Sony ILCE-6500 User manual

Revision History
LEVEL 3
Check the SERVICE NOTE (LEVEL 2) before the service.
989679813.pdf
2018D08-1
© 2018.04
Published by Sony Imaging Products & Solutions Inc.
INTERCHANGEABLE LENS DIGITAL CAMERA
The components identified
by mark 0or dotted line with
mark 0are critical for safety.
Replace only with part number
specified.
Les composants identifiés par
une marque 0sont critiques pour
la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
9-896-798-13
ILCE-6500/6500M_L3
SERVICE MANUAL
Ver. 1.2 2018.04
ILCE-6500/6500M
Ver. Date History Contents S.M. Rev.
issued
1.0 2016.11 Official Release — —
1.1 2017.02 Revised-1
(A1 16-090)
• Change of REPAIR PARTS LIST.
Page 2-2
Yes
1.2 2018.04Revised-2
(A2 17-082)
• Addition of ILCE-6500M. Yes*
US Model
Canadian Model
AEP Model
UK Model
Russian Model
E Model
Indian Model
Australian Model
Chinese Model
Korea Model
Japanese Model
Tourist Model
Photo: ILCE-6500 (Main body)
Revised-2
Replace the previously issued
SERVICE MANUAL 9-896-798-12
with this Manual.
[About the service of this model]
ILCE-6500M is commodity that packed the Interchangeable Lens Digital Camera and Interchangeable Lens.
Refer to each following service manual the Interchangeable Lens kit, when you repair.
Model Lens Service Manual of Lens
ILCE-6500 No supplied lens No supplied lens
ILCE-6500M SEL18135 (E 18-135mm F3.5-5.6 OSS) 9-896-833-1[]
*: S.M. revised only top cover.
SYSSET
2018/04/1801:27:27(GMT+09:00)

ILCE-6500/6500M_L3
– 2 –
SAFETY-RELATED COMPONENT WARNING!!
COMPONENTS IDENTIFIED BY MARK 0OR DOTTED LINE WITH
MARK 0ON THE SCHEMATIC DIAGRAMS AND IN THE PARTS LIST
ARE CRITICAL TO SAFE OPERATION. REPLACE THESE COMPO-
NENTS WITH SONY PARTS WHOSE PART NUMBERS APPEAR AS
SHOWN IN THIS MANUAL OR IN SUPPLEMENTS PUBLISHED BY
SONY.
ATTENTION AU COMPOSANT AYANT RAPPORT
À LA SÉCURITÉ!
LES COMPOSANTS IDENTIFIÉS PAR UNE MARQUE 0SUR LES
DIAGRAMMES SCHÉMATIQUES ET LA LISTE DES PIÈCES SONT
CRITIQUES POUR LA SÉCURITÉ DE FONCTIONNEMENT. NE REM-
PLACER CES COMPOSANTS QUE PAR DES PIÈCES SONY DONT
LES NUMÉROS SONT DONNÉS DANS CE MANUEL OU DANS LES
SUPPLÉMENTS PUBLIÉS PAR SONY.
Caution
Danger of explosion if battery is incorrectly replaced.
Replace only with the same or equivalent type.
Dispose of used batteries according to the instructions.
Caution
電池の交換は，正しく行わないと破裂する恐れがあります。
電池を交換する場合には必ず同じ型名の電池又は同等品と
交換してください。
使用済み電池は，取扱指示に従って処分してください。
SAFETY CHECK-OUT
After correcting the original service problem, perform the following
safety checks before releasing the set to the customer.
サービス，点検時には次のことにご注意ください。
1. Check the area of your repair for unsoldered or poorly-soldered
connections. Check the entire board surface for solder splashes and
bridges.
2. Check the interboard wiring to ensure that no wires are “pinched”
or contact high-wattage resistors.
3. Look for unauthorized replacement parts, particularly transistors,
that were installed during a previous repair. Point them out to the
customer and recommend their replacement.
4. Look for parts which, through functioning, show obvious signs of
deterioration. Point them out to the customer and recommend their
replacement.
5. Check the B+ voltage to see it is at the values specified.
6. Flexible Circuit Board Repairing
• Keep the temperature of the soldering iron around 350°C during
repairing.
• Do not touch the soldering iron on the same conductor of the circuit
board (within 3 times).
• Be careful not to apply force on the conductor when soldering or
unsoldering.
UNLEADED SOLDER
This unit uses unleaded solder.
Boards requiring use of unleaded solder are printed with the lead free
mark (LF) indicating the solder contains no lead.
(Caution: Some printed circuit boards may not come printed with the
lead free mark due to their particular size.)
: LEAD FREE MARK
Be careful to the following points to solder or unsolder.
• Set the soldering iron tip temperature to 350°C approximately.
If cannot control temperature, solder/unsolder at high temperature
for a short time.
Caution: The printed pattern (copper foil) may peel away if the
heated tip is applied for too long, so be careful!
Unleaded solder is more viscous (sticky, less prone to
flow) than ordinary solder so use caution not to let solder
bridges occur such as on IC pins, etc.
• Be sure to control soldering iron tips used for unleaded solder and
those for leaded solder so they are managed separately. Mixing un-
leaded solder and leaded solder will cause detachment phenomenon.
1. 注意事項をお守りください。
 サービスのとき特に注意を要する個所については，キャビ
ネット，シャーシ，部品などにラベルや捺印で注意事項を
表示しています。これらの注意書きおよび取扱説明書等の
注意事項を必ずお守りください。
2. 指定部品のご使用を
 セットの部品は難燃性や耐電圧など安全上の特性を持った
ものとなっています。従って交換部品は，使用されていた
ものと同じ特性の部品を使用してください。特に回路図，
部品表に0印で指定されている安全上重要な部品は必ず指
定のものをご使用ください。
3. 部品の取付けや配線の引きまわしはもとどおりに
 安全上，チューブやテープなどの絶縁材料を使用したり，
プリント基板から浮かして取付けた部品があります。また
内部配線は引きまわしやクランパによって発熱部品や高圧
部品に接近しないよう配慮されていますので，これらは必
ずもとどおりにしてください。
4. サービス後は安全点検を
 サービスのために取外したネジ，部品，配線がもとどおり
になっているか，またサービスした個所の周辺を劣化させ
てしまったところがないかなどを点検し，安全性が確保さ
れていることを確認してください。
5. チップ部品交換時の注意
 ・ 取外した部品は再使用しないでください。
 ・ タンタルコンデンサのマイナス側は熱に弱いため交換時
は注意してください。
6. フレキシブルプリント基板の取扱いについて
 ・ こて先温度を約350℃に設定して行ってください。
 ・ 同一パターンに何度もこて先を当てないでください。
  （3回以内）
 ・ パターンに力が加わらないよう注意してください。
無鉛半田について
本機には無鉛半田が使用されています。
無鉛半田を使用している基板には，無鉛（LeadFree）を意味する
レッドフリーマークがプリントされています。
（注意：基板サイズによっては，無鉛半田を使用していてもレッ
ドフリーマークがプリントされていないものがありま
す）
：レッドフリーマーク
無鉛半田は，下記の点に注意して使用してください。
・ 半田こてのこて先温度は約350℃に設定してください。
 温度調節が無理な場合は，高温短時間で作業を行ってくだ
さい。
 注意：半田こてを長く当てすぎると，基板のパターン（銅
箔）がはがれてしまうことがありますので，注意して
ください。また，従来の半田よりも粘性が強いため，
IC端子などが半田ブリッジしないように注意してく
ださい。
・ 半田こてのこて先は，必ず無鉛半田用と有鉛半田用に分け
て管理してください。
 無鉛半田と有鉛半田が混在すると剥離現象が発生してしま
います。
注意
如果电池更换不当会有爆炸危险。
只能用同样类型或等效类型的电池来更换。
务必按照说明处置用完的电池。
SYSSET
2018/04/1801:27:27(GMT+09:00)

ILCE-6500/6500M_L3
2-1
(ENGLISH)
NOTE:
• -XX, -X mean standardized parts, so they may have some dif-
ferences from the original one.
• Items marked “*” are not stocked since they are seldom required
for routine service. Some delay should be anticipated when
ordering these items.
• The mechanical parts with no reference number in the exploded
views are not supplied.
• Due to standardization, replacements in the parts list may be
different from the parts specified in the diagrams or the com-
ponents used on the set.
• CAPACITORS:
uF: μF
• COILS
uH: μH
• RESISTORS
All resistors are in ohms.
METAL: metal-film resistor
METAL OXIDE: Metal Oxide-film resistor
F: nonflammable
• SEMICONDUCTORS
In each case, u: μ, for example:
uA...: μA... , uPA... , μPA... ,
uPB... , μPB... , μPC... , μPC... ,
uPD..., μPD...
(JAPANESE)
【使用上の注意】
• ここに記載されている部品は,補修用部品であるため,回路図
及びセットに付いている部品と異なる場合があります。
• -XX,-Xは標準化部品のため,セットに付いている部品と異な
る場合があります。
• *印の部品は常備在庫しておりません。
• コンデンサの単位でuFはμFを示します。
• 抵抗の単位Ωは省略してあります。
 金 被：金属被膜抵抗。
 サンキン：酸化金属被膜抵抗。
• インダクタの単位でuHはμHを示します。
• 半導体の名称でuA...,uPA...,uPB...,uPC...,uPD...等はそれぞれ
μA...,μPA...,μPB...,μPC...,μPD...を示します。
2. REPAIR PARTS LIST
The components identified by mark 0or
dotted line with mark are critical for safety.
Replace only with part number specified.
Les composants identifiés par une marque
0sont critiques pour la sécurité.
Ne les remplacer que par une pièce portant
le numéro spécifié.
図面番号で部品を指定するときは基板名
又はブロックを併せて指定してください。
お願い
0印の部品，または0印付の点線で囲ま
れた部品は，安全性を維持するために，
重要な部品です。
従って交換時は，必ず指定の部品を使用
してください。
When indicating parts by reference
number,please include the board name.
Caution
Danger of explosion if battery is incorrectly replaced.
Replace only with the same or equivalent type.
Dispose of used batteries according to the instructions.
注意
電池の交換は，正しく行わないと破裂する恐れがあります。
電池を交換する場合には必ず同じ型名の電池又は同等品と
交換してください。
使用済み電池は，取扱指示に従って処分してください。
Note 1: Be sure to read “Precautions for Replacement of Imager”
on page 6-1.
Note 1: イメージャの交換時は6-1ページの“イメージャ交換時の
注意”を必ずお読みください。
1-889-592-12 AN-1006 FLEXIBLE BOARD
*********************
A-2165-963-A AN-1025 BOARD, COMPLETE
***********************
< CAPACITOR >
C7383 1-117-736-81 CERAMIC CHIP 2.2PF 0.1PF 16V
< TERMINAL >
ET7381 1-780-992-11 TERMINAL (ON BOARD CONTACT)
< JACK >
J7391 1-820-196-11 CONNECTOR, COAXIAL (SMT TYPE)
< COIL >
L7381 1-481-370-11 INDUCTOR 2nH
A-2165-968-A BDR-2000 FLEXIBLE BOARD, COMPLETE
********************************
< CAPACITOR >
C009 1-117-745-81 CERAMIC CHIP 7PF 0.1PF 16V
C010 1-116-155-11 CERAMIC CHIP 82PF 1% 50V
< CONNECTOR >
*CN001 1-820-031-71 CONNECTOR, FPC (LIF) 14P
CN002 1-816-654-61 FFC/FPC CONNECTOR (LIF) 6P
*CN003 1-843-618-11 CONNECTOR, FFC/FPC (LIF) 10P
< DIODE >
D001 (Not supplied) DIODE CSL0701DT5
< THERMISTOR >
TH001 1-804-949-11 THERMISTOR, NTC (SMD)
1-889-866-11 BT-2011 FLEXIBLE BOARD
*********************
A-2165-964-A CN-1053 BOARD, COMPLETE
***********************
< BATTERY HOLDER >
BH101 1-251-928-21 SOCKET, BATTERY
< CAPACITOR >
C202 (Not supplied) TANTAL. CHIP 22uF 20% 6.3V
*C203 1-116-720-11 CERAMIC CHIP 10uF 20% 6.3V
*C7100 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C7101 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
Ref. No. Part No. Description
< CONNECTOR >
CN101 1-843-209-11 CONNECTOR, FFC/FPC (ZIF) 39P
CN201 1-843-088-23 CARD CONNECTOR
< RESISTOR >
R203 1-240-683-91 METAL CHIP 100 5% 1/20W
R219 1-240-683-91 METAL CHIP 100 5% 1/20W
R7100 1-240-683-91 METAL CHIP 100 5% 1/20W
R7101 1-240-683-91 METAL CHIP 100 5% 1/20W
< COMPOSITION CIRCUIT BLOCK >
RB201 1-234-372-11 RES, NETWORK 100 (1005X4)
RB202 1-234-702-11 RES, NETWORK 68 (1005X4)
RB203 1-234-702-11 RES, NETWORK 68 (1005X4)
1-981-256-11 FP-2377 FLEXIBLE BOARD
*********************
A-2064-122-A GY-1008 BOARD, COMPLETE
**********************
< CAPACITOR >
C001 1-118-480-11 CERAMIC CHIP 4.7uF 10% 6.3V
C7711 (Not supplied) CERAMIC CHIP 0.33uF 10% 6.3V
C7712 1-116-713-11 CERAMIC CHIP 22uF 20% 10V
*C7713 1-118-033-11 CERAMIC CHIP 0.047uF 10% 10V
*C7714 1-118-033-11 CERAMIC CHIP 0.047uF 10% 10V
*C7715 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C7717 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
C7718 1-118-026-11 CERAMIC CHIP 470PF 10% 25V
*C7719 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
< CONNECTOR >
CN001 1-816-654-61 FFC/FPC CONNECTOR (LIF) 6P
< IC >
*IC7711 6-719-814-01 IC NJM3232MG2 (TE2)
< RESISTOR >
R001 1-216-864-91 SHORT CHIP 0
R7711 (Not supplied) METAL CHIP 15K 1% 1/20W
R7712 (Not supplied) METAL CHIP 150K 1% 1/20W
R7713 (Not supplied) METAL CHIP 10K 1% 1/20W
R7714 (Not supplied) METAL CHIP 22K 1% 1/20W
R7715 (Not supplied) METAL CHIP 22K 1% 1/20W
< SENSOR >
SE7711 (Not supplied) SENSOR, ANGULAR VELOCITY
Ref. No. Part No. Description
2-2. ELECTRICAL PARTS LIST
AN-1006 AN-1025 BDR-2000 BT-2011 CN-1053 FP-2377 GY-1008
Note 2: Replace the battery holder (BH101) together when replac-
ing the lithium secondary battery (BT101) on the CN-1053
board. (The battery holder removed once cannot be used
again.) When mounting these parts, mount new battery
holder first and attach new lithium storage battery next.
Note 2: CN-1053基板のリチウム蓄電池（BT101）を交換する場合
はバッテリホルダ（BH101）も同時に新品に交換してくださ
い。（一度使用したバッテリホルダは再使用できません。）
部品取り付けの際は、先にバッテリホルダを取り付けてか
らリチウム蓄電池を装着してください。
注意
如果电池更换不当会有爆炸危险。
只能用同样类型或等效类型的电池来更换。
务必按照说明处置用完的电池。
SYSSET
2018/04/1801:27:27(GMT+09:00)

