_CLK
LCD_DATEN
I2C_SDA/SCK
BEEP_PWM_P/N
XSYS_RST
SDO
SP_L
±
SP_R ±
BLK_OUT/MCK_
INOUT/LRCK_OUT
LCD_CLK
XCS_IC_5201
IC_5201_VD
CN4001
STEADYSHOT
PROCESSOR
(3/7)
IC5501
IC_5501_SO/SI/SCK
IC_5201_VD
CRESET_P
XCS_IC_5501
XIC_5501_CPU_RST
IC_5501_INT_REQ
ZM_DIR_A/B, ZM_ENB
CAM_V
IC_5501_IC_5201_CLK
I_BIAS±, I_HALL±,
IC_5201_OUT0A/OUT0B
LENS_TEMP_AD
F_MR_A/B
ND
DRIVE
IRIS
DRIVE
LENS TEMP
SENSOR
OIS TEMP
SENSOR
PITCH/YAW
DRIVE
OPTICAL IMAGE
STABILIZER
PITCH_HALL±/BIAS-
LENS BLOCK (2/2)
ZOOM_A/B/XA/XB_OUT
ZM_SENSE1A
IC_5501_OUT4A/OUT4B
ZOOM
DRIVE
FOCUS
DRIVE
IC_5501_P_LIMIT
IC_5501_2_EXPOSE
LENSV_EN
LENS_COVER_DIR_PWM
IC_5501_OUT6B
MIC901(L)
MIC902(R)
MIC903(F)
(FOR CHECK)
IC_5501_OUT6A
CN4004
CN4006
CN4003
LENS
BARRIER
UNIT
ND_DRIVE±, ND_BIAS±,
ND_HALL±
YAW_HALL±/BIAS-
PITCH±
YAW±
TZ_HALL_TEMP
CN4002
I_BIAS±, I_HALL±,
IC_5201_OUT0A/OUT0B
LENS_TEMP_AD
FC_SENSE
IRIS
DRIVE
LENS TEMP
SENSOR
OIS TEMP
SENSOR
PITCH/YAW
DRIVE
OPTICAL IMAGE
STABILIZER
PITCH_HALL±/BIAS-
LENS BLOCK (2/2)
ZOOM_A/B/XA/XB_OUT
ZM_SENSE1A
IC_5501_OUT4B/OUT5B/
OUT4A/OUT5A
ZOOM
DRIVE
FOCUS
DRIVE
YAW_HALL±/BIAS-
PITCH±
YAW±
TZ_HALL_TEMP
IC_5501_IC_5201_CLK
XSYS_RST
YAW_ AD
PITCH_AD
IC_5501_SO/SI/SCK
CRESET_P
XCS_IC_5501
XIC_5501_CPU_RST
IC_5501_INT_REQ
ZM_DIR_A/B, ZM_ENB
CAM_V
IC_5501_IC_5201_CLK
IC_5501_P_LIMIT
IC_5501_2_EXPOSE
FC_DIR_A/B, FC_ENB
LENSV_EN
LENS_COVER_DIR_PWM
XSYS_RST
YAW_ AD
PITCH_AD
XR160/XR160E
PJ50/PJ50E/PJ50V/PJ50VE
IC_5201_PIO0/PIO1
PITCH±
_OUT
YAW±
_OUT
CN6901
DOAP,DOAM,DOBP,
DOBM,DOCP,DOCM,
DODP,DODM
XVS, XHS
SDI,SCK,XCE
DCKP,DCKM
INCK
XCLR
LD-279BOARD
FP-1324
FLEXIBLE
BOARD
CM-114 BOARD
CN1004
VC-621 BOARD (1/2)
SENS_VD/HD
SUBL_CLKINP/CLKINN
SUBL_DINN4-DINN7/DINP4-DINP7
IC_1301_SENSSO/SENSSCK/SENSXCS
XFLASH_RST
CLK_CMOS_IN_IMG CLK_CMOS_IN_GEN
XTALLY_LED
D4001
(TALLY)
ROLL SENSOR
AMP
(4/7)
IC7701
ROLL
SENSOR
(4/7)
SE7701
ROLL_AD
VST_C_CHARGE
ROLL_AD
VST_C_CHARGE
INT_MIC_R
INT_MIC_F
DEBUG_UART0_TXD
DEBUG_UART0_RXD
BOOT_MODE_1
INT_MIC_L
INT_MIC_R
INT_MIC_F
DEBUG_UART0_TXD
DEBUG_UART0_RXD
BOOT_MODE_1
LENS_TEMP_AD
ZM_SENSE1A
TZ_HALL_TEMP
FC_SENSE
LENS_TEMP_AD
ZM_SENSE1A
TZ_HALL_TEMP
FC_SENSE
CN4005 CN1007
MICROPHONE UNIT
CPC
CPU,
AV SIGNAL,
LENS CONTROL,
MODE CONTROL,
HDMI PROCESS
(2/12 - 4/12)
PROGRAMMABLE
TRANSMITTER
(8/12)
IC3301
IC2601
IC2801
BLK_OUT/MCK_INOUT/LRCK_OUT
XCS_ACO
SDO
SDI1
SDI0_SPDIF_IN
DAC_IOUT_Y
AV_SO/SCK
S_Y/D3_Y
INT_MIC_L
INT_MIC_R
INT_MIC_F
AUDIO_L_I/O
AUDIO_R_I/O
JACK_AD
DAC_IOUT_PB
XSYS_SRT
AUDIO_L_I/O
HP_PRE_OUT_L
HP_PRE_OUT_R
HP_PS
AUDIO I/O
AUDIO_R_I/O
MICAMP_OUT_L
MICAMP_OUT_R
EXT_LINE_SET
EXT_MIC_L
HP_R_OUT
HP_L_OUT
HP_JACK_IN
EXT_MIC_R
XMIC_MONO
MIC_JACK_IN
MIC_PWR_ON (5/12)
(7/12)
D/A CONVERTER,
VIDEO/AUDIO AMP
DAC_IOUT_PR
S_C/D3_PB
VIDEO/D3_PR
CN1011
CN1005
CN0201
FP-1321 FLEXIBLE
BOARD
MULTI_JACK_IN
S_Y_I/O
S_C_I/O
VIDEO_I/O
AUDIO_L_I/O
AUDIO_R_I/O
FP-1320 FLEXIBLE BOARD
EXT MIC
J0302
HEAD
PHONE
J0301
DATA0-DATA2_+/-
FP-1352 FLEXIBLE
BOARD
CN1001
TMDS_CLOCK_+/-
SDA, SCL
CEC
HPD
CN1006
HDMI_TXCN/TXCP
HDMI_TX2SOP/TX2SON, HDMI_TX1SOP/TX1SON, HDMI_TX0SOP/TX0SON
Q1302 Q1301
Q1403
HPD
HDMI_JACK_IN
CEC CEC
SDA, SCL SDA, SCL
HDMI
A/V R
USB_SEL
AL18,AK18
USB_DP/DM USB_D±
USB SWITCH
(12/12)
IC9103
USB_D±_STD_CN
USB SWITCH
(12/12)
IC9104
VOLTAGE
MANAGEMENT
(12/12)
IC9107
CN9102
CN9101
(USB_mini)
(USB)
SWITCH
Q9103
USB_CHG_D±
XUSB_CHG_SYS_ON
USB_DP/DM
XSYS_RST
XFLASH_RST
FR_XRESET
XRESET_REQ
EXT_MIC_L_JACK
EXT_MIC_R_JACK
HP_L_OUT_JACK
HP_R_OUT_JACK
HP_JACK_IN
IC4801
(1/2)
(11/12)
LANC INTERFACE,
HI PROCESSOR
XCS_FRONT
XPWR_OFF
USB_DP/DM
STD_A_DATA_SEL
USB_ID2
USB_VCC_MINI
USB_VBUS
USB_ID
USB_ID2
USB_VCC_MINI
SWITCH
Q9104
XVBUS_DET
USB_ID2
USB_VCC_MINI
USB_SEL
USB_SEL
FR_SI/SO/SCK
SWITCH
Q9113
USB_CHG_500_CN
X4801
32.768KHz
Q1406,Q1407
SYSAD_SEL_1,
XSYSAD_SEL_2
SYSTEM_AD
F1401
JACK_AD
HP_JACK_IN
XSYS_RST
TOUCH
PANEL
3.0 INCH
WIDE COLOR
LCD
LCD901
(LCD MODULE)
CN6001 (1/2)
CN1010 (1/2)
CN6003
TP_SEL1
TP_X/YTP_X/Y/SEL1
CN6002
TP_R
TP_BOT
TOUCH PANEL
INTERFACE
Q6001, Q6002
SE6001
XCS_LCD
LCD_VD/HD/CK
PANEL_NOR/REV
XBB_RST
PD-432 BOARD (1/2)
PANEL
NORMAL/REVERSE
DETECTION
AV_SO/SCK
LCD_DG0-DG7
IC6101
PROGRAMMABLE
RECEIVER
(2/2)
LCD_VD/HD/CK/DATEN
LCD_DB0-DB7
LCD_DB0-DB7
D1 ± − D1 ±, CLK ±
CN6007
SP_R ±
SP_L ±
CN6004 SP901 (LCH)
(SPEAKER)
SP901 (RCH)
(SPEAKER)
CN6005
D0 ± − D1 ±, CLK ±
LCD_DR0-DR7
I2C_SDA, I2C_SCK, XPJ_RESET
XPJ_PARK
PJ_TEMP_AD
XPJ_PARK
PJ_TEMP_AD
D/A CONVERTER
AUDIO AMP
(6/12)
IC2701
IC1301
(1/2)
PJ50/PJ50E/PJ50V/PJ50VE
PJ50/PJ50E/
PJ50V/PJ50VE
XR160/XR160E XR160/XR160E
PJ50/PJ50E/PJ50V/PJ50VE
CLOCK
GENERATOR
(2/12)
IC1302
CLK_CMOS_IN_GEN
CLK_SYS_IN
CLK_CMOS_IN
D0±−D1±,CLK±
LCD_XVD/XHD
XCS_LCD
XBB_RST
AV_SO/SCK
PANEL_NOR/REV
TP_X/Y/SEL1
XPJ_PARK
PJ_TEMP_AD
SP_L ±
SP_R ±
D0±−D1±,CLK±
XVS, XHS
SDI,SCK,XCE
DCKP,DCKM
INCK
XCLR
X1302
60MHz
XTALLY_LED
SIRCS
(1/7)
IC4001
SIR_RXD SIR_RXD
PANEL
OPEN/CLOSE
DETECT
(1/12)
IC1001
Q1001
XPANEL_POWER
_ON
BUILT IN USB
USB_D±
I2C_SDA/SCK
FC_DIR_A/B, FC_ENB
XR160/XR160E
PJ50/PJ50E/
PJ50V/PJ50VE
GSENSE_X/Y/Z
GSENSE_REF
GSENSE_X/Y/Z
GSENSE_REF
3AXIS
ACCELERATION
SENSOR
(7/7)
SE9501
PJ50/PJ50E/PJ50V/PJ50VE PJ50/PJ50E/PJ50V/PJ50VE
D1
D10
K9, J9
J3
49,47,
48,46,
44,50
32,38,
37,35,
36,34
26,27,
28,29
31,30
40,41
23
42
19,20
13,14
17,18
15,16
11,10
6
9,8
3
2
20,22,
21,23,
17,18
15,14,
13,12
1,4,
2,3
7
9
6
27,28
25,26
33,31,
30
35,37,
36
39
1
2
3
1
5
PITCH AMP
IC5203
YAW AM P
(3/7)
IC5204
(3/7)
26,25,
23,22,
17,16,
14,13
10,9
20,19
8-6
2
5
21,18,
12,9,
20,17,
11, 8
24,25
14,15
26 - 28
32
29
68,66,
64
55
70
50
46
48
52
63
