Sony Cyber-shot DSC-S600 User manual

FEATURES
1/2.7" 4.1 Megapixel Super HAD™ CCD
Super HAD (Hole Accumulation
Diode) CCDs provide excellent
image quality by allowing more
light to pass to each pixel, increasing
sensitivity and reducing noise.
3X Digital Zoom
Sony’s Precision Digital Zoom
provides an additional 3X
magnification without the
jagged edges of other designs, resulting in
smoother images.
0 –3.6X Smart Zoom™Feature
(at VGA Resolution)
The Smart Zoom feature
intelligently uses the full CCD to
let you zoom into the portion of
interest by cropping the image size –thus
avoiding the image degradation of Digital Zooms.
Real Imaging Processor
The innovative Real Imaging
Processor in the DSC-P41 not
only improves picture quality and
clarity but also improves camera response
time, decreases shutter lag and improves
battery stamina.
Optical Viewfinder
Provides accurate framing at eye level, great
for added stability and following fast moving
subjects.
1.5" LCD Monitor
The 1.5" 67K LCD Monitor makes framing
shots and reviewing pictures easy.
Auto Bright Monitoring
To help framing in low-or no-light situations,
CCD gain is briefly increased to provide an
extra bright display on the LCD viewfinder just
before exposure.
14-Bit DXP A/D Conversion
Sony’s 14-bit Digital EXtended
Processor captures the range
between highlight and shadow
with up to 16,384 values, for extended
dynamic contrast and detail.
5 Area Multi-Point Auto Focus
By evaluating 5 separate focus
areas of the frame, Sony’s
Multi-Point AF system can
intelligently focus on the subject and avoid
mistakenly focusing on the background.
AF (Auto Focus) Illuminator
An amber light briefly illuminates
the subject, in low –or no –light
conditions, helping to establish a
positive focus lock.
Selectable Focus Mode
Monitoring AF (Auto Focus) helps you
anticipate the action by focusing even
before you press the shutter release.
Multi-Pattern Measuring
Independently light-metering 49
points of the frame, Multi-Pattern
Measuring establishes the
optimum exposure, even when highlight and
shadow isn’t centered in the frame.
Auto Daylight Synchro Fill Flash
If the Multi-Pattern Measuring system
determines the subject is backlit or in shadow,
fill flash automatically fires to provide optimum
exposure.
Pre-Flash Metering
With a momentary pre-flash, the camera
illuminates the subject and sets exposure
through the lens for accurate flash metering.
Adjustable flash level and red-eye reduction
ensure great flash shots.
Slow Shutter Noise Reduction
During long exposures, Slow
Shutter NR captures the scene,
and then the CCD noise pattern
with a dark frame exposure. By subtracting the
two, even long exposures can be clear.
Memory Stick®Media and Memory Stick
PRO™Media
Digital. Powerful. Transportable.™
Memory Stick
®
media is compact,
portable and rugged –connecting a
variety of hardware and software applications.
4 Shot Burst Mode
Capture up to 4 shots (fine) or 7
shots (standard) at 1.7 frame/sec.
even at 4 MP resolution. Perfect
for high speed subjects or fast moving action
such as sports.
Multi-Burst Mode
Captures 16 320 x 240 frames
as part of a single 1280 x 960
image which plays back
sequentially in the camera. Selectable 1/7.5,
1/15, 1/30 second.
MPEG Movie VX Standard/Fine Mode
with Audio
Captures VGA (640 x 480) high
frame rate (up to 30 frames per
second) audio/video clips with
length limited only by the capacity of the
media. Video mail mode captures smaller file
sizes suitable for email.
Playback Zoom
During playback, magnify the
image up to 5 times with 17-step
playback zoom for a closer look.
Scroll to any part of the image with the
cursor keys.
PictBridge™Compatibility
Connect to any PictBridge™
compatible printer with the supplied
USB cable and print directly from the
camera. Images can be viewed and selected
for printing right on the camera’s LCD, with
menus for print quantity, date and index print.
