DSC-TX7/L
Cyber -shot® Digital Still Camera
The sleek and stylish DSC -TX7 offers a large 3.5 ” touch screen to easily take and review photos. An advanced “ Exmor R ” CMOS sensor
provides stunning low-light images and sweeping panoramic views with iSweep Panorama mode. Plus, enjoy 1920x1080 Full HD
video recording and playback .
1
9
10
10.2 Megapixel Back-illuminated
“ Exmor R ” CMOS Image Sensor
The DSC-TX7 features a 10.2 megapixel
“Exmor R”CMOS image sensor that
brings out the full resolving power of the
camera’s Carl Zeiss® Vario- Tessar ® lens
to deliver extremely fast speed, high
resolution, and stunning low-light
sensitivity with improved image clarity
and drastically reduced grain. In
addition, the combined “Exmor R”
CMOS sensor and BIONZ™image
processor delivers extremely fast 10fps,
Anti Motion Blur, Hand-held Twilight
and 1080i movie modes .
9
Carl Zeiss ® Vario- Tessar ® Lens with
25mm equialent wide 4x Optical Zoom
The high -performance Carl Zeiss®
Vario- Tessar ® 4x optical zoom lens
brings distant subjects closer for video
recording as well as for outdoor, sports,
and travel photos, and Close Focus
shoots close- ups up to just under ½”
from the subject. A wide angle of
25mm equivalent wide-angle lens
allows you to take wider shots of the
scene or group in crowded spaces.
3.5 ” Xtra Fine LCD ™ touch screen
display w/TruBlack™technology
A large 3.5” Xtra Fine LCD ™ touch
screen display w/TruBlack™
technology (921K pixels), the largest of
Sony’s Cyber-shot DSC line makes it
easy for viewing and sharing images
with simple and fun touch screen
operation. With its Ultra AR film coating,
which reduces reflections and increases
contrast and brightness, viewing
images on the LCD even in bright light
is possible.
1
1
Easy Touch Screen Interaction
The DSC-TX7 offers intuitive functions to
the multi- purpose touch screen, such as
the ability to select the focus point with
a simple touch, scroll through images
by sliding your finger across the screen
and one- touch access to the MENU. The
display also features improved
readability with list view and index
view.
Anti -Motion Blur Mode
Capture cleaner and sharper images in
low light for non landscape shots. When
set in Anti -motion Blur Mode, the DSC-
TX7 captures six images in a fraction of
a second with higher shutter speed and
combines the data from all six to create
a single image of extraordinary detail
and eliminate subject blur, beyond the
capability of traditional cameras.
Handheld Twilight
Capture cleaner and sharper night shots
without using a tripod. When set to
Handheld Twilight Mode, the DSC- TX7
captures six images in a fraction of a
second with one press of the shutter,
and combines the data from all six to
create a single image of extraordinary
detail and low noise. With these modes,
you can capture images in low light,
without flash, beyond the capability of
traditional cameras.
Intelligent Sweep Panorama Mode
Capture expansive landscapes with
Intelligent Sweep Panorama Mode.
Press shutter and sweep and the camera
does the rest, continuously, shooting
images and in one second stitching
them together. This model even detects
faces and moving subjects to stitch
intelligently different widths to help
avoid subject distortion.
Backlight Correction HDR
Shooting high- contrast scenes can often
lead to washed out backgrounds
and/or details lost in shadow.
Backlight Correction HDR helps correct
for this by taking two pictures at
different exposure settings and
processing the best elements of both
into a single image for more natural
looking shots.
High speed shooting
The DSC- TX7 can capture full 10.2
megapixel resolution images at up to
10 frames per second, helping to ensure
that you capture the decisive moment
such as the soccer ball flying into the
goal. In addition, the DSC-TX7 employs
a mechanical shutter that helps reduce
distortion when continuously shooting
moving subjects.
