SONY 3_06__648_./3,
Video Camera
Recorder Hi
Operating Instructions
Before operating the unit, please read this n-lanual thoroughly,
and retain it fur t\mlre reference.
Owner's Record
The mode] and serial numbers are located on the bottom. Record the
serial ntln-lber in the space provided helow. Refer to these numbers
whenever you call t/pon your Sony dealer regarding this product.
Model No. CCD-TRV Model No. AC-L
Serial No. Serial No.
HandgcamVimi®_o
C'_,.,o,,..,..O
s_mEs
CCD-TRV98
videoHi8
CCD- TRV49/TRV58/TRV68/TRV78/
TRV88/TRV98 Hi Bl
@2001 Sony Corporation

Welcome!
Congratulations on your pm chase of this Sony Handyranl Vision TM canlrorder. Witb your
Handycam Vision, you can capture life's precious moments with superior picture and sound
quality. Your Handycam Vision is loaded with advanced %atures, but at the same time it is
very easy to use. You will soon be producing home video that you can enjoy fbr years to
coIlle.
To prevent fire or shock hazard, do
not expose the unit to rain or
moisture.
CAUTION: TO REDUCE THE RISK OF ELECTRIC SI OCK,
DO NOT RKMOVE COVER {OR BACK},
NO USER-SERVIOEABI K PARTS INSIDE.
R F R S RVICING TO QUALIFI D SERVICE PERSONNEL.
DISPOSAL OF LITHIUM ION BATTERY.
LITHIUM ION BATTERY.
DISPOSE OF PROPERLY.
You can return your unwanted lithiurn ion batteries
to your nearest Sony Service Center or Factory
Service Center.
Note: In some areas tile disposal of lithium ion
batteries in household or business trash may
be prohibited.
For the Sony Service Center nearest you call
1 800 222 SONY (United States only)
For the Sony Factory Service Center nearest you call
416 499 SONY (Canada only)
Caution: Do not handle damaged or leaking lithium
ion battery.
This symbol is intended to alert
tile user to the presence of
uninsulated 'dangerous voltage"
within tile product's enclosure
that may be of sufficient
nlagnitude to constitute a risk of
electric shock to persons.
This symbol is intended to alert
tile user to tile presence of
important operating and
maintenance (servicing)
instructions ill tile literature
accompanying tile appliance.
Never expose the battery pack to tenlperatmes
above 60°C (140°F) such as in a car parked in
the sun or under dilect sunlight.
CAUTION
You are cautioned that any changes or modifications
not expressly approved in this manual could void
your authority to operate this equipment,
2

Note:
This equipment has been tested and found to comply
with the limit5 for a Class B digital device, pursuant
to Part 15 of the FCC Rules, These limits are designed
to provide reasonable protection against harmflfl
interference in a residential installation. This
equii)ment generates, uses, and carl radiate radio
flequency energy and, if not installed and used in
accordance with tile instructions, may cause han-nfkfl
interference to radio conlnlunications. However,
there is no guarantee that interference will not occur
in a particular installation. If this equipment does
cause harmfkfl interference to radio or television
reception, which carl be determined by turning tile
equipment of{and on, the user is encouraged to try to
correct the interf>rence by one or more of tile
following measures:
Reorient or relocate the receiving antenna.
Increase the separation between tile equipment
and receiver.
Connect the equipment into an outlet on a circuit
dif{brent flora that to which the receiver is
connected.
Consult the dealer or an experienced radio/TV
technician for help.
CAUTION
TO PREVENT ELECTRIC SHOCK_MATCH
WIDE BLADE OF PLUG TO WIDE SLOT,
FULLY INSERT.

Main Features
Functions to adjust exposure (in the recording mode)
•In a dark place
•In dark environments such as sunset, fireworks,
or general night views
• Shooting backlit subjects
• In si)otlight, such as at the theater o1"a formal
event
• In strong light or reflected light, such as
at a beach in midsummer or oil a ski slope
NIGHTSHOT (p. 26)
Sunset & moon mode (p. 39)
BACK LIGHT (p. 25)
Spotlight mode (p. 39)
Beach & ski mode (p. 39)
Functions to give images more impact (in the recording mode)
•Smooth transition between scenes FADER (p. 36)
• Digital processing of images PICTURE EFFECT (p. 38)
•Creating a soft background for subjects Soft portrait mode (p. 39)
• Superimposing a title TITLE (p. 43)
Functions to give a natural appearance to your recordings
(in the recording mode)
•Preventing deterioration of picture quality D ZOOM IMENI II (p. 52)
in digital zoom
The default setting is set to OFF.
(To zoom greater than 20×, select the digital zoom
power in D ZOOM in the menu settings. )
• Focusing manually
• Shooting distant subjects
• Recording f_lst moving subjects
Manual focus (p. 42)
Landscape mode (p. 39)
Sports lesson mode (p. 39)
Functions to use in editing (in the recording mode)
• Watching tile picture on a wide screen TV Wide mode (p. 34)
• Playing back the picture on a TV without SUPER LASER LINK (p. 33)
connecting a cord (CCD TRV98 only)
• Recording with the date/time Date and time (p. 27)
• Enhancing old tapes ORC IMENU] (p. 54)
Functions to use after recording (in the playback mode)
• Correcting jitter TBC [MENUI (p. 53)
• Correcting color noise DNR IMENIII (p. 53)
4

