Sony F65 User manual

OPERATION MANUAL [English]
2nd Edition (Revised 1)
DIGITAL MOTION PICTURE CAMERA
F65
F65 UPGRADE KIT
CBK-65EL

2
Before operating the unit, please read this manual thoroughly
and retain it for future reference.
To reduce the risk of fire or electric shock,
do not expose this apparatus to rain or
moisture.
To avoid electrical shock, do not open the
cabinet. Refer servicing to qualified
personnel only.
Caution
Use of controls or adjustments or performance of procedures
other than those specified herein may result in hazardous
radiation exposure. Do not open the outer case and
disassemble or otherwise modify.
This Digital Motion Picture Camera is classified as a CLASS 1
LASER PRODUCT.
Tämä Digital Motion Picture Camera on luokiteltu 1. LUOKAN
LASERTUOTTEEKSI.
Den här Digital Motion Picture Camera klassificeras som en
LASERPRODUKT AV KLASS 1.
VAROITUS!
LAITTEEN KÄYTTÄMINEN MUULLA KUIN TÄSSÄ
KÄYTTÖOHJEESSA MAINITULLA TAVALLA SAATTAA
ALTISTAA KÄYTTÄJÄN TURVALLISUUSLUOKAN 1
YLITTÄVÄLLE NÄKYMÄTTÖMÄLLE LASERSÄTEILYLLE.
VARNING
OM APPARATEN ANVÄNDS PÅ ANNAT SÄTT ÄN I DENNA
BRUKSANVISNING SPECIFICERATS, KAN ANVÄNDAREN
UTSÄTTAS FÖR OSYNLIG LASERSTRÅLNING, SOM
ÖVERSKRIDER GRÄNSEN FÖR LASERKLASS 1.
Internal Laser Module Properties
Wavelength : 850 nm
Emission duration : Pulse Modulation
Laser output power : 4 mW/channel (max)
Standard : IEC60825-1 (2007)
Egenskaber for internt lasermodul
Bølgelængde : 850 nm
Strålingsvarighed : Pulsmodulering
Afgivet lasereffekt : 4 mW/kanal (maks.)
Standard : IEC60825-1 (2007)
Egenskaper för intern lasermodul
Våglängd : 850 nm
Strålningens varaktighet : Pulsmodulation
Lasereffekt : 4 mW/kanal (max)
Standard : IEC60825-1 (2007)
Egenskaper for innvendig lasermodul
Bølgelengde : 850 nm
Strålingsvarighet : Pulsmodulasjon
Utgangseffekt for laser : 4 mW / kanal (maks.)
Standard : IEC60825-1 (2007)
Caution
The use of optical instruments with this product will increase
eye hazard.
For the customers in the U.S.A.
This equipment has been tested and found to comply with the
limits for a Class A digital device, pursuant to part 15 of the
FCC Rules. These limits are designed to provide reasonable
protection against harmful interference when the equipment is
operated in a commercial environment. This equipment
generates, uses, and can radiate radio frequency energy and,
if not installed and used in accordance with the instruction
manual, may cause harmful interference to radio
communications. Operation of this equipment in a residential
area is likely to cause harmful interference in which case the
user will be required to correct the interference at his own
expense.
You are cautioned that any changes or modifications not
expressly approved in this manual could void your authority to
operate this equipment.
All interface cables used to connect peripherals must be
shielded in order to comply with the limits for a digital device
pursuant to Subpart B of part 15 of FCC Rules.
This device complies with part 15 of the FCC Rules. Operation
is subject to the following two conditions: (1) This device may
not cause harmful interference, and (2) this device must
accept any interference received, including interference that
may cause undesired operation.
For the customers in Canada
This Class A digital apparatus complies with Canadian ICES-
003.
For the customers in Europe
This product with the CE marking complies with the EMC
Directive issued by the Commission of the European
Community.
Compliance with this directive implies conformity to the
following European standards:
• EN55103-1: Electromagnetic Interference(Emission)
• EN55103-2: Electromagnetic Susceptibility(Immunity)
This product is intended for use in the following
Electromagnetic Environments: E1 (residential), E2
(commercial and light industrial), E3 (urban outdoors), E4
(controlled EMC environment, ex. TV studio).
This product has been manufactured by or on behalf of Sony
Corporation, 1-7-1 Konan Minato-ku Tokyo, 108-0075 Japan.
WARNING

