Sony CDP-791 User manual

CDP-791/X1 11ES
SERVICE MANUAL US Mode!
Canadian Mode
i
CDP-X 111ES
AEP Model
UK Mode!
CDP-791
Photo: CDP-791
i
j
i
t
c
c
t
SPECIFICATIONS
Compact disc player
Frequency response
Signal-to-noise ratio
Dynamic range
Harmonic distortion
Channel separation
2Hz -20 kHz ±0.5 dB
More than 108 d8
More than 98 d8
Less than 0.0027%
More than 100 dB
Outputs
LINE OUT (FIXED)
(phono jacks)
LINE OUT
(VARIABLE)
(phono jacks)
DIGITAL OUT
(OPTICAL)
(optical output
connector)
PHONES
(stereo phone jack)
Output level 2V(at 50 kilohms)
Load impedance over 10 kilohms
Output level max. 2V(at 50 kilohms)
Load impedance over 50 kilohms
Wave length 660 nm
Output level —18dBm
Output level max. 10mW
Load impedance 32 ohms
General
Power requirements US, Canadian Model:
120 VAC, 60 Hz
AEP Model:
220 V-230 VAC, 50/60 Hz
UK Model:
240 VAC, 50 Hz
Model Name Using Similar Mechanism CDP-291/391
CD Mechanism Type CDM14-5BD1
Optcal Pick-Up Block Type BU-5BD1
Power consumption 12W
Dimensions (approx., 430 X11oX280 mm (w/h/d)
including projections) (17X47. X117. inches)
Weight (approx.) 40 kg (8 lbs 14oz)
Supplied accessories
Audio cord 1
(2 phono plugs -2phono plugs)
Remote commander 1
R6 (AA) batteries 2
Remote commander RM-D791
Remote control Infrared control
system
Power requirements 3VDC with two R6 (size AA) batteries
Dimensions Approx. 62 X20 X175 mm (w/h/d)
(IVnX U/«X7 inches)
Wei9ht Approx. 130 g(4.6 oz)
Including batteries
Design and specifications subject to change without notice.
COMPACT DISC PLAYER
SONY

CDP-791/X1 11ES MODEL IDENTIFICATION
—Model Number Label
—
CDP-791
CDP-X111ES
SAFETY CHECK-OUT
After correcting the original service problem,
perform the following safety check before releasing
the set to the customer:
Check the antenna terminals, metal trim, “metallized”
knobs, screws, and all other exposed metal parts for
AC leakage. Check leakage as described below.
LEAKAGE TEST
The AC leakage from any exposed metal part to
earth ground and from all exposed metal parts to any
exposed metal part having areturn to chassis, must
not exceed 0.5 mA (500 microampers). Leakage
current can be measured by any one of three
methods.
Canadian Model:
AEP Model:
UK Model:
AC: 120V 60 Hzl2W
AC220 -230V, 50/60Hz
AC240V-50/ 60Hz
1. Acommercial leakage tester, such as the
Simpson 229 or RCA WT-540A. Follow the
manufacturers’ instructions to use these instru-
ments.
2. Abattery-operated AC milliammeter. The Data
Precision 245 digital multimeter is suitable for
this job.
3. Measuring the voltage drop across aresistor by
means of aVOM or battery-operated AC volt-
meter. The “limit” indication is 0.75 V, so
analog meters must have an accurate low-
voltage scale. The Simpson 250 and Sanwa
SH-63Trd are examples of apassive VOM that
is suitable. Nearly all battery operated digital
multimeters that have a2V AC range are
suitable. (See Fig. A)
To Exposed Meta!
Parts on Set
0. 15pF -p >1.5kil .Z. AC
voltmeter
(0.75 V)
Earth Ground
|
Fig- A. Using an AC voltmeter to check AC leakage.
TABLE OF CONTENTS
Section Title Page
Specifications 1
Safety Check-out 2
Model Identification 2
1. GENERAL
Notes on Handling the Optical Pick-up
Block or Base Unit 3
Notes on Laser Diode Emission Check 3
Location of Controls 3
Adjusting Operating Voltage 3
2. DISASSEMBLY 4
3. ELECTRICAL BLOCK CHECKING
SCurve Check 5
RF Level Check 5
E-F Balance Check 5
RF PLL Free- run Frequency Check 6
Focus/Tracking Gain 6
4. DIAGRAMS
IC101(CXA1372Q)P1N DESCRIPTIONS •••• 7
4-1. Block Diagram 8
4-2. Printed Wiring Boards 12
4-3. Schematic Diagram 15
5. EXPLODED VIEWS 21
SAFETY-RELATED COMPONENT WARNING!!
COMPONENTS IDENTIFIED BY MARK OR DOTTED
LINE WITH MARK ^ON THE SCHEMATIC DIAGRAMS
AND IN THE PARTS LIST ARE CRITICAL TO SAFE
OPERATION. REPLACE THESE COMPONENTS WITH
SONY PARTS WHOSE PART NUMBERS APPEAR AS
SHOWN IN THIS MANUAL OR IN SUPPLEMENTS PUB-
LISHED BY SONY.
6. ELECTRICAL PARTS LIST 24
ATTENTION AU COMPOSANT AYANT RAPPORT
ALA SECURITE!
LES COMPOSANTS IDENTIFIES PAR UNE MARQUE ^
SUR LES DIAGRAMMES SCHEMATIQUES ET LA LISTE
DES PIECES SONT CRITIQUES POUR LA SECURITE
DE FONCTIONNEMENT. NE REMPLACER CES COM-
POSANTS QUE PAR DES PIECES SONY DONT LES
NUMEROS SONT DONNES DANS CE MANUEL OU
DANS LES SUPPLEMENTS PUBLIES PAR SONY.

