Sony MEGA BASS CFD-616 User manual

S
O
NY.
3-798-462-21(1)
®
CD Radio
Cassette-Corder
Operating Instructions
IGITAL AUDIO
CFD-616
CFD-626
©1995 by Sony Corporation

Warning
To prevent fire or shock hazard, do
not expose the player to rain or
moisture.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK).
NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
This symbol is intended to alert
the user to the presence of
uninsulated “dangerous voltage”
within the product's enclosure
that may be of sufficient
magnitude to constitute a risk of
electric shock to persons.
This symbol is intended to alert
the user to the presence of
important operating and
maintenance (servicing)
instructions in the literature
accompanying the appliance.
CAUTION
The use of optical instruments with this
product will increase eye hazard.
For customers in Canada
To prevent electric shock, match wide blade
of plug to wide slot, fully insert.
Information
For customers in the United States
This equipment has been tested and found to
comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide
reasonable protection against harmful
interference in a residential installation. This
equipment generates, uses and can radiate
Introduction
radio frequency energy and, if not installed
and used in accordance with the instructions,
may cause harmful interference to radio
communications. However, there is no
guarantee that interference will not occur ina
particular installation. If this equipment does
cause harmful interference to radio or
television reception, which can be determined
by turning the equipment off and on, the user
is encouraged to try to correct the
interference by one or more of the following
measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the
equipment and receiver.
—Connect the equipment into an outlet ona
circuit different from that to which the
receiver is connected.
—cConsult the dealer or an experienced
radio/TV technician for help.
You are cautioned that any changes or
modifications not expressly approved in this
manual could void your authority to operate
this equipment.
Owner's Record
The model and serial numbers are located at
the rear of the CD radio cassette-corder.
Record these numbers in the spaces provided
below. Refer to these numbers whenever you
call your Sony dealer regarding this product.
Model No.
Serial No.
About This Manual
The instructions in this manual are for the
CFD-616 and CFD-626. Before you start
reading, check your model number. The
CFD-626 is the model used for illustration
purposes.

SSS a a a a
Table of contents
10
Basic Operations
Playing a CD
Listening to the radio
Playing a tape
Recording on a tape
12
13
14
15
17
19
20
21
22
The CD Player
Playing multiple discs
Using the display
Locating a specific track
Playing tracks repeatedly
(Repeat Play)
Creating your own program
(Program Play)
The Radio
Presetting radio stations
Playing preset radio stations
The Tape Player
Recording through a
microphone/ Using as a PA
system
The Timer
Falling asleep to music
23
25
26
28
30
31
Setting Up
Hooking up the system
Selecting the audio emphasis
(Sound Mode/MEGA BASS)
Additional Information
Precautions
Troubleshooting
Maintenance
Specifications
Back cover
Index
Introduction
suoijesado diseg H
3

4
Playing a CD
2 1
quay |
For hookup instructions, see pages 23-24.
1 Press & OPEN/CLOSE (direct
OPEN/ power-on) and place the disc on
mLOSe the disc tray.
Note
You can't play 3 inch (8 cm) CDs even
with an adaptor for single-CDs.
With the label side up
2
Press
Pll.
Display
cD The disc tray closes and the
player plays all the tracks once.
Music calendar Playing time
Basic Operations

Tips
If “ALL DISCS” lights
up, the player plays
other CDs in numerical
sequence. To play only
one CD, press DISC
MODE to select “1
DISC.”
Next time you want to
listen to a CD, just press
Pll. The player turns on
automatically and starts
playing the CD.
Use these buttons for additional operations
POWER Pll i />>I AMS/SEARCH
To
Adjust the volume
Stop playback
Pause playback
VOLUME +/-
OPEN/CLOSE
Press
VOLUME +/-
|
Pil
Press again to resume play
after pause.
Go to the next track Pi AMS/SEARCH
Go back to the previous track é<d AMS/SEARCH
Remove the CD S40PEN/CLOSE
Turn on/off the player POWER
Basic Operations
suoinesado diseg
5