3
Inquiries related to product compliance based on European
Union legislation shall be addressed to the authorized
representative, Sony Deutschland GmbH, Hedelfinger
Strasse 61, 70327 Stuttgart, Germany. For any service or
guarantee matters, please refer to the addresses provided in
the separate service or guarantee documents.
For the State of California, USA only
Perchlorate Material - special handling may apply, See
www.dtsc.ca.gov/hazardouswaste/perchlorate
Perchlorate Material : Lithium battery contains perchlorate.
For the customers in Taiwan only
Afin de réduire les risques d’incendie ou
d’électrocution, ne pas exposer cet
appareil à la pluie ou à l’humidité.
Afin d’écarter tout risque d’électrocution,
garder le coffret fermé. Ne confier
l’entretien de l’appareil qu’à un personnel
qualifié.
Attention
L’emploi de commandes ou ajustements ou l’exécution de
procédures autres que celles spécifiées ici peut provoquer
une exposition dangereuse au rayonnement.
Digital Motion Picture Camera est classée comme PRODUIT
LASER DE CLASSE 1.
Propriétés du module laser interne
Longueur d’onde : 850 nm
Durée d’émission : Modulation d’impulsion
Puissance du laser : 4 mW/canal (max)
Norme : IEC60825-1 (2007)
Attention
L’emploi d’instruments optiques avec ce produit augmentera
les risques pour les yeux.
Pour les clients au Canada
Cet appareil numérique de la classe A est conforme à la
norme NMB-003 du Canada.
Pour les clients en Europe
Ce produit portant la marque CE est conforme à la Directive
sur la compatibilité électromagnétique (EMC) émise par la
Commission de la Communauté européenne.
La conformité à cette directive implique la conformité aux
normes européennes suivantes :
• EN55103-1 : Interférences électromagnétiques (émission)
• EN55103-2 : Sensibilité électromagnétique (immunité)
Ce produit est prévu pour être utilisé dans les environnements
électromagnétiques suivants : E1 (résidentiel), E2
(commercial et industrie légère), E3 (urbain extérieur) et E4
(environnement EMC contrôlé, ex. studio de télévision).
Ce produit a été fabriqué par ou pour le compte de Sony
Corporation, 1-7-1 Konan Minato-ku Tokyo, 108-0075 Japon.
Toutes les questions relatives à la conformité des produits
basées sur la législation européenne doivent être adressées à
son représentant, Sony Deutschland GmbH, Hedelfinger
Strasse 61, 70327 Stuttgart, Allemagne.
AVERTISSEMENT

4
Pour toute question relative au Service Après-Vente ou à la
Garantie, merci de bien vouloir vous référer aux coordonnées
qui vous sont communiquées dans les documents « Service
(SAV) » ou Garantie.
Um die Gefahr von Bränden oder
elektrischen Schlägen zu verringern, darf
dieses Gerät nicht Regen oder Feuchtigkeit
ausgesetzt werden.
Um einen elektrischen Schlag zu
vermeiden, darf das Gehäuse nicht
geöffnet werden. Überlassen Sie
Wartungsarbeiten stets nur qualifiziertem
Fachpersonal.
Dieser Digital Motion Picture Camera ist als
LASERPRODUKT DER KLASSE 1 eingestuft.
Eigenschaften des internen Lasermoduls
Wellenlänge : 850 nm
Emissionsdauer : Pulsmodulation
Laser-Ausgangsleistung : 4 mW/Kanal (max.)
Standard : IEC60825-1 (2007)
Für Kunden in Europa
Dieses Produkt besitzt die CE-Kennzeichnung und erfüllt die
EMV-Richtlinie der EG-Kommission.
Angewandte Normen:
• EN55103-1: Elektromagnetische Verträglichkeit
(Störaussendung)
• EN55103-2: Elektromagnetische Verträglichkeit
(Störfestigkeit)
Für die folgenden elektromagnetischen Umgebungen: E1
(Wohnbereich), E2 (kommerzieller und in beschränktem
Maße industrieller Bereich), E3 (Stadtbereich im Freien) und
E4 (kontrollierter EMV-Bereich, z.B. Fernsehstudio).
Dieses Produkt wurde von oder für Sony Corporation, 1-7-1
Konan Minato-ku Tokio, 108-0075 Japan hergestellt.
Bei Fragen zur Produktkonformität auf Grundlage der
Gesetzgebung der Europäischen Union kontaktieren Sie bitte
den Bevollmächtigten Sony Deutschland GmbH, Hedelfinger
Strasse 61, 70327 Stuttgart, Deutschland. Für Kundendienst
oder Garantieangelegenheiten wenden Sie sich bitte an die in
den Kundendienst- oder Garantiedokumenten genannten
Adressen.
WARNUNG
For the customers in the U.S.A.
SONY LIMITED WARRANTY - Please visit
http://www.sony.com/psa/warranty for important information
and complete terms and conditions of Sony's limited warranty
applicable to this product.
For the customers in Canada
SONY LIMITED WARRANTY - Please visit
http://www.sonybiz.ca/solutions/Support.do for important
information and complete terms and conditions of Sony's
limited warranty applicable to this product.
For the customers in Europe
Sony Professional Solutions Europe - Standard Warranty
and Exceptions on Standard Warranty.
Please visit http://www.pro.sony.eu/warranty for important
information and complete terms and conditions.
For the customers in Korea
SONY LIMITED WARRANTY - Please visit
http://bpeng.sony.co.kr/handler/BPAS-Start for important
information and complete terms and conditions of Sony's
limited warranty applicable to this product.

