Sony ILCE-3000K User manual

Sony Corporation
SERVICE MANUAL
Revision History
LEVEL 3
Check the SERVICE NOTE (LEVEL 2) before the service.
983474112.pdf
2014D08-1
© 2014.04
Published by Sony Techno Create Corporation
INTERCHANGEABLE LENS DIGITAL CAMERA
The components identified
by mark 0or dotted line with
mark 0are critical for safety.
Replace only with part number
specified.
Les composants identifiés par
une marque 0sont critiques pour
la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
US Model
Canadian Model
AEP Model
UK Model
Russian Model
E Model
Australian Model
Chinese Model
Korea Model
Brazilian Model
Tourist Model
9-834-741-12
ILCE-3000K/3500J
ILCE-3000K/3500J_L3
[About the service of this model]
ILCE-3000K/3500J are commodity that packed the Interchangeable Lens Digital Camera and Interchangeable Lenses.
Refer to each following service manual the Interchangeable Lens kit, when you repair.
Model Lens Service Manual of Lens
ILCE-3000K SEL1855 (E 18-55 mm F3.5-5.6 OSS) 9-852-799-[][]
ILCE-3500J SEL1850 (E 18-50 mm F4-5.6) 9-834-791-[][]
Ver. 1.1 2014.04
Photo: ILCE-3000K
Ver. Date History Contents S.M. Rev.
issued
1.0 2013.08 Official Release — —
1.1 2014.04 Revised-1
(A1 13-200)
• Addition of ILCE-3500J. Yes*
Revised-1
Replace the previously issued
SERVICE MANUAL 9-834-741-11
with this Manual.
*: S.M. revised only top cover.

ILCE-3000K/3500J_L3
– 2 –
SAFETY-RELATED COMPONENT WARNING!!
COMPONENTS IDENTIFIED BY MARK 0OR DOTTED LINE WITH
MARK 0ON THE SCHEMATIC DIAGRAMS AND IN THE PARTS LIST
ARE CRITICAL TO SAFE OPERATION. REPLACE THESE COMPO-
NENTS WITH SONY PARTS WHOSE PART NUMBERS APPEAR AS
SHOWN IN THIS MANUAL OR IN SUPPLEMENTS PUBLISHED BY
SONY.
ATTENTION AU COMPOSANT AYANT RAPPORT
À LA SÉCURITÉ!
LES COMPOSANTS IDENTIFIÉS PAR UNE MARQUE 0SUR LES
DIAGRAMMES SCHÉMATIQUES ET LA LISTE DES PIÈCES SONT
CRITIQUES POUR LA SÉCURITÉ DE FONCTIONNEMENT. NE REM-
PLACER CES COMPOSANTS QUE PAR DES PIÈCES SONY DONT
LES NUMÉROS SONT DONNÉS DANS CE MANUEL OU DANS LES
SUPPLÉMENTS PUBLIÉS PAR SONY.
Caution
Danger of explosion if battery is incorrectly replaced.
Replace only with the same or equivalent type.
Dispose of used batteries according to the instructions.
SAFETY CHECK-OUT
After correcting the original service problem, perform the following
safety checks before releasing the set to the customer.
1. Check the area of your repair for unsoldered or poorly-soldered
connections. Check the entire board surface for solder splashes and
bridges.
2. Check the interboard wiring to ensure that no wires are “pinched”
or contact high-wattage resistors.
3. Look for unauthorized replacement parts, particularly transistors,
that were installed during a previous repair. Point them out to the
customer and recommend their replacement.
4. Look for parts which, through functioning, show obvious signs of
deterioration. Point them out to the customer and recommend their
replacement.
5. Check the B+ voltage to see it is at the values specified.
6. Flexible Circuit Board Repairing
• Set the soldering iron tip temperature to 350 °C approximately.
• Do not touch the soldering iron on the same conductor of the circuit
board (within 3 times).
• Be careful not to apply force on the conductor when soldering or
unsoldering.
UNLEADED SOLDER
This unit uses unleaded solder.
Boards requiring use of unleaded solder are printed with the lead free
mark (LF) indicating the solder contains no lead.
(Caution: Some printed circuit boards may not come printed with the
lead free mark due to their particular size.)
: LEAD FREE MARK
Be careful to the following points to solder or unsolder.
• Set the soldering iron tip temperature to 350 °C approximately.
If cannot control temperature, solder/unsolder at high temperature
for a short time.
Caution: The printed pattern (copper foil) may peel away if the
heated tip is applied for too long, so be careful!
Unleaded solder is more viscous (sticky, less prone to
flow) than ordinary solder so use caution not to let solder
bridges occur such as on IC pins, etc.
• Be sure to control soldering iron tips used for unleaded solder and
those for leaded solder so they are managed separately. Mixing un-
leaded solder and leaded solder will cause detachment phenomenon.
注意
如果电池更换不当会有爆炸危险。
只能用同样类型或等效类型的电池来更换。
务必按照说明处置用完的电池。

ILCE-3000K/3500J_L3
2-1
2. REPAIR PARTS LIST
A-1923-785-A BT-2002 FLEXIBLE BOARD, COMPLETE
******************************
< CONNECTOR >
CN001 1-816-655-61 CONNECTOR, FFC/FPC 8P
A-1954-964-A SERVICE, MECHA DEVICE (1100)
(Not supplied) IS-1007 BOARD, COMPLETE
**********************
(All mounted parts and IS-1007 COMPLETE BOARD are not supplied, but they are
included in MECHA DEVICE (1100) (SERVICE).)
1-885-294-11 IS-105 FLEXIBLE BOARD
*******************
1-887-267-11 IS-1006 FLEXIBLE BOARD
********************
1-888-083-11 HB-1002 FLEXIBLE BOARD
*********************
A-1957-985-A LC-1012 FLEXIBLE BOARD, COMPLETE
******************************
(IC002 is not supplied, but this is included in LC-1012 FLEXIBLE COMPLETE BOARD.)
< CAPACITOR >
C001 1-116-737-11 CERAMIC CHIP 1uF 20% 10V
C002 1-116-717-11 CERAMIC CHIP 10uF 20% 10V
C003 1-118-039-11 CERAMIC CHIP 1uF 10% 25V
C004 1-118-039-11 CERAMIC CHIP 1uF 10% 25V
C101 1-116-729-11 CERAMIC CHIP 2.2uF 20% 10V
C102 1-116-734-11 CERAMIC CHIP 1uF 20% 16V
*C103 1-116-738-11 CERAMIC CHIP 1uF 10% 6.3V
C104 1-116-729-11 CERAMIC CHIP 2.2uF 20% 10V
C105 1-116-737-11 CERAMIC CHIP 1uF 20% 10V
C106 1-116-737-11 CERAMIC CHIP 1uF 20% 10V
C107 1-114-098-91 CERAMIC CHIP 2.2uF 20% 25V
C108 1-116-734-11 CERAMIC CHIP 1uF 20% 16V
C109 1-116-729-11 CERAMIC CHIP 2.2uF 20% 10V
C110 1-116-729-11 CERAMIC CHIP 2.2uF 20% 10V
C111 1-100-743-91 CERAMIC CHIP 2.2uF 20% 16V
< CONNECTOR >
*CN001 1-816-649-51 FFC/CONNECTOR, FPC (LIF) 22P
*CN101 1-821-503-11 CONNECTOR, FPC (ZIF) 39P
< IC >
*IC001 6-719-358-01 IC MM3416A25URE
IC002 (Not supplied) IC MM3416A48URE
< COIL >
*L101 1-481-102-21 INDUCTOR 10uH
Ref. No. Part No. Description
< RESISTOR >
R008 1-218-941-81 METAL CHIP 100 5% 1/16W
R106 1-218-941-81 METAL CHIP 100 5% 1/16W
< COMPOSITION CIRCUIT BLOCK >
RB114 1-234-375-21 RES, NETWORK 1K (1005X4)
A-1959-442-A MIS-2002 FLEXIBLE BOARD, COMPLETE
*******************************
(CN001 is not supplied, but this is included in MIS-2002 FLEXIBLE COMPLETE
BOARD.)
< CONNECTOR >
CN001 (Not supplied) CONNECTOR (SHOE)
A-1957-983-A RL-1023 FLEXIBLE BOARD, COMPLETE
*******************************
(S007 is not supplied, but this is included in RL-1023 FLEXIBLE COMPLETE BOARD.)
< BATTERY HOLDER >
BH001 1-251-928-21 SOCKET, BATTERY
< BATTERY >
BT001 1-756-134-15 BATTERY, LITHIUM (SECONDARY)
< DIODE >
D001 6-502-887-01 DIODE SCM-J14DTT96
< RESISTOR >
R001 1-218-949-11 METAL CHIP 470 5% 1/16W
R006 1-218-369-11 METAL CHIP 2.2K 5% 1/2W
R101 1-218-955-11 METAL CHIP 1.5K 5% 1/16W
R102 1-218-956-11 METAL CHIP 1.8K 5% 1/16W
R104 1-218-961-11 METAL CHIP 4.7K 5% 1/16W
R105 1-218-964-11 METAL CHIP 8.2K 5% 1/16W
R106 1-218-967-11 METAL CHIP 15K 5% 1/16W
R107 1-218-972-11 METAL CHIP 39K 5% 1/16W
R133 1-218-957-11 METAL CHIP 2.2K 5% 1/16W
< SWITCH >
S001 1-798-420-11 SWITCH, DETECTION
*S002 1-798-136-21 TACTILE SWITCH
*S003 1-786-914-51 SWITCH, TACTILE
S004 1-786-914-31 SWITCH, TACTILE
S005 1-786-148-11 SWITCH, PUSH (1 KEY)
S006 1-786-914-31 SWITCH, TACTILE
S007 (Not supplied) SWITCH, ROTARY
< THERMISTOR >
TH001 1-804-949-11 THERMISTOR, NTC (SMD)
Ref. No. Part No. Description
2-2. ELECTRICAL PARTS LIST
BT-2002 IS-1007 IS-105 IS-1006 HB-1002 LC-1012 MIS-2002 RL-1023
NOTE:
• -XX, -X mean standardized parts, so they may have some differ-
ences from the original one.
• Items marked “*” are not stocked since they are seldom required for
routine service. Some delay should be anticipated when ordering
these items.
• The mechanical parts with no reference number in the exploded
views are not supplied.
• Due to standardization, replacements in the parts list may be dif-
ferent from the parts specified in the diagrams or the components
used on the set.
• CAPACITORS:
uF: μF
• COILS
uH: μH
• RESISTORS
All resistors are in ohms.
METAL: metal-film resistor
METAL OXIDE: Metal Oxide-film resistor
F: nonflammable
• SEMICONDUCTORS
In each case, u: μ, for example:
uA...: μA... , uPA... , μPA... ,
uPB... , μPB... , uPC... , μPC... ,
uPD..., μPD...
The components identified by mark 0
or dotted line with mark 0are critical
for safety.
Replace only with part number specified.
Les composants identifiés par une
marque 0sont critiques pour la sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
When indicating parts by reference
number, please include the board name.
Caution
Danger of explosion if battery is incorrectly replaced.
Replace only with the same or equivalent type.
Dispose of used batteries according to the instructions.
Note: Be sure to read “Precautions for Replacement of Imager”
on page 6-1 when changing the imager.
注意
如果电池更换不当会有爆炸危险。
只能用同样类型或等效类型的电池来更换。
务必按照说明处置用完的电池。

