High Picture Quality
The PMW-400 Series incorporate three 2/3-inch-type Full-HD Exmor
CMOS sensors (1920 x 1080) to achieve high resolution, high sensitivity
(F12 at 60 Hz / F13 at 50 Hz), low noise (60 dB), and a wide dynamic
range to give more freedom of expression for creative shooting.
Three-dimensional Noise Reducer
In addition to existing noise reduction features, the PMW-400 Series also
includes a three-dimensional noise reducer. This not only detects vertical
and horizontal direction in a frame picture but also noise components in
a time axis, utilizing correlation characteristics between video frames.
Using this feature, the S/N ratio is improved to 60 dB which is the highest
level of noise reduction in a 2/3-inch-type Full-HD shoulder camcorder.
Selectable Format and Bit Rates
The PMW-400 Series provide a wide variety of codec operation points.
Users can record Full-HD video (1920 x 1080) at up to 50 Mbps using
MPEG HD422 as well as MPEG HD at 35 Mbps*2/ 25 Mbps, MPEG IMX at
50 Mbps, and DVCAM at 25 Mbps in an MXF file, as standard supported
formats. These camcorders also incorporate XAVC*3in the HD domain at
a 100-Mbps data rate, enabling the creation of rich content with 10-bit
quality.
*2 Requires firmware upgrade, planned in October, 2013.
*3 Requires firmware upgrade, planned in 2014. 4K not supported.
3.5-inch*4Color LCD Viewfinder
With a large, easy-to-read 3.5-inch QHD color LCD viewfinder as a
standard accessory, the PMW-400 Series offer outstanding resolution of
960 × 540 pixels, strongly supporting critical focus control during HD
shooting. The viewfinder cover can be flipped up to enhance visibility
when the camera is set on a tripod.
*4 Viewable area measured diagonally.
Various Conveniences via a Wireless Adapter
The PMW-400 Series are designed to support wireless operation using
an optional wireless adapter, the CBK-WA101*5. Using this adapter, the
user can stream out pictures to a mobile tablet, enabling crews to check
shooting images live in the field. After shooting, proxy files created on
the CBK-WA101 can be immediately transmitted to the broadcasting
station. The adapter also provides remote control of the PMW-400 with
mobile application software.
*5 Requires firmware upgrade, planned in October, 2013.
Enhanced Flash Band Reducer
Incorporating a newly developed algorithm, the PMW-400 Series detects
and processes flash banding inside its hardware before recording
begins*6. This provides greater flexibility in reducing flash banding across
different shooting environments. This feature can be disabled from the
menu if the users wants to use Content Browser for flash band reduction
after shooting. The user is free to choose when to reduce the flash band,
either before or after shooting according to varying circumstances.
*6 Requires firmware upgrade, planned in October, 2013.
Variety of Interfaces
The PMW-400 Series offers two lines of SDI output
connection enabling, for example, the director and
camera operator to concurrently check shot content via
two separate monitors. Also, for monitoring purposes
these camcorders can be connected via
HDMI to professional displays as well as
domestic-use TVs with an HDMI
connector. The i.LINK*7connector can
be used for HDV when SP 1440 (FAT) mode is
selected, and for DV when DVCAM (FAT) mode is
selected, for both input and output signal flows.
*7 i.LINK is a trademark of Sony used only to designate that a
product contains an IEEE1394 connector. Not all products with
an i.LINK connector will necessarily communicate with each
other. For information on compatibility, operating conditions,
and proper connection, please refer to the documentation
supplied with any device with an i.LINK connector.
The PMW-400K (with 16X HD lens) and the PMW-400L (without
lens) have now joined the XDCAM®HD422 family, equipped with
three 2/3-inch-type Full-HD Exmor®CMOS sensors that provide high
picture quality and an extremely high S/N ratio. These camcorders
support MPEG HD422, MPEG HD™, MPEG IMX™, DVCAM®, and
also XAVC™*1in the HD domain for future expansion of the
broadcasting workflow. Two SxS®card slots provide a wide range
of AV and IT interfaces including two HD/SD-SDI, HDMI,
i.LINK®, and composite outputs. The PMW-400 Series also supports
wireless operation using an optional adapter, the CBK-WA101. This
enables easy and quick clip data transmission to broadcast stations
using cloud services, saving the time and transportation cost of
shot clip delivery.
*1 Requires firmware upgrade, planned in 2014. 4K not supported.