5
Table of Contents
Table of Contents
Chapter 1 Overview
1-1 Features ...........................................................................8
1-2 Example of System Configuration ..............................11
1-2-1 SR-R4 Docking System .................................................12
1-2-2 SKC-4065 + CA4000 Docking System .........................13
1-3 Locations and Functions of Parts ...............................14
Chapter 2 Installation and Preparations
2-1 Mounting the SR-R4 .....................................................19
2-2 Mounting the SKC-4065 + CA4000 ..............................20
2-3 Attaching a Filter ..........................................................20
2-4 Attaching a Lens ...........................................................21
2-5 Attaching a Viewfinder .................................................23
2-6 Mounting the Camera on a Tripod ..............................24
2-7 Mounting the CBK-WA01 .............................................25
2-8 Preparing the Power Supply ........................................26
2-9 Setting the Date and Time ............................................26
Chapter 3 Basic Adjustments and Settings
3-1 Basic Operation of the Camera ...................................28
3-2 Camera Settings ...........................................................29
3-3 Basic Settings using the Subdisplay ..........................30
3-3-1 Basic Operation of the Subdisplay .................................30
3-3-2 Setting the Video Format ...............................................31
3-3-3 Setting the Shutter Value ...............................................32
3-3-4 Selecting an ND Filter ....................................................34
3-3-5 Setting the Sensitivity (EI Value) (Cine Mode) .............34
3-3-6 Setting the Color Temperature .......................................35
3-3-7 Setting the SDI OUT2 Output Color Space ...................35
3-3-8 Setting the SDI OUT2 Output LUT ...............................35
3-3-9 Selecting the Fan Operating Mode .................................36
3-3-10 Checking the Voltages .................................................36
3-3-11 Checking the Remaining Media ...................................37
3-3-12 Checking the File Name ...............................................37
3-3-13 Checking the Time Code ..............................................37

6Table of Contents
3-3-14 Assigning Functions to the ASSIGN Buttons ..............37
3-3-15 Adjusting the Subdisplay Brightness ...........................38
3-3-16 Checking the Self-Diagnostic Results .........................39
3-4 VF Menu Basic Operation ........................................... 39
3-5 Setting the Shooting Mode ......................................... 41
3-6 Setting the Output Signal ............................................ 42
3-6-1 Adjusting the Output Signal Image ...............................42
3-6-2 Selecting the Viewfinder Output Signal ........................43
3-7 Viewing and Setting the Viewfinder Display ............. 44
3-7-1 Viewing the Basic Status Display ..................................44
3-7-2 Setting the Marker Display ............................................45
3-7-3 Setting the Voltage Warning Values .............................46
3-7-4 Magnifying the Image Display ......................................46
3-7-5 Monitoring High Key Blown-out Highlights and
Low Key Clipped Blacks ...............................................46
3-8 Manual RPN Correction Settings ................................ 47
3-8-1 Registering RPNs ...........................................................47
3-8-2 Deleting Registered RPNs .............................................48
3-9 Restoring the Factory Default Settings ..................... 49
Chapter 4 Menu Configuration and Detailed Settings
4-1 Subdisplay Menu List .................................................. 50
4-2 VF Menu List ................................................................. 53
4-2-1 Camera Menu .................................................................54
4-2-2 VF/SDI Menu ................................................................58
4-2-3 Display Info Menu .........................................................62
4-2-4 Config Menu ..................................................................64
4-2-5 File Menu .......................................................................66
4-2-6 Network Menu ...............................................................68
4-2-7 Diagnosis Menu .............................................................69
Appendix
Metadata .............................................................................. 70
RDD 18 format metadata set ....................................................70
Non-realtime metadata .............................................................72
Warning/Error Messages .................................................... 74
Precautions ......................................................................... 76
Cleaning the Recorder Connector ..................................... 77
About “Memory Stick Duo” ................................................ 77
Specifications ...................................................................... 79
Connector Pin Assignments .............................................. 82

7
Table of Contents
Menu Operation using a Web Browser ..............................85
Operation using a Tablet Device ........................................85
Color Space According to the COLOR SPACE
Settings ..........................................................................87
Notice Concerning Software Governed by the GNU
GPL/LGPL ......................................................................89

