Sony PDW-HD1550 User manual

PROFESSIONAL DISC RECORDER
PDW-HD1550
SERVICE MANUAL
1st Edition (Revised 2)

警告
このマニュアルは，サービス専用です。
お客様が，このマニュアルに記載された設置や保守，点検，修理などを行うと感電や火災，
人身事故につながることがあります。
危険をさけるため，サービストレーニングを受けた技術者のみご使用ください。
WARNING
This manual is intended for qualified service personnel only.
To reduce the risk of electric shock, fire or injury, do not perform any servicing other than that
contained in the operating instructions unless you are qualified to do so. Refer all servicing to
qualified service personnel.
WARNUNG
Die Anleitung ist nur für qualifiziertes Fachpersonal bestimmt.
Alle Wartungsarbeiten dürfen nur von qualifiziertem Fachpersonal ausgeführt werden. Um die
Gefahr eines elektrischen Schlages, Feuergefahr und Verletzungen zu vermeiden, sind bei
Wartungsarbeiten strikt die Angaben in der Anleitung zu befolgen. Andere als die angegeben
Wartungsarbeiten dürfen nur von Personen ausgeführt werden, die eine spezielle Befähigung
dazu besitzen.
AVERTISSEMENT
Ce manual est destiné uniquement aux personnes compétentes en charge de l’entretien. Afin
de réduire les risques de décharge électrique, d’incendie ou de blessure n’effectuer que les
réparations indiquées dans le mode d’emploi à moins d’être qualifié pour en effectuer d’autres.
Pour toute réparation faire appel à une personne compétente uniquement.
安全のために，周辺機器を接続する際は，過大電圧を持
つ可能性があるコネクターを以下のポートに接続しない
でください。
:LANコネクター
上記のポートについては本書の指示に従ってくだい。
For safety, do not connect the connector for peripheral
device wiring that might have excessive voltage to the
following port(s).
: LAN connector
Follow the instructions for the ports(s).
For kundene i Norge
Dette utstyret kan kobles til et IT-strømfordelingssystem.
PDW-HD1550

CAUTION
Danger of explosion if battery is incorrectly replaced.
Replace only with the same or equivalent type rec-
ommended by the manufacturer.
When you dispose of the battery, you must obey the
law in the relative area or country.
ATTENTION
Il y a danger d’explosion s’il y a remplacement incor-
rect de la batterie. Remplacer uniquement avec
une batterie du même type ou d’un type équivalent
recommandé par le constructeur.
Lorsque vous mettez la batterie au rebut, vous devez
respecter la législation en vigueur dans le pays ou la
région où vous vous trouvez.
VORSICHT
Explosionsgefahr bei Verwendung falscher Batterien.
Batterien nur durch den vom Hersteller empfohlenen
oder einen gleichwertigen Typ ersetzen.
Wenn Sie die Batterie entsorgen, müssen Sie die
Gesetze der jeweiligen Region und des jeweiligen
Landes befolgen.
注意
指定以外の電池に交換すると，破裂する危険があり
ます。
必ず指定の電池に交換してください。
使用済みの電池は，国または地域の法令に従って
処理してください。
FÖRSIKTIGHET!
Fara för explosion vid felaktigt placerat batteri.
Byt endast mot samma eller likvärdig typ av batteri,
enligt tillverkarens rekommendationer.
När du kasserar batteriet ska du följa rådande lagar
för regionen eller landet.
PAS PÅ
Fare for eksplosion, hvis batteriet ikke udskiftes
korrekt.
Udskift kun med et batteri af samme eller tilsvarende
type, som er anbefalet af fabrikanten.
Når du bortskaffer batteriet, skal du følge
lovgivningen i det pågældende område eller land.
HUOMIO
Räjähdysvaara, jos akku vaihdetaan virheellisesti.
Vaihda vain samanlaiseen tai vastaavantyyppiseen,
valmistajan suosittelemaan akkuun.
Noudata akun hävittämisessä oman maasi tai
alueesi lakeja.
FORSIKTIG
Eksplosjonsfare hvis feil type batteri settes i.
Bytt ut kun med samme type eller tilsvarende
anbefalt av produsenten.
Kasser batteriet i henhold til gjeldende avfallsregler.
⌞ᝅ
⌞ᝅ
ྸ󰵳ᴪᦘⲺ⭫⊖у↙⺤θቧՐᴿ⠼⛮Ⲻধ䲟Ⱦ
ᴪᦘж㊱ශᡌ࡬䙖୼᧞㦆Ⲻ⭫⊖ශȾ
༺⨼⭫⊖ᰬθᗻ亱䚫ᆾ⴮ީ൦ᡌളᇬⲺ⌋ᗁȾ
PDW-HD1550

