Equipment used in illustrations (not supplied)
from car antenna (aerial)
Rear speaker
Front speaker Power amplifier
Cautions
• This unit is designed for negative ground (earth) 12 V
DC operation only.
• Do not get the leads under a screw, or caught in
moving parts (e.g. seat railing).
• Before making connections, turn the car ignition off to
avoid short circuits.
• Connect the yellow and red power supply leads only
after all other leads have been connected.
• Run all ground (earth) leads to a common
ground (earth) point.
• Be sure to insulate any loose unconnected leads with
electrical tape for safety.
Notes on the power supply lead (yellow)
• When connecting this unit in combination with other
stereo components, the connected car circuit’s rating
must be higher than the sum of each component’s
fuse.
• When no car circuits are rated high enough, connect
the unit directly to the battery.
Parts list
• The numbers in the list are keyed to those in the
instructions.
• The bracket  and the protection collar  are
attached to the unit before shipping. Before mounting
the unit, use the release keys  to remove the bracket
 from the unit. For details, see “Removing the
protection collar and the bracket ()” on the reverse
side of the sheet.
• Keep the release keys  for future use as
they are also necessary if you remove the unit
from your car.
Caution
Handle the bracket  carefully to avoid injuring your
fingers.

Catch
Note
Before installing, make sure that the catches on both sides of
the bracket  are bent inwards 2 mm (3/32 in). If the catches are
straight or bent outwards, the unit will not be installed securely
and may spring out.
Connection example
Notes (-B)
• Be sure to connect the ground (earth) lead before connecting
the amplifier.
• The alarm will only sound if the built-in amplifier is used.
Connection diagram
 To a metal surface of the car
First connect the black ground (earth) lead, then connect
the yellow and red power supply leads.
 To the power antenna (aerial) control lead
or power supply lead of antenna (aerial)
booster
Notes
• It is not necessary to connect this lead if there is no
power antenna (aerial) or antenna (aerial) booster, or with
a manually-operated telescopic antenna (aerial).
• When your car has a built-in FM/AM antenna (aerial) in
the rear/side glass, see “Notes on the control and power
supply leads.”
 To AMP REMOTE IN of an optional power
amplifier
This connection is only for amplifiers. Connecting any other
system may damage the unit.
 To the interface cable of a car telephone
 To a car’s illumination signal
Be sure to connect the black ground (earth) lead to a metal
surface of the car first.
 To the +12 V power terminal which is
energized in the accessory position of the
ignition switch
Notes
• If there is no accessory position, connect to the +12 V
power (battery) terminal which is energized at all times.
Be sure to connect the black ground (earth) lead to a
metal surface of the car first.
• When your car has a built-in FM/AM antenna (aerial) in
the rear/side glass, see “Notes on the control and power
supply leads.”
 To the +12 V power terminal which is
energized at all times
Be sure to connect the black ground (earth) lead to a metal
surface of the car first.
 To the parking brake switch cord
Notes on the control and power supply leads
• The power antenna (aerial) control lead (blue) supplies +12 V
DC when you turn on the tuner.
• When your car has built-in FM/AM antenna (aerial) in the
rear/side glass, connect the power antenna (aerial) control
lead (blue) or the accessory power supply lead (red) to the
power terminal of the existing antenna (aerial) booster. For
details, consult your dealer.
• A power antenna (aerial) without a relay box cannot be used
with this unit.
Memory hold connection
When the yellow power supply lead is connected, power will
always be supplied to the memory circuit even when the ignition
switch is turned off.
Notes on speaker connection
• Before connecting the speakers, turn the unit off.
• Use speakers with an impedance of 4 to 8 ohms, and with
adequate power handling capacities to avoid its damage.
• Do not connect the speaker terminals to the car chassis, or
connect the terminals of the right speakers with those of the
left speaker.
• Do not connect the ground (earth) lead of this unit to the
negative (–) terminal of the speaker.
• Do not attempt to connect the speakers in parallel.
• Connect only passive speakers. Connecting active speakers
(with built-in amplifiers) to the speaker terminals may damage
the unit.
• To avoid a malfunction, do not use the built-in speaker leads
installed in your car if the unit shares a common negative (–)
lead for the right and left speakers.
• Do not connect the unit’s speaker leads to each other.
Notes on connection
• If speaker and amplifier are not connected correctly,
“FAILURE” appears in the display. In this case, make sure the
speaker and amplifier are connected correctly.
• If you are to use the monitor for the rear seats, connect the
parking brake switch cord to the ground (earth).
 