Table of contents
Main Features ..........................................4Editing
Quick Start Guide ...............................6 Dubbing a tape ......................................50
Getting started
Using this manual ................................... 8
Checking supplied accessories ............ 10
Step 1 Preparing the power supply ... 11
Installing the battery pack ............ 11
Charging the batter T pack ............ 12
Connecting to a wall outlet ........... 16
Step 2 Setting the date and time ........ 17
Step 3 Inserting a cassette ................... 19
Recording - Basics
Recording a picture .............................. 20
Shooting backlit subjects
BACK LIGHT ........................ 25
Shooting in the dark
NightShot ............................... 26
Superimposing the date and time on
pictures ...................................... 27
Checking the recording
END SEARCH ............................. 28
Playback -Basics
Playing back a tape ............................... 29
Viewing the recording on TV .............. 32
Customizing Your Camcorder
Changing the menu settings ................51
Troubleshooting
Types of trouble and their solutions
........................................................... 57
Self2diagnosis display .......................... 61
Warning indicators and messages ...... 62
Additional Information
Usable cassettesand playback modes
........................................................... G4
About "InfoLITHIUM" battery ........... 65
Using your camcorder abroad ............ 66
Maintenance information and
precautions ...................................... 67
Specifications ......................................... 72
Quick Reference
Identif3ring the parts and controls ...... 73
Index ........................................ Back cover
Advanced Recording
Operations
Using the wide mode ........................... 34
Using the fhder function ...................... 3{3
Using special effects
Picture effect ................................. 38
Using the PROGRAM AE function .... 39
Adjusting the exposure manually ...... 41
Focusing manually ................................ 42
Superimposing a title ........................... 43
Making your own titles ........................ 45
Using the built-in light ......................... 47

iiiiiiii :!i:!i:!i:!i
iiiiiiiii_il;i
iiiiiiiii_!i_i_iiiii
iiiiiiiii iiiiiii
'i'i'i'i'i'i'i'i'i'i'i'i'i'i'i'i'i'i'i'i
Quick Start Guide
This chapter introduces you to the basic features of your
camcorder. See the page in parentheses "( )" for more
information.
Use the battery pack when using your camcorder outdoors (p. 11).
Open tile DC IN
jack cover.
AC power adaptor (supplied)
Connect the phlg with
its • mink facing up.
_1_ Open the lid of the
cassette
compartment, and
press EJECT.
The compartment
opens automatically.
0 Insert a cassette
into the cassette
compartment
with its window
fi_cing out and
the write-protect
tab on the
cassette up.
_Close the cassette
coinpartment by
pressing the (NN_ mark
on the cassette
con_partmei_t. The
cassette compartment
automatically goes
down.
Close the lid of the
cassette coml_artn-_ent.

_ Remove tile lens cap. ][0 Set tile POWER
| svvitcb to CAMERA
while pressing tile
small green button.
O Open the LCD panel
while pressing OPEN.
The picture appears
on tile LCD screen.
) Press tbe red button.
Your Calllcordel"
starts recording. To
stop recording, press
tile red button again.
Viewfinder
When the LCD panel is closed, use tile viewfinder placing
your eye against its eyecup.
The picture in the vievvfinder is black and white.
When you purchase your camcorder, the clock setting is set to off If you want to record tbe
date and time for a picture, set the clock setting before recording (i7. 17).
O Press _ to rewind the tape.
REW@
0 Press _ to start playback.
PLAY
_1_ Set tbe POWER
switch to PLAYER
wbile pressing the
small green button.
NOTE
Do not pick up your camcorder by holding
the viewfinder, tbe LCD panel or the
batte_T pack.
iiiiiiiiiiiiiiiiiiiiiiiiiiiiii
iiiiiiiiiiiiiiiiiiiiiiiiiiiiiL

