KDL-V32XBR1
BRAVIA™ XBR®Flat Panel Television
Key Features
ATSC Integrated Tuner with CableCARD™ Slot
16:9 HD Resolution S- PVA Panel -1366(H) x 768(V)
WEGA Engine™System
WCG-CCFL (Wide Color Gamut-CCFL) backlight
WEGA GATE™-Easy Operation Guide
PC Input
HDMI™(High Definition Multimedia Interface) Connector
S - Master ® Digital Amplifier
SRS ® TruSurround® XT Equipped
Key Technologies
7th Generation Sony®LCD Panel The Sony
® BRAVIA ™ XBR ® series uses the world’s first 7th
generation Sony LCD panel for truly matchless image quality and performance. Specially crafted at the S- LCD
plant, these panels are produced from the world’s biggest mother glass to efficiently create large, high quality
panels. The 1 Mega Pixel S-PVA high definition display (1366 x 768) that is used offers an astounding 178
degree viewing angle, very fast response times (8 ms total rise and fall time) and a spectacular contrast ratio.
WCG-CCFL (Wide Color Gamut-Cold Cathode Fluorescent Light) Sony brings decades of television
expertise and experience to LCD with a revolutionary backlight ? WCG-CCFL. New spectrum phosphors have
been developed exclusively by Sony to deliver a very wide color gamut that exceeds the color gamut of
ordinary CCFL backlights and produces true reds, vivid greens and vibrant blues. Images are reproduced with
enhanced vibrancy and intensity resulting in an even greater sense of realism.
WEGA Engine™Because of the special demands HDTV places on signal quality a new generation of Sony’s
exclusive WEGA Engine™advanced picture quality system has evolved. Two innovative digital imaging
processes have been added to improve overall picture quality. A High Contrast Image processor dynamically
detects the histogram of each frame and instantly applies the ideal contrast level for crisper images. And the
Natural High Density Picture image processor reduces noise elements by intelligently separating the noise
from the video signal for a purer more detailed picture. Enjoy a stunning display of realistic images, amazing
detail and sharpness, reduced noise and enhanced clarity with improved depth and contrast.
WEGA GATE®User Guide Explore and navigate your Sony “
BRAVIA ”television effortlessly with the WEGA
GATE user guide. You can easily change your settings or access your favorite TV channels and external
inputs. Simply touch the WEGA GATE button on the remote control to activate the comprehensive graphic
menu. Your eyes remain on the screen instead of searching in the dark for tiny buttons on the remote control.

KDL-V32XBR1
BRAVIA™ XBR®Flat Panel Television
Sony Electronics Inc. • 16530 Via Esprillo Drive • San Diego, CA 92127 • 1-800-222-7669 • www.sony.com
Last Updated: 12/04/2005
Please visit the Dealer Network for current
information at www.sony.com/dn
Features
General
Auto SAP:
Yes
Closed Caption (CC): Yes
ID1 Detection: Yes
Video Label: Yes
Clean Wire Management: Yes
Video
Screen or Display Technology:
7th Generation
LCD Panel
Tuner: 8 VBS, ATSC, NTSC, Clear QAM
Video Signal System: ATSC, NTSC
Video Processing:
WEGA Engine ™ Technology
Color Temperature:
Cool, Neutral, Warm 1,
Warm 2
Color Correction: Yes
Noise Reduction: Yes
Black Corrector:
High, Medium, Low, Off
Clear White:
High, Low, Off
Color Space: Wide, Normal
Gamma Compensation: Max, High, Medium,
Low, Off
Live Color:
High, Medium, Low, Off
CineMotion ® Reverse 3:2 Pulldown
Technology: Yes
Contrast Enhancer:
High, Low, Off
Direct Digital II Circuitry: Yes
Screen Modes (4:3):
Wide Zoom, Normal, Full,
Zoom, Off
Wide Mode (16:9):
Wide Zoom, Full, Zoom
Wide Mode (4:3):
Wide Zoom, Normal, Full, Zoom
