Clarion VS735 User manual

Warning!
THE CLARION VS735 DIGITAL MEDIA PLAYER IS DE-
SIGNED TO ENABLE VIEWING OF DVD OR CD-VIDEO
RECORDINGS ONLY FOR REAR-SEAT OCCUPANTS.
DIGITAL VIDEO PRODUCTS ARE NOT INTENDED FOR
VIEWING BY THE DRIVER WHILE THE VEHICLE IS IN
MOTION. SUCH USE MAY DISTRACT THE DRIVER OR
INTERFERE WITH THE DRIVER’S SAFE OPERATION OF
THE VEHICLE, AND THUS RESULT IN SERIOUS INJURY
OR DEATH. SUCH USE MAY ALSO VIOLATE STATE LAW.
CLARION DISCLAIMS ANY LIABILITY FOR ANY BODILY
INJURY, INCLUDING FATALITIES, OR PROPERTY DAMAGE
THAT MAY RESULT FROM ANY IMPROPER OR UNIN-
TENDED USES OF THIS PRODUCT.
About Installation
Installation of mobile audio and video components requires
experience with a variety of mechanical and electrical proce-
dures. Even though this manual provides general installation
and operation instructions for your new Clarion VS735 Digital
Media Player, it does not show the exact installation methods
for your particular vehicle.
If you do not have the required knowledge and experience to
successfully complete the installation, we strongly recommend
consulting an authorized Clarion dealer about professional
installation options.
Table of Contents
1. Introduction....................................................................2
2. Care and Maintenance ..................................................3
3. Discs Played by the VS735 ...........................................4
4. Using the VS735.............................................................5
5. The Remote Control.......................................................9
6. DVD/VCD/CD-Audio Playback ....................................11
7. MP3 Playback on CD-R Discs.....................................15
8. Installation and Wiring................................................17
9. Setup .............................................................................29
10. Troubleshooting.........................................................37
11. Specifications.............................................................. 38
12. Limited Warranty Information ................................... 39

2 VS735
1. INTRODUCTION
The Clarion VS735 is a full-featured Digital Media Player
designed specifically for the mobile environment. It is intended
for use with other Clarion multimedia products, and can also
be integrated with many other products as part of a complete
mobile video solution. With a set of auxiliary audio and video
inputs and a digital audio output, the VS735 can also support
use of optional audio/video components such as
camcorders, videogames, or digital audio processors. The
VS735 incorporates many different video output settings to
allow the best possible viewing experience, regardless of
what type of video monitor you may be using.
The VS735 plays DVD discs in NTSC or PAL formats (NTSC
is the standard North American video format), CD-Audio
discs, and CD-recordable discs with MP3 files. For more
details on disc types supported, please see “Discs Played by
the VS735.”
The remote control (included) provides access to the full set
of standard DVD functions, such as subtitle control, digital
freeze-frame viewing, viewing from multiple camera angles,
selection of various language audio soundtracks, and digital
playback at fast or slow speeds. The VS735 also supports
direct access to defined points on a DVD or CD.
Note:
•The VS735 is designed to be a component in a full audio/video
system. If you have any questions about compatible components,
such as system controllers, monitors, FM modulators, or other audio/
video products, please contact your authorized Clarion dealer.
Accessories Supplied with the VS735
•Detachable Control Panel (DCP) case
•Infrared (IR) remote control and two AAA alkaline batteries
•External IR Receiver for optional applications
•Power-supply harness and RCA audio and video cables
•Assorted mounting hardware
•Owner’s Manual / Installation Guide
About the Registered Marks
This product incorporates copyright protection technology that
is protected by method claims of certain U.S. patents and
other intellectual property rights owned by Macrovision
Corporation and other rights owners. Use of this copyright
protection technology must be authorized by Macrovision
Corporation, and is intended for limited viewing uses only
unless otherwise authorized by Macrovision Corporation.
Reverse engineering or disassembly is prohibited.
Manufactured under license from Dolby Laboratories. Dolby

