TABLE OF CONTENTS
1. OPERATION
2. DISASSEMBLY
2-1. Flow Chart........................................................................ 2-1
2-2. Memory Card ................................................................... 2-2
2-3. Top Cover ......................................................................... 2-2
2-4. HDD, Drive Holder.......................................................... 2-3
2-5. FDD, CD-ROM................................................................ 2-3
2-6. Modem Card..................................................................... 2-4
2-7. Riser Support, Riser Card ................................................ 2-4
2-8. Memory (DIMM) ............................................................. 2-5
Memory (DIMM) Installation.......................................... 2-5
2-9. CPU and Heat Sink .......................................................... 2-6
Heat Sink Installation....................................................... 2-6
2-10. SWX-26, LEX-14 Board ................................................. 2-7
2-11. Power Supply ................................................................... 2-7
2-12. Drive Support ................................................................... 2-8
2-13. Main Board....................................................................... 2-8
2-14. LCD Ass’y........................................................................ 2-9
2-15. Front Cover Ass’y .......................................................... 2-10
2-16. LCD Panel ...................................................................... 2-10
2-17. Inverter Unit ................................................................... 2-11
2-18. Main Electric Pats Arrangement .................................... 2-12
Main Section .................................................................. 2-12
Display Section .............................................................. 2-12
3. MOTHERBOARD DESCRIPTION...................... 3-1
4. SERVICE INFORMATION
4-1. Jumper Setting on Hard Disk Drive ................................ 4-1
4-2. Jumper Setting of Main Board......................................... 4-2
5. BLOCK DIAGRAM................................................... 5-1
6. FRAME HARNESS
6-1. Connector List .................................................................. 6-1
6-2. Frame Harness Diagram .................................................. 6-7
7. REPAIR PARTS LIST
7-1. Exploded views and Parts List (Main Section) ............... 7-1
7-2. Exploded views and Parts List (Display Section) ........... 7-3
7-3. Accessories and Parts List ............................................... 7-5
7-4. BarCord Label .................................................................. 7-6