71
59
41
75
51
38
28,32,
30
54
33,35,
37
58
83
67
56
36
79
24
42
74
45,47,
49
4
3
2
11
15
19
94
92
60
68,66,
64
55
70
50
46
48
52
63
71
59
41
75
51
38
28,32,
30
54
33,35,
37
58
83
67
56
36
79
24
42
45,47,
49
11
15
19
94
86 86
92
60
AK28
B12
C12
K11
M5
L3
J1
M2
L1
K2
D3
D5
D6
M7
L6
D1
C5
E2
A11
A10
A9
C1
E3
E4
E6
9
8
1
10
2
4
5
9
1
10
6
7
3
10
8
6
1
14
8,9,5,6,2,311,1216,15
19
20
13,11,9,7,5,317,1523,22
25
AH2
AL24
AJ24
AK26
A8
K2
SWITCH
USB SWITCH
(12/12)
IC9105
B8
E2
C2
3, 2
3, 2
1
4
L3
L2
SWITCH
2
5
4, 1
4
3
17 - 10
8, 7, 9
5, 6
54,56,
38,36,
32,30,
26,24
13,15,
19,9
23,25,
29,31,
35,37,
41,43
55,53,
49,47,
42,44,
49,50
1. 2
1. 2
16
3,5,12
17
9
4
58,60,
48,50,
44,46,
54,56
32,31,29
8, 6
11,12,17
33
53
58
4, 2,
14, 12,
18, 16,
8, 6
30,31,33
54, 56
51,50,45
1052
557
2, 160, 61
40, 4122, 21
29
W1,W2
H2,H1
32
OVERALL (1/2)
(PAGE 4-1)
1
OVERALL (1/2)
(PAGE 4-1)
1
OVERALL (2/2)
(PAGE 4-2)
3
4
1
3
OVERALL (2/2)
(PAGE 4-1)
2
AF2
AD30
AC30,AC29
88 88
SWITCH
3, 2
7,9
4,6
OVERALL (2/2)
(PAGE 4-2)
4
LEVEL SHIFT
LEVEL SHIFT
76,77,
78
74
76,77,
78

4-2
HDR-PJ50/PJ50E/PJ50V/PJ50VE/XR160/XR160E_L3
MSX_BS/CLK
MSX_BIO_0 - MSX_BIO_7
PDATA0 - PDATA7
MS-454 BOARD
CN8003CN8001
MSX_BS/CLK
MSX_BIO_0 - 7
MEMORY STICK
PRO DUO
TE0_XSDCD
MSX_INS_HIZ
TE0_DAT_0 - 3
TE0_XSDCD
TE0_CMD/SDWP/CLK
MSX_INS_HIZ
TE0_DAT_0 - 3
TE0_CMD/SDWP/CLK
XMS_ACC_LEDXMS_ACC_LED
D8001
(2/2)
(MS ACCESS)
FR_XRESETFR_XRESET
SD
FP-1313 FLEXIBLE
BOARD
VC-621 BOARD (2/2)
FP-1325 FLEXIBLE
BOARD (2/2)
GP-037 BOARD
PJ-104 BOARD FP-1319 FLEXIBLE
BOARD
PD-432 BOARD
(2/2)
FP-1326 FLEXIBLE
BOARD (2/2)
FP-1327
FLEXIBLE
BOARD
FP-1328 FLEXIBLE
BOARD
ST-248 BOARD FP-1322 FLEXIBLE
BOARD
PITCH_AD
SE7501 CRESET_P
YAW_AD
RESET
S8001
(2/3)
TE0_DAT_0 - 3
TE0_CMD/SDWP/CLK
XMS_ACC_LED
FR_XRESET
PITCH_AD
CRESET_P
YAW_AD
PITCH_AD
CRESET_P
YAW_AD
MSX_BIO_0-7
MSX_BS/CLK
MSX_INS_HIZ
PITCH/YAW
SENSOR
CN1012
CN1009
P_L_i_SW
PLAY_SW
PROJECTOR_SW
PLAY_SW
POWER_SW
KEY_AD2
XPOWER_TACT_SW
TE0_XSDCD
CONTROL SWITCH BLOCK
CONTROL SWITCH BLOCK
MEMORY CARD
SLOT
SS
MODE_SW
PHOTO_REC
PHOTO_FREEZE
START/STOP
PHOTO_FREEZE
PHOTO_REC
MODE_SW KEY_AD1
ZOOM_VR_AD
XCAM_LED
XPHOTO_LED
XCHARGE_LED
SS
KEY_AD1
ZOOM_VR_AD
XCAM_LED
XPHOTO_LED
XCHARGE_LED
SS
KEY_AD1
ZOOM_VR_AD
XCAM_LED
XPHOTO_LED
XCHARGE_LED
ZOOM_VR
CAM_LED
PHOTO_LED
CHARGE_LED
D001-D003
S001-S004
(PS38900)
( SK37000: XR160/XR160E )
( SK38010: PJ50/PJ50E/PJ50V/PJ50VE )
RV001
CN8002
S001,S002,S004
PJ50/PJ50E/PJ50V/PJ50VE
S001,S002
XR160/XR160E
CN1010(2/2) CN6006
CN7201 CN7204CN1002
CN1001
CN9201CN6001 (2/2)
CN8503
CN8501
CN8502
GPS_UART_RXD
GPS_UART_TXD
GPS_UART_CTS
GPS_UART_RTS
GPS_UART_RXD
(XR160/XR160E)
GPS_UART_TXD
GPS_UART_CTS
GPS_UART_RTS
STROBE_ON
XSTRB_FULL
I2C_SDA/SCK
HC_SEL
XSYS_RST
STROBE_ON
XSTRB_FULL
I2C_SDA/SCK
EDLC_BAL
XSYS_RST
SHOE_MIC_FL
XSYS_RST
SHOE_MIC_FR
HOTSHOE_ID1
HOTSHOE_ID2
LANC_SIG
EXT_STROBE_ON
SHOE_MIC_FL
HOT
SHOE
SHOE_MIC_FR
HOTSHOE_ID1
HOTSHOE_ID2
LANC_SIG
EXT_STROBE_ON
D1302
D1301
STROBE_ON
XSTRB_FULL
I2C_SDA/SCK
LED1_3_K
LED2_K
TH
LED1_3_K
LED2_K
TH
EDLC_BAL
XSYS_RST
GPS_UART_RXD
GPS_UART_TXD
GPS_UART_CTS
GPS_UART_RTS
SIN0/RX0_1
SCK0/TX0_1
XSCS0/CTS_1
SO0/RTS_1
X9201
16.368MHz
(PJ50/PJ50E/PJ50V/PJ50VE)
D001, D002
(FLASH)
TH001
DMD_D0 - D11
DMD_SAC_BUS
DMD_STRB/0EZ
DMD_LOADB/SCTRL
DMD_DCLK/BUS
LED_SEL0
LED_SEL1
PDATA8 - PDATA15
PDATA16 - PDATA23
VSYNC_WE, HSYNC_CS
DATEN_CMD, PCLK
SDA/SCL_2601,
DPP_RESETZ
PARKZ
CN5503CN5505
DMD_D0 - D11
DMD_SAC_BUS
DMD_STRB/OEZ
DMD_LOADB/SCTRL
DMD_DCLK/BUS
RED_STROBE
BLU_STROBE
GRN_STROBE
LEDDRV_ON
SDA/SCL_2601
LED_ANODE
PROJECTOR
UNIT
RED_CATMODE
GRN_CATMODE
BLU_CATMODE
PJ_TEMP_AD
MEMO_A0 - A12
MEMO_DQ0 - DQ15
OVERALL (1/2)
(PAGE 4-1)
2
PJ50V/PJ50VE
PJ50/PJ50E/PJ50V/PJ50VE
OVERALL (1/2)
(PAGE 4-1)
3
PJ50/PJ50E/PJ50V/PJ50VE
FR_XRESET TE0_XSDCD MSX_INS_HIZ
(1/2)
08
OVERALL (1/2)
(PAGE 4-1)
4
XGPS_RST XGPS_RST XGPS_RST XGPS_RST
X8601
16.7MHz
FLEXIBLE
FLAT
CABLE
(FFC-254)
AUDIO SIGNAL
VIDEO SIGNAL
VIDEO/AUDIO SIGNAL
MEMO_CLK_N/P
MEMO_BA0/BA1
MEMO_LDM/UDM
MEMO_LDQS/UDQS
MEMO_CASZ/RASZ/CSZ
MEMO_CKE/WEZ
CN1003
SATA_RX0SIP/RX0SIN
HDD_UNLOAD
SATA_TX0SOP/TX0SON
HW_UNLOAD
B +/-
A +/-
HARD DISK DRIVE
FP-1329 FLEXIBLE
BOARD
SATA_RX0SIP/RX0SIN
HDD_UNLOAD
SATA_TX0SOP/TX0SON
160GB :
XR160/XR160E
220GB :
PJ50/PJ50E/PJ50V/PJ50VE
10,8,11,16,2,4,13,2021,23,1,3
24
14
42,44,41,30,51,48,35,20
16
34
11
12
58
55
60
19,17,52,49
16
34
11
12
58
55
60
6 6
4 4
5 5
33
2 2
8 8
6,15,26
42,44,41,30,51,48,35,2046,14,32
7,17
45,28 45,28
19,17,52,4946,14,32
5
7
10
12
8
13
4
15
LANC INTERFACE,
HI PROCESSOR
(11/12)
CPU,
AV SIGNAL,
LENS CONTROL,
MODE CONTROL,
HIDMI PROCESS
(2/12-4/12)
IC4801
(2/2)
2
3
4
2
3
4
37
38
46
47
15
16
9, 10
14
13
15
16
9, 10
14
18 - 22
3-7
1
13
25
24
16
15
2
4
1
3
4
2
3
1
GPS
IC9204
RF AMP
(SAW FILTER)
SF9202
(SAW FILTER)
SF9201
IC9203
RF AMP
IC9202
AT9201
E7
IC7201
LED
CONTROL
23, 25,
29, 31,
35, 37,
41, 43
55, 53,
49, 47,
42, 44,
48, 50,
56, 54,
38, 36,
32, 30,
26, 24
13, 15,
9, 19
3, 5,
12
16
7
DMD
CONTROL
(2/4)
IC8605
25, 3,
7, 11,
13, 15,
23, 19,
8, 4,
14, 12
32
29, 36
20, 24
18, 28
25, 3,
7, 11,
13, 15,
23, 19,
8, 4,
14, 12
29, 36
20, 24
18, 28
25, 3,
7, 11,
13, 15,
23, 19,
8, 4,
14, 12
29, 36
20, 24
18, 28
LED
DECODER
(2/4)
IC8601
SDRAM
(3/4)
IC8701
INVERTER
(2/4)
IC8602
LED
DRIVE
(4/4)
IC8801 1, 2
3, 4
7, 8
9, 10
6
4
2
5
3
1
10
11
8
5
3
4
IC1301
(2/2)
K2
8 8
36
26
K15
J15
32 32
2
3
4
5
8, 9
15
11,12
4-2. OVERALL BLOCK DIAGRAM (2/2)( ) : Number in parenthesis ( ) indicates the division number of schematic diagram where the component is located.

