Sony VAIO VPCYB Series User manual

N
User Guide
Personal Computer
VPCYB Series

2
nN
Contents
Before Use.......................................................................... 4
Finding More about Your VAIO Computer .................... 6
Ergonomic Considerations .......................................... 11
Getting Started.................................................................. 13
Locating Controls and Ports........................................ 14
About the Indicator Lights ........................................... 16
Connecting a Power Source ....................................... 17
Using the Battery Pack................................................ 19
Shutting Down Your Computer Safely ........................ 25
Using the Power Saving Modes .................................. 26
Keeping Your Computer in Optimum Condition .......... 29
Using Your VAIO Computer.............................................. 32
Using the Keyboard..................................................... 33
Using the Touch Pad................................................... 35
Using the Special-function Button ............................... 36
Using the Built-in Camera ........................................... 37
Using "Memory Stick".................................................. 38
Using Other Modules / Memory Cards........................ 44
Using the Internet........................................................ 48
Using the Network (LAN) ............................................ 49
Using the Wireless LAN .............................................. 50
Using the BLUETOOTH Function ............................... 54
Using Peripheral Devices ..................................................59
Connecting an Optical Disc Drive ................................60
Connecting External Speakers or Headphones ..........62
Connecting an External Display ..................................63
Selecting Display Modes .............................................68
Connecting an External Microphone ...........................69
Connecting a USB Device ...........................................70
Customizing Your VAIO Computer....................................72
Setting the Password...................................................73
Using AMD-V ...............................................................79
Using the VAIO Control Center ...................................80
Upgrading Your VAIO Computer.......................................81
Adding and Removing Memory ...................................82

3
nN
Precautions....................................................................... 88
Safety Information ....................................................... 89
Care and Maintenance Information............................. 92
Handling Your Computer............................................. 93
Handling the LCD Screen ........................................... 95
Using the Power Source ............................................. 96
Handling the Built-in Camera ...................................... 97
Handling Discs ............................................................ 98
Using the Battery Pack................................................ 99
Handling "Memory Stick"........................................... 100
Handling the Built-in Storage Device ........................ 101
Troubleshooting .............................................................. 102
Computer Operations................................................ 104
System Update / Security.......................................... 110
Recovery / Recovery Media ...................................... 111
Partition ..................................................................... 113
Battery Pack.............................................................. 114
Built-in Camera ......................................................... 116
Networking (LAN/Wireless LAN) ............................... 118
BLUETOOTH Technology......................................... 121
Optical Discs ............................................................. 124
Display ...................................................................... 125
Printing ...................................................................... 129
Microphone ............................................................... 130
Speakers ...................................................................131
Touch Pad .................................................................133
Keyboard ...................................................................134
Floppy Disks ..............................................................135
Audio/Video ...............................................................136
"Memory Stick" ..........................................................138
Peripherals ................................................................139
Trademarks .....................................................................140
Notice ..............................................................................143

4
nN
Before Use >
Before Use
Congratulations on your purchase of this Sony VAIO®computer and welcome to the on-screen User Guide. Sony has
combined leading-edge technology in audio, video, computing, and communications to provide you with a state-of-the-art
computing experience.
!
External views illustrated in this manual may look slightly different from those of your computer.
How to find specifications
Some features, options, and supplied items may not be available on your computer.
To find out about the configuration of your computer, visit the Sony online support web site at the following URLs:
❑For customers in USA
http://esupport.sony.com/EN/VAIO/
❑For customers in Canada
http://www.sony.ca/support/ (English)
http://www.fr.sony.ca/support (French)
❑For customers in Spanish-speaking Latin American countries or areas
http://esupport.sony.com/ES/VAIO/LA
❑For customers in Brazil
http://esupport.sony.com/PT/VAIO/BR/

5
nN
Before Use >
About Models with Windows 7 Starter
On models with the Windows 7 Starter operating system, you cannot use some of the features available on models with other
editions of the Windows 7 operating system. Among those described in this User Guide, for example, you cannot use the
following:
❑Ad-hoc connections of the wireless LAN function
❑Multiple Monitors function
❑Long Battery Life Wallpaper Setting of the VAIO Control Center

6
nN
Before Use >
Finding More about Your VAIO Computer
Finding More about Your VAIO Computer
This section provides support information about your VAIO computer.
1. Printed Documentation
❑Quick Start Guide — An overview of components connection, set-up information, etc.
❑Recovery, Backup and Troubleshooting Guide
❑Safety Information — Safety guidelines and owner information.
✍
Before activating the wireless functions such as the wireless LAN and BLUETOOTH technology, read the Safety Information carefully.