ILCE-6500/6500M_L3
2-2
A-2186-807-A GY-1012 BOARD, COMPLETE (SERVICE)
********************************
< CAPACITOR >
C201 1-118-480-11 CERAMIC CHIP 4.7uF 10% 6.3V
*C301 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
C302 1-118-480-11 CERAMIC CHIP 4.7uF 10% 6.3V
*C7701 1-118-033-11 CERAMIC CHIP 0.047uF 10% 10V
*C7702 1-118-033-11 CERAMIC CHIP 0.047uF 10% 10V
C7703 1-118-029-11 CERAMIC CHIP 0.0022uF 10% 16V
*C7704 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
C7705 1-118-029-11 CERAMIC CHIP 0.0022uF 10% 16V
*C7706 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
< CONNECTOR >
*CN201 1-816-644-51 FFC/CONNECTOR, FPC (LIF) 12P
< SENSOR >
SE301 (Not supplied) LIS221DLHTRSENSOR, ACCELERATION
SE7701 (Not supplied) GSU-C370D/N (PITCH/YAW)
A-2092-191-A HP-1011 FLEXIBLE BOARD, COMPLETE
*******************************
< JACK >
J001 1-784-943-71 JACK (SMALL TYPE)
A-2078-515-A SERVICE, MECHA DEVICE (4000)
(Not supplied) IS-1027 BOARD, COMPLETE
*************************
1-894-656-11 ISL-2005 FLEXIBLE BOARD
*********************
1-894-655-11 ISP-2004 FLEXIBLE BOARD
*********************
A-2058-056-A LC-1022 BOARD, COMPLETE
***********************
< CAPACITOR >
C8040 1-118-040-11 CERAMIC CHIP 2.2uF 10% 16V
C8041 1-118-040-11 CERAMIC CHIP 2.2uF 10% 16V
C8042 1-118-477-11 CERAMIC CHIP 2.2uF 10% 6.3V
C8043 1-118-462-11 CERAMIC CHIP 1uF 10% 10V
C8044 1-118-045-11 CERAMIC CHIP 2.2uF 10% 25V
C8045 1-118-477-11 CERAMIC CHIP 2.2uF 10% 6.3V
C8046 1-118-462-11 CERAMIC CHIP 1uF 10% 10V
C8047 1-118-462-11 CERAMIC CHIP 1uF 10% 10V
C8048 1-118-045-11 CERAMIC CHIP 2.2uF 10% 25V
C8049 1-118-462-11 CERAMIC CHIP 1uF 10% 10V
C8050 1-118-462-11 CERAMIC CHIP 1uF 10% 10V
Ref. No. Part No. Description
C8051 1-118-462-11 CERAMIC CHIP 1uF 10% 10V
C8052 1-118-462-11 CERAMIC CHIP 1uF 10% 10V
C8053 1-118-462-11 CERAMIC CHIP 1uF 10% 10V
C8054 1-118-462-11 CERAMIC CHIP 1uF 10% 10V
C8055 1-118-462-11 CERAMIC CHIP 1uF 10% 10V
< CONNECTOR >
*CN001 1-821-501-11 CONNECTOR, FPC (ZIF) 51P
CN002 1-821-857-71 CONNECTOR, FPC (LIF (NON-ZIF))
CN003 1-821-857-71 CONNECTOR, FPC (LIF (NON-ZIF))
CN8040 1-842-604-11 CONNECTOR, FPC (ZIF) 61PIN
*CN8041 1-822-910-11 CONNECTOR, FPC (LIF (NON-ZIF))
< DIODE >
D8040 6-502-934-01 DIODE DB2S31100K8
1-894-657-11 LC-1030 FLEXIBLE BOARD
*********************
A-2165-965-A MC-2004 BOARD, COMPLETE
***********************
A-2092-366-A MIS-2003 FLEXIBLE BOARD, COMPLETE
*******************************
< CONNECTOR >
CN7551 (Not supplied) CONNECTOR (SHOE)
A-2165-969-A OD-2000 FLEXIBLE BOARD, COMPLETE
*******************************
< CONNECTOR >
CN0001 1-816-655-61 FFC/CONNECTOR, FPC (LIF (NON-ZIF)) 8P
< SWITCH >
*S0001 1-786-914-31 SWITCH, TACTILE
*S0002 1-786-914-31 SWITCH, TACTILE
S0003 (Not supplied) SWITCH, DETECTION (SMD)
*S0004 1-786-914-51 SWITCH, TACTILE
< SENSOR >
*SE0001 1-489-167-11 SENSOR MAGNETIC
A-2165-967-A RL-1050 FLEXIBLE BOARD, COMPLETE
*******************************
< CAPACITOR >
*C0001 1-116-738-11 CERAMIC CHIP 1uF 10% 6.3V
< IC >
IC0001 6-600-629-01 IC RS-470
< SWITCH >
*S0001 1-798-136-21 TACTILE SWITCH
S0002 (Not supplied) SWITCH, DETECTION (SMD)
A-2165-971-A SH-1019 FLEXIBLE BOARD, COMPLETE
*******************************
< CAPACITOR >
C2700 (Not supplied) CERAMIC CHIP 2.2uF 10% 6.3V
*C3800 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
C3801 1-118-403-11 CERAMIC CHIP 0.001uF 10% 50V
C3802 1-118-403-11 CERAMIC CHIP 0.001uF 10% 50V
C3803 1-118-403-11 CERAMIC CHIP 0.001uF 10% 50V
C3804 1-118-403-11 CERAMIC CHIP 0.001uF 10% 50V
C3805 (Not supplied) CERAMIC CHIP 22uF 20% 10V
C8800 1-118-462-11 CERAMIC CHIP 1uF 10% 10V
< CONNECTOR >
*CN3800 1-822-378-11 CONNECTOR, FPC (ZIF) 33P
< DIODE >
*D8800 6-503-573-01 DIODE 1SS400SMGJT2R
< TRANSISTOR >
Q3802 (Not supplied) TRANSISTOR PBHV8540T, 215
Q8800 6-551-631-01 TRANSISTOR RN1104MFV (TL3S
Q8801 6-552-874-01 TRANSISTOR RW1C025ZPT2CR
< RESISTOR >
R3800 1-218-965-11 METAL CHIP 10K 5% 1/16W
R3801 1-218-973-11 METAL CHIP 47K 5% 1/16W
R8800 1-218-965-11 METAL CHIP 10K 5% 1/16W
R8801 1-250-567-11 METAL CHIP 1M 1% 1/16W
< SENSOR >
SE2700 (Not supplied) INFRARED RECEIVER SENSOR
*SE3800 1-489-167-11 SENSOR MAGNETIC
A-2167-069-A SY-1077 BOARD, COMPLETE (SERVICE)
*******************************
< CAPACITOR >
C125 1-118-462-11 CERAMIC CHIP 1uF 10% 10V
C126 1-118-462-11 CERAMIC CHIP 1uF 10% 10V
C128 1-116-749-11 CERAMIC CHIP 22uF 20% 6.3V
C0200 (Not supplied) CERAMIC CHIP 0.01uF 10% 16V
C0300 1-118-040-11 CERAMIC CHIP 2.2uF 10% 16V
C0400 (Not supplied) CERAMIC CHIP 0.022uF 10% 10V
C0407 1-116-749-11 CERAMIC CHIP 22uF 20% 6.3V
C0408 1-118-168-11 CERAMIC CHIP 1uF 20% 6.3V
C412 1-116-749-11 CERAMIC CHIP 22uF 20% 6.3V
C413 1-116-749-11 CERAMIC CHIP 22uF 20% 6.3V
C600 (Not supplied) CERAMIC CHIP 0.001uF 10% 25V
*C0703 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
C0706 (Not supplied) CERAMIC CHIP 0.01uF 10% 16V
C0707 (Not supplied) CERAMIC CHIP 0.001uF 10% 25V
C0708 (Not supplied) CERAMIC CHIP 0.01uF 10% 16V
C0709 (Not supplied) CERAMIC CHIP 0.01uF 10% 16V
C0710 (Not supplied) CERAMIC CHIP 0.01uF 10% 16V
*C1106 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C1121 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C1124 1-116-720-11 CERAMIC CHIP 10uF 20% 6.3V
*C1127 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
C1128 (Not supplied) CERAMIC CHIP 0.22uF 20% 6.3V
*C1129 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C1130 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C1131 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C1132 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C1155 1-118-757-11 CERAMIC CHIP 5PF 5% 50V
C1200 1-116-749-11 CERAMIC CHIP 22uF 20% 6.3V
C1201 1-116-749-11 CERAMIC CHIP 22uF 20% 6.3V
*C1202 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C1203 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
C1204 (Not supplied) CERAMIC CHIP 10uF 20% 6.3V
C1205 (Not supplied) CERAMIC CHIP 10uF 20% 6.3V
*C1206 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C1207 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C1208 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C1210 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C1211 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
C1213 (Not supplied) CERAMIC CHIP 10uF 20% 6.3V
*C1214 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C1215 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
C1218 (Not supplied) CERAMIC CHIP 10uF 20% 6.3V
C1219 (Not supplied) CERAMIC CHIP 10uF 20% 6.3V
C1220 1-118-168-11 CERAMIC CHIP 1uF 20% 6.3V
C1221 1-118-168-11 CERAMIC CHIP 1uF 20% 6.3V
*C1222 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C1223 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C1224 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C1225 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C1226 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C1227 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C1228 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C1229 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C1230 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C1231 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C1232 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C1233 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C1234 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C1235 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C1236 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C1237 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C1238 1-118-757-11 CERAMIC CHIP 5PF 5% 50V
*C1239 1-118-757-11 CERAMIC CHIP 5PF 5% 50V
*C1240 1-118-757-11 CERAMIC CHIP 5PF 5% 50V
*C1241 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C1242 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C1243 1-118-757-11 CERAMIC CHIP 5PF 5% 50V
C1244 (Not supplied) CERAMIC CHIP 10uF 20% 6.3V
*C1501 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C1502 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C1504 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
Ref. No. Part No. Description Ref. No. Part No. Description Ref. No. Part No. Description
GY-1012 HP-1011 IS-1027 ISL-2005 ISP-2004 LC-1022 LC-1030 MC-2004 MIS-2003 OD-2000 RL-1050 SH-1019 SY-1077
The changed portions from
Ver. 1.0 are shown in blue.
Ver. 1.1 2017.02
SYSSET
2018/04/1801:27:27(GMT+09:00)

ILCE-6500/6500M_L3
2-3
C1513 1-118-168-11 CERAMIC CHIP 1uF 20% 6.3V
*C1522 1-118-033-11 CERAMIC CHIP 0.047uF 10% 10V
*C1523 1-118-033-11 CERAMIC CHIP 0.047uF 10% 10V
*C1524 1-118-033-11 CERAMIC CHIP 0.047uF 10% 10V
*C1525 1-118-033-11 CERAMIC CHIP 0.047uF 10% 10V
*C1528 1-118-033-11 CERAMIC CHIP 0.047uF 10% 10V
*C1529 1-118-033-11 CERAMIC CHIP 0.047uF 10% 10V
C1530 1-118-477-11 CERAMIC CHIP 2.2uF 10% 6.3V
C1534 (Not supplied) CERAMIC CHIP 0.47uF 10% 6.3V
C1535 (Not supplied) CERAMIC CHIP 0.47uF 10% 6.3V
C1536 1-118-168-11 CERAMIC CHIP 1uF 20% 6.3V
C1540 (Not supplied) CERAMIC CHIP 47uF 20% 10V
C1811 (Not supplied) CERAMIC CHIP 10uF 10% 10V
*C1813 1-116-738-11 CERAMIC CHIP 1uF 10% 6.3V
C2303 1-116-749-11 CERAMIC CHIP 22uF 20% 6.3V
C2304 1-118-269-11 CERAMIC CHIP 4.7uF 20% 6.3V
C2305 1-118-269-11 CERAMIC CHIP 4.7uF 20% 6.3V
C2306 1-118-477-11 CERAMIC CHIP 2.2uF 10% 6.3V
*C3005 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C3008 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C3009 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
C3013 (Not supplied) CERAMIC CHIP 0.01uF 10% 16V
C3402 1-118-168-11 CERAMIC CHIP 1uF 20% 6.3V
*C3800 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
C4002 (Not supplied) CERAMIC CHIP 0.001uF 10% 25V
C4914 (Not supplied) CERAMIC CHIP 0.01uF 10% 16V
C4915 (Not supplied) CERAMIC CHIP 0.01uF 10% 16V
C4916 (Not supplied) CERAMIC CHIP 0.01uF 10% 16V
*C4918 1-118-757-11 CERAMIC CHIP 5PF 5% 50V
*C4919 1-118-757-11 CERAMIC CHIP 5PF 5% 50V
*C4920 1-118-757-11 CERAMIC CHIP 5PF 5% 50V
C4926 (Not supplied) CERAMIC CHIP 0.01uF 10% 16V
C4927 (Not supplied) CERAMIC CHIP 0.01uF 10% 16V
C4928 (Not supplied) CERAMIC CHIP 0.01uF 10% 16V
C4929 (Not supplied) CERAMIC CHIP 0.01uF 10% 16V
C4930 (Not supplied) CERAMIC CHIP 0.01uF 10% 16V
C4931 (Not supplied) CERAMIC CHIP 0.01uF 10% 16V
C4933 (Not supplied) CERAMIC CHIP 0.01uF 10% 16V
C4934 (Not supplied) CERAMIC CHIP 0.01uF 10% 16V
C4935 (Not supplied) CERAMIC CHIP 0.01uF 10% 16V
C4936 (Not supplied) CERAMIC CHIP 0.01uF 10% 16V
*C5000 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
C5100 1-118-462-11 CERAMIC CHIP 1uF 10% 10V
C5101 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C5102 (Not supplied) CERAMIC CHIP 0.01uF 10% 16V
C5103 1-118-039-11 CERAMIC CHIP 1uF 10% 25V
C5104 1-118-462-11 CERAMIC CHIP 1uF 10% 10V
C5105 1-118-462-11 CERAMIC CHIP 1uF 10% 10V
C5106 1-118-462-11 CERAMIC CHIP 1uF 10% 10V
*C5107 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
C5108 1-118-477-11 CERAMIC CHIP 2.2uF 10% 6.3V
C5109 1-118-477-11 CERAMIC CHIP 2.2uF 10% 6.3V
C5110 1-118-040-11 CERAMIC CHIP 2.2uF 10% 16V
C5111 1-118-040-11 CERAMIC CHIP 2.2uF 10% 16V
C5112 1-118-040-11 CERAMIC CHIP 2.2uF 10% 16V
C5114 1-118-040-11 CERAMIC CHIP 2.2uF 10% 16V
C5116 1-116-749-11 CERAMIC CHIP 22uF 20% 6.3V
*C5117 1-116-720-11 CERAMIC CHIP 10uF 20% 6.3V
*C5118 1-116-720-11 CERAMIC CHIP 10uF 20% 6.3V
Ref. No. Part No. Description
*C5120 1-116-720-11 CERAMIC CHIP 10uF 20% 6.3V
C5150 1-116-713-11 CERAMIC CHIP 22uF 20% 10V
C5151 1-116-713-11 CERAMIC CHIP 22uF 20% 10V
C5152 1-116-713-11 CERAMIC CHIP 22uF 20% 10V
C5153 1-116-713-11 CERAMIC CHIP 22uF 20% 10V
C5154 (Not supplied) CERAMIC CHIP 0.1uF 10% 10V
C5155 (Not supplied) CERAMIC CHIP 0.1uF 10% 10V
C5156 (Not supplied) CERAMIC CHIP 10PF 5% 50V
C5157 (Not supplied) CERAMIC CHIP 10PF 5% 50V
C5158 1-116-713-11 CERAMIC CHIP 22uF 20% 10V
C5159 1-116-713-11 CERAMIC CHIP 22uF 20% 10V
C5160 1-118-040-11 CERAMIC CHIP 2.2uF 10% 16V
C5162 1-118-462-11 CERAMIC CHIP 1uF 10% 10V
C5163 1-118-462-11 CERAMIC CHIP 1uF 10% 10V
*C5200 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
C5201 1-118-041-11 CERAMIC CHIP 4.7uF 10% 10V
*C5202 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C5203 1-116-738-11 CERAMIC CHIP 1uF 10% 6.3V
C5204 1-118-462-11 CERAMIC CHIP 1uF 10% 10V
C5205 1-118-462-11 CERAMIC CHIP 1uF 10% 10V
*C5206 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
C5207 1-118-269-11 CERAMIC CHIP 4.7uF 20% 6.3V
C5208 1-118-462-11 CERAMIC CHIP 1uF 10% 10V
C5209 1-118-462-11 CERAMIC CHIP 1uF 10% 10V
C5250 1-116-744-11 CERAMIC CHIP 0.22uF 10% 10V
C5300 1-118-462-11 CERAMIC CHIP 1uF 10% 10V
C5301 1-118-039-11 CERAMIC CHIP 1uF 10% 25V
*C5325 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C5326 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C5327 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
C5328 1-118-041-11 CERAMIC CHIP 4.7uF 10% 10V
C5329 1-118-040-11 CERAMIC CHIP 2.2uF 10% 16V
C5330 1-118-039-11 CERAMIC CHIP 1uF 10% 25V
C5331 (Not supplied) CERAMIC CHIP 0.01uF 10% 16V
C5500 1-118-168-11 CERAMIC CHIP 1uF 20% 6.3V
C5502 1-118-168-11 CERAMIC CHIP 1uF 20% 6.3V
C5650 1-118-039-11 CERAMIC CHIP 1uF 10% 25V
C5651 (Not supplied) CERAMIC CHIP 0.22uF 10% 6.3V
C5652 (Not supplied) CERAMIC CHIP 0.1uF 10% 10V
C5653 1-118-040-11 CERAMIC CHIP 2.2uF 10% 16V
C5654 1-118-047-11 CERAMIC CHIP 10uF 10% 16V
C5655 1-118-047-11 CERAMIC CHIP 10uF 10% 16V
C5656 1-118-039-11 CERAMIC CHIP 1uF 10% 25V
C5657 1-118-039-11 CERAMIC CHIP 1uF 10% 25V
C5658 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C5700 1-116-713-11 CERAMIC CHIP 22uF 20% 10V
*C5704 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
C5705 (Not supplied) CERAMIC CHIP 4.7uF 10% 6.3V
C5707 (Not supplied) CERAMIC CHIP 15PF 5% 50V
C5708 1-118-477-11 CERAMIC CHIP 2.2uF 10% 6.3V
C5709 (Not supplied) CERAMIC CHIP 15PF 5% 50V
C5710 (Not supplied) CERAMIC CHIP 12PF 5% 50V
C5711 (Not supplied) CERAMIC CHIP 12PF 5% 50V
*C5712 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C5714 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
C5715 (Not supplied) CERAMIC CHIP 0.1uF 10% 10V
*C5800 1-116-738-11 CERAMIC CHIP 1uF 10% 6.3V
C5801 (Not supplied) CERAMIC CHIP 22uF 20% 10V
*C5803 1-116-456-11 CERAMIC CHIP 0.047uF 10% 350V
C5804 1-100-761-21 CERAMIC CHIP 0.01uF 10% 250V
C6003 1-118-477-11 CERAMIC CHIP 2.2uF 10% 6.3V
*C6004 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C6005 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C6008 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C6009 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
C6010 (Not supplied) CERAMIC CHIP 0.22uF 20% 6.3V
*C6011 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C6040 1-116-720-11 CERAMIC CHIP 10uF 20% 6.3V
C6041 1-116-749-11 CERAMIC CHIP 22uF 20% 6.3V
*C6042 1-116-720-11 CERAMIC CHIP 10uF 20% 6.3V
*C6043 1-116-720-11 CERAMIC CHIP 10uF 20% 6.3V
*C6044 1-116-720-11 CERAMIC CHIP 10uF 20% 6.3V
*C6045 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C6046 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C6048 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C6049 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C6050 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C6051 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C6052 1-118-757-11 CERAMIC CHIP 5PF 5% 50V
*C6053 1-118-757-11 CERAMIC CHIP 5PF 5% 50V
*C6054 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C6055 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C6056 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
C6057 1-118-168-11 CERAMIC CHIP 1uF 20% 6.3V
C6060 1-118-477-11 CERAMIC CHIP 2.2uF 10% 6.3V
*C6061 1-116-720-11 CERAMIC CHIP 10uF 20% 6.3V
*C6062 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C6063 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C6064 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
C6065 1-118-477-11 CERAMIC CHIP 2.2uF 10% 6.3V
*C6067 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C6080 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C6081 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C6084 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C6086 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
C6100 (Not supplied) CERAMIC CHIP 10uF 20% 6.3V
*C6103 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C6104 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C6127 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C6128 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
C6129 1-118-168-11 CERAMIC CHIP 1uF 20% 6.3V
*C6130 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C6131 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C6132 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C6133 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C6134 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
C6141 1-116-749-11 CERAMIC CHIP 22uF 20% 6.3V
*C6142 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C6143 1-118-757-11 CERAMIC CHIP 5PF 5% 50V
C6700 1-118-269-11 CERAMIC CHIP 4.7uF 20% 6.3V
*C6701 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
C6702 1-118-026-11 CERAMIC CHIP 470PF 10% 25V
C6703 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
*C6760 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
C6761 1-118-462-11 CERAMIC CHIP 1uF 10% 10V
*C7401 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
C7731 1-118-269-11 CERAMIC CHIP 4.7uF 20% 6.3V
*C7732 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C7733 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
C8060 1-118-039-11 CERAMIC CHIP 1uF 10% 25V
C8062 1-118-039-11 CERAMIC CHIP 1uF 10% 25V
C8063 1-118-039-11 CERAMIC CHIP 1uF 10% 25V
C8064 1-118-039-11 CERAMIC CHIP 1uF 10% 25V
C8065 1-118-039-11 CERAMIC CHIP 1uF 10% 25V
C8066 1-118-040-11 CERAMIC CHIP 2.2uF 10% 16V
C8067 1-118-462-11 CERAMIC CHIP 1uF 10% 10V
C8500 1-118-168-11 CERAMIC CHIP 1uF 20% 6.3V
C8501 1-118-168-11 CERAMIC CHIP 1uF 20% 6.3V
C8503 1-118-168-11 CERAMIC CHIP 1uF 20% 6.3V
C8504 1-118-168-11 CERAMIC CHIP 1uF 20% 6.3V
C8505 1-118-168-11 CERAMIC CHIP 1uF 20% 6.3V
C8506 1-118-168-11 CERAMIC CHIP 1uF 20% 6.3V
*C8507 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C8508 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
C8509 (Not supplied) CERAMIC CHIP 0.001uF 10% 25V
C8511 (Not supplied) CERAMIC CHIP 0.001uF 10% 25V
C8512 (Not supplied) CERAMIC CHIP 0.001uF 10% 25V
C8514 (Not supplied) CERAMIC CHIP 0.001uF 10% 25V
C8515 1-118-168-11 CERAMIC CHIP 1uF 20% 6.3V
C8516 1-118-168-11 CERAMIC CHIP 1uF 20% 6.3V
C8517 1-118-462-11 CERAMIC CHIP 1uF 10% 10V
C8518 1-118-462-11 CERAMIC CHIP 1uF 10% 10V
*C8519 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
C8520 1-118-462-11 CERAMIC CHIP 1uF 10% 10V
C8521 (Not supplied) CERAMIC CHIP 10uF 20% 6.3V
C8524 (Not supplied) CERAMIC CHIP 0.0047uF 10% 6.3V
C8525 1-118-026-11 CERAMIC CHIP 470PF 10% 25V
*C8526 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C8527 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C9011 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
C9012 1-118-168-11 CERAMIC CHIP 1uF 20% 6.3V
C9013 1-118-168-11 CERAMIC CHIP 1uF 20% 6.3V
*C9014 1-118-757-11 CERAMIC CHIP 5PF 5% 50V
*C9015 1-118-757-11 CERAMIC CHIP 5PF 5% 50V
C9016 (Not supplied) CERAMIC CHIP 10uF 20% 6.3V
*C9017 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
C9100 (Not supplied) CERAMIC CHIP 0.1uF 10% 10V
C9101 1-116-717-11 CERAMIC CHIP 10uF 20% 10V
C9102 1-118-168-11 CERAMIC CHIP 1uF 20% 6.3V
*C9103 1-118-341-11 CERAMIC CHIP 0.0033uF 10% 16V
C9104 1-118-168-11 CERAMIC CHIP 1uF 20% 6.3V
C9106 1-118-168-11 CERAMIC CHIP 1uF 20% 6.3V
*C9109 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C9110 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
C9113 (Not supplied) CERAMIC CHIP 0.1uF 10% 10V
C9115 1-118-168-11 CERAMIC CHIP 1uF 20% 6.3V
C9116 1-118-168-11 CERAMIC CHIP 1uF 20% 6.3V
C9117 1-118-168-11 CERAMIC CHIP 1uF 20% 6.3V
C9118 1-116-749-11 CERAMIC CHIP 22uF 20% 6.3V
*C9200 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
C9201 (Not supplied) CERAMIC CHIP 0.001uF 10% 25V
*C9202 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C9203 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C9204 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C9205 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
Ref. No. Part No. Description Ref. No. Part No. Description Ref. No. Part No. Description
SY-1077
SYSSET
2018/04/1801:27:27(GMT+09:00)