VS735 3
and the double-D symbol are trademarks of Dolby Laborato-
ries.
FCC Approval
This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to Part 15 of the
FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential
installation. This equipment generates, uses, and can radiate
radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interfer-
ence to radio communications. However, there is no guarantee
that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or
television reception, which can be determined by turning the
equipment off and on, the user is encouraged to consult the
dealer or an experienced radio/TV technician for help.
2. CARE AND MAINTENANCE
Handling Discs
Always handle a disc by its edges. Never touch the surface of
the disc directly. To remove inadvertent fingerprints and dust,
use a soft cloth and wipe in a straight line from the center of
the disc to the outside edge. Never use liquid or aerosol
cleaners, anti-static spray, or thinner to clean the disc surface.
Do not place discs in the following places: direct sunlight; dirty,
dusty and damp areas; near car heaters; on the seats or
dashboard. Avoid using adhesive labels on discs.
Liquids and the VS735
Keep all liquids, including beverages and cleaning liquids,
away from the VS735. Liquids inside the player can damage
the electronics, and result in electrical shock or fire. If the unit,
the detachable control panel, or the remote control should
become wet, turn off all power and contact an authorized
Clarion dealer to have the system inspected.
Servicing the VS735
This unit uses a precision mechanism. In the event that
trouble arises, never open the case, disassemble the unit, or

4 VS735
lubricate the rotating parts.
Do not attempt to open the unit, the detachable control panel,
or the remote control. The internal parts are not serviceable
by the user. Opening any of the components will void the
warranty. THE VS735 IS A CLASS I LASER PRODUCT,
USING A LASER WHICH COULD CAUSE HAZARDOUS
RADIATION EXPOSURE IF IMPROPERLY DISASSEMBLED.
All warranty service should be performed by authorized
Clarion service centers.
CAUTION!
Changes or modifications to this product not
approved by the manufacturer will void the
warranty and will violate FCC approval.
Temperature and Moisture
If the player is used while the interior of the vehicle is very
cold, condensation may form on the disc or on the internal
optical pickup system and prevent proper playing of the disc. If
you suspect that condensation is an issue, eject the disc and
inspect the playing surface. If necessary, remove the conden-
sation with a clean soft cloth as described above. If you still
experience problems with playback, you will need to wait for
approximately one hour to allow the VS735 to warm up, and
for the condensation to evaporate. If playback issues continue,
please see your authorized Clarion dealer.
3.DISCSPLAYED BY THE VS735
Discs Compatible with the VS735
DVD, Video CD (VCD), CD/CD-R, and MP3 discs are compat-
ible with the VS735. The identifying logo and description of
each disc type is given below.
DVD 12 cm disc/8 cm disc
(single-sided disc only)
Video CD 12 cm disc/8 cm disc
CD/CD-R,MP3 12 cm disc/8 cm disc
DVD Regions
This digital media player is designed and manufactured to
respond to the Region Management Information that is
recorded on a DVD disc. If the Region number described on

VS735 5
the DVD disc does not correspond to the Region number of
this player (Region 1), this player will not be able to play the
DVD disc. Some DVD discs are manufactured to operate in
“all” zones, and those discs are compatible with the VS735.
Region Identification Markers:
ALL
146
1
Discs Incompatible with the VS735
The following disc types are incompatible with the VS735:
•DVD-ROM
•DVD-R/DVD-RW/DVD-RAM
•Photo CD
•CD-ROM (Excluding most CD-Recordable discs using MP3
or CD-A formats)
•CD-ReWriteable (CD-RW)
•CD-Audio manufactured with certain copy protection
methods
•Any DVD with a Region number other than “1” and “ALL”
4. USING THE VS735
In order to operate the VS735, the vehicle ignition key switch
must be in the ACC or RUN position.
ACC or engine
ON position
WARNING!
To prevent the battery from going dead,
operate this unit with the engine
running, if possible.
Front-Panel Controls
[OPEN] button
[POWER]
button
front-panel display
IR receiver
The [OPEN] button lowers the face so that discs can be
inserted and ejected.