When installing the installation space must be secured
in consideration of the ventilation and service operation.
. Do not block the ventilation slots at the left side and
right side panels, and vents of the fans.
. Leave a space around the unit for ventilation.
. Leave more than 25 cm of space in the rear of the unit
to secure the operation area.
When the unit is installed on the desk or the like, leave
at least 2 cm of space in the left and right sides.
Leaving 40 cm or more of space above the unit is
recommended for service operation.
設置時には，通気やサービス性を考慮して設置スペース
を確保してください。
. ファンの排気部や通気孔（左側面および右側面）をふ
 さがない。
. 通気のために，セット周辺に空間をあける。
. 作業エリアを確保するため，セット後方は，25cm 以
 上の空間をあける。
机上などの平面に設置する場合は，左側面および右側面
は 2cm 以上の空間をそれぞれ確保してください。ただ
し，セット上部はサービス性を考慮し 40cm 以上の空
間を確保することを推奨します。
Laser Diode Properties
Wavelength : 400 to 410 mm
Emission duration : Continuous
Laser output power : 280 mW
(max. of pulse peak), 150 mW
(max. of CW)
Standard :
CAUTION
Use of controls or adjustments or performance of
procedures other than those specified herein may
result in hazardous radiation exposure.
CAUTION
The use of optical instruments with this product will
increase eye hazard.
The PDW-HD1550 is classified as a CLASS 1
LASER PRODUCT.
This label is located on the top cover of the drive unit.
PDW-HD1550

Table of Contents
Manual Structure
Purpose of this manual....................................................................................................................7
Related manuals...........................................................................................................................7
Trademarks................................................................................................................................7
1. Service Overview
1-1. Power Supply..................................................................................................................1-1
1-1-1. Power Cord............................................................................................................. 1-1
1-2. Installation Space..............................................................................................................1-2
1-2-1. Outside Dimensions.................................................................................................... 1-2
1-2-2. Notes on Installation....................................................................................................1-2
1-2-3. To Mount the Unit in a Rack........................................................................................... 1-3
1-3. Location of Printed Circuit Boards and Circuit Function.....................................................................1-4
1-4. Function and Location of Sensors.............................................................................................1-6
1-5. Connectors and Cables........................................................................................................1-8
1-5-1. Signal Inputs and Outputs.............................................................................................. 1-8
1-5-2. Connection Connectors/Cables........................................................................................1-11
1-6. Functions of Onboard Parts..................................................................................................1-12
1-6-1. Description of Onboard LED Indicators.............................................................................. 1-12
1-6-2. Functions of Onboard Switches.......................................................................................1-14
1-7. Circuit Protection Parts...................................................................................................... 1-18
1-7-1. Circuit Protection Element............................................................................................1-18
1-8. Fixtures.......................................................................................................................1-19
1-9. Service Action after Replacing or Repairing the Block and Board..........................................................1-20
1-9-1. SY-438 Board......................................................................................................... 1-20
1-9-2. CPU Board/HPR-55 Board............................................................................................1-20
1-9-3. Optical Block Assembly.............................................................................................. 1-20
1-9-4. BD-42 Board.......................................................................................................... 1-20
1-9-5. SE-1004 Board........................................................................................................ 1-21
1-10. Replacing EEPROMs........................................................................................................1-22
1-10-1. Overview.............................................................................................................. 1-22
1-10-2. Replacing FRAM (IC310/SY-438 Board).............................................................................1-22
1-10-3. Replacing EEPROM (IC1100/HPR-55 Board)....................................................................... 1-22
1-10-4. Replacing EEPROM (IC806/AU-366 Board).........................................................................1-23
1-10-5. Replacing D/A Converter (IC502/VPR-118 Board).................................................................. 1-23
1-11. Backup Battery...............................................................................................................1-24
1-12. Updating the Firmware...................................................................................................... 1-25
1-12-1. Corresponding Firmware..............................................................................................1-25
1-13. Circuit Description...........................................................................................................1-28
1-13-1. Video Signal Processing System...................................................................................... 1-28
1-13-2. Audio Signal Processing System......................................................................................1-31
1-13-3. Synchronization Signal Processing System...........................................................................1-34
1-13-4. IO System Control System............................................................................................1-34
1-13-5. IT System Control System............................................................................................ 1-35
1-13-6. I/O Interface System.................................................................................................. 1-36
1-13-7. Control Panel (LCD/SW/JOG/SHUTTLE)........................................................................... 1-37
1-14. Flexible Card Wire...........................................................................................................1-38
1-14-1. Disconnecting/Connecting Flexible Card Wire.......................................................................1-38
PDW-HD1550 1