ILCE-3000K/3500J_L3
2-2
A-1957-984-A ST-1017 FLEXIBLE BOARD, COMPLETE
*******************************
< CAPACITOR >
C003 1-100-672-11 CERAMIC CHIP 10uF 20% 16V
C006 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
*C007 1-116-456-11 CERAMIC CHIP 0.047uF 10% 350V
< CONNECTOR >
*CN101 1-822-910-11 CONNECTOR, FPC (LIF (NON-ZIF))
< DIODE >
*D003 6-503-901-01 DIODE DA2JF6500L
D004 6-501-119-01 DIODE RR264M-400
< IC >
IC001 6-716-806-01 IC R2J20071DNS
< COIL >
*L001 1-400-820-11 INDUCTOR 2.2uH
< TRANSISTOR >
Q001 6-552-987-01 TRANSISTOR RJP4010AGE-01
< RESISTOR >
*R005 1-250-523-11 METAL CHIP 15K 1% 1/16W
R006 1-250-521-11 METAL CHIP 12K 1% 1/16W
R008 1-218-871-11 METAL CHIP 10K 0.5% 1/10W
R009 1-208-889-11 METAL CHIP 1.2K 0.5% 1/16W
*R010 1-246-338-21 METAL CHIP 3M 1% 1/8W
R011 1-218-881-11 METAL CHIP 27K 0.5% 1/10W
R012 1-218-938-11 METAL CHIP 56 5% 1/16W
R013 1-216-121-11 METAL CHIP 1M 5% 1/10W
R016 1-220-880-11 METAL CHIP 27 0.5% 1/16W
< SWITCH >
S001 1-786-707-11 SWITCH, DETECTION (SMD)
< TRANSFORMER >
*T001 1-445-774-11 D.C.-D.C.CONVERTER TRANSFORMER
A-1958-136-A SY-1026 BOARD, COMPLETE (SERVICE)
*******************************
(CN0601, FB1501, FB1502, FB1503, FB1504, FB1505, FB1506, FB1507, FB1508,
IC0304, IC0305, IC1001, IC2001 and IC2003 are not supplied, but they are included in
SY-1026 COMPLETE BOARD (SERVICE).)
< CAPACITOR >
C0102 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C0103 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C0104 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C0105 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C0106 1-112-298-91 CERAMIC CHIP 1uF 10% 16V
C0107 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C0108 1-118-347-11 CERAMIC CHIP 0.1uF 10% 25V
C0111 1-100-696-91 CERAMIC CHIP 1uF 10% 6.3V
Ref. No. Part No. Description
C0113 1-116-728-11 CERAMIC CHIP 2.2uF 10% 10V
C0114 1-116-728-11 CERAMIC CHIP 2.2uF 10% 10V
C0115 1-116-728-11 CERAMIC CHIP 2.2uF 10% 10V
C0116 1-116-728-11 CERAMIC CHIP 2.2uF 10% 10V
C0117 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C0118 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C0119 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C0120 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C0121 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
*C0123 1-112-746-11 CERAMIC CHIP 4.7uF 10% 6.3V
*C0124 1-112-746-11 CERAMIC CHIP 4.7uF 10% 6.3V
C125 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C0201 1-100-966-91 CERAMIC CHIP 10uF 20% 10V
C0202 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C0203 1-100-966-91 CERAMIC CHIP 10uF 20% 10V
C0206 1-114-354-11 CERAMIC CHIP 0.1uF 10% 16V
C0207 1-114-354-11 CERAMIC CHIP 0.1uF 10% 16V
C0210 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C0211 1-100-696-91 CERAMIC CHIP 1uF 10% 6.3V
C0212 1-116-707-11 CERAMIC CHIP 47uF 20% 10V
*C0213 1-114-728-91 CERAMIC CHIP 22uF 10% 10V
*C0215 1-114-728-91 CERAMIC CHIP 22uF 10% 10V
C0216 1-114-354-11 CERAMIC CHIP 0.1uF 10% 16V
C0217 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C0301 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
*C0304 1-112-746-11 CERAMIC CHIP 4.7uF 10% 6.3V
C0307 1-114-983-91 CERAMIC CHIP 2.2uF 10% 16V
C0308 1-137-988-91 CERAMIC CHIP 1uF 10% 35V
C0309 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C0310 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C0601 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C0602 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C0603 1-112-300-91 CERAMIC CHIP 4.7uF 10% 10V
C0604 1-112-534-11 CERAMIC CHIP 10uF 20% 6.3V
C0605 1-114-419-21 CERAMIC CHIP 10uF 10% 16V
C0606 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C0608 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C0610 1-112-342-91 CERAMIC CHIP 10uF 20% 10V
C0612 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C0624 1-164-850-11 CERAMIC CHIP 10PF 0.5PF 50V
C0625 1-164-850-11 CERAMIC CHIP 10PF 0.5PF 50V
C1001 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C1002 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C1003 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C1004 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
*C1008 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C1009 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C1011 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C1016 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C1021 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
C1022 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C1023 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
C1024 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
C1026 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
*C1101 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C1103 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C1104 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C1105 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C1106 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C1111 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
C1112 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
*C1115 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C1116 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
C1118 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C1119 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C1123 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C1124 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
*C1128 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
C1129 1-112-815-91 CERAMIC CHIP 10uF 20% 6.3V
C1130 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C1131 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C1132 1-100-252-11 CAP, CERAMIC 0.1MF B (1310)
C1133 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C1202 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C1203 1-116-350-21 CERAMIC CHIP 47uF 20% 4V
*C1204 1-112-746-11 CERAMIC CHIP 4.7uF 10% 6.3V
C1205 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C1206 1-100-611-91 CERAMIC CHIP 22uF 20% 6.3V
*C1207 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C1209 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C1210 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
C1211 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
*C1212 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C1213 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
C1214 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
*C1215 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C1216 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C1217 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
C1218 1-128-627-91 CERAMIC CHIP 0.001uF 10% 16V
C1219 1-128-627-91 CERAMIC CHIP 0.001uF 10% 16V
*C1220 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C1221 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
C1223 1-128-627-91 CERAMIC CHIP 0.001uF 10% 16V
*C1224 1-112-746-11 CERAMIC CHIP 4.7uF 10% 6.3V
C1225 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C1226 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
*C1227 1-112-746-11 CERAMIC CHIP 4.7uF 10% 6.3V
C1228 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C1301 1-116-737-11 CERAMIC CHIP 1uF 20% 10V
C1302 1-116-737-11 CERAMIC CHIP 1uF 20% 10V
C1303 1-116-737-11 CERAMIC CHIP 1uF 20% 10V
C1305 1-116-737-11 CERAMIC CHIP 1uF 20% 10V
*C1306 1-118-389-11 CERAMIC CHIP 0.022uF 10% 25V
C1307 1-116-737-11 CERAMIC CHIP 1uF 20% 10V
C1308 1-116-737-11 CERAMIC CHIP 1uF 20% 10V
C1310 1-116-737-11 CERAMIC CHIP 1uF 20% 10V
C1312 1-116-506-91 CERAMIC CHIP 47uF 20% 6.3V
C1314 1-118-417-11 CERAMIC CHIP 0.1uF 10% 16V
*C1316 1-116-714-11 CERAMIC CHIP 22uF 20% 6.3V
C1405 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
*C1406 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C1407 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
C1408 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C1409 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C1411 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C1412 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C1415 1-100-567-81 CERAMIC CHIP 0.01uF 10% 25V
C1416 1-100-567-81 CERAMIC CHIP 0.01uF 10% 25V
C1417 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C1418 1-164-935-11 CERAMIC CHIP 470PF 10% 50V
C1419 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C1420 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C1601 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C1602 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C1902 1-100-611-91 CERAMIC CHIP 22uF 20% 6.3V
C1903 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
*C2001 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
C2002 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C2003 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C2004 1-100-567-81 CERAMIC CHIP 0.01uF 10% 25V
C2005 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
*C2006 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
C2007 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
*C2008 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C2009 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
C2010 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
*C2011 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
C2014 1-100-567-81 CERAMIC CHIP 0.01uF 10% 25V
C2015 1-100-567-81 CERAMIC CHIP 0.01uF 10% 25V
C2016 1-100-567-81 CERAMIC CHIP 0.01uF 10% 25V
C2017 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C2101 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C2102 1-112-298-91 CERAMIC CHIP 1uF 10% 16V
C2303 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
C2304 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C2402 1-100-415-91 CERAMIC CHIP 0.47uF 10% 6.3V
C2403 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
*C7301 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
C7302 1-114-219-21 CERAMIC CHIP 1uF 10% 10V
C7304 1-165-887-91 CERAMIC CHIP 0.22uF 10% 6.3V
< CONNECTOR >
CN0601 (Not supplied) SOCKET, USB CONNECTOR
*CN1301 1-817-829-81 CONNECTOR, FPC (ZIF) 27P
CN1302 1-818-320-71 CONNECTOR, FPC (ZIF) 39P
CN1501 1-843-072-51 CONNECTOR, FPC (ZIF) 39P
CN1901 1-843-088-23 CARD CONNECTOR
*CN2101 1-822-914-11 CONNECTOR, FPC (LIF (NON-ZIF))
*CN2301 1-822-914-11 CONNECTOR, FPC (LIF (NON-ZIF))
CN3001 1-821-858-61 CONNECTOR, FPC (LIF (NON-ZIF)) 24P
*CN3002 1-820-031-71 CONNECTOR, FPC (LIF) 14P
*CN3003 1-816-643-51 FFC/CONNECTOR, FPC (LIF) 10P
CN3004 1-822-245-61 CONNECTOR, FPC (LIF (NON-ZIF)) 20P
CN7301 1-822-245-61 CONNECTOR, FPC (LIF (NON-ZIF)) 20P
< DIODE >
*D0001 6-503-573-01 DIODE 1SS400SMGJT2R
*D303 6-503-578-01 DIODE RB520SM-30T2R
*D304 6-503-578-01 DIODE RB520SM-30T2R
D0601 6-502-196-01 DIODE SML-D12Y8WT86SP
D0603 6-503-702-01 DIODE RB070M-30FJTR
*D1101 6-503-573-01 DIODE 1SS400SMGJT2R
*D1301 6-503-578-01 DIODE RB520SM-30T2R
*D1302 6-503-578-01 DIODE RB520SM-30T2R
*D1303 6-503-578-01 DIODE RB520SM-30T2R
D1901 6-502-193-01 DIODE SML-D12V8WT86SN
Ref. No. Part No. Description Ref. No. Part No. Description Ref. No. Part No. Description
ST-1017 SY-1026

