Sony PFM-42B2 User guide

MODEL:
DESCRIPTION:
DIMENSIONS
(WHD):
WEIGHT:
PFM-42B2 DESCRIPTION:
DIMENSIONS
(WHD):
WEIGHT:
POWER
REQUIREMENTS:
POWER
CONSUMPTION:
42" Flat Panel
Monitor
40 3/4 " X 24 7/8 X 3 3/4"
65 lbs. 8 oz.
120/240V
50/60Hz
400w
max
Features and specifications subject to change without notice. • Non-metric weights and measurements are approximate.
NOTE:
WHERE THERE ARE CLOSE TOLERANCES INVOLVED IN CABINET BUILDING
OR APPLICATIONS WHICH REQUIRE A GREAT DEGREE OF PRECISION WE
RECOMMEND THAT THE PRODUCT ITSELF BE USED TO MAKE THE ACTUAL
MEASUREMENTS. SONY WILL NOT BE RESPONSIBLE FOR INACCURACIES
IN THE DESIGN OR MANUFACTURE OF ENCLOSURES .
Consumer Integrated Systems • Park Ridge, New Jersey 07656 • FAX [phone] • b2b.sel.sony.com
FRONT VIEW
TOP VIEW
BACK VIEW
RGB 2
RGB/ YUV AUDIO
INPUT1
RGB/ YUV AUDIO
INPUT2
AUDIO OUT COMPOSITE Y/CIN AUDIOIN
VIDEO
IN OUT
RS-232REMOTE
SIDE VIEW
21 7/8 "
40 3/4 "
24 7/8 "
3 1/4 "
1/2 "
15 3/4 " 12 7/16 "
15 3/4 "
4 9/16 "
37 7/8 "
RGB 2
RGB / YUV AUDIO
INPUT 1
RGB / YUV AUDIO
INPUT 2
AUDIO
OUT
COMPOSITE Y/C IN AUDIO IN
VIDEO
IN OUT
RS-232 REMOTE
JACK PACK
MOUNTING HOOKS
AC IN
VENTILLATION
VENTILLATION
IR RECEIVER
MOUNTING HOOKS
JACK PACK
LOCATION
CARRyING HANDLES
