Sony ILCE-6000 User manual

Camera
Lens Compatibility Sony E-mount, (Sony A-mount, Minolta/Konica Minolta Maxxum lenses conrmed
via optional LA-EA adaptor)
Lens Mount Sony E-mount
Camera Type Mirrorless DSLR
Imaging Sensor
Imaging Sensor Exmor™ APS HD CMOS sensor (23.5 X 15.6mm)
Processor BIONZ X™ image processor
Anti Dust Charge protection coating on Optical Filter and ultrasonic vibration mechanism
Pixel Gross Approx. 24.7 megapixels
Eective Picture Resolution Approx. 24.3 megapixels
Focal Length Conversion Factor 1.5x
Color Filter System RGB primary color
Recording
Media Type SD, SDHC and SDXC memory card
Memory Stick PRO Duo™/Pro-HG Duo™ media
Color Space
Still: sRGB standard (with sYCC gamut), Adobe RGB
Movie: xvYCC standard (x.v.Color™ when connected via HDMI cable)
Compatible with TRILUMINOS™ color
Still Image Mode RAW, RAW JPEG, JPEG Fine, JPEG Standard
Still Image Max Eective Resolution 24.3M pixels (approx.)
Still Image Size 16:9
L: 6000 x 3376 (20M)
M: 4240 x 2400 (10M)
S: 3008 x 1688 (5.1M)
Still Image Size 3:2
L: 6000 x 4000 (24M)
M: 4240 x 2832 (12M)
S: 3008 x 2000 (6.0M)
Panorama Still Image Size
Wide: Horizontal 23M (12,416 x 1,856),
Wide: Vertical 12M (5,536 x 2,160),
Standard: Horizontal 15M (8,192 x 1,856),
Standard: Vertical 8.4M (3,872 x 2,160)
Video Format AVCHD Ver. 2.0 / MP4 (MPEG-4 AVC (H.264))
Video Mode
AVCHD:
PS - 1920x1080/60p @28Mbps
FX - 1920x1080/60i @24Mbps
FH - 1920x1080/60i @17Mbps
FX - 1920x1080/24p @24Mbps
FH - 1920x1080/24p @17Mbps
MP4:
HD - 1440x1080/30fps @12Mbps,
VGA - 640x480/30fps @3Mbps
Audio Format Dolby Digital (AC-3) / MP4: MPEG-4 AAC-LC, 2ch
Still Image File Format JPEG (DCF Ver. 2.0, Exif Ver.2.3, MPF Baseline compliant), RAW (Sony ARW 2.3
format)
Viewnder
Type 0.39" (1.0 cm) OLED electronic viewnder (color), 1,440,000 dots
ILCE-6000/B
Mirrorless DSLR camera
Specications

Diopter Adjustment -4.0 to +3.0m-1
Field of View 100% (approx. 33° vewing angle)
Magnication Approx. 1.07x (35mm camera equivalent: Approx. 0.70x) with 50mm lens at innity,
-1m-1 diopter
LCD Display
LCD Type 3.0" TFT LCD (921,600 dots)
Angle Adjustment Tilt up by approx. 90 degrees, down by approx. 45 degrees
Brightness Control Auto, Manual (5 steps between -2 and +2), Sunny Weather mode
Coverage 100%
Live View Continuous Live View
Real-time image adjustment display Yes (On/O)
Histogram Yes (On/O)
Peaking Yes (Level setting: High/Mid/Low/O, Color: White/Red/Yellow)
Grid Display Yes (Rule of Thirds, Square 4x6, Diagonal Square 4x4, O)
Customization Graphic Display, Display All Info, No Disp. Info, Histogram, For viewnder
Zebra Yes (levels 70, ,75, 80, 85, 90, 95, 10, 100+, o)
Focus Control
Focus System Fast Hybrid AF(phase-detection AF/contrast-detection AF)
Focus Points 179 points (phase-detection AF)
25 points (contrast-detection AF)
AF Modes AF-A (Automatic AF), AF-S (Single-shot AF), AF-C ( Continuous AF), DMF (Direct
Manual Focus), Manual Focus
Focus Area Wide (179 points phase-detection AF, 25 points contrast-detection AF), Zone,
Center-weighted, Flexible Spot (Small, Medium, Large)
