Sony CDX-GT650UI - Fm/am Compact Disc Player User manual

CDX -GT650UI
CDX-GT650UI CD Recevier
The easy - to - read two line LCD display shows clock, station ID and track
data when playing back your digital MP3/WMA/AAC files . Front auxiliary
input lets you connect almost any portable audio device to your car's
sound system.
1
Dynamic Color Illuminator lets you match your radio’s illumination to
complement your existing vehicle lighting components. With selectable
Sound Synchronization, the timing of the color change is synchronized
with the audio source.
Multi - format playback lets you play your MP3, WMA, or AAC songs . Hear
digital music files in their original vibrancy with DM+ (Digital Music Plus), a
Sony codec enhancer that reproduces detailed frequencies from
compressed audio files.
1
®
Connect, charge, and control your iPod , iPhone , Walkman player
or other compatible USB devices via the USB 1 - Wire jack in the front of
the unit. You can also view metadata like song title and artist on the
front display.
®2
®2
®
3
The Quick - BrowZer feature lets you search and select songs by
category, including artist, album, genre, or playlist. Jump Mode gets you
closer to the song you want by fast forwarding through the music
categories in 10 percent increments.
®
The ZAPPIN™feature lets users play music samples in 6, 9, or 30 - second
clips until you find the song you're looking for.
Passenger Control lets your co - pilot control the music playing from your
iPod device via connected USB 1 - Wire, and as they scan through your
music, artist and album information is conveniently shown on the
receiver display.
®2
SensMe™application can organize your music into playlists that
perfectly match your mood, scene and location, making it easier to
choose the music that fits the moment.
The Advanced Sound Engine uses EQ7 equalizer, adjustable LPF/HPF
crossovers, Listener Position calibration, DM+ advanced sound
restoration, Rear Bass Enhancer, and Dynamic Loudness volume leveler
to create an ideal in - car listening environment.
When you’re ready to expand your system, the CDX - GT650UI offers front
and selectable rear or subwoofer pre - amp RCA outputs for external
amplifiers. Set the built in electronic HPF/LPF crossovers to improve sound
quality and reduce system distortion.
Control your Xplod™CD receiver while keeping your eyes on the road
with the included wireless card remote (RM - X151).

Sony Electronics Inc. • 16530 Via Esprillo • San Diego, CA 92127 • 1.800.222.7669 • www.sony.com
Last Updated: 04/13/2011
CDX -GT650UI
CDX-GT650UI CD Recevier
Please visit the Dealer Source for current information at
www.sony.com/dealersource
Features
Detach face with front aux input The easy-to-read two line LCD display shows
clock, station ID and track data when playing back your digital MP3/WMA/AAC
files . Front auxiliary input lets you connect almost any portable audio device to
your car's sound system.
1
Dynamic Color Illuminator Dynamic Color Illuminator lets you match your radio’s
illumination to complement your existing vehicle lighting components. With
selectable Sound Synchronization, the timing of the color change is
synchronized with the audio source.
MP3/WMA/AAC playback Multi-format playback lets you play your MP3, WMA,
or AAC songs . Hear digital music files in their original vibrancy with DM+ (Digital
Music Plus), a Sony codec enhancer that reproduces detailed frequencies
from compressed audio files.
1
1
®
Front USB 1-Wire Connect, charge, and control your iPod , iPhone ,
Walkman player or other compatible USB devices via the USB 1-Wire jack in the
front of the unit. You can also view metadata like song title and artist on the
front display.
®2
®2
®
3
Intuitive Search Features The Quick-BrowZer feature lets you search and select
songs by category, including artist, album, genre, or playlist. Jump Mode gets
you closer to the song you want by fast forwarding through the music
categories in 10 percent increments.