ILCE-3000K/3500J_L3
2-3
SY-1026
*D1904 6-503-573-01 DIODE 1SS400SMGJT2R
D1905 8-719-056-23 DIODE MA2S111-(K8).SO
*D2001 6-503-578-01 DIODE RB520SM-30T2R
D2301 8-719-056-23 DIODE MA2S111-(K8).SO
*D2302 6-503-578-01 DIODE RB520SM-30T2R
D2306 8-719-084-17 DIODE EMZ6.8EFJT2R
D2307 8-719-084-17 DIODE EMZ6.8EFJT2R
*D2401 6-503-578-01 DIODE RB520SM-30T2R
D3002 8-719-084-17 DIODE EMZ6.8EFJT2R
D3007 6-503-031-01 DIODE DZ2J18000L
D7301 8-719-056-23 DIODE MA2S111-(K8).SO
< FUSE >
F0001 1-576-874-41 FUSE (2.5A/32V)
F0002 1-576-603-41 FUSE (3.15A/24V)
F0003 1-576-596-41 FUSE (1A/36V)
F0004 1-576-913-41 FUSE (1.6A/36V)
F0006 1-576-913-41 FUSE (1.6A/36V)
F0601 1-576-416-41 FUSE (2A/36V)
< FERRITE BEAD >
FB1101 1-481-900-21 INDUCTOR, FERRITE BEADS (1005)
FB1102 1-469-580-21 INDUCTOR, FERRITE BEAD (1005)
FB1201 1-400-619-11 BEAD, FERRITE (CHIP) (1608)
FB1501 (Not supplied) INDUCTOR (FERRITE BEAD 0603)
FB1502 (Not supplied) INDUCTOR (FERRITE BEAD 0603)
FB1503 (Not supplied) INDUCTOR (FERRITE BEAD 0603)
FB1504 (Not supplied) INDUCTOR (FERRITE BEAD 0603)
FB1505 (Not supplied) INDUCTOR (FERRITE BEAD 0603)
FB1506 (Not supplied) INDUCTOR (FERRITE BEAD 0603)
FB1507 (Not supplied) INDUCTOR (FERRITE BEAD 0603)
FB1508 (Not supplied) INDUCTOR (FERRITE BEAD 0603)
< IC >
IC0101 6-717-389-01 IC BD8330AGU-E2
IC0102 6-716-873-01 IC RP109L111DA-TR
IC0103 6-714-000-01 IC TC7MBL6125SFK (EL)
IC0201 6-717-448-01 IC AN30235A-PL
IC0202 6-715-773-01 IC NJM12904RB1 (TE2)
*IC301 6-720-388-01 IC RP173K301D-TR
IC0303 6-716-949-01 IC RT9292DGJ6
IC0304 (Not supplied) IC BD2224G-BZTR
IC0305 (Not supplied) IC BD2224G-BZTR
IC0601 6-718-154-01 IC BD8668GW-E2
IC0602 6-718-429-01 IC MAX14599EEWV+TG1A
IC1001 (Not supplied) IC (CPU)
IC1301 6-717-276-01 IC MM3416A45URE
IC1302 6-717-276-01 IC MM3416A45URE
IC1401 6-718-156-01 IC BU76312GUW-E2
*IC1402 6-719-629-01 IC MM3411A31RRE
IC2001 (Not supplied) IC 19A44FDAXBG7NC5 (EL
IC2002 6-715-620-01 IC PST8240UL
IC2003 (Not supplied) IC R2062L01-E2
IC2102 6-706-491-01 IC TC7SH86FU
*IC2302 6-711-430-01 IC TC74VHC367FK (EL)
IC2401 6-718-671-01 IC uPD79F0043FC-404-2N1-E2-A
IC7302 6-708-327-01 IC TC7WH240FK
Ref. No. Part No. Description
< COIL >
L0101 1-460-359-11 INDUCTOR 4.7uH
L0102 1-481-036-11 INDUCTOR 4.7uH
L0103 1-481-036-11 INDUCTOR 4.7uH
L0105 1-481-036-11 INDUCTOR 4.7uH
L0201 1-481-036-11 INDUCTOR 4.7uH
L0202 1-460-359-11 INDUCTOR 4.7uH
L0301 1-460-369-11 INDUCTOR 33uH
L0601 1-460-359-11 INDUCTOR 4.7uH
L1301 1-469-553-21 INDUCTOR 4.7uH
*L1302 1-481-103-21 INDUCTOR 4.7uH
< TRANSISTOR >
Q0001 6-552-838-01 TRANSISTOR TPC6604
*Q0002 6-552-354-01 TRANSISTOR DRC3144E0L
Q0004 6-552-842-01 TRANSISTOR QS8J2FU7TR
*Q0005 6-552-354-01 TRANSISTOR DRC3144E0L
*Q101 6-552-700-01 TRANSISTOR SSM3K15AMFV, L3SF
Q0201 6-551-202-01 TRANSISTOR LM6K1FS8T2R
Q0202 6-552-874-01 TRANSISTOR RW1C025ZPT2CR
Q0203 6-552-126-01 TRANSISTOR MTM8612709S0
Q0204 6-552-842-01 TRANSISTOR QS8J2FU7TR
Q0205 6-552-842-01 TRANSISTOR QS8J2FU7TR
Q0206 6-551-346-01 TRANSISTOR LSK3541FS8T2L
Q0207 6-552-765-01 TRANSISTOR FC6943010R
Q0208 6-551-202-01 TRANSISTOR LM6K1FS8T2R
*Q0301 6-552-213-01 TRANSISTOR RW1A020ZPFU7
*Q0302 6-552-354-01 TRANSISTOR DRC3144E0L
Q303 6-552-805-01 TRANSISTOR EM6M2T2R
*Q304 6-552-213-01 TRANSISTOR RW1A020ZPFU7
*Q0601 6-552-354-01 TRANSISTOR DRC3144E0L
Q0602 6-552-874-01 TRANSISTOR RW1C025ZPT2CR
Q0603 6-551-630-01 TRANSISTOR RN1102MFV (TL3S
Q0605 6-551-630-01 TRANSISTOR RN1102MFV (TL3S
*Q1301 6-552-354-01 TRANSISTOR DRC3144E0L
Q1302 6-552-845-01 TRANSISTOR SSM3K121TU, LSOYF
Q1303 8-729-053-58 TRANSISTOR RN1904FE
*Q1304 6-552-397-01 TRANSISTOR DSC300100L
*Q1305 6-552-523-01 TRANSISTOR DMA904010R
Q1306 6-551-346-01 TRANSISTOR LSK3541FS8T2L
Q1307 6-552-398-01 TRANSISTOR FJ3303010L
Q2001 6-551-346-01 TRANSISTOR LSK3541FS8T2L
Q2102 6-551-630-01 TRANSISTOR RN1102MFV (TL3S
Q2103 8-729-013-22 TRANSISTOR HN1A01FU
Q2104 8-729-055-01 TRANSISTOR RN4984FE
Q2106 6-551-630-01 TRANSISTOR RN1102MFV (TL3S
Q2107 6-551-630-01 TRANSISTOR RN1102MFV (TL3S
Q2108 6-552-883-01 TRANSISTOR US6M2GTR
Q2304 6-551-202-01 TRANSISTOR LM6K1FS8T2R
Q2306 6-550-576-01 TRANSISTOR SSM6E01TU
Q3001 6-552-845-01 TRANSISTOR SSM3K121TU, LSOYF
Q3002 6-551-630-01 TRANSISTOR RN1102MFV (TL3S
*Q7301 6-552-354-01 TRANSISTOR DRC3144E0L
Q7302 6-550-576-01 TRANSISTOR SSM6E01TU
Q7303 6-552-622-01 TRANSISTOR MTM761230LBF
Q7304 8-729-053-57 TRANSISTOR RN1902FE
Q7305 6-551-630-01 TRANSISTOR RN1102MFV (TL3S
< RESISTOR >
R0001 1-216-796-11 METAL CHIP 8.2 5% 1/10W
R0002 1-218-953-11 METAL CHIP 1K 5% 1/16W
R0003 1-218-961-11 METAL CHIP 4.7K 5% 1/16W
R0004 1-218-977-11 METAL CHIP 100K 5% 1/16W
R0104 1-250-535-11 METAL CHIP 47K 1% 1/16W
R0201 1-218-989-11 METAL CHIP 1M 5% 1/16W
R0202 1-218-977-11 METAL CHIP 100K 5% 1/16W
R0203 1-248-472-11 METAL CHIP 0.05 1% 1/2W
R0206 1-208-935-11 METAL CHIP 100K 0.5% 1/16W
R0207 1-208-935-11 METAL CHIP 100K 0.5% 1/16W
R0208 1-208-931-11 METAL CHIP 68K 0.5% 1/16W
R0209 1-208-931-11 METAL CHIP 68K 0.5% 1/16W
R0210 1-218-977-11 METAL CHIP 100K 5% 1/16W
R0211 1-218-981-91 METAL CHIP 220K 5% 1/16W
R0212 1-208-955-11 METAL CHIP 680K 0.5% 1/16W
R0213 1-208-955-11 METAL CHIP 680K 0.5% 1/16W
R0215 1-250-533-11 METAL CHIP 39K 1% 1/16W
R0216 1-250-519-11 METAL CHIP 10K 1% 1/16W
*R0218 1-250-539-11 METAL CHIP 68K 1% 1/16W
*R0219 1-250-523-11 METAL CHIP 15K 1% 1/16W
R0221 1-218-977-11 METAL CHIP 100K 5% 1/16W
R0222 1-218-977-11 METAL CHIP 100K 5% 1/16W
R0227 1-216-025-11 METAL CHIP 100 5% 1/10W
R0232 1-218-977-11 METAL CHIP 100K 5% 1/16W
R0302 1-218-981-91 METAL CHIP 220K 5% 1/16W
R0304 1-250-447-11 METAL CHIP 10 1% 1/16W
R0308 1-218-965-11 METAL CHIP 10K 5% 1/16W
R309 1-218-985-11 METAL CHIP 470K 5% 1/16W
R0602 1-248-311-11 RES-CHIP 0.1 1% 1/4W
R0603 1-218-985-11 METAL CHIP 470K 5% 1/16W
R0604 1-250-535-11 METAL CHIP 47K 1% 1/16W
R0605 1-218-944-11 METAL CHIP 180 5% 1/16W
R0606 1-218-973-11 METAL CHIP 47K 5% 1/16W
R0607 1-218-957-11 METAL CHIP 2.2K 5% 1/16W
R0610 1-218-953-11 METAL CHIP 1K 5% 1/16W
R0622 1-218-989-11 METAL CHIP 1M 5% 1/16W
R0633 1-218-941-81 METAL CHIP 100 5% 1/16W
R0655 1-218-963-11 METAL CHIP 6.8K 5% 1/16W
R1004 1-240-766-11 METAL CHIP 180 0.5% 1/20W
R1012 1-240-712-91 METAL CHIP 27K 5% 1/20W
R1013 1-240-695-91 METAL CHIP 1K 5% 1/20W
R1014 1-240-695-91 METAL CHIP 1K 5% 1/20W
R1025 1-240-703-91 METAL CHIP 4.7K 5% 1/20W
R1026 1-240-703-91 METAL CHIP 4.7K 5% 1/20W
R1029 1-240-714-91 METAL CHIP 47K 5% 1/20W
R1030 1-240-714-91 METAL CHIP 47K 5% 1/20W
R1104 1-240-676-91 METAL CHIP 22 5% 1/20W
R1106 1-240-676-91 METAL CHIP 22 5% 1/20W
R1107 1-240-683-91 METAL CHIP 100 5% 1/20W
R1108 1-240-676-91 METAL CHIP 22 5% 1/20W
R1117 1-208-699-11 METAL CHIP 4.7K 0.5% 1/16W
R1118 1-208-699-11 METAL CHIP 4.7K 0.5% 1/16W
R1139 1-240-687-91 METAL CHIP 220 5% 1/20W
R1154 1-240-707-91 METAL CHIP 10K 5% 1/20W
R1155 1-240-703-91 METAL CHIP 4.7K 5% 1/20W
R1156 1-240-703-91 METAL CHIP 4.7K 5% 1/20W
R1157 1-240-707-91 METAL CHIP 10K 5% 1/20W
*R1158 1-250-543-11 METAL CHIP 100K 1% 1/16W
R1202 1-208-668-11 METAL CHIP 240 0.5% 1/16W
R1301 1-218-965-11 METAL CHIP 10K 5% 1/16W
R1302 1-218-977-11 METAL CHIP 100K 5% 1/16W
R1303 1-218-953-11 METAL CHIP 1K 5% 1/16W
R1304 1-218-965-11 METAL CHIP 10K 5% 1/16W
R1307 1-218-969-11 METAL CHIP 22K 5% 1/16W
R1308 1-208-922-11 METAL CHIP 30K 0.5% 1/16W
R1310 1-208-930-11 METAL CHIP 62K 0.5% 1/16W
R1311 1-218-937-11 METAL CHIP 47 5% 1/16W
R1321 1-218-933-11 METAL CHIP 22 5% 1/16W
R1322 1-218-977-11 METAL CHIP 100K 5% 1/16W
R1405 1-218-990-81 SHORT CHIP 0
R1409 1-240-713-91 METAL CHIP 33K 5% 1/20W
R1411 1-218-990-81 SHORT CHIP 0
R1501 1-240-687-91 METAL CHIP 220 5% 1/20W
R1502 1-240-687-91 METAL CHIP 220 5% 1/20W
R1503 1-240-687-91 METAL CHIP 220 5% 1/20W
R1504 1-240-687-91 METAL CHIP 220 5% 1/20W
R1505 1-240-687-91 METAL CHIP 220 5% 1/20W
R1506 1-240-687-91 METAL CHIP 220 5% 1/20W
R1507 1-240-687-91 METAL CHIP 220 5% 1/20W
R1508 1-240-687-91 METAL CHIP 220 5% 1/20W
R1901 1-218-949-11 METAL CHIP 470 5% 1/16W
R1902 1-218-941-81 METAL CHIP 100 5% 1/16W
R1903 1-218-941-81 METAL CHIP 100 5% 1/16W
R1904 1-218-941-81 METAL CHIP 100 5% 1/16W
R1905 1-218-941-81 METAL CHIP 100 5% 1/16W
R1916 1-218-941-81 METAL CHIP 100 5% 1/16W
R1917 1-218-941-81 METAL CHIP 100 5% 1/16W
R1918 1-218-941-81 METAL CHIP 100 5% 1/16W
R1919 1-218-941-81 METAL CHIP 100 5% 1/16W
R1920 1-218-941-81 METAL CHIP 100 5% 1/16W
R1921 1-218-941-81 METAL CHIP 100 5% 1/16W
R1922 1-218-941-81 METAL CHIP 100 5% 1/16W
R1923 1-218-941-81 METAL CHIP 100 5% 1/16W
R2001 1-218-949-11 METAL CHIP 470 5% 1/16W
R2005 1-218-953-11 METAL CHIP 1K 5% 1/16W
R2008 1-218-989-11 METAL CHIP 1M 5% 1/16W
R2009 1-218-989-11 METAL CHIP 1M 5% 1/16W
R2010 1-218-965-11 METAL CHIP 10K 5% 1/16W
R2011 1-218-977-11 METAL CHIP 100K 5% 1/16W
R2012 1-218-977-11 METAL CHIP 100K 5% 1/16W
*R2013 1-250-511-11 METAL CHIP 4.7K 1% 1/16W
R2015 1-218-941-81 METAL CHIP 100 5% 1/16W
R2016 1-218-941-81 METAL CHIP 100 5% 1/16W
R2017 1-218-941-81 METAL CHIP 100 5% 1/16W
R2105 1-218-953-11 METAL CHIP 1K 5% 1/16W
R2106 1-216-796-11 METAL CHIP 8.2 5% 1/10W
R2107 1-250-525-11 METAL CHIP 18K 1% 1/16W
R2108 1-250-519-11 METAL CHIP 10K 1% 1/16W
R2110 1-218-944-11 METAL CHIP 180 5% 1/16W
R2111 1-218-969-11 METAL CHIP 22K 5% 1/16W
R2112 1-218-969-11 METAL CHIP 22K 5% 1/16W
R2114 1-218-953-11 METAL CHIP 1K 5% 1/16W
R2115 1-216-799-11 METAL CHIP 15 5% 1/10W
R2116 1-218-977-11 METAL CHIP 100K 5% 1/16W
R2117 1-218-977-11 METAL CHIP 100K 5% 1/16W
Ref. No. Part No. Description Ref. No. Part No. Description Ref. No. Part No. Description