1-15. Cautions on Handling the Optical Block Assembly.........................................................................1-39
1-16. Lead-free Solder............................................................................................................. 1-41
2. Error Messages
2-1. Error Message Overview......................................................................................................2-1
2-2. Error Code List................................................................................................................2-2
2-2-1. Error 0X................................................................................................................ 2-2
2-2-2. Error 20.................................................................................................................2-4
2-2-3. Error 3X................................................................................................................ 2-4
2-2-4. Error 5X................................................................................................................ 2-5
2-2-5. Error 6X................................................................................................................ 2-5
2-2-6. Error 71.................................................................................................................2-6
2-2-7. Error 91.................................................................................................................2-6
2-2-8. Error 92.................................................................................................................2-6
2-2-9. Error 95.................................................................................................................2-7
2-3. Alarms (Warning)............................................................................................................. 2-9
2-3-1. At the Time of Startup..................................................................................................2-9
2-3-2. When a Disc is Inserted.................................................................................................2-9
2-3-3. After a Memory Card is Inserted......................................................................................2-11
2-3-4. After a Folder in the External Storage is Mounted....................................................................2-12
2-3-5. During Front Panel Operations........................................................................................2-12
2-3-6. During Recording Operations.........................................................................................2-14
2-3-7. During Playback Operations.......................................................................................... 2-15
2-3-8. During Operations in the Clip List Screen/Thumbnail Search/EDL Edit/Copy ......................................2-15
2-3-9. Alarms Relating to Audio and Video Signals.........................................................................2-17
2-3-10. Alarms Relating to Sensors........................................................................................... 2-17
2-3-11. Other Alarms..........................................................................................................2-18
3. XDCAM Web Site
3-1. XDCAM Web Site Overview................................................................................................. 3-1
3-1-1. Connecting to the XDCAM Website................................................................................... 3-1
3-2. Status Menu................................................................................................................... 3-2
3-2-1. Software Version........................................................................................................3-2
3-3. Maintenance Menu............................................................................................................3-4
3-3-1. Network.................................................................................................................3-4
3-3-2. SNMP...................................................................................................................3-5
3-3-3. Account.................................................................................................................3-9
3-3-4. Setup Menu.............................................................................................................3-9
3-3-5. Software Update.......................................................................................................3-10
3-3-6. Log.................................................................................................................... 3-15
3-3-7. Warning................................................................................................................3-16
4. Maintenance Mode
4-1. Maintenance Menu Overview.................................................................................................4-1
4-1-1. Operation Keys......................................................................................................... 4-1
4-1-2. Activating the Maintenance Mode......................................................................................4-2
4-1-3. Exiting Maintenance Mode.............................................................................................4-2
PDW-HD1550 2