6 VS735
The [POWER] button turns the VS735 on and off. When the
ignition switch is in the ACC or RUN positions, this button is
illuminated red. The [POWER] button on the remote can also
be used.
The IR Receiver detects the signals from the included infrared
remote control. Aim the remote control at the IR receiver
during use.
DVD
VCD
CD
DOLBY
DIGITAL
REMAIN
ANGLE
CHP TRK
A - B
REPEAT 1
TITLE
SCN
RDM
L/R
MP 3
PBC
Media Type
Play/Pause
Disc
Status
Disc Loaded Alphanumeric display
Function
status indicators Playback Control Status
Mono Audio
Indicator
The front-panel display provides basic information about the
status of the VS735. Please note that much information about
using the VS735 will be displayed on the video screen
connected to the unit, and initial setup of the VS735 cannot be
completed without an operating video monitor providing this
on-screen display of menus and settings. Whenever the term
“on-screen display” is used, it refers to the video monitor
display, not the front panel display.
Disc loading
slot
Eject button
(on back of DCP)
Reset button Security
LED
DCP release button
(on back of DCP)
Once the face is lowered, insert discs by placing them into
the disc loading slot.
The [ ] eject button is located on the back of the detachable
control panel (DCP), not on the front panel. It is backlit green
whenever the key is in the ACC or RUN positions. It ejects
discs from the disc loading slot.
The Security LED flashes red when the Detachable Control
Panel is removed.
The Reset button can be used to reset the internal micropro-
cessor. See “Troubleshooting”, in Section 10, for more
information.

VS735 7
The Detachable Control Panel (DCP)
The DCP can easily be damaged by shocks. After removing it,
be careful not to drop it or subject it to strong shocks - store it
immediately in the included storage case. Be careful not to
damage it by pressing on it with hard objects.
If the DCP becomes dirty, wipe off the dirt with a soft, dry
cloth only.
Other precautions when handling the DCP:
•Do not drop the DCP.
•Do not put pressure on the display or control buttons when
detaching or re-installing the DCP.
•Do not expose the DCP to high temperatures or leave in
direct sunlight.
•Do not touch the contacts on the DCP or on the main unit
body. It may result in poor electrical contact. If any dirt or
foreign substances adhered on the contacts, they can be
removed with a clean and dry cloth.
Detaching the DCP
To detach the DCP:
1 Press the [OPEN] button. The DCP will deploy outward.
2 Remove the DCP by pressing the [RELEASE] button on the
rear of the DCP, and pulling the DCP up and away from its
hinged mounting tray.
DCP release button
(on back of DCP)

8 VS735
3 When the DCP is removed, the security LED will flash red.
Fold the hinged DCP tray into the main body. A ‘click’ will
be heard.
Security LED
4 For safekeeping, store the DCP immediately in the
supplied protective case.
Protective Case
DCP
Reattaching the DCP
Holding the DCP by its edges, press the DCP into the hinged
DCP tray on the front panel of the VS735. A 'click' should be
heard when the DCP is properly attached.
Note:
•If the DCP fails to lock into position properly, some control buttons
may not function, and/or the front-panel display may not display
properly. Should this occur, remove the DCP and reattach it .

VS735 9
5. THE REMOTE CONTROL
1Power
Switches the VS735 on and off.
2 0-9 Numeric keys
Used with various functions.
3 ILL/GOTO Illumination/Goto
Adjusts front-panel display brightness when the disc is in
STOP mode.
Enables direct access to a defined point within a track or
chapter during playback.
4Stop
Press to stop playback.
5/ Fast reverse/fast forward
Use for high-speed search within a chapter or track.
Moves the cursor left and right within a menu.
6/ Next/Previous
Steps to the next or previous chapter/track.
Moves the cursor up and down within a menu.
7 SUBTITLE
Accesses the various subtitle functions on DVD discs with
multilingual support.
8 SETUP
Accesses the SETUP menu of the VS735.
9 TITLE
Accesses the TITLE menu of the DVD disc.
10 DISPLAY
Displays or conceals the on-screen display status line
during playback.

