DSC-TX5
10.2MP | 4x OPTICAL ZOOM | 3.0” TOUCH SCREEN LCD1
Review your shots with the touch
of a fi nger
The large 3” Wide Clear Photo LCD Plus™ touch
screen display¹ (230K pixels) allows you to scroll
through images by simply touching the display.
Take clearer photos with less
grain in low-light conditions
The DSC-TX5 features a 10.2 megapixel,
back-illuminated “Exmor R” CMOS image
sensor. This advanced technology leverages
the full resolving power of the camera’s 25mm
equivalent wide Carl Zeiss® Vario-Tessar®
lens, plus gives the camera stunning low-light
sensitivity for capturing extraordinarily clear
images with drastically reduced grain.
Be sure to catch all those
once-in-a lifetime moments
The DSC-TX5 can capture up to ten full 10.2
megapixel resolution images per second.
So now you can be sure to capture the bat
hitting the game-winning homerun, the lead
runner crossing the fi nish line, and other
decisive moments. The camera also uses a
mechanical shutter to help reduce distortion
when continuously shooting moving subjects.
Capture breathtaking
panoramic shots
Intelligent Sweep Panorama mode lets
capture stunningly expansive shots with
ease. Simply press the shutter button and
sweep the camera horizontally or vertically
over your desired scene. The camera shoots
continuously at a high speed, automatically
adjusts the position of each image, then
seamlessly stitches up to 100 pictures together
into one panoramic photo of up to 258
degrees. This model even detects faces and
moving objects, intelligently stitching subjects
of different widths together to minimize
distortion. With the DSC-TX5 you can even take
these panoramic images under water or, get
even more creative, and take shots partially
above and below water while you sweep.
MP4 for PC: 720p
MP4 is ideal for enjoying and sharing HD
movies on your PC, Mac® or the Internet. You
can record video up to 1280x720 at 30fps. A
MP4 HD fi le is a compressed single fi le format,
perfect for uploading to computers and Web
sharing sites like YouTube™. (Compatible
computer with Internet compatibility required.)
Carl Zeiss® Vario-Tessar® Lens
The high-performance Carl Zeiss® Vario-Tessar®
4x optical zoom (25mm equivalent) lens brings
distant subjects closer for video recording as
well as for outdoor, sports, and travel photos.
The Close Focus function lets you shoot from
just under ½” from your subjects, while the
25mm equivalent wide-angle lens allows for
wider shots of a scene or group in crowded
spaces.
Additional features:
• Motion Detection suppresses blur in people
and other subjects.
• Anti Motion Blur and Hand-held Twilight
modes reduce grain and blur
• High sensitivity ISO 3200
• Get yourself in the picture with Self-Portrait
Timer
• Intuitive touch screen operation (Flick, Drag
& Drop)
• Card slot for optional Memory Stick Duo™
and SD/SDHC media13
• Includes PMB (Picture Motion Browser)2 and
PMB Portable software3
Sony’s fi rst certifi ed waterproof / dustproof / shockproof / freeze-proof
camera15, the DSC-TX5 is just 3/4”29 thin, so it can into the slimmest pocket
or purse. Yet it’s waterproof to depths of 10 feet, shockproof from falls of
5 feet, and dustproof thanks to its airtight construction. With “Exmor R”
CMOS sensor, this tough little camera is capable of powerful features
like 10fps, iSweep Panorama and 720p MP4 HD movie recording.9
Sony Electronics Inc. | 16530 Via Esprillo | San Diego, CA 92127 | 1.800.222.7669 | www.sony.com

SILVER 3.0” LCD1 BLACK PINK GREEN RED
Specifi cations
DSC-TX5
T-SERIES Digital Still Camera
General
Camera Type Waterproof18 sleek and stylish with 3" touch screen1
Image Device 1/2.4"(7.59mm)"Exmor R" CMOS
Effective Pixels Resolution 10.2MP
Processor BIONZ®
Optics & Lens
Lens Type Carl Zeiss® Vario-Tessar®
Lens Construction 12 elements in 10 groups
(including 6 aspheric elements,1 prism)
Aperture Range iAUTO(F3.5-F6.3(W)) / Program Auto(F3.5-F6.3(W))
Focal Length 4.43-17.7mm
35mm Equivalency Still shots: 25-100mm / Movie 16:9: 28-112mm /
Movie 4:3: 34-136mm
Optical Zoom 4x
Digital Zoom Smart Zoom / Precision Digital Zoom / Off
Total Zoom Approximately 8x with Precision Digital Zoom
LCD & Viewfi nder
LCD Type 3.0” Clear Photo LCD Plus™ wide display1 (230K)
Viewfi nder -
Recording
Media Slot MS PRO Duo™ media / SD/SDHC media13
Still Images
10M (3,648 x 2,736) / 5M (2,592 x 1,944) /
VGA (640 x 480); 16:9 / 7M( 3,648 x 2,056)
/ 2M(1,920 x1,080); Panorama 7,152 x
1,080(258deg) / 4,912 x 1,080(177deg) /
4,912 x 1,920(177deg) / 3,424 x 1,920(123deg)
Video
1280 x 720 (29.97fps, Progressive) (Approx.6Mbps)
/VGA (640 x 480) (29.97fps, Progressive)
(Approx.3Mbps)
Microphone / Speaker Mono / Mono
Focus
Focus 9 points AF / Center Weighted AF / Spot AF / Flex-
ible Spot AF(Touch)
Intelligent Auto Focus Yes
Macro Mode
iAUTO(W:Approx.1cm (0.39”) to Infi nity,
T:Approx. 50cm (19.7”) to Infi nity”;
Program Auto “W: Approx. 1cm (0.39”) to Infi nity,
T:Approx. 50cm (19.7”)
Exposure
Exposure Metering Multi Pattern / Center Weighted / Spot
Exposure Compensation Plus / Minus 2.0EV, 1 / 3EV step
ISO Auto / 125 / 200 / 400 / 800 / 1600 / 3200
Backlight Correction HDR Yes
Dynamic Range Optimizer Standard
White Balance
Auto / Daylight / Cloudy / Fluorescent 1(White
Fluorescent Lighting) / Fluorescent 2 (Natural
White Fluorescent Lighting) / Fluorescent 3 (Day
White Fluorescent Lighting) / Incandescent /
Flash / One Push
Shutter
Shutter Speed iAUTO(2” - 1/1,600) / Program Auto(1” - 1/1,600)
Burst Mode Normal / Hi-Speed Burst(High/Mid/Low)
(Approx. 10fps at 10.2MP (Maximum 10 shots))
Flash
Flash Type Built-In
Flash Effective Range
ISO Auto: Approx.0.08-Approx.2.9m(Approx.