nGetting started --
Using this manual
Tile instructions in this manual are fbr the six models listed in the table below. Before
you stalt reading this manual and operating yore camcorder, check the model number
by looking at the bottom of your camcorder. Tile CCD TRV98 is tile model used fur
illustration purposes. Otherwise, the model name is indicated in the illustrations. Any
differences in operation are clearly indicated in the text, tor example, "CCD TRV98
only."
As you read through this manual, buttons and settings on yotn camcorder are shown in
capital letters.
e.g. Set the POWER switch to CAMERA.
When you can T out an operation, you can hear a beep sound to indicate that the
operation is being carried out.
Types of differences
CCD
Ren-lote sensor
Digital zoom
SUPER LASER LINK
SteadyShot
• Provided
Not provided
TRV49 TRV58 TRV68 TRV78 TRV88 TRV98
• • •
450× 460x 460× 560x 560× 560×
TV color systems differ from cotmtry to cotmtry. To view your recordings on a TV, you
need an NTSC system based TV.
8

Using this manual
Lens and LCD screen /finder (on mounted models only)
•The LCD screen and the finder are manufactured using extremely high-precision
technology so over 99.99% of the pixels are operational for effective use.
However, there may be some tiny black points and/or bright points (white, red,
blue or green in color) that constantly appear on the LCD screen and the finder,
These points are normal in the manufacturing process and do not affect the
recording in any way.
• Do not let yore camcorder get wet. Keep your camcorder away fl'om rain and sea
water. Letting your camcorder get wet may cause your camcorder to malflmction.
Sometimes this malflmction cannot be repaired [a].
• Never leave your camcorder exposed to temperatures above 60°C (140°F), such as ill a
car parked in the sun or under direct sunlight [hi.
• Be careflfl when placing the camera near a window or outdoors. Exposing the LCD
screen, tile finder or the lens to direct sunlight fbr long periods may cause
malflmctions [c].
• Do not directly shoot tile sun. Doing so n-light cause your camcoMer to mall\ruction.
Take pictures of the sun in low ligbt conditions such as duck [4.
¢Q
[a] [b]
[d]

Checking supplied accessories
Make sure that tile fbllowing arressories are supplied with your ranlrorder.
[]
[]
[]
[]
[] [] []
[] Wireless Remote Commander (1)
(p. 78)
CCD-TRV49/TRV78/TRV98 only
[] AC-L10A/L10B/L10C AC power adaptor
(1), Power cord (1) (p. 12)
[] NP-F330 battery pack (1) (p. 11, 12)
[] Size AA (R6) battery for Remote
Commander (2) (p. 78)
CCD-TRV49/TRV78/TRV98 only
[] A/V connecting cable (1) (p. 32)
[] Shoulder strap (1) (p. 75)
[] Lens cap (1) (p. 20, 74)
Contents of tile recording cannot be compensated if recording or playback is not
made due to a malfimction of the camcorder, storage media, etc.
10

Step 1 Preparing the power supply
Install tile battery pack to use your camcorder outdoors.
Slide the battery pack clown until it clicks.
i!__ii;!_J!iiiiiiiii!!!
ili_i_I_ ;i!!!!:
To remove the battery pack
Slide the battery pack out in the direction of the mrow while pressing I BATT
RELEASE down.
BATT RELEASE
11

Step 1 Preparing the power supply
Use tile battery pack after charging it fbr your camcorder.
Your camcorder operates only with the "Inf,)LITHIUM" battery pack (L series).
See page 65 for more information about "InIoLITHIUM" batte W pack.
(1) Open the DC IN jack cover and connect the AC power adaptor supplied with
your camcorder to the DC IN jack with the plug's • mark f>ming up.
(2) Connect the power cot'd to the AC power adaptor.
(3) Connect the power cord to a wall outlet.
(4) Set the POWER switch to OFF (CHARGE). Charging begins, and the CHG
lamp lights up.
When the CHG lamp goes out, the chalging is completed.
4
CHG lamp
After charging the battery pack
Disconnect the AC power adaptor from the DC IN jack on your eaIneorcter.
12

Step 1 Preparing the power supply
Notes
•Prevent metallic objects fl'om coming into contact with the metal parts of" the DC plug
of the AC power adaptor. This may cause a short circuit, damaging tile AC power
adaptor.
• Keep tile battel T pack dry.
•When tile batteWpack is not to be used for a long tin-le, charge tile batte Wpack fiflly,
and then use it until it f\flly discharges again. Do this once a year. Keep the battery
pack in a cool place.
g
While charging the battery pack, the CHG lamp does not light up in the following
cases
The battery pack is not installed correctly.
Something is wrong with tile battery pack.
If the power may go off although the battery remaining indicator indicates that
the battery pack has enough power to operate
Charge tile battery pack fiflly again so that the indication on tile hattery remaining
indicator is correct.
Charging time
Battery pack Full charge
NP F330 (supplied) 150
NP F530/F550 210
NP F730/F730H/F750 300
NP F930/F950 390
NP F960 420
Approximate number of minutes to chalge an empty battery pack
13