ILCE-6500/6500M_L3
2-4
*C9206 1-116-720-11 CERAMIC CHIP 10uF 20% 6.3V
*C9207 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C9208 1-118-757-11 CERAMIC CHIP 5PF 5% 50V
*C9209 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
C9210 (Not supplied) CERAMIC CHIP 0.001uF 10% 25V
C9211 (Not supplied) CERAMIC CHIP 10PF 5% 50V
*C9212 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C9213 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C9214 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C9216 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
C9217 (Not supplied) CERAMIC CHIP 22PF 5% 50V
*C9218 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
C9219 1-116-749-11 CERAMIC CHIP 22uF 20% 6.3V
*C9221 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C9223 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C9225 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C9227 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
C9229 1-116-749-11 CERAMIC CHIP 22uF 20% 6.3V
C9230 1-116-749-11 CERAMIC CHIP 22uF 20% 6.3V
*C9231 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
C9236 1-116-749-11 CERAMIC CHIP 22uF 20% 6.3V
*C9237 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C9238 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
C9240 1-118-168-11 CERAMIC CHIP 1uF 20% 6.3V
*C9241 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
C9243 1-118-168-11 CERAMIC CHIP 1uF 20% 6.3V
C9244 1-116-749-11 CERAMIC CHIP 22uF 20% 6.3V
*C9245 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C9246 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C9247 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C9249 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C9250 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C9251 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C9300 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
C9310 (Not supplied) CERAMIC CHIP 100PF 5% 50V
C9311 (Not supplied) CERAMIC CHIP 100PF 5% 50V
*C9312 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C9313 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C9401 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
< CONNECTOR >
CN0400 1-822-769-21 CONNECTOR, FPC (ZIF) 27P
CN0401 (Not supplied) CONNECTOR, FPC (ZIF) 51P
*CN802 1-821-666-21 PIN, CONNECTOR
CN803 (Not supplied) CONNECTOR, FPC (LIF (NON-ZIF))
CN1501 1-843-623-11 CONNECTOR, FFC/FPC (LIF) 20P
CN1700 (Not supplied) CONNECTOR, FPC (LIF (NON-ZIF))
CN1811 1-821-858-61 CONNECTOR, FPC (LIF (NON-ZIF)) 24P
CN3000 (Not supplied) CONNECTOR, FPC (ZIF) 51P
CN4001 (Not supplied) SOCKET, USB CONNECTOR
CN4901 (Not supplied) CONNECTOR, FPC (LIF (NON-ZIF))
CN4902 (Not supplied) CONNECTOR, FPC (LIF (NON-ZIF))
CN4903 1-822-245-61 CONNECTOR, FPC (LIF (NON-ZIF)) 20P
CN4908 1-843-209-11 CONNECTOR, FFC/FPC (ZIF) 39P
CN4910 1-816-654-61 FFC/FPC CONNECTOR (LIF) 6P
CN4911 (Not supplied) CONNECTOR, FPC (ZIF) 51P
*CN8060 1-842-176-51 CONNECTOR, FPC (ZIF) 61P
CN9000 (Not supplied) CONNECTOR, HDMI (TYPE-D)
Ref. No. Part No. Description
< COMPOSITION CIRCUIT BLOCK >
CP2300 (Not supplied) WIFI+BT COMBO MODULE
< DIODE >
D100 8-719-024-71 DIODE 1SS362-TE85L
*D0601 6-501-573-01 DIODE CL-271TLY-C-TS
*D0700 6-503-578-01 DIODE RB520SM-30T2R
*D1100 6-503-573-01 DIODE 1SS400SMGJT2R
*D1101 6-503-573-01 DIODE 1SS400SMGJT2R
D4900 6-501-216-01 DIODE CL-271HR-C-TS
D5321 6-503-737-01 DIODE CES520
*D5800 6-503-901-01 DIODE DA2JF6500L
D5801 6-501-119-01 DIODE RR264M-400
*D5802 6-503-001-01 DIODE RR255M-400FJTR
*D6081 6-503-573-01 DIODE 1SS400SMGJT2R
*D6082 6-503-573-01 DIODE 1SS400SMGJT2R
*D6700 6-503-578-01 DIODE RB520SM-30T2R
D6701 (Not supplied) DIODE EMZ6.8EFJT2R
D6702 (Not supplied) DIODE EMZ6.8EFJT2R
D6780 6-503-031-01 DIODE DZ2J18000L
D6781 6-502-975-01 DIODE DZ2J15000L
*D9000 6-502-988-01 DIODE RB480Y-40T2R
*D9101 6-503-578-01 DIODE RB520SM-30T2R
*D9102 6-503-578-01 DIODE RB520SM-30T2R
< TERMINAL >
ET4901 (Not supplied) TERMINAL, GROUND
< FUSE >
F0001 1-523-412-11 FUSE (3A/32V)
F0002 1-523-412-11 FUSE (3A/32V)
F0003 1-523-209-11 FUSE (0.25A/32V)
F0004 1-523-379-11 FUSE (2A/32V)
F0005 1-523-409-11 FUSE (1.5A/32V)
F0006 1-523-412-11 FUSE (3A/32V)
F0007 1-576-844-31 FUSE (2.5A/24V)
< FERRITE BEAD >
FB0600 (Not supplied) EMI FERRITE (SMD) (1608)
*FB1000 1-481-250-11 INDUCTOR, FERRITE BEAD (1005)
FB1100 1-400-354-11 INDUCTOR, FERRITE BEAD (1005)
FB1101 1-400-354-11 INDUCTOR, FERRITE BEAD (1005)
FB4900 1-400-198-21 INDUCTOR, FERRITE BEAD (1005)
FB4901 (Not supplied) INDUCTOR (FERRITE BEAD 0603)
FB4902 (Not supplied) INDUCTOR (FERRITE BEAD 0603)
FB6040 (Not supplied) EMI FERRITE (SMD) (1608)
FB6060 (Not supplied) INDUCTOR, FERRITE BEAD (1005)
FB9010 1-481-912-21 EMI FERRITE (SMD) (1005)
FB9200 (Not supplied) FERRITE, EMI (SMD)
FB9201 (Not supplied) FERRITE, EMI (SMD)
*FB9400 1-481-250-11 INDUCTOR, FERRITE BEAD (1005)
< IC >
IC1200 (Not supplied) IC LSZ16NN01A
IC1501 (Not supplied) IC R2J30503LG#W2
IC1503 (Not supplied) IC MM3416A28RRE
IC3001 (Not supplied) IC TC7QPB9306FTG
IC3801 (Not supplied) IC TC7WH04FK, RSNJ (CT
IC3802 (Not supplied) IC TC7WH125FK, RSNJ (CT
IC5100 (Not supplied) IC BD8336GU-E2
IC5150 (Not supplied) IC TPS63060DSCR
IC5151 (Not supplied) IC TPS63060DSCR
IC5200 6-716-945-01 IC BD8331GU-E2
IC5300 6-718-155-01 IC R1207N823B-TR-FE
*IC5321 6-720-977-01 IC TPS61093DSKR
IC5500 (Not supplied) IC NCP380HSNAJAAT1G
IC5502 (Not supplied) IC MM3411A18RRE
IC5600 6-716-783-01 IC BD11600NUX-E2
*IC5651 6-720-759-01 IC OZ8072PN-C5-0-TR
IC5700 (Not supplied) IC MB9AF004BGL-G-103-K1ERE1
IC5800 (Not supplied) IC RT9598GQW
IC6000 (Not supplied) IC MCZ4G8G21A
IC6700 (Not supplied) IC TC7WH125FK, RSNJ (CT
IC6701 (Not supplied) IC TC7WH125FK, RSNJ (CT
IC6702 6-710-786-01 IC TC7SH125FU
IC6760 6-706-491-01 IC TC7SH86FU
*IC7401 6-715-114-01 IC CXD9950AK
*IC8500 6-719-793-01 IC AK4695ECB-L
IC8501 (Not supplied) IC MM3411A28RRE
IC9010 6-720-312-01 IC R5540K002D-TR
IC9011 (Not supplied) IC SI52112-B3ZM21R
IC9012 (Not supplied) IC CXD4236-2GG
IC9100 6-716-849-01 IC TPS54326RGTR
IC9101 6-720-312-01 IC R5540K002D-TR
IC9102 (Not supplied) IC BDS2DJ22GUL-E2
IC9103 (Not supplied) IC BDS2DJ22GUL-E2
IC9104 (Not supplied) IC MM3416A25RRE
*IC9105 6-720-455-01 IC OZ8034
IC9300 (Not supplied) IC TC7SB3157CFU, RSF
*IC9401 6-722-627-01 IC TC7WZ74FK, RSNJ (CT
< JACK >
J7381 1-820-196-11 CONNECTOR, COAXIAL (SMT TYPE)
< COIL >
L0101 (Not supplied) INDUCTOR 2.2uH
L0102 (Not supplied) INDUCTOR 3.3uH
L0103 (Not supplied) INDUCTOR 10uH
L0105 (Not supplied) INDUCTOR 10uH
L0106 (Not supplied) INDUCTOR 4.7uH
L0300 1-460-369-11 INDUCTOR 33uH
*L1200 1-481-103-21 INDUCTOR 4.7uH
*L1201 1-400-136-21 INDUCTOR 4.7uH
*L1202 1-400-674-21 INDUCTOR 4.7uH
*L1203 1-400-136-21 INDUCTOR 4.7uH
*L1212 1-400-674-21 INDUCTOR 4.7uH
L2300 (Not supplied) INDUCTOR 2.2uH
L5150 (Not supplied) INDUCTOR 2.2uH
L5151 (Not supplied) INDUCTOR 1uH
L5152 1-469-845-11 INDUCTOR 4.7uH
L5320 (Not supplied) INDUCTOR 10uH
L5650 (Not supplied) INDUCTOR 2.2uH
L5800 (Not supplied) INDUCTOR 2.2uH
*L6040 1-400-136-21 INDUCTOR 4.7uH
*L6041 1-400-674-21 INDUCTOR 4.7uH
*L6042 1-400-136-21 INDUCTOR 4.7uH
Ref. No. Part No. Description Ref. No. Part No. Description
L9100 (Not supplied) INDUCTOR 2.2uH
< TRANSISTOR >
Q102 6-551-934-01 TRANSISTOR SSM3K15CT (TL3SONY)
Q103 8-729-053-52 TRANSISTOR HN1C01FE
*Q104 6-552-213-01 TRANSISTOR RW1A020ZPFU7
Q0402 6-551-631-01 TRANSISTOR RN1104MFV (TL3S
Q0405 6-552-845-01 TRANSISTOR SSM3K121TU, LSOYF
Q0406 8-729-053-58 TRANSISTOR RN1904FE
Q0600 6-552-761-01 TRANSISTOR TPCP8305, LSONYF
Q0601 6-551-630-01 TRANSISTOR RN1102MFV (TL3S
Q3800 8-729-053-57 TRANSISTOR RN1902FE
Q4905 6-551-631-01 TRANSISTOR RN1104MFV (TL3S
*Q4906 6-552-700-01 TRANSISTOR SSM3K15AMFV, L3SF
Q5250 6-551-631-01 TRANSISTOR RN1104MFV (TL3S
Q5252 (Not supplied) TRANSISTOR SSM6J412TU, RSOYF
*Q5321 6-552-213-01 TRANSISTOR RW1A020ZPFU7
Q5520 (Not supplied) TRANSISTOR SSM6J213FE, RSOYF (A
Q5521 6-551-631-01 TRANSISTOR RN1104MFV (TL3S
Q5541 6-551-631-01 TRANSISTOR RN1104MFV (TL3S
*Q5542 6-551-625-01 TRANSISTOR RN2104MFV (TL3S
Q5600 6-551-631-01 TRANSISTOR RN1104MFV (TL3S
Q5700 (Not supplied) TRANSISTOR SSM6J213FE, RSOYF (A
Q5701 6-551-630-01 TRANSISTOR RN1102MFV (TL3S
Q5702 6-552-749-01 TRANSISTOR RN2131MFV
Q5800 (Not supplied) TRANSISTOR TIG065E8-TL-HQ
Q6700 6-552-761-01 TRANSISTOR TPCP8305, LSONYF
Q6703 (Not supplied) TRANSISTOR SSM6N15AFE
Q6704 (Not supplied) TRANSISTOR SSM6N15AFE
Q6705 (Not supplied) TRANSISTOR SSM6N15AFE
Q6706 (Not supplied) TRANSISTOR SSM6J213FE, RSOYF (A
*Q6709 6-552-700-01 TRANSISTOR SSM3K15AMFV, L3SF
Q6760 6-551-630-01 TRANSISTOR RN1102MFV (TL3S
Q6761 6-552-883-01 TRANSISTOR US6M2GTR
Q6780 6-551-630-01 TRANSISTOR RN1102MFV (TL3S
Q6782 (Not supplied) TRANSISTOR MTM765200LBF
Q7890 8-729-013-22 TRANSISTOR HN1A01FU
Q7891 6-551-630-01 TRANSISTOR RN1102MFV (TL3S
Q9000 6-551-202-01 TRANSISTOR LM6K1FS8T2R
*Q9001 6-552-700-01 TRANSISTOR SSM3K15AMFV, L3SF
Q9002 8-729-055-01 TRANSISTOR RN4984FE
< RESISTOR >
R0202 1-240-695-91 METAL CHIP 1K 5% 1/20W
R0403 1-240-703-91 METAL CHIP 4.7K 5% 1/20W
R0406 1-240-718-91 METAL CHIP 100K 5% 1/20W
R0407 1-240-695-91 METAL CHIP 1K 5% 1/20W
R0414 1-240-679-91 METAL CHIP 47 5% 1/20W
R0602 1-218-957-11 METAL CHIP 2.2K 5% 1/16W
R0703 1-240-718-91 METAL CHIP 100K 5% 1/20W
*R0715 1-250-511-11 METAL CHIP 4.7K 1% 1/16W
R0717 1-240-718-91 METAL CHIP 100K 5% 1/20W
R0723 1-240-713-91 METAL CHIP 33K 5% 1/20W
R0724 1-240-711-91 METAL CHIP 22K 5% 1/20W
R0730 1-240-714-91 METAL CHIP 47K 5% 1/20W
R0731 1-240-714-91 METAL CHIP 47K 5% 1/20W
R0732 1-240-714-91 METAL CHIP 47K 5% 1/20W
R0733 1-240-729-91 METAL CHIP 1M 5% 1/20W
SY-1077
Ref. No. Part No. Description
SYSSET
2018/04/1801:27:27(GMT+09:00)