8Features
Chapter 1 Overview
Chapter1
Overview
1-1 Features
The F65 is a digital motion picture camera equipped with
a Super 35-mm type CMOS sensor array with a total of 20
Megapixels.
The camera is incorporated with newly developed imagers
and a digital signal-processing LSI that yield images of a
high quality for cinematic, commercial, and dramatic
production applications. The camera also supports the
features of a “production camera” up to details in its shape,
button and indicator layout, and materials of the parts.
• In order to use the various functions described in this
manual, the software version of each connected device
must be as follows.
F65: V4.00 or later
SR-R4: V4.00 or later
SR-CP1: V4.00 or later
CA4000: V2.0 or later
BPU4000: V2.0 or later
In addition, when operating the system with a CA4000
and BPU4000 connected, the SY_PLD of the F65 must
be V4.000-01 or later. For details, contact your local
Sony representative.
• The description in this manual assumes an F65 camera
fitted with the CBK-65EL upgrade kit.
Superior picture quality and high
performance
Super 35-mm type CMOS and PL mount
With the F65’s Super 35-mm-type CMOS imagers and PL
mount, most movie lenses designed for conventional 35-
mm film cameras can be mounted without a converter.
Wide latitude and high-quality pictures
With its newly developed imagers, and unique 16-bit
digital LSI, the camera achieves wide latitude and high-
grade picture quality with minimal noise.
RAW image output
Outputs RAW image data, without camera signal
processing or non-linear gamma processing, for increased
convenience during post-production.
Multiple frame formats
The camera supports 3840/4096-pixel wide images for
high-end content creation, including commercial and
broadcasting program production as well as movie
making.
The camera supports the following formats.
F65RAW mode: 23.98p, 24p, 25p, 29.97p, 50p, 59.94p,
S47.95 (Select FPS), S48 (Select FPS), S59.94p (Select
FPS), S60p (Select FPS)
F65RAW-HFR mode: S119.88p (Select FPS), S120p
(Select FPS), 100P (when connected to a CA4000/
BPU4000 system), 119.88P (when connected to a
CA4000/BPU4000 system)
HD mode: 23.98p, 24p, 25p, 29.97p, 50p, 59.94p,
S59.94p (Select FPS), S60p (Select FPS)
Imaging characteristics with wide color space
Sony’s unique technology color filters allow the camera to
capture images with natural-looking color reproduction
close to those of the actual scene.
S-LOG gamma and 709(800%) gamma for
monitors
The camera is equipped with S-LOG gamma for checking
the entire dynamic range of the image, and 709(800%)
gamma for general monitoring.
Mechanical rotary shutter
The camera is equipped with a mechanical rotary shutter
that eliminates the rolling shutter effect common to
conventional CMOS image sensors.
HD shooting
When used with the SR-R4 recorder, the camera can also
shoot images in HD mode, in addition to RAW mode.
SR-R4 version 1.4 or later is required to record in HD.
HFR (high frame rate) mode
Supports recording at 120 frames per second. Frame rates
from 1 to 120 fps can be selected using Select FPS.
Notes

9
Features
Chapter 1 Overview
In HFR mode, the ND filter is set to Clear, and the
mechanical rotary shutter cannot be used.
In addition, only when the frame rate is set to 120 fps, two
cameras can be genlocked so that the phase of the images
obtained are synchronized.
When a CA4000/BPU4000 system is connected, operation
in 100P and 119.88P, twice the speed of 50P and 59.94P
respectively, is possible.
2-system independent SDI outputs
Selectable, independent signal output on SDI1 and SDI2.
• A signal with a varied “look” (tone and color space)
based on CDL or 3D LUT can be selected for output on
SDI1.
• A video assist monitor image using Hi/Lo Key, MAG, or
other effects can be selected for output on SDI2, in
addition to the standard LUT.
The SDI1 system supports “Graded ACES” and “Look
Profile” settings that perform color conversion using a
built-in 3D LUT. The F65 employs a 3D LUT with
17×17×17 lattice to obtain a contour line signal for areas
of smoothly varying luminous intensity.
The recording signal is not affected, allowing the
processing to be improved using a color grading tool that
performs color conversion employing a higher-degree 3D
lattice grid.
DVF-EL100 viewfinder connection
Connects to the DVF-EL100 OLED color viewfinder
(option) that displays a high-resolution, accurate color
reproduction image. 1)
1) The DVF-L350/L700 viewfinder is not supported.
Connections for live operating systems
Connecting the unit to a CA4000 via an SKC-4065 and
connecting an optical SMPTE cable between the BPU4000
and HDCU2000/2500 allows the unit to transmit signals
and provide a power supply.
This allows the unit to operate as a system camera.
Design and shape
New compact design
For a high level of mobility in consideration of various
shooting situations, such as inside a car, the camera is
housed in as compact a body as possible. In addition,
buttons and indicators are laid out to provide a familiar and
intuitive user interface to users of conventional cinema
film cameras.
Dockable system for the SR-R4 Portable Memory
Recorder
A dockable interface system for docking with the SR-R4 is
employed for versatility under shooting conditions and on-
site demands.
Compatible with film-camera accessories
The F65 is designed to be compatible with a variety of
film-camera accessories, giving users a broad array of
choices. These include ARRIFLEX-made bridge plates,
matte boxes, follow focus units, lens focus/zoom/iris servo
control units, and more. These film-camera accessories
can be attached to the F65 without modification, enabling
users who principally work with film to fully utilize their
existing assets.
The F65 is equipped with one 12 V DC and connector one
24 V DC1) output connector to supply power to accessories
connected to the camera.
1) To supply accessories with 24 V DC power, the camera must have both
12 V DC and 24 V DC supplies, and the CAM POWER switch must be
turned ON.
Assignable buttons
The F65 is equipped with assignable buttons on the side of
the camera head.
The operator can assign frequently used functions, such as
magnifying the image in the viewfinder, to assignable
buttons to call these functions rapidly when working in the
field.
Operational versatility
Cine mode
This mode records video without processing, on the
presumption color grading is performed in post-
production, while applying basic color grading to the VF/
SDI outputs.
In Cine mode, the camera can be operated just like a
conventional film camera.
Custom mode
This mode allows you to adjust the black/white level and
the gain of the main signal when creating images on
location.
The SY_PLD of the F65 must be V2.200-01 or later to use
this function.
Shutter control
The shutter speed is adjustable in terms of shutter angle.
You can also switch between a mechanical rotary shutter
and an electronic shutter.
Sensitivity adjustment function
In Cine mode, the F65 employs an EI sensitivity indicator
for shooting using a light meter, just as for film cameras, to
Note