0 BBRBBR 00%
For hookup instructions, see pages 23 -24.
RADIO
Press BAND until the band you
want appears in the display
(direct power-on).
Display
Hold down TUNING+ until the
frequency digits begin to change
in the display.
The player automatically scans
the radio frequencies and stops
when it finds a clear station.
If you can't tune in a station,
press the button once at a time.
Indicates an FM
stereo broadcast.
Basic Operations

Tips
¢ If the FM broadcast is
noisy, press PLAY
MODE/MONO/ST
until “Mono” appears in
the display and the
radio will play in
monaural.
Next time you want to
listen to the radio, just
press the BAND button.
The player turns on
automatically and starts
playing the previous
station.
Use these buttons for additional operations
POWER VOLUME +/-
To Press
Adjust the volume VOLUME +/-
Turn on/off the radio POWER
To improve broadcast reception
Reorient the antenna for FM. Reorient the player itself
for AM.
Basic Operations
suonesadgo dIseg ;
7

8
© BBRBBB 00°
For hookup instructions, see pages 23 - 24.
1 STOP/EJECT
Press i to open the tape
compartment and insert a
recorded tape. Close the
compartment.
With the side you want
to play facing up.
Press >.
The player turns on (direct
power-on) and starts playing.
Basic Operations

Tips
¢ Next time you want to
listen to a tape, just
press B . The player
turns on automatically
and starts playing the
tape.
¢ For the best results, use
TYPE I (normal) tape.
Use these buttons for additional operations
POWER B4 u
VOLUME +/-
To Press
Adjust the volume VOLUME +/-
Stop playback Ey
Fast-forward or rewind the tape PP or dd *
Pause playback ul
Press the button again to
resume play after pause.
Eject the cassette LS
Turn on/off the player POWER
*After winding the tape with P® or 4, press EA to
release it.
Basic Operations
suoieiado diseg |
9

For hookup instructions, see pages 23 -24.
Press Ml# to open the tape
compartment and insert a blank
tape.
With the side you want to
record on facing up
Basic Operations
Select the program source you
want to record.
To record from the CD player, Display
insert a CD (see page 4) and press
@ on the CDsection.
To record from the radio, press
BAND and tune in the station
you want (see page 6.)
Press @ to start recording. (B> is
depressed automatically.)

Tips
¢ Adjusting the volume or
the audio emphasis (see
page 25) will not affect
the recording level.
¢ For the best results, use
the AC power source as
a power sourse and use
TYPE I (normal) tape.
¢ If the AM program
makes a whistling
sound after you've
pressed @ in step 3, set
the ISS (Interference
Suppress Switch) at the
rear to the position that
most decreases the
noise. Normally set the
switch to “2.”
To record from discs at
the average recording
level, press A. AGC
berore starting
recording . Do not press
A. AGC during
recording.
* To erase a recording,
proceed as follows:
1 Disconnect the
microphone if
connected at the MIX
MIC jack.
2 Turn on the power
and then press
FUNCTION until
“TAPE” appears in
the display window..
3 Press@.
Use these buttons for additional operations
POWER #4
To
Stop recording
Pause recording
Turn on/off the player
© BBBBRB co%
Press
ry
iT
Press the button again to
resume recording.
POWER
Basic Operations
suoneisdo Jiseg |
11

The CD Player
Playing multiple
discs
You can play up to 6 CDs one after
another.
DISC 1 to 6
DISC MODE
1 Press one of the DISC 1 to 6 buttons to select the
disc tray.
The indicator of the selected disc tray blinks
quickly (CFD-626 only).
2 Press 4 OPEN/CLOSE on the player and place a
CD on the disc tray.
3 Press 4 OPEN/CLOSE on the player to close the
disc tray.
The number of the
disc tray where the
CD is inserted appears
in the display. To
insert more discs,
repeat steps 1 to 3.
Tip 4 Press DISC MODE to
To play only one CD, “ ”
press DISC MODE to select “ALL DISCS.
select “1 DISC.”
5 Press one of the DISC 1 to 6 buttons to select the
disc you want to start playing.
Play starts from the selected CD and the indicator
of the selected disc tray blinks slowly (CFD-626
only).
12 | The CD Player