4-3
HDR-PJ50/PJ50E/PJ50V/PJ50VE/XR160/XR160E_L3
BT901
BATTERY
TERMINAL
CN1008
ACV_UNREG_CN
+
S
–
Q4103
ACV/BATT SWITCH
Q4101, Q4102
BATTERY CHARGE
SWITCH
D4101
F0003 (F3) L4301
F0004 (F4)
DC/DC CONVERTER
FRONT CONTROL
(10/12)
IC4301
LX1a
FB1
LX1b
L4306
LX6a
FB6
LX6b
L4305
LX5a
FB5
LX5b
L4302
LX2
FB2
LDO1_SOURCE
TE0_VCC REG
(10/12)
IC4304
VOUT
VIN
EN
DD_ON
Q4305
F0002 (F2)
BATT_UNREG
D_1.2V
L4303
LX3a
FB3
LX3b
LD02_SOURCE
D_1.8V
VREG_3.0V
DD_ON
L4304
LX4
FB4
AU_2.8V
D_2.8V
A_3.3V
MEDIA_3.3V
D_3.3V
SD_PWR_ON TE0_VCC
TE1 VCC
SWITCH
Q4301-Q4303
TE1_VCC
PJ50/PJ50E/
PJ50V/PJ50VE
MMC_PWR_ON1/IC_4301_CP_OUT
MEDIA_3.3V
D_3.3V
J_5.0V
A_5.0V
MT_5.0V
MT_5.0V
BL REG
(10/12)
IC4303
VOUT
VIN
LX
BL_H
LCD_CABC_PWM
L4307
F4301
EN
FB BL_L
LDO2_OUT
HB_1.2V
HB_1.8V
LDO1_OUT
CORE_UNREG
I/O_UNREG
MT_UNREG
Q4304
BATT_UNREG_SENSE
XLANC_PWR_ON
XLANC_ON
BATT_IN
XCS_ROUGE
XUSB_INIT_CHG DC/DC CONVERTER
LANC DRIVE
(10/12)
IC4302
F0005 (F5)
F0001 (F1) ACV_UNREG
CN1011
CN1003
CN0201
FP-1323 FLEXIBLE
BOARD
FP-1329 FLEXIBLE
BOARD
CN9102
CN9101
USB_VCC_MINI
(USB-mini)
(USB)
USB_VCC_STD
A/V R
LANC_DC
TE1_VCC 3.3V
LANC_DC
CURRENT CONTROL
(12/12)
IC9102
CN1006
HDMI_5V
ACV_ON
BATT_ON
BATT/XEXT_CN
Q9101, Q9102
CURRENT
CONTROL
CURRENT LIMITTER
(12/12)
IN
X_FAULT
VBUS_XOVR_CUR
IC9101
VBUS_EN
VBUS_UNLIMIT
IN OUT
USB_VCC_
STD_LIM
BUS_A
BUS_B
VOLTAGE
MANEGEMENT
(12/12)
IC9107
Q9119,Q9120
VBUS
SWITCH VBUS
EN_CH
BOOSTER
PROCESSOR
(12/12)
IC9108
L9101
D9103
Q9117,
Q9118,
Q9121
F0007 (F7)
BATT_UNREG_CN
Q9110,Q9111
D9102
XUSB_CHG_ON
XBUS_DET_STD_A
XUSB_INIT_CHG
REF
J_5.0V
VOLTAGE MONITOR
(12/12)
VDD OUT
IC9106
Q9109
SWITCH
Q9106,Q9114
XCHG
Q9107,
Q9115
BATT_IN
BATT_UNREG
D_1.8V
A_1.8V
D/A CONVERTER
AUDIO AMP
(6/12)
IC2701
D_2.8V
LANC INTERFACE,
HI PROCESSOR
(11/12)
IC4801
L1301
A_2.8V_IC_1301_1
D_1.8V_IC_1301_2
D_1.8V_IC_1301_1
AVDD18_SUBL
A_1.8V
A_1.125V
A_1.25V_SENSE
SD_PWR_ON
MMC_PWR_ON1
LCD_CABC_PWM
MS_PWR_ON
L1302
CLOCK
GENERETOR
(2/12)
IC1302
X1302
60MHz
D_1.8V_IC_1301_3
D_2.8V_IC_1301_2
D_2.8V_IC_1301_1
CPU,
AV SIGNAL,
LENS CONTROL,
MODE CONTROL,
HDMI PROCESS
(2/12 - 4/12)
IC1301
(1/2)
L2601
AUDIO I/O
(5/12)
IC2601
L2802
AU_2.8V_ACO
D/A CONVERTER,
VIDEO AMP
(7/12)
IC2801
L2801
L2803
MT_5.0V
A_1.8V
VC-621 BOARD (1/2)
BATT_UNREG_CN
BATT/XEXT_CN
BATT_SIG
OUT
LK
INP
INP
B0
FR_EVER_
SI/SO/SCK
XCS_
ROUGE
Q9108
USB SW
(12/12)
IC9104
Q9105
OUT
EN
USB SWITCH
(12/12)
IC9103
GPIO_S__2
GPIO_SB__5
VBUS_EN
VBUS_UNLIMIT
FRC_RTG_IN1
LCD_CABC_PWM
GPIO_S__4
GPIO_S__6
J_5.0V
CN1001
FP-1352 FLEXIBLE
BOARD
HDMI
+5V_POWER
ACV_UNREG
CS
PVDD_LP02
VTR_UNREG
FR_EVER_
SO/SCK
VuC
BATT_UNREG
EVER3
XLANC_ON
XLANC_PWR_ON
UNREG_IN
CS
ACV_ON
BATT_ON
LDO1_OUT
LDO1_FB
PVDD_LDO1
LDO1_ON
LDO2_OUT
LDO2_ON
LOAD_IN
LOAD_OUT
LOAD_ON
DD_ON
VCH
LANC_DC
D_1.2V
A_1.125V_SENSE
A_1.125V
HDMI_5V
DD_ON
MS_PWR_ON
MSX_3.3V
DD_ON
BATT_LI_3V
LANC_DC
LDO1_ENB
PVDD1a
PVDD1b
PVDD2
PVDD3a
PVDD3b
PVDD4
PVDD5a
PVDD5b
PVDD_CP
AVDD
PVDD6a
PVDD6b
LDO2_ENB
A_1.8V
A_2.8V
A_VID_1.1V
D_VID_1.1V
XO_USB_CHG_FET_ON
LDO1_ON
VOUT
EVER_3.0V
ACV_ON
BATT_ON
LDO2_ON
A_2.8V
D_1.8V
A_3.3V
D_2.8V
D_3.3V
MEDIA_3.3V
TE0_VCC
A_VID_1.1V
D_VID_1.1
HB_1.2V
HB_1.8V
A_2.8V
D_2.8V
HDMI_5.0V
AU_2.8V
BATT_GND
ACV_GND
Q1001
SE1001
(1/12)
XPANEL_POWER_ON
LANC_SIG
LANC_SIG
LANC_SIG LANC_SIG
L2602
MIC_VCC
CP_OUT IC_4301_CP_OUT
D_1.2V
D_1.8V
A_1.8V
D_2.8V
A_3.3V
D_3.3V
TE0_VCC
J_5.0V
MT_5.0V
MSX_3.3V
BATT_LI_3V
MIC_VCC
EVER_3.0V
SHOE_UNREG
AVDD18_SUBL
A_5.0V
A_2.8V
MIC_VCC
AVDD18_SUBL
EVER_3.0V
F0006 (F6) SHOE_UNREG
IRIS1 SHOE_ON
Q4104,Q4105 SHOE_UNREG
VBUS SWITCH
(12/12)
IC9105
LCD
AMP
(8/12)
IC3301 A_1.8V
PJ50/PJ50E/PJ50V/PJ50VE
PJ50/PJ50E/PJ50V/PJ50VE
BL_H, BL_L
PJ50/PJ50E/PJ50V/PJ50VE
PJ50/PJ50E/PJ50V/PJ50VE
PJ50/PJ50E/PJ50V/PJ50VE
D1
D2
B8
C5
A6
F5
D3
A2
C4
B4
B2
SWITCH
C7
H7
E4
H4
E3
G4
5
1
3
E8
D5
E7
5
6
1
4
3
A5
D6
A4
E1
E2
C8
A1
B1
H6
H5
G5
H2
B7
D8
D7
B1
A1
B2
C1
A3
A5
B6
A6
B5
D2
F5
SWITCH
E1
F6
C2
C4
E4
F4
4
3
2
5
7
2,3
4
G1 G6
E3K9
C1
A7
F1
E3
A4
E6
D1
E5
D3
C4
F2
F10
A4
H9
C7
Q4801
SWITCH
D6
61
4
3
A3,B3,D3,A4-D4
A1-D1
A5,B5
3,14,15
1
19
20
17
18
12
7
SWITCH
24SWITCH
B2
SWITCH
COM137
COM134
COM135
COM139
COM138
COM136
COM132
COM133
SWITCH
E2
1
AF10
Y10
P26
P24
R25
T25
AE21
AD19
XPUIO_BATT_SIG
O_INIT_CHARGE
PUI_BATT_XEXT
XCS_DD
DD_ON
XO_CS_DDCON
XO_CS_ROUGE
J10
XO_INIT_USB_CHG
XPUI_LANC_PWR_ON
H2
XO_LANC_IC_ON
I_BATT_IN
O_LDO1.2_ON
K9
XO_CS_ROUGE
O_LDO1.8_ON
O_SYS_DD_ON
SWITCH
SWITCH
24 18
CS
INIT_CHARGE_ON
BATT_SIG
1
6
SWITCH
GMR PANEL
OPEN/CLOSW
DETECT
32
C5
G2
SWITCH
A16
COM131
DC IN
J901
DC JACK HARNESS
POWER (2/2)
(PAGE 4-4)
A
HARD DISK DRIVE
160GB :
XR160/XR160E
220GB :
PJ50/PJ50E/PJ50V/PJ50VE
4-3. POWER BLOCK DIAGRAM (1/2) ( ) : Number in parenthesis ( ) indicates the division number of schematic diagram where the component is located.