ILCE-6500/6500M_L3
2-5
R0734 1-240-729-91 METAL CHIP 1M 5% 1/20W
R0735 1-240-729-91 METAL CHIP 1M 5% 1/20W
R1016 1-240-683-91 METAL CHIP 100 5% 1/20W
R1036 (Not supplied) METAL CHIP 22 5% 1/20W
R1062 (Not supplied) METAL CHIP 2.2K 5% 1/20W
R1066 (Not supplied) METAL CHIP 2.2K 5% 1/20W
R1067 1-240-703-91 METAL CHIP 4.7K 5% 1/20W
R1068 1-240-703-91 METAL CHIP 4.7K 5% 1/20W
R1101 1-240-678-91 METAL CHIP 33 5% 1/20W
R1126 1-218-945-11 METAL CHIP 220 5% 1/16W
R1127 1-240-683-91 METAL CHIP 100 5% 1/20W
R1129 (Not supplied) METAL CHIP 100K 1% 1/20W
R1130 (Not supplied) METAL CHIP 4.7K 1% 1/20W
R1131 (Not supplied) METAL CHIP 4.7K 1% 1/20W
R1140 (Not supplied) METAL CHIP 47K 1% 1/20W
R1145 (Not supplied) METAL CHIP 4.7K 1% 1/20W
R1146 1-240-678-91 METAL CHIP 33 5% 1/20W
R1147 1-240-678-91 METAL CHIP 33 5% 1/20W
R1148 1-240-678-91 METAL CHIP 33 5% 1/20W
R1158 1-240-718-91 METAL CHIP 100K 5% 1/20W
R1159 1-240-718-91 METAL CHIP 100K 5% 1/20W
R1160 1-240-718-91 METAL CHIP 100K 5% 1/20W
R1201 1-240-802-91 METAL CHIP 5.6K 0.5% 1/20W
R1202 1-240-802-91 METAL CHIP 5.6K 0.5% 1/20W
R1204 (Not supplied) METAL CHIP 22K 1% 1/20W
R1205 (Not supplied) METAL CHIP 10K 1% 1/20W
R1206 (Not supplied) METAL CHIP 12K 1% 1/20W
R1207 (Not supplied) METAL CHIP 240 1% 1/20W
R1209 (Not supplied) METAL CHIP 240 1% 1/20W
R1210 (Not supplied) METAL CHIP 10K 1% 1/20W
R1211 (Not supplied) METAL CHIP 10K 1% 1/20W
R1510 1-208-711-11 METAL CHIP 15K 0.5% 1/16W
R1537 1-240-695-91 METAL CHIP 1K 5% 1/20W
R1538 1-240-695-91 METAL CHIP 1K 5% 1/20W
R2308 1-240-683-91 METAL CHIP 100 5% 1/20W
R2310 1-240-683-91 METAL CHIP 100 5% 1/20W
R2311 1-240-683-91 METAL CHIP 100 5% 1/20W
R2312 1-240-683-91 METAL CHIP 100 5% 1/20W
R2313 1-240-683-91 METAL CHIP 100 5% 1/20W
R3010 (Not supplied) METAL CHIP 10K 5% 1/20W
R3012 (Not supplied) METAL CHIP 10K 5% 1/20W
R3015 1-240-687-91 METAL CHIP 220 5% 1/20W
R3016 1-240-687-91 METAL CHIP 220 5% 1/20W
R3017 1-240-687-91 METAL CHIP 220 5% 1/20W
R3018 1-240-687-91 METAL CHIP 220 5% 1/20W
R3019 1-240-687-91 METAL CHIP 220 5% 1/20W
R3020 1-240-687-91 METAL CHIP 220 5% 1/20W
R3021 1-240-687-91 METAL CHIP 220 5% 1/20W
R3022 1-240-687-91 METAL CHIP 220 5% 1/20W
R3023 1-240-687-91 METAL CHIP 220 5% 1/20W
R3024 1-240-687-91 METAL CHIP 220 5% 1/20W
R3025 1-240-687-91 METAL CHIP 220 5% 1/20W
R3026 1-240-687-91 METAL CHIP 220 5% 1/20W
R3027 1-240-687-91 METAL CHIP 220 5% 1/20W
R3028 1-240-687-91 METAL CHIP 220 5% 1/20W
R3029 1-240-687-91 METAL CHIP 220 5% 1/20W
R3030 1-240-687-91 METAL CHIP 220 5% 1/20W
R3031 1-240-687-91 METAL CHIP 220 5% 1/20W
R3032 1-240-687-91 METAL CHIP 220 5% 1/20W
R3033 1-240-687-91 METAL CHIP 220 5% 1/20W
R3034 1-240-687-91 METAL CHIP 220 5% 1/20W
R3035 1-240-687-91 METAL CHIP 220 5% 1/20W
R3036 1-240-687-91 METAL CHIP 220 5% 1/20W
R3037 1-240-687-91 METAL CHIP 220 5% 1/20W
R3038 1-240-687-91 METAL CHIP 220 5% 1/20W
R3039 1-240-687-91 METAL CHIP 220 5% 1/20W
R3040 1-240-687-91 METAL CHIP 220 5% 1/20W
R3041 1-240-687-91 METAL CHIP 220 5% 1/20W
R3042 1-240-687-91 METAL CHIP 220 5% 1/20W
R3043 1-240-687-91 METAL CHIP 220 5% 1/20W
R3044 1-240-687-91 METAL CHIP 220 5% 1/20W
R3045 1-240-687-91 METAL CHIP 220 5% 1/20W
R3046 1-240-687-91 METAL CHIP 220 5% 1/20W
R3047 1-240-687-91 METAL CHIP 220 5% 1/20W
R3048 1-240-687-91 METAL CHIP 220 5% 1/20W
R3049 1-240-687-91 METAL CHIP 220 5% 1/20W
R3050 1-240-687-91 METAL CHIP 220 5% 1/20W
R3051 1-240-687-91 METAL CHIP 220 5% 1/20W
R3052 1-240-687-91 METAL CHIP 220 5% 1/20W
R3053 1-240-687-91 METAL CHIP 220 5% 1/20W
R3054 1-240-687-91 METAL CHIP 220 5% 1/20W
R3055 1-240-687-91 METAL CHIP 220 5% 1/20W
R3056 1-240-687-91 METAL CHIP 220 5% 1/20W
R3057 1-240-687-91 METAL CHIP 220 5% 1/20W
R3058 1-240-687-91 METAL CHIP 220 5% 1/20W
R3059 1-240-687-91 METAL CHIP 220 5% 1/20W
R3060 1-240-687-91 METAL CHIP 220 5% 1/20W
R3061 1-240-687-91 METAL CHIP 220 5% 1/20W
R3062 1-240-687-91 METAL CHIP 220 5% 1/20W
R3063 1-240-687-91 METAL CHIP 220 5% 1/20W
R3064 1-240-687-91 METAL CHIP 220 5% 1/20W
R3065 1-240-687-91 METAL CHIP 220 5% 1/20W
R3066 1-240-687-91 METAL CHIP 220 5% 1/20W
R3067 1-240-687-91 METAL CHIP 220 5% 1/20W
R3068 1-240-687-91 METAL CHIP 220 5% 1/20W
R3800 1-240-701-91 METAL CHIP 3.3K 5% 1/20W
R3801 1-240-718-91 METAL CHIP 100K 5% 1/20W
R3802 1-240-718-91 METAL CHIP 100K 5% 1/20W
R4928 (Not supplied) METAL CHIP 2.2K 5% 1/20W
R4929 1-240-701-91 METAL CHIP 3.3K 5% 1/20W
R4930 1-240-703-91 METAL CHIP 4.7K 5% 1/20W
R4944 1-218-943-11 METAL CHIP 150 5% 1/16W
R4956 1-240-695-91 METAL CHIP 1K 5% 1/20W
R4957 1-240-718-91 METAL CHIP 100K 5% 1/20W
R4961 (Not supplied) METAL CHIP 10K 5% 1/20W
R4962 1-240-716-91 METAL CHIP 68K 5% 1/20W
R4963 (Not supplied) METAL CHIP 10K 5% 1/20W
R5100 (Not supplied) METAL CHIP 47K 1% 1/20W
R5151 (Not supplied) METAL CHIP 47K 1% 1/20W
R5152 (Not supplied) METAL CHIP 4.7K 1% 1/20W
R5153 1-257-229-11 METAL CHIP 470 1% 1/20W
R5154 (Not supplied) METAL CHIP 120K 1% 1/20W
R5155 (Not supplied) METAL CHIP 12K 1% 1/20W
R5156 (Not supplied) METAL CHIP 15K 1% 1/20W
R5164 (Not supplied) METAL CHIP 10K 5% 1/20W
R5165 1-250-521-11 METAL CHIP 12K 1% 1/16W
*R5166 1-250-526-11 METAL CHIP 20K 1% 1/16W
R5167 (Not supplied) METAL CHIP 10K 5% 1/20W
R5169 1-240-695-91 METAL CHIP 1K 5% 1/20W
R5200 1-218-941-81 METAL CHIP 100 5% 1/16W
*R5201 1-257-273-11 METAL CHIP 33K 1% 1/20W
R5202 (Not supplied) METAL CHIP 10K 1% 1/20W
R5203 (Not supplied) METAL CHIP 10K 5% 1/20W
R5250 1-240-724-91 METAL CHIP 330K 5% 1/20W
R5251 1-240-718-91 METAL CHIP 100K 5% 1/20W
R5300 (Not supplied) METAL CHIP 15 1% 1/20W
R5301 (Not supplied) METAL CHIP 15 1% 1/20W
R5331 (Not supplied) METAL CHIP 10K 5% 1/20W
R5334 1-240-722-91 METAL CHIP 220K 5% 1/20W
R5335 (Not supplied) METAL CHIP 10K 1% 1/20W
R5336 (Not supplied) METAL CHIP 180K 1% 1/20W
R5337 (Not supplied) METAL CHIP 10K 1% 1/20W
R5338 (Not supplied) METAL CHIP 10K 5% 1/20W
R5500 1-240-711-91 METAL CHIP 22K 5% 1/20W
R5501 1-240-695-91 METAL CHIP 1K 5% 1/20W
R5520 1-240-722-91 METAL CHIP 220K 5% 1/20W
R5543 (Not supplied) METAL CHIP 100K 1% 1/20W
R5544 (Not supplied) METAL CHIP 47K 1% 1/20W
R5600 (Not supplied) METAL CHIP 10K 5% 1/20W
R5650 1-240-679-91 METAL CHIP 47 5% 1/20W
*R5654 1-250-503-11 METAL CHIP 2.2K 1% 1/16W
R5655 (Not supplied) METAL CHIP 2.2K 5% 1/20W
R5656 (Not supplied) METAL CHIP 2.2K 5% 1/20W
R5701 1-240-701-91 METAL CHIP 3.3K 5% 1/20W
R5702 1-240-697-91 METAL CHIP 1.5K 5% 1/20W
R5711 1-240-711-91 METAL CHIP 22K 5% 1/20W
R5712 (Not supplied) METAL CHIP 22 5% 1/20W
R5713 (Not supplied) METAL CHIP 22 5% 1/20W
R5716 (Not supplied) METAL CHIP 10K 5% 1/20W
R5717 (Not supplied) METAL CHIP 10K 5% 1/20W
R5718 (Not supplied) METAL CHIP 10K 5% 1/20W
R5802 1-250-531-11 METAL CHIP 33K 1% 1/16W
R5803 1-208-923-11 METAL CHIP 33K 0.5% 1/16W
R5804 1-208-683-11 METAL CHIP 1K 0.5% 1/16W
*R5806 1-246-338-21 METAL CHIP 3M 1% 1/8W
R5807 1-218-970-11 METAL CHIP 27K 5% 1/16W
R5808 (Not supplied) METAL CHIP 130 5% 1/16W
R5809 1-216-857-11 METAL CHIP 1M 5% 1/10W
R5810 1-216-845-11 METAL CHIP 100K 5% 1/10W
R5811 1-218-977-11 METAL CHIP 100K 5% 1/16W
R5812 1-218-977-11 METAL CHIP 100K 5% 1/16W
R6000 1-240-695-91 METAL CHIP 1K 5% 1/20W
R6001 1-218-953-11 METAL CHIP 1K 5% 1/16W
R6040 1-240-695-91 METAL CHIP 1K 5% 1/20W
R6041 (Not supplied) METAL CHIP 12K 1% 1/20W
*R6060 1-250-507-11 METAL CHIP 3.3K 1% 1/16W
R6061 (Not supplied) METAL CHIP 12K 1% 1/20W
*R6062 1-250-507-11 METAL CHIP 3.3K 1% 1/16W
R6083 1-240-683-91 METAL CHIP 100 5% 1/20W
R6084 1-240-681-91 METAL CHIP 68 5% 1/20W
R6085 1-240-678-91 METAL CHIP 33 5% 1/20W
R6086 1-240-678-91 METAL CHIP 33 5% 1/20W
R6125 (Not supplied) METAL CHIP 220 1% 1/20W
R6126 (Not supplied) METAL CHIP 220 1% 1/20W
R6128 (Not supplied) METAL CHIP 240 1% 1/20W
SY-1077
Ref. No. Part No. Description Ref. No. Part No. Description Ref. No. Part No. Description
R6129 (Not supplied) METAL CHIP 10K 1% 1/20W
R6130 (Not supplied) METAL CHIP 10K 1% 1/20W
R6700 1-240-683-91 METAL CHIP 100 5% 1/20W
R6702 1-240-718-91 METAL CHIP 100K 5% 1/20W
R6703 1-240-711-91 METAL CHIP 22K 5% 1/20W
R6704 1-240-729-91 METAL CHIP 1M 5% 1/20W
R6706 (Not supplied) METAL CHIP 10K 5% 1/20W
R6707 (Not supplied) METAL CHIP 10K 5% 1/20W
R6708 1-218-941-81 METAL CHIP 100 5% 1/16W
R6709 1-240-689-91 METAL CHIP 330 5% 1/20W
R6710 1-240-726-91 METAL CHIP 470K 5% 1/20W
R6711 1-240-711-91 METAL CHIP 22K 5% 1/20W
R6712 (Not supplied) METAL CHIP 10K 5% 1/20W
R6714 1-240-703-91 METAL CHIP 4.7K 5% 1/20W
R6715 1-240-718-91 METAL CHIP 100K 5% 1/20W
R6716 1-240-718-91 METAL CHIP 100K 5% 1/20W
R6760 1-240-695-91 METAL CHIP 1K 5% 1/20W
R6780 1-240-718-91 METAL CHIP 100K 5% 1/20W
R6781 1-240-718-91 METAL CHIP 100K 5% 1/20W
R6782 1-240-703-91 METAL CHIP 4.7K 5% 1/20W
R6783 1-240-683-91 METAL CHIP 100 5% 1/20W
R6852 1-240-718-91 METAL CHIP 100K 5% 1/20W
R6853 1-240-718-91 METAL CHIP 100K 5% 1/20W
R7890 1-240-695-91 METAL CHIP 1K 5% 1/20W
R7891 1-216-796-11 METAL CHIP 8.2 5% 1/10W
R7892 1-216-799-11 METAL CHIP 15 5% 1/10W
R8500 1-240-705-91 METAL CHIP 6.8K 5% 1/20W
R8501 1-240-705-91 METAL CHIP 6.8K 5% 1/20W
R8502 (Not supplied) METAL CHIP 2.2K 5% 1/20W
R8503 1-240-687-91 METAL CHIP 220 5% 1/20W
R8504 1-240-687-91 METAL CHIP 220 5% 1/20W
R8505 (Not supplied) METAL CHIP 2.2K 5% 1/20W
R8506 (Not supplied) METAL CHIP 2.2K 5% 1/20W
R8507 (Not supplied) METAL CHIP 2.2K 5% 1/20W
R8508 1-240-722-91 METAL CHIP 220K 5% 1/20W
R9000 1-240-712-91 METAL CHIP 27K 5% 1/20W
R9011 1-240-709-91 METAL CHIP 15K 5% 1/20W
R9012 1-240-713-91 METAL CHIP 33K 5% 1/20W
R9101 (Not supplied) METAL CHIP 10K 1% 1/20W
*R9102 1-250-527-11 METAL CHIP 22K 1% 1/16W
R9109 1-250-495-11 METAL CHIP 1K 1% 1/16W
R9310 (Not supplied) METAL CHIP 510 1% 1/20W
R9311 (Not supplied) METAL CHIP 510 1% 1/20W
R9316 (Not supplied) METAL CHIP 180 1% 1/20W
R9334 1-240-718-91 METAL CHIP 100K 5% 1/20W
R9335 1-240-718-91 METAL CHIP 100K 5% 1/20W
R9336 1-240-718-91 METAL CHIP 100K 5% 1/20W
R9337 1-240-718-91 METAL CHIP 100K 5% 1/20W
R9338 1-240-718-91 METAL CHIP 100K 5% 1/20W
R9339 1-240-718-91 METAL CHIP 100K 5% 1/20W
R9340 1-240-718-91 METAL CHIP 100K 5% 1/20W
R9341 1-240-718-91 METAL CHIP 100K 5% 1/20W
R9401 1-240-683-91 METAL CHIP 100 5% 1/20W
< COMPOSITION CIRCUIT BLOCK >
RB1102 1-234-378-21 RES, NETWORK 10K (1005X4)
RB3016 1-234-378-21 RES, NETWORK 10K (1005X4)
RB6700 1-234-378-21 RES, NETWORK 10K (1005X4)
RB6702 1-234-374-21 RES, NETWORK 470 (1005X4)
Ref. No. Part No. Description
SYSSET
2018/04/1801:27:27(GMT+09:00)