Features
PMW-400
Solid-State Memory Camcorder
PMW-400K

Optional Accessories
Specifications
CBK-WA100/101
Wireless Adapter
SxS Memory Card Series CA-FB70/TX70
System Camera Configuration Units
MEAD-MS01/SD02 QDA-EX1
Media Adapters for MS/SD Card and XQD
CBK-CE01
50-pin Interface Unit and
Digital Extender Option
PMW-400K PMW-400L
General
Weight Approx.3.4 kg (body only without lens, VF, Mic)
Dimensions 5 x 10 5/8 x 13 1/8 inches (124 x 269 x 332 mm) (excluding protrusions, body only)
Power Requirements DC 12 V
Power Consumption Approx. 26 W (with viewfinder, lens and microphone while recording)
Operating Temperature 32° F to 104° F (0° C to 40° C)
Storage Temperature -4° F to +140° F (-20° C to +60° C)
Continuous Operating Time Approx. 180 min with BP-L80S
Recording Format (Video) XAVC (future upgrade)
MPEG-2 Long GOP:
- HD 422 mode: CBR, 50 Mbps max., MPEG-2 422P@HL
- HQ mode:VBR, 35 Mbps max., MPEG-2 MP@HL
- SP mode: CBR, 25 Mbps, MPEG-2 MP@H-14
- SD mode : MPEG IMX, DVCAM
Recording Format (Audio) <UDF>
- HD 422 50 mode: LPCM 24 bits, 48 kHz, 4 channels
- HD 420 HQ mode: LPCM 16 bits, 48 kHz, 4 channels
- SD MPEG IMX mode: LPCM 16/ 24 bits, 48 kHz, 4 channels
- SD DVCAM mode:LPCM 16 bits, 48 kHz, 4 channels
<FAT>
- HD mode: LPCM 16 bits, 48 kHz, 4 channels
- SD DVCAM mode:LPCM 16 bits, 48 kHz, 2 channels
Recording/Playback Time
(MPEG HD)
<UDF Mode>
HD 422 50/ SD MPEG IMX Mode: *1
- Approx. 120 min with SBS-64G1A (64 GB) memory card
- Approx. 60 min with SBP-32/SBS-32G1A (32 GB) memory card
- Approx. 30 min with SBP-16 (16 GB) memory card
HD 420 HQ Mode:
- Approx. 180 min with SBS-64G1A (64 GB) memory card
- Approx. 90 min with SBP-32/SBS-32G1A (32 GB) memory card
- Approx. 45 min with SBP-16 (16 GB) memory card
SD DVCAM Mode:(option)
- Approx. 220 min with SBS-64G1A (64 GB) memory card
- Approx. 110 min with SBP-32/SBS-32G1A (32 GB) memory card
- Approx. 55 min with SBP-16 (16 GB) memory card
<FAT Mode> *1
- HD HQ Mode:
- Approx. 200 min with SBS-64G1A (64 GB) memory card
- Approx. 100 min with SBP-32/SBS-32G1A (32 GB) memory card
- Approx. 50 min with SBP-16 (16 GB) memory card
HD SP Mode:
- Approx. 280 min with SBS-64G1A (64 GB) memory card
- Approx. 140 min with SBP-32/SBS-32G1A (32 GB) memory card
- Approx. 70 min with SBP-16 (16 GB) memory card
SD DVCAM Mode:(option)
- Approx. 260 min with SBS-64G1A (64 GB) memory card
- Approx. 130 min with SBP-32/SBS-32G1A (32 GB) memory card
- Approx. 65 min with SBP-16 (16 GB) memory card
Recording Frame Rate <UDF>
HD 422 50 Mode: MPEG-2 422P@HL, 50 MBps/ CBR
- 1920 x 1080/59.94i, 50i, 29.97p, 25p, 23.98p
- 1280 x 720/59.94p, 50p, 29.97p, 25p, 23.98p
HD 420 HQ Mode: MPEG-2 MP@HL, 35 MBps/ VBR
- 1920 x 1080/59.94i, 50i, 29.97p, 25p, 23.98p, (Version Up)
- 1440 x 1080/59.94i, 50i, 29.97p, 25p, 23.98p,
- 1280 x 720/59.94p, 50p, 23.98p (2-3 pull down)
SD MPEG IMX Mode
- 720 x 486/ 59.94i, 29.97PsF
- 720 x 576/50i, 25PsF
SD DVCAM Mode
- 720 x 486/59.94i, 29.97PsF
- 720 x 576/50i, 25PsF
<FAT>
HD HQ 1920 Mode: MPEG-2 MP@HL, 35 Mbps/ VBR
- 1920 x 1080/59.94i, 50i, 29.97p, 25p, 23.98p
HD HQ 1440 Mode: MPEG-2 MP@HL, 35 Mbps/ VBR
- 1440 x 1080/59.94i, 50i, 29.97p, 25p, 23.98p
HD HQ 1280 Mode: MPEG-2 MP@HL, 35 Mbps/ VBR
- 1280 x 720/59.94p, 50p, 29.97p, 25p, 23.98p
HD SP 1440 Mode: MPEG-2 MP@H-14, 25 Mbps/ CBR
- 1440 x 1080/59.94i, 50i, 23.98p (2-3 pull down)
SD DVCAM Mode
- 720 x 486/59.94i, 29.97PsF
- 720 x 576/50i, 25PsF
PMW-400K PMW-400L
Lens
Lens Mount Sony 2/3-inch type bayonet mount