Focus Sensitivity EV0 to EV20 (ISO100 equivalent with F2.8 lens attached)
Focus Features
Lock-on AF, Eye AF, Predictive control, Focus lock, AF illuminator (with Built-in
LED type) Approx. range; 0.3- approx. 3.0m (with E PZ 16-50mm F3.5-5.6 OSS lens
attached)
AF Illuminator Built-in LED, Range: approx. 3' 4” - 9' 9” (0.3m-3.0m)
Exposure System
Picture Eect(s)
13 modes: Posterization (Color, B/W), Pop Color, Retro Photo, Partial Color (R, G,
B, Y), High Contrast Monochrome, Toy Camera, So High-key, So Focus, HDR
Painting, Rich-tone Monochrome, Miniature, Watercolor, Illustration
Auto Exposure Lock Yes with AE lock button (AE also locked when shuter button is halfway: Auto/On/
O selectable)
Color Temperature 2500 to 9900K Color Filter (G7 to M7: 15-steps, A7 to B7: 15-steps)
Creative Style
Standard, Vivid, Neutral, Clear, Deep, Light, Portrait, Landscape, Sunset, Night
Scene, Autumn leaves, Black White, Sepia, Style Box(1-6),
(Contrast (-3 to +3 steps), Saturation (-3 to +3 steps), Sharpness (-3 to +3 steps))
D-Range Optimizer O, Dynamic Range Optimizer (Auto/Level (1-5)), Auto High Dynamic Range (Auto
Exposure Dierence, Exposure Dierence Level (1-6 EV, 1.0 EV step))
Exposure Bracketing
Cont. Bracket: x3 or x5 image in 1/3 EV, 1/2 EV, 2/3 EV, 1.0 EV, 2.0 EV, 3.0 EV
increments,
Single Bracket: x3 or x5 image in 1/3 EV, 1/2 EV, 2/3 EV, 1.0 EV, 2.0 EV, 3.0 EV
increments,
White Balance Bracket: Low (LO), high (HI)
DRO Balance Bracket: Low (LO), high (HI)
Exposure Compensation Still images: ±5.0 EV(1/3EV, 1/2EV steps selectable)
Movies: ±2.0 EV(1/3EV steps selectable)
Exposure Settings iAUTO, Superior Auto, Programmed AE (P), Aperture priority (A), Shutter priority (S),
Manual (M), Memoru Recal (MR), Sweep Panorama, Scene Selection, Movie
ISO
Stills: ISO 100-25,600 selectable in 1/3 EV steps,
Still Auto: ISO 100-25,000 selectable upper and lower limit,
Movies: ISO 100-12,800 selectable in 1 EV steps,
Movie Auto ISO 200-12,800 selectable upper and lower limit
Metering Advanced 1200-zone evaluative metering

Metering Modes Multi-segment, Center-weighted, Spot
Metering Sensitivity EV 0 to 20 EV (at ISO100 equivalent, with F2.8 lens attached)
Noise Reduction Long exposure NR: On/O, available at shutter speeds longer than 1 sec., High ISO
NR: Normal/Low/O selectable, Multi-frame NR: Auto/ISO 100 to 51200
Scene Mode(s) Portrait, Landscape, Macro, Sports Action, Sunset, Night Portrait, Night View, Hand-
held Twilight, Anti Motion Blur
White Balance Mode
Auto WB, Daylight, Shade, Cloudy, Incandescent, Fluorescent (Warm White, Cool
White, Day White, Daylight), Flash, Color Temperature (2500 to 9900K) Color Temp.
Filter (G7 to M7: 15-steps, A7 to B7: 15-steps), Custom, Underwater Auto
Drive System
Continuous Shooting Speed Continuous mode: 11fps (hi), 6fps (mid), 2.5fps (low) with AF
Drive Mode
Single Shot, Continuous shooting (Hi/Mid/Lo selectable), Self-timer (10/2 sec
delay selectable), Self-timer (Cont.) (with 10 sec delay 3/5 exposures selectable),
Bracket: Cont. / Single/ WB / DRO
Flash Sync Speed 1/160 sec.