1080i AVCHD Movie Mode
Record movies in 1080i AVCHD high
definition at 60i . The AVCHD format
captures a high degree of detail and
smooth movement, and when footage
is burned to disc, can be played back
on Blu-ray Disc™players, Sony®
PlayStation®3 systems and compatible
PCs and HDTVs The convenience
Movie start/stop icon makes it easy to
access this mode via touch screen.
9
9
7.
ADDITIONAL FEATURES
HDMI Output
DVDirect® DVD recorder Compatible
720p HD MP4 Movie Mode
9
Compatible with PC and Mac Systems
Self-Portrait Timer
TransferJet ™technology
Stylish Ultra-slim Design
BIONZ™Image Processor
Intelligent Scene Recognition (iSCN)
Mode
Anti-blink Function
Optical SteadyShot™image
stabilization
High Sensitivity Mode (ISO 3200)
Face Detection technology
Motion Detection
Smile Shutter™technology
Scene modes
Intelligent AF
Easy Shooting Mode
Function Guide
Lithium-ion battery
PHOTOMUSIC
Viewing modes
In-Camera Retouching Tools
Creative painting tools
Wide zoom display
PhotoTV HD
Media card slot
Includes Sony® PMB (Picture Motion
Browser) Software ver. 5.0
7
Includes Sony® PMBP (Picture Motion
Browser Portable) software
Colors Available

Sony Electronics Inc. • 16530 Via Esprillo • San Diego, CA 92127 • 1.800.222.7669 • www.sony.com
Last Updated: 02/01/2010
DSC-TX7/L
Cyber -shot® Digital Still Camera
Please visit the Dealer Network for more
information at www.sony.com/dn
Specifications
General
Megapixel: Approx. 10.2 Megapixels
Imaging Device: 1/2.4" (7.59mm) 'Exmor R'
CMOS Sensor
Recording Media: 45MB internal Flash Memory,
optional Memory Stick Duo™Media, optional
Memory Stick PRO Duo™Media, optional
Memory Stick PRO Duo™ ( High Speed),
optional Memory Stick PRO HG-Duo™,
optional SD media
Convenience
White Balance: Auto / Daylight / Cloudy /
Fluorescent 1(White Fluorescent Lighting) /
Fluorescent 2 (Natural White Fluorescent
Lighting) / Fluorescent 3 (Day White Fluorescent
Lighting) / Incandescent / Flash / One Push.
Self Timer: Yes (Off / 10sec. / 2sec./ portrait1 /
portrait2)
Still Image Mode(s): Normal / Hi- Speed Burst
(High/Mid/Low)
Red - Eye Reduction: Auto / On / Off
Burst Mode: Approx 10 fps at 10.2MP (Maximum
10 shots)
Erase/Protect: Yes / Yes
Date/Time Stamp: Available in the included PMB
software.
Media/Battery Indicator: Yes/Yes
Dynamic Range Optimizer: Standard
Scene Mode(s): High Sensitivity / Twilight /
Twilight Portrait / Soft Snap / Landscape /
Beach / Snow / Fireworks / Hi- Speed Shutter /
Underwater / Gourmet / Pet
Image Stabilization: Optical
Movie Mode(s): AVCHD: 1920 x 1080 (59.94i,
Interlace) (Approx.17Mbps) / 1440 x 1080
(59.94i, Interlace) (Approx.9Mbps) MP4: 1440 x
1080 (29.97fps, Progressive) (Approx.12Mbps) /
1280 x 720 (29.97fps, Progressive)
(Approx.6Mbps) / VGA (640 x 480) (29.97fps,
Progressive) (Approx.3Mbps)
PictBridge Compatible: Yes
TransferJet: Single / Select
Convenience Features
Histogram Display: No
AF Illuminator Light: Auto / Off
Multi - Pattern Measuring: Yes
NightShot® Infrared System: No
NightFraming System: No
Clear RAW NR: Yes
Power Save Mode: Standard / Stamina /Off
In -Camera Editing: Trimming / Red Eye
Correction / Unsharp Masking
Inputs and Outputs