CDP-791/X1 11ES
NOTES ON HANDLING THE OPTICAL PICK-UP
BLOCK OR BASE UNIT
The laser diode in the optical pick-up block may suffer
electrostatic breakdown because of the potential di-
ference generated by the charged electrostatic load,
etc. on clothing and the human body.
During repair, pay attention to electrostatic break-
down and also use the procedure in the printed matter
which is included in the repair parts.
The flexible board is easily damaged and should be
handled with care.
NOTES ON LASER DIODE EMISSION CHECK
The laser beam on this model is concentrated so as to
be focused on the disc reflective surface by the objec-
tive lens in the optical pick-up block. Therefore, when
checking the laser diode emission, observe from more
than 30cm away from the objective lens.
For UK Model and AEP Model
This Compact Disc player is classified as a
CLASS 1LASER product.
The CLASS 1LASER PRODUCT label is located
on the rear exterior.
Adjusting Operating Voltage
For the customers of the model equipped
with the voltage selector
Check that the voltage selector is set to the
local power line voltage. If not, set the selector
to the correct position before connecting AC
power cord to awall outlet.
110-1 20 V220-240 V
'hr-1
This section is extracted from
instruction manual.
SECTION 1
GENERAL
Location of Controls
Front Panel
mDisc tray ©
IT1 ±OPEN/CLOSE button ©
fTl PEAK SEARCH button ©
fTl CONTINUE button and indicator ©, ©, ©. ©, ©
l~6~l SHUFFLE button and indicator ©
CD PROGRAM button and indicator ©, ®
GD TIME SET button©,©
[Tl EDIT/TIME FADE button ©. ©
Hol Numeric buttons ©
fm REPEAT button©
m.>20 (over 20) button ©
i~13! CHECK (program check) button ©, ©
OS CLEAR (program clear) button ©, ©, ©
RBI LINE OUT/PHONE LEVEL control ©
i~18~i -4-^ (manual search) buttons ©. ©
119! FADER button ©©
f20l (AMS*) buttons ©. ©
Ej TIME button ©
122J A. SPACE (auto space)/A. CUE(auto cue) button and auto cue
indicator ©, ©
ijS] (stop) button ©
(241 II (pause) button ©
i25~i (play) button ©
faTl Display window
1271 TIMER switch ©
L28J Remote sensor ©
-3-

