– 3 – PCV-J120 (US)
Confidential
TABLE OF CONTENTS
1. OPERATION
2. DISASSEMBLY
2-1. Flow Chart .................................................................... 2-1
2-2. Main Electric Parts Arrangement ................................ 2-1
2-3. L Side Plate Ass’y ........................................................ 2-2
2-4. Front Panel Ass’y ......................................................... 2-2
2-5. Slot Cover..................................................................... 2-3
2-6. Ethernet Card ............................................................... 2-3
2-7. IFX-90 (A) Ass’y ......................................................... 2-4
2-8. Modem/PC Card .......................................................... 2-4
2-9. HDD ............................................................................. 2-5
2-10. Switching Power .......................................................... 2-5
2-11. CD-RW ......................................................................... 2-6
2-12. FDD .............................................................................. 2-6
2-13. Memory (DIMM) ......................................................... 2-7
2-14. CPU .............................................................................. 2-7
2-15. Mother Board ............................................................... 2-8
3. MOTHER BOARD DESCRIPTION
3-1. MEW-AV Mother Board .............................................. 3-1
4. PROGRAMS FOR SERVICE
4-1. General Description ..................................................... 4-1
4-2. PC-Doctor Starting Method ......................................... 4-1
4-3. Intel Video Diag Starting Method................................ 4-1
5. SERVICE INFORMATION
5-1. Jumper Setting on Hard Disk Drive ............................ 5-1
5-2. Jumper Setting of Main Board..................................... 5-2
6. FRAME HARNESS
6-1. Connector List.............................................................. 6-1
6-2. Frame Harness Diagram .............................................. 6-5
7. REPAIR PARTS LIST
7-1. Exploded View and Parts List ...................................... 7-1
7-2. Accessories and Parts List ........................................... 7-4