ILCE-3000K/3500J_L3
2-4E
R2302 1-218-941-81 METAL CHIP 100 5% 1/16W
R2317 1-218-953-11 METAL CHIP 1K 5% 1/16W
R2324 1-218-977-11 METAL CHIP 100K 5% 1/16W
R2402 1-240-718-91 METAL CHIP 100K 5% 1/20W
R3007 1-218-941-81 METAL CHIP 100 5% 1/16W
R3008 1-218-961-11 METAL CHIP 4.7K 5% 1/16W
R3019 1-218-941-81 METAL CHIP 100 5% 1/16W
R3020 1-218-941-81 METAL CHIP 100 5% 1/16W
R3021 1-218-953-11 METAL CHIP 1K 5% 1/16W
R3025 1-218-977-11 METAL CHIP 100K 5% 1/16W
R7301 1-218-977-11 METAL CHIP 100K 5% 1/16W
R7302 1-240-701-91 METAL CHIP 3.3K 5% 1/20W
R7303 1-240-718-91 METAL CHIP 100K 5% 1/20W
R7304 1-218-965-11 METAL CHIP 10K 5% 1/16W
R7305 1-218-989-11 METAL CHIP 1M 5% 1/16W
R7306 1-218-977-11 METAL CHIP 100K 5% 1/16W
R7307 1-218-953-11 METAL CHIP 1K 5% 1/16W
< COMPOSITION CIRCUIT BLOCK >
*RB0101 1-234-384-11 RES, NETWORK 1M (1005X4)
*RB201 1-234-384-11 RES, NETWORK 1M (1005X4)
RB202 1-234-378-21 RES, NETWORK 10K (1005X4)
RB301 1-234-381-11 RES, NETWORK 100K (1005X4)
RB1101 1-234-372-11 RES, NETWORK 100 (1005X4)
RB1102 1-234-381-11 RES, NETWORK 100K (1005X4)
RB1401 1-234-376-11 RES, NETWORK 2.2K (1005X4)
RB1507 1-234-372-11 RES, NETWORK 100 (1005X4)
RB1508 1-234-372-11 RES, NETWORK 100 (1005X4)
RB2301 1-234-374-21 RES, NETWORK 470 (1005X4)
RB2302 1-234-374-21 RES, NETWORK 470 (1005X4)
RB2303 1-234-381-11 RES, NETWORK 100K (1005X4)
RB2304 1-234-381-11 RES, NETWORK 100K (1005X4)
*RB2305 1-234-384-11 RES, NETWORK 1M (1005X4)
RB2306 1-234-378-21 RES, NETWORK 10K (1005X4)
RB3004 1-234-375-21 RES, NETWORK 1K (1005X4)
RB3005 1-234-375-21 RES, NETWORK 1K (1005X4)
< SENSOR >
*SE2101 1-487-961-11 SLANT SENSOR
< VARISTOR >
*VDR232 1-802-128-11 VARISTOR (SMD)
< VIBRATOR >
X0601 1-814-304-11 VIBRATOR, CRYSTAL (12MHz)
X1001 1-487-897-31 SILICON OSCILLATOR (12MHz)
X2001 1-795-244-11 VIBRATOR, CERAMIC (10MHz)
X2002 1-781-525-11 VIBRATOR, CRYSTAL (32.768kHz)
Ref. No. Part No. Description
SY-1026

ILCE-3000K/3500J_L3
4-1
4. BLOCK DIAGRAMS
4-1. OVERALL BLOCK DIAGRAM (1/2) ( ) : Number in parenthesis ( ) indicates the division number of schematic diagram where the component is located.
BACKLIGHT
CA_XRESET_IC_1001
CA_XRESET_IC_1001
BL_H
BL_L
AV_SO,
AV_SCK
W1
W2
CN1501 CN101
38
39
6
7
LCD_XHD LCD_HD
LCD_VD
LCD_CLK
BL_H
BL_L
7
34
LCD_XVD 8
33
LCD_CLK 9
32
36
30
29
28
3
LCD_SO 5
LCD_SCK 6
XCS_LCD
AV_SO
AV_SO, AV_SCK,
XCS_LCD
AV_SCK
XCS_LCD 4
LCD_XHD
LCD_XVD
LCD_CLK
35
LCD_B[0 - 7] LCD_B[0 - 7]
SP901
(SPEAKER)
MIC901
(MICROPHONE UNIT)
IC1401
AUDIO
INTERFACE
(10/19)
IC7302 , Q7304
Q7305
EXTERNAL
FLASH I/F
(19/19)
INT_MIC_L
INT_MIC_R
SP+, SP-
INT_MIC_L
INT_MIC_R
SHUTTER
DRIVE
Q3001
CP6001
(SHUTTER)
SHUTTER
UNIT
CLK_SYS_IN
XHS
XVS
XCLR
SENS_HD
SENS_VD
XCIS_RST
IMAGER_TEMP1IMG_TEMP1
2ND_CURTAIN_MG
SHUTTER_PI
2C
PI-K
DOP00 - DOP07,
DOM00 - DOM07,
DCKP, DCKM
SUBL_DINP2 - SUBL_DINP9,
SUBL_DINN2 - SUBL_DINN9,
SUBL_CLKINP, SUBL_CLKINN
SDI, SDO,SCK, XCE
IC_1001_SENSSO/SENSSI/SENSSCK/SENSXCS
TH6001
D2301
AF2
AA24
AC29
AC30
C9
C6
D6
R11
7
4
CN3003
27
27
CN1301
CN1302CN6002
CN6001
IS-1006
FLEXIBLE
BOARD
IS-105
FLEXIBLE
BOARD
IS-1007 BOARD SY-1026 BOARD (1/2)
3
2
11
7 - 10
13,14,16,17,19,20,22,23,25, 26,28,29,31,32,34,35,37,38 13,14,16,17,19,20,22,23,25, 26,28,29,31,32,34,35,37,38
3
2
11
XPI CIS_SHT_RST
W26 D5 6 6
7 - 10
IC2102
Q2107, Q2108
SHUTTER CHARGE
MOTOR CONTROL
(15/19)
MB N
HOLDER
ASSY
IC2302
CHARGE
MOTOR
M
MB CHARGE
UNIT
LENS_CS_IC_1001
LENS_XDETECT_IC_1001
IC_1001_VD_CA
IC_1001_VD_CA
LENS_CS_CA
GP_UART1_TXD
GP_UART1_RXD
IC_1001_CS_LENS
BODY_VD_LENS
LENS_CS_BODY
LENS_DATA_BODY
BODY_DATA_LENS
BODY_CS_LENS
XSHUTTER_CHARGE_CAM_2
XSHUTTER_CHARGE_CAM_1
XSHUTTER_CHARGE_CAM_3
CHARGE_MOTOR_TEMP
CHARGE_MOTOR_TEMP
SHUTTER_CHARGE_MOTOR_1,
SHUTTER_CHARGE_MOTOR_2
: VIDEO SIGNAL
: AUDIO SIGNAL
08
2
3
AE9
IC_1001_VD_CA
M16
CN2301
CN2101
16
5 - 9
1
2
4
7
3
2
4
5
LENS_XDETECT_BODY
1
LENS_XDETECT_CA
LENS_3.1V_ON
Q2304
SDI0_SPDIF_IN
SDO
BCK_OUT, LRCK_OUT, MCK_INOUT
XCS_AVIO
BEEP_PWM_P
IC0303
BACKLIGHT
DRIVE
(4/19)
IC2001
(1/2)
IC1001
(1/2)
LCD_CABC_PWM
XCS_EVF XCS_EVF
SHUTTER_CHARGE_MOTOR_1,
SHUTTER_CHARGE_MOTOR_2,
XSHUTTER_CHARGE_CAM_1,
XSHUTTER_CHARGE_CAM_2,
XSHUTTER_CHARGE_CAM_3,
LENS_CS_CA, LENS_3.1V_ON
LENS_XDETECT_CA
SHUTTER_PI_ON,
SHUTTER_PI, SHUTTER_ID,
2ND_CURTAIN_MG
OVERALL (2/2)
(PAGE 4-2)
1
CAM_SI_2
CAM_SO_2
CAM_SCK_2
XCS_EXT_FL
EXT_FLASH_TRIG
OVERALL (2/2)
(PAGE 4-2)
2
SHUTTER_PI_ON
SHUTTER PI
SWITCH
Q3002
6
LC-1012 FLEXIBLE
BOARD
ST-1017 FLEXIBLE
BOARD (1/2)
LCD901
(LCD MODULE)
3.0 INCH
COLOR LCD
MAIN CPU
(14/19)
CHARGE
MOTOR
DRIVE
LENS REMOVE
DETECT
Q2306
BUFFER
(16/19)
CONTROL
BLOCK
CMOS
IMAGER X6001
54MHz
PROCESSOR
(6/19 - 8/19)
X1001
12MHz
B+ SWITCH
2SHUTTER_ID
ID
PI-E
10 - 17 19 - 26
LCD_DB0 - DB7
CN001
CN3004
(1/2) CN101
EVF_HVD
EVF_XVD
EVF_CLK
18
17
LCD_HD
LCD_VD 7
8
19
20
EVF_SO 6
EVF_SCK 4
XCS_EVF 3
LCD902
EVF UNIT
7-10, 12-15
EVF_E0 - E7
LCD_DB0 - DB7
1
20
6
3
EXT_MIC_L
EXT_MIC_R
SHOE_ID1 - ID3SHOE_ID1 - ID3 ID1 - ID3
MIC_L/GVIF_SDATA_N
MIC_R/GVIF_SDATA_P
MIS-2002 FLEXIBLE
BOARD
CN7301 CN001
14
13
5
6
F2_EXT/EVF_SI
F3_EXT/EVF_SCK
F2/EXT_EVF_SI
F3/EXT_EVF_SCK
4
5
19
18
F1_EXT/EVF_SO F1/EXT_EVF_SO
3 20
ISO_SHOE_X X_contact
20 22
1 - 3
16 - 18
MULTI
INTERFACE
SHOE