4-1-4. Maintenance Mode Access Prohibiting Switch........................................................................ 4-2
4-2. Maintenance Menu List....................................................................................................... 4-4
4-3. ADJUST (M1).................................................................................................................4-7
4-3-1. VPR VR (A20)......................................................................................................... 4-7
4-3-2. CP VR (A23)........................................................................................................... 4-7
4-3-3. APR VR (A27)......................................................................................................... 4-8
4-3-4. BATTERY (A2E).......................................................................................................4-9
4-3-5. NV-RAM CONTROL (A2F)...........................................................................................4-9
4-4. SERVICE SUPPORT (M2).................................................................................................. 4-11
4-4-1. ERROR LOG (M20).................................................................................................. 4-11
4-4-2. DIAG CONTROL (M21)............................................................................................. 4-11
4-4-3. OPTION KEY (M23)................................................................................................. 4-11
4-5. OTHERS (M3)...............................................................................................................4-13
4-5-1. SOFTWARE VERSION (M30).......................................................................................4-13
4-5-2. SERIAL NUMBER (M31)............................................................................................4-13
4-5-3. FILE I/F CONFIG (M33)............................................................................................. 4-14
4-5-4. HOUR METER RESET (M36).......................................................................................4-14
4-5-5. HEAD ROOM (M370)................................................................................................4-15
4-5-6. DATA LEN (M371)................................................................................................... 4-15
4-5-7. NON-AUDIO INPUT (M372)........................................................................................4-15
4-5-8. IN LEVEL (M373)....................................................................................................4-16
4-5-9. ANALOG I/O (M374)................................................................................................ 4-17
4-5-10. OUT LEVEL (M377)................................................................................................. 4-17
4-5-11. VITC REC (M391)....................................................................................................4-17
4-5-12. FRMT MEDIA (M395)............................................................................................... 4-18
4-5-13. VERIFY USB (M399)................................................................................................ 4-18
4-5-14. COPY TO USB (M39B).............................................................................................. 4-19
4-5-15. VANC RX PACKET (M3B0).........................................................................................4-19
4-5-16. LINE1 SEL (M3B1)...................................................................................................4-21
4-5-17. LINE2 SEL (M3B2)...................................................................................................4-21
4-5-18. DATE/TIME PRESET (M3D)........................................................................................ 4-22
4-5-19. USB to ROM (M3E0).................................................................................................4-22
4-5-20. ROM to USB (M3E1).................................................................................................4-23
4-5-21. FORMAT USB (M3E2)...............................................................................................4-24
4-5-22. PACKAGE UPDATE (M3E3)........................................................................................ 4-24
4-5-23. LOG UPLOAD (M3E4)...............................................................................................4-25
4-5-24. FACTORY SETUP (M3F)............................................................................................ 4-25
4-6. SETUP MAINTENANCE (M4).............................................................................................4-27
4-6-1. EXTENDED MENU (M40).......................................................................................... 4-27
4-6-2. AUTO RECALL (M48)...............................................................................................4-27
4-6-3. RESET ALL SETUP (M49).......................................................................................... 4-28
4-7. NETWORK (M5)............................................................................................................4-29
4-7-1. DHCP (M50)..........................................................................................................4-29
4-7-2. IP ADDRESS (M51)..................................................................................................4-29
4-7-3. SUBNET MASK (M52).............................................................................................. 4-30
4-7-4. DEFAULT GATEWAY (M53)........................................................................................ 4-30
4-7-5. LINK SPEED (M54)..................................................................................................4-31
4-7-6. JUMBO FRAME (M56).............................................................................................. 4-31
4-7-7. NetBIOS (M5A).......................................................................................................4-32
4-7-8. RESET NET CONFIG (M5F)........................................................................................ 4-32
4-8. DRIVE MAINTENANCE (D0)............................................................................................. 4-33
4-8-1. TEMPERATURE SENSOR...........................................................................................4-33
4-8-2. FAN MOTOR......................................................................................................... 4-33
PDW-HD1550 3