HDR-PJ50/PJ50E/PJ50V/PJ50VE/XR160/XR160E_L3
4-4. POWER BLOCK DIAGRAM (2/2) ( ) : Number in parenthesis ( ) indicates the division number of schematic diagram where the component is located.
4-4E
POWER (1/2)
(PAGE 4-3)
A
FP-1325 FLEXIBLE
BOARD
PD-432 BOARD
CN6001
A_1.8V
BL_H, BL_L
EP_2.8V
A_1.8V
BL_H, BL_L
D_2.8V
CN1010 CN6203
L6001
TOUCH
PANEL
INTERFACE
Q6001, Q6002
SE6001
PANEL
NORMAL/REVERSE
DETECT
A_1.8V
BL_H,BL_L
D_2.8V D_2.8V
3.0 INCH
WIDE COLOR
LCD
LCD901
(LCD MODULE)
LCD BACKLIGHT
GMR
POWER CONTROL
(1/4)
VOUTA
SW
VINB
IC8502
ENA
ENB
VOUTB
DMD_VOFS
DMD_VBIAS
POWER CONTROL
(1/4)
LX2
VIN1
VIN2
IC8503
EN1
EN2
LX1
P1P8V
P1P0V
L8501
L8503
LED DECODER
(2/4)
IC8601
INVERTER
(2/4)
IC8602
DMD CONTROL
(2/4)
IC8605
LED DRIVE
(4/4)
IC8801
SDRAM
(3/4)
IC8701
POWER_EN
INVERTER
(1/4)
OUTY
VCC
INA
IC8501
DMD_EN
DMD_PWREN
VFLASH
VFLASH
L8504
PJ_SYSPWR
D8501,D8502 FP-1319
FLEXIBLE
BOARD
CN8501
CN8503
DMD_VOFS
DMD_VBIAS
P1P8V
DMD_VRST
DMD_VRST
CN5505 CN5503
PROJECTOR UNIT
PJ-104 BOARD
A_5.0V
D_3.3V
POWER_EN
CN6007
D_3.3V
A_5.0V
PJ_PWR_EN
A_5.0V
D_3.3V
PJ_PWR_EN
2.8V REG
VOUT
VIN
ON_OFF
IC9201
L9214
GPS
IC9204
CN9201CN6006
D_3.3V
D_2.8V
D_3.3V
G_2.8V
L9201
L9202
RF AMP
IC9202
IC9203
X9201
16.368MHz
L9206
GP-037 BOARD
IRIS/ND/FOCUS
DRIVE
(2/7)
VOUT
VDD
CE
IC5201
MA_R_2.8V
A_3.3V
Q4001
PI_A
D_2.8V
XZM_RST_LED
CN4001
CN4002
D_1.8V
2.8V REG
(2/7)
IC5202
PITCH AMP
(3/7)
IC5203
YAW AMP
(3/7)
IC5204
STEADYSHOT
PROCESSOR
(3/7)
IC5501
SIRCS
(1/7)
IC4001
ROLL SENSOR
(4/7)
SE7701
ROLL SENSOR
AMP
(4/7)
IC7701
MT_5.0V
MA_R_2.8V
PI_A
MA_R_2.8V
D4001 (TALLY)
MT_5.0V
D_1.2V
A_2.8V
LENS
BLOCK
MT_5.0V
CN4005
MIC_VCCMIC_VCC
A_3.3V
D_2.8V
XZM_RST_LED
D_1.8V
D_1.2V
A_2.8V
MT_5.0V
CN1007
LD-279 BOARD
CN4003
CN4006
D_2.8V CPC
(FOR CHECK)
MIC_VCC MICROPHONE
UNIT
LED
CONTROL
IC7201
ST-248 BOARD
D0001,D0002
(FLASH)
VOUT_LED_A
CN7201CN7204
J_5.0V
D_2.8V
FP-1322 FLEXIBLE
BOARD
VOUT_LED_A J_5.0V
D_2.8V
FP-1327 FLEXIBLE
BOARD
CN1002
J_5.0V
D_2.8V
SHOE_UNREG
FP-1328 FLEXIBLE
BOARD CN1001
SHOE_UNREG
HOT
SHOE
LND002
FP-1313 FLEXIBLE
BOARD
CN1012
D_2.8V
D8001
(MS ACCESS)
MS-454 BOARD
CN8003
CN8001
MSX_3.3V
TE0_VCC
D_2.8V
MSX_3.3V
TE0_VCC
A_2.8
PITCH/ YAW
SENSOR
SE7501
(1/2)
EVER_3.0V
A_2.8
BT8001
LITHIUM
SECONDARY
BATTERY
MSX_3.3V
TE0_VCC
D_2.8V
A_2.8
EVER_3.0V
CN8002
D001-D003
LED_VDD
CHARGE_LED_VDD
CONTROL SWITCH BLOCK
(PS38900)
BATT_LI_3V
BATT_LI_3V
BATT_LI_3V
D_1.2V
D_1.8V
A_1.8V
D_2.8V
A_3.3V
D_3.3V
TE0_VCC
A_5.0V
MT_5.0V
MSX_3.3V
BATT_LI_3V
MIC_VCC
EVER_3.0V
A_2.8V
CPU,
AV SIGNAL,
LENS CONTROL,
MODE CONTROL,
HDMI PROCESS
IC1301
(2/2)
(2/12 - 4/12)
AVDD18_SUBL
A_3.3V
CN6901 CN1004
CM-114 BOARD
CMOS
IMAGER
CP002
FP-1324 FLEXIBLE
BOARD
LVDS_I/O_1.8V
LVDS_I/O_1.8V
D_1.8V
D_1.8V D_1.8V
A_2.7V CMOS_A_3.3V CMOS_A_3.3V
2.7V REG.