ILCE-3000K/3500J_L3
4-2
4-2. OVERALL BLOCK DIAGRAM (2/2) ( ) : Number in parenthesis ( ) indicates the division number of schematic diagram where the component is located.
: VIDEO/AUDIO SIGNAL
IC2003
REAL TIME
CLOCK,
2.7V DETECT
(14/19)
IC2002
Q2106
LED
DRIVE
IC2001
(2/2)
IC2401
S001 - S007
SE2101
HORIZONTAL/VERTICAL
POSITION DETECT
(15/19)
XDIRECT_PB
XMOVIE_REC
XPOWER_SW
XS2
XS1
XS2
XS2 XS1
XS1
XS1, XS2, XDIAL_1_A, XDIAL_1_B,
KEY_AD_CURSOR, KEY_AD_DEL, KEY_AD_MODE
CA_XRESET_OUT_IC_1001
CA_XRESET_IC_1001
CA_XRESET_IC_1001
RESET
CA_CSREQ_IC_1001, CA_RELEASE_LOCK_IC_1001,
PRE_INT, CA_FREEZE_DET, CAP_CTRL_IN,
IC_1001_CAM_NOTIFY, CA_CSDIR_IC_1001,
IC_1001_IMG_READ_CA, IC_1001_STAMINA_MODE_CA,
IC_1001_S2_REQ_CA
32KHZ
CS_RTC
VH_SENSE_1, VH_SENSE_2
ROTATE_SENS_ON
XCS_IC_2401_1
CA_XRESET_CAM
CA_1ST_CURTAIN_START,
IC_1001_1ST_CURTAIN_END
IC_1001_SI_CA, IC_1001_SO_CA, IC_1001_SCK_CA
CAM_SI_1,
CAM_SO_1,
CAM_SCK_1
CAM_SI_1,
CAM_SO_1,
CAM_SCK_1
CAM_SI_1,
CAM_SO_1,
CAM_SCK_1
D-/D+USB_DM, USB_DP
TH001
D2001
D1101
AH2
J16
A14
K14
D16
B2
08
12
1
13
6
7
CN0601
2, 3
USB_ID
4
3
8
6
XMENU
BATT_TEMP
14
13
OVERALL (1/2)
(PAGE 4-1)
1
XSD_IN_CA
SD_XSDCD
SD_SDWP
XMS_IN_CA
XMS_INS_HIZ
XSD_IN_CA
CA_XENU_USBIF, XPWR_ON
USBIF_ISET1_CA, USBIF_ISET2_CA
XMS_IN_CA
MSX_D[0-7], XMS_BS, MSX_CLK
SD_D[0-3], SD_CMD, SD_CLK
D1905
D1904
24
26
14
2, 4, 7, 8, 10,
11, 13, 16, 17, 20
1, 3, 6, 15,
21, 23
CN1901
4
5
CN3002
7
XBATT_DETECT
SY-1026 BOARD (2/2)
4.0V DETECT
(14/19)
Q2001
SLANT
SENSOR
BATTERY
DETECTOR
(17/19)
CONTROL
SWITCH
BLOCK
RL-1023 FLEXIBLE BOARD
MAIN CPU
(14/19)
A16
A15
X2001
10MHz
X2002
32.768kHz
IC0101
DC/DC
CONVERTER
(2/19)
IC0103
BUS
SWITCH
(2/19)
Q101
BUS
CONTROL
XCS_DDCS
CA_XENU_USBIF
IC0602
USB
INTERFACE
(5/19)
E2
E3
X0601
12MHz
ST-1017 FLEXIBLE BOARD (2/2)HB-1002
FLEXIBLE
BOARD
UNREG_ST
Q001
FLASH
DRIVE
IC001
XE_A
XE_K
XE_A
XE_C
D004 T001
CN3004
(2/2)
XINT_FLASH_UP_SENS
+
FLASH
CONTROL,
CHARGE
CONTROL
(1/2)
C901
CHARGING
CAPACITOR
FLASH
UNIT
D003
FLSTOP
INT_FLASH_CHARGE
INT_FLASH_TRIG
INT_FLASH_FULL
CLK, DIN, DOUT
4.0V DETECT
CANCEL
10 KEY_AD_MODE
1
2
5
4 KEY_AD_DEL
KEY_AD_CURSOR
XDIAL_1_A
XDIAL_1_B
Q2102, Q2103
LED
DRIVE
AF_LED_CNT
AF_LED_A
EVF_LCD_SW
S2
KEY_AD
S1
BATT_UNREG
BATT_SIG
BATT_GND
WHEEL_B
WHEEL_A
CN001
2
4
3
5
6
BATT_IB
BATT_UNREG
8 - 1518 - 24
3
6
CN3001
16,17
BT-2002
FLEXIBLE
BOARD
S001
POP-UP
DETECT
CA_XENU_USBIF,
USBIF_ISET1_CA,
USBIF_ISET2_CA
CAM_SI_2, CAM_SCK_2
CAM_SI_2, CAM_SO_2,
CAM_SCK_2
CA_XENU_USBIF
15
10
12
11
7
AD_JACK_IN
XPWR_ON
DEBUG_UART0_TXD/RXD
IC_1001_XRESET_REQ_CA
IC_1001_XRESET_REQ_CA
XS1
XS2
IC1001
(2/2)
PROCESSOR
(6/19 - 8/19)
XMS_ACC_LED
D1901
(ACCESS)
D001
SELF-TIMER,
SMILE SHUTTER,
AF ILLUMINATOR
S
BT901
BATTERY
TERMINAL
CHG_LED_ON
LED
DRIVE
Q0605
D0601
CHG
CA_ISET1_DD, CA_ISET2_DD,
DD_ISET1_CA, DD_ISET2_CA,
CA_CHG_ON_DD, DD_VBUSOK_CA,
DD_PGOOD_CA USB POWER
MANAGEMENT
(5/19)
IC0601
MEMORY
STICK
PRO DUO
SD
MULTI
8, 9
3
4
5
6
7
CAM_SCK_2
CAM_SO_2
CAM_SI_2
OVERALL (1/2)
(PAGE 4-1)
2

ILCE-3000K/3500J_L3
4-3
4-3. POWER BLOCK DIAGRAM (1/3) ( ) : Number in parenthesis ( ) indicates the division number of schematic diagram where the component is located.
IC_1001_LENS_4.8V_ON
IC_1001_LENS_UNREG_ON
LENS_XDETECT_CA
UNREG_CUR_MON
LCD_CABC_PWM
B+ SWITCH
SY-1026 BOARD (1/3)
BATT_IB
BT-2002
FLEXIBLE
BOARD
(1/2)
BATT_UNREG UNREG
UNREG
UNREG_SUBPOWER
A_VID,
D_VID
CN3001
(1/2)
F0001
F0002
1.125V REG
(2/19)
IC0102
DC/DC CONVERTER
(2/19)
IC0101
PVDD1a
PVDD1b
PVDD2
LX1a
LDO1_OUT
LDO1_ENB
Vout
LX1b
FB1
L0101
D_3.15V, D_3.15V_IC_1001,
D_3.15V_MEDIA, D_3.15V_PANEL,
A_ 3.15V_IC_1001,
D_3.15V_SHOE
D_3.15V, D_3.15V_PANEL,
A_3.15V_ BATT_KEY_AD
PVDD5a
PVDD5b
LX5a
LX5b
FB5
L0105
D_1.8V_IS,
D_1.8V_IC_1001,
A_1.8V_IC_1001_2
PVDD3a
PVDD3b
LX3a
LX3b
FB3
Vdd
LDO1_ON
CE
L0103
LDO2_SOURCE
D_1.2V
LX2
FB2
LPDDR2_1.2V
L0102
LDO1_SOURCE
LDO2_OUT
LDO2_ENB LDO1_ON
LDO1_ON
DD_ON_1
DD_ON_1
DD_ON_1
LPDDR2_1.8V
A_1.125V_IC_1001
3.15V REG
(4/19)
IC301
VOUTVDD
CE
DC/DC CONVERTER
(3/19)
IC0201
VOBa
VOBb
VINB
VIN
VINA
BATTERY DETECTOR
(17/19)
IC2401
CURRENT
MONITOR
(3/19)
IC0202
TxRx
EVER_3.15V
EVER_3.15V
EVER_3.15V
LENS_POWER
LENS_POWER
PVDD_CP
AVDD
ENB
POKB
POKA
VOAa
VOAb
Q0301, Q0302
D_3.15V
D_3.15V
DD_ON
B+ SWITCH
Q0205, Q0206
Q0207, Q0208
CC_POK_B CC_POK_B
ENA
DD_ON_3
CC_POK_A
DD_ON_3
CC_POK_A
UNREG_CUR_MON
CAM_5.5V, IS_5.5V
CAM_5.5V, EVF_5.5V
CAM_5.5V, IS_5.5V,
AUDIO_5.5V, EVF_5.5V
B+ SWITCH
Q0204
B+ SWITCH
Q0201 (1/2), Q0202
EVER_3.15V
LENS POWER
CONTROL
Q0201 (2/2), Q0203
REFERENCE
VOLTAGE SWITCH
UNREG_MOTOR
UNREG_MOTOR UNREG_MOTOR
F0004
BL_H
BL_L
F0003 L0301
D_3.15V
UNREG_BL LCD_CABC_PWM
VIN
LX
VOUT
EN
FB
BACKLIGHT DRIVE
(4/19)
IC0303
AUDIO_5.5V
3.1V REG
(10/19)
IC1402
Vout
VDD
CE
D_3.15V
AUDIO
INTERFACE
(10/19)
IC1401
SLANT SENSOR
SE2101
HORIZONTAL/VERTICAL
POSITION DETECT
(15/19)
POWER (3/3)
(PAGE 4-5)
D
POWER (2/3)
(PAGE 4-4)
C
POWER (2/3)
(PAGE 4-4)
B
POWER (3/3)
(PAGE 4-5)
A
F0006
UNREG_ST
UNREG_ST
08
UNREG_ST
VBUS1
USB_VCC_STD USB_VCC_STD
USB POWER
MANAGEMENT
(5/19)
L0601
D0603
VFB
VFB
SW1
VBUS2
ISNS
VBUSLIM
SW2
USB INTERFACE
(5/19)
VB1
VB2
NVP
OUT1
OUT2
VCC
SUSP
CN0601
Q0602
F0601
NEGATIVE
VOLTAGE
PROTECTOR
VBUS
Q0001, Q0002
CHARGE
SWITCH
Q0004, Q0005
FAST CHARGE
SWITCH
D0001
INIT_CHARGE_ON
CA_CHG_ON_DD
FAST_CHARGE_ON
XFORCE_UNREG_ON
XFORCE_UNREG_ON
INIT_CHARGE_ON
FAST_CHARGE_ON
Q303, Q304
UNREG SWITCH
D304 D303
IC2001
(1/2)
MAIN CPU
(14/19)
USB_VCC_STD_LIM
IC_0101_LX5
BUS SWITCH
(2/19)
IC0103
USB
DETECT
Q0601
P71/AINA1
P06
BATT_AD_IN
BATT_AD_ON
BATTERY
VOLTAGE
CHECK
Q2104
BATT_AD_IN
BATT_AD_ON
DISCHARGE_ON
Q0603
DISCHARGE
D0601
CHG
IC0602
IC0601
EVER_3.15V
XUSB_CABLE_IN
USB_VCC_STD_LIM
D_3.15V_USB
CAM_ON
CAM_ON
LDO1_ON
D_1.8V_IC_1001
USB_CHG_OUT
BATT_UNREG
BATT_SIG
BATT_GND
S
BT901
BATTERY
TERMINAL
8 - 1518 - 24
E4
A5
A6
B6
A1
A2
B1
A3
U3
H15
M17 PJ1/TB11IN1
K17 PG1/KEY01
A6PF3/KEY19
C2
U6
R8
P37/TC3IN
PI1/PHC4IN1
P20/TB1IN0
T6P07
A4
B4
C1
C6
D1
B5
C3
D3
E4
F4
E5
14
3
14
3
E1
E2
C8
D1
A5
D6
D2
D3
H5
G5
H4
G4
E3
A1
B1
A2
B2
C4
B4
B8
C5
A6
A4
E5
H2
B7
F5
6
1
5
4
3
E4
D4
B5
EN B2
A1
A2
A3
A5
D5
14
3
16, 17
PG0/KEY00
L14
PJ0/TB11IN0
N14
1
6
15
MULTI
PF4/KEY20/TCOUT4
XPWR_ON B6
nENU
C1
F500
CA_XENU_USBIF
B2
POWER (2/3)
(PAGE 4-4)
F
POWER (2/3)
(PAGE 4-4)
G

ILCE-3000K/3500J_L3
4-4
4-4. POWER BLOCK DIAGRAM (2/3) ( ) : Number in parenthesis ( ) indicates the division number of schematic diagram where the component is located.
LENS_XDETECT_CA
REAL TIME CLOCK,
2.7V DETECT
(14/19)
IC2003
VDCCVDD
VCC
4.0V DETECT
(14/19)
IC2002
OUTVDD
RESET
PG4/KEY04
P27/TB5IN1
PG3/KEY03
DD_ON_3
UNREG_MOTOR
PF2/KEY18
P02
P03
EVER_3.15V
LENS_XDETECT_CA
D2001
LENS_3.1V_ON
PH2/INT1A/TBAIN0 XPWR_OFF
MAIN CPU
(14/19) CA_XRESET_OUT_IC_1001 CA_XRESET_IC_1001
UNREG_CUR_MON
08
P75/AINB1
CC_POK_A P86/AINC6/INT8
AF_LED_CNT
AF_LED_CNT
CN3002
D_3.15V
VL_3V
VL_3V
RL-1023 FLEXIBLE BOARD
SY-1026 BOARD (2/3)
BUFFER
(16/19)
IC2302
SHUTTER CHARGE
MOTOR CONTROL
(15/19)
IC2102
EVER_3.15V
LENS_3.1V_ON
LENS REMOVE
DETECT
CN2301
CN2101
B+ SWITCH
Q2306
LED DRIVE
Q2102, Q2103
LENS_XDETECT_BODY
LENS_POWER
Q2304
Q2107,Q2108
LENS_3.1V MB N HOLDER
ASSY
MB CHARGE
UNIT
LENS_POWER
CAM_5.5V,
EVF_5.5V
POWER (1/3)
(PAGE 4-3)
B
LENS_XDETECT_CA
POWER (1/3)
(PAGE 4-3)
C
POWER (3/3)
(PAGE 4-5)
E
D2301
LENS_XDETECT_IC_1001
UNREG_ST
UNREG_MOTOR
D_3.15V, D_3.15V_PANEL
A_3.15V_ BATT_KEY_AD
D_3.15V,
D_3.15V_PANEL
A_3.15V_ BATT_KEY_AD
LENS_POWER
CAM_5.5V,
EVF_5.5V
CAM_5.5V
UNREG_ST
CA_XENU_USBIF
FLASH CONTROL,
CHARGE CONTROL
(1/2)
IC001
ST-1017 FLEXIBLE BOARD HB-1002
FLEXIBLE
BOARD
UNREG_ST
CN3004
CHARGING
CAPACITOR
D003,
D004
C901
T001
XE_A
+
FLASH
UNIT
4.0V DETECT
CANCEL
Q2001
BT001
S001
S004
TH001
LITHIUM
BATTERY
IC2001
(2/2)
L001
INB OUT
INA
SHUTTER_CHARGE_MOTOR_1
SHUTTER_CHARGE_MOTOR_2
SHUTTER_CHARGE_MOTOR_1
SHUTTER_CHARGE_MOTOR_2
CHARGE MOTOR
DRIVE
AF_LED_A
XPOWER_SW
XBATT_DETECT
BATT_TEMP
A_3.15V_ BATT_KEY_AD
CN3001
(2/2)
BT-2002 FLEXIBLE
BOARD (2/2) CN001 CONTROL
SWITCH
BLOCK
VCC_KEY_AD
XE_A
1
6
9 - 12 5 - 9
8
15 - 18
R10
K14
D16
E14
R5
K15
E7
E1
C1
U5
R4
128
10
12
14
2
12
1
4
3
6
S005
(BATTERY DETECT)
XDIRECT_PB 13
XPOWER_SW
XBATT_DETECT
BATT_TEMP
PF0/KEY16 C7
P73/INT11/AINA3 D1
P72/INT10/AINA2 D2
POWER (1/3)
(PAGE 4-3)
F
POWER (1/3)
(PAGE 4-3)
G
XDIRECT_PB
PE0/KEY08 E9
D001
SELF-TIMER,
SMILE SHUTTER,
AF ILLUMINATOR
BL_H
BL_L
CN1501
LC-1012 FLEXIBLE BOARD
CN101
CN001
3.0 INCH
COLOR
LCD
LCD901
(LCD MODULE)
EVF UNIT
LCD902
BACKLIGHT
18
39
38
7
13
36
6
RST 3
VDD 26
VDDIO 25
1
22
L101
2.5V REG
(1/2)
IC001
VOUT
VIN
CE
VDD_2.5V
34
1
5.0V REG
(1/2)
IC002
VOUT
BL_H
BL_L
CA_XRESET_IC_1001
D_3.15V_PANEL
EVF_5.5V
VIN
CE
VCC_5.0V
34
1
11, 12
ON/OFF