Step 1 Preparing the power supply
Recording time
CCD-TRV49/TRV58/TRV68/TRV78
Recording with Recording with
Battery pack the viewfinder the LCD screen
Continuous* Typical** Continuous* Typical**
NP F330 (supplied) 140 75 120 05
NP F530 245 135 205 110
NP F550 280 155 240 130
NP F730 500 275 410 225
NP F730H/F750 580 320 490 270
NP F930 780 430 650 355
NP F950 900 495 750 410
NP F960 1035 570 880 485
CCD-TRV88
Recording with Recording with
Battery pack the viewfinder the LCD screen
Continuous* Typical** Continuous* Typical**
NP F330 (supplied) 140 75 95 50
NP F530 245 135 160 90
NP F550 280 155 195 105
NP F730 500 275 325 180
NP F730H/F750 580 320 395 215
NP F930 780 430 515 285
NP F950 900 495 610 335
NP F960 1035 570 720 395
CCD-TRV98
Recording with Recording with
Battery pack the viewfinder the LCD screen
Continuous* Typical** Continuous* Typical**
NP F330 (supplied) 140 75 95 50
NP F530 245 135 155 85
NP F550 280 155 190 105
NP F730 500 275 315 175
NP F730H/F750 580 320 385 210
NP F930 780 430 495 270
NP F950 900 495 590 325
NP F960 1035 570 700 385
Approximate number of minutes wben you use a fully charged battery pack
* Approximate continuous recording time at 25°C (77°F). Tbe battery 1i% will be
shorter if you use your camcorder in a cold environment.
** Approximate number of minutes when recording while you repeat recording start/
stop, zooming and turning the power on/off. The actual battery lifo may be shorter.
14

Step 1 Preparing the power supply
Playing time
CCD-TRV49/TRV58/TRV68/TRV78
Battery pack Playing time Playing time
on LCD screen with LCD closed
NP F330 (snpplied) 120 145
NP F530 205 260
NP F550 240 295
NP F730 410 525
NP F730H/F750 490 610
NP F930 600 825
NP F950 700 930
NP F960 880 1090
CCD-TRV88
Playing time Playing time
Battery pack on LCD screen with LCD closed
NP F330 (supplied) 95 145
NP F530 160 260
NP F550 195 295
NP F730 325 525
NP F730H/F750 395 610
NP F930 510 825
NP F950 610 930
NP F960 720 1090
CCD-TRV98
Playing time Playing time
Battery pack on LCD screen with LCD closed
NP F330 (supplied) 90 145
NP F530 155 260
NP F550 190 295
NP F730 315 525
NP F730H/F750 385 610
NP F930 495 825
NP F950 590 930
NP F960 700 1090
Approximate number of i_linutes when you nse a fiflly charged battery pack
The battery life will be shorter if yon nse your camcorder in a cold environment.
g
What is "InfoLITHIUM"?
The "InfoLITHIUM" is a lithimrl ion battery pack which can exchange data such as
battery consumption with compatible electronic equipment. This trait is compatible
with the "InfoLITHIUM" battery pack (L series). Your camcorder operates only with
the "InfoLITHKJM" battery. "In%LITHIUM" L series battery packs have the
Ci) I.roUmlUMO mark.
"InfoLITHIUM" is a trademark of Sony Corporation.
15

Step 1 Preparing the power supply
When you use your camcorder for a long time, we recommend that you power it fi'om a
wall outlet using tile AC power adaptor.
(1) Open the DC IN jack cover, and connect the AC power adaptor to the DC IN
jack on your camcorder with tile plug's • mark facing up.
(2) Connect tile power cord to the AC power adaptor.
(3) Connect the power cord to a wall outlet.
2, 3
PRECAUTION
Tile set is not disconnected Dora the AC power source (wall outlet) as long as it is
connected to the wall outlet, even if the set itself has been turned off.
Notes
•The AC power adaptor ran supply power even if the hattery park is attarhed to your
canlcorder.
• The DC IN jack has "source priority". This means that the battery pack cannot supply
any power if the power cord is connected to the DC IN jack, even when the power
cord is not plugged into a wall outlet.
• Place the AC power adaptor near a wall outlet.
While using the AC power adaptor, if any trouble occurs with this unit, disconnect the
plug fi'om the wall outlet as soon as possible to cut offthe power.
Using a car battery
Use Sony DC Adaptor/Charger (optional).
16