4-8-3. ACCELERATION SENSOR..........................................................................................4-34
4-8-4. LOADER..............................................................................................................4-36
4-8-5. SLIDER AUTO TEST................................................................................................ 4-42
4-8-6. SLIDER IN-LIM TEST...............................................................................................4-43
4-8-7. SPINDLE MOTOR AUTO TEST.................................................................................... 4-44
4-8-8. SA ACTUATOR...................................................................................................... 4-45
4-8-9. LASER................................................................................................................ 4-46
4-8-10. LCD ATT..............................................................................................................4-48
4-8-11. SKEW.................................................................................................................4-49
4-8-12. LENS CLEANING....................................................................................................4-52
4-8-13. LENS CLEANING JIG............................................................................................... 4-52
4-8-14. LD IL ADJUST....................................................................................................... 4-53
4-8-15. TRK/TLT DRV OFFSET..............................................................................................4-53
4-8-16. SKEW.................................................................................................................4-53
4-8-17. ERROR LOGGER.................................................................................................... 4-54
4-8-18. VERSION.............................................................................................................4-55
4-8-19. SERIAL NO...........................................................................................................4-56
4-8-20. UPLOAD TO EEPROM.............................................................................................. 4-56
4-8-21. UPLOAD TO FLASH.................................................................................................4-57
5. Periodic Maintenance and Inspection
5-1. Periodic Maintenance......................................................................................................... 5-1
5-1-1. Digital Hours Meter.................................................................................................... 5-1
5-1-2. Periodic Replacement Parts.............................................................................................5-2
5-2. Cleaning.......................................................................................................................5-4
5-2-1. General Information for Cleaning Using Cleaning Cloth.............................................................. 5-4
5-2-2. Cleaning the Loader Assembly.........................................................................................5-4
5-2-3. Cleaning the Spindle Motor............................................................................................ 5-5
5-2-4. Cleaning the Pickup Lens...............................................................................................5-5
5-2-5. Cleaning the Lens in the Optical Block Assembly.....................................................................5-5
6. Replacement of Main Parts
6-1. General Information for Parts Replacement.................................................................................. 6-1
6-1-1. Basic Knowledge.......................................................................................................6-1
6-1-2. Tightening Torque ......................................................................................................6-2
6-2. Control Panel Section......................................................................................................... 6-3
6-2-1. Control Panel........................................................................................................... 6-3
6-2-2. Bottom Case Assembly.................................................................................................6-4
6-2-3. Speaker................................................................................................................. 6-5
6-2-4. LCD/FP-209 Board.....................................................................................................6-6
6-3. Top Plate Assembly........................................................................................................... 6-8
6-4. Bottom Plate Assembly....................................................................................................... 6-9
6-5. MEM-138 Board.............................................................................................................6-10
6-6. Lithium Battery.............................................................................................................. 6-11
6-7. Optical Drive Section........................................................................................................6-12
6-7-1. Optical Drive Assembly...............................................................................................6-12
6-7-2. DC Fan (50) (Optical Drive Assembly)...............................................................................6-13
6-7-3. IF-1240 Board.........................................................................................................6-16
6-7-4. Optical Drive (XDD-P210)........................................................................................... 6-17
PDW-HD1550 4