10 Features
Chapter 1 Overview
enable overexposure/underexposure processing in post-
production.
ASC CDL
American Society of Cinematographers Color Decision
List (ASC CDL) is a format for the exchange of basic color
grading information, recommended by ASC. The CDL
parameters can be specified by importing a CDL file or by
adjusting using the F65Remote Look Plus remote control
application or a web browser. The adjustments made are
not reflected in the master video signal, but are saved as
metadata in the SR-R4 recorder. When recording, the
video can be monitored on the VF/SDI outputs by applying
the values in metadata to the recorded material.
Only CDL files that contain parameter values within the
setting ranges defined in the <SDI1 ASC CDL> page of
the VF/SDI menu can be imported.
Other features
USB host connectors
The camera is equipped with USB connectors (host) for
connection with an optional Wi-Fi adapter (CBK-WA01)
to enable wireless camera operation from a tablet or other
Wi-Fi capable device.
Anamorphic format support
Normal VF/SDI video, without distortion, is output when
using a 2x anamorphic lens.
Supports various setup methods
The F65 can be configured from a variety of devices. The
basic configuration is performed on the camera’s
subdisplay. However, detailed settings can be performed
from the menu (VF Menu) displayed in the viewfinder or
on a monitor connected to the SDI OUT connector. You
can also make detailed settings by displaying the menu in
a web browser or on a tablet device, such as an iPad.1,2)
1) iPad is a trademark of Apple Inc.
2) The items displayed in the menu that can be configured using a web
browser or a tablet device may vary. For details, see “4-2 VF Menu List”
(page 53).
Note

11
Example of System Configuration
Chapter 1 Overview
1-2 Example of System Configuration
The diagram below shows a system configuration example
for use of this camera.
This manual assumes the use of an optional Sony HD
Electronic Viewfinder.
For more information about the fittings, connections, or
use of additional equipment and accessories, see “Chapter
2 Installation and Preparations” (page 19) as well as the
operation manuals for the connected equipment.
If attaching and using products, such as a shoulder set,
from other manufacturers, check beforehand that the
product can be fitted correctly to the camera.
Note
Products for tripod mounting
Product Model name
Bridge Plate BP-8 (ARRIFLEX)
Shoulder Set S-4 (ARRIFLEX)
F65 Product Configuration Center handle
Viewfinder mounting plate
19mm DIA carbon rod
Rod mounting plate
Riser plate
SR-R4
Viewfinder
Product Model name
HD Electronic Viewfinder HDVF-C30WR, HDVF-C35W, HDVF-20A, HDVF-200, DVF-EL100
Video recorder
Product Model name
Portable Memory Recorder SR-R4

12 Example of System Configuration
Chapter 1 Overview
1-2-1 SR-R4 Docking System
An SR-R4 recorder can be docked on the rear of the camera head.
The SR-R4 power source is supplied via the camera’s DC IN connector.
HDVF-C30WR or DVF-EL100
12 V DC power
SR-R4