10 VS735
11 REPEAT
Selects among the three repeat modes: 1, all, and off.
12 Play/Pause
Begins and pauses playback.
13 A/V A/V Input
Switches between the internal disc player and the auxiliary
audio/video input.
14 ENTER
Used to select a highlighted menu item.
15 AUDIO
Accesses the various language audio tracks on DVD discs
with multi-language support.
16 ANGLE
Selects among the various camera angles on DVD discs
with multi-angle support.
17 MENU
Accesses the MAIN menu of the DVD disc.
Using the Remote Control
Aim the remote control towards the IR receiver on the front
panel, as shown. The remote control can operate at a 30-
degree angle from the front of the unit.
IR Receiver
If you try to perform a function that’s not permitted, either
temporarily or by the disc, the on-screen display shows this:
Inserting the Batteries
The remote control uses two AAA batteries.
To insert the batteries:
1 Slide open the battery compartment cover.
2 Insert the new batteries. Make sure that the positive and

VS735 11
negative poles of the batteries are positioned as shown
inside the battery compartment.
+
+
+
+-
-
-
-
3 Slide the battery compartment closed .
6. DVD/VCD/CD-AUDIO PLAYBACK
Inserting a DVD/VCD/CD
1 Turn the vehicle’s ignition key to the ACC position.
ACC or engine
ON position
2 Press the [POWER] button .
[OPEN] button
[POWER]
button
front-panel display
IR receiver
2 Press [OPEN] so that the front cover opens slowly forward.

12 VS735
3 Holding the disc by its edges, gently insert the disc label-
side up into the loading slot until the power-loading
mechanism pulls the disc in.
4 Gently close the front panel by pressing it back into place.
You will hear a “click” when the front panel is properly
secured in the closed position.
Removing a Disc
1 Press [OPEN]. Let the panel fully fold down, then press the
[ ] eject button to eject the disc.
Disc loading slot
Eject button
2 Remove the disc and close the detachable control panel
(DCP).

VS735 13
Disc Playback
DVD playback will often begin automatically when the disc is
inserted. With some DVD discs, you will need to press
[ENTER] or [ ] to begin playback.
CD-Audio discs will begin playback automatically.
CDs with MP3 files may require you to navigate the file
structure menu. For more information, see “MP3 Playback on
CD-R Discs.”
Stopping Playback
There are two ways to stop playback:
•Pressing []once will stop playback, and the VS735 will
store the location last played on the disc. Playback can be
resumed at the same point on the disc by pressing [ ].
•Pressing []twice will stop playback and clear the
VS735’s memory of the last point played on the disc.
Pressing [ ] at this point will cause the VS735 to begin
playback from the beginning of the disc.
Selecting a Track or Chapter
Moving to the Next Track or Chapter
Press the []button during playback. The next track or
chapter will be selected.
Moving to the Previous Track or Chapter
Press the []button during playback. The first time this button
is pressed, playback of the current track or chapter will restart
from the beginning. Pressing this button again will cause the
previous track or chapter to be played.
Note:
•For some VCD 2.0 discs, the []and [ ] functions may be
unavailable.
Fast Searching During Playback
Press [ ] and [ ] during playback to rapidly search for a
particular section of a DVD or CD. Each time a fast-search
button is pressed, the speed of the fast search changes as
follows:
Standard Speed – 2X Standard Speed – 4X – 6X – 8X – Back
to Standard Speed.
Pausing Playback
Press [ ] during playback. Disc playback will pause, and the
frame displayed at the point pause mode was entered will be
displayed on the screen.
Press [ ] again to return to normal playback.

14 VS735
Repeat Mode
Press the [REPEAT] button to select from the following repeat
modes:
Repeat 1 - Repeat - Repeat Off.
With DVD playback, pressing the [REPEAT] button once
causes the current chapter to be replayed. Pressing it twice
enables the DVD disc to be continuously replayed.
With CD playback, pressing the [REPEAT] button once
causes the current track to be replayed. Pressing it twice
enables the disc to be continuously replayed.
Viewing Angles
The Angle Mark appears during scenes that offer multiple
viewing angles. (Not all DVD discs support this function.) Use
the [ANGLE] button to select from the various angles avail-
able. To conceal the Angle Mark, please see section 9 “Setup.”
GOTO Mode
During DVD playback, pressing the [ILL/GOTO] button once
allows direct input of the chapter you wish to directly access.
Pressing it twice allows you to enter the elapsed time of the
scene that you wish to directly access (within the current
chapter).
During CD playback, pressing the [ILL/GOTO] button allows
you to enter the elapsed time of the passage that you wish to
directly access within the current track.