Accessory Terminal: Multi connector
Audio/Video Output(s): Yes
USB Port(s): Yes -USB2.0 Hi-Speed
HD Output: HDMI / Component (1080i)
Hardware
LCD: 3.5" Xtra Fine TruBlack (921K pixels)
Viewfinder: No
Lens Construction: 12 elements in 10 groups
(including 6 aspheric elements,1 prism)
Microphone/Speaker: Stereo / Mono
Lens Type: Carl Zeiss® Vario- Tessar ®
13
1
Optics/Lens
Focal Length: 4.43-17.7mm
35mm Equivalent: Still shots: 25-100mm / Movie
16:9: 28-112mm / Movie 4:3 : 34-136mm
Focus: 9 points AF / Center Weighted AF / Spot
AF/ Flexible Spot AF (touch)
Aperture Range: iAuto(F3.5-F6.3(W)) / Program
Auto(F3.5 - F6.3(W))
Shutter Speed: iAuto(2" -1/1,600) / Program Auto
(1" -1/1,600)
Exposure Compensation: Plus / Minus 2.0 EV, 1/3
EV step
Smart Zoom® Technology: 5M : Approx.5.6x
(Total),
VGA : Approx.22x(Total),
16:9 (2M) : Approx.7.6x(Total)
Digital Zoom: Smart Zoom / Precision Digital
Zoom / Off
Optical Zoom: 4x
Macro Mode: iAuto(W:Approx.1cm(0.39'') to
Infinity, T:Approx.50cm(1.64') to Infinity)
Total Zoom: Approximately 8x with Precision
Digital Zoom
Face Detection: 8 Faces (Auto / Touch / Child
Priority / Adult Priority)
Power
Battery Type: LITHIUM ION N type 3.6V
Battery Capacity: Approx. 115 minutes / Approx.
230 images (when shooting still images)
Power Consumption (in Operation): Approx. 1.0W
Software
Supplied Software: Picture Motion Browser Ver 5.0,
PMB Portable 5.0 (for Windows), PMB Portable
1.1 (for Macintosh), Music Transfer
Operating System Compatibility: Microsoft®
Windows XP SP3, Windows Vista SP2, Windows
7, Macintosh ® OS X(v10.4-v10.6)
Processor
Bionz™ Engine: Yes
Operating Conditions
Flash Effective Range: ISO Auto: Approx.0.08-
Approx.3.8m(Approx.0.26'-Approx.12.47')(W)
/ Approx.0.5-Approx.3.1m(Approx.1.64'-
Approx.10.17')(T),
ISO3200: up to Approx.8.0m(Approx26.25')
(W) / Approx.6.3m(Approx20.67')(T)
Flash Mode(s): Auto / On / Slow Syncro / Off
Dimensions
Weight: Body: Approx. 4.7oz. (133g), With battery
and Memory Stick media:; Approx. 5.3oz.
(149g)
Measurements: W x H x D: 3 7/8" x 2 3/8" x
23/32" (97.8mm x 59.5mm x 17.5mm)
Service and Warranty Information
Limited Warranty Term: Limited 1 Year Parts &
Labor
Supplied Accessories
Rechargeable Battery (NP- BN)
Battery Charger
AV Cable
USB Cable
wrist Strap
Paint Pen
CD- ROM
Multi Output Stand
Optional Accessories
Accessory Kit (ACC-CLGB)
GPS Unit Kit (GPS-CS3KA)
Party Shot
Memory Stick PRO Duo™Media (MSX-512S)
Memory Stick PRO Duo™Media (MSX-1GST)
Memory Stick PRO Duo™Media (MS- MT2G)
Memory Stick PRO Duo™Media (MS- MT4G)
Memory Stick PRO Duo™Media (MS- MT8G)
Memory Stick PRO Duo™Media (MS- MT16G)
Memory Stick PRO Duo™Media (MS- MT32G)
Memory Stick PRO-HG Duo™"HX" Media (MS-
HX16G)
Memory Stick PRO-HG Duo™"HX" Media (MS-
HX8G)
Memory Stick PRO-HG Duo™"HX" Media (MS-
HX4G)
Memory Stick Duo™USB Adaptor (MSAC-US40)
Memory Stick PRO-HG Duo™"HX" Media (MS-
HX16G)
Memory Stick PRO-HG Duo™"HX" Media (MS-
HX32G)
Color: Blue
UPC Code: 027242779143
1.Viewable area, measured diagonally
2.PMBrequiresMicrosoft® Windows ®XPSP3/WindowsVista®
SP2/Windows7.PictureMotionBrowsersoftwarenot supported by
MacOS.MovieformatiscompatiblewithiMovie® ' 09orlater
versions.