OUT
CE
IN
IC6902
AVDD18_SUBL
VC-621 BOARD (2/2)
BL_H,BL_L
PJ50/PJ50E/PJ50V/PJ50VE
PJ50/PJ50E/PJ50V/PJ50VE PJ50/PJ50E/PJ50V/PJ50VE
PJ50/PJ50E/
PJ50V/PJ50VE
XR160/XR160E
PJ50/PJ50E
(XR160/XR160E)
FP-1326 FLEXIBLE
BOARD
PJ_PWR_EN
XZM_RST_LED
UART1_RXD
GPIO_SB__2
J_5.0V
SHOE_UNREG
PJ50/PJ50E/PJ50V/PJ50VE
PJ50/PJ50E/PJ50V/PJ50VE
2.8V REG
(1/2)
Vout
VDD
CE
IC6001
( PJ50/PJ50E/PJ50V/PJ50VE )
PJ50/PJ50E/PJ50V/PJ50VE
EVER_3.0V
PJ50/PJ50E/
PJ50V/PJ50VE
7
14,13
55
48,49
37
38, 39
25
26, 27
25
2
7
8
11
4
9
5
8
3
1
6
10
4
5
1
4,6,8,10
20
18
30
1,2,21,22,41,42
31
39
30
1,2,21,22,41,42
31
39
30
31
39
20
18
28
18,19,20
26
34
42,43,44
36
1
2
3
7
6
7
6
COM601
3
4
SWITCH
1
4,5
8,1032,34
91
89
90
95,97,99
44
87
84
91
89
90
95,97,99
44
87
84
2323
1,3,5
5
12
1-3
12
8-17
12
1-3
12
12
6, 7
23 - 25
7
37 - 39
23 - 2537 - 39
7
54 54
MEMORY CARD
SLOT
19
12
11 99
10
10
F7
V24
32
31
2
3
30 4
1
34
9
24
1,2,21,22,41,42
4,6,8,10
3
4
1E7

HDR-PJ50/PJ50E/PJ50V/PJ50VE/XR160/XR160E_L3
5. FRAME SCHEMATIC DIAGRAMS
5-1E
5-1. FRAME SCHEMATIC DIAGRAM
LENS
BLOCK
MIC901
(MIC UNIT)
PROJECTOR
UNIT
LCD901
(LCD MODULE)
3.0 INCH
WIDE COLOR
LCD
BACKLIGHT
TOUCH
PAN EL
(USB)
J901
DC IN
BT901
BATTERY
TERMINAL
SD
CONTROL SWITCH BLOCK
SP901 (L CH)
(SPEAKER)
HDMI
EXT MIC
J0302 J0301
(FOR CHECK)
A/V R
LITHIUM
SECONDARY
BATTERY
BT8001 CONTROL SWITCH
BLOCK (PS38900)
(HEADPHONE)
(USB-Mini)
DC JACK HARNESS
SP902 (R CH)
(SPEAKER)
CPC
XR160/XR160E)
(SK38010: PJ50/PJ50E/PJ50V/PJ50VE)
(SK37000:
101
331
116
331
61 1 61 1
61 1
61 1
124
160GB :
XR160/XR160E
220GB :
PJ50/PJ50E/PJ50V/PJ50VE
2
1
32
33
CN6901
CM-114 BOARD
(SIDE A)
CM-114 BOARD
(SIDE B)
(Not supplied)
CP002
61 1
61 1
1
2
3
4
1
2
3
4
2
13233
1
2
9
10
1
1
2
25
26
16
7
8
9
5
CN1005
CN1006
CN9101
CN9102
5
1
2
99
100
16
1
2
5
6
2
1
60
61
110
2
1
60
61
CN1007
CN1008
CN1009
CN1010
CN1011
CN1012
VC-621 BOARD (SIDE B) VC-621 BOARD (SIDE A)
12
1
2
99
100
16
CN4005
LD-279 BOARD
(SIDE A)
PJ-104 BOARD
(SIDE B)
LD-279 BOARD
(SIDE B)
16
1
250
51
1
238
39
CN4001
CN4002
1
2
59
60
CN8503
110
CN8501
CN8502
242 4446
141 4345
PJ-104 BOARD
(SIDE A)
112116
CN1001CN1002
116
CN1003CN1004
LENS
BARRIER
UNIT
XR160/XR160E PJ50/PJ50E/PJ50V/PJ50VE
FP-1313
FLEXIBLE
BOARD
RESET
IC1301
(Not supplied)
S8001 SE7501
(PITCH/YAW)
B to B Connector
242
CN5503
CN5505
141
44 46 43 45
242 4446
141 4345
HARD
DISK
DRIVE
HOT
SHOE
FP-1326
FLEXIBLE
BOARD
FP-1352
FLEXIBLE
BOARD
FP-1328 FLEXIBLE
BOARD
FP-1325
FLEXIBLE
BOARD
PJ50/PJ50E/PJ50V/PJ50VE
XR160/XR160E
FLEXIBLE FLAT CABLE
(FFC-254)
PJ50/PJ50E/PJ50V/PJ50VE
PJ50/PJ50E/PJ50V/PJ50VE
PJ50V/PJ50VE
FP-1324 FLEXIBLE
BOARD
FP-1329
FLEXIBLE
BOARD
FP-1327 FLEXIBLE
BOARD
CN7201
CN7204
ST-248 BOARD (SIDE A)
FP-1322 FLEXIBLE
BOARD
FP-1320 FLEXIBLE
BOARD
18
CN9201
2
160 61
1
768
1
238
39
12
12
18
1
2
59
60
CN6001
CN6002
CN6003
CN6004
CN6005
CN6006
CN6007
PD-432 BOARD
(SIDE A)
FP-1319
FLEXIBLE
BOARD
FP-1321 FLEXIBLE
BOARD
1
110
26
2728
CN8001
116
2
160
61
CN8002
CN8003
GP-037 BOARD
(SIDE B) GP-037 BOARD (SIDE A)
2219 20 23
1
21
CN1001
116
24 1
MS-454 BOARD (SIDE A) MS-454 BOARD (SIDE B)
CN4006
CN4004 CN4003
24 1
16 1
116
112
112
26 1
BH8001
CN0201
1
11
12
13
14
10

6-1
HDR-PJ50/PJ50E/PJ50V/PJ50VE/XR160/XR160E_L3
6. SCHEMATIC DIAGRAMS AND PRINTED WIRING BOARDS
– ENGLISH – – JAPANESE –
Precautions for Replacement of Imager
• If the imager has been replaced, carry out all the adjustments
for the camera section.
• As the imager may be damaged by static electricity from its
structure, handle it carefully like for the MOS IC.
In addition, ensure that the receiver is not covered with dusts
nor exposed to strong light.
イメージャ交換時の注意
・イメージャを交換した場合は，カメラ部の全調整を行って
ください。
・イメージャは構造上，静電気により破壊される恐れがある
ため，MOSICと同様に注意して取り扱ってください。
 また，受光部にはゴミの付着，および強い光がはいること
のないように注意してください。
The components identified by mark 0
or dotted line with mark 0are critical
for safety.
Replace only with part number specified.
Les composants identifiés par une mar-
que 0sont critiques pour la sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
When indicating parts by reference num-
ber, please include the board name.
0印の部品，または0印付の点線で囲まれた部品は，
安全性を維持するために，重要な部品です。
従って交換時は，必ず指定の部品を使用してください。
図面番号で部品を指定するときは基板名又はブロック
を併せて指定してください。
お願い
THIS NOTE IS COMMON FOR SCHEMATIC DIAGRAMS AND PRINTED WIRING BOARDS
(In addition to this, the necessary note is printed in each block)
回路図，プリント図共通ノート
（他に必要なノートは各セクションに記載しています）
For Schematic Diagrams
• All capacitors are in μF unless otherwise noted. pF :
μF. 50 V or less are not indicated except for electrolytics
and tantalums.
• Chip resistors are 1/10 W unless otherwise noted.
kΩ=1000 Ω, MΩ=1000 kΩ.
• Caution when replacing chip parts.
New parts must be attached after removal of chip.
Be careful not to heat the minus side of tantalum capacitor,
Because it is damaged by the heat.
• Some chip part will be indicated as follows.
Example C541 L452
22U 10UH
TA A 2520
Kinds of capacitor External dimensions (mm)
Case size
• Constants of resistors, capacitors, ICs and etc with XX
indicate that they are not used.
In such cases, the unused circuits may be indicated.
• Parts with differ according to the model/destination.
Refer to the mount table for each function.
• All variable and adjustable resistors have characteristic curve
B, unless otherwise noted.
• Signal name
XEDIT →EDIT PB/XREC →PB/REC
•: non flammable resistor
• : fusible resistor
• : panel designation
• : B+ Line
• : B– Line
• : IN/OUT direction of (+, –) B LINE.
• : adjustment for repair.
For Printed Wiring Boards
• : Uses unleaded solder.
•: Circuit board
: Flexible board
Pattern from the side which enables seeing.
: pattern of the rear side
(The other layers’ patterns are not indicated)
• Through hole is omitted.
• There are a few cases that the part printed on diagram isn’t
mounted in this model.
• : panel designation
• Chip parts.
Transistor Diode
21
3
21
3
21
3
345
21
123
654
EB
C
31
5
2
46
123
654
31
5
2
46
123
54
43
12
312
45
534
12
14
23
46
2
5
31
12
43
14
23
回路図ノート
・ケミコン，タンタルを除くコンデンサで，耐圧50V以下の
ものはその耐圧を省略。単位はすべてμF（pはpF）。
・チップ抵抗で指示のないものは，1/10W以下。
 kΩ＝1000Ω，MΩ＝1000kΩ
・チップ部品交換時の注意
 取り外した部品は再使用せず，未使用の部品をご使用く
ださい。
 タンタルコンデンサのマイナス側は熱に弱いため注意し
てください。
・チップ部品には下記のように表示したものがあります。
 例 C541 L452
  22U 10UH
  TA A 2520
 種類外形寸法（mm）
   ケースサイズ
・抵抗，コンデンサ，ICなど定数にXXがあるものは，使用
していない事を示しています。このため，使用していな
い回路が記載されている事があります。
・★印のある部品は，機種などにより異なりますので機能
別マウント一覧表を参照してください。
・可変抵抗と半固定抵抗で，B特性の表示を省略。
・信号名表記について，下記のような場合があります。
 XEDIT → EDIT PB/XREC → PB/REC
・ は不燃性抵抗。
・ はヒューズ抵抗。
・ はパネル表示名称。
・ はB＋ライン。
・ はB−ライン。
・ はBライン（＋，−）の入出力方向を示す。
・ は調整名称。
プリント図ノート
・ ：無鉛半田を使用しています。
・ ：基板
 ：フレキシブル配線板
 見ている面側のパターン。
 ：裏側のパターン
 （他のパターンについては表示されていません）
・スルーホールは省略。
・プリント図には，本機で使用していない部品が記載され
ている場合があります。
・ はパネル表示名称。
• Chipparts.
 TransistorDiode
21
3
21
3
21
3
345
21
123
654
EB
C
31
5
2
46
123
654
31
5
2
46
123
54
43
12
312
45
534
12
14
23
46
2
5
31
12
43
14
23

6-2
HDR-PJ50/PJ50E/PJ50V/PJ50VE/XR160/XR160E_L3
6-1. SCHEMATIC DIAGRAMS
Note: CP002 (CMOS IMAGER) is not supplied, but this is
included in CM-114 COMPLETE BOARD.