Using the display
DISPLAY
You can check information about the
disc using the display.
tae
—
>=
0
QO
7]
a}
g
< l
o
=
Checking the total track numbers and playing
time
Press DISPLAY in stop mode.
If the disc has more than 16 tracks, “OVER 16”
appears in the display.
Music calendar
Disc number
Total track numbers
Total playing time
Checking the remaining time
Press DISPLAY while playing a disc.
The track numbers in the music calendar disappear
after they are played.
* Fora track whose To display Press DISPLAY
number is more than 16
the remaining time Remaining time on the Once
appears as “—-:--—”. current track*
™ If the remaining tracks Remaining time on the disc Twice
are over 99, “~~ and the number of tracks left**
appears instead of the
track number. If the Playing time and the current _— Three times
remaining time is over track number
99 minutes, “- —— —”
appears instead of the
remaining time.
The CD Player | 13

Locating a specific
track
You can quickly locate any track using
the number buttons. You can also find a
specific point in a track while playing a
disc.
Note
You cannot start play if
“PGM” or “SHUF REP”
is lit in the display.
Turn off the indication
by pressing Ml.
Tip
When you locate a
track numbered over
10, press > 10 first, then
the corresponding
number buttons.
Example:
To play track number
23, press >10 first, then
2 and 3.
The CD Player
cece =
DISC 1to 6
To locate
a specific track directly
a point while listening to
the sound
a point while observing
the display
Press
one of the DISC 1 to 6
buttons to select the disc
and a number button of the
track.
bP (forward) or <4
(backward) while playing
and hold down until you
find the point.
bP (forward) or 44
(backward) in pause and
hold down until you find
the point.
When you use the buttons
on the player, use Kd / >i
AMS/SEARCH.
Locating a specific disc by scanning the first
track of each disc
1 Press @.
“CD” appears in the display.
2 Press DISC MODE to select “ALL DISCS.”
3 Press DISC SCAN on the player.
The player starts scanning the first track of each
disc for 10 seconds. Scanning always starts from
the disc in DISC 1 no matter what disc number is
selected.

Playing tracks
CONTINUE
repeatedly
SHUFFLE
Number
(Repeat
Play)
buttons
Sam
You can play tracks repeatedly in =|
normal,
shuffle
or
program
play
modes
=
(see
pages
15
-
16.).
DISC
1
to
6
0
a]
e
®
x
=i DISC MODE
== PLAY MODE
ees, en
>
Playing discs repeatedly using ONE-TOUCH CD
RELAY buttons
Press either CONTINUE or SHUFFLE.
To play all CDs repeatedly Press
in numerical sequence CONTINUE. “ALL DISCS
REP ALL” appears in the
display.
in random order SHUFFLE. “ALL DISCS
SHUF REP ALL” appears in
the display.
continued
The CD Player | 15

Playing tracks repeatedly (Repeat Play) (continued)
Playing tracks repeatedly
1 Press PLAY MODE/MONO/ST until the repeat
mode you want appears in the display.
To repeat Select
a single track REP 1
all the tracks REP ALL
tracks in random order SHUF REP ALL
programmed tracks PGM REP and then program
tracks (see steps 3-5 on page
17).
2 Doeither of the following to start repeat play:
* When you've selected REP1, select the disc by
pressing one of the DISC 1 to 6 buttons, then
select the track by pressing the number button.
¢ When you've selected REP ALL, press DISC
MODE to select “ALL DISCS” (to repeat all
discs) or “1 DISC” (to repeat only 1 disc). If you
select “1 DISC,” then press one of the DISC 1 to 6
buttons to select the disc you want.
¢ When you've selected SHUF REP ALL, press
DISC MODE to select “ALL DISCS” (to repeat
tracks in all discs in different order) or “1 DISC”
(to repeat only one disc in different order). Then,
press > .
e When you've selected PGM REP ALL, press >.
16 | The CD Player