CDP-791/X1 11ES
j£OPEN/CLOSE button ©
jSHUFFLE button ©
JPROGRAM button ©, ©
]M.SCAN (music scan) button ©
]Numeric buttons ©
jCLEAR (program clear) button ©. ©. ©
]CHECK button ©, ©
jA*— Brepeat button ©
]A. SPACE (auto space)/A.CUE (auto cue) button ©, ©
JFADER button ©, ©
J(stop) button ©
JLINE OUT LEVEL + /- (line out/headphone volume)
buttons ©
JSLOW (low speed manual search) buttons ©
j(manual search) buttons ©, ©
]*INDEX buttons ©
jM-4 WAMS buttons ©, ©
jII (pause) button ©
j(play) button ©
1CLEAR/REPEAT (A •>— Brepeat clear/repeat) button ©
)TIME button ©
!20 (over 20) button ©
jCONTINUE button ©, ©, ©, ©, ©
BASE UNIT REMOVAL
SECTION 2
DISASSEMBLY
Note: Follow the disassembly procedure in the numerical order given.
1. Remove CD mechanism from the set and turn over.
2. Turn the cam Oin the Arrow ©direction by the ©driver.
3. Take out disc table ©.
4. Remove bracket yoke ©.
5. Remove DU-5BD1 0in the Arrow 0direction.
Base Unit
BU-5BD1
bracket yoke
©
"O
&
-4-

SECTION 3
ELECTRICAL BLOCK CHECKING
CDP-791/X1 11ES
Note
:
1. CD Block basically constructed to operate with-
out adjustment. Therefore, check each item in
order given.
2. Use YEDS-18 disc (3-702-101-01) unless otherwise
indicated.
3. Use the oscilloscope with more than 10MJ? im-
pedance.
4. Clean an object lens by an applicator with neutral
detergent when the signal level is low than
specified value with the following checks.
RF Level Check
SCurve Check
BD board
TP (FEO)
TP (VC)
oscilloscope
JP
Procedure :11
1. Connect oscilloscope to test point TP (FEO) on
BD board.
2. Connect between test point TP (FES) and TP
(VC) by lead wire.
3. Turned Power switch on and actuate the focus
serch. (actuate the focus serch when disc table is
moving in and out.)
4. Check the oscilloscope waveform (S curve) is
symmetrical between Aand B. And confirm peak
to peak level within 3±lVp-p.
Scurve waveform symmetry
within 3±lVp-p
5.
After check, remove the lead wire connected in
step 2.
Note :•Try to mesure several times to make sure
that the ratio of A:Bor B:Ais more than
10 :7.
•Take sweep time as long as possible and light
up the brightness to obtain best waveform.
BO board
Tp"(RF) O
TP (VC) O
oscilloscope
-P
Procedure
:
1. Connect oscilloscope to test point TP (RF) on
BD board.
2. Turn Power switch on.
3. Put disc (YEDS-18) in and playback.
4. Confirm that oscilloscope waveform is clear and
check RF signal level is correct or not.
Note :
Clear RF signal waveform means that the shape “0”
can be ^clearly distinguished at the center of the wave-
form.
RF signal waveform VOLT/DIV :200mV
TIME/DIV :500nS
Tlevel
:
vp-p
E-F Balance Check
BD board
oscilloscope
TP (TEO)
TP (VC)
Procedure :
1. Connect test point TP (ADJ) to ground and TP
(TES) to TP (VC) with lead wire.
2. Connect oscilloscope to test point TP (TEO) on
BD board.
3. Turn Power switch on.
4. Put disc (YEDS-18) in and playback.
5. Confirm that the osilloscope waveform is sym-
metrical on the top and bottom in relation to 0V,
and check this level;
Traverse oscilloscope
,v —drntewfHr ——Lsymmetry
level: 2±lVp-p
6.
Remove the lead wire connected in step 1.
-5-

CDpCDP-791/X1 11ES
RF PLL Free-run Frequency Check
Procedure
:
1. Connect frequency counter to test point (PCK)
with lead wire.
Main board ffeqUenCy COUnt*r
2. Turn Power switch on.
3. Confirm that reading on frequency counter is
4. 3218MHz.
Focus/Tracking Gain
This gain has amargin, so even if it is slightly off.
There is no problem.
Therefore, do not perform, this adjustment.
Please note that it should be fixed to mechanical cen-
ter position when you moved and do not know
original position.
Adjustment Locations
:
[BD board]
—conductor side —
[Main board]
-Component Side -
-6-