ILCE-6500/6500M_L3
2-6E
RB6703 1-234-374-21 RES, NETWORK 470 (1005X4)
RB9000 1-234-375-21 RES, NETWORK 1K (1005X4)
< SENSOR >
*SE7731 1-490-064-31 SENSOR 3 AXIAL ACCELERATION
< TRANSFORMER >
*T801 1-445-774-11 D.C.-D.C.CONVERTER TRANSFORMER
< THERMISTOR >
TH1100 1-804-949-11 THERMISTOR, NTC (SMD)
< VARIABLE RESISTOR >
VR670 1-802-090-21 VARISTOR, CHIP
VR4901 (Not supplied) VARISTOR, CHIP
VR4902 (Not supplied) VARISTOR, CHIP
*VR4903 1-802-251-21 CHIP VARISTOR
< VIBRATOR >
X1200 (Not supplied) QUARTZ CRYSTAL OSCILLATOR (72MHz)
*X5000 1-813-403-81 QUARTZ CRYSTAL OSCILLATOR (12MHz)
X5700 1-781-525-11 VIBRATOR, CRYSTAL (32.768kHz)
X5701 1-814-304-11 VIBRATOR, CRYSTAL (12MHz)
X6000 (Not supplied) SILICON OSCILLATOR (2520/12MHZ) (12MHz)
X9010 (Not supplied) SILICON OSCILLATOR (2520) (74.25MHz)
X9011 (Not supplied) QUARTZ CRYSTAL UNIT 25MHZ (25MHz)
A-2165-970-A TF-2000 FLEXIBLE BOARD, COMPLETE
*******************************
< CAPACITOR >
*C001 1-116-738-11 CERAMIC CHIP 1uF 10% 6.3V
< PHOTO INTERRUPTER >
PH001 (Not supplied) PHOTO REFLECTOR PR-40-T
PH002 (Not supplied) PHOTO REFLECTOR PR-40-T
< TRANSISTOR >
Q001 6-551-631-01 TRANSISTOR RN1104MFV (TL3S
Q002 6-551-631-01 TRANSISTOR RN1104MFV (TL3S
< RESISTOR >
R001 1-218-957-11 METAL CHIP 2.2K 5% 1/16W
R002 1-218-959-11 METAL CHIP 3.3K 5% 1/16W
R003 1-218-961-11 METAL CHIP 4.7K 5% 1/16W
R004 1-218-965-11 METAL CHIP 10K 5% 1/16W
R005 1-218-965-11 METAL CHIP 10K 5% 1/16W
R006 1-218-961-11 METAL CHIP 4.7K 5% 1/16W
R007 1-218-959-11 METAL CHIP 3.3K 5% 1/16W
R008 1-218-957-11 METAL CHIP 2.2K 5% 1/16W
R009 1-216-819-11 METAL CHIP 680 5% 1/10W
R010 1-216-819-11 METAL CHIP 680 5% 1/10W
R011 1-218-973-11 METAL CHIP 47K 5% 1/16W
R012 1-218-973-11 METAL CHIP 47K 5% 1/16W
SY-1077 TF-2000
< SWITCH >
S001 1-798-035-61 ROTARY SWITCH
*S002 1-786-914-31 SWITCH, TACTILE
*S003 1-786-914-31 SWITCH, TACTILE
Ref. No. Part No. Description Ref. No. Part No. Description
SYSSET
2018/04/1801:27:27(GMT+09:00)

ILCE-6500/6500M_L3
4-1
4. BLOCK DIAGRAMS
4-1. OVERALL BLOCK DIAGRAM (1/3) ( ) : Number in parenthesis ( ) indicates the division number of schematic diagram where the component is located.
TOUCH
PANEL
CPU, CAMERA DSP,
AV SIGNAL PROCESS,
LENS CONTROL,
MODE CONTROL,
HDMI PROCESS
(9/34 - 12/34)
SHUTTER
DRIVE
Q6782
LED DRIVE
Q6780
IC6001
CMOS
IMAGER
(SHUTTER)
SHUTTER
UNIT
XHS
XVS
XCLR
CIS0_HD
FSP_XCS_2, FSP_XOE,
FSP_XWE, FSP_XADV
CIS0_VD
CIS0_IMG_RST
IMAGER_TEMP1 IMAGER_TEMP1
IMG_TEMP
1ST_CURTAIN_MG
TH1100
SHUTTER_PI_ON
SHUTTER_PI_ON,
SHUTTER_PI, SHUTTER_ID,
1ST_CURTAIN_MG,
2ND_CURTAIN_MG
2ND_CURTAIN_MG
SC_M_1
SC_M_2
XSC_CAM_1 - 3
SHUTTER_PI, SHUTTER_ID
DOP00 - DOP07,
DOM00 - DOM07
IMG_GCS2_D0P - D7P,
IMG_GCS2_D0N - D7N
SLTX_D0P - SLTX_D11P,
SLTX_D0N - SLTX_D11N,
SLTX_CKP/CKN
FSP_AD_0 - 15,
FSP_ADDR_16 - 19
SDI, SDO,
SCK, XCE CIS0_SO/SI/SCK/XCS
X6001
72MHz
TH6001
U7
AB4
AC4
D10
D8
E8
L6
28,29,31,32,34,35,37,38,
40,41,43,44,46,47,49,50
27
27
CN0400
CN0401
CN6002
CN6001
CN1811
CN1501
1C_CURRENT
PI_K
2C_CURRENT
ISL-2005
FLEXIBLE
BOARD
ISP-2004
FLEXIBLE
BOARD
IS-1027 BOARD SY-1077 BOARD (1/3)
28,29,31,32,34,35,37,38,
40,41,43,44,46,47,49,50
XPI CIS0_SHT_RST
AE3 E6
IC_1200_INT0/INT1
CLK_SYS_IN
XMSS_RESET
SENS_VD P6
G13
AD13
G4
IC6000
(1/3)
CAMERA SIGNAL
PROCESS
(13/34)
IC1200
X6000
12MHz
X1200
72MHz
A22
CA_1ST_CURTAIN_START
CA_1ST_CURTAIN_START
POWER CONTROL,
MECHANISM CONTROL
(8/34)
IC5700
(1/3)
CHARGE MOTOR
DRIVE
Q6760, Q6761 (1/2)
Q6761 (2/2)
DISCHARGE
CM+
IC6760
CHARGE MOTOR
CONTROL
(16/34)
SC_M_1, SC_M_2
CHARGE_MOTOR_TEMP CHARGE_MOTOR_TEMP
IC3001
LEVEL SHIFT
(22/34)
XSC_CAM_1 - 3
XSC_CAM_1 - 3
F7
K6
H26
D1101
MB N
CONTACT
UNIT
IC6702
IC6701
IC6700
LEVEL SHIFT
(15/34)
LENS_CS_MSS
VD_CA
MSS_CS_LENS
GP_UART1_RXD
GP_UART1_TXD
VD_CA
BODY_VD_LENS
LENS_CS_BODY
LENS_DATA_BODY
BODY_DATA_LENS
BODY_CS_LENS
CN1700
LENS_XDETECT_BODYLENS_XDETECT
V8
310
LENS_XDETECT
LENS_CS_CA
EVF_D_XHD
CN3000 CN001
CN8040
CN8041
CN8060
LCD_D_XHD
LCD_D_XVD
LCD_D_CLK
LCD_XHD
LCD_XVD
LCD_CLK
LCD_R_0 - 7,
LCD_G_0 - 7,
LCD_B_0 - 7
LCD_DR_0 - 7,
LCD_DG_0 - 7,
LCD_DB_0 - 7
LCD_DR0 - DR7,
LCD_DG0 - DG7,
LCD_DB0 - DB7
EVF_DR_0 - 7,
EVF_DG_0 - 7,
EVF_DB_0 - 7
EVF_D_CLK
EVF_D_XVD
EVF UNIT
LCD902
35
32
33
AV_SO
AV_SO, AV_SCK,
XCS_LCD
AV_SCK
XCS_LCD
LCD_HD
LCD_VD
LCD_CK
AV_SO
AV_SCK
XCS_LCD
BL_H
BL_L
AV_SO, AV_SCK
I2C_SDA/SCK
42
41
40
BL_L 44
BL_H 45
5-12, 14-21, 23-30
EVF_SI_1.8V
MSS_SI/SO_EVF_VG,
MSS_SCK_EVF_VG
EVF_SO_1.8V
XCS_EVF_1.8V 20
18
17
EVF_SCK_1.8V 19
52
51
53
XMSS_RESET_1.8V 50
24-31, 34-49
LC-1022 BOARD
3.0 INCH
COLOR
LCD
LCD901
(LCD MODULE)
BACKLIGHT
32
30
31
36
35
34
6 - 29
4 - 6
1 - 3
LC-1030
FLEXIBLE
BOARD
XMSS_RESET
XMSS_RESET
XMSS_RESET
: VIDEO SIGNAL
CA_XRESET_OUT_MSS
H11
XCS_EVF
17
20
19
10
11
12
8
7
22-29, 31-38, 40-47
W31
W30
3
2
11
6
7 - 10
3
2
11
6
7 - 10
11, 23
9
8
5
19 - 221 - 3
14
7
3
2
4
5
1
IC_1501_P_LIMIT
GY-1012 BOARD
U10
D1
F5
IC_1501_IC_6000_CLK
IC_1501_EXPOSE2
IC_1501_EXPOSE2
MSS_XCS_IC_1501
XIC_1501_RST
IC_1501_IMG_READ,
IC_1501_INT_REQ,
IC_1501_EXPOSE
MSS_SI/SO/SCK_IC_1501
PITCH_AD PITCH_AD
YAW_AD
XCS_ACCEL
SCK_ACCEL
SI_ACCEL
SO_ACCEL
ROLL_AD
ROLL_RST
YAW_AD 11
9
XCS_ACCEL 2
SCK_ACCEL 3
SI_ACCEL 4
SO_ACCEL 5
CN201
SE301
3 AXIAL
ACCELERATION
SENSOR
(2/2)
SE7701
PITCH/YAW
SENSOR
(1/2)
GY-1008 BOARD
ROLL_ADOUT
VREF ROLL_RST
5
3
CN001
SE7711
ROLL
SENSOR
IC7711
ROLL
SENSOR
AMP
4
BDR-2000
FLEXIBLE
BOARD (1/2)
41
43
50
49
48
47
7
5
CN4911 (1/2)
IC1501
STEADYSHOT
PROCESSOR
(14/34)
C1
1, 2
10 - 12
3, 4
14 - 16
5, 6
18 - 20
8
TEBURE
UNIT
VCM_W(+/-)
VCM_U(+/-)
PITCH_2_HALL(+/-), PITCH_2_BIAS(-)
TEMPERATURE_OUT AS_TEMPERATURE
PITCH_1_HALL(+/-), PITCH_1_BIAS(-)
YAW_HALL(+/-), YAW_BIAS(-)
VCM_V(+/-)
IC_1501_IC_6000_CLK
OVERALL (2/3)
(PAGE 4-2)
2
OVERALL (2/3)
(PAGE 4-2)
1
OVERALL (2/3)
(PAGE 4-2)
3
08
X5701
12MHz L9
L8
X5700
32.768kHz L6
L5
I2C_SDA/SCK
XRES
nINT 6
2
CN003
3, 5
5
2
3, 4
47
50
48, 49
I2C_SDA/SCK
CAP_TP_XRES
CAP_TP_INT
I2C_SDA/SCK,
CAP_TP_XRES,
CAP_TP_INT
F4
SYSSET
2018/04/1801:27:27(GMT+09:00)

ILCE-6500/6500M_L3
4-2
4-2. OVERALL BLOCK DIAGRAM (2/3) ( ) : Number in parenthesis ( ) indicates the division number of schematic diagram where the component is located.
Q9000
Q9001
Q9002
CEC
HotPlugDetect
HDMI_TX0SOP - TX2SOP,
HDMI_TX0SON - TX2SON
HDMI_TXCP/TXCN
CN9000
LEVEL SHIFT
LEVEL SHIFT
LEVEL SHIFT
HDMI_SDA
HDMI_CEC
HDMI_JACK_IN
HDMI_SCL
SDA
SCL 18
12, 14
17
1
15
3, 5, 6, 8, 9, 11
D6081
D6082
MSX_CLK
CN4903
CN4902
29, 30, 32, 33, 35, 36, 38, 39
MSX_D0 - D7
27
MSX_BS
17 XMS_IN_DWN
XSD_IN_DWN
14
SD_CLK
19
XMS_ACC_LED
SD_CMD
16
XSD_IN_DWN
XMS_IN_DWN
MSX_INS_HIZ
SD_XSDCD
4
MSX_CLK
CN201
MSX_D[0-7]
SD_D[0-3]
MSX_BS
XMS_INS_HIZ
SD_CLK
D4900
(ACCESS)
SD_CMD
SD_XSDCD
CN-1053 BOARD
CN101
SD_SDWP
15
SD_SDWP
FP-2377
FLEXIBLE
BOARD
15
6
24
17
7
26
14
2, 4, 8, 10, 11, 13, 16, 20
1, 3, 21, 23
MEMORY
STICK
PRO DUO
SD
10, 11, 13, 14, 16, 17, 19, 20
8
14
11
16
13
4
12
SD_DAT_0 - 3
21, 22,
24, 25
2, 3,
5, 6
B3
XCS_AVIO
SHOE_ID1 - ID3
MSS_SO/SI/SCK_DWN,
DWN_CSDIR_MSS,
CA_RELEASE_LOCK_MSS,
DWN_IN_RELEASE,
MSS_IMG_READ_CA,
PRE_INT, MSS_S2_REQ_CA,
MSS_CAM_NOTIFY,
CAP_CTRL_IN,
DWN_CSREQ_MSS
EXT_MIC_L
1
5
6
SH-1019 FLEXIBLE BOARD
MIS-2003 FLEXIBLE BOARD
MC-2004 BOARD
HP-1011 FLEXIBLE BOARD
IC8500
AUDIO
PROCESSOR
(23/34)
BEEP_PWM_P
XMSS_RESET
SP±
SHOE_MIC_L
SHOE_MIC_R
XEYE_SENS_OUT_MSS
SP901
(SPEAKER)
J001
MIC902
(MICROPHONE) (R)
CN4908
CN4910
CN3800 CN7551
LINE_OUT_L
LINE_OUT_R
LINE_OUT_L
LINE_OUT_R
18
20
25
26 SHOE_MIC_R
SHOE_MIC_L 16
14
6
5MIC_L/GVIF_SDATA_N
MIC_R/GVIF_SDATA_P
MIC_C/WLAN_SD_CMD/SP_OUT/AUDIO_L
XGPS_RST/XWLAN_RST/AUDIO_R
16
14
6
5
INT_MIC_L
INT_MIC_R
MIC_L+
MIC_R+
23
28 MIC901
(MICROPHONE) (L)
BCK_OUT, LRCK_OUT,
MCK_INOUT
SDO
SDI0_SPDIF_IN, SDI1
SHOE_ID1 - ID3 ID1 - ID3
16
15
34
1
3
14
EXTERNAL
FLASH I/F
(24/34)
IC3801 IC3802
Q3800
CAM_SI/SO_2
CAM_SI/SO_2, CAM_SCK_2,
XCS_EXT_FL,
EXT_FLASH_TRIG
CAM_SCK_2
XCS_EXT_FL
EXT_FLASH_TRIG
EXT_FLASH_F2 F2_EXT_EVF_SI
EXT_FLASH_F3 F3_EXT_EVF_SCK 26
28
27
F1_EXT_EVF_SOF1_EXT_EVF_SO
X_contact
ID1 - ID3
1 - 3 1 - 3
31 - 3336, 37
18
20
19
F1/EXT_EVF_SO
20 22
X_contact
F2/EXT_EVF_SI
F3/EXT_EVF_SCK
Q3802
MULTI
INTERFACE
SHOE
FLASH CONTROL,
CHARGE CONTROL
(18/34)
IC5800
FLASH POP-UP
DETECT
(2/2)
SE3800
XE_K
UNREG_ACC
2 - 413 - 15
FLASH
UNIT
C901, C902
CHARGING
CAPACITOR
Q5800
FLASH
DRIVE
D5800, D5801
INT_FLASH_FULL
INT_FLASH_TRIG
INT_FLASH_CHARGE
T801
CN803
CN802
XE_A
XE_A
INT_FLASH_UP_SENS
XINT_FLASH_UP_SENSE
+
Q4905
INT_FLASH_FULL,
INT_FLASH_TRIG,
INT_FLASH_CHARGE,
XINT_FLASH_UP_SENSE
I2C_SDA/SCK
XEYE_SENS_OUT_MSS
I2C_SDA/SCK
XEYE_SENS_OUT_MSS
EYEPIECE
SENSOR
(1/2)
SE2700
I2C_SDA,
I2C_SCK
EXT_MIC_R
EXT_MIC_L
EXT_MIC_R
MIC_JACK_INHP_JACK_IN
MIC_JACK_IN MIC IN
DETECT
Q4906
SE7731
3 AXIAL
ACCELERATION
SENSOR
(21/34)
: VIDEO SIGNAL
: AUDIO SIGNAL
: VIDEO/AUDIO SIGNAL
SY-1077 BOARD (2/3)
POWER CONTROL,
MECHANISM CONTROL
(8/34)
IC5700
(2/3)
CPU, CAMERA DSP,
AV SIGNAL PROCESS,
LENS CONTROL,
MODE CONTROL,
HDMI PROCESS
(9/34 - 12/34)
IC6000
(2/3)
CLKIREF
SWITCH
(30/34)
IC9300
CLOCK
GENERATOR
(27/34)
IC9011
VIDEO SIGNAL
PROCESS
(29/34 - 34/34)
IC9012
GCS3_RODP0/RODN0,
GCS3_RODP1/RODN1
GCS3_TODP0/TODN0,
GCS3_TODP1/TODN1
MSS_PCIE_RP/RN_IC_9012
GCS_CLK_BONU_RX
A3
AE21
AJ14
AH30
GCS_CLK_BONU_TX
C19
B20
X9010
74.25MHz
X5000
12MHz
GCS_CLK1
MSS_PCIE_TP/TN_IC_9012
SD1_O0 - O2, SD1_I0 - I2,
MCK1_INOUT, BCK1_OUT,
LRCK1_OUT
X_PERST_IC_9012
VIO_FLD
VIO_CLK
PCIE_REFP_IC_6000,
PCIE_REFN_IC_6000
PCIE_REFP_IC_6000,
PCIE_REFN_IC_6000
PCIE_REFP_IC_9012,
PCIE_REFN_IC_9012
X9011
25MHz
3
2
FIELD_INFO0/INFO1
CLKISTC
BN_CLK_EN
BN_CLK_EN BN_CLK_EN
CLOCK
DIVIDER
(34/34)
IC9401
IC_1501_IC_6000_CLK
OVERALL (1/3)
(PAGE 4-1)
2
OVERALL (1/3)
(PAGE 4-1)
3
AV_SO, AV_SCK
OVERALL (1/3)
(PAGE 4-1)
1
08
HDMI
I2C_SDA/SCK
PLUG IN POWER
SYSSET
2018/04/1801:27:27(GMT+09:00)