6-7-5. Loader Assembly......................................................................................................6-18
6-7-6. Loading Motor Assembly.............................................................................................6-22
6-7-7. Optical Block Assembly.............................................................................................. 6-24
6-7-8. BU Assembly/Seek Motor............................................................................................ 6-27
6-7-9. Spindle Motor......................................................................................................... 6-29
6-7-10. BD-42 Board, SY-400 Board..........................................................................................6-31
6-7-11. KY-666 Board.........................................................................................................6-36
6-7-12. Front Frame Assembly................................................................................................6-37
6-7-13. LDR-35 Board.........................................................................................................6-38
6-7-14. LDR-36 Board.........................................................................................................6-39
6-7-15. SE-1004 Board........................................................................................................ 6-40
6-7-16. SE-1005 Board........................................................................................................ 6-41
6-8. Rear Panel....................................................................................................................6-43
6-9. Power Section................................................................................................................6-44
6-9-1. Power Assembly.......................................................................................................6-44
6-9-2. DC Fan (30 Square) (Power Assembly)...............................................................................6-45
6-10. AU Section...................................................................................................................6-48
6-10-1. AU-366 Board.........................................................................................................6-48
6-10-2. DC Fan (40 Square) (AU Board Assembly).......................................................................... 6-50
6-11. ADI-11 Board/VPR-118 Board..............................................................................................6-51
6-12. SY-438 Board................................................................................................................ 6-53
6-13. HPR Section................................................................................................................. 6-54
6-13-1. HPR Board Assembly.................................................................................................6-54
6-13-2. Memory Module.......................................................................................................6-56
6-13-3. DIO-100 Board........................................................................................................6-57
6-13-4. Fine-Wire Coaxial Cable..............................................................................................6-58
6-13-5. ENC-158 Board/HPR-55 Board.......................................................................................6-59
6-13-6. DC Fan (40) (HPR-55 Board Assembly)............................................................................. 6-63
7. Adjustment of Optical Drive System
7-1. General Information for Adjustment of Optical Drive System............................................................... 7-1
7-1-1. Precautions..............................................................................................................7-1
7-1-2. Tools.................................................................................................................... 7-1
7-1-3. Preparation for Adjustment.............................................................................................7-1
7-2. LD IL Adjustment.............................................................................................................7-2
7-3. TRK/TLT DRV OFFSET Adjustment........................................................................................ 7-4
7-4. SKEW Adjustment............................................................................................................7-6
7-5. Actions to be Taken after Adjustment....................................................................................... 7-10
8. Electrical Adjustment
8-1. Electrical Adjustment Overview ..............................................................................................8-1
8-1-1. Precautions .............................................................................................................8-1
8-1-2. Tools/Fixtures...........................................................................................................8-1
8-1-3. Displaying the Adjustment Item........................................................................................8-1
8-2. HD Free-Running Frequency Adjustment.................................................................................... 8-2
8-2-1. Adjustment Procedure..................................................................................................8-2
8-3. SD Free-Running Frequency Adjustment.....................................................................................8-5
8-3-1. Adjustment Procedure..................................................................................................8-5
8-4. Video System Adjustment/VPR-118 Board ..................................................................................8-7
PDW-HD1550 5

8-4-1. Adjustment Overview.................................................................................................. 8-7
8-4-2. Adjustment Procedure..................................................................................................8-7
8-5. Audio System Adjustment...................................................................................................8-12
8-5-1. Adjustment Overview.................................................................................................8-12
8-5-2. Adjustment Procedure.................................................................................................8-12
8-6. DC IN +12 V Adjustment ...................................................................................................8-16
8-6-1. Adjustment Procedure.................................................................................................8-16
9. Spare Parts
9-1. Note on Repair Parts.......................................................................................................... 9-1
9-2. Exploded Views............................................................................................................... 9-2
Cover.................................................................................................................................9-2
Front..................................................................................................................................9-3
Optical Drive Assembly............................................................................................................. 9-4
Control Panel-1...................................................................................................................... 9-5
Control Panel-2...................................................................................................................... 9-6
Power Block......................................................................................................................... 9-7
AU/VPR Block.......................................................................................................................9-8
SY Board/CN-3594 Board...........................................................................................................9-9
Chassis..............................................................................................................................9-10
ENC/CPU Board....................................................................................................................9-11
HPR/DIO/MEM Board.............................................................................................................9-12
Overall (XDD-P210)............................................................................................................... 9-13
Frame Assembly-1 (XDD-P210)...................................................................................................9-14
Frame Assembly-2 (XDD-P210) .................................................................................................. 9-15
Loader Assembly (XDD-P210).....................................................................................................9-16
BU Assembly (XDD-P210)........................................................................................................ 9-17
9-3. Supplied Accessories........................................................................................................ 9-18
10. Diagrams
Block Diagrams....................................................................................................................... 10-1
Frame Wiring..........................................................................................................................10-4
PDW-HD1550 6