13
Example of System Configuration
Chapter 1 Overview
1-2-2 SKC-4065 + CA4000 Docking System
Mount an SKC-4065 on which a CA4000 is attached onto the rear of the camera.
When an SKC-PB40 (option) is attached to the CA4000, using the dedicated cable to connect the camera to the CA4000
allows you to supply power to the camera from the CCU.
Lens
BP-8 Bridge Plate
(ARRIFLEX)
Tripod
HDVF-EL75
DVF-L700
Viewfinder
Optical fiber cable
DVF-EL100
Viewfinder
HDCU2000
Camera Control Unit
BNC
HDCU2500
Camera Control Unit
MSU-1000 series
Master Setup Unit
RCP-1000 series
Remote Control Panel
BNC
Video
Monitor
Waveform
Monitor
Video Router
CCA-5
LAN cable
Optical fiber cable
Hub
RCP-1000 series
Remote Control Panel
CCA-5
CAC-6 Return Video
Selector
Intercom Headset
CAC-12
Microphone
Holder
Microphone
USB flash drive
Sync signal input
Return video input
Intercom microphone
input
F65
BPU4000
Baseband Processor Unit
BNC × 4
2K Video
Monitor
BNC
4K Video
Monitor
LAN cable
Sync signal input
Return video input
Intercom microphone
input
SKC-4065+CA4000
+SKC-PB40

14 Locations and Functions of Parts
Chapter 1 Overview
1-3 Locations and Functions of Parts
Front panel
a(Network) connector (RJ-45 type, 10BASE-T/
100BASE-TX)
Connects to a network cable when configuring the camera
from a web browser on a computer.
For a network cable connection, the IP address must be
configured in the Network menu in the VF menu.
For details, see “4-2-6 Network Menu” (page 68).
• For safety, do not connect the connector for peripheral
device wiring that might have excessive voltage to this
port. Follow the instructions for this port.
• When you connect the network cable of the unit to
peripheral device, use a shielded-type cable to prevent
malfunction due to radiation noise.
• When operating the system with a CA4000 connected,
network connection via this connector is not possible.
• Par mesure de sécurité, ne raccordez pas le connecteur
pour le câblage de périphériques pouvant avoir une
tension excessive à ce port. Suivez les instructions pour
ce port.
• Lors de la connexion du câble réseau de l’appareil au
périphérique, utilisez un câble blindé afin d’empêcher
tout dysfonctionnement dû au bruit de rayonnement.
• Aus Sicherheitsgründen nicht mit einem
Peripheriegerät-Anschluss verbinden, der zu starke
Spannung für diese Buchse haben könnte. Folgen Sie
den Anweisungen für diese Buchse.
• Verwenden Sie beim Anschließen des Netzwerkkabels
des Geräts an ein Peripheriegerät ein abgeschirmtes
Kabel, um Fehlfunktionen aufgrund von Störungen zu
vermeiden.
bVentilation holes (intake)
Make sure that a gap of about 8 mm (11/32 inch) is
maintained in front of the ventilation holes for cooling.
cViewfinder shoe
Attach an optional viewfinder.
For details, see “2-5 Attaching a Viewfinder” (page 23).
dVF (viewfinder) connector (20-pin)
Connects to the cable supplied with a viewfinder
(optional).
eLens fixing lever
When mounting a lens, turn the lever clockwise to secure
the lens. To remove the lens, turn the lever
counterclockwise.
If the lens fixing lever is difficult to operate due to the
shape of the lens or accessory being mounted, you can
remove the lever and attach it in a different orientation.
For details, see “2-4 Attaching a Lens” (page 21).
fHot shoe
Supports the Cooke /i Intelligent Electronic Lens System
and can record lens information as metadata.
cViewfinder shoe
Lens mount
a(Network) connector
eLens fixing lever
dVF connector
fHot shoe
Shutter emergency open
screw (page 76)
bVentilation holes (intake)
CAUTION
ATTENTION
VORSICHT
Note

15
Locations and Functions of Parts
Chapter 1 Overview
Left panel
aUSB connectors
USB 2.0 standard connector. Connect a CBK-WA01 Wi-Fi
Adapter (optional) to enable communication with wireless
LAN devices.
When operating the system with a CA4000 connected,
network connection via this connector is not possible.
bAccessory receptacles
For mounting accessories using M3 screws. The depth of
the screws is 5 mm (7/32 inch).
cCAM POWER switch
Turns the camera power supply ON/OFF.
dDC OUT 12V 4A (12 V DC supply output)
connector
Supplies 12 V DC power source to accessories, when the
CAM POWER switch is in the ON position.
eDC OUT 24V 4A (24 V DC supply output)
connector
Supplies 24 V DC power source to accessories when there
is a 24 V DC supply connected to the DC IN connector and
the CAM POWER switch is in the ON position.
fWrench box
Stores a 3 mm (1/8inch) wrench for attaching/detaching
the handle.
gLENS connector (12-pin)
Controls the aperture remotely with the connection of a
commercially-available iris servo unit.
hEXT. I/O (external control) connector (5-pin)
It is not used in this version.
iHandle
The handle is attached to the top of the camera head at the
factory. It has two sizes of screw holes (3/8", 1/4") for
accessories on the upper side.
jMeasure hook/focus reference mark
Use as reference for focusing.
For actual measurement of the distance from a subject, you
can fix the end of a tape measure to the hook.
When shooting shallow depth-of-field images in high
resolution, it is recommended that you adjust the focus
using the camera or viewfinder magnification function.
kSDI OUT2 connector (BNC type)
Outputs the SDI2 Look (single link) signal.
lVF connector (26-pin, for DVF-EL100)
Connects to the DVF-EL100 viewfinder (option).
To reduce OLED burn-in, use the DVF-EL100 switch to
turn VF DISPLAY (viewfinder display function) On/Off.
cCAM POWER switch
dDC OUT 12V 4A connector
eDC OUT 24V 4A connector
fWrench box
gLENS connector
hEXT. I/O connector
iHandle
jMeasure hook/
focus reference mark
bAccessory receptacles
aUSB connectors kSDI OUT2 connector
lVF connector (for DVF-EL100)
mVentilation holes (exhaust)
Note
Note