Creating your
own prog ram Number
buttons
(Program Play)
=
You can make a program of up to 20 3
tracks from all the CDs in the order you ©
want them to be played. DISC 1to 6 8
a
9
<
©
=
CLEAR
DISC MODE
>P /PGM
CHECK
PLAY MODE/
MONO/ST
| ad
Tes 1 Press PLAY MODE/MONO/ST until “PGM”
* You can select the track
on the player. Press
Ke / PPI AMS/ 2 Press DISC MODE to select “ALL DISCS”.
SEARCH, then press
ENTER/MEM Lae 3 Press one of the DISC 1 to 6 buttons to select the
appears in the display.
of the number buttons.
You can program one
whole CD as one
program step.
Repeat step 3 and select
another disc tray by
pressing one of the
DISC 1 to 6 buttons.
disc tray.
Programmed track
; arr |
DISC number
Track number
Playing order
Press the number
buttons for the tracks
you want to program
in the order you want.
You can program up
to 20 tracks.
Programmed tracks
appear in the music
calendar.
St
¥
rar) aa== Bee,
If you made a mistake, press CLEAR and re-enter
the track number.
To program additional tracks from another disc,
repeat steps 3 and 4.
5 Press B to start program play.
continued
The CD Player | 17

18
Creating your own program (Program Play) (continued)
Tips
¢ You can play the same
program again, since
the program is saved
until you open the disc
tray.
¢ You can record your
own program. After
you've created the
program, insert a blank
tape and press @ to
start recording.
The CD Player
To cancel Program Play
Press PLAY MODE/MONO/ST until no indication
appears in the display.
To check the order of tracks before play
Press B® /PGM CHECK on the remote or ENTER/
MEM on the player.
Every time you press the button, the track number
appears in the programmed order.
To change the current program
To Do this
Erase the last track in 1 Press CLEAR. Every time you
the program press the button, the last track
in the program is cleared.
2 Re-enter the track numbers.
Change the whole Press @ . Then create a new
program completely. program following the
programming procedure.

The Radio
Presetting radio
stations
You can store radio stations into the
player's memory. You can preset up to
24 radio stations, 12 for each FM or AM
in any order.
Tip
To preset radio staions
on the player, proceed
as follows:
1 Select the band and
tune ina station you
want.
Hold down ENTER/
MEM for about 2
seconds.
“PRESET” and a
preset number flash
in the music
calendar.
Decide on a preset
number for the
station (1 to 12) by
pressing PRESET
+/-.
Press ENTER/MEM.
Number
buttons
BAND
TUNING+/-
1 Press BAND until the band you want appears in
2
3
the display.
Tune in a station you want.
Hold down the number buttons that you want to
preset the new station for about 2 seconds.
To select the preset number over 10, press >10 first,
then the corresponding number buttons. You need
to hold down the last number button to enter for
about 2 seconds. (Example: To select 12, press >10
and 1, then hold down 2 for about 2 seconds.)
The new station replaces the old one.
The Radio
ompey ayL I
19

Playing preset
radio stations
Once you've preset the stations, use the
number buttons to tune in your favorite
stations.
Number
buttons
BAND
Tip : 1 Press BAND to select FM or AM.
You can tune ina
preset station with the 2 Press the number buttons to tune in a stored
player. Use PRESET station.
+/— instead of the . ; ;
number buttons. To tune in a preset station over 10, press >10 first,
then the corresponding number buttons.
(Example: To tune in a preset station 11, press >10,
and then press 1 and 1.)
20 | The Radio