®
ADDITIONAL FEATURES
ZAPPIN ™track sampling search
Passenger Control
SensMe™App Music Channels
Advanced Sound Engine
RCA outputs for external amplifiers
Wireless card remote
Specifications
Convenience Features
CDTextDisplay: CD/MP3/WMA/AACdata displayed
On - ScreenClock: 12H
DimmerAdjust: SelectableAuto/on/off
KeyIllumination: Variable color illumination
General
DiscCapacity: 1
Color: DarkTitanium
Audio
PreoutImpedance: 220ohms
PreoutVoltage: 2volt
S/NRatio: Audio Power:CEA2006 S/N80 dBA
FrequencyResponse: CD:10 - 20,000Hz
WowandFlutter: Belowmeasurable limit
StationPreset(s): 18FM /12 AM
Digital - to - AnalogConverter: 24bit
TunerFrequencyRange:
FM:Tuner Frequency Range(MHz): 87.5 - 107.9
AM:TunerFrequency Range(kHz): 530 - 1710
TunerType: SSIR - EXAwith RDS
VolumeControl: Tel/NavAttenuation Circuitry
Band: AM/ FM
Signal - to - NoiseRatio(dB): CD:120 dB
Format(s)Supported: MP3/WMA/AACfiles
Equalizer: EQ7:7 bandEQ,
+/ - 6 dBat 63Hz
+/ - 6 dBat 160Hz
+/ - 6 dBat 400Hz
+/ - 6 dBat 1kHz
+/ - 6 dBat 2.5kHz
+/ - 6 dBat6.3kHz
+/ - 6 dBat 16kHz
Convenience
TiltRange: 0 - 45° mounting angle
Display
Technology: LCD
DisplayColor: Black/ Variable color
TextDisplayed: Source,artist, track, playbacktime, menuand clock
TextLines: 2 lines of information
Amplifier Section
SpeakerImpedance: 4 - 8Ohms
Maxpoweroutput: 52watts x4 at4 ohms
Tuner
FMUsableSensitivity: 10dBf
Selectivity:75 dBat 400kHz
1
S/NRatio: 70dB (mono)
FrequencyResponse: FM:20 - 15,000Hz
StereoSeparation: 40dB at1 KHz
Power
OutputPower: 52Wx4WattsMax Power - CEA2006 StandardPowerOutput: 17Watts RMSperchannel into4
Ohms,4 channels drivenfrom 20Hz to 20 kHz withless than1% THD+N.
CurrentDrain: 3 - 5 amps
InputVoltage: 12V DCcar battery(negative ground)
Inputs and Outputs
RCAAudioOutput(s): Front,Rear and SubRCA pre - ampoutputs
DigitalAudioInput(s): - Abilityto use allforms ofUSB devices mayvary asnot all devicesare compatible.
Thisunit can beconnected to thefollowing iPods. Updateyour iPod tothe latest softwarebefore you useit.
iPodNano 1st generation*
iPod Nano 2nd generation (aluminum)
iPodNano 3rd generation(video)
iPod5th generation (video)*
iPod Classic
iPod Touch
iPhone
Thisunit iscompliant with MSC(Mass StorageClass) andMTP (MediaTransfer Protocol)type USBdevices
compliantwith the USBstandard.
Thisunit cannot recognizeUSB devices viaa USB hub.
Ifyou haveany questions orproblems concerningyour unitthat arenot covered in the ownersmanual,
consultyour nearestSony dealer
USBPort(s): FrontUSB - Full Speed
AntennaTerminal(s): AM/FMAntenna InputTerminal
12VTriggerOutput(s):
Powerantenna
Amplifierturn on
RemoteJack: Optional wiredremote inputterminal
AudioIn:
FrontAuxwithvariable level: - 8dB∼+18dB
FrontUSB input
SonyBus terminals
InfraredPort: Wirelessremote
Dimensions
Weight: 1.3 kg (2 lb. 14 oz.)
Measurements: 178x 50x 179mm
Supplied Accessories
Partsfor installation andconnections (1 set)
RM - X151wireless remote
Optional Accessories
Replacementremote: RM - X151
CDchanger (6discs): CDX - T69
Sourceselector: XA - C40
Aux - inselector: XA - 300
HD Radio tuner:XT - 100HD
iPod USB cable: RC - 100IP
Color: DarkTitanium
UPCCode: 027242796003
1.Not allMP3 andWMA filesmay playbackdue tofile variations.Copyright protectedACC - LCfiles cannotbe
played back.
2.Ability to useall generationsof iPodproducts may vary as notall productsare compatible.Compatible with
iPod touch, iPod Nano 3rd generation, iPod classic
3.Ability to useall formsof USB devicesmay vary asnot alldevices are compatible.
©2010 SonyElectronics Inc.Allrights reserved.Reproduction inwhole orinpart withoutwritten permissionis
prohibited.Sony, Walkman, Xpl
ō d,SenseMe, ZAPPIN, Quick - BrowZerand theSony andXplod logos are
trademarksof Sony. iPhoneand iPodare trademarksof Apple Inc.,registered inthe U.S.and other countries.
Allother trademarksare trademarksof theirrespective owners.Features andspecifications are subject to
changewithout notice. Non - metricweights and measuresare approximate andmay vary.
®
®
®