ILCE-3000K/3500J_L3
4-5E
4-5. POWER BLOCK DIAGRAM (3/3) ( ) : Number in parenthesis ( ) indicates the division number of schematic diagram where the component is located.
D1901
(ACCESS)
CN1901
19
12
PI_A
PI_C
CN3003
SHUTTER
UNIT
8, 9
5
3
MS_VCC
SD_VCC
CAM_5.5V
D_3.15V
IS-1007 BOARDIS-105
FLEXIBLE
BOARD
MIS-2002 FLEXIBLE
BOARD
IS-1006
FLEXIBLE
BOARD
VDDDA/
VDDVREF
VDDVREF/
DA(4.5V) VIN4VOUT3
CONTROL1
VDDCM
VDDSV
VDDCB/CN/SC/PL/LSV(1.8V)
VDDLV(1.8V)VDDLV(1.8V)
VDDSUB(4.5V)
4.5V REG
IC6001
CN6001
CN6002
CMOS
IMAGER
CP6001
VDDCB/CN/
SC/PL/LSV(1.8V)
5
10
6, 7 2, 3 23, 24 13-16
CN1301
CN1302
CN7301 CN001
5
10
6, 7 2, 3 23, 2419,20
19,20
13-16
L6002
L6001
VDDSV/CM(4.5V)
VDDSUB(4.5V)
IS_PWR_ON3
VDDVREF/DA(4.5V)
IS_5.5V
VRL(-1.5V)VRL(-1.5V)
VRH(4.4V)VRH(4.4V)
VDDSV/
CM(4.5V)
IS_PWR_ON2
B+ SWITCH
Q1302, Q1303
Q1301
B+ SWITCH
Q7302
4 3
1
4.5V REG
(9/19)
IC1301
IS_PWR_ON3
IS_PWR_ON1
D_3.15V_SHOE
EVER_3.15V
EVER_3.15V
SHOE_VDD_ON_IC_1001
D_3.15V_SHOE_SWD
4 3
1
4.5V REG
(9/19)
IC1302
EXTERNAL
FLASH I/F
(19/19)
IC7302
SY-1026 BOARD (3/3)
IC1001
GPIO_S__6 P24
XRESET
LCD_CABC_PWM
Y10 LCD_CABC_PWM
F17 DIR0B
F16 DIR0A
IC_1001_LENS_4.8V_ON
IC_1001_LENS_UNREG_ON
AE20 USB_ACV_DET
LENS_XDETECT_IC_1001
IMAGE PROCESSOR
(6/19 - 8/19)
MS_PWR_ON
A_1.125V_IC_1001
SD_VCC
AH2
DIR2B C18
DIR2A C17
IS_PWR_ON2
GPIO_S__10 M26
TPU4_OUT AK7
XPWR_OFF
IS_PWR_ON1
ND_DIR_A H18
IS_PWR_ON3
A_1.8V_IC_1001_2
D_3.15V_IC_1001
FRC_RTG_OUT2 AB10
CC_POK_B
FRC_RTG_IN1 AF10
SD_PWR_ON
A_VID
D_VID
D_1.2V
LPDDR2_1.2V
A_3.15V_IC_1001
D_3.15V_MEDIA
D_3.15V_PANEL
D_1.8V_IC_1001
LPDDR2_1.8V
D_1.8V_IS
LVDS_1.8V_IMG
FB1201
B+ SWITCH
(4/19)
IC0304
VOUT 5VIN1
EN
3
D_3.15V_MEDIA
MS_PWR_ON
SD_PWR_ON
B+ SWITCH
(4/19)
IC0305
VOUT 5VIN1
EN
3
A_VID,
D_VID
D_3.15V, D_3.15V_IC_1001,
D_3.15V_MEDIA, D_3.15V_PANEL,
A_3.15V_IC_1001,
D_3.15V_SHOE
D_1.8V_IS,
D_1.8V_IC_1001
A_1.8V_IC_1001_2
D_1.2V
LPDDR2_1.2V
LPDDR2_1.8V
A_1.125V_IC_1001
CAM_5.5V, IS_5.5V
IC_0101_LX5
POWER (1/3)
(PAGE 4-3)
A
POWER (1/3)
(PAGE 4-3)
D
CA_XRESET_IC_1001
AF_LED_CNT
ND_DIR_B
H17
BRK0B F14
POWER (2/3)
(PAGE 4-4)
E
USB_VCC_STD_LIM
D_3.15V,
D_3.15V_SHOE
08
VDDREF_ON
18 18
B- SWITCH
CHARGE
PUMP
Q1304, Q1305
D1301, D1302
Q1306, Q1307
DISCHARGE
MEMORY
STICK
PRO DUO
SD
Vin Vout
Control
Vin Vout
Control
11
B+ SWITCH
Q7301, Q7303
UNREG_ST
UNREG_ST
SHOE_UNREG_ON
UNREG
LOGIC_VDD 13
UNREG 17
6, 7
MULTI
INTERFACE
SHOE
L1302
L1301

ILCE-3000K/3500J_L3
5-1E
5. FRAME SCHEMATIC DIAGRAMS
IC2001
(Not supplied)
IC2003
(Not supplied)
IC1001
(Not supplied)
IC0304
(Not supplied)
IC0305
(Not supplied)
139
CN6002
CP6001
(Not supplied)
127
CN6001
81
CN001
114
S004
S007
(MODE DIAL)
S003
CN0601
S006
(FINDER/LCD)
S005
(BATTRY DETECT)
S001
S002
(SHUTTER)
120
1
17
16
18
CN3004
615
15
CN2101
1
2
41
38 120 124
114
CN1501 CN7301
CN3002 CN3001
126
CN1901
238
139
1
226
27
116
110
CN1301 CN1302 CN2301
CN3003
122
1
1
238
39
39
IC002
(Not supplied)
CN101
CN001
1
1
21
20
2324
CN001
(MULTI INTERFACE SHOE)
16
CN101
S001
(POP-UP DETECT)
120
BT-2002 FLEXIBLE BOARD
BT901
BATTERY
TERMINAL
CONTROL
SWITCH
BLOCK
24
1
127
127
IS-105
FLEXIBLE
BOARD
IS-1006
FLEXIBLE
BOARD
139
139
IS-1007 BOARD
(SIDE A)
IS-1007 BOARD
(SIDE B) SHUTTER
UNIT
SY-1026 BOARD
(SIDE A)
LC-1012
FLEXIBLE
BOARD
RL-1023 FLEXIBLE BOARD
SY-1026 BOARD (SIDE B)
MOVIE
MULTI
BT001
(LITHIUM BATTERY)
ON/OFF
MB N
HOLDER
ASSY
SP901
(SPEAKER)
RED
BLK
MB
CHARGE
UNIT
MIS-2002 FLEXIBLE BOARD HB-1002 FLEXIBLE BOARD
ST-1017 FLEXIBLE
BOARD
WHT
FLASH UNIT
PNK
ORG
LCD901
(LCD MODULE)
BACKLIGHT
3.0 INCH
COLOR
LCD
LCD902
(EVF UNIT)
MIC901
(MICROPHONE UNIT)
C901
CHARGING
CAPACITOR

ILCE-3000K/3500J_L3
6-1
6. SCHEMATIC DIAGRAMS AND PRINTED WIRING BOARDS
THIS NOTE IS COMMON FOR SCHEMATIC DIAGRAMS AND PRINTED WIRING BOARDS.
(In addition to this, the necessary note is printed in each block.)
For Schematic Diagrams
• All capacitors are in μF unless otherwise noted. pF : μμF. 50 V
or less are not indicated except for electrolytics and tantalums.
• Chip resistors are 1/10 W unless otherwise noted.
kΩ=1000 Ω, MΩ=1000 kΩ.
• Caution when replacing chip parts.
New parts must be attached after removal of chip.
Be careful not to heat the minus side of tantalum capacitor,
Because it is damaged by the heat.
• Some chip part will be indicated as follows.
Example C541 L452
22U 10UH
TA A 2520
Kinds of capacitor External dimensions (mm)
Case size
• Constants of resistors, capacitors, ICs and etc with XX indicate
that they are not used.
In such cases, the unused circuits may be indicated.
• Parts with ★differ according to the model/destination.
Refer to the mount table for each function.
• All variable and adjustable resistors have characteristic curve
B, unless otherwise noted.
• Signal name
XEDIT → EDIT PB/XREC →PB/REC
•: non flammable resistor
• : fusible resistor
• : panel designation
• : B+ Line
• : B– Line
• : IN/OUT direction of (+, –) B LINE.
• : adjustment for repair.
For Printed Wiring Boards
• : Uses unleaded solder.
•: Circuit board
: Flexible board
Pattern from the side which enables seeing.
: pattern of the rear side
(The other layers’ patterns are not indicated)
• Through hole is omitted.
• There are a few cases that the part printed on diagram isn’t
mounted in this model.
• : panel designation
• Chip parts.
Transistor Diode
21
3
21
3
21
3
345
21
123
654
EB
C
31
5
2
46
123
654
31
5
2
46
123
54
43
12
312
45
534
12
14
23
46
2
5
31
12
43
14
23
Precautions for Replacement of Imager
• If the imager has been replaced, carry out all the adjustments
for the camera section.
• As the imager may be damaged by static electricity from its
structure, handle it carefully like for the MOS IC.
In addition, ensure that the receiver is not covered with dusts
nor exposed to strong light.
When indicating parts by reference
number, please include the board name.
The components identified by mark 
or dotted line with mark are critical
for safety.
Replace only with part number specified.
Les composants identifiés par une
marque sont critiques pour la sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.