Zoom Ratio 16x (optical),
servo/manual (AF lens for PMW-400K)
Focal Length f = 8 mm to 128 mm (equivalent to 31.5 mm
to 503 mm on 35 mm lens)
Iris F1.9 to F16 and Close,Auto/Manual
selectable
Focus AF/MF/Full MF selectable
800 mm to ∞ (MACRO OFF)
50 mm to ∞ (MACRO ON,Wide)
732 mm to ∞ (MACRO ON,Tele)
Filter Diameter M82 mm, pitch 0.75 mm (on lens)
Input/Output
Genlock Input BNC (x1)
Timecode Input BNC (x1)
Audio Input XLR-type 3-pin (female) (x2), Line/Mic/Mic +48 V selectable
Mic Input XLR-type 5-pin
SDI Output BNC (x2), HD-SDI/SD-SDI selectable
Video Output BNC (x1) HD-Y or Analog composite
Audio Output XLR-type 5-pin
Timecode Output BNC (x1)
Earphone Output Stereo mini jack (x1)
Speaker Output Monaural
DC Input XLR-type 4-pin
DC Output 4-pin
Lens 12-pin
Remote 8-pin
Light 2-pin
i.LINK Interface IEEE 1394, 6-pin (x1), HDV (HDV 1080i )/DVCAM stream input/output *2, S400
USB USB device B Type (x1), host A Type (x1)
HDMI A type (x1)
Camera Section
Imager 3-chip 2/3-type "Exmor" Full HD CMOS
Effective Picture Elements 1920 (H) x 1080 (V)
Optical System F1.4 prism system
Built-in Optical Filters 1: Clear, 2: 1/4ND, 3: 1/16ND, 4: 1/64ND
Shutter Speed (Time) 1/60 sec to 1/2,000 sec + ECS (Extended Clear Scan)
Shutter Speed (Slow Shutter
(SLS))
2, 3, 4, 5, 6, 7, 8, 16, 32, 64-frame accumulation
Slow & Quick Motion
Function
720p: Frame rate selectable from 1 fps to 60 fps
1080p: Frame rate selectable from 1 fps to 30 fps
Sensitivity (2000 lx, 89.9%
reflectance)
F12 (typical) (1920 x 1080/59.94i mode)
F13 (typical) (1920 x 1080/50i mode)
Minimum Illumination 0.006 lx (typical) (1920 x 1080/59.94i mode,
F1.9, +42 dB gain, with 64-frame accumulation)
0.003 lx (typical) (1920 x 1080/59.94i mode,
F1.4, +42 dB gain, with 64-frame accumulation)
White Balance Preset (3200K), Memory A,Memory B/ATW
Gain Selection -3, 0, 3, 6, 9, 12, 18, 24, 30, 36, 42 dB
S/N Ratio 60 dB (Y) (typical)
Horizontal Resolution 1,000 TV lines or more (1920 x 1080i mode)
Viewfinder
Viewfinder 3.5-inch *3type color LCD monitor: 960 (H) x 540 (V), Quarter HD Size
Other Equipment
Built-in LCD Monitor Black & White LCD (Audio level,TC, battery and media remaining capacity)
Built-in Speaker 1
Supplied Accessories
Viewfinder (1)
Shoulder strap (1)
Stereo microphone (1)
Wind-screen (1)
Cold shoe kit (1)
Lens mount cap (1)
Flange back adjustment chart (1)
Auto focus lens (1)
Before Using this Unit (1)
CD-ROM:
Operating Instructions
Viewfinder (1)
Shoulder strap (1)
Stereo microphone (1)
Wind-screen (1)
Cold shoe kit (1)
Lens mount cap (1)
Flange back adjustment chart (1)
Before Using this Unit (1)
CD-ROM:
Operating instructions
* The specifications are measured with supplied lens of PMW-400K.
*1: Recording/ Playback time may vary the according to the encoding or memory.
*2: HDV/ DV stream input/ output are available only in FAT mode. Depending on the connected products, it may not be
recorded correctly.
*3: Viewable area measured diagonally.
Sony Electronics Inc.
1 Sony Drive
Park Ridge, NJ 07656
sony.com/xdcam
V-2577 (MK11055V1) Printed in USA (9/13)
©2013 Sony Electronics Inc. All rights reserved.
Reproduction in whole or in part without written permission is prohibited.
Features, design, and specifications are subject to change without notice.
Weights and measurements are approximate.
Sony, XDCAM, Exmor, MPEG HD422, MPEG HD, MPEG IMX, DVCAM, XAVC,
SxS, i.LINK and the Sony make.believe logo are trademarks of Sony.
All other trademarks are the property of their respective owners.