7
nN
Before Use >
Finding More about Your VAIO Computer
2. On-screen Documentation
❑VAIO User Guide — General information of your VAIO computer including support and troubleshooting information.
To access VAIO User Guide, click Start , All Programs, and VAIO Manual.
❑Help and Support — General information and technical assistance for your VAIO computer.
To access Help and Support:
1Click Start and Help and Support.
2Choose from the following categories to find the answers you need.
Get started with my VAIO Get help with Internet and wireless setup, security setup, personalizing your VAIO computer, creating
Recovery Media, and more.
Use my VAIO Get assistance with your VAIO computer by accessing useful information such as interactive VAIO tutorials,
how-to articles, the VAIO technology page, specifications, and system and software information. The
available information varies depending on the model you purchased.
You can find useful documentation such as general and model specific user guide on your VAIO computer.
Troubleshoot my VAIO Maintain and troubleshoot your VAIO computer with the VAIO Care, system restore, backup and recovery,
and contact Sony support.

8
nN
Before Use >
Finding More about Your VAIO Computer
❑Program help files — May be included with the preinstalled software programs on your computer. You may be able to
access the help files from the help menu on a specific program.
❑SmartWi™Connection Utility Help — Information about setting up BLUETOOTH®, wireless LAN, GPS, and wireless
WAN functions.
Some features and options may not be available on your computer.
See the specifications to find out about the configuration of your computer.
To access this on-screen guide:
1Click Start, All Programs, and SmartWi Connection Utility.
2Click SmartWi Connection Utility Help.

9
nN
Before Use >
Finding More about Your VAIO Computer
3. Support Web Sites
❑Sony online support web site
The Sony online support web site provides instant access to information on commonly encountered problems. Type a
description of the problem and the Knowledge Database searches for the corresponding solutions online.
❑For customers in USA
http://esupport.sony.com/EN/VAIO/
❑For customers in Canada
http://www.sony.ca/support/ (English)
http://www.fr.sony.ca/support (French)
❑For customers in Spanish-speaking Latin American countries or areas
http://esupport.sony.com/ES/VAIO/LA
❑For customers in Brazil
http://esupport.sony.com/PT/VAIO/BR/
❑Operating system online support web site
Your computer comes preinstalled with a Microsoft Windows operating system. For operating system support, you can
visit Microsoft customer support at http://support.microsoft.com/directory/.

10
nN
Before Use >
Finding More about Your VAIO Computer
4. Customer Information Center
If you do not find the information you are looking for at our site, you may call Sony directly. You can find the contact numbers
on the Sony online support web site. In order to receive the fastest and most efficient services, have the following information
readily available:
1Your VAIO computer model
You can find it at the lower right corner of the display on the computer.
2Your computer's serial number
You can find it on the bottom, the back panel, or inside the battery compartment of your Sony VAIO computer. The serial
number is the last 7 digits of the number below the barcode.
3The operating system on your computer
4The hardware component or the software program that is causing the problem
5A brief description of the problem
5. In Store Service & Support (available in USA only)
Make an appointment with a Sony certified technician at a U.S. Sony Style store and get personalized service and support
for your VAIO computer. Sony Style Backstage Technicians can assist with the setup of your new VAIO computer, system
optimization, data rescue, and any repair service you might need.
Visit the web site at www.sonystyle.com/backstage to find the nearest location.

11
nN
Before Use >
Ergonomic Considerations
Ergonomic Considerations
You will be using your computer as a portable device in a variety of environments. Whenever possible, you should attempt
to take account of the following ergonomic considerations for both stationary and portable environments:
❑Position of your computer – Place the computer directly in front of you. Keep your forearms horizontal, with your wrists
in a neutral, comfortable position while using the keyboard or the pointing device. Let your upper arms hang naturally at
your sides. Take frequent breaks while using your computer. Excessive use of the computer may strain eyes, muscles, or
tendons.
❑Furniture and posture – Sit in a chair with good back support. Adjust the level of the chair so your feet are flat on the
floor. A footrest may make you more comfortable. Sit in a relaxed, upright posture and avoid slouching forward or leaning
far backwards.

12
nN
Before Use >
Ergonomic Considerations
❑Viewing angle of the computer display – Use the display tilting feature to find the best position. You can reduce eye
strain and muscle fatigue by adjusting the tilt of the display to the proper position. Adjust the brightness level of the display
as well.
❑Lighting – Choose a location where windows and lights do not cause glare and reflection on the display. Use indirect
lighting to avoid bright spots on the display. Proper lighting adds to your comfort and work efficiency.
❑Positioning an external display – When using an external display, set the display at a comfortable viewing distance.
Make sure the display screen is at or slightly below eye level when you are sitting in front of the monitor.