SECTION 4
DIAGRAMS
IC101 (CXA1372Q) PIN DESCRIPTIONS
PIN NO. PIN NAME I/O FUNCTION
1VC 2.5 Volts power supply.
2FGD IFocus gain adjusting capacitor connected between (2) pin and (3) pin.
3FS3 1Focus gain adjusting capacitor connected between ©pin and ®pin
4FLB IFocus Servo low frequency boost-up capacitor' connected.
5FEO 0Focus drive output.
6FE- IFocus error amp inverted input.
7SRCH IConnected capacitor to making the focus serch waveform
8TGU 1Tracking gain adjusting capacitor connected between ®pin and ®pin
9TG2 ITracking gain adjusting capacitor connected between ®pin and ®pin
10 AVCC +5Volts power supply.
11 TAO 0Tracking drive output.
12 TA- ITracking amp inverted input.
13 SL +ISled amp non-inverted input.
14 SLO 0Sled drive output.
15 SL- ISled amp non-inverted input.
16 FSET 1Phase stabilizer setting resistor connected.
17 ISET ICurrent setting resistor connected.
18 SSTOP ILimit switch connection port.
19 AV EE Ground (0V).
20 DIRC IDirect control port. Non-connected.
21 LOCK 1Sled free-run protection is operate at “L".
22 CLK ISerial data transmission clock input form digital signal processor.
23 XLT ILatch input from digital signal processor.
24 DATA ISerial input from digital signal processor.
25 SENS 0Outputs internal state corresponding to address.
26 XRST 1System reset input. Reset at "L".
27 C. OUT 0Tracking counter output.
28 DGND Digitel ground. Grounded
29 MIRR 0Mirror output digital signal processor.
30 DFCT 0Deflect output. Deflect at "H".
31 ASY IAuto symmetry control input.
32 EFM 0EFM Comparator output.
33 FOK 0Focus OK.
34 CC2 IDeflect bottom hold input.
35 CC1 0Deffect bottom hold output.
36 DV CC +5Volts power supply.
37 CB 1Deffect bottom hold capacitor connected.
38 CP 1Mirror hold capacitor connected.
39 RF! 1RF Signal input (Capacitance coupled).
40 RFO IRF Signal input (Direct Coupled).
41 DV EE Grounded (0V).
42 TZC 1Tracking Zero-cross comparator input.
43 TE ITracking error amp input.
44 TDFCT IDeffect correction hold capacitor connected
45 ATSC 1Anti-shock input.
46 FZC 1Focus Zero-cross comparator input.
47 FE IFocus error input.
48 FDFCT IDeffect correction hold capacitor connected.

4-1. BLOCK DIAGRAM
-8-

IC30I A
DIGITAL SIGNAL PROCESSOR XRST
-TOSEIN
-(so) MIRR DATA (34
8CLK (35
iimiB
V8)XLTO
cr O^ooo
C/1 o°q <_> i— z
u.oZJ O3UJ
O</5 c/i c/> 2</j
<I4) FOK °«5S§£
DATA L(32)-
LRCfC 0(28>
BCLK 0(33>
5)—(!i>—U3>
1?9) OFECT SW
IC40I
SYSTEM CONTROL
SIRCS/8S IN(T)
VL UP(2j)-
zVL A.
-DOWN^ST
qX40I
_T(4MHzI
IIC49I
(2
)
REMOTE
VCONTROL
SENSOR
A-P ,IG-8G
1- 4, 40- 47, 50-55. 58-63 KEY0-YEY3
21-22 }
SI92 $191 FL040I
-0AD IN LOAD OUT dispiav
SWITCH SWITCH 1Lflr
0421
SWITCH
V, 4,5,9,12,13 )
IC403
FLIP FLOP
(IX7XiTHj5>
0419
SWITCH
FUNCTION
SWITCH kD-1
M191
LOADING MOTOR
IC47I
VOLUME MOTOR
DRIVE
RV45I
VLUME DRIVE
MOTOR
L01)20 I042 1XD4I8 TD4I9
(PROGRAM) (CONTINUE) (A CUE) (SHFFLE)
-9-