16 Locations and Functions of Parts
Chapter 1 Overview
mVentilation holes (exhaust)
Connectors and other parts positioned near the exhaust
vents may become hot.
Right panel
aASSIGN (assignable) buttons
You can assign various functions to these buttons, using
the subdisplay or the menu displayed in the viewfinder or
on a monitor.
ASSIGN button 1 is on the far left, and ASSIGN button 4
is on the far right.
For details, see “3-3-14 Assigning Functions to the
ASSIGN Buttons” (page 37).
bDIAGNOSIS indicator
Indicates the diagnostics status.
Lit green: Normal
Lit red: Error
Flashing red: Fatal error
Lit yellow: Not ready
If the red or flashing red indication continues, consult your
local Sony representative.
cLOCK switch
Locks operation of the side panel (excluding the REC and
PAGE buttons).
dSHUTTER button
Switches between the electronic shutter and the
mechanical rotary shutter.
Press the “M.” button for one second or longer to switch to
the mechanical rotary shutter, or press the “E.” button for
one second or longer to switch to the electronic shutter.
The button indicator for the selected shutter is lit. The
shutter indicator flashes when changing shutter.
It takes about 20 to 40 seconds to change shutter.
eREC button and LOCK switch
The REC button starts/stops recording to the SR-R4
docked on the camera. The REC button indicator is lit
while recording. The indicator flashes as a warning if the
connected supply voltage drops.
When the LOCK switch is in the LOCK position, the REC
button cannot be operated.
The REC button cannot be operated during REC REVIEW,
PLAY, F.FWD, or REW mode on the SR-R4 to prevent
overwriting.
For details on warning indications, see “Warning/Error
Messages” (page 74).
f“Memory Stick”/SD memory card section
Slots for a “Memory Stick PRO Duo” and an SD memory
card are provided behind the rubber cap. The access lamp
turns red when a “Memory Stick PRO Duo” or an SD
Note
bDIAGNOSIS indicator
cLOCK switch
dSHUTTER button
hTripod receptacles (bottom)
Display/menu operation block
f“Memory Stick”/
SD memory card section
aASSIGN buttons
eREC button and LOCK switch
gDOCK indicator
Note

17
Locations and Functions of Parts
Chapter 1 Overview
memory card is inserted into a slot, and then turns off. It
flashes red when reading to or writing from a “Memory
Stick PRO Duo” or an SD memory card.
When the access lamp is flashing red, do not insert/remove
the “Memory Stick PRO Duo” or SD memory card, or turn
off the power.
gDOCK (docking) indicator
When an SR-R4 is docked, the light reception status of the
recorder connectors is displayed.
Green: Good
Yellow: Caution level
Sensitivity has decreased, but signal can be transferred
without error. Clean the recorder connector or replace
the connector optical module as soon as practicable.
Red: Light detection error
A light reception problem occurred, and signal cannot
be transferred correctly. Promptly clean the recorder
connector or replace the connector optical module.
Off: No signal
For details about cleaning the connectors, see “Cleaning
the Recorder Connector” (page 77). For information
about replacing the optical module, consult your local
Sony representative.
hTripod receptacles (bottom)
Mounting point for a tripod using 3/8" tripod screws.
Display/menu operation block
Used to switch the monitor display between the subdisplay
and the viewfinder, and to operate the menus.
For details on menu operations, see “3-3-1 Basic
Operation of the Subdisplay” (page 30) and “3-4 VF Menu
Basic Operation” (page 39).
aVF DISPLAY (viewfinder display) button
Displays the status screen on the viewfinder and monitor.
For details about the information displayed, see “3-7
Viewing and Setting the Viewfinder Display” (page 44).
bVF MENU (viewfinder menu) button
Displays the menu screen on the viewfinder and monitor.
With the DVF-EL100 connected, press and hold this
button for two seconds or longer to display the Digital VF
Picture menu.
cSubdisplay
Displays the camera configuration settings. Press and hold
the SETTING button (1 second or longer) to enter Settings
Change mode.
dSETTING button
Press and hold for 1 second or longer to enter Settings
Change mode to change camera settings using the
subdisplay.
ePAGE button
Displays the next page when the subdisplay is in Settings
Change mode.
fBACK button
Cancels changes and returns to the previous screen when
the subdisplay is in Settings Change mode or when
displaying the menu in the viewfinder or on a monitor.
Pressing the BACK button when the DVF adjustment
menu is displayed returns the display to the VF menu page
select screen.
gMENU SEL (selection)/ENTER dial
Turn the dial to select items and press to enter when the
subdisplay is in Settings Change mode or when displaying
the menu in the viewfinder or on a monitor.
aVF DISPLAY button
gMENU SEL/ENTER dial
ePAGE button
bVF MENU button
cSubdisplay
dSETTING button
fBACK button