ILCE-6500/6500M_L3
4-3
4-3. OVERALL BLOCK DIAGRAM (3/3) ( ) : Number in parenthesis ( ) indicates the division number of schematic diagram where the component is located.
WIRELESS LAN/
BLUETOOTH
MODULE
(19/34)
CP2300
REMOTE SENSOR
CONTROL
SWITCHES
S001 - S003
CONTROL
SWITCHES
S0001 - S0004
LCD ROTATION
DETECT
SE0001
IC0001
USB SELECT
(7/34)
IC5600
USB ACTIVE
SWITCH
Q5702
LED DRIVE
Q0601
WLAN_SDIO_CLK
WLAN_SDIO_CMD
BT_UART_HOST_TXD/RXD
BT_UART_HOST_CTS/RTS
BT_DEV_WAKE
WLAN_HOST_WAKE
WLAN_SDIO_D0 - D3
SY-1077 BOARD (3/3)
CN4001
MULTI
USB_D±_DWN
USB_D±_UM
USB_D±_MSS
USB_D±_MSS
BDR-2000 FLEXIBLE BOARD (2/2)
D0601 CHG_LED_ON
LED DRIVE
Q7890, Q7891 AF_LED_CNTAF_LED_A_EMT
DWN_USB_SEL
USBVOUT
AD_JACK_IN
AD_JACK_IN,
DEBUG_UART0_TXD,
DEBUG_UART0_RXD,
BOOT_SERIAL_IN
DEBUG_UART0_TXD
DEBUG_UART0_RXD,
BOOT_SERIAL_IN
XS_2
XS_1
POWER CONTROL,
MECHANISM CONTROL
(8/34)
IC5700
(3/3)
CHG
10
8
9
12
11
XRESET_REQXRESET_REQ
XRESET_REQ
7
2, 3
CN0001
TH001
2
3
4
7
5, 6
1, 59, 10
CN003
CN001
CN4911 (2/2)
XDIAL_2_A/B
34
9, 11
IR_OUT
XDIAL_2_A/B
SIR_RXD
2
AF_LED_A
30
BATT_TEMP
15, 16
24
256 KEYAD
SIR_RXD, XDIAL_2_A/B,
XDIAL_1_A/B, KEY_AD_0 - 3,
AFMF_LEVER, XMOVIE_REC,
ROTATE_SENS_ON
KEY_AD_1
XDIRECT_PB
KEYAD
XFUNC
XDEL
WHEEL_A/BWHEEL_A/B
S2
KEYAD
S1
S3
WHEEL_A/B
29
38
1
3
4
5
21
37
36
BATT_TEMP
XDIRECT_PBXDIRECT_PB
XS_2
XPOWER_SW
XPOWER_SW,
XMENU,
XDIRECT_PB,
BATT_TEMP
XMOVIE_RECXMOVIE_REC
KEY_AD_2/3
XAEL XAEL
AFMF_LEVER
XMOVIE_REC
XMENU
XS_1
XS_2
XS_1
XMENUXMENU
XMENU
XS_1
DIAL
ROTATION
SENSOR
DIAL
ROTATION
DETECT
PH001, PH002 Q001, Q002
19 AFMF_LEVERAFMF_LEVER
XMOVIE_REC
XAEL
AFMF_LEVER
18 ROTATE_SENS_ON
CONTROL
SWITCH
BLOCK
(BK79700)
D001
AF ILLUMINATOR,
SELF-TIMER,
SMILE SHUTTER
08
CPU, CAMERA DSP,
AV SIGNAL PROCESS,
LENS CONTROL,
MODE CONTROL,
HDMI PROCESS
(9/34 - 12/34)
IC6000
(3/3)
NFC
INTERFACE
(20/34)
IC7401
NFC_L1/L2
NFC_L1/L2NFC_L1/L2
32, 33
ANT901
NFC
ANTENNA
D1100
NFC_SCK, NFC_SEL,
NFC_SW
NFC_IRQ, XNFC_RFDET
NFC_SIO
FR_XRESETXDWN_RESET E5L7
CAM_SI_1
DC/DC CONVERTER
(2/34)
IC5100
DC/DC CONVERTER
(3/34)
IC5200
CAM_SO_1
CAM_SCK_1
CAM_SO_1
CAM_SCK_1
XCS_DD
XCS_IC_5200
: VIDEO/AUDIO SIGNAL
AN-1025 BOARD AN-1006 FLEXIBLE BOARD
J7381 ET7381 J7391
WIRELESS LAN
ANTENNA
ROTATE_SENS_ONROTATE_SENS_ON
12
13
6
7
23
28
20
11
12
1
10
ROTATE_SENS_ON 13
8
3
7
XCUSTOM1XCUSTOM1
XCUSTOM2
MODE_DIAL_A/B
XCUSTOM1
XCUSTOM2
MODE_DIAL_A/B
XDIAL_2_A/B
XCUSTOM2
XFUNCXFUNC
XDEL
KEY_AD_0
XDEL
XAEL
XDIAL_1_A/B
26, 27
4, 5
TF-2000 FLEXIBLE BOARD
OD-2000 FLEXIBLE BOARD
RL-1050 FLEXIBLE BOARD
CN002
CONTROL
SWITCHES
S0001, S0002 XS_2
XS_1
XPOWER_SW
IR_OUT
XS_2
XS_1
XPOWER_SW
SYSSET
2018/04/1801:27:27(GMT+09:00)

ILCE-6500/6500M_L3
4-4
4-4. POWER BLOCK DIAGRAM (1/4) ( ) : Number in parenthesis ( ) indicates the division number of schematic diagram where the component is located.
D0601
DC/DC CONVERTER
(2/34)
IC5100
USB POWER
MANAGEMENT
(7/34)
IC5651
POWER CONTROL,
MECHANISM CONTROL
(8/34)
IC5700
DC/DC CONVERTER
(3/34)
IC5200
PVDD1A
UNREG
UNREG
UNREG_SUB
UNREG_SUB
UNREG_ACC UNREG_CM
UNREG_ACC
D_1.0V, A_1.0V_MSS
D_1.0V, A_1.0V_MSS,
D_1.0V_IC_1200,
A_1.0V_IC_1200
D_3.3V_WLAN
D_3.3V_WLAN
E1
PVDD1B
E2
D1LX1A
D2LX1B
D3FB1
L0101
E8LX6A
E7LX6B
D5FB6
L0106
PVDD3A
D_1.8V, A_1.8V
D_1.8V, D_1.8V_WLAN,
A_1.8V
A1
PVDD3B
B1
A2LX3A
B2LX3B
B2LDO1_FB
C4FB3
L0103
PVDD5A
D_3.15V, D_3.15V_MSS,
A_3.15V_MSS
IS_NEG
D_3.15V, D_3.15V_MEDIA,
D_3.15V_MSS, A_3.15V_MSS
H5
PVDD5B
G5
H4LX5A
G4LX5B
E3FB5
L0105
PVDD6AD8
PVDD6B
D7
PVDD2
D_1.2V
LPDDR2_1.2V
C8 B8LX2
C5FB2
A5LDO1_OUT
L0102
LDO1_ENB
LDO1_ON D6
DD_ON
DD_ON1
USB_CHG_SDA
USB_CHG_SCL
F5
LDO2_ENBE5
A6LDO1_SOURCE
B1PVDD_LDO1
B4LDO2_SOURCE
D_1.2V, IS_1.2V, D_1.2V_IC_1200
D_1.2V
LPDDR2_1.8V
A4LDO2_OUT
C9P5F
E2P2C
G10 P53
G11 P10/AN00
BATT_AD_IN
BATT_AD_ON G4 P45
H10 P50/SIN3
H9P51/SOT3
H8P52/SCK3
E4P2A/INT06
H4P44
B11 VCC_B11
C4P0F/NMIX/WKUP0
L7INITX
A_1.0V_HDMI
A_1.0V_HDMI
D_3.15V_MEDIA
D_3.15V
A1LDO1_OUT
C1LDO1_ON
PVDD4
CAM_5.0V
H6
BATT
E1
BATTG
E2
PVDD_CPH2
AVDD
B7
CSG6
DOUT
E6
DINF6
CLK
CAM_SI_1
XCS_DD
CS
E3
XPOWER_SW
08
E8P5B/INT26 XPWR_OFF
CAM_SO_1
CAM_SCK_1
D1SYS1
UNREG_IC_5651_OUT
UNREG_IC_5651_OUT
D2SYS2
A2SW100
B6PVBUS
G7
DIND3
CLK
CAM_SO_1
CAM_SCK_1
XCS_IC_5200 D4
VO_SELF4
VTR_UNREGE6
UNREG_IN_DET
F2
A4PVDD_LDO2 HDMI_5.0V
DD_ON3
A3LDO2_OUT
B6LOAD_IN
D7P08
A5 LDO2_ON
BATT_IN_IC_5700 E4 UNREG_IN
XPOWER_SW
XPWR_OFF
VUC
C1VCC_C1
J11 VCC_J11
L2VCC_L2
F5 VUC
FR_XRESETXDWN_RESET E5 VUC_RST
MS_3.15V
MS_3.15V
A_1.8V, D_1.8V,
D_1.8V_WLAN, D_1.8V_IC_1200
D_3.15V, D_3.15V_MSS,
D_3.15V_MEDIA,
D_3.15V_IC_9012, A_3.15V_MSS,
D_3.15V_IC_1200, A_3.15V_IC_1200
IS_NEG
D_1.2V, IS_1.2V,
D_1.2V_IC_1200
MS_3.15V
A6LOAD_OUT
EVER_3.0V
EVER_3.15V
LPDDR2_1.2V
LPDDR2_1.8V
A_1.0V_HDMI
CAM_5.0V
MS_3.15V
EVER_3.15V
EVER_3.15V
EVER_3.15V
VBUS_5V
VBUS_5V
VBUS_5V
VBUS_5V
F6 EVER3
F4VCH
MS_PWR_ON MS_PWR_ON
VCH_3V
VCH_3V
B5LOAD_ON
B+
SWITCH
Q5700, Q5701
B+
SWITCH
Q0600
F0005
BATT_1_IB
SY-1077 BOARD (1/4)
UNREG_IC_5651_IN
1
6
15
CN4001
Q5541, Q5542
VBUS1A5
USB_VBUS
USB_VBUS
D_3.15V D_3.15V
D_3.15V_MSS
XPWR_ON
VBUS2B5
SDAC6
USB SELECT
(7/34)
IC5600
CHG
SCLD6
P24/INT00/WKUP1
C2
P3F/INT15
K1
SIO2
J5
P58/SCK1
F8
F0007
P57/SOT1F9
IC_5651_EN
USB_CHG_SDA
USB_CHG_SCL
IC_5651_EN
DD_OND3
MSS_SUS
MSS_SUS MSS_SUS
SUS
C3
MULTI
19
HDMI_5.0V
CN9000
HDMI
D_1.0V, D_1.0V_IC_1200,
A_1.0V_IC_1200
D_3.15V_IC_9012, D_3.15V_IC_1200,
A_3.15V_IC_1200
UNREG
D_1.8V, A_1.8V, D_1.8V_IC_1200
D_1.2V
UNREG_CM
F0004
BN_UNREG
BN_UNREG
F0006
F0001
F0002
POWER (2/4)
(PAGE 4-5)
A
POWER (3/4)
(PAGE 4-6)
B
POWER (4/4)
(PAGE 4-7)
C
POWER (3/4)
(PAGE 4-6)
G
POWER (3/4)
(PAGE 4-6)
D
POWER (2/4)
(PAGE 4-5)
F
POWER (2/4)
(PAGE 4-5)
E
BATTERY
CHECK
B+ SWITCH
Q5520, Q5521
C10 P17/AN07 BATT_TEMP BATT_TEMP
H2 P3A/RTCCO/SUBOUT
LENS_3.1V_ON
F3P33/INT11 LENS_XDETECT LENS_XDETECT
LENS_3.1V_ON
DD_ON2 DD_ON2
DD_ON1
DD_ON2
DD_ON1
UNREG_CUR_ UNREG_BL
UNREG_SUB_
B+ SWITCH
Q5250, Q5252
F0003
J4P43
8, 91 - 7 10 - 16
NET2
NET3
BATT_1_IB
BT-2011
FLEXIBLE
BOARD
BATT_UNREGNET1
CN4901
S
BT901
BATTERY
TERMINAL
FB0600
CHARGE
PUMP
D100
for charge motor drive
DD_ON3
SYSSET
2018/04/1801:27:27(GMT+09:00)

ILCE-6500/6500M_L3
4-5
4-5. POWER BLOCK DIAGRAM (2/4) ( ) : Number in parenthesis ( ) indicates the division number of schematic diagram where the component is located.
EVER_3.15V
LEVEL SHIFT
(15/34)
IC6700
LEVEL SHIFT
(15/34)
IC6702
LEVEL SHIFT
(15/34)
IC6701
LENS_4.8V
MSS_LENS_UNREG_ON
UNREG_SUB_
E_4.9V/A_7.0VE_4.9V/A_7.0V
B+ SWITCH
Q6700, Q6704 (1/2)
Q6704 (2/2)
DISCHARGE
LENS_3.1V
LENS_3.1V_ON
LENS_3.1V_ON
LENS_3.1V_ON
LENS_XDETECT LENS_XDETECT_BODY
EVER_3.15V
B+ SWITCH
Q6706, Q6709
LENS REMOVE
DETECT
Q6703
LENS REMOVE
DETECT
Q6705
VOLTAGE
SELECT
Q102
CPU, CAMERA DSP,
AV SIGNAL PROCESS,
LENS CONTROL,
MODE CONTROL,
HDMI PROCESS
(9/34 - 12/34)
IC6000
(1/2)
SD0_1.8_PWR_ON
D_3.15V,
D_3.15V_MSS,
A_3.15V_MSS
D_3.15V_MSS,
A_3.15V_MSS
H22 USB_CHG_EN
XDD_PFM_ON2
F23 USB_ACV_DET
XDD_VSEL
XDD_VSEL
AB12 ND_DIR_A
CROSSCON_ENB
G10 MMC_XRST
POKB
F14 MMC_CMD LENS_XDETECT
LENS_XDETECT
L16 GPIO_S_9
MS_PWR_ON
K18 GPIO_S_6
SD0_3.1_PWR_ON
N11 TPU3_OUT
D_1.8V, A_1.8V
D_1.0V, A_1.0V_MSS
A_1.0V_HDMI
MS_3.15V
SD_3.15V
SD_1.8V
D_1.2V
LPDDR2_1.8V
LPDDR2_1.2V
XDD_PFM_ON
AB15 AS_PWM1A
SHOE_UNREG_ON
AA16 AS_PWM0B
MSS_SUS
N10 TPU2_OUT
AF_LED_CNT
P10 TPU4_OUT
BT_REG_ON
H8FRC_RTG_OUT1
WL_REG_ON
J7FRC_RTG_IN1
USB_VBUS F21
Q5600
D1101
VBUS_5VXVBUS_DET
GPIO_S_10 K15
XPWR_OFF
SY-1077 BOARD (2/4)
CN1700
6
1
9 - 12
DC/DC CONVERTER
(2/34)
IC5150
VIN
AS_5.5V,
CAM_5.0V,
AUDIO_5.0V,
SHUT_MG_5.5V
CAM_5.0V
2 9VOUT
EN
DD_ON2 3 8FB
DC/DC CONVERTER
(2/34)
IC5151
VIN
UNREG_SUB_
UNREG_SUB_
UNREG_SUB_
2 9VOUT
EN
CROSSCON_ENB_ 3 8FB
PS/SYNC
XDD_PFM_ON 4
PG
POKB 5
17
39
4
13
1
22 - 25
5 - 8
AS_5.5V,
CAM_5.0V,
AUDIO_5.0V,
SHUT_MG_5.5V
MIS-2003 FLEXIBLE
BOARD
MC-2004 BOARD
MB N
CONTACT
UNIT
CN4908 CN7551
UNREG
MULTI
INTERFACE
SHOE
D_3.15V
UNREG_ACC
UNREG_ACC UNREG_ACC
UNREG_ACC
EVER_3.15V
UNREG_ACC
SHOE_UNREG_ON SHOE_UNREG_ON
UNREG_OUT_FL Q8800, Q8801
B+ SWITCH
PS/SYNC
XDD_PFM_ON2 4
POWER (1/4)
(PAGE 4-4)
F
POWER (3/4)
(PAGE 4-6)
I
POWER (3/4)
(PAGE 4-6)
J
CAM_5.0V
POWER (4/4)
(PAGE 4-7)
K
08
POWER (1/4)
(PAGE 4-4)
A
POWER (1/4)
(PAGE 4-4)
E
POWER (3/4)
(PAGE 4-6)
H
VBUS
DETECT
FLASH CONTROL,
CHARGE CONTROL
(18/34)
IC5800
UNREG
EYE_LED_VCC
D_3.15V_ACC_POPUP_VCC
L5800
D5800,
D5801
CN803
CN3800
T801
FLASH POP-UP
DETECT
(2/2)
SE3800
EYEPIECE SENSOR
(1/2)
SE2700
SH-1019 FLEXIBLE BOARD
2 - 4
CN802
+C901, C902
CHARGING
CAPACITOR
FLASH
UNIT
L6041
MSS_LENS_UNREG_ON
H13 MMC_CLK
L6040
L6042
FB6040
EVER_3.15V CHARGE MOTOR
CONTROL
(16/34)
IC6760
EVER_3.15V EXTERNAL
FLASH I/F
(24/34)
IC3801
EVER_3.15V EXTERNAL
FLASH I/F
(24/34)
IC3802
SYSSET
2018/04/1801:27:27(GMT+09:00)