ILCE-3000K/3500J_L3
6-2
6-1. SCHEMATIC DIAGRAMS
IS-105
FLEXIBLE
LND101
(PAGE 6-3)
IS-1006
FLEXIBLE
LND101
(PAGE 6-3)
Note: All mounted parts and IS-1007 COMPLETE BOARD are not supplied,
but they are included in MECHA DEVICE (1100) (SERVICE).
123456789
A
B
C
D
E
F
A
B
C
D
E
F
08
IS-1007 BOARD
CMOS IMAGER
XX MARK: NO MOUNT
DOM00
DOP01
DOM01
DOP02
DOM02
DOP03
DOM03
DCKP
DCKM
DOP04
DOM04
DOP05
DOM05
DOP06
DOM06
DOP07
DOM07
DOM04
DOP05
DOP00
DOM00
DOP01
DOM01
DOP02
DOM02
DOP03
DOM03
DOP04
DCKP
DCKM
DOM05
DOP06
DOM06
DOP07
DOM07
DOP00
SCK SDI XCE
XCLR
SDO
SCK
SDI
XCE
XPI
XHS
XVS
XPI
XCLR
XVS
XHS
SDO
VDDCM
VDDSV
VDDSV
VDDSUB
VDDSUB
VDDSUB
VRL
VRL
VRL
VRH
VRH
VRH
VDDLV
VDDDA/VDDVREF
VDDDA/VDDVREF
VDDCN/SC/PL/VDDCB/LSV
VDDCN/SC/PL/VDDCB/LSV
VDDCN/SC/PL/VDDCB/LSV
VDDCN/SC/PL/VDDCB/LSV
C6005 XX
C6032 XX
C6033 XX
C6049 XX
C6007 0.1u
C6020 XX
C6031 0.1u
C6025 0.1u
C6035
0.1u
C6042 0.022u
C6004
4.7u
C6029 0.1u
C6030
4.7u
C6023 0.1u
C6024
4.7u
C6053
0.1u
C6011 XX
C6010 XX
C6054 1u
C6055
0.33u
C6009 0.01u
C6014
4.7u
C60150.1u
C6018
4.7u
C6056 XX
C6057
XX
C60190.1u
C6013
4.7u
C6012 0.1u C6016 0.1u
C6017
4.7u
C6037 10u C6041 4.7u C6040 0.1u
C6036 0.1u
C6003
4.7u
C6006 0.1u
C6028 0.1u C6027 10u
C6039 0.1u C6038 10u
C6048 4.7u
C6043 0.1u
C6022 XX C6021 XX
C6046 XX C6051 XX
C6001
XX
C6008
XX
C6047 0.1u
C6002
XX
C6052 4.7u
C6045 0.1u C6050 4.7u
C6044 XX
C6034
22u 10V
CL6007
CL6008 CL6009
CL6010
CL6001
CL6005 CL6006 CL6002 CL6003 CL6004
CN6002 39P
1GND
2XVS
3XHS
4GND
5 VDDVREF_ON
6XPI
7XCE
8SDI
9SCK
10 SDO
11 XCLR
12 LVDSGND
13 DOP00
14 DOM00
15 LVDSGND
16 DOP01
17 DOM01
18 LVDSGND
19 DOP02
20 DOM02
21 LVDSGND
22 DOP03
23 DOM03
24 LVDSGND
25 DCKP
26 DCKM
27 LVDSGND
28 DOP04
29 DOM04
30 LVDSGND
31 DOP05
32 DOM05
33 LVDSGND
34 DOP06
35 DOM06
36 LVDSGND
37 DOP07
38 DOM07
39 LVDSGND
C4
VDDSC7
D1
NC
D2
VRH1
D3
VSSSC8
D4
VSSSC7
E1
NC
E2
VRL1
E3
NC
E4
NC
F2
NC
F1
NC
G4
NC
L2
NC
G1
VDDSUB1
F4
NC
F3
NC
G2
NC
G3
NC
H1
NC
H2
VDDSV
H3
VSSSV
H4
NC
J1
NC
J2
VDDSV
K2
NC
K1
VDDSUB2
L1
AMON2
K4
NC
K3
NC
J3
VSSSV
J4
NC
N1
NC
M1
AMON1
M2
VBIAS
L3
NC
L4
NC
P2
VSSDA
M4
NC
N3
VDDVREF
M3
NC
N2
VDDDA
T4
EXRES
R4
NC
P3
VSSVREF
R3
V124V
P4
VDDLV1
N4
VSSLV
T5
DOP00
R5
DOM00
P5
DOP01
N5
DOM01
T6
DOP02
R6
DOM02
M6
NC
M5
VDDSC1
P6
DOP03
N6
DOM03
L7
NC
M7
NC
T7
DCKP
R7
DCKM
T8
DOP04
R8
DOM04
M9
VDDSC2
M8
NC
P8
DOP05
N8
DOM05
T9
DOP06
R9
DOM06
P9
DOP07
N9
DOM07
T10
NC
R10
NC
R11
INCK
P11
VSSPL
P10
VDDLV2
N10
VSSLV
N12
VDDSC3
M11
NC
N11
VDDPL
M10
NC
P12
VSSSC3
L10
VDDCB1
L11
VSSCB1
M12
NC
M13
NC
L12
NC
L13
NC
K11
VSSCB2
K12
NC
K10
VDDCB2
K13
VSSCN
J10
VDDCM
J11
VSSCM
J12
NC
J13
VDDCN
H10
VDDCM
H11
VSSCM
H12
NC
H13
VDDCN
G11
VSSCB3
G12
NC
F11
VSSCB4
F10
VDDCB4
G13
VSSCN
G10
VDDCB3
N13
NC
F13
NC
F12
NC
E10
NC
E11
NC
E12
NC
E13
NC
D10
VSSSC5
D11
VSSSC4
D12
NC
D13
NC
C10
VDDSC5
C11
VDDSC4
C12
NC
B11
VDSUN
B9
NC
B10
NC
A10
VDWH
A9
VRL2
A8
VRH2
C9
XCLR
D9
SCK
E9
SDI
D8
SDO
E8
TOUT
C8
XCE
B7
NC
A7
VCOMB
D7
VSSSC6
B8
NC
C7
VDDSC6
E7
NC
F7
NC
B6
NC
C6
XHS
D6
XVS
E6
TENABLE
E5
ID
D5
XPI
C5
TSCANEN
A6
VDDSUB3
A5
NC
A4
VLOAD
B4
NC
B5
NC
B3
VDDLSV
C2
NC
C3
VDDSC8
C1
NC
B2
NC
A3
NC
A11
NC
B12
NC
C13
NC
P13
NC
R12
NC
T11
NC
T3
NC
R2
NC
P1
NC
N7
VSSLV
P7
VSSLV
F5
NC
F6
NC
F8
NC
F9
NC
L9
VSSSC2
L8
NC
L6
NC
L5
VSSSC1
B1
NC
A2
NC
A12
NC
B13
NC
R13
NC
T12
NC
T2
NC
R1
NC
IC6002
XX
1
CONTROL
2
GND VOUT
3
VIN
4
IC6001
MM3416A45URE
4.5V REG
1
CONTROL
2
GND
VOUT
3
VIN
4
L6001
10uH
L6002
10uH
Q6002
XX
Q6001
XX
R6003
XX
R6006 XX
R6002
22k
R6004
XX
R6005
XX
R6016
XX
R6013
XX
R6014
XX
R6008 XX
R6007
XX
R6001 1k
R6010 XX
R6009 XX
R6011
XX
R6015
XX
TH6001
X6001
54MHz
1
4
3
2
CN6001 27P
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
C6059
XX
R6017 XX
C6060
XX
C6062
4.7u
C6063
XX
C6064
XX
C6065 XX
D6001
DZ37068D0L
3
2
1
R6012
XX
C6026
22u 6.3V
C6058
22u 6.3V
VDDLV(1.8V)
VDDLV(1.8V)
REG_GND
REG_GND
VRH(4.4V)
REG_GND
VRL(-1.5V)
REG_GND
IMG_TEMP1
REG_GND
REG_GND
VDDCB/CN/
SC/PL/LSV(1.8V)
VDDSV/CM(4.5V)
REG_GND
VDDSV/CM(4.5V)
VDDVREF/DA(4.5V)
REG_GND
REG_GND
REG_GND
VDDCB/CN/
SC/PL/LSV(1.8V)
REG_GND
REG_GND
VDDCB/CN/
SC/PL/LSV(1.8V)
VRH(4.4V)
VDDCB/CN/
SC/PL/LSV(1.8V)
VDDVREF/DA(4.5V)
VDDSUB(4.5V)
CP6001
IMX156AQL-13
CMOS IMAGER

ILCE-3000K/3500J_L3
6-3
SY-1026
(9/19)
CN1302
(PAGE 6-12)
IS-1007
CN6002
(PAGE 6-2)
12 3 4
A
B
C
D
E
F
A
B
C
D
E
F
08
IS-1006 FLEXIBLE BOARD
SY-IS CONNECTION
(PRINTED WIRING BOARD is omitted.)
LND101 39P
1GND
2 XVS
3 XHS
4GND
5 VDDVREF_ON
6 XPI
7 XCE
8 SDI
9 SCK
10 SDO
11 XCLR
12 LVDSGND
13 DOP00
14 DOM00
15 LVDSGND
16 DOP01
17 DOM01
18 LVDSGND
19 DOP02
20 DOM02
21 LVDSGND
22 DOP03
23 DOM03
24 LVDSGND
25 DCKP
26 DCKM
27 LVDSGND
28 DOP04
29 DOM04
30 LVDSGND
31 DOP05
32 DOM05
33 LVDSGND
34 DOP06
35 DOM06
36 LVDSGND
37 DOP07
38 DOM07
39 LVDSGND
LND00139P
1GND
2XVS
3XHS
4GND
5VDDVREF_ON
6XPI
7XCE
8SDI
9SCK
10SDO
11XCLR
12LVDSGND
13DOP00
14DOM00
15LVDSGND
16DOP01
17DOM01
18LVDSGND
19DOP02
20DOM02
21LVDSGND
22DOP03
23DOM03
24LVDSGND
25DCKP
26DCKM
27LVDSGND
28DOP04
29DOM04
30LVDSGND
31DOP05
32DOM05
33LVDSGND
34
DOP06
35DOM06
36LVDSGND
37DOP07
38DOM07
39LVDSGND
SY-1026
(9/19)
CN1301
(PAGE 6-12)
IS-1007
CN6001
(PAGE 6-2)
12 3 4
A
B
C
D
E
F
A
B
C
D
E
F
08
IS-105 FLEXIBLE BOARD
SY-IS CONNECTION
(PRINTED WIRING BOARD is omitted.)
LND101 27P
1 REG_GND
2 VDDSV/CM(4.5V)
3 VDDSV/CM(4.5V)
4 REG_GND
5 REG_GND
6 VDDVREF/DA(4.5V)
7 VDDVREF/DA(4.5V)
8 REG_GND
9 REG_GND
10 VDDSUB(4.5V)
11 REG_GND
12 REG_GND
13 VDDCB/CN/SC/PL/LSV(1.8V)
14 VDDCB/CN/SC/PL/LSV(1.8V)
15 VDDCB/CN/SC/PL/LSV(1.8V)
16 VDDCB/CN/SC/PL/LSV(1.8V)
17 REG_GND
18 VRL(-1.5V)
19 VRH(4.4V)
20 VRH(4.4V)
21 REG_GND
22 REG_GND
23 VDDLV(1.8V)
24 VDDLV(1.8V)
25 REG_GND
26 REG_GND
27 IMG_TEMP1
LND00127P
1GND
2VDDSV/CM(4.5V)
3VDDSV/CM(4.5V)
4GND
5GND
6VDDVREF/DA(4.5V)
7VDDVREF/DA(4.5V)
8GND
9GND
10VDDSUB(4.5V)
11GND
12GND
13VDDCB/CN/SC/PL/LSV(1.8V)
14VDDCB/CN/SC/PL/LSV(1.8V)
15VDDCB/CN/SC/PL/LSV(1.8V)
16VDDCB/CN/SC/PL/LSV(1.8V)
17GND
18VRL(-1.5V)
19VRH(4.5V)
20VRH(4.5V)
21GND
22GND
23VDDLV(1.8V)
24VDDLV(1.8V)
25GND
26GND
27IMG_TEMP1
Pin
1
2
3
25
26
27
Pin
1
2
3
25
26
27

ILCE-3000K/3500J_L3
6-4
123456789
A
B
C
D
E
F
A
B
C
D
E
F
08
SY-1026 BOARD (1/19)
BATTERY IN
XX MARK: NO MOUNT
BATT_GND
UNREG_MOTOR
GND_MOTOR
UNREG_SUBPOWER
F0001
2.5A/32V
UNREG
COM002
REG_GND
F0003
1A/36V
UNREG_BL
COM001
USB_CHG_OUT
F0002
3.15A/24V
Q0002
RN1104MFV(TL3S
Q0001
TPC6604
1
2
34
5
6
D0001
1SS400SMGJT2R
R0001
8.2
INIT_CHARGE_ON
R0002
1k
R0003
4700
FAST_CHARGE_ON
R0004
100k
F0004
1.6A/36V
R0005
XX
COM004
UNREG_ST
F0006
1.6A/36V
Q0005
RN1104MFV(TL3S
BATT_UNREG
Q0004
QS8J2FU7TR
8
7
2
1
6
5
4
3
GND_ACC
COM003
Q0001,Q0002
CHARGE SWITCH
Q0004,Q0005
FAST CHARGE
SWITCH