XR160/XR160E
12345 6 7 8 9
A
B
C
D
E
F
A
B
C
D
E
F
08
R1114Q271D-TR-FA
IC6902
12
34
D_1.8V
R6908
XX
R6904
XX
REG_GND
R6905
XX
R6901
XX
LVDS_I/O_1.8V
C6906
XX
C6905
1u
C6902
XX
A_2.7V
R6907
XX
INCK
CMOS_A_3.3V
DCKP
XCLR
XCE
XHS
XVS
SDI
SCK
REG_GND
DCKM
REG_GND
A_2.7V
REG_GND
LVDS_I/O_1.8V
REG_GND
D_1.8V
R6912
XX
INCK
XCE
XVS
SDI
R6934 XX
XHS
XCLR
SCK
C6940
0.1u
C6917
0.1u
C6939
1u
C6907
1u
C6908
2.2u
C6909
0.1u
C6932
2.2u
C6933
0.1u
R6918
XX
R6909
XX
C6919 XX
R6914
XX
C6912
0.1u
C6916
0.22u
R6916
XX
C6928
2.2u C6930
1u
C6935
0.1u
C6936
0.1u
C6910
2.2u
C6920
2.2u
C6921
1u
C6925
2.2u
C6924
1u
R6915
C6923
10u
C6914
0.001u
R6919 47k
C6922
XX
R6932 1k
C6915
1u
0
DOAP
DOAM
DOBP
DOBM
DOCP
DOCM
DODP
DODM
DCKP
DCKM
DOAM
DOAP
DOBM
DOBP
DOCM
DOCP
DODM
DODP
CMOS_A_3.3V
CP002
M1
NC4
M2
NC
L3
NC
K3
NC
M3
NC
L2
NC
M4
VDDLIO1
M5
VSSLIO1
M6
VDDLIO2
M7
VSSLIO2
K5
VDDLCN2
K4
VSSLCN2
K6
VDDLCN3
K7
VSSLCN3
L5
VDDLSC1
L4
VSSLSC1
L6
VDDLSC2
L7
VSSLSC2
M8
VDDSUBD
L8
TOUT
K8
TENABLE
L9
TSCANEN
M9
NC
M10
NC
L10
NC
L11
NC
M11
NC4
K9
XVS
J9
XHS
H9
SDO
G9
SDI
F9
SCK
E10
XCE
D10
XCLR
K11
DOAM
K10
DOAP
J11
DOBM
J10
DOBP
H11
DCKM
H10
DCKP
G11
DOCM
G10
DOCP
F11
DODM
F10
DODP
E11
VDDHCM2
D11
VSSHCM2
D9
VDDLCN4
E9
VSSLCN4
A11
NC4
C11
NC
A10
NC
B11
NC
B10
NC
C10
AMON2
C9
AMON1
B9
NC
A3
VDDSUBA1
A9
VDDSUBA2
A7
VDDHDA
A8
VSSHDA
A5
VDDHPX
A6
VSSHPX
B7
NC
B6
VLOADLM
B5
VEXRES
C5
VBGR
C7
VLO
C6
VHI
A4
NC
C8
VDDLCM2
B8
VSSLCM2
C4
VDDLCM1
B4
VSSLCM1
B3
NC
C3
NC
A2
NC
B2
NC
C2
NC
A1
NC4
B1
NC
C1
NC
D2
NC
E2
NC
E1
VDDHCM1
D1
VSSHCM1
G1
VDDHVS
F1
VSSHVS
H1
VDDHCP
H2
VSSHCP
F3
NC
F2
VRL
G2
VCP
G3
VBO
H3
NC
D3
VDDLCN1
E3
VSSLCN1
K1
VDDLPL
K2
VSSLPL
J1
NC
J2
NC
J3
INCK
L1
NC
CN6901 33P
1 REG_GND
2 INCK
3 REG_GND
4 REG_GND
5XCLR
6XCE
7SCK
8SDI
9XHS
10 XVS
11 REG_GND
12 REG_GND
13 DODM
14 DODP
15 REG_GND
16 DOCM
17 DOCP
18 REG_GND
19 DCKM
20 DCKP
21 REG_GND
22 DOBM
23 DOBP
24 REG_GND
25 DOAM
26 DOAP
27 REG_GND
28 REG_GND
29 REG_GND
30 CMOS_A_3.3V
31 D_1.8V/D_2.8V
32 LVDS_I/O_1.8V
33 REG_GND
XX
IC6903
12
34
R6920
XX
C6927
10u
C6926
XX
C6918
XX
D_1.8V
CL6901
CL6902
CL6903
CL6904
LF6901
2
1
34
LF6902
2
1
34
LF6903
2
1
34
LF6904
2
1
34
LF6905
2
1
34
C6941
0.01u
D_1.8V
C6903
1u
OUT
2.7V REG.
GND
GND
CE
OUT
IN
CE IN
XX MARK:NO MOUNT
CMOS IMAGER
FP-1324
(PAGE 6-32)
FLEXIBLE
CMOS IMAGER
IMX055CHL-13: XR160/XR160E
CM-114 BOARD
LND001
IMX055CHL-23: PJ50/PJ50E/PJ50V/PJ50VE

6-3
HDR-PJ50/PJ50E/PJ50V/PJ50VE/XR160/XR160E_L3
CN1007
(PAGE 6-10)
VC-621
(1/12)
LND001
(PAGE 6-9)
MICROPHONE
UNIT
LENS BLOCK and LENS BARRIER UNIT are not included
in LD-279 COMPLETE BOARD.
LENS BLOCK is replaced as block,
so that PRINTED WIRING BOARD is omitted.
Note 1:
Note 2:
XR160/XR160E
PJ50/PJ50E/PJ50V/PJ50VE
PJ50/PJ50E/PJ50V/PJ50VE
XR160/XR160E
PJ50/PJ50E/PJ50V/PJ50VE
12345 6 7 8 9
A
B
C
D
E
F
A
B
C
D
E
F
08
LD-279 BOARD (1/7)
CONNECTORS
XX MARK: NO MOUNT
1
GND
2
VCC
3
OUT
1N.C
2T_TEMP_OUT
3YAW_BIAS-
4YAW_BIAS+
5PITCH_BIAS+
6PITCH_BIAS-
7T_TEMP_GND
8YAW_HALL-
9YAW_HALL+
10 PITCH_HALL+
11 PITCH_HALL-
12 REG_GND
13 PITCH-
14 PITCH-
15 YAW-
16 YAW-
17 YAW+
18 YAW+
19 PITCH+
20 PITCH+
21 REG_GND
22 Z_PI_K/E
23 Z_PI_C
24 Z_PI_A
25 REG_GND
26 ZOOM_A
27 ZOOM_B
28 ZOOM_XA
29 ZOOM_XB
30 FOCUS+
31 FOCUS-
32 ND_DRIVE+/IN
33 REG_GND
34 ND_HALL-
35 ND_BIAS-
36 ND_HALL+
37 ND_BIAS+
38 ND_DRIVE-/IN
39 F_MR_VCC
40 F_MR_A
41 F_MR_B
42 L_TEMP_OUT
43 L_TEMP_GND/F_MR_GND
44 IRIS_DRIVE+/OPEN
45 REG_GND
46 IRIS_HALL-
47 IRIS_BIAS-
48 IRIS_HALL+
49 IRIS_BIAS+
50 IRIS_DRIVE-/OPEN
51 N.C
1SHUTTER_XA
2SHUTTER_A
1FOCUS_A
2FOCUS_XA
3 FOCUS_XB
4 FOCUS_B
5 REG_GND5
6 LENS_TEMP_AD
7 FC_SENSE
8 FOCUS_PI_A
9 ZM_SENSE1A
10 ZOOM_PI_A
11 REG_GND11
12 ZOOM_XB_OUT
13 ZOOM_XA_OUT
14 ZOOM_B_OUT
15 ZOOM_A_OUT
16 REG_GND16
17 IRIS_DRIVE+
18 IRIS_DRIVE-
19 REG_GND19
20 IRIS_BIAS+
21 IRIS_HALL+
22 IRIS_BIAS-
23 IRIS_HALL-
24 REG_GND24
25 YAW-
26 YAW+
27 PITCH+
28 PITCH-
29 REG_GND29
30 PITCH_BIAS-
31 PITCH_HALL-
32 PITCH_BIAS+
33 PITCH_HALL+
34 YAW_BIAS+
35 YAW_HALL+
36 YAW_BIAS-
37 YAW_HALL-
38 REG_GND38
39 TZ_HALL_TEMP
1
2
3
4
5
6
1 TE1_CMD
3REG_GND
5 TE1_CLK
7REG_GND
9MIC_GND
11 INT_MIC_L
13 MIC_GND
15 INT_MIC_R
17 MIC_GND
19 INT_MIC_F
21 MIC_GND
23 MIC_VCC
25 REG_GND
27 TE1_VCC
29 TE1_VCC
31 REG_GND
33 ZM_DIR_A
35 ZM_DIR_B
37 ZM_ENB
39 REG_GND
41 IC_5501_IC_5201_CLK
43 REG_GND
45 IC_5501_SO
47 IC_5501_SI
49 IC_5501_SCK
51 XCS_IC_5501
53 REG_GND
55 IC_5201_VD
57 REG_GND
59 CAM_V
61 REG_GND
63 XIC_5201_RST
65 REG_GND
67 XSYS_RST
69 REG_GND
71 XIC_5501_CPU_RST
73 REG_GND
75 IC_5501_INT_REQ
77 REG_GND
79 YAW_AD
81 REG_GND
83 PITCH_AD
85 REG_GND
87 D_2.8V
89 A_2.8V
91 D_1.2V
93 REG_GND
95 MT_5.0V
97 MT_5.0V
99 MT_5.0V
2
4
6
8
10
12
14
16
18
20
22
24
26
28
30
32
34
36
38
40
42
44
46
48
50
52
54
56
58
60
62
64
66
68
70
72
74
76
78
80
82
84
86
88
90
92
94
96
98
100
1
2
3
4
5
6
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
CPC
(FOR CHECK)
SIRCS
(TALLY)
LENS
BLOCK
LENS
BLOCK
UNIT
BARRIER
LENS
CN40066P
R4003 1500
R4004 1500
R4005 1500
INT_MIC_L
AUDIO_GND
INT_MIC_F
INT_MIC_R
MIC_VCC
D4001
CL-271HR-C-TS
C4001
XX
R4001
330
IC4001
RS-450-T
CN4003 6P
CN4005 100P
R4012
XX
XX
XX
RB4001
RB4002
VD4003
XX
IC_5501_OUT6A
REG_GND
VD4004
XX
CN4004 2P
IC_5501_OUT6B
CN4002 39P
CN4001 51P
Q4001
DRA3143T0L
2.8V SWITCH
INT_MIC_R_IN
MIC_GND
INT_MIC_F_IN
MIC_GND
INT_MIC_L_IN
MIC_GND
REG_GND
DEBUG_UART0_TXD
DEBUG_UART0_RXD
BOOT_MODE_1
D_2.8V
N.C.