ILCE-6500/6500M_L3
4-6
4-6. POWER BLOCK DIAGRAM (3/4) ( ) : Number in parenthesis ( ) indicates the division number of schematic diagram where the component is located.
DC/DC CONVERTER
(4/34)
IC5300
LX
CN101
CN001
CN201
CN8041
CN8040
1
VIN
BL_H
BL_L
6
5VOUT
3VFB
L0300
6 - 89 - 12
CE 4
REMOTE
SENSOR
IC0001
DIAL
ROTATION
SENSOR
PH001, PH002
19
12
BT101
(LITHIUM BATTERY)
D_1.8V
D_3.15V
AN
CA
VDDIO
VDD
LEDPWM
LCD_PWMLCD_PWM
UNREG_BL
CN4902
D_3.15V
D_3.15V
6, 78, 9
4 - 61 - 3
D_3.15V
A_3.15V_MSS
XPOWER_SW
NFC INTERFACE
(20/34)
IC7401
D_3.15V
LEVEL SHIFT
(22/34)
IC3001
D_3.15V
2
14
D_3.15V_IR
IC_1501_2.8V_2
IC_1501_2.8V_1
A_3.15V_MSS
IC_1501_2.8V
IC_1501_2.8V
A_3.15V_MSS
XPOWER_SW
XPOWER_SW
D_3.15V_IR
A_3.15V_1
A_3.15V
BATT_TEMP
CN4911
35
3
45
38
2
5
BATT_TEMP 30
17
10
51
33
48
MS_3.15V
MS_3.15V
SD_3.15V
MS_VCC
SD_VCC
1, 2 1, 2
VCH_3V
VCH_3V
D4900
(ACCESS)
MEMORY
STICK
PRO DUO
SD
CN-1053 BOARD
SY-1077 BOARD (3/4)
FP-2377
FLEXIBLE
BOARD
BDR-2000 FLEXIBLE BOARD
OD-2000 FLEXIBLE BOARD
TF-2000 FLEXIBLE BOARD
RL-1050 FLEXIBLE BOARD
CN001
CN003
CN002
A_3.15V_2
8
A_3.15V
CN0001
CONTROL
SWITCH
BLOCK
(BK79700)
LC-1022 BOARD
3.0 INCH
COLOR
LCD
LCD901
(LCD MODULE)
LCD902
EVF UNIT
BACKLIGHT
37, 38
43
16
2
45
44
14, 15
9
50
7
8
5
LC-1030
FLEXIBLE
BOARD
BL_H
BL_L
D_3.15V
CN3000
D_1.8V
D_1.8V
EVF_DD_ON
D_3.15V,
A_3.15V_MSS
CN8060
13, 22, 33, 54
EVF_VDD
3, 59
S0002
TH001
ON/OFF
D_3.15V_MEDIA SD_3.15V
SD_3.15V
SD0_3.1_PWR_ON
SD0_3.1_PWR_ON
B+ SWITCH
(6/34)
IC5500
6OUT
D_3.15V
EN3
IN
1
1.8V REG
(6/34)
IC5502
1VOUT
CE
3
VDD
4
D_1.8V
D_1.8V_WLAN
D_3.15V_MSS
CP2300
SD_1.8V
SD_1.8V
SD0_1.8_PWR_ON
SD0_1.8_PWR_ON
SE7731
3 AXIAL
ACCELERATION
SENSOR
(21/34)
D_3.15V_MEDIA
D_3.15V
D_3.15V
D_3.15V
PI_A
SHUT_MG_5.5V
A_1.8V
AUDIO
PROCESSOR
(23/34)
IC8500
AUDIO_5.0V
2.8V REG
(23/34)
IC8501
1VOUT
CE3
VDD
4
AF_LED_A_EMT AF_LED_ACAM_5.0V
AF_LED_CNT
AF_LED_CNT
AF_LED_CNT
LED
DRIVE
Q7890, Q7891
2
D001
AF ILLUMINATOR,
SELF-TIMER,
SMILE SHUTTER
L5320
DC/DC CONVERTER
(4/34)
OVERVOLTAGE
PROTECTOR
IC5321
Q5321
8OUT
7FB
UNREG
D_3.15V VIN2EN5
VO 10
SW
9
08
UNREG
D_1.8V, D_1.8V_WLAN,
A_1.8V D_1.8V
D_3.15V, D_3.15V_MEDIA,
D_3.15V_MSS, A_3.15V_MSS
MS_3.15V
POWER (1/4)
(PAGE 4-4)
B
POWER (1/4)
(PAGE 4-4)
D
POWER (1/4)
(PAGE 4-4)
G
POWER (2/4)
(PAGE 4-5)
I
POWER (2/4)
(PAGE 4-5)
H
AS_5.5V,
CAM_5.0V,
AUDIO_5.0V,
SHUT_MG_5.5V
POWER (2/4)
(PAGE 4-5)
J
D_3.3V_WLAN
D_1.2V
D_3.3V_WLAN
SHUTTER
UNIT
6, 7
12
10
D_3.15V
D_1.2V
STEADYSHOT
PROCESSOR
(14/34)
IC1501
D_3.15V
5.0V REG
Q103, Q104
2.8V REG
(14/34)
IC1503
1VOUT
CE
3
VDD
4
AS_5.5V MT_5.0V
IC_1501_2.8V
IC_1501_2.8V
TEBURE
UNIT
CN1501
9, 13, 17
IC_1501_2.8V
LCD ROTATION
DETECT
SE0001
GY-1012 BOARD
1
7
CN201
SE301
3 AXIAL
ACCELERATION
SENSOR
(2/2) PITCH/YAW
SENSOR
(1/2)
SE7701
GY-1008 BOARD
CN001 ROLL
SENSOR
SE7711
ROLL SENSOR
AMP
IC7711
1
3, 4
CN1811
WIRELESS LAN/
BLUETOOTH
MODULE
(19/34)
1
D_3.15V
CN003
BT_REG_ON
WL_REG_ON
WL_REG_ON
BT_REG_ON
BT_REG_ON 7
WL_REG_ON 24
TOUCH
PANEL
SYSSET
2018/04/1801:27:27(GMT+09:00)

ILCE-6500/6500M_L3
4-7E
4-7. POWER BLOCK DIAGRAM (4/4) ( ) : Number in parenthesis ( ) indicates the division number of schematic diagram where the component is located.
D_1.8V +1.8V_BN
+3.15V_BN
BN_CLK_EN
B+ SWITCH
(28/34)
IC9103
VIN2
B4 A4VOUT2
VIN1
B1 A1VOUT1
D_3.15V_IC_9012
EN1A2
BN_PW1 EN2A3
D_1.8V +1.8V_BN_WDRAM
+1.2V_BN_WDRAM
B+ SWITCH
(28/34)
IC9102
VIN2
B4 A4VOUT2
VIN1
B1 A1VOUT1
D_1.2V
EN1A2
EN2A3
VCC
B2
+1.1V_BN_GCS
B+ SWITCH
(28/34)
IC9101
VIN
3 4VOUT
+1.1V_BONU_CORE
2
BN_PW3
D_3.15V_IC_9012
D_3.15V_IC_9012
+2.5V_BN_PLL
2.5V REG
(28/34)
IC9104
VDD
4 1VOUT
CE
3
B+ SWITCH
(27/34)
IC9010
VIN
3 4VOUT
2
D_1.0V +0.4V_BN_GCS
0.4V REG
(28/34)
IC9105
CLOCK DIVIDER
(34/34)
IC9401
CLOCK
GENERATOR
(27/34)
IC9011
SWITCH
(30/34)
IC9300
VIN
8 1VOUT
2FBEN7
VDDA 4
VIDEO SIGNAL
PROCESS
(29/34 - 34/34)
IC9012
VDGITXREFR
C26
VDGIRXREFR G16
FB9400
FB9200
FB9201
FB9010
VCCB2
D_3.15V_IC_9012, D_3.15V_IC_1200,
A_3.15V_IC_1200
D_1.2V, IS_1.2V, D_1.2V_IC_1200
D_1.8V, A_1.8V, D_1.8V_IC_1200
IS_5.0V
IS_5.0V
IS_NEG
IS_NEG
D_1.8V
D_1.8V
BN_CLK_EN
BN_PW1
FRC_RTG_OUT3 J8
FRC_RTG_OUT2 K7
FRC_RTG_IN0 J6
SD0_SPDIF_OUT
AE20
BN_PW3
BN_PW2
CPU, CAMERA DSP,
AV SIGNAL PROCESS,
LENS CONTROL,
MODE CONTROL,
HDMI PROCESS
(9/34 - 12/34)
D_1.0V, D_1.0V_IC_1200,
A_1.0V_IC_1200
SY-1077 BOARD (4/4)
08
IS_NEG
POWER (1/4)
(PAGE 4-4)
C
VIN113
9SW1
VIN2
14
10SW2
11SW3
16VO
VCC
D9101
D9102
15
EN BN_PW2
BN_UNREG
CAM_5.0V
6
DC/DC CONVERTER
(28/34)
IC9100
L9100
POWER (2/4)
(PAGE 4-5)
K
IC6000
(2/2)
CN0401
CN0400
IS_1.2VIS_1.2V B+ SWITCH
Q0405, Q0406 (1/2)
Q0402
ISP-2004
FLEXIBLE
BOARD
IS-1027 BOARD
ISL-2005
FLEXIBLE
BOARD
Q0406 (2/2)
DISCHARGE
VDDSUB
IS_PWR_ON1
IS_PWR_ON1
IS_PWR_ON5
IS_PWR_ON4
IS_VDD_SUB/HAN/HDA,
IS_VDD_HCM
CN6001
CN6002
IS_VDD_HPX/HVS
4.5V REG
IC6002
1VOUT
CE
3
VDD
4
2 - 5
19, 20
-UNREG
17, 18
VDDLLP1/LPL2,
VDDLIF
23, 24
13
10
VDDHAN/HDA
4.5V REG
IC6003
1VOUT
CE/CE
3
VDD
4
IS_PWR_ON3
16 IS_PWR_ON4
17 IS_PWR_ON5
19 IS_PWR_ON6
20
IS_PWR_ON1 13
IS_PWR_ON3 16
IS_PWR_ON4 17
IS_PWR_ON5 19
IS_PWR_ON6 20
IS_PWR_ON5
4.1V REG
IC6004
1VOUT
3
VDD
4
B+ SWITCH
Q6003, Q6006
IS_PWR_ON4
VDDHCM
4.5V REG
IC6005
1VOUT
CE
3
VDD
4
IS_PWR_ON5
4.1V REG
IC6006
CMOS IMAGER
IC6001
1VOUT
CE
3
VDD
4
VDDMIO/MPX
-1.5V REG
IC6014
4 VOUT
CONT1
VEE_3 3
B+ SWITCH
Q6004, Q6007
IS_PWR_ON6
VDDHPX/HVS
4.5V REG
IC6008
1VOUT
EN
3
VIN
4
IS_PWR_ON5
VRLS15
VRLT12
IS_PWR_ON3
B+ SWITCH
IC6015
4VOUT
CE
2
VIN
3VDDMIO/MPX
VDDLSC/LSA
6 - 9
VDDLCB/LCN
VDDLSC/LSA
VDDLCB/LCN
13 - 16
IS_5.0V
2 - 5
19, 2017, 1823, 24
10
6 - 913 - 16
IS_PWR_ON6
B+ SWITCH
IC6010
4VOUT
2
VIN
3VDDLIF
VDDLPLA/LPLD
1.8V REG
IC6009
1VOUT
CE
3
VDD
4
B+ SWITCH
Q6001, Q6002
CAMERA SIGNAL PROCESS
(13/34)
IC1200
A_1.8V LVDS_1.8V_MSS
L1202
IS_PWR_ON1
V8GPIO_12
IS_PWR_ON2
U8GPIO_13
IS_PWR_ON3
W7GPIO_14 IS_PWR_ON4
IS_PWR_ON5
IS_PWR_ON6
V7GPIO_15
AB10 GPIO_3
AB8 GPIO_4
L5152
D_1.2V_IC_1200
A_1.0V_IC_1200
L1212
L1203
A_3.15V_IC_1200
CE/CE
CE/CE
D_1.0V_IC_1200
L1200
D_1.8V_IC_1200
L1201
D_3.15V_IC_1200
CE/CE
CE/CE
L6004,
L6005
SYSSET
2018/04/1801:27:27(GMT+09:00)

ILCE-6500/6500M_L3
5-1
5. FRAME SCHEMATIC DIAGRAMS
5-1. FRAME SCHEMATIC DIAGRAM (1/2)
116
127
2
1
50
51
116
116 201
16
2
1
139
238
50
51
20 1
1
2
19
18
2
1
50
51
CN1700
CN0400 CN0401
CN4901
CN4902 CN4903
CN4908
CN4910
CN4911
CN3000
J7381
CN1501
15
615
TOUCH
PANEL
SY-1077 BOARD (SIDE A) SY-1077 BOARD (SIDE B)
1
260
61
CN8060
ISL-2005 FLEXIBLE BOARD
ISP-2004 FLEXIBLE BOARD
1
1
51
51
1
1
27
27
CN4001
CN9000
IS-1027 BOARD (SIDE A)
IS-1027 BOARD (SIDE B)
SHUTTER
UNIT
HP-1011
FLEXIBLE
BOARD
FP-2377
FLEXIBLE
BOARD
TEBURE
UNIT
EVF UNIT
LCD902
LC-1030 FLEXIBLE BOARD
1
1
1
51
51
51
CN001
LC-1022 BOARD
161
16
61
CN8040
CN8041
(N.C.)
LCD901
(LCD MODULE)
BACKLIGHT
3.0 INCH
COLOR
LCD
MB N
CONTACT
UNIT
CN-1053 BOARD
(SIDE A)
CN-1053 BOARD
(SIDE B)
1
1
39
16 1 20
BT101
(LITHIUM BATTERY)
S
BT901
BATTERY
TERMINAL
16
1
BT-2011 FLEXIBLE BOARD
MC-2004 BOARD
SP901
(SPEAKER)
FLASH
UNIT
C901
CHARGING
CAPACITOR
C902
CHARGING
CAPACITOR
SH-1019 FLEXIBLE BOARD
MIS-2003 FLEXIBLE BOARD
MULTI
INTERFACE
SHOE
MIC901
(MICROPHONE)(L)
MIC902
(MICROPHONE)(R)
COAXIAL CABLE
AN-1006
FLEXIBLE
BOARD
WIRELESS LAN
ANTENNA
AN-1025 BOARD
BDR-2000
FLEXIBLE
BOARD
(Page 5-2)
A
12
21
116
24 1
CN802
PINK
HARNESS
BLK
CN803
CN1811
151127
CN6001 CN6002
2
1
38
39
CN101
126
CN201
133
39 1
CN3800
ET7381
J7391
16
J001
RED
BLK
331
121
CN7551
BLK ORG BLK ORG
HDMI
MULTI
PLUG IN
POWER
CN003
CN002
16
SYSSET
2018/04/1801:27:27(GMT+09:00)

ILCE-6500/6500M_L3
5-2E
5-2. FRAME SCHEMATIC DIAGRAM (2/2)
GY-1012 BOARD
BDR-2000
FLEXIBLE BOARD
RL-1050
FLEXIBLE BOARD
TF-2000
FLEXIBLE BOARD
OD-2000
FLEXIBLE BOARD
ON/OFF
C1
C2
MENU
(AF/MF - AEL)
CONTROL
SWITCH
BLOCK
(BK79700)
SY-1077
BOARD
(SIDE A)
(Page 5-1)
A
NFC
ANTENNA
ANT901
S0001, S0003
114
16
110
CN001
CN002
CN003
1
112 61
12
CN201
SE7701
PITCH/YAW
16
CN001
GY-1008 BOARD
61
151
S0001
(SHUTTER)
S0002
S001
(MODE)
S002 S003
114 1 10
18
CN0001
S0001
S0002
S0003
S0004
(MOVIE)
SYSSET
2018/04/1801:27:27(GMT+09:00)

ILCE-6500/6500M_L3
6-1
回路図ノート
・ ケミコン，タンタルを除くコンデンサで，耐圧50V以下の
ものはその耐圧を省略。単位はすべてμF（pはpF）。
・ チップ抵抗で指示のないものは，1/10W以下。
 kΩ＝1000Ω，MΩ＝1000kΩ
・ チップ部品交換時の注意
 取り外した部品は再使用せず，未使用の部品をご使用く
ださい。
 タンタルコンデンサのマイナス側は熱に弱いため注意し
てください。
・ チップ部品には下記のように表示したものがあります。
 例 C541 L452
  22U 10UH
  TA A 2520
  種類 外形寸法（mm）
  ケースサイズ
・ 抵抗，コンデンサ，ICなど定数にXXがあるものは，使用
していない事を示しています。このため，使用していな
い回路が記載されている事があります。
・ ★印のある部品は，機種などにより異なりますので機能
別マウント一覧表を参照してください。
・ 可変抵抗と半固定抵抗で，B特性の表示を省略。
・ 信号名表記について，下記のような場合があります。
 XEDIT → EDIT PB/XREC → PB/REC
・ は不燃性抵抗。
・ はヒューズ抵抗。
・ はパネル表示名称。
・ はB＋ライン。
・ はB−ライン。
・ はBライン（＋，−）の入出力方向を示す。
・ は調整名称。
6. SCHEMATIC DIAGRAMS AND PRINTED WIRING BOARDS
THIS NOTE IS COMMON FOR SCHEMATIC DIAGRAMS AND PRINTED WIRING BOARDS
(In addition to this, the necessary note is printed in each block)
– ENGLISH –
21
3
21
3
21
3
345
21
123
654
EB
C
31
5
2
46
123
654
31
5
2
46
123
54
43
12
312
45
534
12
14
23
46
2
5
31
12
43
14
23
For Schematic Diagrams
• All capacitors are in μF unless otherwise noted. pF : μ
μF. 50 V or less are not indicated except for electrolytics
and tantalums.
• Chip resistors are 1/10 W unless otherwise noted.
kΩ=1000 Ω, MΩ=1000 kΩ.
• Caution when replacing chip parts.
New parts must be attached after removal of chip.
Be careful not to heat the minus side of tantalum
capacitor, Because it is damaged by the heat.
• Some chip part will be indicated as follows.
Example C541 L452
22U 10UH
TA A 2520
Kinds of capacitor External dimensions (mm)
Case size
• Constants of resistors, capacitors, ICs and etc with XX
indicate that they are not used.
In such cases, the unused circuits may be indicated.
• Parts with ★differ according to the model/destination.
Refer to the mount table for each function.
• All variable and adjustable resistors have characteristic
curve B, unless otherwise noted.
• Signal name
XEDIT EDIT PB/XREC PB/REC
•: non flammable resistor
• : fusible resistor
• : panel designation
• : B+ Line
• : B– Line
• : IN/OUT direction of (+, –) B LINE.
• : adjustment for repair.
Precautions for Replacement of Imager
• If the imager has been replaced, carry out all the adjustments for the
camera section.
• As the imager may be damaged by static electricity from its structure,
handle it carefully like for the MOS IC.
In addition, ensure that the receiver is not covered with dusts nor
exposed to strong light.
The components identified by mark 0
or dotted line with mark 0are critical
for safety.
Replace only with part number specified.
Les composants identifiés par une
marque 0sont critiques pour la sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
When indicating parts by reference num-
ber, please include the board name.
For Printed Wiring Boards
• : Uses unleaded solder.
•: Circuit board
: Flexible board
Pattern from the side which enables seeing.
: pattern of the rear side
(The other layers’ patterns are not indicated)
• Through hole is omitted.
• There are a few cases that the part printed on diagram
isn’t mounted in this model.
• : panel designation
• Chip parts.
Transistor Diode
回路図，プリント図共通ノート
（他に必要なノートは各セクションに記載しています）
プリント図ノート
・ ：無鉛半田を使用しています。
・ ：基板
 ：フレキシブル配線板
 見ている面側のパターン。
 ：裏側のパターン
 （他のパターンについては表示されていません）
・ スルーホールは省略。
・ プリント図には，本機で使用していない部品が記載さ
れている場合があります。
・ はパネル表示名称。
• Chipparts.
 Transistor Diode
21
3
21
3
21
3
345
21
123
654
EB
C
31
5
2
46
123
654
31
5
2
46
123
54
43
12
312
45
534
12
14
23
46
2
5
31
12
43
14
23
イメージャ交換時の注意
・ イメージャを交換した場合は，カメラ部の全調整を行って
ください。
・ イメージャは構造上，静電気により破壊される恐れがある
ため，MOSICと同様に注意して取り扱ってください。
 また，受光部にはゴミの付着，および強い光がはいること
のないように注意してください。
0印の部品，または0印付の点線で囲まれた部品は，
安全性を維持するために，重要な部品です。
従って交換時は，必ず指定の部品を使用してください。
図面番号で部品を指定するときは基板名又はブロック
を併せて指定してください。
お願い
– JAPANESE –
SYSSET
2018/04/1801:27:27(GMT+09:00)