Wide Mode (PC):
Normal, Full, Full 2, Zoom, Off
Slide Show Mode:
Slide Show transitions
Display Mode for PC Input:
Video, Text
Comb Filter:
3D Digital Comb Filter
DRC ® MultiFunction Circuitry: Yes (DRC MF
V1)
DRC ® Mode: Yes
DRC ® Palette Presets: Yes
Game Mode: On/Off
Auto Adjustment (PC): Yes
Phase (PC Only): Yes
Pitch (PC Only): Yes
Light Sensor: Yes
Advanced Video Menu: Yes
Picture Modes: Vivid, Standard, Custom;
Audio
Tone Control(s): Treble and Bass
Sound Mode: Dynamic, Standard, Custom
MTS Stereo Decoder: Yes
A/V Synch: Off/1/2/3
Digital Amplifier: S-Master
® Digital Amplifier
Audio Mute: Yes
Speaker On/Off: Yes
Simulated Surround: Yes
SRS ® TruSurround ® XT Audio Effect: Yes
Convenience
Channel Caption: Yes
Channel Label: Yes
Channel Skip/Add: Yes
Channel Jump: Yes
Favorite Channel: Yes
Speed Surf™ Channel Selection: Yes
WEGA GATE™ Technology: Yes
Scrolling Channel Index ® System: Yes
Program Guide Access: Yes
Auto Channel Programming: Yes
Menu Color: Yes
Multiple Language Display:
English, Espa ñ ol,
Fran ç ais
Parental Control (V - Chip): Yes
Freeze Memo Screen Freeze:
Yes (with side
by side viewing)
Mode Memory: Yes
Info Banner: On/Off
Programmable Timer: Yes
Sleep Timer:
15, 30, 45, 60, 90, Off
Timer Events:
Timer 1, Timer 2
Caption Vision:
Basic, Digital CC, Advanced,
Clock: Yes
Power Save Mode: Standard, Reduced, Picture
Off
Built - in AC Adaptor: Yes
Specifications
General
Aspect Ratio:
16:9
Screen Size:
32"
Video
Native Resolution:
720p
Contrast Ratio:
1300:1
Display Resolution:
1366 x 768
Overscan: Normal, -
1, - 2
Viewing Angle:
Right/Left: 178 ° , Up/Down: 178 °
Display Response Time: 8 msec
Vertical Size: Yes
Vertical Center: Yes
Horizontal Center: Yes
Brightness:
Typical 480 cd/m
Audio
Speaker Type:
2 -way Speakers, Oval Cone
Speakers (Total):
4
Tweeter Size:
1 4/7" (40mm)
Full Range Speaker Size:
40 x 100 mm Oval
Audio Power Output:
26W Total (13W x 2)
Convenience
Stand Tilt Range: Forward 3
° / Back 8 °
Stand Swivel Range:
L/R: 30 °
Inputs and Outputs
Analog Audio Input(s):
6 (1 Front/5 Rear)
Audio Out (Variable/Fixed): 1 (Rear)
CableCARD™ Slot: 1 (Rear)
Component Video (Y/Pb/Pr ) Input(s):
3 (1
Front/2 Rear) 480i, 480p, 720p, 1080i
Composite Video Input(s):
3 (1 Front/2 Rear)
Digital Audio Output(s):
Dolby ® Digital Optical
Output -1 (Rear)
HDMI ™ Connection Input(s):
1 (Rear) with
Analog Audio
RF Connection Input(s): 2 (Rear)
1
2
S - Video Input(s): 1 (Rear)
Headphone Output(s):
1 (Front)
PC Audio Input(s): 1 (Rear)
PC Video Input(s): 1 (Rear)
Power
Internal Power Supply: Yes
Power Consumption (in Operation):
166 W
Power Consumption (in Standby):
Less than
0.15 W
Power Requirements:
AC 120 - 240V, 50/60Hz
Power Management: Yes (for PC Input Only)
Regulation and Standard
Compliance
VESA:
VESA FDMI Compliant Mounting Holes
Service and Warranty Information
Limited Warranty: 1 Year Labor / 1 Year Parts
Dimensions
Weight:
46 lbs, 12 oz (23.7 kg) with pedestal; 38
lbs, 6 oz (19.7 kg) without pedestal
Measurements:
31 13/16 x 23 3/16 x 12
3/16" (808 x 587.8 x 309 mm) with pedestal; 31
13/16 x 21 5/8 x 4 3/8" (808 x 549.3 x 110.5 mm)
without pedestal
Supplied Accessories
Remote Control (RM - YD002)
Battery (Type AA, x2)
AC Power Cord
75 - ohm Coaxial Cable (TBD)
D15 - D15 Cable
Cable Clamper
Support Belt
Securing Screws
Operating Instructions
Quick Setup Guide
Warranty Card (SEL, SOCAN)
Leaflet (TBD)
On - line Registration Card (SEL)
Optional Accessories
Wall - Mounted Bracket (SU - WL31)
UPC Code:
027242677265
Confidential Sony Information. For Internal Use Only.
1. Screen Size measured diagonally.