®
DSC-P41
Cyber-shot®Digital Still Camera

OPTIONAL ACCESSORIES
ADDITIONAL FEATURES
SPECIFICATIONS
Imaging Device: 1/2.7" 4.1 Megapixel Super HAD™CCD
Recording Media: Memory Stick®Media, Memory Stick PRO™Media
Lens Construction: 4 Elements in 5 Groups, 1 Aspheric Element
Zoom: Fixed Focal Length
Smart Zoom™Feature: 0 –3.6X (at VGA Resolution)
Digital Zoom: Precision, 0 –3.0X Range
Filter Diameter: N/A
Focal Length: 5mm
Auto Focus : 5 Area Multi-Point AF
Minimum Focus Distance: 3.9" (10cm)
Macro Mode: Auto
Shutter Speed: 1/8 –1/1000 sec. (auto), 2 –1/1000 sec (twilight)
Aperture Range: f2.8 –f5.6
Exposure Compensation: +/- 2.0 EV, 1/3 EV Steps
Color LCD: 1.5" 67K Pixel LCD Screen
Flash Modes: Auto/Forced On/Forced Off/Slow Synchro
Red-Eye Reduction: On/Off
Flash Effective Range: 1.6 –12.5 ft. (0.5 –3.8m)
White Balance: Auto, Daylight, Cloudy, Fluorescent, Incandescent
Burst Mode: 4 Shot (JPEG fine), 7 Shot (JPEG std.), 1.7fps
Picture Effects: Sepia, Black & White
ISO: Auto, 100, 200, 400
Scene Modes: Twilight, Twilight Portrait, Landscape, Soft Snap, Candle, Beach
Self-Timer: Yes, 10 Seconds
Audio/Video Output: N/A
Still Image Modes: Normal (JPEG Fine/Standard), Burst, Multi-Burst
MPEG Movie Modes: MPEG VX Fine with Audio (640 x 480 at 30fps),
(MPEG VX Fine requires Memory Stick PRO™media)
MPEG VX Standard with Audio (640 x 480 at 16fps),
Video Mail (160 x112 at 8fps) with Audio
Microphone/Speaker: Yes/Yes
USB Terminal: Yes, Supports USB 2.0
Memory Stick PRO™Media Compatibility: Tested to support up to 1GB media
capacity; does not support Access Control security function
Compatible Battery: “AA”NiMH, Alkaline
Supplied Software: Picture Package™for Sony v1.0 (Windows), Pixela™
ImageMixer VCD2 (Macintosh), SPVD-012.1 USB Driver,
Cyber-shot Life tutorial (Windows)
OS Compatibility: Microsoft®Windows®98/98SE/Me/ 2000/XP Home/XP Pro
Macintosh®OS 9.1/9.2/X (10.0, 10.1, 10.2, 10.3)
Supplied Accessories: “AA”Alkaline Batteries x 2, Wrist Strap, USB Cable,
MSA-16A 16MB Memory Stick®Media, Software CD-ROM
Dimensions: 4" x 2 1⁄8" x 1 3⁄8" (101 x 54 x 36mm)
Weight: 4.9 oz (134g) Body; 7.1 oz. (195g) Body w/Batteries, Media, Wrist Strap
©2004 Sony Electronics Inc.
Reproduction in whole or in part without written permission is prohibited. All rights reserved.
Sony, Cyber-shot, Digital, Powerful, Transportable, Memory Stick, the Memory Stick logo, Memory Stick PRO,
Smart Zoom and Super HAD, are trademarks of Sony. Microsoft and Windows are registered trademarks of
Microsoft Corporation. Macintosh is a trademark of Apple Computer. PictBridge is a trademark of CIPA. All
other trademarks are property of their respective owners. Features and specifications subject to change with-
out notice. Non-metric weights and measures are approximate.
1Available storage capacity of Memory Stick and Memory Stick PRO media may vary. A portion of the
memory is used for data management functions. Actual available memory in MBs is:16=15, 32=30, 64=61,
128=123, 256=220, 512=460, 1GB=940MB
ACC-CN3P/ACC-CN3M Starter Kit
NH-AA-2DA Rechargeable NiMH Batteries (2pk)
HVL-FSL1B External Slave Flash w/ Bracket
LCM-PEA “Just Fit”Carrying Case
LCS-CSD General Carrying Case
LCH-MA Memory Stick®Media Carrying Case
MSA-32A, MSA-64A, MSA-128A Memory
Stick®Media
MSA-128S2 Memory Stick®Media with Select
Function (256MB total)
MSA-256, MSX-512, MSX-1G Memory Stick
PRO™Media
MSAC-US30 Memory Stick PRO™Media USB
Adaptor
®
3:2 Aspect Ratio Mode
Clear Color/Clear Luminance NR
Supports High Speed USB 2.0
MPEG1 Cue, Review and Divide
DSC-P41
Cyber-shot®Digital Still Camera
Sony Electronics Inc.
16765 West Bernardo Drive
San Diego, CA 92127
www.sony.com/di
For more information:
1.800.352.SONY
Memory Stick®2304x1728 2304x1536 2048x1536 1280x960 640x480
Media1(4.1 MP) (3:2) (3 MP) (1 MP) (VGA)
16MB 8/14 8/14 10/18 24/46 97/243
32MB 16/30 16/30 20/37 50/93 196/491
64MB 32/30 32/60 41/74 101/187 394/895
128MB 64/120 64/120 82/149 202/376 790/1,975
Memory Stick
PRO™Media1
256MB 128/240 128/240 148/264 357/649 1,428/3,571
512MB 256/480 256/480 302/537 726/1,320 2,904/7,261
1GB 512/960 512/960 617/1,097 1,482/2,694 5,928/14,821
JPEG STILL IMAGE MODE
Fine/Standard Picture Quality
Memory Stick®MPEG VX MPEG VX Video Mail
Media (640x480) Fine (640x480) Standard (160x112)
16MB – 42s 11m 36s
32MB – 1m 27s 23m 30s
64MB – 2m 54s 47m 15s
128MB – 5m 54s 1h 34m 45s
Memory Stick
Pro™Media
256MB 2m 57s 10m 42s 2h 51m 21s
512MB 6m 2s 21m 47s 5h 48m 28s
1GB 12m 20s 44m 27 11h 51m 21s
MPEG MOVIE MODE
Maximum Storage Time