18 Locations and Functions of Parts
Chapter 1 Overview
Rear panel
aRecorder connector
Connects signal and power with the SR-R4 or CA4000
(with the SKC-4065 also attached) docked on the camera.
Attach the connector cap on the optical connector when
not connected to an SR-R4 to protect the connector.
bREC (record) indicator
The indicator is lit red while the recorder is recording.
You can slide the cover to hide the indicator.
cGENLOCK IN (external sync signal input)
connector (BNC type)
Connects to an external sync signal (HD 3-level sync) or
HD-SDI signal for camera synchronization.
The sync signal is selected in the VF menu.
When operating the system with a CA4000 connected, this
connector is disabled.
dSHUTTER (external shutter) connector
It is not used in this version.
eHD-Y OUT connector
Outputs the Y-signal for the HD analog component signal.
Used to synchronize external analog equipment.
fSDI OUT1 (SDI output 1) connector (BNC type)
Outputs the SDI1 Look (single link) signal.
gREMOTE connector (8-pin)
Controls the main line signal with the connection of the
optional RM-B170 remote control unit or similar unit
(custom mode).
When operating the system with a CA4000 connected, this
connector is disabled.
hDC IN (DC power input) indicator
A 10.5 V to 17 V indicator and 20 V to 30 V indicator are
provided. When the CAM POWER switch is turned ON,
the corresponding indicator lights up according to the
voltage of the power source.
iDC IN connector (LEMO 8-pin)
Connects to a power cable with the supplied power cable
connector.
For details, see “2-8 Preparing the Power Supply” (page
26).
jCable clamp screw holes
Can be used to attach the supplied cable clamp.
There are also screw holes on the upper surface on the left
panel side.
fSDI OUT1 connector
gREMOTE connector
hDC IN indicator
iDC IN connector
eHD-Y OUT connector
bREC indicator
cGENLOCK IN connector
aRecorder connector
dSHUTTER connector
jCable clamp screw holes
Note
Note
Note

19
Chapter 2 Installation and Preparations
Chapter
Mounting the SR-R4
2
Installation and
Preparations
2-1 Mounting the SR-R4
The SR-R4 docks on the rear of the camera head.
For details about mounting the SR-R4, refer to the
Operation Manual of the SR-R4.
• SR-R4/SRK-CP1 software V4.00 or later is required.
• Always turn off the camera power supply when
mounting the SR-R4.
• The recorder connector for connecting the SR-R4 is an
optical connector. Attach the connector cap on the
optical connector when not connected to an SR-R4 to
protect the connector. After removing the cap, store it in
the position shown in the following figure for
safekeeping.
• When mounting the SR-R4, fix the camera head on a
tripod in advance to keep the camera head stable.
For tripod mounting, see “2-6 Mounting the Camera on
a Tripod” (page 24).
• When the camera is used with the SR-R4 docked, make
sure that the camera is securely fixed and stable so that it
will not fall over.
Notes
SR-R4

20 Mounting the SKC-4065 + CA4000 / Attaching a Filter
Chapter 2 Installation and Preparations
2-2 Mounting the
SKC-4065 + CA4000
A CA4000 on which an SKC-4065 is attached can be
docked on the rear of the camera for system operations.
• CA4000 and BPU4000 software V2.0 or later is
required.
• Always turn off the camera power supply when
mounting the CA4000 on which the SKC-4065 is
attached.
For details on mounting, refer to the Operation Guide for
the SKC-4065.
2-3 Attaching a Filter
You can mount commercially available gel filters in the
supplied filter holder and then attach them to the camera if
you wish to use an ND filter in F65RAW-HFR mode or
wish to use a filter other than those built into the camera.
Recommended filter: Fujifilm neutral density filters
1 Place the filter template (metallic disc) on the gel filter,
then trim the filter around the edge of the filter
template.
2 Remove the ring from the filter holder, place the filter
on the ring, and then attach the holder.
3 Align the protrusion on the mounting tool with the
notch on the filter holder, then insert the holder into the
tool.
Notes
Filter holder
Filter
Ring