Manual Structure
Purpose of this manual
This manual is the service manual for Professional Disc Recorder PDW-HD1550.
This manual describes the information items that premise the service based on the block-level such as service overview,
error messages, periodic maintenance and inspection, replacement of main parts, etc. assuming use of system and service
engineers.
Related manuals
The following manual is provided for this unit in addition to this “Service Manual”.
• Operation Manual (Supplied with this unit)
This manual contains information required to operate and maintain the unit.
• Factory Service Manual
This manual describes parts list, circuit diagram, and mount diagram of the unit to provide information required
for part-level service.
Trademarks
Trademarks and registered trademarks used in this manual are follows.
• Ethernet is a registered trademark of Xerox Corporation.
• Internet Explorer is a trademark or registered trademark of Microsoft Corporation in the United States and Other
countries.
• Professional Disc is a registered trademarks of Sony Corporation.
Other system names and product names written in this manual are usually registered trademarks or trademarks of
respective development manufacturers.
PDW-HD1550 7

Section 1
Service Overview
1-1. Power Supply
The unit works with three types of power supply: AC, DC, and a battery. When repairing or checking the unit, using
AC power is recommended.
• Power voltage:
- AC 100 V, 50/60 Hz
- DC 12 V
• Power consumption:
- AC: 100 W
- DC: 7.5 A
1-1-1. Power Cord
To get a power cord, please contact your local Sony Sales Office/Service Center.
WARNING
• Use the approved Power Cord (3-core mains lead)/Appliance Connector/Plug with earthing-contacts
that conforms to the safety regulations of each country if applicable.
• Use the Power Cord (3-core mains lead)/Appliance Connector/Plug conforming to the proper ratings
(Voltage, Ampere).
• Never use an damaged power cord.
PDW-HD1550 1-1

1-2. Installation Space
1-2-1. Outside Dimensions
Unit : mm
210
132 9.512.5
420
1-2-2. Notes on Installation
CAUTION
To avoid an injury, do not install the unit on an unstable table.
Ventilation, and Work Space for Servicing
• Do not block the air exhaust sections (rear panel) and the air vent (bottom of front side and both the right and left
sides).
• Do not install the unit with the feet (on the four corners of the bottom plate) removed.
• In order to make a unit with good ventilation, ensure sufficient clearance around the unit.
• Be sure to provide 2 cm or more space to both the right and left sides and the top of the unit, and 25 cm or more
space behind the unit.
• Do not stack any equipment on this unit.
Tip
When the unit is installed on flat surface like a desk, provide 2 cm or more space to both right and left sides of the unit.
Providing 40 cm or more space above the unit is recommended considering service operations.
PDW-HD1550 1-2

1-2-3. To Mount the Unit in a Rack
Notes on Rack Mounting
• Heat generation by neighboring units could lead to a failure of the unit. Check that the temperature inside the rack
is within the range of specified operating temperature of the unit.
• Do not cover the exhaust port or ventilation holes (lower front, right and left sides).
• When installing units side by side, leave 1 cm or more of space between the sides of the units. Blocking the air
intake will damage the unit.
• Leave 25 cm or more of space to the rear of the unit.
• Use a commercially available rack mount shelf.
Select an appropriate shelf taking size and weight of the unit into consideration.
• Never remove the top panel, bottom panel, handle, or legs of the unit when installing.
• Use adequately long cables for connection of the connector panel, considering that the unit is pulled out from the
rack.
Note
After rack mounting, check that the temperature inside the rack is within the range of 5 ℃ through 35 ℃.
PDW-HD1550 1-3