•Circuit Boards Location
•Semiconductor Location
Ref. No. Location Ref. No. Location
D101 B-22 IC202 G-17
D201 E-19 IC203 G-16
D202 1-19 IC301 H-16
D203 E-18 IC302 G-15
D204 E-18 IC303 G-14
D205 E-17 IC304 H-13
D206 E-17 IC305 E-15
D207 G-19 IC306 D-15
D208 F-17 IC307 C-15
D209 F-16 IC391 B-14
D341 F-15 IC401 C-9
D351 G-13 IC403 B-4
D401 E-2 IC451 H-6
D402 E-2 IC471 1-7
D403 E-3 IC491 H-2
D404 E-3
D405 E-3 Q101 D-22
D406 B-9 Q201 F-19
D407 B-9 Q202 G-18
D408 B-9 Q203 F-18
D409 B-9 Q204 H-18
D410 B-9 Q205 H-18
D41
1
B-9 Q206 H-17
D412 B-4 Q207 G-18
D413 B5 Q208 G-18
D414 B-5 Q209 F-16
D415 B6 Q341 0-13
D416 B-6 Q342 D-14
D417 D-8 Q343 D-13
D418 D-3 Q344 G-13
0419 F-2 Q371 B-14
D420 F-3 Q372 0-16
0421 F-2 Q373 B-14
0471 J-7 Q374 C-16
Q375 C-14
IC101 0-21 Q376 B-16
IC102 C-21 Q393 B-14
IC103 B-22 Q41
9
A-5
IC201 F-19 Q421 B-2
Note:
•O- parts extracted from the component side,
parts mounted on the conductor side.
J
K
-11 -

3S
12-

[POWER SWITCH BOARD (2/2)]
REMOTE
CONTROL
RECEIVER
O
illUiil
mu
ilia
mu
aaGS
SS2K
:©i
J20;
©1
|©J
ZQM
U
ZQm
:©5
?©2
Sal
SDi
IBS
©J
llHiiteogSmul
IqSq!
o™o
pSjoJ
NbS9
©'S©Ems2 ISM
©=©
ii
Ef^SjD
ik©b©i
ETW1©IM©I
KHs 3©
©SI
pB©
S
:• ©
©s©
pS
pB©
©B©
©Bp
©B©
almiia
Ik
!IIhuuhbhuhi
mu
D41I IN4MM-TA
anal
mm\
INIl
iail
gS|
\-rrrfrTY
ietueebI
1MD
ime:
iad
m&s-m
-16-

ick Diagram
10 |11 112
rm—
i
ml
CN402-2LJ•
1-- TP AMP
:401
p. ...trrgTii
m
ass
an
aa
ass
m
LO
as
i
MM
oao".
SsSSsB
b8b8^bbbb
F5sSlSi;iHt-;,ta'3IBIB
CT^MffcnzmETig
&S.&I
S^raSal

SlOl ft 04.7M- TIB I
[BD BOARD]
~7~ loading I
•MOTOR •
[MAIN BOARD]

OPTICAL PICK UP BLOCK
;coil
DMOTOR
3(is)
(li)i
£>(l3)
2.5Ti(it
j
[Ti>
£|L^(io\
—
-
YVC yJ
TE
L.I
2*
FE 3
iRFol FZC 4
YRFO 5
QND 6
vcc 7
ICON jj 8
~I±I 9'-
T+ 10
T- II ~Tl
FI Ft FI 71 F~,\
TRACKING
COIL
M52103FP
DETECTOR
RF AMP
*N0T REPIACE8LE :BUILT IN TRANSFORMER
KSS-240A
mst
-32VREG
IC201 L
-r'5
~-«3.4
~oL-T >
is
^0>^T-3,;'2.0 -,0V
[LOADING BOARD] SB
1LOADING MOTOR
DRIVE GND 22
1NSW °
3 3
u
LOAD °
4 4
J
LOAD °
c55o-
CN30I
t5P S27
1
1.3 ^-11 .0-
cnuj^moaoaw
con iu. uj <_> >
°^«V* PO'^
i£h sis 5 S
Rft Liar
C203 Z. [fci
3300 |+ *
16V D204
IIES2-TA1B
[BD BOARD] 0202, 203
REG
0204 'V/ 206
B+ SWITCH
1C203 r* 9*5
RCA558P g| 5
3-0*1 d+^7 J,
AIN BOARD]