3.PMBPortableforWindowsispre - loaded.PMB Portable for Mac is
availableatwww.eSupport.sony.com . PMB Portable requires USB
cable(included) and PC with internet connectivity. 64 - bit
environmentsnotsupported
4.Uploadingdirectlytothewebrequires PMB Portable software and USB
cable(included),andPCwithinternetconnectivity(not included).
PMBPortable for Mac is available at www.eSupport.sony.com. 64 - bit
environmentsnot supported.
5.Requirescompatiblewirelessaccesspoint(s).Somefeaturesmayrely
onInternetservices.
6.Whenfullycharged.Actualresultsmayvarybasedonproduct
settings, usage patterns and environmental conditions.
7.CompatibleBRAVIA® HDTV, and HDMI ™ orcomponent cable (sold
separately)requiredforPhotoTVHDviewing. Specifications for BRAVIA
HDTVshown vary according to market region.
8.Four preset music tracksstoredininternal memory. Imported music
trackscanbe up to five minutes long. When using Music Transfer to
downloadmusic,trackslongerthan five minutes will be reduced to
fiveminutes when uploading to the Cyber - shot ® camera.
9.Movie recording is limited to(29minsegmentsforMP4 up to 12Mbps
1440x1080/30p)(and) (10 minutesegmentsforAVCHD up to
16mbps1920x1080/60i.)
10.HD Viewing requires an HDoutput adapter cable(VMC - MHC1)and
compatible HDTV, both sold separately.
11.TransferJetenabledtechnology (sold separately) required in both
devices.Interoperability and compatibility among TransferJet ™
enabled devices vary.
12.Thiscamera captures high definition footage in the AVCHD format.
HighDefinitionAVCHD discs can be created using standard DVD
media,the supplied software and a compatible PC. DVD media
containing AVCHD footage may be played on a compatible Blu - ray
Disc™player/recorder,PCwithsuppliedsoftwareorPlayStation®3
devices.DVDmedia containing AVCHD footage should not be used
withstandardDVDbasedplayers,asthe DVD player may fail to eject
themedia and may erase its contents withoutwarning.
13.Whenusing movie mode MemoryStickPRODuo with MARK2 logo,
MemoryStickPRO - HG,Class4 or higher for SD/SDHC media are
recommended.
©2010Sony Electronics Inc. Allrightsreserved.Reproduction in whole or
inpartwithoutwrittenpermissionisprohibited.Sony,Cyber - shot,Optical
SteadyShot,BIONZ, Xtra FineLCD,SmileShutter, TruBlack, TransferJet,
ExmorR, Smile Shutter, DVDirect,BRAVIA,MemoryStick PRO Duo,
MemoryStick Duo and the MemorySticklogoare trademarks of Sony.
PlayStationis a trademarkofSonyComputer Entertainment. Microsoft,
Windows,andWindowsVistaaretrademarksofMicrosoftCorporation.
Blu - rayDiscisatrademark.HDMIisatrademarkofHDMILicensingLLC.
iMovie,Mac,andtheWorkswithiMovielogoandtheMaclogoare
trademarksof Apple Computer,Inc.Allother trademarks are
trademarksoftheirrespectiveowners.