D_2.8V
BOOT_MODE_1
REG_GND
DEBUG_UART0_TXD
DEBUG_UART0_RXD
SIR_RXD
REG_GND
XTALLY_LED
D_2.8V
IC_5501_OUT4B
ZOOM_B_OUT
I_HALL-
REG_GND
F_MR_B
IC_5501_OUT4A
ND_HALL+
ND_DRIVE-
ND_HALL-
I_BIAS+
ND_DRIVE+
ZOOM_XA_OUT
MR_A_2.8V
ZOOM_XB_OUT
LENZ_TEMP_AD
F_MR_A
I_HALL+
I_BIAS-
IC_5201_OUT0B
IC_5201_OUT0A
ND_BIAS-
ND_BIAS+
PITCH_BIAS-
YAW-
YAW+
TZ_HALL_TEMP
PITCH_HALL+
YAW_BIAS-
PITCH-
PITCH_HALL-
PITCH+
ZM_SENSE1A
MR_A_2.8V
YAW_HALL+
YAW_HALL-
ZOOM_A_OUT
XZM_RST_LED
D_2.8V
PI_A
IC_5501_OUT4A
IC_5501_OUT5B
ZOOM_A_OUT
ZOOM_B_OUT
YAW_HALL+
PITCH_BIAS-
PITCH_HALL+
PITCH_HALL-
ZOOM_XB_OUT
YAW+
PITCH+
LENZ_TEMP_AD
ZOOM_XA_OUT
PITCH-
MR_A_2.8V
I_HALL-
I_BIAS+
I_BIAS-
YAW-
I_HALL+
IC_5501_OUT4B
IC_5501_OUT5A
ZM_SENSE1A
FC_SENSE
IC_5201_OUT0A
IC_5201_OUT0B
YAW_BIAS-
REG_GND
YAW_HALL-
TZ_HALL_TEMP
PI_A
TE1_DAT_6_CN
TE1_DAT_3_CN
TE1_DAT_2_CN
TE1_DAT_4_CN
TE1_CMD
TE1_DAT_5_CN
TE1_VCC
TE1_DAT_0_CN
TE1_DAT_1_CN
TE1_DAT_7_CN
TE1_DAT_2
TE1_DAT_7
TE1_DAT_3
TE1_DAT_1
TE1_DAT_6
TE1_DAT_0
TE1_DAT_5
TE1_DAT_4
TE1_VCC
TE1_CMD
MT_GND
MT_GND
MT_GND
SIR_RXD
DEBUG_UART0_TXD
XTALLY_LED
DEBUG_UART0_RXD
IC_55012_EXPOSE
CRESET_P
IC_5501_P_LIMIT
TE1_DAT_0_CN
REG_GND
TE1_DAT_1_CN
REG_GND
GSENSE_REF
GSENSE_X
GSENSE_Y
GSENSE_Z
REG_GND
TE1_DAT_4_CN
TE1_DAT_6_CN
TE1_DAT_7_CN
REG_GND
TE1_DAT_5_CN
TE1_DAT_3_CN
TE1_DAT_2_CN
XZM_RST_LED
ROLL_AD
BOOT_MODE_1
TZ_HALL_TEMP
ZM_SENSE1A
LENZ_TEMP_AD
VST_C_CHARGE
REG_GND
REG_GND
FC_SENSE
REG_GND
REG_GND
IC_5201_SO
IC_5201_SI
REG_GND
XCS_IC_5201
FC_DIR_B
IC_5201_SCK
FC_ENB
LENS_COVER_DIR_PWM
LENSV_EN
FC_DIR_A
A_3.3V
D_1.8V
TE1_DAT_7
TE1_DAT_6
REG_GND
TE1_DAT_5
TE1_DAT_4
TE1_DAT_3
REG_GND
TE1_DAT_2
TE1_DAT_1
TE1_DAT_0
REG_GND
ROLL_AD
REG_GND
FC_DIR_A
FC_ENB
FC_DIR_B
REG_GND
LENS_COVER_DIR_PWM
LENSV_EN
REG_GND
VST_C_CHARGE
A_3.3V
FC_SENSE
ZM_SENSE1A
LENZ_TEMP_AD
TZ_HALL_TEMP
IC_5501_2_EXPOSE
CRESET_P
IC_5501_P_LIMIT
BOOT_MODE_1
REG_GND
IC_5201_SCK
IC_5201_SO
IC_5201_SI
XCS_IC_5201
REG_GND
GSENSE_REF
GSENSE_X
GSENSE_Y
GSENSE_Z
REG_GND
XZM_RST_LED
XTALLY_LED
SIR_RXD
D_1.8V
DEBUG_UART0_RXD
DEBUG_UART0_TXD
MT_GND
MT_GND
MT_GND
MT_5.0V
AUDIO_GND
INT_MIC_F
INT_MIC_R
INT_MIC_L
MIC_VCC
REG_GND
AUDIO_GND
TE1_CLK
REG_GND
REG_GND
XCS_IC_5501
IC_5501_SI
IC_5501_SO
IC_5501_SCK
REG_GND
IC_5501_IC_5201_CLK
REG_GND
D_2.8V
A_2.8V
REG_GND
TE1_CMD
TE1_VCC
REG_GND
REG_GND
REG_GND
D_1.2V
REG_GND
IC_5201_VD
CAM_V
XIC_5201_RST
XSYS_RST
ZM_DIR_B
ZM_ENB
REG_GND
ZM_DIR_A
YAW_AD
REG_GND
XIC_5501_CPU_RST
REG_GND
REG_GND
REG_GND
PITCH_AD
REG_GND
IC_5501_INT_REQ
AUDIO_GND
AUDIO_GND

6-4
HDR-PJ50/PJ50E/PJ50V/PJ50VE/XR160/XR160E_L3
XIC_5201_RST
IC_5201_VD
XR160/XR160E
PJ50/PJ50E/
PJ50V/PJ50VE
PJ50/PJ50E/
PJ50V/PJ50VE
PJ50/PJ50E/ PJ50V/PJ50VE
PJ50/PJ50E/PJ50V/PJ50VE
PJ50/PJ50E/PJ50V/PJ50VE
PJ50/PJ50E/PJ50V/
PJ50VE
XR160/XR160E
PJ50/PJ50E/
PJ50V/PJ50VE
XR160/XR160E
39k:
0:
PJ50/PJ50E/PJ50V/PJ50VE XR160/XR160E
XR160/XR160E
XR160/XR160E
XR160/
XR160E
XR160/
XR160E
XR160/XR160E
PJ50/PJ50E/
PJ50V/PJ50VE
PJ50/PJ50E/PJ50V/
PJ50VE PJ50/PJ50E/PJ50V/PJ50VE
180k:
0:
PJ50/PJ50E/PJ50V/PJ50VE
XR160/XR160E
PJ50/PJ50E/PJ50V/PJ50VE
PJ50/PJ50E/PJ50V/
PJ50VE
12345 6 7 8 9
A
B
C
D
E
F
A
B
C
D
E
F
08
LD-279 BOARD (2/7)
IRIS DRIVE, ND DRIVE, FOCUS DRIVE
XX MARK: NO MOUNT
E6
OPOUT6
F8
OPIN6N
E8
OPIN6P
D6
OPOUT7
D7
OPIN7N
D8
OPIN7P
D5
VD
B8
CLK
C7
XCLR
A3
SOUT
B2
SIN
B3
CSB
A2
SCK
C8
VDDIO
A4
DVDD
C6
DVSS
E5
OPOUT2
F5
OPIN2N
C2
DAC2OUT
H5
OPIN2P
G6
OPOUT3
H6
OPIN3N
D2
DAC3OUT
H7
OPIN3P
F6
OPOUT5
F7
OPIN5N
D3
DAC6OUT
E7
OPIN5P
F2
OPIN9N
E4
OPOUT9
F3
ISEN7
H2
IR7
F1
AVSS
G1
AVDD
H1
CREFIN
G2
VREF
E1
OPIN8N
E3
OPOUT8
D1
ISEN5
E2
IR5
H8
OPOUT4
G8
OPIN4N
C1
DAC4OUT
G7
OPIN4P
F4
OPOUT1
G5
OPIN1N
C3
DAC1OUT
H4
OPIN1P
G4
OPOUT0
G3
OPIN0N
A1
DAC0OUT
H3
OPIN0P
A5
MVCC
B5
MGND
A8
PIO0
B7
PIO1
A7
PIO2
C4
PIO3
B4
OUT0A
C5
OUT0B
A6
OUT1A
B6
OUT1B
D4
TEST
1
CE
2
GND
VOUT
3
VDD
4
FOCUS DRIVE
ND DRIVE,
IRIS DRIVE,
2.5V REG
F_MR_B
I_HALL+
I_BIAS-
I_HALL-
F_MR_A
ND_HALL-
ND_BIAS-
ND_HALL+
ND_BIAS+
I_BIAS+
F_MR_A F_MR_B
C5201
0.1u C5202
22u
I_BIAS+ I_BIAS-
I_HALL+
I_HALL-
C5208
*
C5206
0.1u
C5205
0.0022u
50V
C5209
0.1u
C5211
0.1u
R5212
180k
R5206
2.7k
R5210
220k
R5211
330
R5215
8200
R5207
8.2k
R5208
*
R5217
10k
R5209 4700
C5207
0.001u
50V
R5259
0
ND_HALL+
ND_BIAS+
ND_BIAS-
ND_HALL-
C5215
0.1u
C5213
0.1u
R5222
10k
R5221
8.2k
C5216
0.1u
R5255
0
R5256 0
R5257
0
R5258
0
C5222
0.22u
C5221
1u
R5228
R5229
0
R5225 220k
R5232
XX
R5231 0
R5230 3.9k
C5220
0.0033u
MM3404A28URE
IC5202
C5219
1u
IC_5201_SCK
XCS_IC_5201
IC_5201_SO
REG_GND
A_3.3V
IC_5501_IC_5201_CLK
REG_GND
REG_GND
D_1.8V
MT_5.0V
D_2.8V
IC_5201_SI
C5223
22u
10V
L5201
C5224
XX
XX
R5218 XX
C5212
0.1u
C5210
0.1u
C5214
0.1u
R5216
XX
C5203 0.0022u
50V
C5204
0.1u
R5205
R5203 2.7k