VS735 15
Parental Control
The Parental Control feature allows authorized users to
select an upper limit to film ratings that can be played by the
VS735. The factory default setting for this feature is off, and
the default password for managing this feature is 3308. To
enable the Parental Control feature or to change the pass-
word, see section 9, “Setup.” If a DVD is inserted with a film
rating higher than selected, one of the following screens will
appear:
Screen A
PARENTAL VIOLATION
Welcome
Screen B
The parental setting o this
player prohibits play.
Would you like this disc to play?
NO
YES
Screen A: In order for the film to play, the viewer must press
Setup and change the Parental Control setting using the
password. See “Setup”, in section 9, for more information.
Screen B: In order for the film to play, use the navigation and
[ENTER] keys to select “Yes,” and then the four-digit numeric
“password” must be entered. Use the numeric keypad on the
remote to enter the password, and then press enter - the disc
will begin playback.
The parental setting o this
player prohibits play.
Would you like this disc to play?
NO
YES
INPUT PASSWD:
Notes:
•To change the film rating setting, the password must be used.
•The VS735 determines the correct film ratings to use based on
the country selected in the “Locale” setting —see “Setup”, in
section 9.

16 VS735
7.MP3PLAYBACK ON CD-R DISCS
What is MP3?
MP3 is an audio compression method. This audio compres-
sion method has become a standard format with many PC
users. MP3 allows the original digital audio data to be
compressed to about 10 percent of its initial file size while still
retaining high sound quality. This means that about 10 music
CDs can be recorded on a CD-R disc, thus allowing longer
listening time without having to change CDs.
Notes:
•The VS735 cannot play back a disc recorded on a CD-RW unit.
•Some CDs recorded in CD-R mode may not be usable.
•Files without MP3 data will not play.
MP3 Playback
When a disc with MP3 files is inserted, the SMART NAVI
screen will appear. Each folder and file will be shown (the
order may be slightly different than that on your PC). Navigate
the files and folders using the navigation arrow keys, and
select a file or folder to be played by using the [ENTER]
button.
ROOT 0
MP3 (ARTIST NAME) 1
- - SMART NAVI - -
MP3 (ARTIST NAME) 3
ROOT
MP3 (ARTIST NAME) 2
ARTIST NAME - SONG TITLE
To move to the next file or the previous file, use the [] and
[ ] buttons.
To fast-forward or fast-reverse within a file, use the [] and
[ ] buttons.
Three repeat modes are available for MP3 use:
•NO REPEAT
•REP – ONE repeats the current file
•FOLDER REP repeats the current folder
To conceal the SMART NAVI screen, see section 9 “Setup.”
Precautions When Creating an MP3 Disc
Supported MP3 File Formats
•ISO9660, level 1 and level 2 (the most common type of

VS735 17
MP3 format)
•Joliet (a version of ISO9660 that supports longer
filenames)
•Romeo (a format used by some CD-creating software)
File Extensions
Always add a file extension “ .MP3” or “.mp3”to an MP3 file
by using single-byte letters. If you add a different file exten-
sion, or forget to add the file extension “ .MP3” or “.mp3,” the
file cannot be played. In addition, if you use upper case and
lower case letters (capital and small letters) mixed together for
file extensions, normal play may not be possible.
File and Folder Structure
The folder name and file name can be displayed as the title
during MP3 play. However, the title must be within 31 and 27
single-byte alphabetical letters and numerals for the folder
name and file name, respectively (not including an exten-
sion). Entering more letters or numerals than specified may
cause an incorrect display.
A disc with a folder having more than 8 hierarchical levels will
conflict with MP3 system requirements and playback will be
impossible.
A total of 255 files and folders are allowed. When the number
of files and folders is more than 255, playback of tracks in
excess of that number is impossible. There is a maximum of
31 files in each folder. File tracks are played in the order that
they were recorded onto a disc. (Files might not always be
played in the order displayed on the PC.)
Sound Quality
Some noise might be audible—this depends on the type of
encoder software used while recording. It is not noise created
by the VS735.
Bit Rates
The VS735 supports the following bit rates: 32kHz, 44.1kHz,
48kHz, and 96kHz. In case of a track recorded at VBR
(variable bit rate), the display for the play time of the track may
be slightly different from the actual play time. Also, the recom-
mended value for VBR ranges from 32 kbps to 320 kbps.
ID3V1 and ID3V2 Tags Support
Both ID3V1 and ID3V2 tags are supported. These allow up to
30 characters per song name and 30 characters per artist
name.