× 4
× 2


AMP REM
Max. supply current 0.3 A
Fuse (10 A)
Blue/white striped
Red
Yellow
White
Green
Purple
White/black striped
Gray/black striped
Green/black striped
Gray
Left
Right
Left
Right
ANT REM
Black
Blue
Max. supply current 0.1 A
Purple/black striped
*1
*5
Monitor (not supplied)
Light green
*1 RCA pin cord (not supplied)
*2 AUDIO OUT can be switched SUB or REAR. For details,
see the supplied Operating Instructions.
*3 Auxiliary device such as hideaway navigation device, TV
tuner box, etc.
*4 Separate adaptor may be required.
*5 For details on connecting to the parking brake switch
cord, see “Connecting the parking brake cord ()” on
the reverse side.
PARKING BRAKE
*3
4-157-175-11(1)
Multi Disc Player
MEX-DV1600U
MEX-DV1606U
©2009 Sony Corporation Printed in Thailand
Installation/Connections
Active subwoofer
*1
VIDEO OUT
Monitor
(not supplied)
VIDEO OUT
REAR / SUB
AUDIO OUT
FRONT
AUDIO OUT
Monitor
(not supplied)
*1
ATT
ILLUMINATION
Light blue
Orange/white striped

SONY MEX-DV1600U/DV1606U (GB) 4-157-175-11 (1)SONY MEX-DV1600U/DV1606U (GB) 4-157-175-11 (1)
1 2 3
A TOYOTA
to dashboard/center console
Bracket
Bracket
B NISSAN


to dashboard/center console
Bracket
Bracket


A
B
1 2
size
5 × max. 8 mm
(7/32 × max. 5/16 in)
How to detach and attach the
front panel
Before installing the unit, detach the front panel.
-A To detach
Before detaching the front panel, be sure to press and
hold . Press , and pull it off towards
you.
-B To attach
Engage part  of the front panel with part  of the unit,
as illustrated, and push the left side into position until it
clicks.
Warning if your car’s ignition
has no ACC position
Be sure to set the Auto Off function. For details, see the
supplied Operating Instructions.
The unit will shut off completely and automatically in
the set time after the unit is turned off, which prevents
battery drain.
If you do not set the Auto Off function, press and hold
 until the display disappears each time
you turn the ignition off.
RESET button
When the installation and connections are completed,
be sure to press the RESET button with a ball-point pen,
etc., after detaching the front panel.
Precautions
• Choose the installation location carefully so that the
unit will not interfere with normal driving operations.
• Avoid installing the unit in areas subject to dust, dirt,
excessive vibration, or high temperatures, such as in
direct sunlight or near heater ducts.
• Use only the supplied mounting hardware for a safe
and secure installation.
Mounting angle adjustment
Adjust the mounting angle to less than 45°.
Connecting the parking brake
cord
Be sure to connect the parking cord (Light green) of 
to the parking brake switch cord. The mounting position
of the parking brake switch cord depends on your car.
Consult your car dealer or your nearest Sony dealer for
further details.
Removing the protection collar
and the bracket
Before installing the unit, remove the protection
collar  and the bracket  from the unit.
1 Remove the protection collar .
Pinch both edges of the protection collar , then
pull it out.
2 Remove the bracket .
 Insert both release keys  together between
the unit and the bracket  until they click.
 Pull down the bracket , then pull up the unit
to separate.
Mounting example
Installation in the dashboard
Notes
• Bend these claws outward for a tight fit, if necessary (-2).
• Make sure that the 4 catches on the protection collar  are
properly engaged in the slots of the unit (-3).
Mounting the unit in a Japanese
car
You may not be able to install this unit in some makes of
Japanese cars. In such a case, consult your Sony dealer.
Note
To prevent malfunction, install only with the supplied screws .
(SOURCE/OFF)
Foot brake type
Parking brake switch cord
Hand brake type
Parking brake switch cord


 


Face the hook inwards.
182 mm
53 mm

Claws
Dashboard
Fire wall




Existing parts supplied with your car Existing parts supplied with your car
size
5 × max. 8 mm
(7/32 × max. 5/16 in)
size
5 × max. 8 mm
(7/32 × max. 5/16 in)