R5204 8.2k
R5260
0
F_MR_A
F_MR_B
ND_HALL+
I_HALL-
REG_GND
I_HALL+
MR_A_2.8V
ND_HALL-
I_BIAS-
I_BIAS+
ND_BIAS+
ND_BIAS-
IC_5201_OUT0B
IC_5201_OUT0A
ND_DRIVE-
IC_5201_PIO1
IC_5201_PIO0
ND_DRIVE+
C5208
*mark
1u:
0.22u:
R5208
*mark
39k:
0:
IC5201
BU24130GU-E2

6-5
HDR-PJ50/PJ50E/PJ50V/PJ50VE/XR160/XR160E_L3
XSYS_RST
IC_5201_VD
XR160/XR160E
XR160/XR160E
PJ50/PJ50E/PJ50V/PJ50VE
PJ50/PJ50E/PJ50V/PJ50VE
XR160/XR160E
PJ50/PJ50E/PJ50V/PJ50VE
XR160/XR160E
PJ50/PJ50E/PJ50V/PJ50VE
XR160/XR160E
12345 6 7 8 9
A
B
C
D
E
F
A
B
C
D
E
F
08
LD-279 BOARD (3/7)
STEADSHOT PROCESSOR
XX MARK: NO MOUNT
F2 VCCD12
F7 VCCD3
F6 GNDD
B1 VCCA3
A1 GNDA3
G3 VM01
J4 VM23
J7 VM45
K8 VM6
G2 PGND0
H3 PGND1
H4 PGND2
J5 PGND3
J6 PGND4
K7 PGND5
J9 PGND6/RNF
G9 VLIM
G1 CLK
D1 RESET_N
F5 XDL
E1 SIO0_SCK
G5 SIO0_XSCS
F1 SIO0_SI
G4 SIO0_SO
E4 GPIO0
E3 GPIO1
E2 GPIO2
D2 GPIO3
C2 GPIO4
C1 GPIO5
F10 GPIO6/I2C_SCL
E10 GPIO7/I2C_SDA
D6 UDITRST_N
E5 DBGMOD/SEL
E8 UDITCK/SIO2_SCK
D8 UDITDI/SIO2_SI
D7 UDITDO/SIO2_SO
E7 UDITMS/SIO2_SRDY_N
K1 TEST
K10 IN2A
J10 IN2B
G6 IN3A
G7 IN3B
H9 IN4A
H10 IN4B
F9 IN5A
G10 IN5B
G8 IN6A
F8 IN6B K9
J8
H7
H8
K6
H6
H5
K5
K4
K3
H2
J3
F4
F3
J1
J2
K2
H1
D3
D5
C7
C8
B7
A7
A8
B8
A9
B9
B10
A10
C6
D4
C4
C3
C5
B5
B6
A6
A5
E6
D9
D10
E9
C9
C10
B4
B3
B2
A2
A3
A4
1
A_OUTPUT
2
A_OUTPUT
3
VSS
4
VSS
5
NC
678910
1112131415
16
NC
17
NC
18
VDD
19
VDD
20
NC
1
A_OUTPUT
2
A_OUTPUT
3
VSS
4
VSS
5
NC
678910
1112131415
16
NC
17
NC
18
VDD
19
VDD
20
NC
PITCH AMP YAW AMP
C5507 0.1u
C5508 0.1u
0.1u
C5510
0.1u
C5504 1u
C5501
22u
10V
R5504 XX
C5505 XX
C5506 XX
R5503 XX
R5501 XX
R5502 XX
L5501 XX
R5505 XX
CL5501
R5516 XX
C5509
R5527 33k
CL5511
C5524 0.033u
R5530
C5522 0.033u
R5529 33k
R5528 33k
C5528
0.047u
C5525 0.033u
C5523
0.033u
C5526
0.047u
CL5510
CL5530
CL5509
C5527
0.047u
C5529
0.047u
33k
ZOOM_XA_OUT
IC_5501_OUT6B
ZOOM_B_OUT
IC_5501_OUT5B
IC_5501_OUT5A
ZOOM_A_OUT
IC_5501_OUT6A
ZOOM_XB_OUT
PITCH-_OUT
PITCH+_OUT
YAW-_OUT
YAW+_OUT
REG_GND
R5515 15k
IC_5501_OUT4B
IC_5501_OUT4A
R5249 0 R5242 10k
R5239
10k
R5238
10k
R5250 0
R5235 0
C5226
0.0068u
IC5204
NJU7036SE3
YAW+_OUT
R5532 10k
YAW-_OUT
CL5503
CL5504
CL5505
CL5506
CL5507
CL5508
R5531 0
R5520 0
IC_5201_PIO0
R5519 0
R5522 0
R5523 0
R5525 0
PITCH-_OUT
PITCH+_OUT
R5248 0
R5246
10k
YAW+
R5245
10k
C5228
1u
YAW-
R5234 0
C5225
0.0068u
R5243
10k
R5252 0
R5244
10k
R5233 10k
R5251 0
R5247 0
C5227
1u
R5240
10k
R5241 10k
R5237
10k
MT_5.0V IC5203
NJU7036SE3
D_1.2V
D_2.8V
REG_GND
MT_5.0V
MT_GND
IC_5501_IC_5201_CLK
IC_5501_SCK
XCS_IC_5501
IC_5501_SO
IC_5501_SI
MR_A_2.8V
CRESET_P
CAM_V
XIC_5501_CPU_RST
IC_5501_2_EXPOSE
IC_5501_P_LIMIT
IC_5501_INT_REQ
MT_5.0V
OUT6B
OUT6A
OUT5B
OUT5A
OUT4B
OUT4A
OUT3B
OUT3A
OUT2B
OUT2A
OUT1B
OUT1A
OUT0B
OUT0A
SIO1_SO
SIO1_SI
SIO1_XSCS
SIO1_SCK
CC_R
CC_2
OP_9BINP
OP_9BINN
OP_9BOUT
OP_9AINP/DA_9
OP_9AINN
OP_9AOUT
DA_8
OP_8INP
OP_8INN
OP_8OUT
VREF(1.4V)
OP_7INP
OP_7INN
OP_7OUT
DA_7
OP_6INP
OP_6INN
OP_6OUT
DA_6
CC_1
DF_1P
DF_1N
CC_0
DF_0P
DF_0N
SE_5S
SE_4S
SE_5F
SE_4F
SE_3
SE_2
REG_GND
PITCH_HALL-
YAW_HALL-
PITCH_AD
PITCH_HALL+
YAW_BIAS-
PITCH_BIAS-
YAW_HALL+
YAW_AD
REG_GND
NC
VSS VSS
B_OUTPUT B_OUTPUT
A_-INPUT
A_+INPUT
NC
B_+INPUT
B_-INPUT
MT_GND
MT_5.0V
YAW-
LENS_COVER_DIR_PWM
ZM_ENB
ZM_DIR_B
ZM_ENB
ZM_DIR_A
LENSV_EN
IC_5201_PIO1
FC_DIR_B
FC_DIR_A
FC_ENB
FC_ENB
A_-INPUT
A_+INPUT
NC
B_+INPUT
B_-INPUT
NC
VSS VSS
B_OUTPUT B_OUTPUT
PITCH-
MT_GND
PITCH-
PITCH+
STEADYSHOT PROCESSOR
IC5501
R2J30503LG

6-6
HDR-PJ50/PJ50E/PJ50V/PJ50VE/XR160/XR160E_L3
12 3 4
A
B
C
D
E
F
A
B
C
D
E
F
08
LD-279 BOARD (4/7)
ROLL SENSOR
XX MARK: NO MOUNT
4
OUT
1
VREF
2
GND
3
VCC
1
AM1
2
VREF1
3
HO1
4
HI1
5
LO1
6
LIA1
7
LIB1
8
GND
9
LIB2
10
LIA2
11
LO2
12
HI2
13
HO2
14
VREF2
15
AM2
16
OUT2
17
CRST
18
V+
19
NC
20
OUT1
C7707
4.7u
C7702
0.1u
C7705
22u
R7705 10k
L7701 10uH
C7701
0.1u
C7704
0.047u
C7706
0.33u
R7706
15k
R7702 22k
R7703
22k
R7704 XX R7701 XX
R7707 470k
C7703
0.047u
ROLL
SENSOR
SE7701
32.2kHz
ROLL SENSOR
AMP
IC7701
NJM3230SE7
ROLL_AD
REG_GND
VST_C_CHARGE
A_2.8V
VC-621
CN1009
(1/12)
(PAGE 6-10)
CONTROL SWITCH BLOCK (SK37000) is replaced as block,
so that PRINTED WIRING BOARD is omitted.
12 3 4
A
B
C
A
B
C
08
S001
1
3
2
4
S003
1
3
2
4
S002
1
3
2
4
S004
1
3
2
4
LND0016P
1
REG_GND
2XPOWER_TACT_SW
3
PLAY_SW
4NC
5
NC
6
REG_GND
POWER
XX XX
(PLAYBACK)
CONTROL SWITCH BLOCK (SK37000)
(XR160/XR160E)
CONTROL KEY
VC-621
CN1009
(1/12)
(PAGE 6-10)
CONTROL SWITCH BLOCK (SK38010) is replaced as block,
so that PRINTED WIRING BOARD is omitted.
12 3 4
A
B
C
A
B
C
08
CONTROL SWITCH BLOCK (SK38010)
(PJ50/PJ50E/PJ50V/PJ50VE)
CONTROL KEY
S001
1
3
2
4
S003
1
3
2
4
S002
1
3
2
4
S004
1
3
2
4
LND0016P
1
REG_GND
2POWER_SW
3
PLAY_SW
4PROJECTOR_SW
5
NC
6
REG_GND
POWER (PLAYBACK)
XX PROJECTOR