0.26’-Approx.9.51’)(W) / Approx.0.5-Approx.
2.4m(Approx.1.64’-Approx.7.87’)(T), ISO3200:
up to Approx.6.0m(Approx19.7)(W) / Approx.
4.7m(Approx15.4’)(T)
Flash Mode Auto / On / Slow Syncro / Off
Features
Scene Modes
High Sensitivity / Twilight / Twilight Portrait / Soft
Snap / Landscape / Beach / Snow / Fireworks /
Hi-Speed Shutter / Underwater / Gourmet / Pet
Image Stabilization Optical SteadyShot™ image stabilization
GPS -
Waterproof up to approx. 10 feet (1 hour)
Dustproof Yes
Freeze-proof ‘-10°C/ 14°F
Shockproof 1.5m/ 5ft
Panorama Intelligent Sweep Panorama
(Horizontal / Veritcal up to 258-degrees)
Multi-shot layering Handheld Twilight / Anti-motion Blur /
Backlight Correction HDR
Intelligent Auto Yes
Intelligent Scene Recognition 9 scenes
Face Detection 8 Faces (Auto / Touch / Child Priority / Adult Priority)
Motion Detection Yes
Blink Detection Yes
Smile Shutter™ Technology Yes
Self-timer Off / 10sec. / 2sec./ portrait1 / portrait2
In-Camera Editing Trimming / Red Eye Correction / Unsharp Masking
TransferJet™ Technology -
Inputs & Outputs
USB Yes - USB2.0 Hi-Speed
HD Video Component(1080i)
SD Video Yes
Power
Supplied Battery Lithium-ion NP-BN1 3.6V
Battery Life (Approx.)125
Number of Images (Approx.)250
Weights & Measurements
Dimensions (Approx.)3 3/4” x 2 1/4” x 23/32” (94.0mm x 56.9mm x 17.7mm)
Weights (Approx.)Approx. 4.5oz. (128g) body only; Approx. 5.1oz. (144g) -
With battery and Memory Stick PRO Duo media.
Software
Supplied Software Picture Motion Browser Ver 5.0, PMB Portable 5.0
(for Windows)2, PMB Portable 1.1(for Macintosh)
Operating System
Requirements
PMB and PMB Portable: Microsoft Windows XP SP3,
Windows Vista SP2, Windows 7. PMB Portable also
compatible with Macintosh OS X(v10.4 - 10.6).
Service & Warranty
Limited Term Warranty Limited 1 Year Parts & Labor
Supplied Accessories
Battery InfoLITHIUM® NP-BN1
Battery Charger BC-CSN
A/V Cable Yes
USB Cable Yes
Multi-Connector Cable
(A/V / USB)-
Shoulder Strap -
Wrist Strap Yes
Lens Cap Tether -
Paint Pen Yes
CD ROM Yes
Footnotes
1. Viewable area measured diagonally
2. PMB requires Microsoft® Windows® XP SP3/ Windows Vista® SP2/Windows 7. Picture Motion Browser
software not supported by Mac OS. Movie format is compatible with iMovie® ‘09 or later versions.
3. PMB Portable is pre-loaded. PMB Portable requires USB cable (included) and PC with internet
connectivity. Windows® XP SP3 64-bit and Starter Edition and Windows Vista® Starter Edition
environments not supported.
9. HD Movie mode records up to 1280x720p, at 30 fps, and 9Mbps.
13. When using movie mode Memory Stick PRO Duo™ with MARK2 (M2) logo, Memory Stick
PRO-HG™, or SD/SDHC (Class 4 or higher) media are recommended.
15. This camera has waterproof certifi ed to IEC60529 IPX8 standard, shock-proof Certifi ed to
MIL-STD-810F Method 516.5-Shock, dustproof certifi ed to IEC 60529 IP5X standard, and
can operate in temperatures between 14 degrees Fahrenheit (-10 degrees Celsius) and
104-degrees Fahrenheit (40 degrees Celsius)
18. This camera has waterproof certifi ed to IE60529 IPX8 standard.
29. Measured at its narrowest point