13
nN
Getting Started >
Getting Started
This section describes how to get started using your VAIO computer.
!
Before starting your computer for the first time, do not connect any other hardware that did not originally come with your computer. Upon completion,
connect one device (for example, a printer, an external hard disk drive, a scanner, and so on) at a time, following the manufacturer's instructions.
❑Locating Controls and Ports (page 14)
❑About the Indicator Lights (page 16)
❑Connecting a Power Source (page 17)
❑Using the Battery Pack (page 19)
❑Shutting Down Your Computer Safely (page 25)
❑Using the Power Saving Modes (page 26)
❑Keeping Your Computer in Optimum Condition (page 29)

14
nN
Getting Started >
Locating Controls and Ports
Locating Controls and Ports
Take a moment and see the following reference lists to identify the controls and ports on your computer.
!
The appearance of your computer may be different from those illustrated in this manual due to variations in specifications.
Control and Port Mark List
Control/port mark Control/port name
MOTION EYE Built-in camera (page 37)
WIRELESS WIRELESS switch (page 50), (page 54)
"Memory Stick Duo" slot (page 38)
Your computer supports only Duo-size "Memory Stick".
SD SD memory card slot (page 44)
1Power button
ASSIST ASSIST button (page 36)
USB port (page 70)
Compliant with the USB 2.0 standard.
LAN port (page 49)
aMonitor port (page 63)
HDMI HDMI output port (page 66)
mMicrophone jack (page 69)
iHeadphones jack (page 62)

15
nN
Getting Started >
Locating Controls and Ports
Location List of Controls and Ports without Marks
Control/port name Location
Built-in microphone (monaural) Located on the left side of the built-in camera.
Media Access indicator (page 16) Located on the right side of the "Memory Stick Duo" slot.
Security slot Located between the USB port and the LAN port.
DC IN port
Located on the left side of the monitor port.
Memory module compartment cover (page 82) Located on the bottom of the computer.

16
nN
Getting Started >
About the Indicator Lights
About the Indicator Lights
Your computer is equipped with the following indicator lights:
Indicator Functions
Power 1Illuminates in green while the computer is in Normal mode, blinks slowly in orange while the computer is in Sleep
mode, and turns off when the computer is turned off or enters Hibernate mode.
Charge Illuminates while the battery pack is charging. See Charging the Battery Pack (page 22) for more information.
Built-in MOTION EYE camera Illuminates while the built-in camera is in use.
Media Access Illuminates while data access to a memory card, such as "Memory Stick" and an SD memory card, is in
progress. (Do not place the computer into Sleep mode or turn it off while this indicator light is lit.) When the
indicator light is unlit, the memory card is not in use.
Disc drive Illuminates while data access to the built-in storage device is in progress. Do not place the computer into Sleep
mode or turn it off while this indicator light is lit.
Num lock Press the Num Lk key to activate the numeric keypad. Press it a second time to deactivate the numeric keypad.
The numeric keypad is not active when the indicator light is unlit.
Caps lock Press the Caps Lock key to type letters in uppercase. Letters appear in lowercase if you press the Shift key
while the indicator light is lit. Press the key a second time to turn off the indicator light. Normal typing resumes
when the Caps lock indicator light is turned off.
Scroll lock Press the Fn+Scr Lk keys to change how you scroll the display. Normal scrolling resumes when the Scroll lock
indicator light is turned off. The Scr Lk key functions differently depending on the program you are using and
does not work with all programs.
WIRELESS Illuminates while one or more wireless options are enabled.

17
nN
Getting Started >
Connecting a Power Source
Connecting a Power Source
You can use either an AC adapter or a rechargeable battery pack for supplying power to your computer.
Using the AC Adapter
While your computer is directly connected to an AC power source and has a battery pack installed, it uses power from the
AC outlet.
✍
Use only the supplied AC adapter for your computer.
To use the AC adapter
1Plug one end of the power cord (1) into the AC adapter (3).
2Plug the other end of the power cord into an AC outlet (2).
3Plug the cable from the AC adapter (3) into the DC IN port (4) on the computer.
!
The shape of the DC In plug varies depending on the AC adapter.

18
nN
Getting Started >
Connecting a Power Source
✍
To disconnect your computer completely from an AC power source, unplug the AC adapter from the AC outlet.
Make sure that an AC outlet is easily accessible.
If you do not intend to use your computer for an extended period of time, place the computer into Hibernate mode. See Using Hibernate Mode (page
28).

19
nN
Getting Started >
Using the Battery Pack
Using the Battery Pack
The battery pack supplied with your computer is not fully charged at the time of delivery.
Installing/Removing the Battery Pack
To install the battery pack
1Turn off the computer and close the LCD screen lid.
2Slide the battery LOCK switch to the unlock position.
3Slide the battery pack diagonally into the battery compartment until the projection (1) on either side of the battery
compartment fits into the cut (2) on either side of the battery pack.

20
nN
Getting Started >
Using the Battery Pack
4Push the battery pack down into the compartment until it clicks into place.
5Slide the battery LOCK switch to the LOCK position to secure the battery pack on the computer.