Self-timer 2-sec. or 10-sec. delay
Shutter Speeds
Still images: 1/4000 to 30 sec., Bulb
Movies: 1/4000 to 1/4 (in 1/3 step), up to 1/60 in AUTO mode, up to 1/30 in Auto
Slow Shutter mode
Shutter Type Electronically-controlled, vertical-traverse, focal-plane shutter
Flash
Flash Bracketing 1/3, 1/2, 2/3, 1.0, 2.0, 3.0 EV steps, 3/5 frames (1.0/2.0/3.0 EV : only 3 frames)
selectable
Flash Compensation ±3.0 EV (switchable between 1/3 and 1/2 EV steps)
Flash Coverage 16mm (focal length printed on lens body)
Flash Metering System Pre-ash TTL
Flash Modes Flash o, Auto ash, Fill-ash, Slow Sync., Rear Sync, Wireless, Red-eye reduction
(On/O)
Flash Type Built-in, Pop-up
Guide Number 6 (in meters at ISO 100)
Interface
Remote Commander Yes, via optional RM-VPR1
Accessory Shoe MI (Multi-interface shoe), Standard ISO 518:2006 design with multi-pin conguration
for additional accessories
A/V Remote Terminal Yes, via optional RM-DSLR2 wired Multi-terminal remote
DC IN Yes via optional AC-PW20AM (sold separately)
HD Output
HDMI micro connector (Type-D)
BRAVIA Sync (link menu)
PhotoTV HD
4K Still Image playback via HDMI to compatible 4K TV
HDMI Terminal HDMI®micro connector (Type-D)
Memory Card Slot Dual compatibility slot: Memory Stick PRO Duo™/Pro-HG Duo™/PRO-HG HX Duo™
media - SD, SDHC and SDXC memory card
NFC Yes (NFC Forum Type 3 Tag compatible, One-touch remote, One-touch sharing)
Tripod Mount Yes (1/4" diameter, 20 threads per inch)
USB Port(s) USB 2.0 Hi-speed (mass-storage, MTP)
Wi-Fi Yes(Wi-Fi Compatible, IEEE 802.11b/g/n(2.4GHz band) )
Weights and Measurements
Dimensions (Approx.) Approx. 4-3/4" x 2-7/8" x 1-13/16" (120mm x 67mm x 45mm)
Weight (Approx.) Approx. 10.1 oz (285 g) (body only)
Approx. 12.1 oz (344 g) (with battery and memory stick)
Power
Battery Type InfoLITHIUM®NP-FW50 (7.2V)
Battery Capacity 1080 mAh

Number of Still Images Approx. 310 shots (Viewnder),
Approx. 360 shots (LCD monitor) (CIPA standard)
External Power AC Adaptor AC-PW20
Power Consumption (in LCD Screen
Operation) Approx. 2.4W (still images, with E PZ 16-50mm F3.5-5.6 OSS lens)
Power Consumption (in View Finder
Operation) Approx. 2.8W (still images, with E PZ 16-50mm F3.5-5.6 OSS lens)
Soware
Supplied Soware Supplied Soware: PlayMemories Home, Image Data Converter Version 4
Operating System Compatibility
supported, Windows Image Mastering API(IMAPI) Ver.2.0 or later is required to
use the function for creating discs.) Windows Vista®SP2 (Starter Edition is not
supported) Windows®7 SP1; Windows®8; Mac OS X (10.6-10.8)
Service and Warranty Information
Limited Warranty Term 1 Year Parts Labor
Accessories
Supplied Accessories
Rechargeable Battery (NP-FW50)
AC Adaptor (AC-UB10)
Shoulder strap
Body cap
Eyepiece cup
Micro USB cable
1 Among interchangeable-lens digital cameras equipped with an APS-C image sensor as of February 12, 2014. Measured using CIPA internal measurement method with E PZ 16-50mm F3.5-5.6 OSS lens mounted, Pre-AF o and viewnder in use.
2 Not supported in some regions.
3 Records in up to 29 minutes segments.4 Some functions can only be assigned to certain buttons.
4 Some functions can only be assigned to certain buttons.
5 Requires an active 802.11 Wi-Fi® network (802.11n recommended) or PlayMemories Mobile™ app installed on compatible Android™ or iOS device. PlayMemories camera apps require download with existing Sony Entertainment Network account. Download available in all
countries/areas where Sony Entertainment Network is available.