1-3. Location of Printed Circuit Boards and Circuit Function
FP-209
SW-1642
SW-1655
HPR-55
MEM-138
HP-169
ENC-158
IF-1240
CN-3594
PS-885
RE-327
AU-366
ADI-11
VPR-118
SY-438
DIO-100
System Board name Circuit function
Digital process and Video process HPR-55 Audio/Video/Core process/Host/IT CPU/IT process
VPR-118 REF/Composite/SDI I/O
ENC-158 Video Codec
ADI-11 AES/EBU I/O
Audio process AU-366 Analog, audio I/O, A/D, D/A
HP-169 Headphone jack
DRIVE I/F IF-1240 SATA IF
Control panel FP-209 Control panel
SW-1655 ON/STNDBY switch
SW-1642 EJECT switch
Network and I/O SY-438 Network, TC, USB, REMOTE, I/O CPU
Power supply PS-885 AC/DC, DC IN AC/DC select, Primary power source
RE-327 DC-DC out, Secondary power source
Other DIO-100 Extensible host controller interface, USB3.0 controller
MEM-138 mSATA SSD
CN-3594 Connection board
PDW-HD1550 1-4

Optical drive assembly
SE-1004
LDR-35
KY-666
BD-42 SE-1005
LDR-36
SY-400
System Board name Circuit function
Drive unit/Sensor BD-42 Drive main
KY-666 Front panel
LDR-35 Cartridge sensor
LDR-36 Loading position sensor
SE-1004 Angular velocity sensor Cartridge sensor
SE-1005 OP position sensor Cartridge sensor
SY-400 CN-BD connection
PDW-HD1550 1-5

1-4. Function and Location of Sensors
IC2606
HPR-55 Board/Side A
Ref. No. Function
IC2606 Sensor for temperature on the board
Optical drive assembly
(1)
(4)
(6)
(3)
(5)
(2)
Location No. Part name Function
(1) OP position sensor Detects position of the optical block assembly.
(2) REC INH sensor Detects status of the recording prohibition tab of the car-
tridge.
(3) Cartridge Down sensor Detects down position of the cartridge.
(4) Cartridge IN sensor Detects insertion of the cartridge.
(5) Cartridge type sensor Detects type of the inserted cartridge (single-layer disc to
quad-layer disc).
Continued
PDW-HD1550 1-6

Location No. Part name Function
(6) Angular speed sensor Detects angular speed applied to the optical block assem-
bly.
PDW-HD1550 1-7

1-5. Connectors and Cables
1-5-1. Signal Inputs and Outputs
1 7 1020
4 12 15 6
8 18 16 19 17 3 11
14
2
9
13
5
Input connectors
1. SD/HDSDI INPUT
BNC type
SD: Component digital (270 Mbits/s) SMPTE 259M
HD: Component digital (1.485 Gbits/s) SMPTE 292M
2. REF.VIDEO INPUT
BNC type (In loop through connection)
External reference video signal
SD: 0.3 V p-p, 75 Ω, negative sync ( Black burst or
composite sync)
HD: 0.6 V p-p, 75 Ω, positive and negative sync (3-level
sync)
3. TIME CODE IN
BNC type
Time code 0.5 to 18.0 Vp-p, High Impedance, unbalanced
4. ANALOG AUDIO INPUT 1, 2
1
2
3
- External View -
(0 dBu = 0.775 V rms)
XLR 3-pin, Female
No. Signal I/O Specifications
1 AUDIO IN (G) — +4 dBu, 0 dBu, -3 dBu,
-6 dBu selectable, high
impedance, balanced
2 AUDIO IN (X) IN
3 AUDIO IN (Y) IN
5. DIGITAL AUDIO INPUT (AES/EBU)
BNC ×2 (1set: CH1/2, CH3/4)
Digital audio AES/EBU format, AES-3id-1995 compliant
6. DC IN 12V
1
23
4
- External View -
XLR 4-pin, Male
No. Signal I/O Specifications
1 GND — GND
2 NC — No connection
3 NC — No connection
4 EXT DC IN DC +11 to 17 V
Output connectors
7. HDSDI OUTPUT 1, 2 (SUPER)
BNC type
2 (SUPER): Character superimpose enabled
Component digital (1.485 Gbits/s) SMPTE 292M
8. SDSDI OUTPUT 1, 2 (SUPER)
BNC type
2 (SUPER): Character superimpose enabled
Component digital (270 Mbits/s SMPTE 259M/ITU-R BT.
656)
PDW-HD1550 1-8