Step 2 Setting the date and time
Set the date and time settings when you use your camcorder for the first time.
If you do not use your camcorder for ahout 4 months, the date and time settings may he
released (bars may appear) because the built in rechargeable lithium cell in your
camcorder will have been discharged.
First, set the year, then the month, the day. the hour and then the minute.
(1) While your camcorder is in CAMERA mode, press MENU to display the
i]lenu.
(2)TurntheSEL/PUSH EXEC dialtoselect_, thenpressthedial.
(3)TurntheSEL/PUSH EXEC dialtoselectCLOCK SET,thenpressthedial.
(4)Turn theSEL/PUSH EXEC dialtoadjustthedesiredyear,thenpressthedial.
(5) Set the month, clay and hour by turning tile SEL/PUSH EXEC dial and
pressing the diah
(6) Set the minute by turning the SEL/PUSH EXEC dial and pressing the dial by
the time signal. The clock starts to move.
(7) Press MENU to make tile menu disappear. The time indicator appears.
g
1,7 3
MENU
4
,}AN / 200_[Z_ t
/2 O0 Ale/2 O0 AM
6
t_ AUTO DArE
LTR SlZE
c_ LANCUA6E
_DE_O MODE
_ETURt_
17

Step 2 Setting the date and time
To check the preset date and time
Press DATE to display the date indicator.
Press TIME to display the time indicator.
Press DATE (or TIME) and then press TIME (o1"DATE) to simultaneously display the
date and time indicator.
Press DATE and/or TIME again. The date and/or time indicator disappears.
The year changes as follows:
1995 _- .... --_ 2001 _- .... --_ 2079
T T
Auto date function
When you use your camcorder fur the first time, turn it on and reset the date and time
to your local time before you start recording (p. 17). The date is automatically recorded
fbr 10 seconds after you start recording (Auto date function). This flmction works only
once a day.
Note on the time indicator
The internal clock of your camcorder operates on a 12 hour cycle.
• 12:00 AM stands for midnight.
• 12:00 PM stands for noon.
Note on the auto date function
You can change the AUTO DATE setting hy selecting ON or OFF in the menu settings.
The auto date ftmction automatically displays the date once a day.
However, the date may automatically appear more than once a clay ifi
you reset the date and time.
you eject and insert the tape again.
you stop recording within 10 seconds.
you set AUTO DATE to OFF once and set it hack to ON in the menu settings.
18

Step 3 Inserting a cassette
When you vvant to record in tile Hi8 system, nse Hi8 video cassettes I'||_] •
(1) Prepare the power supply (p. 11).
(2) Open the lid of the cassette compartment, and press EJECT. The cassette
comparmlerlt opens automatically.
(3) Insert a cassette with its winctow facing out and the write protect tab on the
cassette up. _-z.
(4) Close the cassette compartment by pressing the _ mark on the cassette
compartment. The cassette compartment automatically goes down.
(S) Close the lid of the cassette compartmerlt.
3
To eject a cassette
4,5
Follow tile procedure ahove, and eject the cassette ill step 3.
Note
•Do not press tile cassette eomparmlent down. Doing so may cause a mall\ruction.
• The cassette compartment may not be closed when you press any part of the cassette
compartment other than tile _ mark.
• Do not pick up your camcorder by holding the lid of tile cassette compartment.
To prevent accidental erasure
Slide the write protect tah on the cassette to expose tile red nlark.
19

-- Recording -Basics--
Recording a picture
Your camcorder automatically focuses for you.
(1) Remove the lens cap by pressing both knobs on its sides and attach the lens
cap to the grip strap.
(2) Install the power source and insert a cassette. See "Step 1" to "Step 3" for more
ilfformation (p. 11 to 19).
(3) Set the POWER switch to CAMERA while pressing the small green button.
Your camcorder is set to the standby mode.
(4) Open the LCD panel while pressing OPEN. The viewfinder automatically
mrns off.
(5) Press START/STOP. Your camcorder starts recording. The REC indicator
appears. The camera recording lamp located on the front of your camcorder
lights up. To stop recording, press START/STOP again.
The recording lamp lights up in the viewfinder when you record with the
viewfinder.
1POWER
Camera
recording
lamp
Microphone
2
5i_ POWER
_i _140mn Ili_l SPREC 0:00:0 E
2O