18 VS735
8. INSTALLATION AND WIRING
1. Before Starting
Read these instructions and the following precautions care-
fully.
WARNING!
Be sure to disconnect the battery (-)
terminal before starting. This is to
prevent short circuits during installa-
tion.
Precautions
•This unit is exclusively for cars with a negative ground, 12V
power supply.
•Do not open the case. There are no user-serviceable parts
inside. If you drop anything into the unit during installation,
consult your dealer or an authorized Clarion service center.
•Use a soft, dry cloth to clean the case. Never use a rough
cloth, thinner, benzene, alcohol, or other solvent. For tough
dirt, apply a small amount of cold or warm water to a soft
cloth and gently wipe.
2. Package Contents
1 VS735R disc unit
2 DCP Case
3 IR Remote control
4 (2) AAA Alkaline Batteries (for remote control)
5 Trim Bezel
6 DIN Mounting Sleeve and release tools
7 (4) M4x6 Truss-head machine screws
8 (4) M5x5 Truss-head machine screws
9 (4) M5x5 Flat-head machine screws
10(4) M5×18 Hexagon washer-head tapping screws
11 (2) M5 Hexagon nuts
12(1) Plain washer
13 (1) Spring washer
14 5-meter 4-pin Power Supply harness
15 5-meter RCA Audio Cable
16 5-meter RCA Video Cable
17 Additional IR Receiver (with 5-meter cable)
18 Installation Brackets
19 Backstrap
20 Owner’s Manual / Installation Guide

VS735 19
3. Installation Requirements
1 Install the unit within 30 degrees of the horizontal plane.
Max. 30˚
2 Use the enclosed screws for installation. Using other
screws can cause damage and void the warranty.
Chassis Chassis
Damage
Max. 8 mm (M5 screw)
4. Installing the VS735
Installing into a Universal In-Dash Mount (using the DIN
sleeve)
First, verify that the opening you will be mounting the VS735
into will accommodate the mounting sleeve.
Sleeve opening dimensions
Hole
7-3/16" (182 mm)
2-1/16" (53 mm)
Note:
•Some car models require special mounting kits for proper installation.
Consultyour Clariondealer for details.
1 Place the universal mounting sleeve into the instrument
panel opening. Ensure a tight fit.
2 Bend the tabs of the mounting sleeve inward as shown to
lock the sleeve into place.
3 Wire the power harness, make all connections to the
VS735 (see “Wiring the VS735”), and plug in the power
harness.
4 Gently insert the VS735 into the mounting sleeve until it
locks into place with a ‘click’.
5 Clip the trim ring into place.

20 VS735
VS735 unit
Screwdriver
Tabs
Hole
Rear fastening hole of vehicle,
Instrument panel
Universal mounting bracket sleeve
Tabs
Trim ring
or other tool
Sleeve clip
or backstrap
Nut and washer
Removing the VS735 from the Universal In-Dash Mount
Note:
•This requires you to have the original release tools provided with the
VS735. Keep these tools in a safe place, not in the vehicle.
1 Remove the rear nut from the backstrap.
2 Remove the trim ring.
3 Insert the removal tools as shown, until a ‘click’ is heard.
Pull gently and evenly on both the left and right side tools,
and the unit will slide out of the mounting bracket sleeve.
Removal tools
Trim ring
Sleeve clip
VS735
Mounting bracket
sleeve Rear nut
Instrument
panel
Installing into the Universal In-Dash Mount Sleeve