ILCE-6500/6500M_L3
6-2
6-1. SCHEMATIC DIAGRAMS
S
S
S
IS-1027 BOARD
XX MARK: NO MOUNT
S
DOM07
DOP07
DOM06
DOP06
DOM05
DOP05
DOM04
DOP04
DOM03
DOP03
DOM02
DOP02
DOM01
DOP01
DOM00
DOP00
XCE
SCK
SDI
SDO
VDDHPX/HVS
C6116
XX
C6110
XX
Q6008
XX
Q6005
XX
12
3
4
56
R6002
XX
R6001
XX
R6003
XX
R6018
XX
R6013
XX
R6014
XX
R6012
XX
R6020
XX
R6021
XX
R6022
XX
R6023
XX
R6024
XX
R6025
XX
IC6007
XX
1
VOUT
2
GND
3
EN
4
VIN
5
C6127
XX
IC6013
XX
1
CONT
2
GND
3
VEE_3
4
VOUT
5
NC
6
CN
7
R6019
XX
R6028
XX
R6029
XX
R6030
XX
R6031 XX
IC6016
XX
1
AE
2
GND
3
CEVDD
4
NC
5
VOUT
6
IC6017
XX
1
AE
2
GND
3
CEVDD
4
NC
5
VOUT
6
C6133
XX
C6134 XX
IC6001
IMX284AQL-13
CMOS IMAGER
TAMON4
R13
TAMON3
T12
TAMON2
T2
TAMON1
R1
VSSLIF_P11
P11
VSSLIF_P8
P8
VSSLIF_N11
N11
VSSLIF_M11
M11
VSSLIF_M10
M10
VSSLIF_M4
M4
VSSLIF_M3
M3
DOM11
N10
DOP11
P10
DOM10
R10
DOP10
T10
DOM09
N9
DOP09
P9
DOM08
R9
DOP08
T9
DOM07
N7
DOP07
P7
DOM06
R7
DOP06
T7
DCKM
R8
DCKP
T8
DOM05
N6
DOP05
P6
DOM04
R6
DOP04
T6
DOM03
N5
DOP03
P5
DOM02
R5
DOP02
T5
DOM01
N4
DOP01
P4
DOM00
R4
DOP00
T4
VSSLIF_M9
M9
VDDLIF_M8
M8
VSSLIF_N8
N8
VDDLIF_M7
M7
VSSLIF_M5
M5
VDDLIF_M6
M6
INCK
L6
VSSLSC_L7
L7
VDDMIO1
L5
VDDHDA_L4
L4
VSSHDA_L3
L3
VDDHAN
L8
VSSHAN
L9
VDDHCM1_D1
D1
VSSHCM1_D2
D2
VDDHCM1_K1
K1
VSSHCM1_K2
K2
VDDLCB1_E1
E1
VSSLCB1_E2
E2
VDDLCB1_H1
H1
VSSLCB1_H2
H2
VDDLCN_F4
F4
VSSLCN_F3
F3
VDDLCN_H4
H4
VSSLCN_H3
H3
VSSLCN_G4
G4
VSSLCN_G3
G3
VDDLCN_K4
K4
VSSLCN_K3
K3
VDDLPLD1
M1
VSSLPLD1
M2
VDDLPLD2_3_P3
P3
VSSLPLD2_3_N3
N3
VDDLPLA1
P1
VSSLPLA1
P2
VDDLPLA2
T3
VSSLPLA2
R3
VLOADCM1
A3
VSSHPX_B3
B3
VLOADCMSF2
A5
VSSHPX_B5
B5
VLOADLM2
A4
VSSHPX_B4
B4
VDDLSC_F1
F1
VSSLSC_F2
F2
VDDLSC_G1
G1
VSSLSC_G2
G2
VDDLSC_L1
L1
VSSLSC_L2
L2
VDDLSA1
N1
VSSLSA1
N2
NC1_A12
A12
NC1_B2
B2
NC1_B12
B12
NC1_B13
B13
VDDHPX_C1
C1
VSSHPX_C2
C2
VDDHPX_C13
C13
VSSHPX_C12
C12
VDDHPX_J1
J1
VSSHPX_J2
J2
VDDHPX_J13
J13
VSSHPX_J12
J12
VDDMPX
A7
VSSHPX_B7
B7
VDDHVS
A8
NC1_D3
D3
VRM
B8
NC1_D4
D4
VRLT
A6
NC1_E3
E3
VRLS
B6
NC1_E4
E4
VDDSUB1
C3
VSSHPX_C4
C4
VDDSUB2
C11
VSSHPX_C10
C10
BIASRESBC1
J3
VBGR1
J4
VBGR2
J10
BIASRESBC2
J11
VDDMIO2
F7
VSSLSC_F8
F8
XCLR
D10
XCE
D9
SCK
E9
SDO
F9
SDI
E10
XVS
E8
XHS
D8
XPI
E6
TIN0
E5
TOUT0
D5
TIN1
D6
TOUT1
E7
TENABLE
F6
TSCANEN
F5
TVCDSIND
B1
TVDSUN
A2
VSSLSC_D7
D7
NC2
R2
NC3
R12
NC1_E11
E11
NC1_D11
D11
NC1_C9
C9
NC1_C8
C8
NC1_C7
C7
NC1_C6
C6
NC1_C5
C5
VSSLSA2
N12
VDDLSA2
N13
VSSLSC_L12
L12
VDDLSC_L13
L13
VSSLSC_G12
G12
VDDLSC_G13
G13
VSSLSC_F12
F12
VDDLSC_F13
F13
VSSHPX_B10
B10
VLOADLM1
A10
VSSHPX_B9
B9
VLOADCMSF1
A9
VSSHPX_B11
B11
VLOADCM2
A11
VSSLPLA3
P12
VDDLPLA3
P13
VSSLPLD2_3_R11
R11
VDDLPLD2_3_T11
T11
VSSLPLD4
M12
VDDLPLD4
M13
VSSLCN_K11
K11
VDDLCN_K10
K10
VSSLCN_G11
G11
VSSLCN_G10
G10
VSSLCN_H11
H11
VDDLCN_H10
H10
VSSLCN_F11
F11
VDDLCN_F10
F10
VSSLCB2_H12
H12
VDDLCB2_H13
H13
VSSLCB2_E12
E12
VDDLCB2_E13
E13
VSSHCM2_K12
K12
VDDHCM2_K13
K13
VSSHCM2_D12
D12
VDDHCM2_D13
D13
VSSHDA_L11
L11
VDDHDA_L10
L10
R6032
XX
R6035
XX
DOM04
DOP07
DOM06
DOM07
DOP05
DOM05
DOP06
DOP04
DOM03
DOP03
DOM02
DOP02
DOM01
DOP01
DOM00
XCLR
SDO
SCK
SDI
XCE
XHS
XVS
DOP00
XPI
XCLR
IS_PWR_ON2
IS_PWR_ON1
VDDLPLA/LPLD
VDDLPLA/LPLD
VDDLSC/LSA
VDDLSC/LSA
VDDSUB
VDDMIO/MPX
VDDMIO/MPX
VRLS15
VRLS15
IS_PWR_ON4
IS_PWR_ON5
IS_PWR_ON6
VDDLCB/LCN
VDDLCB/LCN
VRLT12
VRLT12
REG_GND
XVS
XHS
XPI
VDDHAN/HDA
VDDHAN/HDA
VDDHCM
VDDHCM
VDDHPX/HVS
VDDHPX/HVS
VDDHPX/HVS
VDDHPX/HVS
IS_PWR_ON3
C6098 0.1u
C6119
10u
C6108
0.0022u
C6111
1u
C6094 10u
C6095 0.1u
C6090 10u
C6091 0.1u
C6086 10u
C6087 0.1u
C6083 0.1u
C6079 0.1u C6075 0.1u
C6059 0.001u C6055 0.1u C6052 0.001u C6045 0.0033u
C6037 0.1u C6033 0.1u C6031 0.1u
C6089 10u C6088 0.1u
C6084 0.1u C6080 0.1u C6072 0.1u
C6064 0.001u
C6060 0.1u C6056 0.001u
C6050 0.0033u
C6097 10u C6096 0.1u
C6093 10u C6092 0.1u
C6040 0.1u C6038 0.1u
C6015 0.1u
C6017 0.1u
C6019 0.1u
C6020 0.1u
C6023 0.1u
C6025 1u
C6026 1u
C6016 0.1u
C6113
22u
C6122
10u
C6120
10u
C6112
1u
C6076 0.1u C6066 0.1u
C6018 0.1u
CL6025
CL6007
Q6006
Q6003, Q6006
B+ SWITCH
RN1104MFV(TL3S
Q6003
SSM6J213FE,RSOYF (A
12
3
4
56
R6016
100k
TH6001
C6004 10u
C6005 10u
C6006 10u
C6007 10u
C6009 10u
C6030 10u
C6032 10u C6051 0.1u C6054 10u C6058 0.1u C6074 10u
C6078 10u
C6039 10u C6041 10u C6057 0.1u C6061 10u C6065 0.1u
C6081 10u C6085 10u
C6103 10u
C6043 0.1u
C6071 0.1u C6070 22u C6069 0.1u C6068 22u C6063 0.1u C6062 22u
C6048 10u
C6049 0.1u
C6082 10u
C6036 10u C6028 10u
C6029 0.1u
C6073 22u C6067 22u C6044 10u C6035 10u C6034 0.1u
C6008 10u
R6004 47k
R6005 47k
C6014 10u
C6001
47u
10V
C6102 10u
C6101 0.1u
C6106
0.1u
C6099 0.1u C6104 10u
C6100 0.1u C6105 10u
C6011 1u C6022 0.1u
C6010 1u C6021 0.1u
R6007
1k
C6027
0.1u
C6024
0.01u
C6012 0.47u
C6013 0.47u
CN6001 27P
1REG_GND
2IS_VDD_HCM
3IS_VDD_HCM
4
IS_VDD_SUB/HAN/HDA
5
IS_VDD_SUB/HAN/HDA
6VDDLSC/LSA
7VDDLSC/LSA
8VDDLSC/LSA
9VDDLSC/LSA
10 VDDMIO/MPX
11 REG_GND
12 REG_GND
13 VDDLCB/LCN
14 VDDLCB/LCN
15 VDDLCB/LCN
16 VDDLCB/LCN
17 -UNREG
18 -UNREG
19
IS_VDD_HPX/HVS
20
IS_VDD_HPX/HVS
21 REG_GND
22 REG_GND
23 VDDLLP1/LPL2
24 VDDLIF
25 REG_GND
26 REG_GND
27 IMG_TEMP
28 29
C6121
10u
C6114
1u
C6109
0.0022u C6115
1u
Q6007
RN1104MFV(TL3S
Q6004
SSM6J213FE,RSOYF (A
12
3
4
56
C6118
1u
Q6002
RN1104MFV(TL3S
Q6001
RW1A030APT2CR
Q6001, Q6002
B+ SWITCH
12
3
4
56
CN6002 51P
1REG_GND
2XVS
3XHS
4REG_GND
5REG_GND
6XPI
7XCE
8SDI
9SCK
10 SDO
11 XCLR
12 REG_GND
13 IS_PWR_ON1
14 IS_PWR_ON2
15 REG_GND
16 IS_PWR_ON3
17 IS_PWR_ON4
18 REG_GND
19 IS_PWR_ON5
20 IS_PWR_ON6
21 REG_GND
22 REG_GND
23 REG_GND
24 REG_GND
25 REG_GND
26 REG_GND
27 REG_GND
28 ISRX_D0N
29 ISRX_D0P
30 REG_GND
31 ISRX_D1N
32 ISRX_D1P
33 REG_GND
34 ISRX_D2N
35 ISRX_D2P
36 REG_GND
37 ISRX_D3N
38 ISRX_D3P
39 REG_GND
40 ISRX_D4N
41 ISRX_D4P
42 REG_GND
43 ISRX_D5N
44 ISRX_D5P
45 REG_GND
46 ISRX_D6N
47 ISRX_D6P
48 REG_GND
49 ISRX_D7N
50 ISRX_D7P
51 REG_GND
52 53
L6003
10uH
L6004
10uH
L6005
10uH
R6017
100k
R6015
100k
C6002
47u
C6003
47u
CL6021
C6123
0.0022u
IC6010
R5540K002D-TR
B+ SWITCH
1
GND
2
CE/CE
3
VIN
4
VOUT
C6125
1u
C6126
1u
IC6003
RP130K451D-TR
4.5V REG
1
VOUT
2
GND
3
CE/CE
4
VDD
5
IC6004
RP130K411D-TR
4.1V REG
1
VOUT
2
GND
3
CE/CE
4
VDD
5
IC6002
MM3411A45RRE
4.5V REG
1
VOUT
2
GND
3
CE
4
VDD
5
IC6005
MM3411A45RRE
4.5V REG
1
VOUT
2
GND
3
CE
4
VDD
5
IC6006
MM3571A41RRE
4.1V REG
1
VOUT
2
GND
3
CE
4
VDD
5
IC6008
LP5907SNX-4.5/NOPB
4.5V REG
1
VOUT
2
GND
3
EN
4
VIN
5
IC6009
MM3411A18RRE
1.8V REG
1
VOUT
2
GND
3
CE
4
VDD
5
C6128
1u
C6129
0.01u
C6130
1u
IC6014
MM1898A15RRE
-1.5V REG
1
CONT
2
GND
3
VEE_3
4
VOUT
5
NC
6
CN
7
IC6015
R5540K002D-TR
B+ SWITCH
1
GND
2
CE/CE
3
VIN
4
VOUT
C6131
1u
C6132
1u
COM601
COM602
COM603
COM604
COM605
COM606
COM607
COM608
C6117
22u
C6077 10uC6135 10u
R6033
100
R6034
390
X6001
72MHz
1
ST/OE
2
GND
3
OUTPUT_CLK
4
VDD
CM6001
CM6002
CM6003
CM6004
CM6005
CM6006
CM6007
CM6008
CM6009
Q6004, Q6007
B+ SWITCH
ISP-004
FLEXIBLE
LND002
ISL-2005
FLEXIBLE
LND001
SYSSET
2018/04/1801:27:27(GMT+09:00)

ILCE-6500/6500M_L3
6-3
ISP-2004 FLEXIBLE BOARD
(PRINTED WIRING BOARD is omitted.)
LND002 27P
1REG_GND
2VDD
3VDD
4REG_GND
5REG_GND
6VDD
7VDD
8REG_GND
9REG_GND
10 VDD
11 REG_GND
12 REG_GND
13 VDD
14 VDD
15 VDD
16 VDD
17 VDD2
18 VDD3
19 VDD
20 VDD
21 REG_GND
22 REG_GND
23 VDD
24 VDD
25 REG_GND
26 REG_GND
27 TEMP
LND001 27P
1REG_GND
2VDD
3VDD
4REG_GND
5REG_GND
6VDD
7VDD
8REG_GND
9REG_GND
10VDD
11REG_GND
12REG_GND
13VDD
14VDD
15VDD
16VDD
17VDD2
18VDD3
19VDD
20VDD
21REG_GND
22REG_GND
23VDD
24VDD
25REG_GND
26REG_GND
27TEMP
SY-1077
(5/34)
CN0400
IS-1027
CN6001
ISL-2005 FLEXIBLE BOARD
(PRINTED WIRING BOARD is omitted.)
LND002 51P
1GND
2XVS
3XHS
4GND
5VREF_ON
6XPI
7XCE
8SDI
9SCK
10SDO
11XCLR
12GND
13DP00
14DM00
15GND
16DP01
17DM01
18GND
19DP02
20DM02
21GND
22DP03
23DM03
24GND
25DP04
26DM04
27GND
28DP05
29DM05
30GND
31DPCK
32DMCK
33GND
34DP06
35DM06
36GND
37DP07
38DM07
39GND
40DP08
41DM08
42GND
43DP09
44DM09
45GND
46DP10
47DM10
48GND
49DP11
50DM11
51GND
LND001 51P
1GND
2 XVS
3XHS
4GND
5GND
6 XPI
7XCE
8SDI
9SCK
10 SDO
11 XCLR
12 GND
13 DP00
14 DM00
15 GND
16 DP01
17 DM01
18 GND
19 DP02
20 DM02
21 GND
22 DP03
23 DM03
24 GND
25 DP04
26 DM04
27 GND
28 DP05
29 DM05
30 GND
31 DPCK
32 DMCK
33 GND
34 DP06
35 DM06
36 GND
37 DP07
38 DM07
39 GND
40 DP08
41 DM08
42 GND
43 DP09
44 DM09
45 GND
46 DP10
47 DM10
48 GND
49 DP11
50 DM11
51 GND
IS-1027
CN6002
SY-1077
(5/34)
CN0401
SYSSET
2018/04/1801:27:27(GMT+09:00)