ILCE-3000K/3500J_L3
6-5
E
E
S
E
123456789
A
B
C
D
E
F
A
B
C
D
E
F
08
SY-1026 BOARD (2/19)
DC/DC CONVERTER
XX MARK: NO MOUNT
C0108
0.1u
C0109
XX
C0102
1u
C0106
1u
C0103
1u
C0112
XX
C0107
1u
C0110
XX
CL0105
CL0106
CL0107
DD_ON_1
LDO1_ON
REG_GND
UNREG
D_1.8V_IC_1001
A_VID
D_VID
D_3.15V
LPDDR2_1.2V
LPDDR2_1.8V
IC0101
BD8330AGU-E2
DC/DC CONVERTER
H2
PVDD_CP
G2
CP_OUT
G1
CFP
F1
CFN
F2
PGND_CP
D6
LDO1_ENB
A5
LDO1_OUT
A6
LDO1_SOURCE
E5
LDO2_ENB
A4
LDO2_OUT
B4
3 1
4 2
LDO2_SOURCE
F7
PGND6b
F8
PGND6a
E7
LX6b
E8
LX6a
D7
PVDD6b
D8
PVDD6a
G3
PGND5b
H3
PGND5a
G4
LX5b
H4
LX5a
G5
PVDD5b
H5
PVDD5a
G8
PGND4
H7
LX4
H6
PVDD4
B3
PGND3b
A3
PGND3a
B2
LX3b
A2
LX3a
B1
PVDD3b
A1
PVDD3a
A7
PGND2
B8
LX2
C8
PVDD2
C3
SLOPE1
C2
PGND1b
C1
PGND1a
D2
LX1b
D1
LX1a
E2
PVDD1b
E1
PVDD1a
D3
FB1
C5
FB2
C4
FB3
E4
FB4
E3
FB5
D5
FB6
F4
VO_SEL
B6
AGND
F3
VREG_5.0V
C7
VREG_3.0V
C6
VREF_BG
B7
AVDD
H1
TEST1
H8
TEST2
A8
TEST3
F5
DD_ON
B5
ROSC
G6
CS
G7
CLK
F6
DIN
E6
DOUT
R0109 XX R0110 XX R0107 XX R0108 XX
C0118
10u
C0119
10u
C0120
10u
C0121
10u
R0112
XX
R0113
XX
C0124
4.7u
C0123
4.7u
A_1.125V_IC_1001
D_1.8V_IS
D_3.15V_IC_1001
D_3.15V_MEDIA
R0135 XX
R0104
47k
R0134 XX
R0111
XX
IC0102
RP109L111DA-TR
1.125 REG
1
Vout
2
GND
3
CE
4
Vdd
A_3.15V_IC_1001
A_1.8V_IC_1001
D_3.15V_PANEL
C0105
0.1u
D_3.15V_ACC
IC_0101_LX5
C0111
1u
C0113
2.2u
C0114
2.2u
C0115
2.2u
C0116
2.2u
COM102
COM122
COM123
COM125
COM126
COM127
COM128
COM129
COM130
COM131
COM132
COM133
COM101
COM121
R136
XX
R137
XX
R0115
XX
R138
XX
R139
XX
R140
XX
L0102 4.7uH
L0103
4.7uH
L0101
4.7uH
L0105
4.7uH
A_3.15V_BATT_KEY_AD
COM134
COM135
A_1.8V_IC_1001_2
CAM_SO_1
CAM_SI_1
IC0103
TC7MBL6125SFK(EL)
BUS SWITCH
1
XOE1
2
A1
3
A2
4
A3
5
A4
6
XOE4
7
GND
8
XOE3
9
B4
10
B3
11
B2
12
B1
13
XOE2
14
VCC C125
0.1u
RB0101
1M
12 34 56 78
XCS_DD
CAM_SCK_1
Q101
SSM3K15AMFV,L3SF
BUS CONTROL
EVER_3.15V
CA_XENU_USBIF
C0104
0.1u
C0117
1u
D_1.2V
COM136
D_3.15V_SHOE

ILCE-3000K/3500J_L3
6-6
S
E
123456789
A
B
C
D
E
F
A
B
C
D
E
F
08
SY-1026 BOARD (3/19)
DC/DC CONVERTER, LENS POWER
XX MARK: NO MOUNT
IS_5.5V
LENS_POWER
CL0201
C0205
XX
UNREG_CUR_MON
CC_POK_A
C0204
XX
DD_ON_1
C0201
10u
IC_1001_LENS_UNREG_ON
R0227
100
IC_1001_LENS_4.8V_ON
REG_GND
C0203
10u
IC0201
AN30235A-PL
DC/DC CONVERTER
E6
FBA
D3
POKA
D5
VREF
C5
VREG3
D6
VREG5
C4
AGND
C3
POKB
B6
FBB
A2
PGB
A4
VOBa
B4
VOBb
A5
BSB2
A3
LXB2a
B3
LXB2b
B1
LXB1a
B2
LXB1b
C2
BSB1
C1
VINB
D4
DGND
B5
ENB
F6
TP4
A6
TP3
A1
TP2
F1
TP1
E5
ENA
C6
VIN
D1
VINA
D2
BSA1
E1
LXA1a
E2
LXA1b
E3
LXA2a
F3
LXA2b
F5
BSA2
E4
VOAa
F4
VOAb
F2
PGA
DD_ON_3
UNREG_SUBPOWER
LENS_XDETECT_CA
CC_POK_B
CAM_5.5V
R0212
680k
R0211
220k
R0228
XX
R0218
68k
R0207
100k
R0209
68k
R0213
680k
C0202
0.1u
EVER_3.15V
R0202
100k
Q0204
QS8J2FU7TR
B+ SWITCH
87
2
1
65
4
3
IC0202
NJM12904RB1(TE2)
CURRENT MONITOR
1
Aout
2
A-in
3
A+in
4
GND
5
B+in
6
B-in
7
Bout
8
V+
R0210
100k
R0203
0.05
R0215
39k
R0216
10k
R0219
15k
AUDIO_5.5V
R0201
1M
R0206
100k
D0201 XX
R0231
XX
R0208 68k
Q0206
LSK3541FS8T2L
C0212
47u
C0215
22u
C0213
22u
C0206
0.1u
1
2
3
4
C0207
0.1u
1
2
3
4
C0211
1u
C0210 1u
Q0203
MTM8612709S0
REFERENCE
VOLTAGE SWITCH
1
3
4
2
5
6
C0216
0.1u
12 34
Q0201
LM6K1FS8T2R
B+ SWITCH,
REFERENCE
VOLTAGE SWITCH
6
1
5
2
4
3
Q0208
LM6K1FS8T2R
6
1
5
2
4
3
Q0207
FC6943010R
6
1
5
2
4
3
R0232
100k
C0217
0.1u
Q0202
RW1C025ZPT2CR
1
3
4
2
5
6
Q0205
QS8J2FU7TR
8
7
2
1
6
5
4
3
COM228
COM229
COM230
L0202
4.7uH
L0201
4.7uH
R0221
100k
R0222
100k
R237
XX
R238
XX
RB201
1M
1
2
3
4
5
6
7
8
RB202
10k
1
2
3
4
5
6
7
8
COM231COM232
EVF_5.5V
COM233
COM234
Q0207, Q0208
LENS POWER CONTROL
Q0205, Q0206
B+ SWITCH
3
1
4
2

ILCE-3000K/3500J_L3
6-7
Note: IC0304 and IC0305 are not supplied, but they are included
in SY-1026 COMPLETE BOARD (SERVICE).
S
123456789
A
B
C
D
E
F
A
B
C
D
E
F
08
SY-1026 BOARD (4/19)
REGULATOR
XX MARK: NO MOUNT
C0301
1u
D_3.15V
CAM_ON
EVER_3.15V
R0302
220k
R0303
XX
Q0302
RN1104MFV(TL3S
C0304
4.7u
C0307
2.2u
BL_L
C0309
0.1u
D0302
XX
LCD_CABC_PWM
C0308
1u
UNREG_BL
R0304
10
BL_H
SD_PWR_ON
C0311
XX
MS_PWR_ON
MS_VCCD_3.15V_MEDIA
R0308
10k
IC0305
BD2224G-BZTR
1
VIN
2
GND
3
EN
4
/OC
5
VOUT
IC0304
BD2224G-BZTR
1
VIN
2
GND
3
EN
4
/OC
5
VOUT
C0310
1u
REG_GND
Q0301
RW1A020ZPFU7
1
3
4
2
5
6
IC0303
RT9292DGJ6
BACKLIGHT DRIVE
1
LX
2
GND
3
FB EN
4
VOUT
5
VIN
6
RB301
100k
12 34 56 78
USB_VCC_STD
R309
470k
UNREG
D303
RB520SM-30T2R
D304
RB520SM-30T2R
XFORCE_UNREG_ON
Q303
EM6M2T2R
6
2
1
3
5
4
Q304
RW1A020ZPFU7
1
3
4
2
5
6
REG_GND
IC301
RP173K301D-TR
3.15V REG
1
VOUT
2
GND
3
CE
4
VDD
5
L0301 33uH
SD_VCC
COM301
Q303, Q304
UNREG SWITCH
Q0301, Q0302
B+ SWITCH
B+ SWITCH
B+ SWITCH

ILCE-3000K/3500J_L3
6-8
Note: CN0601 is not supplied, but this is included in
SY-1026 COMPLETE BOARD (SERVICE).
S
123456789
A
B
C
D
E
F
A
B
C
D
E
F
08
SY-1026 BOARD (5/19)
USB INTERFACE
XX MARK: NO MOUNT
EVER_3.15V
Q0601
RN1104MFV(TL3S
USB DETECT
C0621
XX
R0604
47k
R0608
XX
USB_DM
DD_ISET1_CA
C0605
10u
LF0601
XX
3
1
24
R0606
47k
CA_XENU_USBIF
C0603
4.7u
EVER_3.15V
R0602
0.1
REG_GND
USB_VCC_STD_LIM
USB_DP
R0616 XX
DD_ISET2_CA
USB_ID
CA_CHG_ON_DD
XUSB_CABLE_IN
C0612
0.1u
DD_PGOOD_CA
C0608
0.1u
R0622
1M
C0610
10u
Q0602
RW1C025ZPT2CR
NEGATIVE
VOLTAGE PROTECTOR
1
3
4
2
5
6
IC0602
IC MAX14599EEWV+TG1A
USB INTERFACE
E1
GND1
E6
GND2
B1
Vcc
B5
TEST
C3
nSUS
E3
XIN
E2
XOUT
C4
REG33
A4
LD
B3
ISET2
B4
ISET1
C5
I500
A2
OUT2
A1
OUT1
C2
nDI2C
D3
nINT
D2
SDA
D1
SCL
B2
F500
E4
ADP
D4
ADN
E5
TDP
D5
TDN
A5
VB1
A6
VB2
B6
IC_1001
C6
CDN
D6
CDP
A3
SUSP
C1
nENU
C0602
0.1u
R0615 XX
C0606
0.1u
USB_CHG_OUT
R0633
100
DD_VBUSOK_CA
IC0601
BD8668GW-E2
USB POWER
MANAGEMENT
E2
GND
D2
INDEX/GND
C1
FSET
B1
ICOMP
D3
VCOMP
D1
GND
D4
VFB
E4
VFB
C5
PGND
E3
GND
D5
SW2
B5
SW1
A5
VBUSLIM
A3
ISNS
A2
VBUS2
A1
VBUS1
B4
VBUSOK
B2
EN
A4
PGOOD
E1
ACLEN
C2
ISETIN1
C3
ISETIN2
B3
ISETIN3
E5
ISETOUT1
C4
ISETOUT2
C0601
0.1u
R0605
180
D0603
RB070M-30FJTR
CL0601
CL0602
CL0605
CL0606
Q0605
RN1102MFV(TL3S
LED DRIVE
R0610
1k
CHG_LED_ON
D0601
SML-D12Y8WT86SP
R0649 XX
R0650 XX
CL0607
R0655
6800
USBIF_ISET1_CA
USBIF_ISET2_CA
CA_ISET1_DD
CA_ISET2_DD
X0601
12MHz
C0624 10p
C0625 10p
R0663
XX
CL0604
R0603
470k
C0604
10u
USB_VCC_STD
R0664
XX
R0665
XX
D0605
XX
F0601
2A/36V
Q0603
RN1102MFV(TL3S
DISCHARGE
R0607
2200
DISCHARGE_ON
UNREG_MOTOR
L0601
4.7uH
CN0601 15P
1
VBUS
2
D-
3
D+
4
USB_ID
5
GND
6
D_3.1V/LANC_DC
7
XRESET_REQ
8
UART_TX/LANC_SIG
9
UART_RX/BOOT_IN
10
AD_JACK_IN
11
LINEOUT_R/XAE_LOCK_SW
12
LINEOUT_L/XSHUT_SW
13
VIDEO
14
AV_GND
15
XPWR_ON XPWR_ON
XS2
XS1
AD_JACK_IN
DEBUG_UART0_TXD
DEBUG_UART0_RXD
IC_1001_XRESET_REQ_CA
D_3.15V_USB
C0611
XX D0602
XX
R0611
XX
R0609
XX
Q0604
XX
1
2
6
4
5
3
R0601 XX
USB_D3.15V_ON
D_3.15V D_3.15V_USB
Q0606
XX
R0612
XX
R0613
XX
VDR601
XX
VDR602
XX
CL0608
CL0609
R0666 XX
COM601
COM602
COM603
CHG
MULTI
31
42
